Adaptec AWN-8084 User manual

R
Adaptec Ultra WirelessTM
Router
User’s Guide

ii
Copyright
© 2002 Adaptec, Inc. All rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted in any form or by any
means, electronic, mechanical, photocopying, recording or otherwise, without the
prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
Trademarks
Adaptec, the Adaptec logo, and Ultra Wireless are trademarks of Adaptec, Inc.,
which may be registered in some jurisdictions.
Windows 98SE, Windows Me, Windows 2000, and Windows XP, are trademarks of
Microsoft Corporation in the US and other countries, used under license.
All other trademarks are the property of their respective owners.
Changes
The material in this document is for information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, Adaptec, Inc. assumes no liability resulting from
errors or omissions in this document, or from the use of the information contained
herein.
Adaptec reserves the right to make changes in the product design without
reservation and without notification to its users.
Disclaimer
IF THIS PRODUCT DIRECTS YOU TO COPY MATERIALS, YOU MUST HAVE
PERMISSION FROM THE COPYRIGHT OWNER OF THE MATERIALS TO AVOID
VIOLATING THE LAW WHICH COULD RESULT IN DAMAGES OR OTHER
REMEDIES.

iii
Adaptec Technical Support
If you have questions about installing or using your Adaptec product, check this document
first—you will find answers to most of your questions here. If you need further assistance, use
the support options listed below.
Technical Support Identification (TSID) Number
■Before contacting Technical Support, you need your unique 12-digit TSID number. The TSID
number identifies your product and support status.
■The TSID number is included on two white, bar-coded labels, like the example below.
Support Options
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.com for articles,
troubleshooting tips, and frequently asked questions for your product.
■For support via Email, submit your question to Adaptec's Technical Support Specialists at
ask.adaptec.com.
■To order Adaptec products, including accessories and cables, call [phone]. Or, you
can order cables online at www.adaptec.com/buy-cables.
Europe
■Visit our Web site at www.adaptec-europe.com.
■German and English: Search the Adaptec Support Knowledgebase (ASK) at
ask-de.adaptec.com for articles, troubleshooting tips, and frequently asked questions for
your product.
For support via e-mail, submit your question to Adaptec's Technical Support Specialists at
ask-de.adaptec.com.
■French: Search the Adaptec Support Knowledgebase (ASK) at ask-fr.adaptec.com for articles,
troubleshooting tips, and frequently asked questions for your product.
For support via e-mail, submit your question to Adaptec's Technical Support Specialists at
ask-fr.adaptec.com.
■To order Adaptec products, including accessories and cables,
go to www.adaptec.com/buy-cables.
Australia and New Zealand
■Visit our Web site at www.adaptec.com.au.
■For support via e-mail, submit your question to Adaptec's Technical Support Specialists at
ask.adaptec.com.
Hong Kong and China
■Visit our Web site at www.adaptec.com.
■Fax Technical Support at [phone].
Singapore
■Visit our Web site at www.adaptec.com.
Japan
■Search the Adaptec Support Knowledgebase (ASK) at ask.adaptec.co.jp
■Visit our Web site at www.adaptec.co.jp.

