SMART Remote Programmer English
5Copyright Silca S.p.A 2016
OPERATING GUIDE SOFTWARE FEATURES
WARNINGS
1 - FOR PROPER AND RELIABLE OPERATION, KEEP THE SMART REMOTE PROGRAMMER AWAY FROM ANY
SOURCES OF RADIO INTERFERENCE, SUCH AS:
- CORDLESS PHONES
- ELECTRIC MOTORS
- NEON LIGHTS
- WI-FI MODEMS
2 - BEFORE INSTALLING “SMART REMOTE PROGRAMMER SOFTWARE” APP, MAKE SURE THE USB CABLE
IS NOT CONNECTED TO PC
PC PROGRAM
SMART Remote Programmer Soware Program has been developed to allow interfacing the SMART Remote
programmer device with informaon released by Silca.
The program can be freely downloaded from www.silca.biz/www.ilco.us website, and it run on Windows®
Vista, 7, 8 and 10.
The first me the program is run, SMART Remote programmer device must be connected to PC, using a wizard
(see secon “First program start”). Device must be connected to PC, at every program start.
FIRST PROGRAM START
Before starng applicaon: make sure SMART Remote Programmer device is connected to PC through a
special USB cable (supplied with the device).
USB driver installation procedure:
- For Windows 8 and Windows 10 ®Operang systems, connecng your PC to the internet, drivers are auto-
macally installed by the operang system.
- For Vista and Windows 7 ®Operang systems, you will have to manually install USB drivers stored in the
Program File folder...\ Silca Soware\Silca SMART Remote Programmer\driver.
The first time the program is run, the following actions are required:
1. Program configuraon;
2. Device mandatory registraon;
3. Device configuraon;

SMART Remote Programmer
Copyright Silca S.p.A 2016
English
6
PROGRAM CONFIGURATION
The following window allows you to configure the program.
Following informaon should be entered:
Language: This is the language of the program
Preferred region:favourite area for displaying auto-selectable models (AMERICA, ASIA, EUROPE)
Brand: ILCO/SILCA reference mark for displaying arcle codes and remote control part code to be used
In Area 1, buons are available to allow you to move forward or backward within windows during the first
configuraon of the program.
HOW TO EDIT SOFTWARE PREFERENCES
Once you have set soware preferences, you can change them by selecng the icon and by clicking in
the Save buon you can save all entered sengs.

SMART Remote Programmer English
7Copyright Silca S.p.A 2016
HOW TO REGISTER AND CONFIGURE YOUR DEVICE
1. REGISTRATION
To proceed to the next step, you need to REGISTER your device via web through the icon .
Make sure your pc has a reliable Internet connecon before proceeding.
Please fill out the form with the required data and send it back.
You will receive a verificaon email containing a link that you’ll need to click or tap to confirm.
2. CONFIGURATION
The following window allows you to display device informaon:
-Serial number: connected device serial number
-Firmware: firmware version installed on your device
-Database: database version inside your device
-Soware: SRP program version installed
Note: if no data is displayed, please make sure the device is connected to PC via USB.
In Area 1, buons are available to allow you to move forward or backward within windows during the first
configuraon of the program.
In Area 2, three Update buons are available to allow you upgrading firmware of your device and updang
program database, and the program itself, with the latest version available online.

SMART Remote Programmer
Copyright Silca S.p.A 2016
English
8
LAUNCHING A PROGRAM
In Area 1 buons are available to allow you to access the various funcons displayed in Area 2.
Area 1 descrip on bu ons:
This buon leads you to the start view of the program;
This buon leads you to the search funcon vehicle models and the related remote control
programming (see secon "Search your vehicle model");
This buon leads you to the program configuraon funcon (see secon "Program Configu-
raon”);
This buon leads you to SMART remote programmer device informaon (see secon “In-
formaon”);
This buon leads you to programming history display funcon (see secon “Historic
Report”);
This buon leads you to measuring remote control frequency;
This buon leads you to close the program;

SMART Remote Programmer English
9Copyright Silca S.p.A 2016
SEARCH YOU VEHICLE MODEL
This page allows you to search your car model whose remote control need to be preset:
This page includes 3 Areas:
Area 1: display filters input area applied to this list in Area 2;
Area 2: Informaon display area that meets filters entered in area1.
Area 3: commands area associated with this page.
In area 1 some informaon is available to be entered to search models, that will be displayed in area 2
Area 1 - there are the following filters:
-Brand: car brand list in the database;
-Model: car model list for the selected brand;
-Year: reference year of the selected car model;
-Area: car models reference area seng to be displayed (you can find the default value field sengs in the
“Program Configuraon” page;
-Chassis code: chassis reference number;
-FCC: FCC cerficaon reference ID of the original remote control;
-Number of buons: the number of buons available in the original remote control;
-Key profile: ILCO/SILCA key arcle used in car models;
-Transponder: type of transponder used in car models;
-Frequency: transmission frequency used by the original remote control;
-Modulaon: Transmission modulaon used by the original remote control;
The list available in area 2 contains informaon about models that meets filters entered in Area 1; the list with
all models will contain the following columns:
Brand: vehicle brand;
Model: vehicle model;
Year: informaon validity start date of the vehicle model;
Year: informaon validity end date of the vehicle model;
Area: vehicle model reference area (America, Asia, Europe);
Frequency: reference frequency of the original remote control;
Number of buons: the number of buons available in the remote control;
Remote Control Reference: ILCO/SILCA remote control code

