AEG Powertools WS 22-180 E User manual
Original instructions
Originalbetriebsanleitung
Notice originale
Istruzioni originali
Manual original
Manual original
Oorspronkelijke
gebruiksaanwijzing
Original brugsanvisning
Original bruksanvisning
Bruksanvisning i original
Alkuperäiset ohjeet
Πρωτότυπο οδηγιών χρήσης
Orijinal işletme talimatı
Původním návodem k používání
Pôvodný návod na použitie
Instrukcją oryginalną
Eredeti használati utasítás
Izvirna navodila
Originalne pogonske upute
Instrukcijâm oriěinâlvalodâ
Originali instrukcija
Algupärane kasutusjuhend
Оригинальное руководство по
эксплуатации
Оригинално ръководство за
експлоатация
Instrucţiuni de folosire originale
Оригинален прирачник за работа
Оригінал інструкції з експлуатації
WS 22-180, WS 22-180 E, WS 22-230,
WS 22-230 E, WS 24-230 GV, WS 24-230 GEV
Technical Data,Safety Instructions, Specied Conditions of Use,
EC-Declaration of Conformity, Mains connection, Maintenance, Symbols Please read and save
these instructions!
English
15
Technische Daten, Sicherheitshinweise, Bestimmungsgemäße Verwendung,
CE-Konformitätserklärung, Netzanschluss, Wartung, Symbole Bitte lesen und
aufbewahren!
Deutsch
20
Caractéristiques techniques, Instructions de sécurité, Utilisation conforme aux
prescriptions, Déclaration CE de Conformité, Branchement secteur, Entretien, Symboles A lire et à conserver
soigneusement
Français
25
Dati tecnici,Norme di sicurezza,Utilizzo conforme, Dicharazione di Conformità CE,
Collegamento alla rete, Manutenzione, Simboli Si prega di leggere e
conservare le istruzioni!
Italiano
30
Datos técnicos, Instrucciones de seguridad, Aplicación de acuerdo a la nalidad,
Declaracion de Conformidad CE, Conexión eléctrica, Mantenimiento, Símbolos Lea y conserve estas
instrucciones por favor!
Español
35
Características técnicas, Instruções de segurança, Utilização autorizada,
Declaração de Conformidade CE, Ligação à rede, Manutenção, Symbole Por favor leia e conserve
em seu poder!
Português
40
Technische gegevens, Veiligheidsadviezen, Voorgeschreven gebruik van het
systeem, EC-Konformiteitsverklaring, Netaansluiting,Onderhoud, Symbolen Lees en let goed op deze
adviezen!
Nederlands
45
Tekniske data, Sikkerhedshenvisninger, Tiltænkt formål,
CE-Konformitetserklæring, Nettilslutning, Vedligeholdelse, Symboler Vær venlig at læse
og Opbevare!
Dansk
50
Tekniske data, Spesielle sikkerhetshenvisninger, Formålsmessig bruk,
CE-Samsvarserklæring, Nettilkopling, Vedlikehold, Symboler Vennligst les og oppbevar!
Norsk
55
Tekniska data, Säkerhetsutrustning, Använd maskinen Enligt anvisningarna,
CEFörsäkran, Nätanslutning, Skötsel, Symboler Läs igenom och spara!
Svenska
60
Tekniset arvot, Turvallisuusohjeet, Tarkoituksenmukainen käyttö,
Todistus CE-standardinmukaisuudesta, Verkkoliitäntä, Huolto, Symbolit Lue ja säilytö!
Suomi
Τεχνικά στοιχεία, Ειδικές υποδείξεις ασφάλειας, Χρήση σύμφωνα με το σκοπό
προορισμού, Δήλωση πιστότητας ΕΚ, Μπαταρίες, Χαρακτηριστικά, Συντήρηση, Σύμβολα.
Ελληνικά
70
Teknik veriler, Güvenliğiniz için talimatlar, Kullanim, CE uygunluk beyanice,
Şebeke bağlantisi, Bakim, Semboller Lütfen okuyun ve saklayın
Türkçe
75
Technická data, Speciální bezpečnostní upozornění, Oblast využití,
Ce-prohlášení o shodě, Připojení na sít, Údržba, Symboly Po přečtení uschovejte
Česky
80
Technické údaje, Špeciálne bezpčènostné pokyny, Použitie podl’a predpisov,
CE-Vyhlásenie konformity, Siet’ová prípojka, Údrzba, Symboly Prosím prečítať a uschovať!