iv
Limited 2-Year Hardware Warranty
1. Adaptec, Inc. (“Adaptec”) warrants to the purchaser of this product that it will be free from
defects in material and workmanship for a period of two (2) years from the date of purchase.
If the product should become defective within the warranty period, Adaptec, at its option,
will repair or replace the product, or refund the purchaser’s purchase price for the product,
provided it is delivered at the purchaser’s expense to an authorized Adaptec service facility
or to Adaptec.
2. Repair or replacement parts or products will be furnished on an exchange basis and will
either be new or reconditioned. All replaced parts or products shall become the property of
Adaptec. This warranty shall not apply if the product has been damaged by accident,
misuse, abuse or as a result of unauthorized service or parts.
3. Warranty service is available to the purchaser by delivering the product during the warranty
period to an authorized Adaptec service facility or to Adaptec and providing proof of
purchase price and date. The purchaser shall bear all shipping, packing and insurance costs
and all other costs, excluding labor and parts, necessary to effectuate repair, replacement or
refund under this warranty.
4. For more information on how to obtain warranty service, write or telephone Adaptec at 691
South Milpitas Boulevard, Milpitas, CA 95035, [phone].
5. THIS LIMITED WARRANTY DOES NOT EXTEND TO ANY PRODUCT WHICH HAS
BEEN DAMAGED AS A RESULT OF ACCIDENT, MISUSE, ABUSE, OR AS A RESULT OF
UNAUTHORIZED SERVICE OR PARTS.
6. THIS WARRANTY IS IN LIEU OF ALL OTHER EXPRESS WARRANTIES WHICH NOW
OR HEREAFTER MIGHT OTHERWISE ARISE RESPECT TO THIS PRODUCT. IMPLIED
WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE AND NON-INFRINGEMENT SHALL (A) HAVE NO GREATER
DURATION THAN 2 YEARS FROM THE DATE OF PURCHASE, (B) TERMINATE
AUTOMATICALLY AT THE EXPIRATION OF SUCH PERIOD AND (C) TO THE EXTENT
PERMITTED BY LAW BE EXCLUDED. IN THE EVENT THIS PRODUCT BECOMES
DEFECTIVE DURING THE WARRANTY PERIOD, THE PURCHASER’S EXCLUSIVE
REMEDY SHALL BE REPAIR, REPLACEMENT OR REFUND AS PROVIDED ABOVE.
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING WITHOUT LIMITATION
LOSS OF DATA, ARISING FROM BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ARE NOT THE RESPONSIBILITY OF ADAPTEC AND, TO THE EXTENT PERMITTED BY
LAW, ARE HEREBY EXCLUDED BOTH FOR PROPERTY DAMAGE, AND TO THE
EXTENT NOT UNCONSCIONABLE, FOR PERSONAL INJURY DAMAGE.
7. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, AND SOME STATES
DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO
THE ABOVE LIMITATION OR EXCLUSIONS MAY NOT APPLY TO YOU.
8. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.

v
Adaptec Software License Agreement
PLEASE READ CAREFULLY: THE USE OF THIS SOFTWARE IS SUBJECT TO THE SOFTWARE
LICENSE TERMS OF ADAPTEC, INC. AND OTHER LICENSORS WHOSE SOFTWARE MAY
BE BUNDLED WITH THIS PRODUCT.
BY YOUR USE OF THE SOFTWARE INCLUDED WITH THIS PRODUCT YOU AGREE TO THE
LICENSE TERMS REQUIRED BY THE LICENSOR OF THAT SOFTWARE, AS SET FORTH
DURING THE INSTALLATION PROCESS. IF YOU DO NOT AGREE TO THE LICENSE
TERMS APPLICABLE TO THE SOFTWARE, YOU MAY RETURN THE ENTIRE UNUSED
PRODUCT FOR A FULL REFUND.
In return for acquiring a license to use the Adaptec software (“Software”) and the related
documentation, you agree to the following terms and conditions:
1. License. This Agreement grants you, the Licensee, a license to:
a. Use the Software on a single computer system or on multiple workstations, systems and
servers which incorporate an Adaptec RAID controller and may be accessed by multiple
users from multiple locations. You may make as many installations of the Software as
needed, but must restrict such installation only to systems, workstations or servers
using an Adaptec RAID controller.
b. Make one copy of the Software in machine readable form solely for back-up purposes
provided you reproduce Adaptec’s copyright notice and any proprietary legends.
2. Restrictions. You may not distribute copies of the Software to others. You may not post or
otherwise make available the Software, or any portion thereof, in any form, on the Internet.
You may not use the Software in a computer service business, including in time sharing
applications. The Software contains trade secrets and, in order to protect them, you may not
decompile, reverse engineer, disassemble, or otherwise reduce the Software to a human-
perceivable form. YOU MAY NOT MODIFY, ADAPT, TRANSLATE, RENT, LEASE, LOAN,
RESELL FOR PROFIT, DISTRIBUTE, NETWORK OR CREATE DERIVATIVE WORKS
BASED UPON THE SOFTWARE OR ANY PART THEREOF.
3. Ownership of Software. As Licensee, you own the media upon which the software is
recorded or fixed, but Adaptec and its licensors retain title and ownership of the Software
recorded on the original media and all subsequent copies of the Software, regardless of the
form or media in which or on which the original and other copies may exist. This license is
not a sale of the Software or any copy.
4. Confidentiality. You agree to maintain the Software in confidence and that you will not
disclose the Software to any third party without the express written consent of Adaptec. You
further agree to take all reasonable precautions to preclude access of unauthorized persons
to the Software.
5. Term. This license is effective until January 1, 2045, unless terminated earlier. You may
terminate the license at any time by destroying the Software (including the related
documentation) together with all copies or modifications in any form. Adaptec will have the
right to terminate our license immediately if you fail to comply with any term or condition
of this Agreement. Upon any termination, including termination by you, you must destroy
the Software (including the related documentation), together with all copies or
modifications in any form.
6. Special Terms Applicable to Databases. Where a database is included with the Software, you
acknowledge that it is licensed only in connection with the use of the Software to perform
disc creation, and that the database and all data derived therefrom must be maintained in
confidence in accordance with the provisions of Section 4. This license does not grant you
any rights to distribute or disclose such database or data.