SMART Remote Programmer
Copyright Silca S.p.A 2016
English
10
By selecng, with the mouse, the line relang to a model, some addional informaon about it will appear,
such as:
-Vehicle informaon (Brand, Model; Term of validity; Geographical area; Chassis Code)
-Original remote control informaon (Frequency, number of buons; buons funcon; Image)
-ILCO/SILCA remote control informaon (Remote control code; Number of buons; Type;Transponder to be
used for programming and/or cloning; setup code to be used for mechanical duplicaon )
Addi onal notes:
The buon funcons shown below are also available:
This buon applies filters entered in Area 1 to display items in Area 2;
This buon resets all the filter values in the area 1;
This buon leads to start the programming stage of the remote control according to the
selected row in Area 2;
This buon leads you to display an enlarged image;
This buon allows you to view the manual procedure;
Note: please do not move the remote control during programming.

SMART Remote Programmer English
11Copyright Silca S.p.A 2016
REMOTE CONTROL PROGRAMMING
By pressing the buon from the “vehicle model search” page we proceed to the remote control pro-
gramming for the selected model, and the following page will appear:
To proceed to place the remote control in the device area, as shown in the image below:

SMART Remote Programmer
Copyright Silca S.p.A 2016
English
12
and press any buon on the remote control.
Detecng remote control, the program will automacally start the programming procedure, and the
following page will appear:
Upon compleon of the procedure, a message will appear indicang that the process is complete, and the
remote control will be enabled for the next vehicle programming.
By pressing the buon on the page the operaon is cancelled, and the program goes back to the
previous page.

SMART Remote Programmer English
13Copyright Silca S.p.A 2016
INFORMATION
Device informaon is available on these pages:
Window 1: In the event that the device is not connected, we recommend connecng it to your PC and update
the status of the connecon using buon;
Once the devices is connected, appears:
Window 2: device informaon display area:
-Serial number: connected device serial number;
-Firmware: firmware version installed on your device;
-Database: database version inside your device;
-Soware: SRP program version installed;
Note: if no data is displayed, please make sure the device is connected to PC via USB.
In Area 1, three Update buons are available to allow you upgrading firmware of your device and updang
program database, and the program itself, with the latest version available online.
In Area 2 , a buon is available: Send log, enables you to send a log-file to the remote server.

SMART Remote Programmer
Copyright Silca S.p.A 2016
English
14
HISTORIC REPORT
On this page you can consult the programming history performed by the user on a pc.
2 Areas are available on this page:
Area 1: display filters input area applied to this list in Area 2;
Area 2: Informaon display area that meets filters entered in area1.
In area 1 the following items are available:
- Brand: car brands list;
-Model: car model list for the selected brand;
-Clear : this buon resets the entered filters.
Depending on the values entered in area 1, model meeng filters will be displayed in area 2.
In area 2, a list with the following informaon is available:
-Brand: vehicle brand;
-Model: vehicle model;
-Year: informaon validity start date of the vehicle model;
-Year: informaon validity end date of the vehicle model;
-Area: vehicle model reference area (America, Asia, Europe);
-Number: number of programmed remote controls.

SMART Remote Programmer English
15Copyright Silca S.p.A 2016
REPLACING / INSERTING BATTERIES
Lithe baery housing cover (Fig. 6). Remove the exhausted baeries and fit four new 1.5V alkaline baeries
(AA), taking care to posion the poles properly. Replace and close the cover.
WARNING: DANGER OF EXPLOSION IF THE BATTERY IS REPLACED WITH ONE OF THE WRONG TYPE
WASTE DISPOSAL
INFORMATION FOR USERS OF PROFESSIONAL EQUIPMENT
From “Actuaon of Direcve 2012/19/EU regarding Waste Electrical and Electronic Equipment (WEEE)”
The symbol of a crossed waste bin found on equipment or its packing indicates that at the end of the product’s
useful life it must be collected separately from other waste so that it can be properly treated and recycled .
In parcular, separate collecon of this professional equipment when no longer in use is organised and
managed :
a. directly by the user when the equipment was placed on the market before 31 December 2010 and
the user personally decides to eliminate it without replacing it with new equivalent equipment
designed for the same use
b. by the manufacturer, that is to say the subject which was the first to introduce and market new
equipment that replaces previous equipment, when the user decides to eliminate equipment
placed on the market before 31 December 2010 at the end of its useful life and replace it with an
equivalent product designed for the same use. In this laer case the user may ask the manufacturer
to collect the exisng equipment;
c.by the manufacturer, that is to say the subject which was the first to introduce and market new
equipment that replaces previous equipment, if it was placed on the market aer 31 December
2010 ;
With reference to portable baeries/accumulators, when such products are no longer in use the user shall
take them to suitable authorised waste treatment facilies.
Suitable separate collecon for the purpose of forwarding discarded equipment and baeries/accumulators
for recycling, treatment or disposal in an environmentally friendly way helps to avoid possible negave effects
on the environment and human health and encourages re-use and/or recycling of the materials making up
the equipment.
To remove baeries/accumulators, consult the manufacturer’s specific instrucons: (see relevant chapter in
the users’ manual).
The sancons currently provided for by law shall apply to users who dispose of equipment, baeries and
accumulators in unauthorised ways .

