AEG FAVORIT G 330 User manual

FAVORIT G 330
Geschirrspülautomat
Dishwasher
Benutzerinformation
Instruction book
152969 94/0de-en 8-04-2003 13:03 Pagina 1

Dear customer!
Please read these user instructions carefully.
Above all please observe the safety instructions on the first few pages
of these user instructions! Please keep these user instructions for later
reference. Pass them on to any subsequent owner of the appliance.
The warning triangle and/or specific words (Warning!, caution!,
Important!) are used to highlight instructions that are important for
your safety or for the function of the appliance. It is imperative that
these instructions are observed.
Numbered instruction steps lead you step by step through the
operation of the appliance.
Next to this symbol you receive additional information and practical
tips on using the appliance.
Tips and instructions for the economical and environmentally
conscious use of the appliance are marked with a clover leaf.
In the event of a malfunction, these operating instructions contain
information on how to rectify faults yourself, see "What to do, when..."
section.
If these instructions are insufficient, please contact your nearest
customer service centre.
In the case of technical problems, our customer service organisation is
available to provide you with assistance at any time.
Printed on paper manufactured with environmentally sound processes.
He who thinks ecologically acts accordingly...
42
152969 94/0de-en 8-04-2003 13:04 Pagina 42

CONTENTS
Operating instructions 44
Safety instructions 44
Disposing of packaging and old machine 46
Economical and ecological dishwashing 47
Description of the appliance and control panel 48
Prior to using for the first time 50
The water softener 50
Filling with salt 51
Rinse aid 53
In daily use 56
Loading cutlery and dishes 56
The lower basket 57
The cutlery basket 57
The upper basket 58
Adjusting the height of the upper basket 59
Use of detergent 60
Detergent tablets 62
Concentrated detergent 62
Use of "3 in 1"combi detergent tablets 63
Washing programmes 64
Starting a washing programme 65
Unloading the dishwasher 66
Maintenance and cleaning 67
Cleaning the filters 67
What to do, when... 70
Technical specifications 72
Hints for test centres 73
Installation instructions 74
Fitting under a counter 74
Levelling 74
Water supply connections 75
Water inlet hose with safety valve 76
Water outlet hose connection 77
Electrical connection 78
Service 79
Contents
43
152969 94/0de-en 8-04-2003 13:04 Pagina 43

OPERATING INSTRUCTIONS
Safety instructions
The safety of AEG electrical appliances conforms to accepted rules of
technology and the Appliance Safety Act. We as manufacturers,
however, see ourselves as being obliged to familiarise you with the
following safety instructions.
Using your dishwasher for its intended purpose
●Only use your dishwasher for machine washing of household
crockery. If your machine is misused or used for any purposes other
than that for which it is intended, the manufacturer cannot be held
liable for any damage caused.
●For safety reasons, you should not convert or modify your
dishwasher in any way.
Before using your dishwasher for the first time
●Check your dishwasher for any transport damage. Never connect a
damaged machine. If your dishwasher is damaged, you should
contact your supplier.
●Your dishwasher must be correctly installed and connected. Please
read the section on "Installation" to make sure you know all about
this.
●Before using your dishwasher for the first time, do not forget that
the nominal voltage and current type indicated on the rating plate
of your machine must be the same as the nominal voltage and
current type at the installation site. The necessary electrical fusing is
also given on the rating plate.
Child safety
●Packaging parts (e.g. foils, styrene foam) may be dangerous for
children,who could even be suffocated! You should therefore keep
all packaging well away from children.
●Children may not recognise the dangers of improper use of
electrical appliances. You should therefore ensure proper supervision
during operation and not allow your children to play with your
dishwasher.
●Detergents may have a caustic effect on eyes, mouth and throat and
may even cause suffocation! Keep all detergents in a safe place out
of children’s reach.
Operating instructions
44
152969 94/0de-en 8-04-2003 13:04 Pagina 44