vi
7. Limited Warranty. Adaptec and its Licensor warrant only that the media upon which the
Software is furnished will be free from defects in material or workmanship under normal
use and service for a period of thirty (30) days from the date of delivery to you. ADAPTEC
AND ITS LICENSORS DO NOT AND CANNOT WARRANT THE PERFORMANCE OR
RESULTS YOU MAY OBTAIN BY USING THE SOFTWARE OR DOCUMENTATION. THE
FOREGOING STATES THE SOLE AND EXCLUSIVE REMEDIES ADAPTEC AND ITS
LICENSORS WILL PROVIDE FOR BREACH OF WARRANTY. EXCEPT FOR THE
FOREGOING LIMITED WARRANTY, ADAPTEC AND ITS LICENSORS MAKE NO
WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED, AS TO
NON-INFRINGEMENT OF THIRD PARTY RIGHTS, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow the exclusion of implied
warranties or limitations on how long an implied warranty may last, so the above
limitations may not apply to you. This warranty gives you specific legal rights and you may
also have other rights which vary from state to state.
8. The entire liability of Adaptec and its licensors, and your exclusive remedy for a breach of
this warranty, shall be:
a. The replacement of any media not meeting the above limited warranty which is
returned to Adaptec; or:
b. If Adaptec or its distributor is unable to deliver replacement media which is free from
defects in materials or workmanship, you may terminate this Agreement by returning
the Software and your money will be refunded.
9. Limitation of Liability. IN NO EVENT WILL ADAPTEC OR ITS LICENSORS BE LIABLE TO
YOU FOR ANY INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES,
INCLUDING ANY LOST PROFITS, LOST SAVINGS, OR LOSS OF DATA, EVEN IF
ADAPTEC OR A LICENSOR HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY. Some states do not allow the
exclusion or limitation of special, incidental, or consequential damages, so the above
limitation or exclusion may not apply to you.
10. Export. You acknowledge that the laws and regulations of the United States and other
countries may restrict the export and re-export of the Software. You agree that you will not
export or re-export the Software or documentation in any form in violation of applicable
United States and foreign law.
11. Government Restricted Rights. The Software is subject to restricted rights as follows. If the
Software is acquired under the terms of a GSA contract: use, reproduction or disclosure is
subject to the restrictions set forth in the applicable ADP Schedule contract. If the Software is
acquired under the terms of a DoD or civilian agency contract, use, duplication or disclosure
by the Government is subject to the restrictions of this Agreement in accordance with 48
C.F.R. 12.212
of the Federal Acquisition Regulations and its successors and
49 C.F.R. 227.7202-1
of the DoD FAR Supplement and its successors.
12. General. You acknowledge that you have read this Agreement, understand it, and that by
using the Software you agree to be bound by its terms and conditions. You further agree that
it is the complete and exclusive statement of the agreement between Adaptec and you, and
supersedes any proposal or prior agreement, oral or written, and any other communication
between Adaptec and you relating to the subject matter of this Agreement. No additional or
any different terms will be enforceable against Adaptec unless Adaptec gives its express
consent, including an express waiver of the terms of this Agreement, in writing signed by an
officer of Adaptec. You assume full responsibility for the use of the Software and agree to
use the Software legally and responsibly. This Agreement shall be governed by California
law, except as to copyright matters, which are covered by Federal law. This Agreement is
deemed entered into at Milpitas, California by both parties. Should any provision of this
Agreement be declared unenforceable in any jurisdiction, then such provision shall be
deemed severable from this Agreement and shall not affect the remainder hereof. All rights
in the Software not specifically granted in this Agreement are reserved by Adaptec.
Should you have any questions concerning this Agreement, you may contact Adaptec by
writing to:
Adaptec, Inc.
Legal Department
691 South Milpitas Boulevard
Milpitas, California 95035.

