AEG SANTO C 7 14 40-4i User manual

SANTO C 7 14 40-4i
Integrated Fridge Freezer
Operating and Installation Instructions
AEG
55-77 High Street
SLOUGH
Berks
SL1 1DZ
http://www.aeg.c .uk
2222 307-41 12/03

2
Dear customer,
Before s itching on your ne refrigerator/freezer please read these opera-
ting instructions carefully. They contain important information for safe use,
for installation and for care of the appliance.
Please keep these operating instructions for future reference. Pass them on
to possible ne o ners of the appliance.
These operating instructions are for use ith several technically comparable
models ith varying accessories. Please observe the notes hich apply to
your model.
Notes hich are important for your safety or for the proper functioning of
the appliance are stressed ith a arning triangle and/or ith signal ords
(Warning!, Important!, Attention!). Please observe the follo ing instructions
carefully.
Additional information regarding operation and practical applications of
the appliance appear after this symbol.
Tips and notes concerning economical and environmentally sound use of
the appliance are marked ith the flo er.
In the event of a malfunction, these operating instructions contain infor-
mation on ho to rectify faults yourself, see the “Something Not Working”
section.
For futher assistance contact your local AEG Service Force Centre, see the
chapter “Service and Spare Parts”.
Printed on paper manufactured ith environmentally sound processes.
ho thinks ecologically acts accordingly ...

3
Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Appliance Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Disposal of Old Appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Remove Transport Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Shelf holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Description of the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Starting Up and Temperature Regulation . . . . . . . . . . . . . . . . . . . . . . .7
Lo room temperature s itch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Interior Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Storage shelves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Variable inner door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Fresh Food Refrigeration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Free ing and Storing Fro en Food . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Ice Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Preparation of Ice Cubes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Storage Goods Symbols/ Free ing Calendar . . . . . . . . . . . . . . . . . . . .11
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Switching Off the Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Energy Saving Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Something Not Working . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Changing the light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Service and Spare Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Guarantee Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Your appliance needs air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Reversing the door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Housing dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Instructions for building-in . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Regulations, Standards, Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

4
Safety
Please read this instruction book before using the appliance and retain for
future reference. These arnings are provided in the interests of your safe-
ty, ensure you understand them fully before using the appliance.
Intended use
• The appliance is intended for use in the home. It is suitable for the coo-
ling, freezing and storing of frozen food, as ell as for making ice. If the
appliance is used for purposes other than those intended or used incor-
rectly, no liability can be accepted by the manufacturer for any damage
that may be caused.
• Alterations or changes to the appliance are not permitted for reasons of
safety.
Prior to initial start–up
• Check the appliance for transport damage. Under no circumstance should
a damaged appliance be plugged in! In the event of damage, please con-
tact your retailer.
Refrigerant
The refrigerant isobutane (R600a) is contained ithin the refrigerant circuit
of the appliance, a natural gas ith a high level of environmental compat-
ibility, hich is nevertheless flammable.
• During transportation and installation of the appliance, be certain that
none of the components of the refrigerant circuit become damaged.
• If the refrigerant circuit should become damaged:
– avoid open flames and sources of ignition;
– thoroughly ventilate the room in hich the appliance is situated.
Safety of children
• Keep packaging material a ay from children.
• Please make old appliances unusable prior to disposal. Pull out the mains
plug, cut off the mains cable and remove any locks or catches, to prevent
young children being trapped inside.
• Do not allo children to tamper ith the controls or play ith the pro-
duct.
25
PR168
At the end of installation/adjusting, it
is necessary to check if the door of
the furniture closes properly.
Should adjustment of the furniture
door be necessary, use the clearance
of slots.
Regulations, Standards, Guidelines
This appliance as designed for household use and as manufactured in
accordance ith the appropriate standards. The necessary measures in
accordance ith appliance safety legislation regulations (GSG), accident
prevention regulations for refrigeration appliances (VBG 20) and the regu-
lations of the German Society of Electrical Engineers (VDE) ere observed in
the manufacture of this appliance.
The refrigerant circuit has been checked for leaks.
This appliance is in accordance ith the follo ing EU guidelines:
– 73/23/EWG dated 19 February 1973 - lo voltage guidelines.
– 89/336/EWG dated 3 May 1989
(including guideline change notice 92/31/EWG) - EMV guideline
PR167/1
D
B
Fix cover (D) on guide (B) until it clips
into place.

