AEG A92860GNX3 User manual

EN User Manual 2
Freezer
FI Käyttöohje 21
Pakastin
SV Bruksanvisning 40
Frysskåp
A92860GNX3
A92860GNB3

CONTENTS
1. SAFETY INFORMATION...........................................................................................3
2. SAFETY INSTRUCTIONS.......................................................................................... 4
3. OPERATION.............................................................................................................. 6
4. DAILY USE..................................................................................................................8
5. HINTS AND TIPS..................................................................................................... 11
6. CARE AND CLEANING.......................................................................................... 11
7. TROUBLESHOOTING.............................................................................................13
8. INSTALLATION....................................................................................................... 16
9. NOISES.................................................................................................................... 18
10. TECHNICAL INFORMATION...............................................................................19
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.aeg.com
2

1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible if an incorrect
installation and use causes injuries and damages. Always
keep the instructions with the appliance for future
reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Cleaning and user maintenance shall not be made by
children without supervision.
•Keep all packaging away from children.
1.2 General Safety
•This appliance is intended to be used in household
and similar applications such as:
–Farm houses; staff kitchen areas in shops, offices
and other working environments
–By clients in hotels, motels, bed and breakfast and
other residential type environments
•Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
•Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
•Do not damage the refrigerant circuit.
•Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
ENGLISH 3

•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
•Do not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
•If the appliance is equipped with an Ice maker or a
water dispenser, fill them with potable water only.
•If the appliance requires a water connection, connect
it to potable water supply only.
•The inlet water pressure (minimum and maximum)
must be between 1 bar (0,1 MPa) and 10 bar (1 MPa)
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Make sure the air can circulate around
the appliance.
• Wait at least 4 hours before
connecting the appliance to the
power supply. This is to allow the oil
to flow back in the compressor.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where
there is direct sunlight.
• Do not install this appliance in areas
that are too humid or too colds, such
as the construction appendices,
garages or wine cellars.
• When you move the appliance, lift it
by the front edge to avoid scratching
the floor.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the electrical components (e.g. mains
plug, mains cable, compressor).
Contact the Service or an electrician
to change the electrical components.
• The mains cable must stay below the
level of the mains plug.
www.aeg.com
4

• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
2.3 Use
WARNING!
Risk of injury, burns,
electrical shock or fire.
• Do not change the specification of
this appliance.
• Do not put electrical appliances (e.g.
ice cream makers) in the appliance
unless they are stated applicable by
the manufacturer.
• Be careful not to cause damage to
the refrigerant circuit. It contains
isobutane (R600a), a natural gas with a
high level of environmental
compatibility. This gas is flammable.
• If damage occurs to the refrigerant
circuit, make sure that there are no
flames and sources of ignition in the
room. Ventilate the room.
• Do not let hot items to touch the
plastic parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create
pressure on the drink container.
• Do not store flammable gas and
liquid in the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from
the freezer compartment if your hands
are wet or damp.
• Do not freeze again food that has
been thawed.
• Obey the storage instructions on the
packaging of frozen food.
2.4 Care and cleaning
WARNING!
Risk of injury or damage to
the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• This appliance contains hydrocarbons
in the cooling unit. Only a qualified
person must do the maintenance and
the recharging of the unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If
the drain is blocked, defrosted water
collects in the bottom of the
appliance.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door to prevent children
and pets to be closed inside of the
appliance.
• The refrigerant circuit and the
insulation materials of this appliance
are ozone-friendly.
• The insulation foam contains
flammable gas. Contact your
municipal authority for information on
how to discard the appliance
correctly.
• Do not cause damage to the part of
the cooling unit that is near the heat
exchanger.
ENGLISH 5

3. OPERATION
3.1 Control panel
1 2
3
4
5
6
10
11
9
7
8
1Temperature button
2Display
3ON/OFF button
4Minute minder button
5Light button
6Night mode button
7Ice maker ON/OFF button
8Dispenser lever
9Rapid ice button
10 Child lock button
11 Mode button
It is possible to change predefined
sound of buttons to a loudly one by
pressing together Mode button and
Temperature button for some seconds.
Change is reversible.
3.2 Display
A B C D
EFGH
A. Timer
B. FROSTMATIC function
C. Minute minder function
D. Temperature indicator
E. Night mode
F. Alarm indicator
G. Ice maker function
H. Child Lock function
www.aeg.com6

