USER
MANUAL
EN User Manual
Dishwasher
FFB72600PM
FFB72600PW

CONTENTS
1. SAFETY INFORMATION.............................................................................................2
2. SAFETY INSTRUCTIONS.............................................................................................4
3. PRODUCT DESCRIPTION...........................................................................................6
4. CONTROL PANEL....................................................................................................... 7
5. PROGRAMMES............................................................................................................8
6. SETTINGS.....................................................................................................................9
7. OPTIONS....................................................................................................................11
8. BEFORE FIRST USE................................................................................................... 12
9. DAILY USE..................................................................................................................12
10. HINTS AND TIPS..................................................................................................... 14
11. CARE AND CLEANING.......................................................................................... 15
12. TROUBLESHOOTING.............................................................................................17
13. TECHNICAL INFORMATION................................................................................. 20
14. INSTALLATION........................................................................................................21
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
www.aeg.com2
15. WARRANTY..............................................................................................................23

manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
•Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away unless continuously supervised.
•Children of less than 3 years of age should be kept
away unless continuously supervised.
•Do not let children play with the appliance.
•Keep detergents away from children.
•Keep children and pets away from the appliance when
the door is open.
•Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
1.2 General Safety
•This appliance is intended to be used in household
and similar applications such as:
–farm houses; staff kitchen areas in shops, offices
and other working environments;
–by clients in hotels, motels, bed & breakfast and
other residential type environments.
•Do not change the specification of this appliance.
•The operating water pressure (minimum and
maximum) must be between 0.5 (50) / 8 (800) bar (kPa)
•Obey the maximum number of 14 place settings.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or a
similarly qualified persons in order to avoid a hazard.
ENGLISH 3

•Put knives and cutlery with sharp points in the cutlery
basket with the points down or in a horizontal
position.
•Do not leave the appliance with the door open, to
avoid a tripping hazard.
•Before any maintenance operation, deactivate the
appliance and disconnect the mains plug from the
socket.
•Do not use high pressure water sprays and/or steam
to clean the appliance.
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
•The ventilation openings in the base (if applicable)
must not be obstructed by a carpet.
•Some dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed. Avoid
contact with the skin and eyes and keep children away
from the dishwasher when the door is open.
•Check that the detergent receptacle is empty after
completion of the wash cycle.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
2.2 Electrical connection
WARNING!
Risk of fire and electric
shock.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
www.aeg.com
4

installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Water connection
• Do not cause damage to the water
hoses.
• Before connection to new pipes,
pipes not used for a long time, where
repair work has been carried out or
new devices fitted (water meters,
etc.), let the water flow until it is clean
and clear.
• Ensure that there are no visible water
leaks during and after the first use of
the appliance.
• The water inlet hose has a safety valve
and a sheath with an inner mains
cable.
WARNING!
Dangerous voltage.
• If the water inlet hose is damaged,
immediately close the water tap and
disconnect the mains plug from the
mains socket. Contact the Authorised
Service Centre to replace the water
inlet hose.
2.4 Use
• Do not sit or stand on the open door.
• Dishwasher detergents are
dangerous. Obey the safety
instructions on the detergent
packaging.
• Do not drink and play with the water
in the appliance.
• Do not remove the dishes from the
appliance until the programme is
complete. Some detergent may
remain on the dishes.
• The appliance can release hot steam
if you open the door while a
programme operates.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
2.5 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.6 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
ENGLISH 5

3. PRODUCT DESCRIPTION
12
65
8
9
34 21
10 711
1Worktop
2Top spray arm
3Upper spray arm
4Lower spray arm
5Filters
6Rating plate
7Air vent
8Rinse aid dispenser
9Detergent dispenser
10 Cutlery basket
11 Lower basket
12 Upper basket
www.aeg.com6

4. CONTROL PANEL
1
2 4 5
68
3
7
1On/off button
2Program button
3Programme indicators
4Display
5Delay button
6Option button
7Indicators
8Start button
4.1 Indicators
Indicator Description
Washing phase. It comes on when the washing phase operates.
Rinsing phase. It comes on when the rinsing phase operates.
Drying phase. It comes on when the drying phase operates.
End indicator.
TimeSaver indicator.
XtraDry indicator.
Rinse aid indicator. It is always off while the programme operates.
Delay indicator.
ExtraHygiene indicator.
ENGLISH 7