vii
Regulatory Compliance Statements
Federal Communications Commission Radio Frequency Interference Statement
WARNING: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between equipment and receiver.
■Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
■Consult the dealer or an experienced radio/television technician for help.
You are cautioned that changes or modifications not expressly approved by the part responsible
for compliance could void your authority to operate the equipment.
Federal Communications Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 cm
between the radiator and your body.
CE Mark Warning
This is a Class B product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
Canadian Compliance Statement
This Class B digital apparatus meets all requirements of the Canadian Interference-
Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur
le matériel brouilleur du Canada.
Adaptec, Inc. AWN-8084
Tested to Comply
With FCC Standards
FOR HOME OR OFFICE USE

1
In this Guide
Introduction 2
Getting to Know Your Wireless Router 3
Installation Task List 8
Before You Begin... 9
Choosing a Router Setup 10
Installing Your Wireless Router 12
Setting Up Your Network Stations 21
Understanding the Web-based Wireless Router Utility 22
Configuring Your Wireless Router 25
Managing Your Wireless Router 31
Changing the Setup of Your WLAN 38
Using the Advanced Router Functions 48
Troubleshooting 58
Technical Specifications 62
Glossary 63

2
Introduction
Introduction
This User’s Guide provides detailed instructions for installing and
configuring your Adaptec Wireless Router as part of a Local Area
Network (LAN) and/or Wireless LAN (WLAN).
This Guide assumes you have a working knowledge of your
computer and that you are familiar with the Windows operating
system. It also assumes you have basic knowledge of wireless
technology, routers, networks, and Local Area Networks (LANs).
Kit Contents
Your Ultra Wireless Router kit includes:
■Adaptec AWN-8084 Ultra Wireless Router
■Ethernet straight-through cable
■Power adapter
■Wireless Router CD, which contains documentation
■Adaptec Ultra Wireless Router Quick Start Guide
System Requirements
To complete the installation of your Wireless Router, you must have:
■A PC-compatible computer with:
■Windows®98SE, Windows Me®, Windows 2000®, or
Windows XP®
■Microsoft Internet Explorer 5 or later, or Netscape® V4.7 or
later
■ Ethernet adapter and appropriate TCP/IP protocols installed
■Ethernet-based broadband Internet connection (Ethernet
modem or receiver)
To connect with your Wireless Router, each computer station must
be installed with:
■An Ethernet or wireless network adapter
■The TCP/IP protocols for that adapter

3
Getting to Know Your Wireless Router
Getting to Know Your
Wireless Router
With your Wireless Router you can create a network with any
combination of wired and wireless stations:
Your Wireless Router provides network enhancements such as
Internet access control, network security, and the two-way
application support required by instant messaging, online gaming,
and similar applications.
See Choosing a Router Setup on page 10 for more information about
installing your Wireless Router.
Wireless stations only—
Wireless Local Area
Network (WLAN)
Wired stations only—
Local Area Network
(LAN)
Computers with wireless network adapters.
Computers with wired
network adapters.
Wireless and wired
stations—
WLAN & LAN

