AEG SJ-BM585D-SS2 User manual
Home Appliances
Fridge-freezer
For Life
User Manual
EN
FA
Bottom Freezer
SJ-BM585D-SS2
SJ-BM585D-HS2
SJ-BM585D-WH2
EN -1-
Contents
CHAPTER -1: GENERAL WARNINGS ........................................................................2
CHAPTER -2: YOUR FRIDGE FREEZER....................................................................5
CHAPTER -3: USING YOUR FRIDGE FREEZER........................................................7
CHAPTER -4: FOOD STORAGE GUIDANCE ............................................................14
CHAPTER -5: DOOR REVERSAL ..............................................................................15
CHAPTER -6: TROUBLESHOOTING .........................................................................15
CHAPTER -7: TIPS FOR SAVING ENERGY ..............................................................17
Your fridge freezer conforms to current safety requirements. Inappropriate use can lead to personal injury and damage
to property. To avoid the risk of damage read this manual carefully before using your fridge freezer for the rst time. It
contains important safety information on the installation, safety, use and maintenance of your Fridge Freezer. Retain
this manual for future use.
EN -2-
CHAPTER -1: GENERAL WARNINGS
WARNING: Keep the ventilation openings of the Fridge
Freezer clear from obstruction.
WARNING: Do not use mechanical devices or other means
to accelerate the defrosting process.
WARNING: Do not use other electrical appliances inside
the Fridge Freezer
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid personal injury or damage this
appliance must be installed in accordance with the
manufacturer instructions.
The small quantity of refrigerant used in this fridge freezer
is eco- friendly R600a (an isobutene) and is ammable and
explosive if ignited in enclosed conditions.
* While carrying and positioning the fridge, do not damage
the cooler gas circuit.
* Do not store any containers with ammable materials, such
as spray cans or re extinguisher rell cartridges in the
vicinity of the fridge freezer.
* This appliance is intended to be used in household and
similar applications such as;
- staff kitchen areas in shops, ofces and other working
environments
- farm houses and by clients in hotels, motels and other
residential type environments
- bed and breakfast type environments;
- catering and similar non-retail applications
* Your fridge freezer requires a 220-240V, 50Hz mains supply.
Do not use any other supply. Before connecting your
fridge freezer, ensure that the information on the data plate
(voltage and connected load) matches the mains electricity
supply. If in doubt, consult a qualied electrician)
* This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
EN -3-
CHAPTER -1: GENERAL WARNINGS
hazard involved. Children shall not play with the appliance.
Cleaning and user maintenance, shall not be made by
children without supervision.
* A damaged power cord /plug can cause re or give you
an electric shock. When damaged it must be replaced, this
should only be done by qualied personnel.
* This appliance is not intended for use at altitudes exceeding
2000 m.
EN -4-
CHAPTER -1: GENERAL WARNINGS
Disposal
• All packaging and materials used are environmentally friendly and recyclable. Please dispose of any packaging
in an environmentally friendly manner. Consult your local council for further details.
• When the appliance is to be scrapped, cut off the electrical supply cable and destroy the plug and cable. Disable
the door catch in order to prevent children becoming trapped inside.
• A cut off plug inserted into a 16 amp socket is a serious safety (shock) hazard. Please ensure the cut off plug
is disposed of safely.
Notes:
• Please read the instruction manual carefully before installing and using your appliance. We are not responsible
for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to resolve
the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic environments and for the
specied purposes. It is not suitable for commercial or common use. Such use will cause the guarantee of the
appliance to be cancelled and our company will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing foods. It is not
suitable for commercial or common use and/or for storing substances except for food. Our company is not
responsible for the losses to be occurred in the contrary case.
Safety warnings
• Do not connect your Fridge Freezer to the mains electricity supply using an extension lead.
• A damaged power cord / plug can cause re or give you and electric shock. When damaged it must be
replaced, this should only be dine by qualied personnel.
• Never bend the power cord excessively.
• Never touch the power cord / plug with wet hands as this could cause a short circuit electric shock.
• Do not place glass bottles or beverage cans in the freezer department. Bottles or cans may explode.
• When taking ice made in the freezer department, do not touch it, ice may cause ice burns and/or cuts.
• Do not remove items from the freezer if your hands are damp or wet. Tis could cause skin abrasions or frost /
freezer burns.