●The water in your dishwasher should not be used for drinking.
Detergent residues may still be present in your machine. Make sure
you do not splash these caustic residues onto your skin or suffocate
yourself!
Keep children well away from your dishwasher when its door is
open.
Your dishwasher in day-to-day use
●Never operate your dishwasher if the electrical supply lead, supply
or drain hose, control panel, worktop or plinth are damaged.
●If there is a fault, first turn the water tap off. Then switch off your
machine and pull the plug out of the socket. If there is a fixed
connection, switch off or unscrew the fuse(s).
●Never pull the plug out of the socket by the cable - always hold the
plug.
●Dishwasher repairs should only be performed by trained personnel.
Improper repairs may seriously endanger the user. If your
dishwasher needs to be repaired, you should contact our service
centre or your retailer.
●Never place any solvents in your dishwasher or you may cause an
explosion!
●Do not rest or sit on the open door or the machine could tilt.
●Before using special dishwasher salt, detergent or rinse-aid, make
sure that the manufacturer of these products expressly specifies
their use in domestic dishwashers.
●Always turn off the water tap when your dishwasher is left
unattended for any length of time, e.g. when you are away on
holiday.
●Only transport the dishwasher in an upright position. Tipping it
upside down during transport could cause salty water to leak into
the internal compartment and lead to the formation of rust.
Operating instructions
45
152969 94/0de-en 8-04-2003 13:04 Pagina 45

Disposing of packaging and old machine
Disposing of the packaging
Our dishwashers require effective protective packaging in transit,
though we always confine ourselves to what is absolutely necessary.
Warning! Packaging parts (e.g. foils, styrene foam) may be dangerous
for children, who could even be suffocated! You should therefore keep
all packaging well away from children.
All packaging materials used are environmentally compatible and
reusable.
The cardboard parts are produced from recycled paper, and the wood is
untreated.
The plastics are marked as follows:
>PE< for polyethylene, e.g. packaging foils.
>PS< for polystyrene, e.g. padding (essentially CFC-Free).
>POM< for polyoxymethylene, e.g. plastic clamps.
Give the packaging for reuse to your local recycling centre. Your
municipal or local authority will give you its address.
Disposing of your old machine
When your machine finally reaches the end of its life and you
withdraw it from service, you should render it unserviceable before
having it disposed of.
Warning! Children at play could lock themselves in your machine (and
suffocate) or otherwise endanger their lives. Therefore pull out the
main plug and detach and discard the electrical supply lead.
Disable the door lock so that the door no longer closes.
Marking of plastic parts for graded recycling: all plastic parts in your
machine are marked with internationally standardised abbreviations
(e.g. <PS> for polystyrene). When your machine is disposed of, this en-
ables plastic waste to be sorted into individual types for environmen-
tally conscious recycling.
Take your decommissioned machine to your local recycling centre or
dealer, who will take it back from you for a small handling charge.
Operating instructions
46
152969 94/0de-en 8-04-2003 13:04 Pagina 46

Economical and ecological dishwashing
●Only connect the dishwasher to the hot water supply if your hot
water is not electrically heated.
●Ensure that the water softener is correctly adjusted.
●Do not pre-rinse under running water.
●Select the wash programme to suit the nature and degree of the
soiling on the dishes.
●Do not use more detergent, special salt or rinse aid than is
recommended in these operating instructions and by the
manufacturer of the respective product.
Operating instructions
47
152969 94/0de-en 8-04-2003 13:04 Pagina 47

Description of the appliance and control
panel
Operating instructions
48
IN148
1. Upper basket stop
2. Water hardness switch
3. Salt container
4. detergent dispenser (type A / type B)
5. Control panel
6. Rating plate
7. Rinse aid dispenser (type A / type B)
8. Filters
9. Lower spray arm
10. Upper spray arm
11. Upper basket
12. Worktop
152969 94/0de-en 8-04-2003 13:04 Pagina 48