3.3 Switching on
1. Connect the mains plug to the power
socket.
2. Press the ON/OFF if the display is
off.
The alarm buzzer could operate after
few seconds.
To reset the alarm refer to "High
temperature alarm".
If DEMO appears on the display, the
appliance is in demonstration mode.
Refer to "What to do if..." paragraph.
The temperature indicators show the set
default temperature.
To select a different set
temperature refer to
"Temperature regulation".
3.4 Switching off
Press ON/OFF for 3 seconds.
The display switches off.
To disconnect the appliance
from the power disconnect
the mains plug from the
power socket.
3.5 Temperature regulation
The set temperature of the freezer may
be adjusted by pressing the temperature
button.
Default temperature:
• -18°C for the freezer
The temperature indicator shows the set
temperature.
The set temperature will be
reached within 24 hours.
After a power failure the set
temperature remains stored.
3.6 Ice maker function
The ice maker is switched on at delivery
and starts up automatically when the
appliance is connected to water and
power supplies.
To switch on and off the function press
the ice maker ON/OFF for 3 seconds.
The ice maker icon is shown when the ice
maker is activated.
The ice maker icon is
flashing when the ice
container is out of position.
For further details please
refer to "Troubleshooting"
chapter.
3.7 ChildLock function
To lock any possible operation through
the buttons select the ChildLock
function.
1. To switch on the function press
ChildLock for 3 seconds.
The ChildLock indicator is shown.
2. To switch off the function press
ChildLock for 3 seconds.
The ChildLock indicator goes off.
3.8 FROSTMATIC function
Press the Mode button until the
FROSTMATIC icon appears.
This function stops automatically after 52
hours. To switch off the function before
its automatic end, press the Mode
button in order to select another
function or press the Mode button until
you can see none of the special icons.
The function switches off by
selecting a different freezer
set temperature.
3.9 Minute Minder function
The Minute Minder function is to be used
to set an acoustic alarm at the preferred
time, useful for example when a recipe
requires to cool down a mixture for a
certain period of time, or when a
reminder is needed in order not to forget
bottles placed in the freezer for fast
cooling.
1. Press the Minute Minder button.
The Minute Minder indicator appears.
The Timer shows the set value (30
minutes).
2. Press the Temperature button to
change the Timer set value from 1 to
90 minutes.
The Timer indicator is shown (min).
At the end of the countdown the Minute
Minder indicator flashes and an audible
ENGLISH 7

alarm sounds. At that time, remove any
drinks contained in the freezer
compartment, and press the Minute
Minder button to switch off the sound
and terminate the function.
To change the time during the
countdown or at the end, press the
Temperature button.
To deactivate the function at any time
during the countdown, repeat the
procedure until the Minute Minder icon
turns off.
3.10 High temperature alarm
Temperature increase in the freezer
compartment (for example due to an
earlier power failure or door is open) is
indicated by:
• flashing the alarm and freezer
temperature indicators;
• sounding of buzzer.
Press any button.
The buzzer switches off.
The freezer temperature indicator shows
the highest temperature reached for a
few seconds. Then show again the set
temperature.
The alarm indicator continue to flash
until the normal conditions are restored.
3.11 Door open alarm
An acoustic alarm will sound if the door
is left open for a few minutes. The door
open alarm conditions are indicated by:
• a flashing alarm indicator;
• an acoustic buzzer.
When normal conditions are restored
(door closed), the alarm will stop.
During the alarm phase, the buzzer can
be switched off by pressing any control
panel button.
3.12 Lighting
The ice dispenser lighting illuminates
automatically when operated.
3.13 For continuous lighting
Make sure that the ice dispenser is
unlocked.
Press the Light button and the lighting
goes on.
Brightness is now about 20% until the
dispenser is used.
3.14 Switch off the lighting
Make sure that the ice dispenser is
unlocked.
Press the light button and the lighting
goes out.
3.15 Night mode
This function is used to terminate the
icemaking during the darker period of
the day.
To switch on or off the night mode press
the night mode button.
The night mode icon is shown when the
night mode is activated.
3.16 Dispensing of ice
The dispensing of ice starts when the
dispenser lever is fully depressed and
continues until the lever is released.
Stop delivery by removing the container
from the dispenser lever.
3.17 Rapid dispensing of ice
If increased ice dispensing is desired
press the rapid ice button and hold it
and then push the dispenser lever.
4. DAILY USE
WARNING!
Refer to Safety chapters.
4.1 Freezing fresh food
The freezer compartment is suitable for
freezing fresh food and storing frozen
and deep-frozen food for a long time.
www.aeg.com8