5
Daily Operation
• Do not operate any electrical appliances in the refrigerator/freezer (e.g.
electric ice cream makers, mixers etc.).
• Before cleaning the appliance, al ays s itch off the appliance and
disconnect from the electricity supply.
• When unplugging al ays pull the plug from the mains socket, do not pull
on the cable.
Service
• Under no circumstances should you attempt to repair the appliance your-
self. Repairs carried out by inexperienced persons may cause injury or
serious malfunctioning. Contact your local AEG Service Force Centre.
Disposal
Appliance Packaging Information
All materials are environmentally sound.
The plastics can be recycled and are identified as follo s:
>PE< for polyethylene, e.g. the outer covering and the bags in the interior.
>PS< for polystyrene foam, e.g. the pads, hich are all free of chlorofluo-
rocarbon.
The carton parts are made from recycled paper and should be disposed of
at a aste-paper recycling collection location.
Disposal of Old Appliances
For environmental reasons, refrigeration appliances must be disposed of
properly. This applies to your old appliance, and - at the end of its service
life - to your ne appliance as ell.
Warning! Before disposing of old appliances make them inoperable.
Remove plug from mains, sever the po er cable, remove or destroy any
snap or latch closures, to prevent small children being trapped inside.
• Use an authorised disposal site.
Contact your Local Council or Environmental Health Office to see if there
are facilities in your area to recycle the appliance.
24
Open the appliance door and the fur-
niture door at 90°. Insert the small
square (B) into guide (A). Put togeth-
er the appliance door and the furni-
ture door and mark the holes as indi-
cated in the figure. Remove the
squares and drill holes ith ø 2 mm
at 8 mm from the outer edge of the
door. Place the small square on the
guide again and fix it ith the scre s
supplied.
8mm
PR167
A
B
PR33
C
A
Fix cover (C) on guide (A) until it clips
into place.
Place guide (A) on the inside part of
the furniture door, in the upper and
lo er positions as sho n in the fig-
ure and mark the position of external
holes. Having drilled the holes, fix the
guide ith the scre s supplied.
20 mm
A
50mm
PR166

6
Remove Transport Packaging
The appliance and the interior fittings are protected for transport.
• Remove all adhesive tape and packing pieces from the interior of the
appliance.
S elf olders
Your appliance is equipped ith shelf
retainers that make it possible to
secure the shelves during transporta-
tion.
To remove them proceed as follo s:
Raise the shelf from the back, push it
in the direction of the arro until it
is freed and remove the retainers.
Description of t e Appliance
A - Dairy compartment
B - Can storage shelves
C - Bottle storage shelf
D - Thermostat control
E - Glass shelves
F - Glass shelf
G - Salad dra ers
H - Compartment for
storing frozen food
I - Compartment for
freezing fresh food
A
B
C
D
E
F
G
I
H
B
A
23
D726
B
Apply covers (B) into the relevant
holes.
Separate parts A, B, C, D as sho n in
the figure
PR266
AB
C
D
D
C
D723
Open the door and push the appliance
against the side of the kitchen unit op-
posite to that of appliance hinges.
Fasten the appliance ith 4 scre s
provided in the kit included ith the
appliance. Snap ventilation grille (C)
and hinge cover (D) into position.

