:: Introduction
:: KIT Features
:: Key Features
:: Items Needed
:: Other Helpful Items
Associated Electrics, Inc.
26021 Commercentre Dr.
Lake Forest, CA 92630
http://www.TeamAssociated.com · http://www.RC10.com · http://twitter.com/Team_Associated · http://bit.ly/AEonFacebook
Customer Service
Tel: [phone]
Fax: [phone]
Thank you for purchasing this Team Associated product. This assembly manual contains instructions and tips for building and maintaining your new RC10TC7.
Please take a moment to read through this manual to help familiarize yourself with these steps.
We are continually changing and improving our designs; therefore, actual parts may appear slightly different than in the illustrations. New parts will be noted on
supplementary sheets located in the appropriate parts bags. Check each bag for these sheets before you start to build.
Team Associated is proud to release its next generation of 1:10th scale 4WD electric touring car kits, the RC10TC7-FT, evolving forward for the most refined
package to date.
The touring car racing class has matured to a competition level higher than ever before, and the Engineers behind the doors of Area-51 have been hard at work to
make sure the TC7 can keep pace. The RC10TC7-FT car kit comes packed full of Factory Team options and a refined suspension package with precise adjustment
resulting in a level of consistency to be unequalled.
With over four year’s development on the TC6 chassis, the RC10TC7-FT car kit rolls forward including all the Factory Team test parts Area-51 has had in the works
for the last several years. The focus was on a more precise feel with updates in suspension component composites and ultra-smooth FOX with Genuine Kashima
Coated shock bodies. The floating servo controls an updated dual bellcrank steering system with a low center of gravity and refined Ackermann range allowing
the most direct steering feeling for any track condition. Updated motor mount is centrally located to produce the most consistent chassis flex and accurate gear
alignment to help keep cornering as efficient as possible. The RC10TC7-FT gives you all the key features and options necessary to keep you at the top of the racing
circuit. All without sacrificing low part count or affordability. With its prototype sweeping the modified podium at 2015 ROAR Paved Nationals, it’s easy to see that
the RC10TC7-FT kit is… another “Champion by Design” from Team Associated!
• Updated suspension geometry
o Carbon composite material used for the best combination of
strength at minimized mass
o Optimized suspension arm length and shock mounting positions
o Pivot ball on inner hinge pin allows free pin movement at any toe
or kickup angle
o Insert system for precise adjustment of toe and inner pin width
o Independent arm mount design to allow maximum flex through
entire chassis length, resulting in better grip on all track conditions
• FOX with Genuine Kashima Coated shock bodies
o Ultra-smooth Kashima Hard Coating for minimal friction and
extended wear
o Hard coated shock shafts with polished finish
o Machined piston and bushing sets for the most precise build
o Updated bladder profile for consistent performance
• New one-piece motor mount
o Central mounting to allow free chassis flex in either direction
o One-piece design ensures proper spur/pinion gear alignment
o Floating spur helps to center flex point of top plate giving better
overall traction
• Updated drive belts
o Optimized length for better on power steering
o Softer material for a more efficient drive-train
• Updated dual bellcrank steering system
o Low profile mounting for an overall lower center of mass
o Optimized Ackermann and steering rates
o Horizontal ballstuds for fine Ackermann adjustments
o 8 precision bearings for accurate swing motion
• Floating servo mount
o Servo mounts to chassis center to allow equal chassis flex in both
directions and a tweak free assembly
o Mount ties to steering bellcrank posts for stable servo positioning
o Slotted servo mount design allows fit for almost any servo size
• Narrow chassis with optimized flex characteristics
o 2.25mm graphite laminate for optimized flex characteristics
o A narrow 88mm wide to minimize chassis dragging at maximum
chassis roll angles
o Chassis ballast mass mounting locations to fine tune mass balance
• Vertical ball stud bearing caps
o Optimized position for inner ball stud
o Vertical ballstud orientation allows for fine adjustments of roll
center height
o 3 link position options give precise control of camber gain
• Rear gear diff for maximum performance and minimal maintenance
o Lightweight design
o Durable composite construction
o Optimized for a wide “tuning window” to maximize useable
adjustability
o Hard anodized aluminum outdrives for low wear and long life
• Front spool with replaceable composite outdrives
o Outdrives allow the use of existing CVA bone blades to minimize
binding at the bearing surface
o Composite outdrives are replaceable at low cost in the event of a
CVA bone blade failure
• Titanium turnbuckles with turnbuckle eyelets for easy access to ball stud for
adjustment
• 22 precision ball bearings
Your new FT TC7 comes unassembled and requires the following items for completion. (refer to catalog section for suggestions):
• 1:10th scale electric motor and electronic speed control • 1:10th scale 190mm polycarbonate touring car body
• 3.7V-7.4V LiPo, 6.6V LiFe, or 4.8V-7.2V NiMh/NiCd battery • Polycarbonate specific paint for body
• Battery charger (suited for, and particular to, one of the batteries mentioned) • Strapping tape for battery
• 2 channel surface transmitter, 2 channel receiver, and steering servo • 1:10th scale rubber (or foam) touring car tires, wheels and inserts
• Silicone Shock Fluid (Refer to catalog for complete listings) • Silicone Diff Fluid (Refer to catalog for complete listings) • Thread Lock (AE Part #1596)
• Body Scissors (AE Part # 1737) • Reamer / Hole Punch • FT Hex Wrenches (AE Part # 1541) • FT Nut Drivers (AE Part# 1561)
• Needle Nose Pliers • Wire Cutters/ Hobby Knife • Soldering Iron • Calipers or a Precision Ruler

