Omnimount Stellar G343 User manual

Step 7 Slide middle shelf onto bottom shelf. (Fig. 7a) Grasp middle shelf firmly and lift it into position. (Fig. 7b) Align rear of middle shelf with rear support bracket. (Fig. 7c) Rotate middle shelf into position into side support brackets. (Fig. 7d) Caution: Ensure that rear and side brackets are fully engaged before releasing grasp on shelf.
Fig. 7a Fig. 7b Fig. 7c Fig. 7d
Specifications are subject to change without prior notice. Every effort has been made to provide accurate and error-free assembly and installation. OmniMount Systems disclaims liability for any difficulties arising from the interpretation of information contained in these instructions. If OmniMount products are used for purposes other than their original intent, OmniMount, its distributors and retailers shall not be held responsible or liable for injuries or property damage, direct, indirect, or consequential, which may arise from the
inability to use this product safely, properly, and in the manner for which it has been designed and manufactured. War- ranty does not apply to products which have been lost, damaged by misuse, abuse, or accident.
Thank you for purchasing an OmniMount product.
OmniMount Systems, Inc.
8201 South 48th Street • Phoenix, AZ 85044-5355
www.omnimount.com
Step 8 Tighten rear shelf bracket screw. (Fig. 8a) Re-secure the side brackets as close to shelf as possible. (Fig. 8b) Place top shelf onto upper frame members. (Fig. 8c) Note: If the top shelf glass is unstable, move the rubber pad positions or double up the height of the lowest pad until the shelf glass is stable. Caution: Never try to move table by pulling on glass shelves. Always move table by grasping the frame.
Fig. 8b
Fig. 8a
Fig. 8c
Stellar Video Tables: G343, G343T, G348
Assembly Instructions
IMPORTANT: Consult your dealer if you have any questions regard- ing the proper assembly of this product.

Step 1
Install hex screw into pads on bottom of back post. (Fig. 1a)
Install cable port covers into back post. (Fig. 1b)
Fig. 1a
Fig. 1b
Step 2 Lay main frame face down on floor. Match holes on support legs to holes on main frame support brackets. Loosely secure support legs to main frame using hex head screws and supplied hex wrench. (Fig. 2a)
Secure back post to support using long hex head bolts and sup- plied hex wrench. (Fig. 2b) Tighten all support leg screws. Stand table upright.
Fig. 2a
Fig. 2b
Fig. 3a
Step 3 Determine desired height of middle shelf. Install Phillips head screw and shelf pad into rear shelf support bracket. (Fig. 3a) Models: G343, G343T, G348
Secure rear shelf support bracket to back post with countersunk hex screws. (Fig. 3b)
Secure side shelf support brackets to main frame with Phillips head screws. (Fig. 3c) Note: Slide bracket fully to the outside edge of frame. (Fig. 3d)
Fig. 3b
Fig. 3c Fig. 3d
Step 4 Install end caps into foot sections on front of base frame and side of back frame. (Figs. 4a & 4b) Step 5 Place adhesive rubber pads on support legs and main frame. (Figs. 5a & 5b) Rock the stand to check that it is level and stable. Note: For unstable condition, un-screw shortest leveling foot until table sits level. Step 6 Identify glass shelves. (Fig. 6a) Slide bottom shelf onto lower frame members. (Fig. 6b) Rotate bottom shelf into position on lower frame mem- bers. (Fig. 6c)
Fig. 4a Fig. 4b
Fig. 5a
Fig. 5b
Fig. 6a
Fig. 6b Fig. 6c