Operating instructions
49
Programme sequence indicator
As the programme progresses, the programme selector dial turns. to show the phase
in the wash programme the appliance has reached.
152969 94/0de-en 8-04-2003 13:04 Pagina 49

Operating instructions
50
Prior to using for the first time
Before using your dishwasher for the first time:
1. Ensure that the electrical and water connections comply with the
installation instructions
2. Remove all packaging from inside the appliance
3. Set the water softener
4. Pour 1 litre of water inside the salt container and then fill with salt
5. Fill the rinse aid dispenser
6. Run a "Rinse and Hold" programme
The water softener
The dishwasher is equipped with a water softener designed to remove
minerals and salts from the water supply, which would have a
detrimental or adverse effect on the operation of the appliance.
The higher the content of these salts, the harder your water is.
Water hardness is measured in equivalent scales, German degrees,
French degrees and PPM (parts per Million).
The softener should be adjusted according to the hardness of the water
in your area. Your local Water Authority can advise you on the
hardness of the water in your area.
The dishwasher is factory set at position 2.
If your water is below level 1 it is already soft and therefore there is no
need to use salt. In this case adjust the water softener on level 1
without using salt.
If the water softener has been adjusted on level 1 and no salt is being
used, the salt refilling indicator light on the control panel will always
remain illuminated when the machine is switched on.
Water hardness
°dH
(german degrees) °TH
(french degrees) PPM
(parts per million)
Water
hardness
setting
0 - 4
5 - 11
12 - 22
23 - 34
35 - 45
46 - 50
0 - 8
9 - 20
21 - 40
41 - 60
61 - 80
81 - 90
0 - 80
81 - 200
201 - 400
401 - 600
601 - 800
801 - 900
-
Level 1
Level 2
Level 3
Level 4
Level 5
Use
of
salt
NO
YES
YES
YES
YES
YES
152969 94/0de-en 8-04-2003 13:04 Pagina 50

Setting the water softener
1. Open the dishwasher door.
2. Remove the lower basket from the dishwasher.
3. Turn the water hardness switch until the required level (see table)
corresponds with the marker .
4. Replace the lower basket.
Filling with salt
Special salt can be added in one of two ways:
●If you are using dishwasher detergent that already integrates the
salt function, this must be placed in the detergent compartment.
- In this case the water softener must be set to level 1 without
putting salt in the salt container.
●If you are using dishwasher detergent and salt separately,
the special salt is to be put into the salt container.
- In this case the water softener must be set to between level 1 and
5 (depending on the water hardness in your area).
Only use salt specifically designed for use in dishwashers.
All other types of salt not specifically designed for use in a
dishwasher, especially table salt, will damage the water softener.
Only fill with salt just before starting one of the washing
programmes (except the Rinse and Hold programme).
This will prevent any grains of salt or salty water, which may have
been spilt, remaining on the bottom of the machine for any period
of time, which may cause corrosion.
Operating instructions
51
AA08
152969 94/0de-en 8-04-2003 13:04 Pagina 51

To fill:
1. Open the door, remove the lower basket and unscrew the
cap of the salt container by turning it anticlockwise.
2. Pour 1 litre of water inside the container (this is necessary only
before filling with salt for the first time).
3. Using the funnel provided,
pour in the salt until the
container is full.
4. Replace the cap making
sure that there is no trace
of salt on the screw
thread or on the gasket.
5. Screw on the cap tightly
turning it clockwise until it
stops with a click.
The salt container will require topping up periodically. You are
reminded of this by the salt indicator light on the control panel which
will illuminate when the salt has finished.
The salt indicator light on the control panel can remain
illuminated for 2-6 hours after the salt has been replenished,
assuming the dishwasher remains switched on. If you are using
salts that take longer to dissolve then this can take longer. The
function of the machine is not affected.
Do not worry if water over flows from the unit when filling with salt,
this is quite normal.
Operating instructions
52
SALE
ZOUT
SALT
SALZ
SEL
SR14
152969 94/0de-en 8-04-2003 13:04 Pagina 52