4
Getting to Know Your Wireless Router
How Your Wireless Router Fits In
(This section provides a very brief, general overview of how your
Wireless Router fits within a network. There are many books and
Web sites dedicated to this topic that can provide a more
comprehensive explanation, if you require one.)
With your Adaptec Ultra Wireless Router, you can connect a group
of computers on a LAN and/or a WLAN to each other and to a
Wide Area Network (WAN), which is typically the Internet.
Your Wireless Router connects wired and wireless stations on a
single network, lets you share one Internet connection among
multiple network computer stations, and provides extra protection
for your data by helping to prevent outsiders from accessing your
network.
See Changing the Setup of Your WLAN on page 38 and Using the
Advanced Router Functions on page 48 for more information on your
Wireless Router’s features.
Wireless
AP Router
Broadband
Modem Ethernet
Connection
Desktop or laptop network stations on a WLAN
Desktop or laptop
stations on a LAN.
LAN/WLANWAN

5
Getting to Know Your Wireless Router
What About Security?
You can set security on your network by using any or all of these
features of your Wireless Router:
■Set a password for the Web-based Wireless Router Utility to
prevent unauthorized users from changing the configuration of
your Wireless Router. (See page 34.)
■Use a Wireless Network ID (or SSID) to exclude unauthorized
users from your WLAN. (See page 40.)
■Use WEP Encryption and Authentication to exclude
unauthorized users from your WLAN. (See page 41.)
■Filter MAC addresses to control which wireless stations can
connect to your Wireless Router. (See page 47.)
■Control Internet access to your Wireless Router. (See page 49.)
■Limit access to the Internet from specified internal network
stations. (See page 49.)
■Limit access to the Internet from your internal network by
setting service times and blocking access to Web sites
containing specified keywords. (See page 51 and 52.)

6
Getting to Know Your Wireless Router
This is Your Wireless Router
Top View
The top of your Wireless Router has five clearly labeled status
indicator lights (or LEDs). Once your Wireless Router is installed
and the power is on, these LEDs indicate the status of your
network, as described:
See Troubleshooting on page 58 for more on understanding your
Wireless Router’s LEDs.
LED LED is on LED is off LED is blinking
Ready N/A Not working. Working
normally.
LAN At least one LAN
port is connected.
No LAN ports
are connected.
Data is being
transmitted
through any of the
four LAN ports
.
Wireless At least one
wireless station is
connected.
No wireless
stations are
connected.
Data is being
transmitted on
the WLAN.
WAN Modem/receiver
is connected.
Modem
/receiver
is not connected.
Data is being
sent/received on
the WAN.
Power Wireless Router is
on.
Wireless Router
is off.
N/A
LEDs
Adjustable
antennas

7
Getting to Know Your Wireless Router
Side View
The DC-IN port is the port for the power adapter.
The four numbered LAN ports correspond to the numbered LAN
LEDs (see below) and connect your Wireless Router to your wired
LAN stations. Connect only Ethernet cables to these ports.
The LAN indicator lights (LEDs) show the link and activity status
of the corresponding LAN ports, as shown below.
The WAN port connects your Wireless Router to a Wide Area
Network (WAN), which is most often the Internet, through a
Broadband modem or receiver.
The INIT button resets your Wireless Router to its factory default
settings. (Press and hold the INIT button for at least 5 seconds to
reset.)
LED On Off Blinking
LINK/ACT LAN connection is
made on port.
No connection on
port.
Data is being
transmitted.
100Mbps Port is connecting
at 100 Mbps.
Port is connecting
at 10 Mbps.
N/A
DC-IN port
LAN ports 1–4 LAN
LEDs WAN port
INIT button
LINK/ACT
100Mbps
1324
1324
LINK/ACT LEDs are
on the top row.
100Mbps LEDs are
on the bottom row.

8
Installation Task List
Installation Task List
To successfully install your Wireless Router, complete each of these
tasks, in order:
❏Follow the tips and suggestions provided in Before You Begin...
on page 9.
❏Select the setup for your Wireless Router that is most
appropriate for your new or existing network. (See page 10.)
❏ Physically install your Wireless Router. (See page 12.)
❏Set up your network computer stations to communicate with
your Wireless Router. (See page 21.)
❏Open and log in to the Web-based Wireless Router Utility.
(See page 22.)
❏Configure your Wireless Router to work within your network
and with your Internet connection. (See page 25.)