Slovensky
85
Dane techniczne, Specjalne zalecenia dotyczące bezpiecze´nstwa, Użytkowanie zgodne z
przeznaczeniem, Świadectwo zgodności ce, Podłączenie do sieci, Gwarancja, Symbole Należy uważnie przeczytać i
zachować do wglądu!
Polski
90
Műszaki adatok, Különleges biztonsági tudnivalók, Rendeltetésszerű használat,
Ce-azonossági nyilatkozat, Hálózati csatlakoztatás, Karbantartás, Szimbólumok Olvassa el és őrizze meg
Magyar
95
Tehnični podatki, Specialni varnostni napotki, Uporaba v skladu z namembnostjo,
Ce-izjava o konformnosti, Omrežni priključek, Vzdrževanje, Simboli Prosimo preberite
in shranite!
Slovensko
100
Tehnički podaci, Specijalne sigurnosne upute, Propisna upotreba,
CE-Izjava konformnosti, Priključak na mrežu, Održavanje, Simboli Molimo pročitati i sačuvati
Hrvatski
105
Tehniskie dati, Speciālie drošības noteikumi, Noteikumiem atbilstošs izmantojums,
Atbilstība CE normām, Tīkla pieslēgums, Apkope, Simboli Pielikums lietošanas pamācībai
Latviski
110
Techniniai duomenys, Ypatingos saugumo nuorodos, Naudojimas pagal paskirti,
CE Atitikties pareiškimas, Elektros tinklo jungtis, Techninis aptarnavimas, Simboliai Prašome perskaityti
ir neišmesti!
Lietuviškai
115
Tehnilised andmed, Spetsiaalsed turvajuhised, Kasutamine vastavalt otstarbele,
EÜ Vastavusavaldus, Võrku ühendamine, Hooldus, Sümbolid Palun lugege läbi ja hoidke alal!
Eesti
120
Пожалуйста прочтите и
сохраните эту инструкцию.
Pусский
125
Моля прочетете и запазете!
Български
131
Date tehnice, Instrucţiuni de securitate, Condiţii de utilizare specifcate,
Declaraţie de conformitate, Acumulatori, Intreţinere, Simboluri Va rugăm citiţi şi păstraţi
aceste instrucţiuni
Română
136
БАТЕРИИ њ
Ве мoлиме прочитаjте го и
чувајте го ова упатство!
Мaкeдohcки
141
Технічніхарактеристики,Вказівки ЗТехнікиБезпеки,Використання запризначенням,
Сертифікат Відповідності Вимогам Єс, Підключення домережі, Обслуговування, Символи Прочитайте та збережіть
цю інструкцію.
Українська
146
155
65
Accessory
Zubehör
Accessoires
Accessorio
Accessorio Acessório
Toebehoren Tilbehør
Tilbehør Tillbehör
Lisälaite
Aksesuar řš
Príslušenstv
Azokat a tartozékokat
Oprema Piederumi
Priedas Tarvikud
Accesoriu
IIII
IV
TIP
VI
VII
IX
VIII
V
II
2
I
WS 22-180, WS 22-180 E, WS 22-230, WS 22-230 E
WS 24-230 GV, WS 24-230 GEV
3
II
1. 2.
90° 90°
60° 60°
30° 0° 30°
WS 24-230 GV, WS 24-230 GEV
4
III
1.
3.2.
2
1
WS 22-180
WS 22-180 E
WS 22-230
WS 22-230 E
5
III
1. 2.
3.
1
2
WS 24-230 GV
WS 24-230 GEV
6
IV
1
30
°
60
°
30
°
60
°
0
°
AB
7
V
1. 2.
Use only spindle nuts as provided by the manufacturer.
Do not use any keyless nuts!
Benutzen Sie nur die vom Hersteller vorgesehene Spannmutter.
Verwenden Sie keine Schnellspannmuttern!
Utilizzare soltanto il dado di bloccaggio previsto dal produttore.
Non usare dadi di bloccaggio rapido!
Utilice solamente la tuerca de apriete prevista por el fabricante.
¡No utilice ninguna tuerca de apriete rápido!
Somente uso a porca tensora prevista pelo fabricante.
Nunca use porcas tensoras rápidas!
Gebruik alleen de door de fabrikant voorgeschreven spanmoer.
Gebruik géén snelspanmoeren.
Benyt kun spændemøtrikken, som producenten angiver.
Anvend ikke hurtigspændemøtrikker!
Bruk bare spennmuttere som er godkjent av produsenten.
Bruk aldri hurtigspennmuttere!
Använd endast spännmuttrar som tillhandahålls av tillverkaren.
