Fortinet FSM-500F User manual

500F Collector Configuration
Guide
FortiSIEM 6.3.1

FORTINET DOCUMENT LIBRARY
https://docs.fortinet.com
FORTINET VIDEO GUIDE
https://video.fortinet.com
FORTINET BLOG
https://blog.fortinet.com
CUSTOMER SERVICE & SUPPORT
https://support.fortinet.com
FORTINET TRAINING & CERTIFICATION PROGRAM
https://www.fortinet.com/training-certification
NSE INSTITUTE
https://training.fortinet.com
FORTIGUARD CENTER
https://www.fortiguard.com
END USER LICENSE AGREEMENT
https://www.fortinet.com/doc/legal/EULA.pdf
FEEDBACK
Email: [email protected]
11/17/2021
FortiSIEM 6.3.1 500F Collector Configuration Guide

TABLEOFCONTENTS
Appliance Setup 4
Fresh Installation 4
Step 1: Rack mount the FSM-500F Appliance 4
Step 2: Power On the FSM-500F Appliance 4
Step 3: Verify System Information 4
Step 4: Configure FortiSIEM via GUI 5
Step 5: Register Collectors 11
Step 6: Using FortiSIEM 14
Factory Reset 15
Step 1: Uninstall FortiSIEM application 15
Step 2: Reinstall FortiSIEM application 15
Upgrading FortiSIEM Collector 15
Appliance Re-image 15
Step 1: Create Bootable Linux Image 16
Step 2: Staging the FortiSIEM Collector Image 16
Step 3: Prepare 500F by removing FSM 17
Step 4: Configure 500F BIOS to Boot into USB Drive 17
Step 5: Re-image the 500F 17
FortiSIEM 6.3.1 500F Collector Configuration Guide 3
Fortinet Technologies Inc.

Appliance Setup
This document describes how to setup the FSM-500F appliance.
lFresh Installation
lFactory Reset
lUpgrading FortiSIEM Collector
lAppliance Re-image
Fresh Installation
lStep 1: Rack mount the FSM-500F Appliance
lStep 2: Power On the FSM-500F Appliance
lStep 3: Verify System Information
lStep 4: Configure FortiSIEM via GUI
lStep 5: Register Collectors
lStep 6: Using FortiSIEM
Step 1: Rack mount the FSM-500F Appliance
1. Follow FortiSIEM 500F QuickStart Guide to mount FSM-500F into rack.
2. Connect FSM-500F to the network by connecting an Ethernet cable to Port1.
Before proceeding to the next step, connecting Ethernet cable to Port1 is required for Network
configuration.
Step 2: Power On the FSM-500F Appliance
1. Make sure the FSM-500F device is connected to a Power outlet and an Ethernet cable is connected to Port1.
2. Power On the FSM-500F device.
Step 3: Verify System Information
1. Connect to the FSM-500F appliance using VGA port or Console port.
2. Login as user root with password ProspectHills.
3. You will be asked to change your password. Once you change the password, you will be logged out. Login again
with your new password.
FortiSIEM 6.3.1 500F Collector Configuration Guide 4
Fortinet Technologies Inc.

Appliance Setup
Note this password—you will need it in a later step.
4. Run get to check the available FortiSIEM commands.
5. Use the below commands to check the hardware information. After running each command, ensure that there are
no errors in the displayed output.
Command Description
get system status Displays system name, version and serial
number.
diagnose hardware info Displays system hardware information like
CPUs, Memory and RAID information.
diagnose interface detail
port0
Displays interface status.
Step 4: Configure FortiSIEM via GUI
1. Log in as user root with the password you set in Step 3 above.
2. At the command prompt, go to /usr/local/bin, and enter configFSM.sh. For example:
# configFSM.sh
A simple GUIwill open.
3. In the GUI, select 1 Set Timezone, and then press Next.
4. Select your Region, then press Next.
FortiSIEM 6.3.1 500F Collector Configuration Guide 5
Fortinet Technologies Inc.

Appliance Setup
5. Select your Country, and press Next.
6. Select the Country and City for your timezone, and press Next.
7. Select 1 Collector. Press Next.
FortiSIEM 6.3.1 500F Collector Configuration Guide 6
Fortinet Technologies Inc.