7
Starting Up and Temperature Regulation
Wash the inside of the appliance ith luke arm ater ith a little bicar-
bonate of soda added (5ml to 0,5 litre of ater). Do not use soap or deter-
gent as the smell may linger. Dry the appliance thoroughly.
• When the refrigerator compartment door is opened, the internal lighting
is s itched on. The temperature control knob is located on the right hand
side of the refrigerator compartment.
Setting “0”: Off.
Setting “1”: Highest temperature, ( armest setting).
Setting “6” (end-stop) : Lo est temperature, (coldest setting).
The exact setting should be chosen keeping in mind that the temperature
inside the refrigerator depends on:
-the quantity of food stored
-ho often the door is opened
The temperatures in the refrigerator compartment and freezer compart-
ment cannot be independently regulated.
If you ant to freeze fresh food rapidly, select setting “6”, ensuring that the
temperature in the refrigerator compartment does not drop belo 0°C. You
should reset the temperature control knob to setting “3” or “4”, if this does
occur.
As soon as the fresh food placed in the freezer has frozen, return the tem-
perature control knob to “3” or “4”.
Important!
High ambient temperatures (e.g. on hot summer days) and a cold setting on
the temperature regulator (position"5" to "6") can cause the compressor to
run continuously.
If this happens, turn the temperature regulator back to a armer setting
(position "3" to "4"). At this setting the compressor ill be s itched on and
off as usual and automatic defrosting recommenced.
22
A
D023
Push appliance into the housing
until stop strip (A) touches the
kitchen unit.
Instructions for building-in
D765
Apply joint the sealing strip as sho n
in figure.
For a correct alignment make sure that
the distance bet een the appliance and
the cabinet is of 44 mm.
44 mm

8
Low Room Temperature Switch
When the room temperature is +
16° C or less, the Lo Room
Temperature S itch, located next
to the thermostat control knob,
must be s itched on to maintain
the correct temperatures inside
the fridge and freezer compart-
ments.
Please note that in this setting
the interior light ill remain on,
even if the door is closed.
No damage can be caused by leaving the s itch in this position for
any period of time (see page 15 Lo ambient operation). Ho ever
should the temperature rise above 16°C remember to turn the s itch
off again.
Interior Accessories
Storage s elves
The glass shelf above the fruit and
vegetable compartment should
al ays remain in position, to ensure
fruit and vegetables stay fresh longer.
The remaining storage shelves can be
adjusted to various heights:
Pull the storage shelf for ard until it
can be tipped up or do n and remo-
ved.
To insert at a different height use the same procedure in reverse.
Adjustment for tall goods:
Remove the front half of the t o-part vario glass storage shelf and insert it
at a different level. Space is thus gained for storage of tall goods on the
underlying storage shelf.
Variable inner door
The door compartments can be pulled up and removed, and inserted at
other positions as needed.
D338
D710
A
21
Housing Dimensions
Height 1446 mm
Depth 550 mm
Width 560 mm
1. Unscre the upper pin and remove
the spacer
2. Remove the upper door
3. Unscre the middle hinge and the
plugs and refit them on the opposite
side
4. Refit the upper door, the upper pin
and the spacer on the opposite side
5. Unscre the lo er pin and remove
the spacer and refit them on the
opposite side.

9
Fres Food Refrigeration
To obtain the best performance:
• do not store arm food or evaporating liquid in the refrigeator
• do cover or rap the food, particularly if it has a strong flavour.
• position food so that air can circuiate freely round it.
Useful hints:
Meat (all types): rap in polythene bags and place on the glass shelf above
the vegetable dra er(s)
For safety, store in this way only one or two days at the most.
Cooked foods, cold dishes, etc: these should be covered and may be placed
on any shelf.
Fruit and vegetables: these should be thoroughly cleaned and placed in the
special dra er(s) provided.
Butter and cheese: these should be placed in special airtight containers or
apped in aluminium foil or polythene bags to exclude as much air as pos-
sible.
Milk bottles: these should have a cap and should be stored in the bottle
rack on the door.
Bananas, potatoes, onions and garlic, if not in airtight containers, must
not be kept in the refrigerator.
20
Positioning
This appliance should only be installed at a location here the ambient
temperature corresponds to the climate classification indicated on the rat-
ing plate, hich is located on the inside left of the appliance.
The follo ing table sho s hich ambient temperature is correct for each
climate classification.
Climate classification for an ambient temperature of
SN +10 to +32 °C
N+16 to +32 °C
Your appliance needs air
For safety reasons, minimum ventila-
tion must be as sho n Fig.
Attention: keep ventilation openings
clear of obstruction;
50 mm
min.
200 cm
2
200 cm
2
min.
D567
Reversing t e door
The side the door opens can be changed from the right side (factory adjust-
ment) to the left side, if the installation site requires.
Warning! When changing the side the door opens, the appliance must not
be connected to the mains. Remove plug from the mains beforehand.
The appliance should be located in a dry atmosphere, out of direct sunlight
and a ay from continuous heat and extreme temperature, e.g. not next to
a boiler or radiator, or in a very cold room e.g. an outhouse. If these tem-
peratures are exceeded i.e. armer or colder, then the appliance may not
operate correctly.
For building-in and door reversal instructions please refer to the relevant
instructions on the follo ing pages.