To freeze small amount of fresh foods it
is not necessary to change the present
setting.
To freeze fresh food activate the
FROSTMATIC function at least 24 hours
before placing the food to be frozen in
the freezer compartment.
Place the fresh food to be frozen in all
compartments except the lowest one.
The maximum amount of food that can
be frozen in 24 hours is specified on the
rating plate, a label located on the inside
of the appliance.
The freezing process lasts 24 hours:
during this period do not add other food
to be frozen.
When the freezing process is completed,
return to the required temperature (see
"FROSTMATIC Function").
4.2 Storage of frozen food
When first starting-up or after a period
out of use, let the appliance run at least 2
hours before putting products in the
freezer compartment.
The freezer baskets ensure that it is quick
and easy to find the food packages you
want. If large quantities of food are to be
stored, remove all drawers except for the
bottom basket which secures good air
circulation.
It is possible to place food that protrudes
15 mm from the door on all shelves
except the top one.
In the event of accidental
defrosting, for example due
to a power failure, if the
power has been off for
longer that the value shown
in the technical
characteristics chart under
"rising time", the defrosted
food must be consumed
quickly or cooked
immediately and then re-
frozen (after cooling).
4.3 Thawing
Deep-frozen or frozen food, prior to
being used, can be thawed in the
refrigerator compartment or at room
temperature, depending on the time
available for this operation.
Small pieces may even be cooked still
frozen, directly from the freezer: in this
case, cooking will take longer.
4.4 Removing the ice container
The ice container can be removed.
1. Tilt up and pull the ice container
outwards to removal.
When the ice container is pulled out,
this stops all the functions of the ice
machine.
2. When refitting (if necessary) the ice
container feed screw should be
positioned against the rear flange.
1
2
4.5 Shelf above ice maker
CAUTION!
The shelf above the ice
maker cannot be removed.
ENGLISH 9

4.6 Removal of freezing
baskets and glass shelves from
the freezer
The freezing baskets have a limit stop to
prevent their accidental removal or
falling out. At the time of its removal
from the freezer, pull the basket towards
yourself and, upon reaching the end
point, remove the basket by tilting its
front upwards.
2
1
At the time of putting it back, slightly lift
the front of the basket to insert it into the
freezer. Once you are over the end
points, push the baskets back in their
position.
The appliance is equipped with shelf
stops to secure the shelves.
The shelves must be lifted up (1) on each
side and then pulled outwards (2).
1
1
2
The glass shelves equipped with
expander rollers are secured with locking
pins.
To remove them, loose the locking pin
on each side on the expander roller. If
necessary, use a screwdriver.
Afterwards pull out both locking pins (1)
and pull the glass shelf outwards (2).
2
1
1
1
4.7 Cleaning the interior
1. Before using the appliance for the
first time, wash the interior and all
internal accessories with lukewarm
water and neutral soap so as to
remove the typical smell of a brand-
new product, then dry thoroughly.
2. Check that the drain hose at the rear
of the cabinet discharges into the
drip tray.
CAUTION!
Do not use detergents or
abrasive powders, as these
will damage the finish.
www.aeg.com10

5. HINTS AND TIPS
5.1 Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound
from coils sound when refrigerant is
pumped.
• A whirring and pulsating sound from
the compressor when refrigerant is
pumped.
• A sudden cracking noise from inside
appliance caused by thermic
dilatation (a natural and not
dangerous physical phenomenon).
• A faint click noise from the
temperature regulator when the
compressor switches on or off.
5.2 Hints for energy saving
• Do not open the door frequently or
leave it open longer than absolutely
necessary.
• If foreseen, do not remove the cold
accumulators from the freezer basket.
5.3 Hints for freezing
To help you make the most of the
freezing process, here are some
important hints:
• the maximum quantity of food which
can be frozen in 24 hrs. is shown on
the rating plate;
• the freezing process takes 24 hours.
No further food to be frozen should
be added during this period;
• freeze only top quality, fresh and
thoroughly cleaned, foodstuffs;
• prepare food in small portions to
enable it to be rapidly and completely
frozen and to make it possible
subsequently to thaw only the
quantity required;
• wrap up the food in aluminium foil or
polythene and make sure that the
packages are airtight;
• do not allow fresh, unfrozen food to
touch food which is already frozen,
thus avoiding a rise in temperature of
the latter;
• lean foods store better and longer
than fatty ones; salt reduces the
storage life of food;
• water ices, if consumed immediately
after removal from the freezer
compartment, can possibly cause the
skin to be freeze burnt;
• it is advisable to show the freezing in
date on each individual pack to
enable you to keep tab of the storage
time.
5.4 Hints for storage of frozen
food
To obtain the best performance from this
appliance, you should:
• make sure that the commercially
frozen foodstuffs were adequately
stored by the retailer;
• be sure that frozen foodstuffs are
transferred from the foodstore to the
freezer in the shortest possible time;
• not open the door frequently or leave
it open longer than absolutely
necessary;
• once defrosted, food deteriorates
rapidly and cannot be refrozen;
• do not exceed the storage period
indicated by the food manufacturer.
6. CARE AND CLEANING
WARNING!
Refer to Safety chapters.
6.1 General warnings
CAUTION!
Unplug the appliance before
carrying out any
maintenance operation.
ENGLISH 11