Använd inga snabbspännmuttrar!
Käytä vain valmistajan määräämiä kiinnitysmuttereita.
Älä käytä pikakiinnitysmuttereita!
Χρησιμοποιείτε μόνο το προβλεπόμενο από τον κατασκευαστή παξιμάδι
σύσφιξης. Μη χρησιμοποιείτε παξιμάδια ταχείας σύσφιξης!
Sadece imalatçı tarafından öngörülen germe somunlarını kullanınız.
Hızlı germe somunları kullanmayınız!
Používejte pouze upínací matku určenou výrobcem.
Nepoužívejte žádné rychloupínací matice!
Použite len výrobcom určenú upínaciu maticu.
Nepoužívajte žiadne rýchloupínacie matice!
Stosować jedynie nakrętkę mocującą, przewidzianą przez producenta.
Nie stosować szybkozaciskowych nakrętek mocujących!
Csak a gyártó által javasolt szorítóanyát használja.
Ne használjon gyorsszorító anyát!
Uporabljajte zgolj s strani proizvajalca predvidene vpenjalne matice.
Ne uporabljajte hitrovpenjalnih matic!
Koristite samo od strane proizvođača predviđenu zateznu maticu.
Nemojte koristiti nikakve brzopritezne matice!
Izmantojiet tikai vārpstu uzgriežņus, kā to paredz ražotājs.
Neizmantojiet uzgriežņus bez atslēgas palīdzības
Naudokite tik gamintojo nurodytą įtempimo veržlę.
Kasutage ainult tootja ettenähtud võllimutreid.
Ärge kasutage kiirmutreid!
Используйте только предусмотренные производителем натяжные
гайки. Не используйте быстронатяжные гайки!
Използвайте само предвидените от производителя затягащи гайки.
Не използвайте бързозатягащи гайки!
Utilizaţi numai piuliţele de strângere recomandate de către producător.
Nu utilizaţi niciodată piuliţe de strângere rapidă!
Употребувајте само разделна навртка што е предвидена од страна на
производителот. Не употребувајте брзи разделни навртки!
Використовуйте тільки передбачені виробником натяжні гайки.
8
V
< 6 mm
> 6 mm
4.3.
3.
2.
4.
1.
9
VI
1
Start
2
DEADMAN
Stop
WS 22-180
WS 22-230
WS 24-230 GV
Switch cannot be locked
Schalter ist nicht arretierbar
Le commutateur ne peut pas être verrouillé
L'interruttore non si può bloccare
El interruptor no se puede bloquear.
O interruptor não pode ser bloqueado
Schakelaar is niet vastzetbaar
Afbryder kan ikke kseres
Bryter kan ikke låses
Brytaren kan inte arreteras.
Katkaisinta ei voi lukita.
Ο διακόπτης δεν μπορεί να ασφαλιστεί
Şalter ayarlanamaz
Vypínač není aretovatelný
Vypínač je nie aretovateľný
Przełącznik nie daje się zablokować
A kapcsoló nem rögzíthető
Stikalo ni nastavljivo
Prekidač se ne može aretirati
Slēdzis nav labojams
Jungiklis negali būti užblokuojamas
Lüliti ei ole kseeritav
Нефиксируемый переключатель
Превключвателят не може да се фиксира
Comutatorul nu poate blocat
Прекинувачот не може да се заклучи
Перемикач без замком
10
VI
1
3
2
1
2
Stop
Start
WS 22-180 E
WS 22-230 E
WS 24-230 GEV
Switch can be locked
Schalter ist arretierbar
Le commutateur peut être
verrouillé
L’interruttore si può bloccare
El interruptor se puede bloquear.
O interruptor pode ser bloqueado
Schakelaar is vastzetbaar
Afbryder kan kseres
Bryter kan låses
Brytaren kan arreteras.
Katkaisimen voi lukita.
Ο διακόπτης μπορεί να
ασφαλιστεί
Şalter ayarlanabilir
Vypínač je aretovatelný
Vypínač je aretovateľný
Przełącznik daje się zablokować
A kapcsoló rögzíthető
Stikalo je nastavljivo
Prekidač se može aretirati
Slēdzis ir labojams
Jungiklis gali būti užblokuojamas
Lüliti on kseeritav
Фиксируемый переключатель
Превключвателят може да се
фиксира
Comutatorul poate blocat
Прекинувачот може да се
заклучи
Перемикач з замком
3.
Stop
1. 2.
