ADTRAN NetVanta 2730 Getting Started Guide Page i
ADTRAN NetVanta 2730
Getting Started Guide
This Getting Started Guide provides instructions for basic
installation and configuration of the ADTRAN NetVanta 2730.
After you complete this guide, computers on your Local Area
Network (LAN) will have secure Internet access.
Document Contents
This document contains the following sections:
Pre-Configuration Tasks - page 1
Preparing Your WWAN PC Card - page 7
Registering Your Appliance - page 11
Deployment Scenarios - page 17
Verifying Your Connection - page 35
Enabling Essential Security Services - page 39
Additional Deployment Configuration - page 47
Product Safety and Regulatory Information - page 63
1
2
3
4
5
66
7
88

Page ii ADTRAN NetVanta 2730 Front Panel
ADTRAN NetVanta 2730 Front Panel
Indicator LEDs
Provides power and test status
(refer to page 5)
PC Card Slot
(side of unit)
Provides an interface
for the WWAN PC
Card connection
USB Ports
For future application
Provides dedicated LAN/WAN port status as follows:
link/spd:
activity:
Provides Ethernet port status as follows:
link/spd:
activity:
LAN/WAN Port Status
PC Card Status
Provides WWAN PC Card status as follows:
signal:
link/act:
10/100 Ethernet Port Status
Provides Ethernet port status as follows:
link/spd:
activity:
10/100/1,000 Ethernet Port
Off=10M
Green=100M
Solid=link
Blinking=activity
Off=10M
Green=100M
Amber=1,000M
Solid=link
Blinking=activity
Off=10M
Green=100M
Amber=1,000M
Solid=link
Blinking=activity
Green=connected
Amber=negotiating
Solid=link
Blinking=activity

ADTRAN NetVanta 2730 Getting Started Guide Page iii
ADTRAN NetVanta 2730 Rear Panel
Console
WAN
X3X0 X1 X2 X4 X5 X6 X7 Power
LAN
X8
Console Port
Provides access to the
SonicOS Command Line
Interface (CLI) via the
DB9 -> RJ45 cable
LAN Port (X0)
Provides dedicated LAN
access to local area
network resources
WAN Port (X1)
Provides dedicated WAN (Internet)
Ethernet Port (X2)
Provides an additional
Gigabit-capable Ethernet
port for general use
Power Supply
Provides power
connection using
supplied power cable
Reset Button
Press and hold to
manually reset the
appliance to SafeMode
Ethernet Ports (X3-X7)
Provides configurable
10/100 Ethernet ports for
connection to network
devices on WAN, LAN, DMZ,
and other zone types
HA Ethernet Port (X8)
Provides 10/100 Ethernet
port for high availability (HA)
connectivity

Page iv ADTRAN NetVanta 2730 LED Reference Guide
ADTRAN NetVanta 2730 LED Reference Guide
Pwr LED
Operational
Unavailable
Solid = ROM Booting / Firmware Loading
Blinking = SafeMode enabled
Test LED
PWR TEST
P
W
R
TE
S
T

ADTRAN NetVanta 2730 Getting Started Guide Page 1
Pre-Configuration Tasks
In this Section:
This section provides pre-configuration information. Review this section before setting up your ADTRAN NetVanta 2730 appliance.
•Checking NetVanta 2730 Package Contents - page 2
•Obtaining Configuration Information - page 3
•Obtaining WWAN Service Provider Information - page 5
•Verifying System Requirements - page 5
1

Page 2 Checking NetVanta 2730 Package Contents
Checking NetVanta 2730 Package Contents
Before setting up your NetVanta 2730 appliance, verify that your
package contains the following parts:
NetVanta 2730 Appliance
DB9 -> RJ45 (CLI) Cable
Standard Power Adaptor*
Ethernet Cable
1
2
3
4
Release Notes
Getting Started Guide
5
8
96
Any Items Missing?
If any items are missing from your package,
please contact ADTRAN support at 1-888-4-ADTRAN.
A listing of the most current support documents are available online
at: <http://www.adtran.com/support>
*The included power cord is intended for use in North America only.
For European Union (EU) customers, a power cord is not included.
1
Release Notes
Contents
4
5
23
6
Getting Started Guide