B
3
3x2.5mm (31500)
3x3mm (25225)
3x8mm (4670)
4x8mm (25227)
2.5x6mm (4675)
2.5x10mm (31350)
3x6mm (31541)
3x8mm (25201)
3x10mm (25202)
2x4mm (31510)
2x5mm (31511)
2.5x4mm (4673)
2.5x6mm (31520)
2.5x8mm (31521)
3x5mm (31530)
3x6mm (31531)
3x8mm (31532)
3x10mm (25211)
3x12mm (89202)
3x14mm (25187)
3x16mm (89203)
:: Hardware - 1:1 Scale View
Cap Head (shcs)
Setscrew
Notes:
Flat Head (fhcs) Button Head (bhcs)
M3 locknut (31550)
M4 locknut (91148)
Nuts (lock/plain)
1mm and 2mm
blue shims (31286)
Washer (7337)
Bulkhead Shim (4617)
0.5mm, 1mm, 2mm
Axle & Diff shim (31162)
Gear Diff Shims (31348)
Shims and Washers
1.6x5mm (91611)
2x5mm (31511)
Ball Bearings
4x7mm (31403)
4x8x3mm flanged (31331)
5x8mm (31400)
5x10x4mm (91560)
10x15x4mm (91563)
Ballstuds
Ti Nitride 3.25mm short (31374)
Black 5mm short (31280)
Ti Nitride 5mm short (31288)
Silver 5mm long (31283)
Ti Nitride 5mm long (31291)
Black 8mm short (31281)
Ti Nitride 8mm short (31289)
Silver 8mm long (31284)
Ti Nitride 8mm long (31292)
Black 10mm short (31285)
Ti Nitride 10mm short (31290)
Silver 10mm long (31285)
Ti Nitride 10mm long (31293)