11
Startup protection:
When switched on, the machine will not start up after vol-
tage breakdown. To continue working, switch the machine
o and then on again.
Wiederanlaufschutz:
Eingeschaltete Maschine läuft nach Spannungsausfall
nicht wieder an. Um weiter zu arbeiten Maschine aus- und
wieder einschalten.
Dispositif de protection contre un redemarrage
Après une coupure de tension, la machine enclenchée
ne redémarre pas. Pour continuer à travailler, il convient
d‘éteindre la machine et de l‘enclencher à nouveau.
Protezione contro il riavvio
La macchina accesa non riparte in seguito alla caduta della
tensione. Per poter continuare a lavorare bisogna prima
spegnere e poi riaccendere la macchina.
Protección contra el rearranque
La máquina conectada no se vuelve a poner en marcha
después de un fallo de corriente. Para continuar el trabajo,
desconectar y volver a conectar la máquina.
Protecção de reinício
Quando está ligada, após uma falha de energia a máquina
não retoma o seu funcionamento. Para prosseguir o tra-
balho, desligar a máquina e voltar a ligá-la.
Herstartbeveiliging
Na spanningsuitval schakelt de machine niet automatisch
weer in. Schakel de machine uit en weer in om door te
kunnen werken.
Genstartsbeskyttelse
I tilfælde af spændingsudfald, mens maskinen kører, går den
ikke i gang igen, når spændingen kommer tilbage. For at
genoptage arbejdet skal maskinen slukkes og tændes igen.
Automatisk gjenstartsbeskyttelse
En påslått maskin begynner ikke automatisk å gå igjen etter
strømbrudd. For å kunne fortsette å arbeide må maskinen
skues av og så på igjen.
Återstartsskydd
En påslagen maskin startar inte själv efter ett strömavbrott.
Stäng först av och slå sedan på maskinen igen för att
fortsätta att arbeta.
Uudelleenkäynnistyssuoja
Päällekytketty kone ei käynnisty sähkökatkon jälkeen
uudestaan. Työn jatkamiseksi tulee kone sammuttaa ja
käynnistää uudelleen.
Προστασια επανεκκινησης
Η ενεργοποιημένη μηχανή δεν ξεκινά πάλι από μόνη
της μετά από μια πτώση ρεύματος. Για να συνεχίσετε
την εργασία, απενεργοποιείτε και ενεργοποιείτε πάλι τη
μηχανή.
Tekrar çaliştirmada koruma
Çalıştırılan makine voltaj kaybından sonra yeniden çalışmaz.
Makineyi tekrar çalıştırmak için kapatın ve tekrar açın.
Ochrana proti opětovnému náběhu
Zapnutá rozbrušovačka se v případě výpadku proudu po
jeho opětovném zapnutí sama nerozběhne. K pokračování
práce se rozbrušovačka musí vypnout a opět zapnout.
Ochrana proti opätovnému nábehu
Zapnutá rozbrusovačka sa v prípade výpadku prúdu po
jeho opätovnom zapnutí sama nerozbehne. K pokračovaniu
práce sa rozbrusovačka musí vypnúť a opäť zapnúť.
Zabezpieczenie przed ponownym uruchomieniem
Włączone urządzenie nie uruchamia się z powrotem po
ustąpienia zaniku napięcia. Aby móc kontynuować pracę,
urządzenie należy wyłączyć, a potem z powrotem włączyć.
Újraindulás elleni védelem
A bekapcsolt gép feszültségkimaradás után ismét elindul. A
munka folytatásához a gépet ki és újra be kell kapcsolni.
Zaščita pred ponovnim zagonom
Vklopljen stroj se po izpadu napetosti ponovno ne zažene.
Za nadaljevanje dela stroj izklopite in ponovno vklopite.
Zaštita protiv ponovnog pokretanja
Uključeni stroj poslilje nestanka napona više ne starta. Da
bi se dalje radilo, stroj isključiti i ponovno uključiti.
Aizsardzība pret atkārtotu palaišanu
Pārtrūkstot strāvas padevei, ieslēgtā ierīce no jauna neieslēdzas.
Darba turpināšanai ierīci izslēgt un ieslēgt no jauna.
Apsauga nuo pakartotinio įsijungimo
Jei darbo metu dingsta įtampa, ją sutvarkius, mašina
neįsijungia automatiškai. Norint vėl dirbti su mašina, reikia ją
išjungti ir vėl įjungti.
Taaskäivituskaitse
Sisselülitatud masin ei käivitu enam uuesti pärast voolukatke-
stust. Töö jätkamiseks lülitage masin välja ja seejärel taas sisse.