Appliance Setup
8. If you want to enable FIPS, then choose 2 install_with_fips. Otherwise, choose 1 install_without_fips. You have
the option of enabling FIPS (option 3) or disabling FIPS (option 4) later.
Note: After Installation, a 5th option to change your network configuration (5 change_network_config) is
available. This allows you to change your network configuration and/or host name.
9. Determine whether your network supports IPv4-only, IPv6-only, or both IPv4 and IPv6 (Dual Stack). Choose 1for
IPv4-only, choose 2for IPv6-only, or choose 3for both IPv4 and IPv6.
10. If you choose 1(IPv4) or choose 3(Both IPv4 and IPv6), and press Next, then you will move to step 11. If you
choose 2(IPv6), and press Next, then skip to step 12.
11. When prompted, enter the information for these network components to configure the Static IP
address:IPAddress,Netmask,Gateway,DNSServer(s). Configure the network by entering the following fields.
Press Next.
Note:Configuring a DNSServer to resolve external addresses as updates to remote repositories will be required in
FortiSIEM 6.3.1 500F Collector Configuration Guide 7
Fortinet Technologies Inc.

Appliance Setup
the future.
Note the IP Address—you will need it in a later step.
Option Description
IPv4 Address The Collector's IPv4 address
NetMask The Collector's subnet
Gateway Network gateway address
DNS1, DNS2 Addresses of the DNS servers
12. If you chose 1in step 9, then you will need to skip to step 13. If you chose 2or 3in step 9, then you will configure the
IPv6 network by entering the following fields, then press Next.
Option Description
IPv6 Address The Collector's IPv6 address
prefix
(Netmask)
The Collector's IPv6 prefix
Gateway ipv6 IPv6 Network gateway address
DNS1 IPv6,
DNS2 IPv6
Addresses of the IPv6 DNS server 1 and DNS
server2
FortiSIEM 6.3.1 500F Collector Configuration Guide 8
Fortinet Technologies Inc.

Appliance Setup
Note: If you chose option 3in step 9 for both IPv4 and IPv6, then even if you configure 2 DNS servers for IPv4 and
IPv6, the system will only use the first DNS server from IPv4 and the first DNS server from the IPv6 configuration.
Note: In many dual stack networks, IPv4 DNS server(s) can resolve names to both IPv4 and IPv6. In such
environments, if you do not have an IPv6 DNS server, then you can use public IPv6 DNS servers or use IPv4-
mapped IPv6 address.
13. Configure Hostname for Collector. Press Next.
Note: FQDN is no longer needed.
14. Test network connectivity by entering a host name that can be resolved by your DNS Server (entered in the
previous step) and responds to ping. The host can either be an internal host or a public domain host like
google.com. For migration to complete, the system still needs https connectivity to FortiSIEM OS update servers:
os-pkgs-cdn.fortisiem.fortinet.com and os-pkgs-c8.fortisiem.fortinet.com. Press Next.
Note: By default, “google.com” is shown for the connectivity test, but if configuring IPv6, you must enter an
accessible internally approved IPv6 DNS server, for example: “ipv6-dns.fortinet.com"
Note:When configuring both IPv4 and IPv6, only testing connectivity for the IPv6 DNSis required because the IPV6
takes higher precedence. So update the host field with an approved IPv6 DNSserver.
FortiSIEM 6.3.1 500F Collector Configuration Guide 9
Fortinet Technologies Inc.

Appliance Setup
15. The final configuration confirmation is displayed. Verify that the parameters are correct. If they are not, then press
Back to return to previous dialog boxes to correct any errors. If everything is OK, then press Run.
The options are described in the following table.
Option Description
-r The FortiSIEM component being configured
-z The time zone being configured
-i IPv4-formatted address
-m Address of the subnet mask
-g Address of the gateway server used
--host Host name
-f FQDN address: fully-qualified domain name
-t The IP type. The values can be either 4(for ipv4)
or 6(for v6) or 64 (for both ipv4 and ipv6).
--dns1, --dns2 Addresses of the DNS servers
FortiSIEM 6.3.1 500F Collector Configuration Guide 10
Fortinet Technologies Inc.

