Cisco HWIC-4ESW - EtherSwitch HWIC Switch Manual

Corporate Headquarters:
Copyright © 2004 Cisco Systems, Inc. All rights reserved.
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
HWIC-4ESW, HWIC-D-9ESW, ILPM-4, and
ILPM-8 Documentation Roadmap
Updated 9/27/2004
This document provides links to resources for understanding, installing, and configuring
Cisco 10/100BASE-T Ethernet switch high-speed WAN interface cards (HWICs) and their inline power
modules. Use this document in HTML format on Cisco.com.
Products:
Note This is a platform-independent document. To see which routers support these products, refer to the
documents in the following section.
Product Information and Supported Hardware and Software
•Cisco EtherSwitch 4- and 9-Port High-Speed WAN Interface Cards for Cisco 1800 (Modular),
Cisco 2800, and Cisco 3800 Series Integrated Services Routers, data sheet
•Cisco EtherSwitch 4- and 9-Port High-Speed WAN Interface Cards for Cisco 1800 (Modular),
Cisco 2800, and Cisco 3800 Series Integrated Services Routers, Q&A
HWIC-4ESW 4-port single-wide 10/100BASE-T Ethernet switch HWIC
HWIC-D-9ESW 9-port double-wide 10/100BASE-T Ethernet switch HWIC
ILPM-4 4-port 802.3af-compliant inline power module for HWIC-4ESW
ILPM-8 8-port 802.3af-compliant inline power module for HWIC-D-9ESW
HWIC-4ESW-POE 4-port Ethernet switch HWIC with Power over Ethernet
Bundle: HWIC-4ESW with ILPM-4
HWIC-D-9ESW-POE 9-port Ethernet switch HWIC with Power over Ethernet
Bundle: HWIC-D-9ESW with ILPM-8

HWIC-4ESW, HWIC-D-9ESW, ILPM-4, and ILPM-8 Documentation Roadmap
2
OL-5577-01 Rev. B0
Regulatory Compliance and Safety Information
•Cisco Network Modules and Interface Cards Regulatory Compliance and Safety Information
Hardware Installation
See the following chapters of the Cisco Interface Cards Installation Guide:
•Installing Cisco Interface Cards in Cisco Access Routers
•Connecting Cisco 10/100BaseT Ethernet Switch High-Speed WAN Interface Cards
Interface Numbering
•Overview in the hardware installation documentation for your router
Software Configuration
•Cisco HWIC-4ESW and HWIC-D-9ESW EtherSwitch Interface Cards,
Cisco IOS Release 12.3(8)T4 feature module
