Advantech PCI-7032 Installation and operation manual

PCI-7032 Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x PCI-7032 Single Board Computer
• 1 x CPU Cooler only for G2 SKU
• 1 x PCI-7032 Startup Manual
• 1 x DVD with Driver, Utility and Manual (in PDF format)
• 1 x Serial ATA HDD Data Cable
• 1 x Serial ATA HDD Power Cable
• 2 x for G2 SKU & 1for VG SKU
- Dual COM Ports Cable Kit
• 1 x ATX Feature Cable
• 1 x 4-port USB Cable Kit
• 1 x Y Cable for PS/2 Keyboard and PS/2 Mouse
• 1 x Jumper Pack
• 1 x Warranty Card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note1: For detailed contents of PCI-7032, please refer
to information on the enclosed CD-ROM (in PDF
format). Acrobat Reader is required to view any
PDFle.
PCI-7032 Intel®Atom™ J1900/N2930 CPU, PCI
Half-size SBC with DDR3L 1333/Dual Independent
Display/Dual GbE/SATA/USB/m-SATA/COM
Startup Manual
Standard SBC functions
• CPU: Soldered-down (BGA type) Intel® Atom™ 2.0 GHz
J1900 dual-core CPU or 1.83 GHz N2930 fanless CPU
• BIOS: AMI SPI BIOS (64 Mb SPI)
• System Memory: PCI-7032 supports dual channel
DDR3L 1333, up to 8GB for G2 SKU with two 204-pin
SODIMM socket (up to 4GB/DIMM), and up to 4GB for
VG SKU with one socket.
• PCI bus: Four 32 bit/33 MHz PCI bus masters to back-
plane
• Serial ports: G2 SKU with four and VG SKU with two
serialportswhichcanbeconguredasRS-232,RS-422
orRS-485(withautoowcontrol).
• PS/2 keyboard and mouse connector: One 6-pin mini-
DIN connector is located on the mounting bracket for easy
connection to a PS/2 keyboard and mouse via the Y-cable
included in the package.
• USB port:
- G2 SKU: USB 3.0 *1 (5Gbps, rear I/O), and USB 2.0*6
(480 Mbps, pin headers)
- VG SKU: USB 3.0*1 (5Gbps, rear I/O), and USB 2.0*5
(480 Mbps, 1x rear I/O, 4x pin headers)
•LPC: One LPC connector to support optional TPM
(PCA-TPM-00A1E), COM-232 (PCA-COM232-00A1E),
COM-422/485 (PCA-COM485-00A1E) modules.
• GPIO: Supports 8-bit GPIO from super I/O for general
purpose control application.
• Watchdog timer: Can generate a system reset. The
watchdog timer is programmable, with each unit equal to
one second or one minute (255 levels).
VGA Interface
• Chipset: Chipset integrated Intel®HD Graphics
• VRAM: Shared system memory. It is subject to the OS.
Video Interface Dual independent display: a choice of two
interfaces from VGA (default), LVDS (default), and DVI
• Video output:
-VGA: Supports up to 2560 x 1600 @ 60 Hz
-LVDS: 48 bit (Dual channel 24 bit) LVDS up to 1920 x
1200 @ 60 Hz
-DVI: Supports up to 2560 x 1600 @ 60 Hz
-Dual independent display: A choice of two interfaces from
VGA (Default), DVI and LVDS (Default)
Ethernet Interface
• Interface: 10/100/1000 Mbps
• Controller: LAN1: Intel® I210; LAN2: Intel® I210 (G2)
• Connector: RJ-45 with LED Connector x 2
Specications
Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com/ePlatform/
For technical support and service, please visit our
support website at:
http://support.advantech.com/support/default.aspx
This manual is for the PCI-7032 series Rev. A3.
Part No. 2001703201
Printed in China
2nd Edition
November 2022
Specications