SMART Remote Programmer
Copyright Silca S.p.A 2016
English
16
FCC/IC INFORMATION
This device complies with Part 15 of the FCC Rules. Operaon is subject to the following two condions:
(1) This device not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operaon. Changes or modificaons on not expressly
approved by the party responsible for compliance could void the user’s authority to operate the equipment.
“This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protecon against harmful inter-
ference in a residenal installaon. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instrucons, may cause harmful interference to radio
communicaons. However, there is no guarantee that interference will not occur in a parcular installaon.
If this equipment does cause harmful interference to radio or television recepon, which can be determined
by turning the equipment offand on, the user is encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separaon between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.”
ID FCC: 2AHH9-IRKEP1
Contains FCC ID :2ABN2-RFBMS01

SMART Remote Programmer Italiano
17
Copyright Silca S.p.A. 2016
GUIDA OPERATIVA FUNZIONALITA’ SOFTWARE
AVVERTENZE
1 - PER UN CORRETTO ED AFFIDABILE FUNZIONAMENTO, POSIZIONARE SMART REMOTE PROGRAMMER
LONTANO DA TUTTE LE SORGENTI CHE POSSONO GENERARE DISTURBI RADIO QUALI:
- TELEFONI CORDLESS
- MOTORI ELETTRICI
- LUCI AL NEON
- MODEM WI-FI
2 - NON INSERIRE IL CAVO USB NEL PC PRIMA DELL’INSTALLAZIONE DEL PROGRAMMA “SMART REMOTE
PROGRAMMER SOFTWARE”
PROGRAMMA A PC
Il programma SMART Remote programmer Soware è stato sviluppato per consenre di interfacciare il dispo-
sivo SMART Remote programmer con informazioni rilasciate da Silca.
Il programma è scaricabile gratuitamente dal sito www.silca.biz/www.ilco.us e può essere installato su
Windows® versioni Vista, 7, 8 e 10.
Al primo avvio del programma è richiesto il collegamento del disposivo SMART Remote programmer al pc
mediante una procedura guidata ( vedi capitolo “Primo avvio del programma” ). Ad ogni avvio del programma
il disposivo deve essere connesso al pc.
PRIMO AVVIO DEL PROGRAMMA
Prima di avviare l’applicazione: provvedere alla connessione del disposivo SMART Remote Programmer al pc
mediante apposito cavo USB ( fornito in dotazione con il disposivo ).
Installazione dei driver USB :
- per i sistemi operavi Windows ®8 e 10 conneere il pc ad Internet, i driver vengono automacamente
installadal sistema operavo.
- per i sistemi operavi Windows ®Vista e 7 installare manualmente i driver USB presennella cartella di
installazione del programma ...\ Silca Soware\Silca SMART Remote Programmer\driver.
Al primo avvio del programma sono richieste le seguenti azioni:
1. Configurazione del programma;
2. Registrazione obbligatoria del disposivo ;
3. Configurazione del disposivo;
Italiano

SMART Remote Programmer
Copyright Silca S.p.A. 2016
Italiano
18
CONFIGURAZIONE PROGRAMMA
La finestra che segue consente di configurare il programma.
Le informazioni da inserire sono le seguen:
Lingua: lingua ulizzata dal programma
Regione preferita:area preferita per la visualizzazione dei modelli auto selezionabili (AMERICA,ASIA,EUROPA )
Marca: marchio di riferimento ILCO/SILCA per la visualizzazione dei codici arcolo ed il codice parte dei
radiocomandi da ulizzare
Nell’area 1 sono presendei booni che consentono di andare avano indietro con le finestre durante la
prima configurazione del programma.
MODIFICA PREFERENZE SOFTWARE
Una volta impostate le preferenze del Soware, è possibile modificarle selezionando l’icona e col tasto
Salva è possibile salvare le impostazioni inserite.
