Adcom LUNA User manual

Your Speaker
1. POWER button
2. VOL+ button
3. VOL- button
4. MODE button
5. POWER indicator
6. Bluetooth indicator
7. WiFi indicator
8. Aux indicator
9. Stand
10. Handle Hole
11. USB port
12. Headphone socket
13. AUX IN socket
14. AUX OUT socket
15. DC IN 12V 2A socket
Remote Control
1. VOL+ button
2. button
3. button
4. button
5. button
6. MODE button
7. VOL- button

What’s the indicator indicates
Indictors
Indicator status
Indications
POWER indicator
Off
Off
Lights red
Standby
Lights green
On
Flashes green light slowly
Battery is charging
Flashes green light fast
Battery power is low. Advise charging.
Flashes green light very fast
Battery power is very low. Require
charging.
WiFi indicator
Flashes white light slowly
Waiting for network
Lights white
WiFi connected
Flashes white light once
Switch mode among Internet - Spotify
Connect - Music player in turn
Bluetooth indicator
Flashes blue light
Bluetooth mode, waiting for pairing with
Bluetooth device
Lights blue
Bluetooth connected
Aux indicator
Flashes white light
Aux in mode, waiting for connecting to
audio device
Lights white
Audio cable connected
Turning the Speaker On/Off
Connect the plug at the end of power adapter cable to the
DC IN socket on the rear of the speaker. Then insert the
power adapter into the mains socket.
Press POWER button to switch speaker on.
Press POWER button a second time to switch speaker
standby.
Press and hold POWER button for 3 seconds to switch
speaker off.
Your speaker includes a built-in battery, once connected
speaker to mains supply, the battery will be automatically
charged and automatically stop charging since fully
charged.
Battery is still charging even speaker is switched off but
connecting to mains supply. To switch the speaker off
completely, unplug the power cord from the mains socket.
When speaker doesn‟t connect to mains supply, it will run
by battery power. Press POWER button to turn the
speaker on or standby. Press and hold POWER button
for 3 seconds to switch speaker off.

Setting Your Speaker
For first time switch the speaker on, WiFi indicator is
flashing white light slowly. The speaker is waiting for
establishing network.
1. Go to „Settings‟on your smartphone or tablet, select
Wi-Fi and then choose „ADCOM-Luna‟.
2. Start UNDOK app on your smartphone or tablet
(Using iPhone for example), and then tap „Set up audio
system‟ at bottom left corner of screen.
3. Tap „Next‟.

4. It will ask you to „Go to the Settings app on this
iPhone/iPad, select Wi-Fi, choose the network of your
audio system. Once selected return to the UNDOK.‟.
If you have done step 1, tap „Next‟.
5. You can rename your speaker, E.g. My ADCOM-Luna.
Tap „Next‟.
6. Tap to select „Wi-Fi‟, it will search for Wi-Fi networks.
7. Select your preferred network and then type in
password. Tap „Next‟.

6
8. Tap „Skip checking‟.
9. The WiFi indicator will light white once your
speaker connected to network.
Tap „Start using my audio system‟to find your speaker
in the list. Make sure your smart phone connect to the
same WiFi network as the speaker.
Select “ADCOM-Luna xxxxxxxxxxxx”(the 12 digit
alphanumeric code is the MAC address of your
speaker) from list, now playing screen will show.
Note: if you desire to change to another WiFi
network, press and hold MODE button on the
speaker for about 10 seconds to do a factory
reset. Speaker will restart and reset to initial
status and you can set the network again.

7
Controlling Your Speaker
1. Tap your speaker in the list on My Home screen.
2. For initial use, you need to tap „SOURCE‟tab to select
a play mode.
3. Tap „Internet radio‟from „SOURCE‟tab to select
Internet radio mode. The WiFi indicator lights
white.

