ABNICS FT23D User manual

ABNICS FT23D
Face Recognition Terminal
User Manual
Issue
V1.1
Date
2020-12-18

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
i
Precautions
Precautions
Fully understand this document before using this device, and strictly observe rules in this
document when using this device. If you install this device in public places, provide the tip "You
have entered the area of electronic surveillance" in an eye-catching place. Failure to correctly use
electrical products may cause fire and severe injuries. To prevent accidents, carefully read the
following context:
Symbols
This document may contain the following symbols whose meanings are described accordingly.
Symbol
Description
It alerts you to fatal dangers which, if not avoided, may
cause deaths or severe injuries.
It alerts you to moderate dangers which, if not avoided,
may cause minor or moderate injuries.
It alerts you to risks. Neglect of these risks may cause
device damage, data loss, device performance
deterioration, or unpredictable results.
It provides a tip that may help you resolve problems or
save time.
It provides additional information.
To prevent electric shocks or other dangers, keep power plugs dry and clean.
Strictly observe installation requirements when installing the device. The manufacturer shall not
be held responsible for device damage caused by users' non-conformance to these requirements.
Strictly conform to local electrical safety standards and use power adapters that are marked with
the LPS standard when installing and using this device. Otherwise, this device may be damaged.
Use accessories delivered with this device. The voltage must meet input voltage requirements for
this device.

ABNICS FT23D - Face Recognition Terminal
User Manual
ii
Issue V1.1 (2020-12-18)
If this device is installed in places with unsteady voltage, ground this device to discharge high
energy such as electrical surges in order to prevent the power supply from burning out.
When this device is in use, ensure that no water or any liquid flows into the device. If water or
liquid unexpectedly flows into the device, immediately power off the device and disconnect all
cables (such as power cables and network cables) from this device.
Do not expose the thermal imaging camera or unpacked product to extremely strong radiation
sources, such as the sun, laser, or arc welding machine, regardless of whether the device is being
electrified or not; do not put the camera close to high thermal objects such as the sunlight;
otherwise, the precision of the camera may be affected and even the detector inside the camera
may suffer a permanent damage.
If this device is installed in places where thunder and lightning frequently occur, ground the
device nearby to discharge high energy such as thunder strikes in order to prevent device damage.
Unless otherwise specified, do not use the camera in a temperature lower than 0 °C (32°F) or
higher than +50 °C (+122 °F). Too-high or too-low temperature may cause image display
anomaly of the camera and the camera will be damaged if it is working under such a condition
for a long time.
If the camera is installed outdoors, avoid direct sunlight at dawn and dusk on the camera lens and
install a sunshield with frontal and rear positions adjusted according to the sunlight angle.
Avoid heavy loads, intensive shakes, and soaking to prevent damages during transportation and
storage. The warranty does not cover any device damage that is caused during secondary
packaging and transportation after the original packaging is taken apart.
Protect this device from fall-down and intensive strikes, keep the device away from magnetic
field interference, and do not install the device in places with shaking surfaces or under shocks.
Clean the device with a soft dry cloth. For stubborn dirt, dip the cloth into slight neutral cleanser,
gently wipe the dirt with the cloth, and then dry the device.
Since the camera lens is painted with a durable coating material, it adapts to outdoor environment.
The lens must be cleaned regularly. If the image quality is reduced or excessive dirt is deposited
on the lens, clean the lens in a timely manner. In sandy (in desert) or corrosive (on sea)
environment, use the camera with caution; improper use may cause the coating to peel off.
Do not jam the ventilation opening. Follow the installation instructions provided in this
document when installing the device.
Keep the device away from heat sources such as radiators, electric heaters, or other heat
equipment.
Keep the device away from moist, dusty, extremely hot or cold places, or places with strong
electric radiation.
If the device is installed outdoors, take insect- and moisture-proof measures to avoid circuit
board corrosion that can affect monitoring.
Remove the power plug if the device is idle for a long time.
Before unpacking, check whether the fragile sticker is damaged. If the fragile sticker is damaged,
contact customer services or sales personnel. The manufacturer shall not be held responsible for
any artificial damage of the fragile sticker.

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
iii
Special Announcement
All complete products sold by the manufacturer are delivered along with nameplates, operation
instructions, and accessories after strict inspection. The manufacturer shall not be held
responsible for counterfeit products.
This manual may contain misprints, technology information that is not accurate enough, or
product function and operation description that is slightly inconsistent with the actual product.
The manufacturer will update this manual according to product function enhancement or changes
and regularly update the software and hardware described in this manual. Update information
will be added to new versions of this manual without prior notice.
This manual is only for reference and does not ensure that the information is totally consistent
with the actual product. For consistency, see the actual product.