Appliance Setup
Option Description
--i6 IPv6-formatted address
--m6 IPv6 prefix
--g6 IPv6 gateway
-o Installation option.
-z Time zone. Possible values are US/Pacific,
Asia/Shanghai,Europe/London, or
Africa/Tunis
--testpinghost The URL used to test connectivity
Once the configuration is complete, the system reboots automatically.
Step 5: Register Collectors
Collectors can be deployed in Enterprise or Service Provider environments.
lEnterprise Deployments
lService Provider Deployments
Enterprise Deployments
For enterprise deployments, follow these steps:
1. Log in to Supervisor with Admin privileges.
2. Go to ADMIN>Settings > System >Event Worker.
a. Enter the IP of the Worker node. If a Supervisor node is only used, then enter the IP of the Supervisor node.
Multiple IP addresses can be entered on separate lines. In this case, the Collectors will load balance the upload
of events to the listed Event Workers.
Note: Rather than using IP addresses, a DNS name is recommended. The reasoning is, should the IP
addressing change, it becomes a matter of updating the DNS rather than modifying the Event Worker IP
addresses in FortiSIEM.
b. Click OK.
3. Go to ADMIN > Setup > Collectors and add a Collector by entering:
a. Name – Collector name.
b. Guaranteed EPS – This is the EPS that the Collector will always be able to send. It could send more if there is
excess EPS available.
c. Start Time and End Time – set to Unlimited.
4. SSH to the Collector and run following script to register Collectors:
phProvisionCollector --add <user> '<password>' <Super IP or Host> <Organization>
<CollectorName>
The password should be enclosed in single quotes to ensure that any non-alphanumeric characters are escaped.
a. Set user and password use the admin User Name and password for the Supervisor.
b. Set Super IP or Host as the Supervisor's IP address.
c. Set Organization. For Enterprise deployments, the default name is Super.
d. Set CollectorName from Step 2a.
FortiSIEM 6.3.1 500F Collector Configuration Guide 11
Fortinet Technologies Inc.

Appliance Setup
The Collector will reboot during the Registration.
5. Go to ADMIN > Health > Collector Health to see the Collector status.
Service Provider Deployments
For Service Provider deployments, follow these steps.
1. Log in to Supervisor with Admin privileges.
2. Go to ADMIN > Settings > System > Event Worker.
a. Enter the IP of the Worker node. If a Supervisor node is only used, then enter the IP of the Supervisor node.
Multiple IP addresses can be entered on separate lines. In this case, the Collectors will load balance the upload
of events to the listed Event Workers.
Note: Rather than using IP addresses, a DNS name is recommended. The reasoning is, should the IP
addressing change, it becomes a matter of updating the DNS rather than modifying the Event Worker IP
addresses in FortiSIEM.
b. Click OK.
c.
FortiSIEM 6.3.1 500F Collector Configuration Guide 12
Fortinet Technologies Inc.

Appliance Setup
3. Go to ADMIN > Setup > Organizations and click New to add an Organization.
4. Enter the Organization Name,Admin User,Admin Password, and Admin Email.
5. Under Collectors, click New.
6. Enter the Collector Name,Guaranteed EPS,Start Time, and End Time.
The last two values could be set as Unlimited.Guaranteed EPS is the EPS that the Collector will always be able to
send. It could send more if there is excess EPS available.
FortiSIEM 6.3.1 500F Collector Configuration Guide 13
Fortinet Technologies Inc.

Appliance Setup
7. SSH to the Collector and run following script to register Collectors:
phProvisionCollector --add <user> '<password>' <Super IP or Host> <Organization>
<CollectorName>
The password should be enclosed in single quotes to ensure that any non-alphanumeric characters are escaped.
a. Set user and password use the admin User Name and password for the Supervisor.
b. Set Super IP or Host as the Supervisor's IP address.
c. Set Organization as the name of an organization created on the Super.
d. Set CollectorName from Step 6 by command line, for example:
# phProvisionCollector --add admin Admin*11 172.30.53.130 ORG1289 CO1289
A message will display after the completion:
Continuing to provision the Collector
This collector is registered successfully. Normal Exit and restart of phMonitor
after collector license registration.
The Collector will reboot during the Registration.
8. Go to ADMIN > Health > Collector Health to see the status of the Collector.
Step 6: Using FortiSIEM
Refer to the FortiSIEM User Guide for detailed information about using FortiSIEM.
FortiSIEM 6.3.1 500F Collector Configuration Guide 14
Fortinet Technologies Inc.