• Do not refreeze food once it has thawed out.
Disposal of your old appliance
This symbol on the product or package implies that the product should not be treated as domestic waste.
Instead, it should be delivered to applicable waste collection places recycling electrical and electronic
equipment. Recycling materials will help natural resources be preserved. For more detailed information
regarding recycling of this product, please contact local authority, domestic waste disposal service or the
shop you have purchased the product from.
Please ask your local authority about the disposal of the WEEE for the reuse, recycle and recovery
purposes.
Installation Information
Before unpacking and manoeuvering your fridge freezer please take some time to familiarise yourself with the following
points.
• Position away from direct sunlight and away from any heat source such as a radiator.
• Your appliance should be at least 50 cm away from stoves, Gas ovens and heater cores, and should be at least
5 cm away from electrical ovens.
• Do not expose your fridge freezer to moisture or rain.
• Your fridge freezer should be positioned at least 20mm away from another freezer.
• Clearance of at least 150 mm is required at the top of your appliance. Do not place anything on top of your
appliance.
• For safe operation it is important that your fridge freezer is safe and balanced. The adjustable feet are used to
level your fridge freezer. Make sure that your appliance is level before placing any foodstuffs
inside it.
• We recommend that you wipe all shelving and trays with a cloth soaked in warm water mixed
with a teaspoon of bicarbonate of soda before use. After cleaning rinse with warm water and
dry.
• Install using the plastic distance guides, which can be found at the rear of the appliance. Turn
90 degrees (as shown in the diagram). This will keep the condenser from touching the wall.
• Refrigerator should be placed against a wall with a free distance not exceeding 75 mm.
Before Using your Fridge
• Before setting up your fridge freezer, check for any visible damage. Do not install or use your fridge
freezer if it is damaged
• When using your fridge freezer for the rst time, keep it in an upright position for at least 3 hours before
plugging into the mains. This will allow efcient operation and prevents damage to the compressor.
• You may notice a light odour when using your fridge freezer for the rst time. This is perfectly normal and
will fade away as the fridge starts to cool.
EN -5-
CHAPTER -1: GENERAL WARNINGS
Information about new-generation cooling technology
Fridge freezers with new-generation cooling technology have a different working system
than static fridge freezers. In normal fridge freezers, humid air entering the freezer and the
water vapour emanating from the foods, turns into frost in the freezer compartment. In order
to melt this frost, in other words defrost, the fridge has to be unplugged. In order to keep
foods cold during the defrosting period, the user must store the food elsewhere and the user
must clear the remaining ice and accumulated frost.
The situation is completely different in freezer compartments equipped with new-generation
cooling technology. With the aid of fan, cold and dry air is blown throughout the freezer
compartment. As a result of the cold air that is blown easily throughout the compartment
– even in the spaces between shelves – foods are frozen equally and properly. And there
will be no frost.
The conguration in the refrigerator compartmentwill be nearly same as the freezer
compartment. Air emitted by the fan located at the top of refrigerator compartment is cooled
while passing through the gap behind the air duct. At the same time, air is blown out through
the holes on the air duct so that cooling process is successfully completed in the refrigerator
compartment. Holes on the air duct are designed for even air distribution throughout the
compartment.
Since no air passes between the freezer and refrigerator compartment, odours will not mix.
As a result, your fridge with new-generation cooling technology is easy to use and it offers
you an access to a huge volume and aesthetic appearance.
CHAPTER -2: YOUR FRIDGE FREEZER
This gure has been drawn for information purposes to show the various parts and accessories in the appliance.
Parts may vary according to the model of the appliance.
15
14
A) Fridge compartment
B) Freezer compartment
1) Wine rack *
2) Fridge glass shelf
3) Roller storage box cover *
4) Roller storage box *
5) Crisper cover
6) Crisper
7) Lamp switch
8) Freezer upper basket
9) Freezer bottom basket
10) Bottle shelf
11) Water tank
12) Door middle shelf
13) Door upper shelves
14) Egg holder
15) Ice tray
* In some models
A
B
1
2
3
4
5
6
7
8
9
10
11
12
13
EN -6-
Parts of the water dispenser
(A ) Outside the door (water dispenser's tank group)
CHAPTER -2: YOUR FRIDGE FREEZER
(B) Inside the door (Water dispenser's tank group)
1
2
3
4
1) Top cover of the water dispenser
2) Valve lever
3) Drip tray
4) Water dispenser casing
5) Filter cover
6) Top cover of the water tank
7) Tank cover
8) Water tank
9) Gasket ring
10) Tap detail
11) Side locking covers
8
7
6
5
11
10
9
EN -7-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Display and control panel
Operating your fridge
Super freeze mode
How would it be used?
