Adastra AD-100 User manual

AD-100
DAB/FM RADIO TUNER
OWNERS MANUAL
Version 1.0

Safety information
1. Please read these instructi ns bef re perating.
2. Keep these instructi ns f r future reference.
3. Heed all warnings.
4. F ll w all instructi ns.
5. D n t use this item near m isture.
6. Clean nly with dry cl th.
7. D n t bl ck any f the ventilati n penings.
8. D n t install near any heat s urces such as radiat rs, st ves r ther items (including
amplifiers) that pr duce heat.
9. D n t defeat the safety purp se f the p larised plug. The wide blade is pr vided f r
y ur safety. If the pr vided plug d es n t fit int the item r the mains s cket, c nsult
an electrician f r replacement.
10. Pr tect the p wer c rd fr m being walked n r pinched particularly at plug, c nvenience
receptacles, and p int where they exit fr m the item.
11. Only use attachments/access ries specified by the manufacturer.
12. Use nly with a stand, trip d, bracket r table suitable f r supp rt.
13. Unplug this item during lightning st rms r when unused f r l ng peri ds f time.
14. Refer all servicing t qualified service pers nnel. Servicing is required when the item has
been damaged in any way, such as p wer supply c rd r plug is damaged, liquid has
been spilled r bjects have fallen nt the item, the item has been exp sed t rain r
m isture, d es n t perate n rmally, r has been dr pped (N te: Accidental r c smetic
damage is n t c vered by the items 12 m nth warranty)
15. Please keep the unit in a safe envir nment.
16. D n t st re anything n t p f the item
CAUTION: T reduce the risk f electric sh ck, d n t
rem ve any c ver. N user-serviceable parts inside. Refer
servicing t qualified service pers nnel nly.
The lightning flash with arr whead symb l within the equilateral triangle is intended t
alert the user t the presence f un-insulated “danger us v ltage” within the pr duct’s
encl sure that may be f sufficient magnitude t c nstitute a risk f electric sh ck.
The exclamati n p int within the equilateral triangle is intended t alert the user t the
presence f imp rtant perati n and maintenance (servicing) instructi ns in the
literature acc mpanying this appliance.
DO NOT OPEN
RISK OF ELECTRIC SHOCK

ADASTRA AD 100
Main Features:
DAB & FM Tuner
Aut tune
Radi stati n display RSD
9 Preset mem ry
IR rem te c ntr l
1U 19” rack m untable
Supplied with antenna
Accessories
1 x UK p wer cable
1 x EU p wer cable
1 x Rem te c ntr l
1 x Instructi n manual
General Checks and Advice
1) Installati n
•Place the unit n a flat surface r m unt in a secure rack case.
•Be sure the player is m unted in a well ventilated area and is n t exp sed t direct
sunlight, high temperatures r high humidity.
•Keep the unit as far away as p ssible fr m TVs and tuners as the unit may cause
undesirable interference t these devices.

General Functions and Controls
1. POWER SWITCH This switch is used t c ntr l the unit's main p wer.
2. PRESET MEMORY 1 10 – Press t select the pre set radi stati ns 1-5 r t access the
sec ndary mem ry 6-10 press shift f ll wed by the marked number. T save a preset
stati n t a mem ry butt n press and h ld the number y u want t save t f r 5
sec nds and the unit will aut st re.
3. SHIFT – Used t access sec ndary functi ns n the c ntr l panel.
4. MODE The receiving band is changed between DAB and FM frequencies.
5. DOWN – Press t decrease the receiving frequency by 50kHz.
6. UP – Press t increase the receiving frequency by 50kHz.
7. AUTO SCAN – Press t start aut scanning feature. Once finished use the c ntr l wheel
t select the stati n.
8. SELECT – Press t c nfirm a selecti n.
9. MENU/INFO – Press t see the details f the radi stati n (DAB nly)
10. DISPLAY – Alpha numeric display.
11. REMOTE SENSOR – Infrared sens r f r rem te c ntr l.
12. CONTROL WHEEL – M ve left and right t t ggle thr ugh the radi stati ns and press
t c nfirm.
13. ANTENNA – Screw sl t f r the supplied antenna. This is needed especially f r DAB
signal
14. RCA OUTPUT – Unbalanced audi left and right.
15. IEC POWER INPUT – IEC s cket f r the supplied p wer lead.

Remote Control:
Please refer t the previ us secti n t identify the functi ns f each butt n

Specification:
1. GENERAL SECTION
2. Digital pr cessing FM tuner & DAB+
3. 10 preset mem ries f r FM tuner
4. Input/ utput
i. Input: FM 75 hm unbalanced antenna terminals.
ii. Output: RCA audi utput
5. P wer supply: 230V AC
6. P wer c nsumpti n: 50VA
7. Weight: 3.35kg
8. Dimensi n: 482mm * 44mm * 185mm
Electrical performance specifications:
1 1. FM section:
Parameter Value Unit
FM Tuning range 87.5–108 MHz
Sensitivity 10 uV emf
Audi Stere
Separati n 30 dB
Audi Output
V ltage 400mV mV rms
Audi (S+N)/N 50 dB
Audi THD 0.3 %
FM step Frequency 50 KHz
1 2. DAB+ section:
Parameter Value Unit
DAB frequency
range 174.928~239.2 MHz
Adjacent Channel
Selectivity 31 dB
Far- ff selectivity 49 dB
Sensitivity -96 dB

FOR MORE INFORMATION ON ADASTRA PRODUCTS VISIT
WWW.ADASTRA PA.CO.UK