10
Freezing and Storing Frozen Food
You can use your freezer for freezing fresh food yourself.
Important!
• The temperature in the freezer compartment must be –18 °C or colder
before freezing food.
• Please observe the freezing capacity given on the rating plate. The free-
zing capacity is the maximum quantity of fresh food that can be frozen
ithin a period of 24 hours. If you ish to freeze food several days in a
ro , please observe a maximum capacity of only 2/3 to 3/4 of that on the
rating plate. The quality of the food is best preserved hen it is frozen
right through to the core as quickly as possible.
• Allo arm food to cool do n before freezing. The armth ill cause
increased ice formation and increase the po er consumption.
• Please note the maximum storage times specified by the manufacturer.
• Tha ed foods hich have not been processed further (cooked into meals)
may not under any circumstances be frozen a second time.
• Containers ith flammable gases or liquids can leak at lo temperatures.
There is a risk of an explosion! Do not store any containers ith flamma-
ble materials such as, for example, spray cans, fire extinguisher refill car-
tridges etc in the refrigerator/freezer.
• Bottles and cans must not be placed in the freezer. They can burst hen
the contents freeze, high carbonate content drinks can even explode!
Never store lemonade, juices, beer, ine, sparkling ine etc. in the freezer.
• All foods must be packed air tight prior to freezing, so that they do not
dry out or lose their flavour, and so that no flavour contamination of
other frozen goods occurs.
• Ice cream or ice cubes can cause “frost/freezer” burns if consumed strai-
ght from the freezer.
Important! Do not touch frozen food ith et hands. Your hands could
stick to the food.
1. It is not necessary to adjust the thermostat setting hen freezing fresh food.
Depress the ambient s itch at least 12 hours before loading food to be
frozen.
In any 24 hours you can freeze up to 6 kg. of fresh food.
2. Place the packed food in the dra ers. Place food to be frozen in the bot-
tom dra er. Unfrozen food must not touch items already frozen, other ise
the frozen food could begin to defrost.
3 Place frozen foods in the dra ers sorted by type, as far as possible.
19
Installation
Electrical connection
Any electrical ork required to install this appliance should be carried
out by a qualified electrician or competent person.
WARNING – THIS APPLIANCE MUST BE EARTHED
The manufacturer declines any liability should these safety measures not
be observed.
Before s itching on, make sure the electricity supply voltage is the same as
that indicated on the appliance rating plate. The rating plate is inside, on the
left.
The appliance is supplied ith a 13 amp plug fitted. In the event of having
to change the fuse in the plug supplied, a 13 amp ASTA approved (BS 1362)
fuse must be used.
Important!
The ires in the mains lead are
coloured in accordance ith the fol-
lo ing code:
Green and Yello Earth
Blue Neutral
Bro n Live
As the colours of the ires in the
mains lead of this appliance may not
correspond ith the coloured mark-
ings identifying the terminals in your
plug, proceed as follo s:
1. The ire coloured green and yello must be connected to the terminal
marked ith the letter “E” or by the earth symbol or coloured green and yel-
lo .
2. The ire coloured blue must be connected to the terminal marked “N” or
coloured black.
3. The ire coloured bro n must be connected to the terminal marked “L” or
coloured red.
4. Upon completion there must be no cut, or stray strands of ire present and
the cord clamp must be secure over the outer sheath.
Warning! A cut-off plug inserted into a 13 amp socket is a serious safety
(shock) hazard. Ensure that the cut-off plug is disposed of safely.
D207
GREEN & YELLOW 13 AMP. FUSE
BROWN
CORD CLAMP
BLUE
13 AMP