Press the freezer set button until the Super freeze symbol is seen on the screen. The buzzer will beep
twice . The mode will be set.
In this mode:
• Cooler and super cool mode temperatures may be adjusted. In this case super freeze mode will
continue.
• Economy and Holiday mode cannot be selected.
• Super freeze mode can be cancelled using the same selection operation.
Super cool mode
How would it be used?
Press the cooler set button until the Super cool symbol is seen on the screen. The buzzer will beep twice
. The mode will be set.
In this mode:
• The freeze and Super freeze temperature mode may be adjusted. Super cool mode will continue
in this case.
• Economy and Holiday mode cannot be selected.
• Super cool mode can be cancelled using the same selection operation.
1. This is cooler set value screen.
2. This is super cooling indicator.
3. This is freezer set value screen.
4. This is super freeze indicator.
5. This is alarm symbol.
6. This is economy mode symbol.
7. This is holiday mode symbol.
8. This is child-lock symbol.
9. This enables the cooler value settings to be modied and super cool
mode to be activated, if desired. The cooler maybe set to 8, 6, 5, 4, 2
°C super cool.
10. This enables the freezer setting values to be modied and super freeze
mode to be activated, if desired. The freezer may be set to -16, -18,
-20, -22, -24°C super freeze.
11. This enables the modes (economy, holiday…) to be activated, if desired.
1
2
3
4
5
6
7
8
9
10
11
EN -8-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Economy mode
How would it be used?
• Push "mode button" until the eco symbol appears.
• If no button is pressed for 1 second. The mode will be set. The eco symbol will blink 3 times.
When the mode is set, the buzzer will beep twice.
• The freezer and refrigerator temperature segments will display "E".
• The economy symbol and E will light till mode nishes.
In this mode:
• The freezer may be adjusted. When economy mode is cancelled, the selected setting values
will commence.
• Cooler may be adjusted. When economy mode is cancelled, the selected setting values will
commence.
• Super cool and super freeze modes can be selected. Economy mode is automatically cancelled
and the selected mode is activated.
• Holiday mode can be selected after cancelling the economy mode. Then the selected mode is
activated.
• To cancel, you will just need to press the mode button.
Holiday mode
How would it be used?
• Push the "mode button" until the holiday symbol appears
• If no button is pressed for 1 second. Mode will be set. The holiday symbol will blink 3 times. When
the mode is set, the buzzer will beep twice.
• Cooler temperature segment will display "--".
• Holiday symbol and "--" will light till mode nishes.
In this mode:
• The freezer may be adjusted. When holiday mode is cancelled, the selected setting values will
commence.
• Cooler may be adjusted. When holiday mode is cancelled, the selected setting values will
commence.
• Super cool and super freeze modes can be selected. Holiday mode is automatically cancelled
and the selected mode is activated.
• Economy mode can be selected after cancelling the holiday mode. Then the selected mode is
activated.
• To cancel, you will just need to press the mode button.
Drink cool mode
When would it be used?
This mode is used to cool the drinks within an adjustable time.
How would it be used?
• Press the freezer button for 3 seconds.
• Special animation will begin on the set freezer value screen and 05 will blink on set cooler value
screen.
• Press cooler button to adjust the time (05 - 10 - 15 - 20 - 25 - 30 minutes).
• When you select the time, the numbers will blink 3 times on screen and beep twice.
• If no button is pressed within 2 seconds, the time will be set.
• The countdown begins from the adjusted time minute by minute.
• The remaining time will blink on the screen.
• To cancel this mode press the freezer set button for 3 seconds.
EN -9-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Light cancelling mode
When would it be used?
• If you wish to cancel lights of cooler, you can select this mode.
• While pushing the freezer and mode buttons, open and close cooler door 3 times. The mode
will be selected in this way. From now on, the lights will not come on until the function is not
cancelled in the same way.