This appliance contains
hydrocarbons in its cooling
unit; maintenance and
recharging must therefore
only be carried out by
authorized technicians.
The accessories and parts of
the appliance are not
suitable for washing in a
dishwasher.
6.2 Periodic cleaning
CAUTION!
Do not pull, move or
damage any pipes and/or
cables inside the cabinet.
CAUTION!
Take care of not to damage
the cooling system.
CAUTION!
When moving the cabinet,
lift it by the front edge to
avoid scratching the floor.
The equipment has to be cleaned
regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral
soap.
2. Regularly check the door seals and
wipe clean to ensure they are clean
and free from debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser
and the compressor at the back of
the appliance with a brush.
This operation will improve the
performance of the appliance and
save electricity consumption.
6.3 Cleaning the ice maker
When necessary, clean the surfaces of
the dispenser and the ice container that
are accessible from the outside, using
only a soft cloth and warm water.
Ensure that the ice container is
thoroughly dry before being refitted.
CAUTION!
Do not use detergents or
abrasive paste.
6.4 Defrosting the freezer
The freezer compartment is frost free.
This means that there is no build up of
frost when it is in operation, neither on
the internal walls nor on the foods.
The absence of frost is due to the
continuous circulation of cold air inside
the compartment, driven by an
automatically controlled fan.
6.5 Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Switch off the ice maker.
2. Turn off the water connection.
3. Empty the ice container.
4. Disconnect the appliance from
electricity supply.
5. Remove all food.
6. Clean the appliance and all
accessories.
7. Leave the door/doors open to
prevent unpleasant smells.
When the ice maker starts again, do not
use ice produced during the first day to
ensure fresh taste.
WARNING!
If the cabinet will be kept on,
ask somebody to check it
once in a while to prevent
the food inside from spoiling
in case of a power failure.
6.6 Cleaning the ventilation
grille
Make sure the door is open.
The ventilation grille can be removed for
washing.
1. Loosen the edge of the grille by
pulling it according to the figure.
www.aeg.com
12

2. Pull the grille straight out to
completely remove it.
3. Vacuum clean under the cabinet.
7. TROUBLESHOOTING
WARNING!
Refer to Safety chapters.
7.1 What to do if...
Problem Possible cause Solution
The appliance does not op-
erate.
The appliance is switched
off.
Switch on the appliance.
The mains plug is not con-
nected to the mains socket
correctly.
Connect the mains plug to the
mains socket correctly.
There is no voltage in the
mains socket.
Connect a different electrical
appliance to the mains socket.
Contact a qualified electrician.
The appliance is noisy. The appliance is not sup-
ported properly.
Check if the appliance stands
stable.
Audible or visual alarm is on. The cabinet has been re-
cently switched on or the
temperature is still too
high.
Refer to "Door Open Alarm"or
"High Temperature Alarm".
The temperature in the ap-
pliance is too high.
Refer to "Door Open Alarm"or
"High Temperature Alarm".
The door is left open. Close the door.
The temperature in the ap-
pliance is too high.
Contact a qualified electrician
or contact the nearest Author-
ised Service Centre.
A rectangular symbol is
shown instead of numbers
on the Temperature Display.
Temperature sensor prob-
lem.
Contact the nearest Author-
ised Service Centre (the cool-
ing system will continue to
keep food products cold, but
temperature adjustment will
not be possible).
The lamp does not work. The lamp is in stand-by. Close and open the door.
ENGLISH 13