Защита от повторного включения
При исчезновении напряжения устройство не работает.
Для продолжения работы устройство выключите и снова
включите.
Защита от повторно пускане След спиране на
електрозахранването включената машина не започва
да работи отново. За да продължите работа изключете и
отново включете машината.
Protecţie contra repornirii
Maşina conectată nu reporneşte după o întrerupere de
curent. Pentru a putea lucra în continuare, maşina trebuie
oprită şi apoi repornită.
Заштита од повторно придвижување
Вклучената машина во случај на снемување струја не
се вклучува повторно. За да продолжите со работа
исклучете ја машината и вклучете ја повторно.
Захист від повторного запуску
Увімкнена машина не продовжує роботу після того, як
була вставлена акумуляторна батарея.
VI
12
VII
TIP
< 30°
TIP
< 30°
< 30°
< 30°
< 30°
< 30°
13
VIII
1. 2.
1. 2.
Accessory
Zubehör
Accessoires
Accessorio
Accessorio
Acessório
Toebehoren
Tilbehør
Tilbehør
Tillbehör
Lisälaite
Aksesuar
P
Príslušenstv
Tartozékokat
Oprema
Piederumi
Prieda
Tarvikud
Aksessuaarid
Accesoriu
14
VIII
1. 2.
1. 2.
Accessory
Zubehör
Accessoires
Accessorio
Accessorio
Acessório
Toebehoren
Tilbehør
Tilbehør
Tillbehör
Lisälaite
Aksesuar
P
Príslušenstv
Tartozékokat
Oprema
Piederumi
Prieda
Tarvikud
Aksessuaarid
Accesoriu
15
English
TECHNICAL DATA Angle Grinder WS 22-180 WS 22-180 E WS 22-230 WS 22-230 E
Production code 4317 01 03 ...
000001-999999 4316 91 03 ...
000001-999999 4317 31 03 ...
000001-999999 4317 21 03 ...
000001-999999
Rated input 2200 W 2200 W 2200 W 2200 W
Rated speed 8500 min-1 8500 min-1 6600 min-1 6600 min-1
D= Grinding disk diameter max.
d= Grinding disk hole diameter
180 mm
22,2 mm 180 mm
22,2 mm 230 mm
22,2 mm 230 mm
22,2 mm
b= Cutting disk thickness min. / max.
1,5 / 3 mm 1,5 / 3 mm 1,9 / 3 mm 1,9 / 3 mm
b= Grinding disk thickness max.
8 mm 8 mm 8 mm 8 mm
D= Grinding surface diameter max. 180 mm 180 mm 230 mm 230 mm
D= Wiring brush diameter max. 100 mm 100 mm 100 mm 100 mm
Thread of work spindle M 14 M 14 M 14 M 14
Weight according EPTA-Procedure 01/2003 5,1 kg 5,1 kg 5,2 kg 5,2 kg
Noise information
Measured values determined according to EN 60745. Typically, the A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty K=3dB(A)) 96,0 dB(A) 96,0 dB(A) 96,0 dB(A) 96,0 dB(A)
Sound power level (Uncertainty K=3dB(A))
Wear ear protectors!
107,0 dB(A) 107,0 dB(A) 107,0 dB(A) 107,0 dB(A)
Vibration information
Vibration total values (triaxial vector sum) determined according to EN 60745
Surface grinding: Vibration emission value ah,SG
Uncertainty K=
8,7 m/s2
1,5 m/s2
8,7 m/s2
1,5 m/s2
8,7 m/s2
1,5 m/s2
8,7 m/s2
1,5 m/s2
Disk sanding: Vibration emission value ah,DS
Uncertainty K=
4,1 m/s2
1,5 m/s2
4,1 m/s2
1,5 m/s2
4,1 m/s2
1,5 m/s2
4,1 m/s2
1,5 m/s2
TECHNICAL DATA Angle Grinder WS 24-230 GV WS 24-230 GEV
Production code 4317 76 03 ...
...000001-999999 4317 66 03 ...
...000001-999999
Rated input 2400 W 2400 W
Rated speed 6600 min-1 6600 min-1
D= Grinding disk diameter max.
d= Grinding disk hole diameter
230 mm
22,2 mm 230 mm
22,2 mm
b= Cutting disk thickness min. / max.
1,9 / 3 mm 1,9 / 3 mm
b= Grinding disk thickness max.