ADTRAN NetVanta 2730 Getting Started Guide Page 3
Obtaining Configuration Information
Record and keep for future reference the following setup
information:
Registration Information
Networking Information
Administrator Information
Serial Number: Record the serial number found on the
bottom panel of your ADTRAN
appliance.
Authentication Code: Record the authentication code found
on the bottom panel of your ADTRAN
appliance.
LAN IP Address:
. . .
Select a static IP address for your
ADTRAN appliance that is within the
range of your local subnet. If you are
unsure, you can use the default IP
address (192.168.168.168).
Subnet Mask:
. . .
Record the subnet mask for the local
subnet where you are installing your
ADTRAN appliance.
Ethernet WAN IP Address:
. . .
Select a static IP address for your
Ethernet WAN. This setting only
applies if you are already using an ISP
that assigns a static IP address.
Admin Name: Select an administrator account name.
(default is admin)
Admin Password: Select an administrator password.
(default is password)

Page 4 Obtaining Configuration Information
Obtaining Internet Service Provider (ISP) Information
Record the following information about your current ISP:
ISP 1 Record the following information about your secondary ISP:
ISP 2 (Optional for Multiple WAN Failover)
If you connect
via You likely use Please record
Cable modem,
DSL with a
router
DHCP No Internet connection information is
usually required, although some service
providers require a host name.
Host Name:
Home DSL PPPoE User Name:
Password:
Note: Your ISP may require your user name
in the format: [e-mail]
T1/E1,
Static
broadband,
Cable or DSL
with a static IP
Static IP IP Address: . . .
Subnet Mask: . . .
Default Gateway
(IP Address): . . .
Primary DNS: . . .
Secondary DNS
(optional): . . .
Dial-in to a
server PPTP Server Address:
User Name:
Password:
If you connect
via You likely use Please record
Cable modem,
DSL with a
router
DHCP Host Name:
Home DSL PPPoE User Name:
Password:
Note: Your ISP may require your user
name in the format: [e-mail]
T1/E1,
Static
broadband,
Cable or DSL
with a static IP
Static IP IP Address: . . .
Subnet Mask: . . .
Default Gateway
(IP Address): . . .
Primary DNS: . . .
Secondary DNS
(optional): . . .
Dial-in to a
server PPTP Server Address:
User Name:
Password:

ADTRAN NetVanta 2730 Getting Started Guide Page 5
Obtaining WWAN Service Provider Information
Record the following information about your current WWAN
service:
WWAN Service Provider
WWAN Account Information
Note: WWAN Account Information is automatically
populated based on the chosen service provider and
plan type. In most cases,
if you selected the correct service provider and plan
type the WWAN account information does not have to
be altered.
Verifying System Requirements
Before you begin the setup process, verify that you have:
• An Internet connection
• A Web browser supporting Java Script and HTTP uploads.
Supported browsers include the following:
Country: Record the country where you purchased your
WWAN card.
Serv i c e P r o v i d e r: Record the service provider from whom you
purchased your WWAN card. This is the brand
name of the card.
Plan Type: Record the plan type that you purchased from
your provider. If you are unsure about this
information, you may use Standard as the plan
type.
User Name/Password:
Some WWAN service providers require user
specific information, such as a login and
password. If your service provider requires it,
you will need to provide such information during
the setup process.
Supported Browsers Browser Version
Number
Internet Explorer 6.0 or higher
Firefox 2.0 or higher
Netscape 9.0 or higher
Opera 9.10 or higher
for Windows
Safari 2.0 or higher
for MacOS

Page 6 Verifying System Requirements

ADTRAN NetVanta 2730 Getting Started Guide Page 7
Preparing Your WWAN PC Card
In this Section:
This section provides instructions to set up your WWAN PC card for use in the ADTRAN NetVanta 2730 appliance.
•WWAN PC Card Setup - page 8
•Activating Your PC Card Software - page 8
•Verifying Your Connection - page 9
Alert: DO NOT insert your PC card into the ADTRAN NetVanta 2730 appliance until you have completed the setup process for
your card as described in this section.
If your WWAN PC card is already registered and activated with your service provider and you are able to access the Internet through your
PC using this card, you may skip this section and continue to Registering Your Appliance - page 11.
2

