Adp Michel Bench User manual

Thank you for purchasing this ADP product.
By following these instructions, you will
maintain your ADP product for many years to
come and protect your warranty.
ARE YOU INSTALLING THIS PRODUCT?
Please read the installation instructions found in this booklet BEFORE INSTALLATION.
If the product is not installed in accordance with these instructions, your ADP warranty
may be void and the homeowner may have a claim against you (the installer).
We recommend that a qualified trades person install this product.
PLEASE RETURN TO HOMEOWENER - IMPORTANT CARE & WARRANTY
INFORMATION INSIDE. For more information visit www.adpaustralia.com.au
Installation Instructions
for Michel & Minima Bench

PRIOR TO INSTALLATION
IMPORTANT!
ENSURE ALL TILES EXTEND BEHIND AND BENEATH THE BATHROOM FURNITURE.
ADP do not recommend tiling in furniture due to moisture and mould build up which can
damage the material and void the warranty.
ALL AREAS WHERE CABINET MEETS WALL AND/OR FLOOR MUST BE SEALED USING
A NEUTRAL CURE SILICONE.
All edges where vanity top meets cabinet, wall or surrounding furniture must also be
sealed with a continuous bead of silicone.
We recommend that a qualied trades person install this product and we would expect
the installation to be undertaken in a trades person like manner and nished to a trades
person standard. This product carries a full warranty against faulty workmanship and
materials. Please inspect thoroughly before installation to ensure that the product has
not been damaged. It is the responsibility of the installer to make any adjustments to
doors/drawers after installation if required.
Check products for any damages
Positioning & Ventilation
Check for Support Beams
Check for Plumb Walls & Level Floors
Check plumbing positions align with product interior congurations.
Within 48 hours of receiving your goods, unpack your ADP
product and check for any damages or missing parts.
No claims for damages will be recognised after installation.
Check Step 1 on installation guide for parts list. If any
parts are missing, please contact your place of purchase.
Please note: screws/bolts are not supplied.
Furniture must be at least 300mm away from any wet
areas. Materials used in the construction of our units are
moisture resistant, not water proof.
Do not expose furniture to shower spray.
It is important that your bathroom is adequatley
ventilated to eliminate moisture build up.
High humidity will lead to permanent dampness and
mould resulting in a deterioration of the materials in your
bathroom.
Wall hung furniture and wall hung ceramic basins require
xing to a support beam tted between the studs to
give a solid wall backing to attach the vanity. If neces-
sary x additional support noggins at desired height for
cabinet and basin xing. Ensure total width of support
noggin exceeds vanity width.
Refer to Step 2 for recommended height for your
type of vanity.
1
2
3
4
5
Ensure the Wall is plumb and straight, ensure oor is level. If
you x the product to a non-plumb wall or oor the following
could happen:
• Your door or drawers will not operate correctly
• Door or drawer adjustments will not align.
• Basins will not sit level, which may cause water to pool
or not drain properly
If it is not possible to make the wall or oor plumb and
straight you must pack the vanity out so that it does not
follow the out of aligned wall.
Floor standing vanities must sit on a level oor or be packed
so they sit level and true.
Please note if your vanity is xed to a bowed wall, the
fastening of the xings will force your cabinet into a twist
and benchtop materials may crack due to increased stress on
joins and materials.
Please note if your product has any electrical ttings
please allow for this and talk to your electrician
Take note of clearances behind drawers when
considering water supply ttings inside cabinet.
A - 300mm
(minimum clearance)
A

INSTALLATION INSTRUCTIONS: MICHEL & MINIMA BENCH
Parts you should receive
Wall Brackets
Pre-drill bracket positions
Place bench in position on the brackets
Seal the external edges
Apply epoxy glue
Fix brackets to the wall
Support Beam & Positioning
Mark the position of the wall brackets
PLEASE NOTE
For more information please visit www.adpaustralia.com.au
Bracket position
Support Beam
You should have received wall brackets with
your Michel or Minima bench.
• 2 wall brackets - for sizes up to 1500
• 3 wall brackets - for sizes 1500 and longer
Once the wall has been sheeted, mark
the position of the top of the support
beam on the wall (this will be your
overall benchtop height).
1
6
8
10
9
7
3
5
4
2
It is recommended that a 150 x 35mm
timber support beam be pre-installed
into the framework prior to sheeting the
wall.
The recommended height of the support
beam is approximately 850mm from the
nished oor level. This will determine
the overall height of the vanity.
Check that the marks are completely
level.
Measure the bracket position on the
underside of the bench, making sure
to leave enough room for the basin,
waste and plumbing.
Mark the bracket positions on the wall. All three holes in
each bracket should fall within the support beam.
Note: Top of the brackets should sit 20mm below
nished benchtop line to allow for benchtop thickness.
Pre-drill into the wall through each of the hole locations
in the wall bracket (3 per bracket). Be sure to use an
appropriate drill bit for your wall covering (tiles etc).
Place bench on the brackets, check it is level in all directions.
If unlevel, use packing material to ensure that benchtop
surface is completely level.
Seal the external edges of the bench top and sides to
the wall with a neutral cure silicone.
Once the bench is level, remove the bench from the
brackets and apply epoxy glue to the top of each bracket.
Place the unit back on the bracket (with the packing material
if needed).
Secure each bracket to the wall using an appropriate
screw/bolt.
Brackets that are installed correctly are capable of holding
a maximum load of 250kg each.
Where a stud or support beam cannot be located, use an
appropriately sized hollow wall anchor.
Note: It is not recommended to ONLY use hollow wall anchors
to x bench to the wall however these can be used if one or two
pilot holes do not penetrate into support beam.
Note: Keep your basin height in mind - you
may want your bench to sit slightly lower if
you have an above-counter basin.
850mm