8
Tap „BROWSE‟tab to select a program to play.
While playing program, you can:
Save your favourite Internet station or recall saved
station.
Sharing
Stop playing
4. Tap „Spotify‟to select Spotify Connect mode. The
WiFi indicator of speaker will flash white light once and
lights on.
Ensure you have download Spotify app for your
smartphone (iOS or Android) and your speaker
connected to the same WiFi network as your
smartphone.
1) Tap „Open Spotify‟on BROWSE tab to open
Spotify App.
2) Play any song in Spotify app. Tap the square
image of the song‟s cover art in the bottom left of
the screen.
3) „DEVICES AVAILABLE‟will show at the bottom
of screen, tap it.
4) Tap „ADCOM-Luna‟from the list. If you can‟t see it,
just check it‟s connected to the same WiFi
network as your smartphone.
You will notice that your speaker is listed as
“ADCOM-Luna xxxxxxxxxxxx” (the 12 digit
alphanumeric code is the MAC address of your
speaker) in the Spotify App if you didn‟t rename it
at step 5 of “Setting Your Speaker”section.
5) „[Your speaker]‟will turn green to signify that
your speaker is now selected and being used for
audio playback.

9
6) Return to UNDOK app, you can:
Save your favourite Spotify playlist or recall
saved playlist.
Sharing
Shuffle play
Repeat play
Skip to previous track
Skip to next track
Play/pause current playing track
5. Tap „Music player‟to select Music player mode. The
WiFi indicator will flash white light once and lights
on.
Tap „BROWSE‟tab to select music to play:
Shared media - Your UPnP (Universal Plug and Play)
media server - Music/Video Library - Music/Video.
When playing music/video, you can:
Sharing
Shuffle play
Repeat play
Skip to previous track
Skip to next track
Play/pause current playing track
Your speaker has a USB playback feature which
enables you to play music of MP3, WMAand AAC
formats in your USB disk.
1) Insert USB disk to USB port on the rear of
speaker.
2) Tap „BROWSE‟tab and then select „USB
Playback‟.
3) Step by step to find your desired music.

10
6. Tap „Auxiliary Input‟to select Aux in mode. The Aux
indicator flashed white light.
Press and hold POWER button for 3 seconds to
switch speaker off, and then remove power adaptor
from mains socket.
Use a 3.5mm audio cable (not supplied) to connect to
your external audio device through the AUX IN socket
on the rear of speaker.
Connect power adaptor to mains socket and turn
speaker on. The Aux indicator lights white. You can
operate your audio device directly for playback
features.
7. To pair your speaker with your Bluetooth device, Tap
„Bluetooth‟to select Bluetooth mode first, The
Bluetooth indicator flashes blue light. And then go to
Bluetooth setting on your smartphone or tablet. Select
„ADCOM-Luna‟from device list and enter “0000” for
the password if necessary.
The Bluetooth indicator lights blue once Bluetooth
connected. You can operate your Bluetooth device
directly for playback features.

11
Using Multi-room
Multi-room is a feature that enables you control your
speakers (one or group) via UNDOK app for playback.
You can enjoy music by using your smartphone which has
UNDOK app to control the speakers (multi-room capable
devices) in the kitchen, bedroom or living room. Of course
you also can control the speakers playing together.
1. If you have more than one speaker (multi-room
capable device), you can group them to play
synchronously.
2. Create group, taping the edit icon which is
following device name on My Home screen, and then
„Group Setup‟screen will be shown.
1) Tap the grey circle before device name which is
under „Sharing with‟option on „Group setup‟screen
and make it turn green to add the device to group.
2) Tap „Rename‟under „Group name‟option on
„Group Setup‟screen to enter a group name or
select one usual name from the list, and then select
„Done‟to create group.
3) Device list will appears again and the group will be
shown with group name and the devices in the
group. Tap on group name to select the group.

12
4) All clients in the group will synchronously play the
program which the master device is playing. You
can drag the volume control bar to change the
master volume for all grouped devices. You also
can tap on the volume control and then change
volume for each device respectively.
Note: master device is which you selected
from device list for editing group; client is the
device you selected sharing with on ‘Group
Setup’screen.
Note: Aux in and Bluetooth modes are
incompatible multi-room playback. Switch to
it will remove the master radio from the
group.
5) You may need to dissolve the group if you don‟t
want to group play your speakers, tap „Delete
group‟to delete the group on „Group Setup‟
screen.