4
:: Table of Contents
1....................Cover
2....................Introduction
3....................1:1 Hardware “Fold Out”
4...................Table of Contents
5-6...............Shock Build
(Bags 1, 2)
6-9...............Spool and Differential Build
(Bags 3, 4, 5)
9....................Turnbuckle Build
(Bag 6)
9....................CVA Build
(Bag 7)
11-12..........Suspension Arms Build
(Bags 8, 9, 10, 11)
13-16.........Bulkheads, Spur Gear, and
Steering Rack Build
(Bags 12, 13)
16-19.........Caster Blocks /Rear Hubs Build
(Bags 14, 15, 16)
19-23.........Bumper, Anti Roll Bar, and
Electronics Build
(Bags 17, 18)
24-26.........Tuning Tips
27.................Gear Chart
28-35.........Catalog
36................Setup Sheet “Kit Setup”
37.................Setup Sheet “Blank”
38................Back Cover
Associated Electrics, Inc.
26021 Commercentre Dr.
Lake Forest, CA 92630
http://www.TeamAssociated.com · http://www.RC10.com · http://twitter.com/Team_Associated · http://bit.ly/AEonFacebook
Customer Service
Tel: [phone]
Fax: [phone]
:: Notes
There is a 1:1 hardware foldout page in the
front of the manual. To check the size of a part,
line up your hardware with the correct drawing
until you find the exact size. Each part in the
foldout has a number assigned to it for ordering
replacement parts.
This symbol indicates a special
note or instruction in the manual.
Scanning this QR code will take
you to Team Associated’s Tech Tips
videos. These videos will help you
with your build and setup!
This symbol indicates a Racers Tip.
!

5
:: Shock Build - Bag 1 & 2 - Step 1
:: Shock Build - Bag 1 & 2 - Step 2
:: Shock Build - Bag 1 & 2 - Step - 3
Bladder Installation
With the shaft extended 25%, place bladder on
the top of the shock body, displacing the extra oil.
While maintaining pressure on the bladder against
the shock body, carefully lift one side of the bladder
to allow any extra oil to escape. Place stock cap on
top of bladder, and secure it by threading the
aluminum cap retainer onto the shock body.
31326
VCS3 shock
collar o-ring
31326
VCS3
shock collar
Shock oil
#5423
(40wt)
3/16
31689
TC7 shock
piston
(3x1.1)
31700
TC7 shock
eyelet
31696
TC7
shock cap
retainer
31700
TC7 shock
cap
31693
TC7
bladder
31693
TC7 shock
shaft
bushing
31688
TC7 shock
shaft
4637
FT pivot
balls
4637
FT pivot
balls
31687
TC7 FT
shock body
(Fox
Kashima
Coat)
21139
Steel washer
(2.6x6x0.5mm)
5407
Red
o-rings
31327
VCS3 shock
bottom cap
31327
VCS3 shock
bottom cap
o-ring
31510
M2x4mm
bhcs
Shock fluid
#5433
(37.5wt)
Shock fluid
#5433
(37.5wt)
#1596
thread lock
Thread lock
not included!
!
Build four
shock collars
Build four
shocks
Build four
shocks
Build four
shock shafts

6
:: Shock Build - Bag 1 & 2 - Step 4
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 1
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 2
31175
Diff pulley
flange
31175
Diff pulley
(40T)
31342
Spool hub
31698
TC7 shock
spring cup
Build four
shocks
#1597
ca glue
Note!
Always use the same
cam position on both
sides of the car.
Belt Tension
Number
View from left
side of car
17 32
161
Right Side
Left Side
31615
Diff
bearing
cam
31510
M2x4mm
bhcs
31615
Cam
holder
(mid-low)
x2
x4
x2
#1596
thread lock
Use belt tension
position 8 for
standard setup
on the front.
!
Cam Position
Mid-Low Mid-High
Low High
Thread lock
not included!
CA glue
not included!
!
!
31717
TC Spring,
Blue
(15.9lbs)

7
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 3
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 4
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 5
x2
x4
x2
x2
31162
Shim
31350
M2.5x10mm
fhcs
x2
x4
91563
FT bearing
10x15x4mm
31348
TC6 gear
diff shim
31341
TC6 spool
outdrive
x2
Build two
outdrives
31346
TC6 gear
diff outdrive
31349
TC6 gear
diff seals
31349
TC6 gear
diff seals
31345
TC6 gear
diff sun
gear
31345
TC6 gear
diff planet
gear
31347
TC6 gear
diff case
31348
TC6 gear
diff pin
31348
TC6 gear
diff pin
#6588
black grease
#6588
black grease
#1596
thread lock
Thread lock
not included!
!
x2
31348
TC6 gear
diff shim
(1 small, 1 big)