Rinse aid
Rinse aid is automatically added during the last rinse, ensuring
thorough rinsing, and spot and streak free drying. The dispenser, which
is positioned inside the door, holds about 110 ml of rinse aid, which is
sufficient for 16 - 40 dishwashing programmes, depending upon the
dosage setting.
Rinse aid can be added in one of two ways:
●If you are using dishwasher detergent that already integrates the
rinse aid function, this must be placed in the detergent
compartment.
- In this case the rinse aid compartment must be empty.
If in the rinse aid dispenser there is still rinse aid you must wait
until it has finished before using detergent that contains rinse aid.
●If you are using dishwasher detergent and rinse aid separately, the
rinse aid is to be put into the rinse aid dispenser.
- In this case the rinse aid dosage must be set in position from 1 to
6 (see "Adjusting the dose").
Filling with rinse aid
(Rinse aid dispenser type A)
1. Open the container by pressing the release button (A).
2. Fill with rinse aid exactly up to the level indicator marked
"max".
Ensure that the lid is closed after every refill.
Operating instructions
53
BR07 BR14
152969 94/0de-en 8-04-2003 13:04 Pagina 53

Top up with rinse aid when the
indicator (B) becomes clear,
Adjusting the dose
According to the finish and drying
results obtained, adjust the dose of
rinse aid by means of the 6
position selector (position 1
minimum dosage, position 6
maximum dosage).
Increase the dose if there are drops
of water or lime spots on the
dishes after washing.
The dose is factory set in position
4.
Reduce it if there are sticky
whitish streaks on the dishes.
Filling with rinse aid
(Rinse aid dispenser type B)
1. Open the container by turning the lid (A) anticlockwise.
2. Fill with rinse aid exactly up to the level indicator marked
"max".
Ensure the lid is closed after every refill.
Operating instructions
54
BR11
BR09
BR01 BR13
152969 94/0de-en 8-04-2003 13:04 Pagina 54

Top up with rinse aid when the
indicator (B) becomes clear,
Adjusting the dose
According to the finish and drying
results obtained, adjust the dose of
rinse aid by means of the 6
position selector (C) (position 1
minimum dosage, position 6
maximum dosage).
Increase the dose if there are drops
of water or lime spots on the
dishes after washing.
The dose is factory set in position
5.
Reduce it if there are sticky
whitish streaks on the dishes.
Clean up any rinse aid spilt during filling with an absorbent cloth
to avoid excess foaming during the next wash.
Only use branded rinse aid for dishwashers. Never fill the rinse aid
dispenser with any other substances (e.g. dishwasher cleaning
agent, liquid detergent). This would damage the appliance.
Operating instructions
55
BR03
BR02
152969 94/0de-en 8-04-2003 13:04 Pagina 55

In daily use
• Check if it’s necessary to refill with special salt or rinse aid
• Load cutlery and dishes into the dishwasher
• Fill with dishwasher detergent
• Select a wash programme suitable for the cutlery and dishes
• Start the wash programme
Loading cutlery and dishes
Sponges, household cloths and any object that can absorb water
may not be washed in the dishwasher.
•Before loading the dishes, you should:
- Remove large left-overs.
- Soften remnants of burnt food in pans.
•When loading the dishes and cutlery, please note:
- Dishes and cutlery must not impede the rotation of the spray arms.
- Load hollow items such as cups, glasses, pans etc, with the opening
downwards so that water cannot collect in the container or a
deep base.
- Dishes and items of cutlery must not lie inside one another or
cover each other.
- To avoid damage to glasses, they must not touch.
- Lay small objects in the cutlery basket.
Operating instructions
56
For washing in the dishwasher the following cutlery/dishes
are not suitable:
•Cutlery with wooden, horn, china or
mother-of-pearl handles
•Plastic items that are not heat
resistant
•Older cutlery with glued parts that is
not temperature resistant
•Bonded cutlery items or dishes
•Pewter or copper items
•Lead crystal glass
•Steel items subject to rusting
•Wooden platters
•Items made from synthetic fibres
•Only wash stoneware in the dishwasher if it
is specifically marked as being dishwasher-
safe by the manufacturer.
•Glazed patterns may fade if machine
washed frequently.
•Silver and aluminium parts have a tendency
to discolour during washing. Left-overs, e.g.
egg white, egg yolk and mustard often
cause discolouring and staining on silver.
•Some types of glass can become dull after a
large number of washes.
are of limited suitability:
152969 94/0de-en 8-04-2003 13:04 Pagina 56