• If you want to cancel this mode, repeat the same process or the mode will automatically cancel
itself after 24 hours.
Child lock function
When would it be used?
To prevent children from playing with the buttons and changing the settings you have made, child
lock is available in this appliance.
Activating Child Lock
Press the Freezer and Cooler buttons simultaneously for 5 seconds.
Deactivating Child Lock
Press the Freezer and Cooler buttons simultaneously for 5 seconds.
Note: Child lock will also be deactivated if the electricity is interrupted or the fridge is unplugged.
Screen saver mode
Instructions for use
• This mode will be activated when you press the mode button for 5 seconds.
• If no button is pressed within 5 seconds when the mode is active, the lights of the control panel
will go off.
• If you press any button when the control panel lights are off, the current settings will appear on
the screen, and then you can make the adjustment as needed. If you do not cancel the screen
saver mode or do not press any button within 5 seconds, the control panel will go off again.
• To cancel screen saver mode press the on mode button for 5 seconds again.
• When screen saver mode is active you can also activate the child lock.
• If no button is pressed within 5 seconds after child lock is activated, the lights of the control panel
will switch off. You can see latest settings or modes status after you press any button. You can
cancel child lock as described in the instruction of this mode while the control panel light is on .
EN -10-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Cooler temperature settings
• Initial temperature value for the Cooler Setting Indicator is +4 °C.
• Press the cooler button once.
• When you rst push this button, the last value will appear on the cooler setting indicator.
• Whenever you press this button, a lower temperature will be set. (+8°C, +6°C, +5°C, +4°C, +2°C,
Super cool)
• When you push the cooler set button until the Super cool symbol appears, and if you do not push
any button within 1 second, Super Cool will ash.
• If you continue to press the button, it will restart from +8°C.
• The temperature value selected before Holiday Mode, Super Freeze Mode, Super Cool Mode or
Economy Mode is activated and will remain the same when the mode is over or cancelled. The
appliance continues to operate with this temperature value.
Freezer temperature settings
• The initial temperature value for the Freezer Setting Indicator is -18°C.
• Press the set freezer button once.
• When you rst push this button, the last set value will blink on the screen.
• Whenever you press this button, a lower temperature will be set (-16°C, -18°C, -20°C, -22°C,
-24°C Super freeze).
• When you push the set freezer button until the Super freeze symbol appears, and if you do not
push any other button within 1 second, Super Freeze will ash.
• If you continue to press it, it will restart from -16°C.
• The temperature value selected before Holiday Mode, Super Freeze Mode, Super Cool Mode or
Economy Mode is activated and will remain the same when the mode is over or cancelled. The
appliance continues to operate with this temperature value.
Warnings About Temperature Adjustments
• Your temperature adjustments will not be deleted when an energy breakdown occurs.
• It is not recommended that you operate your fridge in environments colder than 10°C.
• Temperature adjustments should be made according to the frequency of door openings, the quantity of food
kept inside the fridge and ambient temperature of the placement of your fridge.
• Your fridge should be operated up to 24 hours according to the ambient temperature without interruption after
being plugged in, this is so it is completely cooled. Do not open the doors of your fridge and do not place food
inside it during this period.
• A 5 minute delay function is applied to prevent damage to the compressor of your fridge, when you take
the plug out and then plug it back in again after an energy
breakdown has occurred. Your fridge will start to operate
normally after 5 minutes.
• Your fridge is designed to operate in the ambient
temperature intervals stated in the standards, according
to the climate class stated in the information label. We
do not recommend operating your fridge out of the stated
temperatures value limits in terms of cooling effectiveness.
• This appliance is designed for use at an ambient tem-
perature within the 16°C - 43°C range.
Climate Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Recommended settings for your appliance temperature
Freezer partition Refrigerator
compartment Remarks
-18 °C 4 °C For regular use and best performance.
-20 °C, -22 °C or -24 °C 4 °C Recommended when environmental temperature exceeds 30°C.
Super Freeze 4 °C Must be used when you wish to freeze food in a short period of time.
-18 °C, -20 °C, -22 °C
or -24 °C 2 °C
These temperature settings must be used when the environmental
temperature is high or if you think the refrigerator compartment is not
cool enough because the door is being opened frequently.