8
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 6
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 7
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 8
x2
x2
31162
Shim
Fill to top of
cross pins
!
31349
TC6 gear
diff seals
31345
TC6 gear
diff sun
gear
31347
TC6 gear
diff pulley
31348
TC6 gear
diff pin
31348
TC6 gear
diff shim
(1 small, 1 big)
4675
M2.5x6mm
fhcs
31347
TC6 gear
diff gasket
x4
#6588
black grease
Diff Fluid
#5452
(3,000cst)
x291563
FT bearing
10x15x4mm

9
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 9
:: Spool and Differential Build - Bag 3, 4 & 5 - Step 10
Use belt tension
position 7 for
standard setup
on the rear.
!
Note!
Always use the same
cam position on both
sides of the car.
Right Side
Left Side
31615
Diff
bearing
cam
31615
Cam
holder
(mid-low)
x2 x2
Belt Tension
Number
View from left
side of car
17 32
161
Cam Position
Mid-Low Mid-High
Low High
:: Turnbuckles Build - Bag 6 - Step 1
Servo Turnbuckle
Steering Turnbuckle
Camber Turnbuckle
10.15mm
1418
0.825”
turnbuckle
1402
1.375”
turnbuckle
1405
1.875”
turnbuckle
19.00mm
30.15mm
x2
20.50mm
x2 x2
31305
Turnbuckle
eyelet
Front Rear

10
:: CVA Build - Bag 7 - Step 3
31238
CVA blade
Build four
CVA’s
:: CVA Build - Bag 7 - Step 2
31237
retaining
clip
31500
M3x2.5mm
setscrew
RACERS TIP!
place a drop of CA glue
on the pin retainer gap.
#1596
thread lock
#1597
CA glue
Thread lock
and CA glue
not included!
!
:: CVA Build - Bag 7 - Step 1
31367
TC6.1 CVA
coupler
31367
CVA
cross pin
31368
TC6.1 CVA
bones 31369
TC6.1 CVA
axle
#6588
black grease
Note!
Align the gap in the
pin retainer to be
opposite of the CVA pin.
!

11
:: Suspension Arms Build - Bag 8, 9, 10, & 11 - Step 1
:: Suspension Arms Build - Bag 8, 9, 10, & 11 - Step 2
:: Suspension Arms Build - Bag 8, 9, 10, & 11 - Step 3
Build four
inner arm
mounts
Build left
and right
sides
31619
TC6.2 Inner
arm mount
31620
TC6.2 arm
mount insert
(Front: -3 dot, -1°)
(Rear: 1 dot, 0°)
Arm Mount Inserts
Negative to the inside of vehicle.
Positive to the outside of vehicle.
1 DOT
0 °
-2 DOT
-1/2 °
+2 DOT
+1/2 °
-1 °
-3 DOT +3 DOT
+1 °
sides
Wheel Base Shims
1mm 2mm
Wheel Base Shims
1mm 2mm
4670
M3x8mm
set screw
31677
TC7 Inner
hinge pin
31677
TC7 Inner
hinge pin
31286
Wheelbase
shim (1mm)
31286
Wheelbase
shim (1mm)
25227
M4x8mm
setscrew
31673
TC7 Front
suspension
arm
25227
M4x8mm
set screw
31674
TC7 Rear
suspension
arm
x4
x4
x2
x2
x2
x2
31541
M3x6mm
fhcs
31650
TC7
chassis
4617
Bulkhead
shim
(0.5mm)
31621
Inner hinge
pin ball
31621
Inner hinge
pin ball
4670
M3x8mm
set screw
Build left
and right
sides
Install
front and
rear
3mm
3mm