Page 8 WWAN PC Card Setup
WWAN PC Card Setup
Complete the following steps to set up and provision your
WWAN PC card. Verify at the www.adtran.com Website that
your WWAN PC card and service provider are supported by the
ADTRAN NetVanta 2730 appliance.
Alert: DO NOT insert your PC card into the ADTRAN
NetVanta 2730 appliance until you have completed the
setup process for your card as described in this section
and successfully accessed the Internet through your
computer using the PC card.
If you are using a GSM-based WWAN service provider, you
may be required to remove the PIN protection from your SIM
chip before using it with the appliance. Please contact your
WWAN service provider for more information on setup and PIN
removal procedures.
Activating Your PC Card Software
This section covers prerequisites necessary to set up most
WWAN PC cards to work with the ADTRAN NetVanta 2730.
Using an available desktop or laptop PC with Type II PC card
slot, complete the following steps:
1. Install the software that came bundled with your WWAN
PC card before activating the card.
2. When prompted, insert the WWAN PC card into an
available Type II PC card slot on the Laptop or Desktop PC
you are using for card configuration.
3. Install updates to your WWAN PC card, if available.
4. Activate your PC card, if required.

ADTRAN NetVanta 2730 Getting Started Guide Page 9
Verifying Your Connection
After activating the card on your PC, you can view your
connection type and verify that the WWAN PC card is
transferring data. For valid connection testing, it is important
that you first disable all other network connections, such as a
WiFi or LAN connection, before continuing. Leave only your PC
card connection enabled.
1. Use the software that came with your WWAN PC card to
initialize a connection with your service provider.
2. In the Windows interface, select Start > Run.
3. Enter cmd in the Open field and click the OK button.
4. At the prompt, type the command ipconfig and press
Enter on the keyboard.
5. Your network device status will display. Verify that you have
obtained an IP Address for your Ethernet adaptor, and that
all other Local Area Network Connections display “Media
disconnected” as their status.
Note: The name of your Ethernet adaptor may differ from
the screenshot below. Common names for newly
acquired cards are “Local Area Connection 2” or “Local
Area Connection 3.”
6. Open a Web browser and navigate to a Website, such as
<http://www.adtran.com>,to verify that your connection
can transfer data.
Congratulations! You have set up and provisioned your
WWAN PC card.

Page 10 WWAN PC Card Setup

ADTRAN NetVanta 2730 Getting Started Guide Page 11
Registering Your Appliance
In this Section:
This section provides instructions for registering your ADTRAN NetVanta 2730 appliance.
• Before You Register - page 12
• Creating a NetVanta Security Portal Account - page 13
• Registering and Licensing Your Appliance on NetVanta Security Portal - page 13
• Registration Next Steps - page 16
Note: Registration is an important part of the setup process and is necessary to receive the benefits of ADTRAN security services,
firmware updates, and technical support.
3

Page 12 Before You Register
Before You Register
You need a NetVanta Security Portal account to register the
ADTRAN NetVanta 2730 appliance. You can create a new
NetVanta Security Portal account on www.adtran.com/
NetVantaSecurityPortal or directly from the ADTRAN
management interface. This section describes how to create an
account by using the Website.
If you already have a NetVanta Security Portal account, go to
Registering and Licensing Your Appliance on NetVanta
Security Portal - page 13 to register your appliance on NetVanta
Security Portal. You can also postpone registration until after
you set up the appliance. Skip ahead to Deployment Scenarios
- page 17 and register your appliance directly from the
management interface once you reach Activating Licenses -
page 40.
For a High Availability (HA) configuration, you must use
NetVanta Security Portal to associate a backup unit that can
share the Security Services licenses with your primary
appliance.
If you do not yet have a NetVanta Security Portal account, you
can use NetVanta Security Portal to register your ADTRAN
appliance and activate or purchase licenses for Security
Services, ViewPoint Reporting and other services, support, or
software before you even connect your device. This method
allows you to prepare for your deployment before making any
changes to your existing network.
Note that your ADTRAN NetVanta 2730 appliance does not
need to be powered on during account creation or during the
registration and licensing process on www.adtran.com/
NetVantaSecurityPortal.