8 mm 8 mm
D= Grinding surface diameter max. 230 mm 230 mm
D= Wiring brush diameter max. 100 mm 100 mm
Thread of work spindle M 14 M 14
Weight according EPTA-Procedure 01/2003 5,6 kg 5,6 kg
GB
16
GB
English
WARNING!
Read all safety warnings and all instructions. Failure to
follow the warnings and instructions may result in electric shock,
re and/or serious injury.
Save all warnings and instructions for future reference.
ANGLE GRINDER SAFETY WARNINGS
Safety Warnings Common for Grinding, Sanding, Wire
Brushing or Abrasive Cutting-O Operations:
a) This power tool is intended to function as a grinder,
sander, wire brush or cut-o tool. Read all safety warnings,
instructions, illustrations and specications provided with
this power tool. Failure to follow all instructions listed below may
result in electric shock, re and/or serious injury.
b) Operations such as polishing are not recommended
to be performed with this power tool. Operations for which
the power tool was not designed may create a hazard and cause
personal injury.
c) Do not use accessories which are not specically
designed and recommended by the tool manufacturer. Just
because the accessory can be attached to your power tool, it does
not assure safe operation.
d) The rated speed of the accessory must be at least equal
to the maximum speed marked on the power tool. Accesso-
ries running faster than their rated speed can break and y apart.
e) The outside diameter and the thickness of your
accessory must be within the capacity rating of your power
tool. Incorrectly sized accessories cannot be adequately guarded
or controlled.
f) Threaded mounting of accessories must match the grin-
der spindle thread. For accessories mounted by anges, the
arbour hole of the accessory must t the locating diameter
of the ange. Accessories that do not match the mounting hard-
ware of the power tool will run out of balance, vibrate excessively
and may cause loss of control.
g) Do not use a damaged accessory. Before each use inspect
the accessory such as abrasive wheels for chips and cracks,
backing pad for cracks, tear or excess wear, wire brush for
loose or cracked wires. If power tool or accessory is dropped,
inspect for damage or install anundamaged accessory. After
inspecting and installing an accessory, position yourself and
bystanders away from the plane of the rotating accessory
and run the power tool at maximum no-load speed for one
minute. Damaged accessories will normally break apart during this
test time.
h) Wearpersonal protectiveequipment. Depending on
application, use face shield, safety goggles or safety glasses.
As appropriate, weardust mask, hearingprotectors, gloves
and shop aproncapable of stopping small abrasive or
workpiecefragments.The eye protection must be capable of
stopping ying debris generated by various operations. The dust
mask or respirator must be capable of ltrating particles generated
by your operation. Prolonged exposure to high intensity noise may
cause hearing loss.
i) Keep bystanders a safe distance away from work area.
Anyone enteringthe workarea must wearpersonal protec-
tiveequipment.Fragments of workpiece or of a broken accessory
may y away and cause injury beyond immediate area of operation.
j) Hold the power tool by insulated gripping surfaces only,
when performing an operation where thecutting accessory
may contact hidden wiring or its own cord. Cutting accessory
contacting a “live” wire may make exposed metal parts of the power
tool “live” and could give the operator an electric shock.
TECHNICAL DATA Angle Grinder WS 24-230 GV WS 24-230 GEV
Noise information
Measured values determined according to EN 60745. Typically, the A-weighted noise levels of the tool are:
Sound pressure level (Uncertainty K=3dB(A)) 96,0 dB(A) 96,0 dB(A)
Sound power level (Uncertainty K=3dB(A))
Wear ear protectors!
107,0 dB(A) 107,0 dB(A)
Vibration information
Vibration total values (triaxial vector sum) determined according to EN 60745
Surface grinding: Vibration emission value ah,SG
Uncertainty K=
8,3 m/s2
1,5 m/s2
8,3 m/s2
1,5 m/s2
Disk sanding: Vibration emission value ah,DS
Uncertainty K=
4,1 m/s2
1,5 m/s2
4,1 m/s2
1,5 m/s2
For other applications, e.g. Abrasive Cutting-O Operations or Wire Brushing other vibration values could occur.
WARNING!
The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 60745
and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for dierent applications,
with dierent accessories or poorly maintained, the vibration emission may dier. This may signicantly increase the exposure level over
the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is
running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories,
keep the hands warm, organisation of work patterns.
17
GB
English
k) Positionthecordclear of thespinning accessory. If you lose
control, the cord may be cut or snagged and your hand or arm may be
pulled into the spinning wheel.
l) Never laythe powertool down until the accessory has
come to a complete stop. The spinning accessory may grab the
surface and pull the power tool out of your control.
m) Do not run the power tool while carrying it at your side.