-18 °C, -20 °C, -22 °C
or -24 °C Super Cool Must be used when the refrigerator compartment is overloaded with
food or when there is food to be cooled instantly.
EN -11-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Accessories
Ice box
• To remove the ice box; pull the upper freezer box out as far as possible and
then pull the ice box out.
• Fill 3/4 full of water and place the ice box in it freezer.
Note: While placing the ice box in the freezer, place it in a horizontal position.
Otherwise the water in the ice box can spill.
Freezer box
• The freezer box is for foods that need to be accessed more easily.
• Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
!Make the inverse of the same operation for the resetting the sliding
compartment.
Note: Always hold the handle of box while moving in or out.
Roller storage box
You can use this compartment for two different functions.
Note: Your fridge is delivered to you with the shown section in the open
position. The declared energy consumption and volume are according
to this setting.
1. To use for 0 °C Department: If you want to use this compartment
as 0 °C box you must take the sliding part (cover, which is indicated
in picture) from closed position to open position.
2. To use for Crisper Department: If you want to use this
compartment as crisper, you must take the sliding part (cover, which
is indicated in picture) from open position to closed position.
• While this compartment is used as an 0 °C compartment, food
retains freshness and for longer.
• Pull the chiller shelf out toward you. The cover will open
automatically.
Please note this this is not a freezer compartment.
Removing The chiller shelf;
• Open the cover fully. (Picture-1)
• Pull the chiller shelf out towards you. (Picture-2)
• Pull the wheels of chiller shelf up from the rail in order to remove it. (Picture-3)
Ice box
sliding part
Picture-1 Picture-2 Picture-3
EN -12-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Fresh dial
The fresh dial is located in the front of the crisper, should be opened when the
compartment is full. The humidity level will be controlled and food will keep
fresher for longer.
If you see condensation on the glass shelf you must open the fresh dial fully.
sliding part
Water Dispenser
Mounting of the Water Tank
Place the water tank in the plastic holder on the door, pitched in the direction of the arrow.
After you have mounted the water tank, push it down to rmly secure in the holder.
Add your drinks with the help of the water tank top cover.
Release the side locking covers to detach the water tank cover.
To serve your drinks, gently press the valve lever.
EN -13-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Filling the Water Tank
• Remove the top cover of the water tank.
• Fill the tank up with water.
• Mount the top cover back on the water tank.
Attention
• Do not use the water dispenser for anything except water.
• If you leave water in the tank for a long time it could cause an odour. In this case, clean the tank and keep
using it.
• Clean the water tank before using it for the rst time.
Cleaning the Water Tank
• Lift the water tank.
• Remove the tank cover by releasing the side locking covers.
• Clean the tank with warm water and reassemble the pieces that you have removed.
Stowing the Water Tank
• Install the water tank as shown.
• Make sure that the tap and the hole match each other while installing.
• Water ow may not be as expected if the tank has not been installed properly. Also check that the gaskets have
been assembled properly.
Drip Tray
Use of the dispenser may cause water to collect in the drip tray. Remove the tray to empty the water and then re-t
the tray.
Filter Detail
There is a lter cover with a lter in at the back of the top cover. Do not use this cover.
Please contact an authorised service agent about exchanging the cover.
Please contact an authorised service centre about opening the cover and exchanging the
lter.
ATTENTION:
PLEASE HOLD THE GLASS MOMENTARILY AFTER DISTRIBUTION TO AVOID DRIPS.
Cleaning
• Make sure to unplug the fridge before starting to clean it.
• Do not wash your fridge by pouring water.
• You can wipe the inner and outer sides with a soft cloth or a sponge using warm and soapy water.
• Remove the parts individually and clean with soapy water. Do not wash in washing machine.
• Never use ammable, explosive or corrosive material like thinner, gas, acid for cleaning.
• You should clean the condenser with broom at least once a year in order to provide energy saving and increase
the productivity.
Make sure that your fridge is unplugged while cleaning.
Visual and text descriptions on the accessories section may vary according which model you have..
Defrosting
Your refrigerator automatically defrosts. The water formed as a result of defrosting passes
through the water collection spout, ows into the vaporization container behind your
refrigerator and evaporates by itself in there.
Evaporating
tray
Replacing LED Lighting
If your fridge freezer has LED lighting contact the Sharp help desk as this
should be changed by authorized personnel only.