Appliance Setup
Factory Reset
Follow the steps below to perform factory reset on FortiSIEM FSM-500F.
Step 1: Uninstall FortiSIEM application
1. Connect FortiSIEM device using VGA or Console port.
2. Login as ‘root’ user with password 'ProspectHills'.
3. To check the available FortiSIEM commands, run get.
4. To uninstall FortiSIEM, run execute fsm-clean.
This script will uninstall FortiSIEM Collector.
Step 2: Reinstall FortiSIEM application
1. Power on the hardware.
2. Login as ‘root’ user with password 'ProspectHills'.
3. To check Hardware status and RAID information, run diagnose hardware info.
Note: RAID Information is NOT applicable to FSM-500F model.
4. To install FortiSIEM Collector, run ‘execute factoryreset’.
Note: This script takes 5 minutes to complete FortiSIEM Collector installation.
Follow the steps under Appliance Setup to configure FSM-500F.
Upgrading FortiSIEM Collector
For upgrading FortiSIEM Collector, refer to the Upgrade Guide.
Appliance Re-image
Ensure that the following prerequisites are met before re-imaging FortiSIEM.
Hardware Software
Peripherals
lUSB Keyboard
lUSB Mouse
lVGA Monitor
USB Thumbdrive
l4 GB Thumbdrive (for Linux installation)
l8 GB Thumbdrive (for FortiSIEM appliance
image)
lUbuntu Desktop Setup Files
lRufus (Bootable USB Utility)
lFortiSIEM Appliance Image
FortiSIEM 6.3.1 500F Collector Configuration Guide 15
Fortinet Technologies Inc.

Appliance Setup
Follow the below steps to re-image FortiSIEM.
Step 1: Create Bootable Linux Image
1. Connect 4 GB USB drive to the system (desktop or laptop).
2. Open Rufus.
3. Select the following settings for the USB:
a. Partition scheme and target system type: MBR partition scheme for BIOS or UEFI
b. File system: FAT32
c. Cluster size: 4096 bytes (Default)
d. Quick Format: Enable
e. Create a bootable disk using: ISO image
4. Click on the 'CD-ROM' icon and select the Ubuntu Setup ISO.
5. Click Start and allow Rufus to complete.
Once finished, the disk is ready to boot.
Note: Alternatively, you can use the Ubuntu guide for creating a USB drive with Ubuntu.
Step 2: Staging the FortiSIEM Collector Image
Staging can be done in one of two ways. The first is through USB. The second is through an NFS server. Follow Step 2A
for staging via USB. Follow Step 2B for staging via an NFSserver.
Step 2A:USBStaging
1. Connect an 8 GB USB Drive to the system (desktop or laptop).
2. Open Windows Explorer > right-click Drive > click Format.
3. Select the following options:
a. File system: NTFS
b. Allocation unit size: 4096 bytes
c. Quick Format: Enable
4. Copy the image file to USB drive. For example:
FSM_Full_All_RAW_HARDWARE_6.3.1.0338.zip
5. Safely remove the USB drive from the desktop or laptop by unmounting it through the operating system.
Step 2B:NFSStaging
1. Prepare an NFSserver. Information on setup can be found here.
2. Download FSM_Full_All_RAW_HARDWARE_6.3.1.0338.zip from the support site.
3. Create and export /FortiSIEM_HW_IMG.
4. Upload the FSM_Full_All_RAW_HARDWARE_6.3.1.0338.zip to /FortiSIEM_HW_IMG.
5. Go to the /FortiSIEM_HW_IMGdirectory by running the following command.
cd /FortiSIEM_HW_IMG
6. run the following command to unzip the zip file.
FortiSIEM 6.3.1 500F Collector Configuration Guide 16
Fortinet Technologies Inc.

