Addonics Technologies AEMDVRBY User manual

Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: [phone]
Email: http://www.addonics.com/support/query/
v7.1.11
www.addonics.com
T E C H N O L O G I E S
User Guide
Multi-Media Bay with Slim DVD-RRW Drive
(AEMDVRBY)

www.addonics.com
Phone: [phone]
Fax: [phone]
Email: http://www.addonics.com/sales/query/
CONTACT US
Cable Connections for DVR Optical Drive:
1. Plug-in the SATA cable into a SATA port.
2. Connect the 4-pin Molex power connector to a power supply.
Cable Connections for Multi-media bay:
1. A SATA power & data Y-cable is provided with the multi-media bay. Connect
this cable to the SATA connection at the back of the bay.
2. The SATA power & data Y-cable has a third connector. Attached this
connector to the power and drive activity LED connector as labeled above.
If this connector is not connected, the power & drive activity LEDs located on
the front of the multi-media bay will not function.
Drive Door Swings Open to Accommodate a 3.5” SATA Drive
Power LED
Drive Activity LED
Reserved Connector
Power and Drive Activity LED Connector
SATA Connection