12
:: Suspension Arms Build - Bag 8, 9, 10, & 11 - Step 4
:: Suspension Arms Build - Bag 8, 9, 10, & 11 - Step 5
:: Suspension Arms Build - Bag 8, 9, 10, & 11 - Step 6
Build two, one for
front, one for rear.
(Front: -3 dot, -1°)
(Rear: 1 dot, 0°)
Droop:
The standard settings of
6mm front and 5mm rear
will work best in most cases.
Droop is measured just
underneath the outer hinge
pin as shown in the photos
to the right.
On bumpy or low grip
surfaces, increase the droop
(going to a lower number on
the droop gauge), this will
help increase traction and
consistency.
Droop adjustments of
0.5mm to 1mm can be
very effective on the track!
x2
31620
TC6.2 arm
mount insert
(-3 dot, -1°)
31618
TC6.2
Outer Arm
Mount
Arm Mount Inserts
Negative to the inside of vehicle.
Positive to the outside of vehicle.
1 DOT
0 °
-2 DOT
-1/2 °
+2 DOT
+1/2 °
-1 °
-3 DOT +3 DOT
+1 °
Arm Mount Inserts
+2
DOT
+3
DOT
(Rear: 1 dot, 0°)
(-3 dot, -1°)
31618
TC6.2
x2
31541
M3x6mm
fhcs
x2
4617
Bulkhead
shim
(0.5mm)
x2
x2
31541
M3x6mm
fhcs
4617
Bulkhead
shim
(0.5mm)
Rear Droop
Setting: 5mm
1
02345678
1
02345678
Front Droop
Setting: 6mm

13
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 1
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 2
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 3
31333
TC6
spur gear
(87T / 48P)
31530
M3x5mm
bhcs
31320
TC6 spur
pulley
(20T)
31314
TC6 spur
gear hub
31319
TC6 spur gear
clamping ring
x3
x2
#1596
thread lock
31541
M3x6mm
fhcs
31541
M3x6mm
fhcs
31541
M3x6mm
fhcs
31663
TC7
motor
mount
x4 x4
x4
x2 x2 31660
TC7
Bulkhead
31660
TC7
Bulkhead
Thread lock
not included!
!
89229
Blue
countersunk
washer
x231731
FT bearing
4x8x3mm
flanged
31664
TC7 spur
gear shaft
31541
M3x6mm
fhcs

14
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 4
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 5
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 6
Front Belt
Rear Belt
Slide belt over
gear diff pulley!
!
Slide belt over
spool pulley!
!
Front Belt
Slide belt over
spool pulley!
!
Slide belt over
gear diff pulley!
!
31658
TC7 Front
belt
31659
TC7 Rear
belt
25202
M3x10mm
fhcs
31286
FT ballstud
washer,
aluminum
(1mm)
31531
M3x6mm
bhcs
31614
TC6.2
bearing
cap (B)
31613
TC6.2
bearing
cap (A)
31283
Ballstud,
long,
5mm
x2
x4
x2

15
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 7
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 8
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 9
Note!
Place top
plate between
the front belt.
!
31653
TC7 top
plate
31286
FT ballstud
washer,
aluminum
(1mm)
31614
TC6.2
bearing
cap (B) 31613
TC6.2
bearing
cap (A)
31283
Ballstud,
long,
5mm
x2 x2 31531
M3x6mm
bhcs
x4
x931530
M3x5mm
bhcs
31541
M3x6mm
fhcs
31541
M3x6mm
fhcs
x4
x4
31655
TC7 front
shock tower
31656
TC7 rear
shock tower

16
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 10
:: Bulkheads, Spur Gear, and Steering Build - Bag 12 & 13 - Step 11
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 1
Build two Build two
Top Plate and
Belts hidden for
view clarity!
!
Build two
31283
5mm
ballstud
(long)
31370
TC6.1
axle crush
tube
31679
TC7
steering
blocks
31667
TC7 steering
rack post
31667
TC7 steering
bellcrank post
spacer
25211
M3x10mm
bhcs
31666
TC7
steering
bellcrank
31732
FT Bearing,
4 x 7 x 2.5mm
31732
FT Bearing,
4 x 7 x 2.5mm
31665
TC7 steering
rack hat
bushing
31665
TC7
steering
rack
x2
x2
x2
x2
x4
x4
x2
31286
FT ballstud
washer,
aluminum
(1mm)
31283
Ballstud,
long,
5mm
x2
x2
31374
TiN 3.25mm
ballstud,
short neck
31541
M3x6mm
fhcs
x2
31286
FT ballstud
washer,
aluminum
(1mm)
x291560
FT bearing
5x10x4mm

