ACTi ACM-4100 series User manual

IP Indoor Cube Camera
ACM-4100 series
Ver. 080918
Quick Installation Guide

0-1
0Getting Started
1.1 PACKAGE CONTENTS
ACM-4100 series Power Adaptor (Option)
Product CD Camera Stand
Warranty Card
1

0-2
1.2 PHYSICAL DESCRIPTION
1. Action LED Indicator
The LED will light up after IP camera has successfully completed
the boot process
2. Microphone Input
Sensitivity: -44dB(0dB=1Vpp at 1KHz)
S/N Ratio: More than 58dB
Directivity: Omni directional

0-3
3. Power Input
If your power input is DC3.3V.
4. Reset Button
Step 1: Switch off IP Indoor Cube Camera by disconnecting the
power cable
Step 2: Press and continue to hold the Reset Button. Reconnect
the power cable while continuing to hold the reset button.
Step 3: Keep holding the reset button depressed around 6 seconds,
release the reset button. The unit will start up with factory default
settings.
5. Audio Output
The IP Indoor Cube Camera supports audio output with earphone
jack
6. Ethernet Port
The IP Indoor Cube Camera connects to the Ethernet via a
standard RJ45 connector. Supporting NWAY, this IP Indoor Cube
Camera can auto detect the speed of local network segment
(10Base-T/100Base-TX Ethernet).

0-4
1.3 BASIC CONNECTIONS
Follow the procedures below to connect the IP Indoor Cube Camera to the
respective apparatuses.
1. Connect the power adaptor to IP Indoor Cube Camera
2. Connect IP Indoor Cube Camera’s ethernet port to an Ethernet (RJ45
connectors). If your IP Indoor Cube Camera has PoE built-in, you can
regard it as a PD and connect it directly to a PSE device like PoE switch.
3. Connect a PC to the Ethernet hub (RJ45 connectors)
1
NOTE: You may find a support package for help you getting familiar
with PoE. Please visit our web site, and get the support document
TS-00040.

1-5
1Quick Tour
This section guides you with a quick tour on this IP Indoor Cube Camera.
2.1 Configure this IP Indoor Cube Camera
2.1.1 Make sure network environment
Default IP of this IP Indoor Cube Camera is 192.168.0.100. Please make sure this IP
Indoor Cube Camera and your PC are on the same network segment before running
the installation.
2
Please set the settings as below.
IP address: 192.168. 0.xxx
Subnet mask: 255.255.255. 0
(NOTE: xxx should be a number
from 1 to 254, but 100 is
excepted.)

1-6
2.1.2 Open Internal Explorer with IP address
NOTE: If your web browser is earlier than IE6, then download IE6 is
recommended.
NOTE: This IP Indoor Cube Camera default IP address is set to
192.168.0.100
2.1.3 Login with default administrator’s account & password
NOTE: Default administrator account is set to Admin, password is set to
123456, and click button.

1-7
2.1.4 Preview the video
2.1.5 Set the new IP address

1-8
*IP Address : The default IP address is 192.168.0.100.
*Subnet Mask : The default subnet mask is 255.255.255.0
*Click button
NOTE: In your Client PC, please make sure the setting of Network
Connections Type is set to Auto Negotation, since this IP Indoor Cube
Camera follows MII standard. Otherwise, you might not see the live
image.
IMPORTANT: After the IP address is changed, please record this IP
address. There’s no way to connect to the IP Indoor Cube Camera if user
forgets the new IP address.
2.1.6 Check Default Video Setting
NOTE: Please make sure the TV Input (NTSC / PAL) is meet your
requirement, and click button.
2.1.7 Click Save Reboot to restore all settings and please wait about 30 seconds
for system reboot.

1-9