Problem Possible cause Solution
The lamp does not work. The lamp is defective. Contact the nearest Author-
ised Service Centre.
The compressor operates
continually.
Temperature is set incor-
rectly.
Refer to "Operation" chapter.
Many food products were
put in at the same time.
Wait some hours and then
check the temperature again.
The room temperature is
too high.
Refer to climate class chart on
the rating plate.
Food products placed in
the appliance were too
warm.
Allow food products to cool to
room temperature before stor-
ing.
The door is not closed cor-
rectly.
Refer to "Closing the door".
The FROSTMATIC function
is switched on.
Refer to "FROSTMATIC func-
tion".
There is too much frost and
ice.
The door is not closed cor-
rectly or the gasket is de-
formed/dirty.
Refer to "Closing the door".
The compressor does not
start immediately after
pressing the FROSTMATIC,
or after changing the tem-
perature.
This is normal, no error has
occurred.
The compressor starts after a
period of time.
Water flows on the floor. The melting water outlet is
not connected to the
evaporative tray above the
compressor.
Attach the melting water out-
let to the evaporative tray.
Temperature cannot be set. The FROSTMATIC or
COOLMATIC function is
switched on.
Switch off FROSTMATIC or
COOLMATIC manually, or wait
until the function resets auto-
matically to set the tempera-
ture. Refer to "FROSTMATIC
or COOLMATIC function".
There is no ice production. The ice maker is not
switched on.
Refer to "Switching on and off
the ice maker".
DEMO appears on the dis-
play.
The appliance is in demon-
stration mode.
Keep the Mode pressed for
approximately 10 seconds un-
til a long sound is heard and
display shuts off for a short
time.
www.aeg.com14

Problem Possible cause Solution
Door is misaligned or inter-
feres with ventilation grill.
The appliance is not level-
led.
Refer to "Levelling".
The temperature in the ap-
pliance is too low/too high.
The temperature regulator
is not set correctly.
Set a higher/lower tempera-
ture.
The food products' tem-
perature is too high.
Let the food products temper-
ature decrease to room tem-
perature before storage.
The door has been
opened often.
Open the door only if necessa-
ry.
The FROSTMATIC function
is switched on.
Refer to "FROSTMATIC func-
tion".
There is no cold air circula-
tion in the appliance.
Make sure that there is cold air
circulation in the appliance.
E1 is flashing the tempera-
ture display.
No water supply. Carry out the necessary meas-
ures on the water supply. Press
any button to reset the Alarm.
E 2 is flashing in the temper-
ature display.
The ice channel in the
door is blocked.
Remove the obstacle. Press
any button to reset the Alarm.
E 3 or E 5 is flashing in the
temperature display.
The ice maker is defective. Contact the nearest Author-
ised Service Centre.
Ice maker icon is flashing. The ice container is in in-
correct position.
Remove the ice container and
place it correctly. Refer to "Re-
moving the ice container".
A rattling noise. The ice being stirred to
prevent it from freezing to-
gether.
No measure necessary, this
sound is normal. As an alterna-
tive, refer to "To activate the
night mode".
If the advice does not lead
to the desired result, contact
the nearest Authorised
Service Centre.
7.2 Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to
"Installation".
3. If necessary, replace the defective
door gaskets. Contact the Authorised
Service Centre.
7.3 Replacing the lamp
The appliance is equipped with a longlife
LED interior light.
Only service is allowed to replace the
lighting device. Contact your Authorised
Service Centre.
ENGLISH 15

8. INSTALLATION
WARNING!
Refer to Safety chapters.
8.1 Positioning
This appliance can be installed in a dry,
well ventilated indoor where the ambient
temperature corresponds to the climate
class indicated on the rating plate of the
appliance:
Climate
class
Ambient temperature
SN +10°C to + 32°C
N +16°C to + 32°C
ST +16°C to + 38°C
T +16°C to + 43°C
Some functional problems
might occur for some types
of models when operating
outside of that range. The
correct operation can only
be guaranteed within the
specified temperature
range. If you have any
doubts regarding where to
install the appliance, please
turn to the vendor, to our
customer service or to the
nearest Service Centre
8.2 Location
To ensure best performance, if the
appliance is positioned below an
overhanging wall unit, the minimum
distance between the top of the cabinet
and the wall unit must be at least 40 mm.
Ideally, however, the appliance should
not be positioned below overhanging
wall units.
The ventilation space can be:
• directly above the appliance
• behind and above the top cupboard.
In this case, the space behind the top
cupboard must be at least 50 mm
deep.
50 mm
8.3 Electrical connection
• Before plugging in, ensure that the
voltage and frequency shown on the
rating plate correspond to your
domestic power supply.
• The appliance must be earthed. The
power supply cable plug is provided
with a contact for this purpose. If the
domestic power supply socket is not
earthed, connect the appliance to a
separate earth in compliance with
current regulations, consulting a
qualified electrician.
• The manufacturer declines all
responsibility if the above safety
precautions are not observed.
• This appliance complies with the
E.E.C. Directives.
8.4 Removing the transport
support
Your appliance is equipped with
transport support to secure the door
during transportation.
1. Open the door.
2. Remove the transport support from
the door sides.
3. Remove the transport support from
the lower hinge (some models).
www.aeg.com
16