17
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 2
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 3
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 4
Do not
overtighten!
Use a 1.5mm hex tool tip to poke
through any left over flashing (extra
thin piece of plastic) in the hinge pin
set screw hole on the caster blocks.
!
!
!
Build two
Build two
Build two
Build two
31112
1/16” x 5/16”
dowel pins
31670
Clamping
wheel hex
(5mm)
91611
M1.6x5mm
shcs
31680
TC7 king
pin bushing
31680
TC7 king
pin bushing
25211
M3x10mm
bhcs
31285
10mm
ballstud
(long)
31678
TC7 caster
block,
(4 degree)
31286
FT ballstud
washer,
aluminum
(1mm)
31286
FT ballstud
washer,
aluminum
(1mm)
31677
TC7 hinge
pin, outer 25225
M3x3
set screw

18
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 5
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 6
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 7
!
Orient the notch
to the left throughout
the car. The notch
indicates which end has
the left hand threads!
Orient the notch
to the left throughout
the car. The notch
indicates which end has
the left hand threads!
It is important that the turnbuckle eyelets move freely
once snapped on to the ballstud. If the fit is too tight,
the car handling will be inconsistent. To check, grab
turnbuckle eyelet with fingers and rotate the cup. If
there is resistance, lightly squeeze ball cup with needle
nose pliers as shown and test again. It is important
that the ball cup be snapped onto the ballstud before
squeezing with needle nose pliers. Be sure to check
and adjust the fit for each ball cup that is installed.
!
Build left
and right
sides
Build left
and right
sides
31286
Aluminum
ballstud
washer
(2mm)
31284
8mm
ballstud
(long)
31681
TC7 rear
hub
carrier
31370
TC6.1
axle crush
tube
x291560
FT bearing
5x10x4mm
Use a 1.5mm hex tool tip to
poke through any left over
flashing (extra thin piece of
plastic) in the hinge pin set
screw hole on the rear hubs.
!

19
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 8
:: Caster Blocks and Hubs Build - Bag 14, 15, & 16 - Step 9
:: Bumper, Anti-Roll Bar, and Electronics Build - Bag 17 & 18 - Step 1
!
Orient the notch
to the left throughout
the car. The notch
indicates which end has
the left hand threads!
Build left
and right
sides
Build left
and right
sides
31112
1/16” x 5/16”
dowel pins
31670
Clamping
wheel hex
(5mm)
91611
M1.6x5mm
shcs
31677
TC7 hinge
pin, outer
25225
M3x3
set screw
31286
Aluminum
ballstud
washer
(2mm)
31532
M3x8mm
bhcs
31532
M3x8mm
bhcs
31286
Aluminum
ballstud
washer
(2mm)
x2 x2 x2 x2

20
:: Bumper, Anti-Roll Bar, and Electronics Build - Bag 17 & 18 - Step 2
:: Bumper, Anti-Roll Bar, and Electronics Build - Bag 17 & 18 - Step 3
:: Bumper, Anti-Roll Bar, and Electronics Build - Bag 17 & 18 - Step 4
Transponder
not included!
31623
TC6.2
bumper
31624
TC6.2
foam
bumper
4673
M2.5x4mm
bhcs
25202
M3x10mm
fhcs
x3
x2
!x2
x2
x3
3897
Pivoting
body mounts
31623
TC6.2
bumper
brace
1736
FT body
clips, blue
(short)
25201
M3x8mm
fhcs
31625
TC6.2 front
body posts
x2
25201
M3x8mm
fhcs
x2
3897
Pivoting
body mounts
1736
FT body
clips, blue
(short)
x2
x2
31532
M3x8mm
bhcs
31625
TC6.2 rear
body posts
x2
x2
31541
M3x6mm
fhcs
31626
TC6.2 lipo
brace
(offset) 31626
TC6.2 lipo
brace
x6
31626
Inner lipo
brace