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
1
Contents
Precautions.................................................................................................................... i
Contents........................................................................................................................ 1
1 Hardware Description............................................................................................. 3
1.1 Product Features............................................................................................................. 3
1.2 Unlock Insturctions........................................................................................................ 4
1.3 Appearance Instructions and Cable description.............................................................. 5
1.4 Requirement of Use........................................................................................................ 8
1.5 Dimensions..................................................................................................................... 8
1.6 Installation and Precaution........................................................................................... 10
1.7 Packaging and instrctions............................................................................................. 16
2 Quick Configuration ............................................................................................. 17
2.1 System Login and Logout ............................................................................................ 17
2.2 Modify the Password.................................................................................................... 19
2.3 Preview Interface.......................................................................................................... 21
2.3.1 Download VLC................................................................................................ 21
2.3.2 Live Video Interface......................................................................................... 22
3 Configuration Setting ........................................................................................... 23
3.1 Basic Information......................................................................................................... 23
3.2 System Setting.............................................................................................................. 23
3.2.1 Time configuration........................................................................................... 23
3.2.2 Logo Settings................................................................................................... 24
3.2.3 User Management ............................................................................................ 25
3.2.4 System Parameters........................................................................................... 27
3.3 Communication Settings .............................................................................................. 29
3.3.1 TCP/IP.............................................................................................................. 29
3.3.2 Device Port Configuration ............................................................................... 29
3.4 Video Settings .............................................................................................................. 30
3.5 Image Settings.............................................................................................................. 31
3.5.1 Display Settings ............................................................................................... 31
3.6 Alarm............................................................................................................................ 33
3.6.1 Alarm Linkage IO Output ................................................................................ 33

ABNICS FT23D - Face Recognition Terminal
User Manual
2
Issue V1.1 (2020-12-18)
3.6.2 Alarm Linkage Email....................................................................................... 33
3.6.3 Alarm Input...................................................................................................... 34
3.7 Network Service........................................................................................................... 35
3.7.1 Upload Service................................................................................................. 35
3.7.2 SMTP............................................................................................................... 35
3.8 UI & Sound Settings .................................................................................................... 36
3.9 Temperature Parameters............................................................................................... 41
3.10 Access Condition........................................................................................................ 42
3.11 System Maintenance................................................................................................... 44
3.11.1 Upgrade and Maintenance.............................................................................. 44
3.11.2 Thermometer Upgrade.................................................................................... 46
4 Face Database ......................................................................................................... 47
4.1 Add Face ...................................................................................................................... 47
5 Capture History...................................................................................................... 50

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
3
1Hardware Description
1.1 Product Features
Based on self-developed AI chip, with the support of powerful computing power and face
recognition algorithms, temperature measurement face recognition terminals are designed to
detect skin-surface temperatures, and can thus be used for rapid and preliminary fever screening
in office buildings; New face recognition system for identifying whom are people wearing masks,
granting access only to verified personnel and eliminating possible fraudulent activities.
Advantages
Proximity wake-up activation: the device is automatically activated when a person
approaches.
7-inch IPS HD screen: displays the software interface, operation guidance and face frame.
Performs real-time face detection (supports local video preview).
million pixel binocular wide angle camera.
Anti-fake function for pictures and videos.
Temperature measuring distance: 0.5 to 1.2 m, response speed: ≤100ms
Face recognition distance: 0.3 to 2.0 m.
Use of deep learning algorithms to support a capacity of 30,000 faces. Fast recognition
with a higher recognition rate.
Storage of up to 60,000 events.
Multiple authentication methods.
Facial comparison time ≤ 0.2 s/person. Recognition rate ≥ 99.8%.
Support for importing of card and facial data to devices through TCP/IP transmission.
Uploading of data through the internet.
Uploading of comparison results and interconnected snapshots to the platform for storage.
Personnel information can be sent down from the platform or uploaded from local devices.
Stand-alone operation in offline mode.
Local login for managing, searching and configuring device parameters.

ABNICS FT23D - Face Recognition Terminal
User Manual
4
Issue V1.1 (2020-12-18)
1.2 Unlock Insturctions
Face recognition terminal can control the lock of door through the multi cable connect to system,
in the retention of existing access control system function of the colleague, the access control
intelligent operation upgrade.
If 1.0 mm standard wire is used, 12V switching power supply is used, and the wiring distance from the
site construction (switching power to equipment distance) does not exceed 20 m.
If 1.5 mm standard cable is used, 12V switching power supply is used, and the wiring distance from
the site construction (switching power to equipment distance) does not exceed 30 m.
If 2.0 mm standard wire is used, 12V switching power supply is used, and the wiring distance
(switching power to the equipment distance) is not more than 40 m.