EN -14-
CHAPTER -4: FOOD STORAGE GUIDANCE
CHAPTER -5: DOOR REVERSAL
Refrigerator compartment
• To reduce frost build up never place liquids with unsealed containers in the fridge compartment.
• Allow warn or hot food to cool down before storing. This helps reduce power consumption.
• To avoid frost buildup ensure that nothing is stored touching the back wall.
• The coldest area of the refrigerator is at the bottom. We recommend to use this area to store food that will perish
easily, such as sh, ready meals, baked goods or dairy products. The warmest area is the top shelf of the door.
We recommend you store butter or cheese here.
Freezer compartment
• Use the freezer to store frozen foods for long periods of time and make ice cubes.
• If you are going to use the refrigerator with maximum freezing capacity:
* Place the foods that you want to freeze to the top basket of the freezer department without exceeding the
freezing capacity of your refrigerator.
* While you use Super Freeze Mode, you mustn't storage an exist foozen food near the fresh foods that you
want to freeze.
Then enable the “Super Freeze” mode again. You may place your food next to the other frozen food after they
are frozen (for at least 24 hours after the 2nd activation of the “Super Freeze” mode).
• To freeze fresh food - ensure that as much of the surface of food to be frozen is in contact with the cooling
surface.
• Do not put fresh food on either side of frozen food as it can thaw it.
• While freezing fresh foods(i.e meat,sh and mincemeat),divide into portion sizes.
• Once the unit has been defrosted replace the foods into freezer and remember to consume them in a short
period of time.
• Never place warm food in the freezer compartment.
• The instructions shown on frozen food packages should always be followed carefully and if no information is
provided food should not be stored for more than 3 months from the purchased date.
• When buying frozen foods ensure that these have been frozen at suitable temperatures and that the packing
is intact.
• Frozen foods should be transported in appropriate containers to maintain the quality of the food and should be
stored in the freezer as soon as possible.
• If a package of frozen food shows signs of humidity and abnormal swelling it has been previously stored at an
unsuitable temperature and that the contents have deteriorated.
• The storage life of frozen foods depends on the room temperature, thermostat setting, how often the door is
opened, the type of food and the length of time required to transport the product from the shop to your home.
Always follow the instructions printed on the package and never exceed the maximum storage life indicated.
That; If you decide to open the freezer door again immediately after closing, it may be difcult to re-open. This is normal
and after the freezer has reached an equilibrium condition the door will open easily.
Important note:
• Frozen foods, when thawed, should be cooked just like fresh foods. If they are not cooked after being thawed
they must NEVER be re-frozen.
• The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar, assorted spices, ginger,
garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they
are stored for a long period. Therefore, only add a small amount of spice if planning to freeze, or the desired
spice should be added after the food has been thawed.
• The storage period of food is dependent on the oil used. The suitable oils are margarine, calf fat, olive oil and
butter and the unsuitable oils are peanut oil and pig fat.
• The food in liquid form should be frozen in plastic cups and the other food should be frozen in plastic folios or
bags.
Repositioning the door
• It depends on which fridge freezer you have as to whether it is possible the reverse the doors.
• It is not possible where handles are attached at the front of the appliance.
• If your model does not have handles it is possible to reverse the doors, but this needs to be completed by
authorised personnel. Please call Sharp service.
EN -15-
CHAPTER -6: TROUBLESHOOTING
Your Fridge Freezer is equipped with a built in fault detection system, which is able to give you guidance should your
fridge freezer not operate as expected. In the event of an error code will be displayed on the control panel. The most
common error codes are shown below. If your fridge freezer displays a code not shown below contact the Sharp help-
desk.
ERROR TYPE ERROR TYPE WHY REMEDY
Sr "Failure
Warning"
Some parts have stopped
working or there is a failure
in the cooling process
Contact the Sharp help desk as soon as
possible.
Sr – Set
value blink
on the
freezer set
value screen
Freezer comp. Not
Cold enough
This warning will be seen
especially after a long term
power failure
1. Do not freeze the foods that have
thawed and use it in a short time period.
2. Set the freezer temperature to colder
values or set the super freeze, until
the compartment achieves a normal
temperature.
3. Do not put in fresh food until this
warning is off.
