AEG F89088VI-M-1 Instruction sheet

DISHWASHER CONNECTION
INSTALL
15MAR2016

AEG Dishwashers Unit Dimensions &
Electrical Requirements
................................................ 1.
F65478VI-S
18” Fully Integrated Dishwasher
................................................ 2.
F89088VI-M-1
24” Stainless Steel Door - Fied
................................................ 3.
F89088VI-S-1
24” Fully Integrated Dishwasher
................................................ 4.
P&C Dishwashers Unit Dimensions &
Electrical Requirements
................................................ 6.
DW18PCFI
24” Compact Dishwasher
................................................ 7.
DW4SS/FI
24” Compact Dishwasher
................................................ 11.
DWTPC5FCSS
24” Dishwasher
................................................ 8.
DWTPC10SS
24” Stainless Steel Dishwasher
................................................ 9.
DWTPC10FI
24” Fully Integrated Dishwasher
................................................ 10.
Connecon Placements
Hose, Electrical, & Drain
................................................ 13.
Appliance Guarantee & Warranty
................................................ 17.
TABLE OF CONTENTS

MODEL HEIGHT WIDTH DEPTH
F89088VI-M-1 86cm- 91cm
337/8”- 3513/16”
59.7cm- 59.9cm
231/2”- 239/16”
57cm
227/16”
F89088VI-S-1 86cm- 91cm
337/8”- 3513/16”
59.7cm- 59.9cm
231/2”- 239/16”
55cm
215/8”
F65478VI-S 82cm- 87cm
321/4”- 341/4”
44.7cm- 44.9cm
175/8”- 1711/16”
55cm
215/8”
MODEL VOLTAGE FREQUENCY RECEPTACLE
REQUIRED
WATTAGE
F89088VI-M-1 115v 60hz 15AMPS 1300W
F89088VI-S-1 115v 60hz 15AMPS 1300W
F65478VI-S 115v 60hz 15AMPS 1300W
UNIT DIMENSIONS
ELECTRICAL REQUIREMENTS
Pg. 1

F65478VI-S
*Install custom door panel 47mm
above dishwasher door.
Panel Dimensions / Weight
Applied Panel Width: 171/2” / 444 cm
Panel Height: Max 2915/16” / Max. 760 cm
Custom Panel Weight MUST NOT EXCEED 7KG
171/2”
444mm
2915/16”
760mm
18” Fully Integrated
Pg. 2
341/4” - 351/16”
870mm 890mm
179/16 ”
453mm
24”
610mm
2915/16”
760mm
325/16” - 341/4”
820mm - 870mm
41/8” - 61/8”
105mm - 155mm
171/2”
444mm
17/8”
47mm
41/2”
max. 115mm
229/16” - 2213/16”
572mm - 580mm

F89088VI-M-1
24” Stainless Steel Door - Fied
Pg. 3
337/8” - 3513/16”
860mm - 910mm
24”
610mm 239/16”
598mm
341/16” - 3513/16”
860mm - 910mm
235/8”
600mm
24”
610mm
235/8”
600mm

F89088VI-S-1
24” Fully Integrated
239/16”
598mm
2915/16”
760mm
Panel Dimensions / Weight
Applied Panel Width: 239/16” / 598 cm
Panel Height: Max 2915/16” / Max. 760 cm
Custom Panel Weight MUST NOT EXCEED 8KG
Pg. 4
337/8” - 3513/16”
860mm - 910mm
24”
610mm 239/16”
598mm
341/16” - 3513/16”
865mm - 910mm
235/8”
600mm
24”
610mm
2011/16”
525mm

Pg. 5

MODEL HEIGHT WIDTH DEPTH
DW18PCFI 82cm- 87cm
321/4”- 341/4”
44.7cm-44.9cm
175/8”-1711/16”
55cm
215/8”
DWTPC10FI/SS 86cm - 91cm
337/8”- 3513/16”
59.7cm-59.9cm
231/2”- 239/16”
55cm
215/8”
DWTPC5FCSS 82cm- 87cm
321/4”- 341/4”
59.7cm-59.9cm
231/2”- 239/16”
55cm
215/8”
DW4SS/FI 43.8cm
171/4”
55cm
235/8”
50cm
1911/16”
MODEL VOLTAGE FREQUENCY RECEPTACLE
REQUIRED
WATTAGE
DW18PCFI 115v 60hz 15AMPS 1300W
DWTPC5FCSS 115v 60hz 15AMPS 1300W
DWTPC10FI/SS 115v 60hz 15AMPS 1300W
DW4SS/FI 115v 60hz 15AMPS 1280W
UNIT DIMENSIONS
ELECTRICAL REQUIREMENTS
Pg. 6

Pg. 7
DW18PCFI
18” Fully Integrated Dishwasher
Panel Dimensions / Weight
Applied Panel Width: 171/2” / 444 cm
Panel Height: Max 2915/16” / Max. 760 cm
Custom Panel Weight MUST NOT EXCEED 7KG
171/2”
444mm
2915/16”
760mm
341/4” - 351/16”
870mm 890mm
179/16 ”
453mm
24”
610mm
2915/16”
760mm
325/16” - 341/4”
820mm - 870mm
41/8” - 61/8”
105mm - 155mm
171/2”
444mm
17/8”
47mm
41/2”
max. 115mm
229/16” - 2213/16”
572mm - 580mm
*Install custom door panel 47mm
above dishwasher door.