Accidental contact with the spinning accessory could snag your
clothing, pulling the accessory into your body.
n) Regularly clean the power tool’s air vents.The motor’s fan
will draw the dust inside the housing and excessive accumulation of
powdered metal may cause electrical hazards.
o) Do notoperatethe powertool nearammable materials.
Sparks could ignite these materials.
p) Donot useaccessoriesthatrequire liquidcoolants.Using
water or other liquid coolants may result in electrocution or shock.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged rotating
wheel, backing pad, brush or any other accessory. Pinching or snag-
ging causes rapid stalling of the rotating accessory which in turn
causes the uncontrolled power tool to be forced in the direction
opposite of the accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by the
workpiece, the edge of the wheel that is entering into the pinch
point can dig into the surface of the material causing the wheel
to climb out or kick out. The wheel may either jump toward or
away from the operator, depending on direction of the wheel’s
movement at the point of pinching. Abrasive wheels may also break
under these conditions.
Kickback is the result of power tool misuse and/or incorrect opera-
ting procedures or conditions and can be avoided by taking proper
precautions as given below.
a) Maintain a rm grip on the power tool and position your
body and arm to allow you to resist kickback forces. Always
use auxiliary handle, if provided, for maximum control over
kickback or torque reaction during start-up. The operator can
control torque reactions or kickback forces, if proper precautions
are taken.
b) Never place your hand near the rotating accessory.
Accessory may kickback over your hand.
c) Do not position your body in the area where power tool
will move if kickback occurs. Kickback will propel the tool
in direction opposite to the wheel’s movement at the point of
snagging.
d) Use special care when working corners, sharp edges etc.
Avoid bouncing and snagging the accessory. Corners, sharp
edges or bouncing have a tendency to snag the rotating accessory
and cause loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed
saw blade. Such blades create frequent kickback and loss of control.
toothed saw blade.
Safety Warnings Specic for Grinding and Abrasive Cutting-
O Operations:
a) Use only wheel types that are recommended for your
power tool and the specic guard designed for the selected
wheel. Wheels for which the power tool was not designed cannot
be adequately guarded and are unsafe.
b) The grinding surface of the centre depressed wheels must
be mounted below the plane of the guard lip. An improperly
mounted wheel that projects through the plane of the guard lip
cannot be adequately protected.
c) The guard must be securely attached to the power tool
and positioned for maximum safety, so the least amount
of wheel is exposed towards the operator. The guard helps
to protect the operator from broken wheel fragments, accidental
contact with wheel and sparks that could ignite clothing.
d) Wheels must beused only for recommended applications.
For example: do not grind with the side of cut-o wheel.
Abrasive cut-o wheels are intended for peripheral grinding, side
forces applied to these wheels may cause them to shatter.
e) Always useundamaged wheel angesthat are of correct
size and shape for your selected wheel. Proper wheel anges
support the wheel thus reducing the possibility of wheel breakage.
Flanges for cut-o wheels may be dierent from grinding wheel
anges.
f) Do not use worn down wheels from larger power tools.
Wheel intended for larger power tool is not suitable for the higher
speed of a smaller tool and may burst.
Additional Safety Warnings Specic for Abrasive Cutting-
O Operations:
a) Do not “jam” the cut-o wheel or apply excessive pressure.
Do not attempt to make an excessive depth of cut. Overstressing
the wheel increases the loading and susceptibility to twisting or
binding of the wheel in the cut and the possibility of kickback or wheel
breakage.
b) Do not position your body in line with and behind the
rotating wheel. When the wheel, at the point of operation, is moving
away from your body, the possible kickback may propel the spinning
wheel and the power tool directly at you.
c) When wheel is binding or when interrupting a cut for any
reason, switch o the power tool and hold the power tool
motionless until the wheel comes to a complete stop. Never
attempt to remove the cut-o wheel from the cut while the
wheel is in motion otherwise kickback may occur. Investigate
and take corrective action to eliminate the cause of wheel binding.
d) Do not restart the cutting operation in the workpiece. Let
the wheel reach full speed and carefully re-enter the cut. The
wheel may bind, walk up or kickback if the power tool is restarted in
the workpiece.
e) Support panels or any oversized workpiece to minimize the
risk of wheel pinching and kickback. Large workpieces tend to sag
under their own weight. Supports must be placed under the workpiece
near the line of cut and near the edge of the workpiece on both sides
of the wheel.
f) Use extra caution when making a “pocket cut” into existing
wallsor other blindareas. The protruding wheel may cut gas or
water pipes, electrical wiring or objects that can cause kickback.