Open the door and slide out the baskets to load the dishes.
The lower basket
The lower basket is designed to take saucepans, lids, plates, salad
bowls, cutlery etc.
Serving dishes and large lids should be arranged around the edge of
the basket, ensuring that the upper spray arm can turn freely.
The cutlery basket
Long bladed knives stored in an upright position are a potential
hazard.
Long and/or sharp items of cutlery such as carving knives must be
positioned horizontally in the upper basket.
Take care when loading or unloading sharp items such as knives.
Cutlery should be placed in the removable cutlery basket with the
handles facing downwards.
If the handles protrude from the bottom of the basket, obstructing the
lower spray arm, load the cutlery with the handles facing upwards.
Mix spoons with other cutlery to prevent them from sticking together.
Silver cutlery tends to go black if mixed with steel cutlery. Place it in
the cutlery basket separate from the others.
Operating instructions
57
UI59
UI13
152969 94/0de-en 8-04-2003 13:04 Pagina 57

For best results we recommend to use the cutlery grid provided (if the
size and the dimensions of the cutlery allow it).
The upper basket
The upper basket is designed for plates (dessert plates, saucers, dinner
plates of up to 25 cm in diameter), salad bowls, cups and glasses.
Arrange items on and underneath the cup racks so that water can
reach all surfaces.
Glasses with long stems can be placed upside down in the cup rack.
Light items (plastic bowls etc.) must be loaded in the upper basket and
arranged so they do not move.
Operating instructions
58
1
2
UI80
US64
152969 94/0de-en 8-04-2003 13:04 Pagina 58

In the case that plates are loaded in the upper basket:
load them starting from the rear
positions of the basket; tilting
them slightly forwards and
avoiding the front positions near
the door.
Before closing the door, ensure that the spray arms can rotate
freely.
Adjusting the height of the upper basket
If washing very large plates you can load them in the lower basket
after moving the upper basket to the higher position.
To move to the higher position proceed as follows:
1. Move the front runner stops (A) of the upper basket outwards and
slide the basket out.
2. Refit the basket in the higher
position and replace the stops
(A) in their original position.
After loading your machine always
close the door, as an open door
can be a hazard.
Operating instructions
59
RC01
US71
With upper basket raised 20 cm 31 cm
With upper basket lowered 25 cm 27 cm
Maximum height of the dishes in:
upper basket lower basket
152969 94/0de-en 8-04-2003 13:04 Pagina 59

Use of detergent
Only use detergents specifically designed for use in dishwashers.
Using no more then the correct amount of detergent contributes
to reducing pollution.
Prior to the start of a wash programme (not for the "Rinse and Hold"
programme, that does not require the use of detergent). The detergent
is released during the washing phase.
Please observe the manufacturer’s dosing and storage
recommendations as stated on the detergent packaging.
Fill with detergent
(Detergent dispenser type A)
1. If the lid is closed: press release button (1). The lid springs open.
2. Fill the detergent dispenser (2) with detergent.
The marking indicates the dosing levels:
20 = approximately 20 ml of detergent
30 = approximately 30 ml of detergent
3. All programmes with prewash need an additional detergent dose
(5/10 g) that must be placed in the prewash detergent chamber (3).
This detergent will take effect during the prewash phase.
4. Close the lid and press until it locks in place.
Operating instructions
60
DE19 DE22
152969 94/0de-en 8-04-2003 13:04 Pagina 60