2 PCI-7032 Startup Manual
Mechanical and Environmental
• Dimensions (L x W): 185 x 122 mm (7.3” x 4.8”)
• Power supply voltage: +5 V, +12 V, 5 Vsb
• Power requirements:
PCI-7032G2-00A1E
Intel Celeron J1900 (2GHz), DDR3L 1333, 4GB SODIMM
module*2
Voltage (V) 5 V 12 V 5 VSB
Current (A) 0.737 A 0.298 A 0.044 A
Total (W) 7.481 W
• Operating temperature: 0 ~ 60 °C (32 ~ 140 °F) (operation
humidity: 40 °C @85% RH, Non-Condensing)
• Weight:
- G2 SKU: 0.264 kg
- VG SKU:0.198 kg
Jumpers and Connectors
The board has a number of connectors and jumpers that
allowyoutocongureyoursystemtosuityourapplication.
The table below lists the function of each of the connectors
and jumpers.
Connectors
Label Function
LAN12 Dual Gigabit Ethernet connector
VGA1 VGA connector
KBMS1, KBMS2
PS/2 Keyboard and mouse connector
KBMS2 Connects chassis front panel
COM12, COM34
(G2 SKU) Serial port: RS-232/422/485
JFP1 Power Switch / Reset connector
JCASE1 Case Open
CPUFAN1 CPU FAN connector (4-pin)
LANLED1 LAN1/2 LED extension connector
HDAUD1 HD audio extension module con-
nector
USB12, USB34 USB port 1-4
USB56 USB port 5, 6
USB7 USB port 7 (USB 3.0)
SATA1 Serial ATA1 (300 MB/s)
SATA2 Serial ATA2 (300 MB/s)
MSATA1 Mini-SATA
DIMMA1 Memory connector channel A
DIMMB1 (G2
SKU) Memory connector channel B
GPIO1 GPIO pin header
LPC1 LPC connector
ATX1 12 V, 5 V, 5 VSB power connector
DVI1 DVI connector
LVDS1 LVDS connector
SMBUS1 SMBUS connector
INV1 LVDS inverter connector
Note: USB7 is reserved and can not be used.
Jumpers
Label Function
JCMOS1 CMOS clear
ATXF1 AT/ATX mode selection
JWDT1 + JOBS1 Watchdog timer output selection and
HW monitor alarm
BZ1 Buzzer setting
JLVDS1,
JLVDS2
LVDS panel voltage selection
JLVDS_VCON1 LVDS VESA, JEIDA format selection
CMOS1: CMOS clear function
Closed Pins Result
1-2 Keep CMOS data *
2-3 Clear CMOS
* Default setting
JLVDS1, JLVDS2: LVDS panel voltage selection
Closed Pins Result
L1-L2* 3.3 V*
L2-L3
5 V
L2-R2
12 V
* Default setting
JLVDS_VCON1: LVDS VESA, JEIDA Format Selection
Closed Pins Result
1-2 Pull high to +3.3 V
2-3* Pull down to GND*
123
Specications(Cont.) JumpersandConnectors(Cont.)

3 PCI-7032 Startup Manual
JWDT1 + JOBS1: Watchdog Timer Output Selection
and HW Monitor Alarm
Closed Pins Result
2-3* Enable watchdog timer*
4-5* Enable hardware monitor alarm*
* Default setting
ATXF1: AT/ATX mode selection
Closed Pins Result
Short Short Pin 1,2 AT mode*
Connect to backplane with 1700002343 ATX mode
* Default setting
JumpersandConnectors(Cont.)
BZ1: Buzzer Setting
Closed Pins Result
3-4* Enable buzzer*
1-2 Connect external speaker
* Default setting
The CD contains a driver installer program that will lead you
through the installation of various device drivers needed to
take full advantage of your CPU card.
Caution! The computer is provided with a battery-powered
real-time clock circuit. There is a danger of explo-
sion if the battery is incorrectly replaced. Replace
only with the same or equivalent type recommend-
ed by Advantech. Discard used batteries according
to the manufacturer’s instructions.
This device complies with the requirements in Part 15 of the FCC rules. Operation is subject to the following two conditions.
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
The locations of all connectors and jumpers:
Figure 1: Jumper and connector locations (G2 SKU)
COM12 SATA1
COM34
SATA2 DVI1 USB12 JCASE1 DIMMA1 ATX1 ATXF1
JFP1
SMBUS1
JOBS1+JWDT1
INV1
JLVDS2
JLVDS1
DIMMB1J1900JLVDS_VCON1
HDAUD1
LVDS1
CPUFAN1
GPIO1
VGA1
SWA1-4
JCOMS1
LAN1
LAN2
BZ1
USB7
KBMS1
KBMS2
USB34
USB56
LANLED1
JumpersandConnectors(Cont.)
Software Installation
Board Layout

4 PCI-7032 Startup Manual
Figure 2: Jumper and connector locations (VG SKU)
Figure 3: Board Layout: Jumper and Connector Locations
“
COM12
SATA1
SATA2
USB12
JCASE1
DIMMA1
ATX1
ATXF1
JFP1
SMBUS1
JOBS1+JWDT1
INV1
JLVDS2
JLVDS1
N2930
HDAUD1
JLVDS_VCON1
CPUFAN1
1
LVDS1
BZ1
GPIO1
VGA1
SWA1-2
LANLED1
LAN1
USB6
JCOMS1
USB7
KBMS1
KBMS2
USB34
DVI1
MSATA1 LPC1
BoardLayout(Cont.)