9
Before You Begin...
Before You Begin...
...Read this section.The tips provided here help make the
installation of your Wireless Router go more quickly and easily.
Tip #1—Review the features of your Wireless Router in Getting to
Know Your Wireless Router on page 3.
Tip #2—Record the information listed here and keep it handy
during the installation. You will need this information when you
configure your network:
■Your Internet (WAN) connection type—DHCP (dynamic),
static, PPPoE, or PPTP. (See the Glossary on page 63 for more
information on each connection type.)
Note: If you don’t have this information available, your ISP
should be able to provide it.
■If you have a static connection, you may also need the IP
address and MAC address of your modem.
■If you have a PPPoE connection, you’ll also need your user
name, password, and service name.
■If you have a PPTP connection, you’ll also need your IP
address, server IP address, subnet mask, and PPTP account
number and password.
■Your WLAN information (if you have an existing WLAN that
includes any non-Adaptec brand wireless products, or if you
have changed the default settings of your existing Adaptec
wireless products):
■Wireless Network ID (SSID)
■Encryption settings
■Security authentication settings
Note: Use your WLAN configuration utility to find this
information.

10
Choosing a Router Setup
Choosing a Router Setup
First, you must decide which setup is appropriate for your
network. Choose one of the situations listed in the boxes below,
then go to the associated section of this User’s Guide for help
installing your Wireless Router.
Create a new network
withwirelessstations
only.
Add wireless to an
existing wired
network.
Create a new network
with both wired and
wireless stations.
See Setting Up a New
Network (LAN & WLAN) on
page 13.
See Setting Up a New
Network (WLAN only) on
page 15.
See Adding a WLAN to an
Existing LAN on page 17.
Change a wired
network to wireless
only.
See Changing a LAN to a
WLAN on page 19.
I want to use my
Wireless Router to...

11
Choosing a Router Setup
What if...?
...I don’t have wired Ethernet computers? Create a network with
only wireless computer stations by installing wireless network
adapters in all your computers, then following the setup
instructions provided in Setting Up a New Network (WLAN only) on
page 15.
...I’m adding my Wireless Router to existing WLAN? Follow the
setup instructions provided in
Changing a LAN to a WLAN on page 19.
...I don’t want any wireless stations on my network? Ensure that
your computers have Ethernet connections, then follow the setup
instructions provided in Setting Up a New Network (LAN & WLAN)
on page 13.

12
Installing Your Wireless Router
Installing Your Wireless
Router
Before continuing, ensure that you have:
❏Followed the tips and suggestions provided in Before You
Begin... on page 9.
❏Selected the setup for your Wireless Router that is most
appropriate for your existing or new network. (See page 10.)
The next step on the Installation Task List (see page 8) is to connect
your Wireless Router.
This chapter provides suggestions for locating your Wireless
Router in the best possible position and guides you through the
installation process. Installation instructions are provided for four
different situations:
■Setting Up a New Network (LAN & WLAN) on page 13.
■Setting Up a New Network (WLAN only) on page 15.
■ Adding a WLAN to an Existing LAN on page 17.
■Changing a LAN to a WLAN on page 19.
For help deciding which set of instructions to use, see Choosing a
Router Setup on page 10 and What if...? on page 11.

13
Installing Your Wireless Router
Setting Up a New Network (LAN & WLAN)
Follow these instructions if you are including your Wireless Router
in a new network that includes both wired and wireless stations—
a combination LAN and WLAN.
To connect your Wireless Router:
1Find a suitable location to install your Wireless Router.
For maximum performance, install it in the center of your
network, in a place that has a line of sight to all the devices
connecting to it.
The higher you place your Wireless Router, the
better the signal coverage will be, especially if you have
wireless stations upstairs from your Wireless Router.
Caution: Keep it as far away as possible from potential
sources of interference, such as microwave ovens, 2.4 GHz
wireless telephones, baby monitors and other wireless
devices.
2If desired, attach your Wireless Router to the wall, using the
mounting screws provided.
3Connect the power cord to the DC-IN port on your Wireless
Router, then plug it into a power outlet.
4Plug your broadband modem into the WAN port on your
Wireless Router, using the Ethernet cable provided. (See the
Figure in Step 3.)
!
Step 3: Connect the
power adapter.
Step 5:
Connect the LAN.
Step 4:
Connect the WAN.