ADTRAN NetVanta 2730 Getting Started Guide Page 13
Creating a NetVanta Security Portal Account
To create a NetVanta Security Portal account, perform the
following steps:
1. In your browser, navigate to www.adtran.com/
NetVantaSecurityPortal.
2. In the login screen, click the Not a registered user? link.
3. Complete the Registration form and click Register.
4. Verify the information is correct and click Submit.
5. In the screen confirming that your account was created,
click Continue.
Registering and Licensing Your Appliance on
NetVanta Security Portal
This section contains the following subsections:
•Product Registration - page 13
•Licensing Security Services and Software - page 14
•Managing Licenses - page 14
•Registering a Second Appliance as a Backup - page 15
Product Registration
You must register your ADTRAN security appliance on
NetVanta Security Portal to enable full functionality.
1. Login to your NetVanta Security Portal account. If you do
not have an account, you can create one at
www.adtran.com/NetVantaSecurityPortal.
2. On the main page, type the appliance serial number in
the Register A Product field. Then click Next.
3. On the My Products page, under Add New Product,
type the friendly name for the appliance, select the
Product Group if any, type the authentication code into
the appropriate text boxes, and then click Register.
4. On the Product Survey page, fill in the requested
information and then click Continue.

Page 14 Registering and Licensing Your Appliance on NetVanta Security Portal
Licensing Security Services and Software
The Service Management - Associated Products page in
NetVanta Security Portal lists security services, support options,
and software that you can purchase or try with a free trial. For
details, click the Info button. Your current licenses are indicated
in the Status column with either a license key or an expiration
date. You can purchase additional services now or at a later
time.
The following products and services are available for the
ADTRAN NetVanta 2730:
• Service Bundles:
• Client/Server Anti-Virus Suite
• Comprehensive Gateway Security Suite
• Gateway Services:
• Gateway Anti-Virus, Anti-Spyware,
Intrusion Prevention, Application Firewall
• Global Management System
• Content Filtering: Premium Edition
• Stateful High Availability Upgrade
• Desktop and Server Software:
• Enforced Client Anti-Virus and Anti-Spyware
• Global VPN Client
• Global VPN Client Enterprise
• Support Services:
• Dynamic Support 8x5
• Dynamic Support 24x7
• Software and Firmware Updates
Managing Licenses
To manage your licenses, perform the following tasks:
1. In the NetVanta Security Portal Service Management -
Associated Products page, check the Applicable Services
table for services that your ADTRAN appliance is already
licensed for. Your initial purchase may have included
security services or other software bundled with the
appliance. These licenses are enabled on NetVanta
Security Portal when the ADTRAN appliance is delivered to
you.
2. If you purchased a service subscription or upgrade from a
sales representative separately, you will have an
Activation Key for the product. This key is emailed to you
after online purchases, or is on the front of the certificate
that was included with your purchase. Locate the product
on the Service Management page and click Enter Key in
that row.
3. In the Activate Service page, type or paste your key into
the Activation Key field and then click Submit. Depending
on the product, you will see an expiration date or a license
key string in the Status column when you return to the
Service Management page.

ADTRAN NetVanta 2730 Getting Started Guide Page 15
4. To license a product of service, do one of the following:
• To try a Free Trial of a service, click Try in the Service
Management page. A 30-day free trial is immediately
activated. The Status page displays relevant
information including the activation status, expiration
date, number of licenses, and links to installation
instructions or other documentation. The Service
Management page is also updated to show the status
of the free trial.
• To purchase a product or service, click Buy Now.
5. In the Buy Service page, type the number of licenses you
want in the Quantity column for either the 1 year, 2 year, or
3 year license row and then click Add to Cart.
6. In the Checkout page, follow the instructions to complete
your purchase.
The NetVanta Security Portal server will generate a license key
for the product. The key is added to the license keyset. You can
use the license keyset to manually apply all active licenses to
your ADTRAN appliance.
Registering a Second Appliance as a Backup
To ensure that your network stays protected if your ADTRAN
appliance has an unexpected failure, you can purchase a
license to associate a second appliance of the same model as
the first in a High Availability (HA) pair. After registering and
associating the second appliance, this appliance will
automatically share the Security Services licenses of the
primary appliance.
To register a second appliance and associate it with the primary,
perform the following steps:
1. Login to your NetVanta Security Portal account.
2. On the main page, in the Register A Product field, type the
appliance serial number and then click Next.
3. On the My Products page, under Add New Product, type
the friendly name for the appliance, select the Product
Group if any, type the authentication code into the
appropriate text boxes, and then click Register.
4. On the Product Survey page, fill in the requested
information and then click Continue. The Create
Association Page is displayed.
5. On the Create Association Page, click the radio button to
select the primary unit for this association, and then click
Continue. The screen only displays units that are not
already associated with other appliances.