CAUTION!
Some models are fitted with
a silencing pad under the
cabinet. Do not remove this
pad.
2
3
8.5 Rear spacers
Install the two spacers and the locking
pins provided within the accessory bag
as shown in the figure.
8.6 Connecting the water hose
WARNING!
Always use a safety valve in
the water connection.
Water supply should be provided with a
tap and 3/4" male connector within 1,5 m
from the appliance.
This work is to be carried out by a skilled
plumber.
There are different type-approved taps
and tap assemblies on the market.
The water hose must not be cracked,
squeezed or put in tight bends.
If the appliance has been purchased
together with the corresponding fridge
the installation should be conducted in
such a way that both appliances share
the safety valve supplied with the fridge.
If this appliance has been purchased as a
single installation or together with an
appliance without water connection, a
safety valve (1504516-00/4) must be
installed. This item can be ordered via
www.electrolux.com
Before the appliance is placed in final
location, ensure that the water
connection has been correctly carried
out and that there is no leakage at the
connection to the water tap.
Tighten the screw enough by hand.
Make sure that the gasket is properly
positioned in the connector.
We recommend that the appliance is
placed on a "run-off" mat intended for
refrigerators and freezers, which makes it
easier to detect possible leakage.
8.7 Levelling
When placing the appliance ensure that
it stands level. If necessary adjust the feet
using the adjustment spanner supplied.
Door alignment is dependent on proper
levelling.
8.8 Starting the ice maker for
the first time
Ensure proper connection to the water
supply, refer to "Connecting the water
hose".
It will start filling water when the
temperature is sufficiently low.
ENGLISH 17

1. Open the tap on the water
connection.
2. Start the freezer.
The ice maker starts automatically.
Do not use ice produced
during the first day to ensure
fresh taste.
8.9 Door reversibility
In case you want to change the opening
direction of the door, contact the nearest
Authorised Service Centre. The
Authorised Service specialist will carry
out the reversibility of the doors at your
cost.
9. NOISES
There are some sounds during normal running (compressor, refrigerant circulation).
BRRR!
HISSS!
CLICK!
BLUBB!
CRACK!
SSSRRR!
OK
CLICK! CLICK!
SSSRRR! SSSRRR!
BRRR! BRRR!
HISSS! HISSS!
www.aeg.com18

BLUBB! BLUBB! CRACK!CRACK!
10. TECHNICAL INFORMATION
10.1 Technical data
Height mm 1800
Width mm 595
Depth mm 650
Rising time Hours 10
Voltage Volts 230 - 240
Frequency Hz 50
The technical information are situated in
the rating plate, on the external or
internal side of the appliance and in the
energy label.
10.2 Water pressure range
Water pressure range
The water pressure must be at least 1 bar (100kPa) Consult your installer if water pres-
sure is less than 1 bar.
Highest allowed water pressure 10 bar (1000kPa) If water pressure exceeds 10 bar a re-
duction valve must be fitted (availa-
ble from your specialist shop).
ENGLISH 19

CAUTION!
• Do not connect the
appliance in spaces
where ambient
temperature can
decrease to below
freezing.
• The appliance may only
be connected to drinking
water supplies.
• The appliance may only
be connected to cold
water supplies.
11. ENVIRONMENTAL CONCERNS
Recycle the materials with the symbol .
Put the packaging in applicable
containers to recycle it. Help protect the
environment and human health and to
recycle waste of electrical and electronic
appliances. Do not dispose appliances
marked with the symbol with the
household waste. Return the product to
your local recycling facility or contact
your municipal office.
www.aeg.com20