5. PROGRAMMES
Programme Degree of soil
Type of load
Programme phases Options
1) • Normal soil
•Crockery and cut-
lery
• Prewash
• Wash 50 °C
• Rinses
• Dry
• ExtraHygiene
• TimeSaver
• XtraDry
2) • All
•Crockery, cutlery,
pots and pans
• Prewash
• Wash from 45 °C
to 70 °C
• Rinses
• Dry
• ExtraHygiene
• XtraDry
3) • Heavy soil
•Crockery, cutlery,
pots and pans
• Prewash
• Wash 70 °C
• Rinses
• Dry
• TimeSaver
• XtraDry
• Normal or light
soil
•Delicate crockery
and glassware
• Wash 45 °C
• Rinses
• Dry
• XtraDry
4) • Fresh soil
•Crockery and cut-
lery
• Wash 60 °C
• Rinses
• ExtraHygiene
• XtraDry
5) • All • Prewash
6) • Normal soil
•Crockery and cut-
lery
• Prewash
• Wash 50 °C
• Rinses
• Dry
• XtraDry
1) With this programme you have the most efficient use of water and energy consumption for crockery
and cutlery with normal soil. (This is the standard programme for test institutes).
2) The appliance senses the degree of soil and the quantity of items in the baskets . It automatically ad-
justs the temperature and the quantity of water, the energy consumption and the programme duration.
3) This programme has a high temperature rinsing phase for better hygiene results. During the rinsing
phase, the temperature stays at 70 °C for at least 10 minutes.
4) With this programme you can wash a load with fresh soil. It gives good washing results in a short time.
5) With this programme you can quickly rinse dishes to prevent remains of food to bond on dishes and
odours to form in the appliance. Do not use detergent with this programme.
6) This is the most silent programme. The pump works at a very low speed to decrease the level of noise.
Because of the low speed, the programme duration is long.
www.aeg.com8

5.1 Consumption values
Programme 1) Water
(l)
Energy
(kWh)
Duration
(min)
11.4 0.76 143
7.5 - 12 1.0 - 1.3 99 - 158
12.5 - 14.5 1.4 - 1.7 170 - 190
12 - 14 0.7 - 0.9 82 - 92
10.5 0.9 38
4.0 0.01 14
9.0 - 10 1.1 - 1.3 230 - 250
1) The pressure and the temperature of the water, the variations of the mains supply, the options and the
quantity of dishes can change the values.
5.2 Information for test
institutes
For all the necessary information for test
performance, send an email to:
[email protected]
Write down the product number (PNC)
that is on the rating plate.
6. SETTINGS
6.1 Programme selection
mode and user mode
When the appliance is in programme
selection mode it is possible to set a
programme and to enter the user mode.
Settings available in the user mode:
• The activation or deactivation of the
rinse aid empty notification.
• The level of rinse aid according to the
required dosage.
• The activation or the deactivation of
the option AirDry.
As the appliance stores the saved
settings, there is no need to configure
it before every cycle.
How to set the programme
selection mode
The appliance is in programme selection
mode when the programme indicator
flashes and the display shows the
programme duration.
After activation, the appliance is in
programme selection mode by default. If
not, set the programme selection mode
the following way:
Press and hold simultaneously Delay and
Option until the appliance is in
programme selection mode.
How to enter user mode
Make sure the appliance is in
programme selection mode.
To enter user mode, press and hold
simultaneously Delay and Option until
the indicators , and
flash and the display is blank.
ENGLISH 9

6.2 The rinse aid empty
notification
The rinse aid helps to dry the dishes
without streaks and stains.
The rinse aid is automatically released
during the hot rinse phase.
When rinse aid chamber is empty, the
rinse aid indicator is turned on notifying
to refill rinse aid. If the drying results are
satisfactory while using multi-tablets
only, it is possible to deactivate the
notification for refilling rinse aid.
However, for best drying performance,
always use rinse aid.
If standard detergent or multi-tablets
without rinse aid are used, activate the
notification to keep the rinse aid refill
indicator active.
How to deactivate the rinse
aid empty notification
Make sure the appliance is in user mode.
1. Press Program.
• The indicators and
are off.
•The indicator still flashes.
• The display shows the current
setting.
– = the rinse aid empty
notification is deactivated.
–= the rinse aid empty
notification is activated.
2. Press Program to change the setting.
3. Press on/off to confirm the setting.
6.3 The rinse aid level
It is possible to set the released quantity
of rinse aid between level 1 (minimum
quantity) and level 6 (maximum quantity).
Level 0 deactivates the rinse aid
dispenser and no rinse aid is released.
Factory setting: level 4.
How to set the rinse aid level
Make sure the appliance is in user mode.
1. Press Start.
• The indicators and are
off.
• The indicator still
flashes.
• The display shows the current
setting: e.g. = level 4.
– The levels of rinse aid range
are from 0A to 6A where level
0A means no rinse aid is used.
2. Press Start repeatedly to change the
setting.
3. Press on/off to confirm the setting.
6.4 AirDry
AirDry improves the drying results with
less energy consumption.
During the drying phase, the
door opens automatically
and remains ajar.
CAUTION!
Do not try to close the
appliance door within 2
minutes after automatic
opening. This can cause
damage to the appliance.
If, afterwards, the door is
closed for another 3
minutes, the running
programme ends.
AirDry is automatically activated with all
programmes excluding (if
applicable).
To improve the drying performance refer
to the XtraDry option or activate AirDry.
www.aeg.com
10