Appliance Setup
unzip -c FSM_Full_All_RAW_HARDWARE_6.3.1.0338.zip
7. Verify that the NFS server is reachable by the 500F appliance and is allowed to mount the sharepoint on the NFS
server.
Example:mount -t nfs 10.0.0.1:/FortiSIEM_HW_IMG /mnt
Step 3: Prepare 500F by removing FSM
1. Connect to the console/SSH of the FortiSIEM appliance.
2. Run the following command: execute fsm-clean
3. Allow this command to run and power-off the FortiSIEM appliance.
Step 4: Configure 500F BIOS to Boot into USB Drive
1. Connect the 4 GB USB drive to the FortiSIEM appliance.
2. Power on the FortiSIEM appliance.
3. During the boot screen, press F11 to login to the boot options.
4. Select the option to enter into the BIOS set up.
5. Select the option for Boot options.
6. Select the 'USB drive'.
7. Save the options and quit set up.
Step 5: Re-image the 500F
If you followed Step 2A USBStaging, continue with Step 5A here. If you followed Step 2B NFSStaging, follow Step 5B
here.
Step 5A:Reimaging from USB Staging
1. Power on the FortiSIEMappliance.
2. Once the FortiSIEMappliance loads from the USBdrive, click Try Ubuntu.
3. Connect the 8GBUSBdrive to the FortiSIEM appliance.
4. Open a terminal.
5. Type the following command to identify the FortiSIEMboot disk (29.5GB):
sudo fdisk –l
Note: This drive will be referred to as /dev/sdb in the following steps.
6. Enter into root while in the terminal using the following command:
sudo -s
7. Determine the mount point of this drive by using the following command:
df -l
Note:For this guide, the assumption for the 8GB mount point is: /media/ubuntu/123456789/*
8. Copy the image from the 8GB disk to the FortiSIEM boot disk.
FortiSIEM 6.3.1 500F Collector Configuration Guide 17
Fortinet Technologies Inc.

Appliance Setup
9. Extract the zipped raw image and copy the image into SATA disk (32GB). For example, use the command:
# unzip -c FSM_Full_All_RAW_HARDWARE_6.3.1.0338.zip
# dd of=/dev/sdb bs=1M status=progress
10. Once this is completed, power off the FortiSIEM appliance using the following commands:
shutdown –h now
11. After shutdown, remove both USB drives from the FortiSIEM appliance.
12. Power on FortiSIEM appliance.
13. Reinstall FortiSIEM application (as in Factory Reset - step 2).
Step 5B:Reimaging from NFSServer Staging
1. Power on the FortiSIEMappliance.
2. Once the FortiSIEMappliance loads from the USBdrive, click Try Unbuntu.
3. Open a terminal.
4. Type the following command to identify the FortiSIEMboot disk (29.5GB):
sudo fdisk -l
Note:This drive will be referred to as /dev/sdb in the following steps.
5. Enter into root while in the terminal by using the following command:
sudo -s
6. Mount the NFSshare to the ubuntu boot environment.
Note: Assuming the REMOTEsite is 10.0.0.1, and remote share is:/FortiSIEM_HW_IMG, you would run:
# mount -t nfs 10.0.0.1:/FortiSIEM_HW_IMG /mnt
7. Directly write the image from the NFS share to the local HDD. For example, use the command:
# dd if=/mnt/FSM_Full_All_RAW_HARDWARE_6.3.1.0338.img of=/dev/sdb bs=1M
status=progress
8. Once this is completed, power off the FortiSIEM appliance using the following commands:
# shutdown –h now
9. After shutdown, remove both USBdrives from the FortiSIEMappliance.
10. Power on the FortiSIEMappliance.
11. Reinstall the FortiSIEMapplication (as in Factory Reset - step 2).
FortiSIEM 6.3.1 500F Collector Configuration Guide 18
Fortinet Technologies Inc.

www.fortinet.com
Copyright© 2021 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., and other Fortinet names herein
may also be registered and/or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners. Performance and other metrics contained herein were
attained in internal lab tests under ideal conditions, and actual performance and other results may vary. Network variables, different network environments and other conditions may affect performance
results. Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding written contract,
signed by Fortinet’s General Counsel, with a purchaser that expressly warrants that the identified product will perform according to certain expressly-identified performance metrics and, in such event, only
the specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal
conditions as in Fortinet’s internal lab tests. Fortinet disclaims in full any covenants, representations, and guarantees pursuant hereto, whether express or implied. Fortinet reserves the right to change,
modify, transfer, or otherwise revise this publication without notice, and the most current version of the publication shall be applicable.
