TRENDnet TFU-430 User manual

TFU-430
Quick Installation Guide

Table of Contents
Table of Contents
Version 01.23.2006
English .....................................................................................................
Troubleshooting ........................................................................................
1
1
2
3
1. Before You Start
2. Install Hardware ................................................................................
................................................................................

System Requirements
Application
TFU-430
Quick Installation Guide
USB 2.0 Cable
IEEE 1394 FireWire Cable
AC Power Adapter
PC with supported operating system
USB 1.1/2.0 port on your computer
IEEE 1394 FireWire port on your computer
Package Content
1. Before You Start
English
1
7-Port USB 2.0/FireWire Combo Hub
(TFU-430)
PC/MAC Systems
USB Keyboard
USB 2.0 (480Mbps) FireWire(400Mbps)
FireWire Digital Camera
FireWire Hard Drive
USB Mouse
USB 1.1 (12Mbps)
USB Printer
* One FireWire Port is reserved for uplink use.
* Backwards compatible
with USB 1.1 at 12Mbps

2. Install Hardware
English
2
Note: Because the TFU-430 is hot-pluggable, you can connect or disconnect
the TFU-430 while the computer is on. Although the TFU-430 is bus-powered
and therefore does not require an AC Power Adapter, it is recommended that
the included AC Power Adapter be used.
3. Connect the included USB Cable
to the Uplink Port, and then to
your computer's USB port.
2. Connect the AC Power Adapter to
the USB Hub.
4. Connect the included IEEE 1394
FireWire Cable to the TFU-430,
and then to your computer's IEEE
1394 FireWire port.
5. Connect USB and FireWire
devices to the remaining ports.
Your installation is now complete.
1. Turn on your computer and wait
until startup completes.

Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Where is the Driver CD-Rom for the TFU-430?
The TFU-430 does not require unique drivers for Windows XP/2000/ME; it
uses preinstalled FireWire drivers provided by your operating system. You must
have properly installed USB and/or FireWire ports on your computer.
Can I connect or disconnect the USB cable while the computer is on?
Yes, you can connect or disconnect the USB cable, or any external USB
device while the computer is on because the USB interface is Plug-and-Play and
hot-pluggable.
My computer has a FireWire (IEEE 1394) interface but the FireWire port
doesn't seem to work. What should I do?
You must have the FireWire Host Controller installed properly for you
computer's FireWire port to work. For more information regarding FireWire Host
Controller installation, please refer to you computer's User Manual.
My computer has a USB interface but the USB port doesn't seem to work.
What should I do?
Check that your computer's BIOS settings have USB enabled. For more
information regarding BIOS settings, please refer to your computer's User Manual.
If you still encounter problems or have any questions regarding the TFU-430, please
contact TRENDnet's Technical Support Department.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