DWTPC5FCSS
Pg. 8
24” Dishwasher
2213/16”
580mm 239/16 ”
598mm
235/8 ”
600mm
24”
610mm
321/4” - 341/4”
820mm - 870mm
321/2” - 341/2”
825mm - 875mm

DWTPC10SS
24” Stainless Steel Dishwasher
239/16”
598mm
2915/16”
760mm
Panel Dimensions / Weight
Applied Panel Width: 239/16” / 598 cm
Panel Height: Max 2915/16” / Max. 760 cm
Custom Panel Weight MUST NOT EXCEED 8KG
Pg. 9
337/8” - 3513/16”
860mm - 910mm
24”
610mm 239/16”
598mm
341/16” - 3513/16”
865mm - 910mm
235/8”
600mm
24”
610mm
2011/16”
525mm

DWTPC10FI
24” Fully Integrated Dishwasher
Pg. 10
337/8” - 3513/16”
860mm - 910mm
24”
610mm 239/16”
598mm
341/16” - 3513/16”
860mm - 910mm
235/8”
600mm
24”
610mm
235/8”
600mm

Pg. 11
DW4SS/FI
171/4”
438mm
1911/16”
500mm
9/16”
*15mm
27/16”
62mm
1029/32”
277mm
1811/16”
*475mm
231/4”
*590mm
11/16”
*18mm
215/8”
550mm
311/2”
800mm
367/16”
925mm
1515/16”
*405mm
21/2”
*63mm
24” Compact Dishwasher

Pg. 12

CONNECTION PLACEMENTS
* Connecons must never be placed behind the appliance.
* Make sure the hoses and power supply cord are not bent or
crushed.
RECOMMENDED CONNECTION PLACEMENTS
& DISTANCES
* If connecons are located in an adjacent space/cabinet, a through
hole with a minimum of 8cm x 8cm ( 3 1/8” x 3 1/8”) is needed.
* Refer to g 1. & Fig2. for detailed outlet hose connecon.
Pg. 13
59”
1500mm
63”
1600mm
47”
1200mm
Cold Water Inlet Hose
Outlet Hose
min. 16”
400mm
Refer to
g 1&2

g 1. Connecng the drain hose with a hard plasc end
1.
2.
3. 4.
5. 6.
7.
1. Dishwasher drain hose
2. Squeeze clamp (supplied)
3. Black rubber connection hose (supplied)
4. 1” or 1 1/4” Gear clamp
5. 3/4” insert x male pipe thread nylon adapter
6. 1 1/2” x 3/4” ABS dishwasher bushing
7. 1 1/2” ABS 45o wyes
1. Dishwasher drain hose
2. Squeeze clamp (supplied)
3. 3/4” insert x male pipe thread nylon adapter
4. 1 1/2” x 3/4” ABS dishwasher bushing
5. 1 1/2” ABS 45o wyes
g 2. Connecng the drain hose with a so plasc end
1.
2.
3. 4.
5.
* Refer to g 1. & Fig2. for detailed outlet hose connecon.
Pg. 14

CONNECTING AQUASTOP INLET HOSE TO THE DISHWASHER
Method1: Garden hose install
* Use the brass adapter provided with the dishwasher to
connect the garden hose outlet to the Aquastop fi ll hose.
* The brass adapter allows for the connec on of a 3/4” GHT to a
3/4 metric thread.
Garden hose
Brass Adapter
(Supplied with dishwasher)
AQUASTOP Fill hose
(Supplied with dishwasher)
* The AQUASTOP angle must not
be more than 30o from the
ver cal for full func onality.
30o 30o
30
o
o
30
30
30
30
30
30
Pg. 15

CONNECTING AQUASTOP INLET HOSE TO THE DISHWASHER
Method2: Connec ng to exis ng 1/2” inlet
* A brass adapter that can be purchased from Home
Hardware (part# 3240102).
* The brass adapter allows for the connec on of a 1/2” inlet to a
3/4” metric thread.
Exis ng 1/2 inlet
Brass Adapter
(Home Hardware
part# 3240102)
AQUASTOP Fill hose
(Supplied with dishwasher)
* The AQUASTOP angle must not
be more than 30o from the
ver cal for full func onality.
30o 30o
30
o
o
30
30
30
30
30
30
Pg. 16

GUARANTEE/CUSTOMER SERVICE CENTRES
EURO-LINE APPLIANCES INC.
LENGTH OF WARRANTY
TWO YEAR FULL WARRANTY from original date of purchase,
including parts and labour, to the rst purchaser of this appliance.
When the appliance is installed, operated, and maintained
according to the instrucons aached to or provided with the
product, EURO-LINE APPLIANCES will pay for replacement parts
and/or labour to repair defects in materials or workmanship.
Service must be provided by an authorized Euro-Line company
(unless advised otherwise). This warranty is void if the consumer
aempts to repair the appliance or has someone other than an
authorized person try to repair it. The sole and exclusive remedy
under this warranty shall be product service and repair as provided
herein. THIS GUARANTEE DOES NOT COVER COMMERCIAL USE.
EXCEPTIONS:
EURO-LINE APPLIANCES WILL NOT PAY FOR THE FOLLOWING
SERVICE CALLS:
1. To install or correct the installaon of an appliance
2. To provide instrucon on the use of an appliance.
3. To replace house fuses, re-set circuit breakers or correct
house wiring.
4. To correct house plumbing.
5. To clean drains, lters or garbage disposals.
6. To repair an appliance if it fails due to misuse or abuse.
7. To repair cosmec damage to the appliance, unless such
damage results from a defect in the workmanship or
materials. Such damage must be reported to EURO-LINE
APPLIANCES within 5 days from the date of purchase.
Pg. 17
