ADDAC System ADDAC216 Sum & Difference User manual

March.2020
ADDAC216 Assembly Guide
ADDAC SYSTEM page 2

ADDAC SYSTEM page 3
ADDAC216 Assembly Guide
STEP 1:
Start by locating all 4 capacitors, notice the orientation printed on the pcb.
Tip: soldering these caps is easy, just place a dab of solder on the pad on your right (left pad if you’re
left handed) and then, with the help of a tweezer, put the capacitor in place and reflow the previously
tinned pad to reflow the solder while pushing the capacitor down. Then solder the other pad.

ADDAC SYSTEM page 4
STEP 2:
Next carefully break the 2 pcbs apart and proceed to locate the male and female pinheaders and solder
them like shown below.
ADDAC216 Assembly Guide

ADDAC SYSTEM
STEP 3:
Next locate and solder the 2x5 boxed pinheader like shown below.
page 5
ADDAC216 Assembly Guide

ADDAC SYSTEM
STEP 4:
Next attach the spacer like shown below.
page 6
ADDAC216 Assembly Guide

ADDAC SYSTEM
STEP 5:
Next locate all trim pots and flatten out their legs with the help of some pliers, like shown below.
page 7
ADDAC216 Assembly Guide

ADDAC SYSTEM page 8
STEP 6:
Next locate and place all front panel parts.
ADDAC216 Assembly Guide

ADDAC SYSTEM page 9
STEP 7:
After all parts are in place, fit the frontpanel in and tighten all the nuts.
ADDAC216 Assembly Guide

ADDAC SYSTEM page 10
STEP 8:
Next proceed by soldering all pads in the back.
STEP 9:
For the last step attach the back pcb and place the bottom screw.
ADDAC216 Assembly Guide

ADDAC SYSTEM page 11
Place the top knobs and tighten all remaining nuts,
then you’re done!
Happy Patching!
ADDAC216 Assembly Guide

For feedback, comments or problems please contact us at:
[email protected]
ADDAC216 ASSEMBLY GUIDE
March.2020Revision.01