Safety Warnings Specic for Sanding Operations:
a) Do not use excessively oversized sanding disc paper.
Follow manufacturers recommendations, when selecting
sanding paper. Larger sanding paper extending beyond the
sanding pad presents a laceration hazard and may cause snagging,
tearing of the disc or kickback.
Safety Warnings Specic for Wire Brushing Operations:
a) Be aware that wire bristles are thrown by the brush
even during ordinary operation. Do not overstress the wires
by applying excessive load to the brush. The wire bristles can
easily penetrate light clothing and/or skin.
18
GB
English
b) If the use of a guard is recommended for wire brushing,
do not allow any interference of the wire wheel or brush
with the guard. Wire wheel or brush may expand in diameter due
to work load and centrifugal forces.
Additional Safety and Working Instructions
When grinding metal, ying sparks are produced. Take care that
no persons are endangered. Because of the danger of re, no
combustible materials should be located in the vicinity (spark ight
zone). Do not use dust extraction.
Avoid ying sparks and sanding dust hit your body.
Never reach into the danger area of the machine when it is running.
Chips and splinters must not be removed while the machine is
running.
Immediately switch o the machine in case of considerable vibra-
tions or if other malfunctions occur. Check the machine in order to
nd out the cause.
Under extreme conditions (e.g. smooth-grinding metals with
the arbour and vulcanized bre grinding disk), signicant
contamination can build up on the inside of the angle grinder. For
safety reasons, in such conditions a ground fault interrupter must
be connected in series. If the ground fault interrupter trips the
machine must be sent for service.
Do not let any metal parts enter the airing slots - danger of short
circuit!
MAINS CONNECTION
Connect only to single-phase AC system voltage as indicated on
the rating plate. It is also possible to connect to sockets without an
earthing contact as the design conforms to safety class II.
Appliances used at many dierent locations including wet room
and open air must be connected via a residual current device (FI,
RCD, PRCD) of 30mA or less.
Only plug-in when machine is switched o.
WS 22-180, WS 22-230, WS 24-230 GV: Inrush currents cause
short-time voltage drops. Under unfavourable power supply
conditions, other equipment may be aected. If the system
impedance of the power supply is lower than 0,2 Ohm, disturbances
are unlikely to occur.
SPECIFIED CONDITIONS OF USE
The angle grinder is intended for grinding and cutting metal, stone
and ceramicmaterials as well as sanding and wire brushing.
Use the cutting guard from the accessories range for cutting
application.
Please refer to the instructions supplied by the accessory
manufacturer.
The machine is suitable only for working without water.
WORKING INSTRUCTIONS
For accessories intended to be tted with threaded hole wheel,
ensure that the thread in the wheel is long enough to accept the
spindle length.
Always use and store the cutting and grinding disks according to
the manufacturer‘s instructions.
Always use the correct guard for cutting and grinding.
The grinding surface of the centre depressed disks must be moun-
ted min. 2 mm below the plane of the guard lip.
The adjusting nut must be tightened before starting to work with
the machine.
Always use the auxiliary handle.
The workpiece must be xed if it is not heavy enough to be steady.
Never move the workpiece towards the rotating disk by hand.
RESTART CUTOUT
WS 22-180 E, WS 22-230 E, WS 24-230 GEV:
Machines with a lockable switch are supplied with a restart cutout.
This prevents the machine restarting by itself after a power failure.
When resuming work, switch the machine o and then switch it
back on again.
STARTING CURRENT LIMITER
WS 22-180 E, WS 22-230 E, WS 24-230 GEV:
The starting current for the machine is several times greater than
rated current. The starting current limiter reduces the starting cur-
rent to such an extent that a fuse (16 A, slow-blow) is not tripped.
SMOOTH START
WS 22-180 E, WS 22-230 E, WS 24-230 GEV:
Electronic smooth start for save use prevents jerky run-up of the
machine.
MAINTENANCE
The ventilation slots of the machine must be kept clear at all times.
If the supply cord of this power tool is damaged, it must be
replaced by a specially prepared cord available through the service
organization.
Use only AEG accessories and spare parts. Should components need to
be replaced which have not been described, please contact one of our
AEG service agents (see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please state
the Article No. as well as the machine type printed on the label
and order the drawing at your local service agents or directly at:
Techtronic Industries GmbH, Max-Eyth-Straße10, 71364Winnen-
den, Germany.
This manual suits for next models
5
Table of contents
Languages:
Other AEG Powertools Grinder manuals