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
5
1.3 Appearance Instructions and Cable description
Figure 1-1 Appearance Instructions

ABNICS FT23D - Face Recognition Terminal
User Manual
6
Issue V1.1 (2020-12-18)
Figure 1-2 Multi cable
1
2
3
4
5
6
7
8
Different device may have different multi-head cable, please refer to actual products.
Table 1-1 Cable description
ID
Description
Description
Remarks
1RJ45
Network port
Connect to Ethernet
Not support POE
2POWER
Power
Connect to DC 12V
3GATE
COM
Connect to Access control’s
COM
Access control port
When the door lock is not
triggered, COM-NC is
short-circuited and NO is
NC
Connect to Access control’s
COM NC

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
7
NO
Connect to Access control’s
NO
suspended;
COM-NO is short-circuited
when the door lock is
triggered; NC is suspended;
4USB
USB port
Connect to USB ID reader.
5ALARM-
IN
1
Connect to alarm device line 1
Alarm IN
2
Connect to alarm device line 2
3
Connect to alarm device line 3
G
GND
6ALARM-
OUT
-
Alarm out COM, negative
Alarm OUT
+
Alarm out, positive
7GATE
/485
G
GND
P
Connect to alarm light negative
The positive of alarm light
need be connected to DC 12
V, or connected to 8 WG-
I/O 12 V port
A
RS485 port A(+)
RS485 port
B
RS485 port B(-)
8WG-I/O
12V
DC 12V
Wiegand IN/OUT port
G
GND
D0
Wiegand data port 0
D1
Wiegand data port 1
The detail of connection is shown in Figure 1-3.

ABNICS FT23D - Face Recognition Terminal
User Manual
8
Issue V1.1 (2020-12-18)
Figure 1-3 Multi cable connection diagram
1.4 Requirement of Use
To ensure the measurement accuracy, please install the devices indoors, with 20~35℃(68-95℉)
ambient temperature.
No other obvious heat source around
No cover on forehead
It is recommended to start measure temperature after 30 minutes being powered on.
Please wait for 2-3 minutes before measuring temperature when coming from outdoors or other
environment with large temperature difference.
The temperature can be measured in real time by aiming the human face at measurement area on
the panel, and trigger high temperature alarm.
1.5 Dimensions
Different device may have different dimensions, please refer to the actual products.

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
9
Figure 1-4 Dimensions (unit: mm)

ABNICS FT23D - Face Recognition Terminal
User Manual
10
Issue V1.1 (2020-12-18)
1.6 Installation and Precaution
Figure 1-5 Accessories description
Position of opening hole：
The diameter of the steel plate opening is 34 mm, the specific position depends on the
situation. When the all-in-one is installed in the factory configuration, the elevation
angle is about 5°.
Figure 1-6 Position of opening hole
Table 1-2 Installing distance
Distance between person and device
Recognizable height range
55 cm
150~185 cm
60 cm
145~190 cm
Position of opening hole
Entrance

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
11
65 cm
140~195 cm
Distance between person and device
Recognizable height range
65 cm
130~185 cm
75 cm
130~190 cm
85 cm
130~195 cm
Place at an elevation without adding a column
Place at an elevation with adding a column
Procedure of installing at the gate:
Drill a hole with the diameter is 34mm on the gate machine according to Table 1-2 (Figure 1);
Remove the nut on the column of the integrated machine, and pass the threaded section of the
column through the hole (Figure 2);
Screw the column nut onto the threaded section of the column, and use a wrench or other tools
to tighten the nut (Figure 3);
Connect the corresponding functions’ cable to multi cable, and the installation is completed
(Figure 4);

ABNICS FT23D - Face Recognition Terminal
User Manual
12
Issue V1.1 (2020-12-18)
Figure 1-7 Fix steel plate
1 2
34

ABNICS FT23D - Face Recognition Terminal
User Manual
Issue V1.1 (2020-12-18)
13
Instruction of wall mounting ：
When mounting on the wall, user can choose to drill hole on wall, or no drill hole, the
accessory is optional following with the different installment.
53
9
28.75
44.75
15
19
36
35
32.75
4-φ5
68.1
4.1
4-φ3.5
12.1
32
25
80.2
The installation method is to first install the wall hanging brackets on the wall and the device
respectively, and then fit the bracket of the all-in-one machine and the wall hanging brackets,
as shown in Figure 1-8.

ABNICS FT23D - Face Recognition Terminal
User Manual
14
Issue V1.1 (2020-12-18)
Figure 1-8 Wall mounting (drill thepassing cables hole)
Wall bracket’s
tray
Groove
Insert completed
Lock screw
Drill holes (56 X 36 mm) on the wall as the dimensions of the wall bracket, insert the rubber
plug into the hole, and reserve a cable hole on the wall;
Fix the wall mount bracket to the wall plug with 4 self-tapping screws, and first pass the
equipment wire through the wall mount bracket into the reserved hole on the wall;
When the camera falls from the top, insert the tray of the bracket into the groove on the back of
the camera;