Sr – Set
value Blink
on the cooler
set value
screen
"Refrigerator comp.
Not Cold enough"
Ideal temperature for Ref.
Compartment is +4 oC. If
you see this warning your
foods is at risk of spoiling.
1. Set the refrigerator temperature to
colder values or set the super cooling
mode until the compartment achieves a
normal temperature.
2. Do not open the door frequently until
this warning is removed.
Sr – Set
value blink
on the
freezer and
cooler set
value screen
"not cold enough
Warning"
This is a combination of
"not cool enough" error for
both of the compartments.
You will see this failure when rst starting
the appliance. It will switch off after
the compartments achieves a normal
temperature
Sr – Set
value blink
on the cooler
set value
screen
Refrigerator comp.
too Cold
The foods starts to freeze
because the temperature
is too low.
1. Check if the “Super cooling mode”
is on
2. Decrease the refrigerator temperature
values
“--” "Low voltage
Warning"
When the power supply
goes lower than 170 V,
the appliance goes into a
steady position.
This not a failure. This prevents any
damage to the compressor. This warning
will go off after the voltage achieves the
required level
Check Warnings;
If your fridge is not operating;
• Is there a power failure?
• Is the plug connected to the socket correctly?
• Is the fuse of the socket to which the plug is connected or the main fuse blown?
• Is there any failure at the socket? To check this, plug your refrigerator into a known working socket.
If your fridge is not cooling enough;
• Is the temperature adjustment right?
• Is the door of your fridge opened frequently and left open for a long while?
• Is the door of fridge closed properly?
• Did you put a dish or food on your fridge so that it contacts the rear wall of your fridge so as to prevent the air
circulation?
• Is your fridge lled excessively?
• Is there adequate distance between your fridge and the rear and side walls?
• Is the ambient temperature within the range of values specied in the operating manual?
If the food in your refrigerator compartment is over cooled
• Is the temperature adjustment right?
• Are there many food recently put inside the freezer compartment? If so, your fridge may over cool the food
inside the refrigerator compartment as it will operate longer to cool these food.
EN -16-
CHAPTER -6: TROUBLESHOOTING
If your fridge is operating too loudly;
To maintain the set cooling level, compressor may be activated from time to time. Noises from your fridge at this time
are normal and due to its function. When the required cooling level is reached, noises will be decreased automatically.
If the noises persist;
• Is your appliance stable? Are the legs adjusted?
• Is there anything behind your fridge?
• Are the shelves or dishes on the shelves vibrating? Re-place the shelves and/or dishes if this is the case.
• Are the items placed on your fridge vibrating?
Normal Noises;
Cracking (Ice cracking) Noise:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking: Heard when the thermostat switches the compressor on/off.
Compressor noise (Normal motor noise): This noise means that the compressor operates normally Compressor
may cause more noise for a short time when it is activated.
Bubbling noise and splash: This noise is caused by the ow of the refrigerant in the tubes of the system.
Water ow noise: Normal ow noise of water owing to the evaporation container during defrosting. This noise
can be heard during defrosting.
Air Blowing Noise (Normal fan noise): This noise can be heard in No-Frost fridge during normal operation of
the system due to the circulation of air.
If humidity builds up inside the fridge;
• Has the food been properly packaged? Have the containers been well dried before they were put into the
refrigerator?
• Are the doors of the refrigerator opened very frequently? When the door is opened, the humidity found in the
air in the room enters the refrigerator. Especially if the humidity rate in the room is too high, the more frequently
the door is opened the faster will be the humidication.
If the doors are not opened and closed properly;
• Do the food packages prevent closing of the door?
• Are the door compartments, shelves and drawers placed properly?
• Are door gaskets broken or torn?
• Is your fridge on a level surface?
If the edges of fridge cabinet that the door joint contact are warm;
Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the
compressor, this is normal.
About the water dispenser;
If the water ow is abnormal;
Check that;
• The tank is well installed.
• The tank gaskets are well assembled.
If dripping occurs;
Check that;
• The tap is well assembled.
• The tap gaskets are well assembled.
IMPORTANT NOTES:
• The compressor protection thermal fuse will cutout after sudden power breakdowns or after unplugging the
appliance, because the gas in the cooling system is not stabilised. This is quite normal, and the fridge will
restart after 4 or 5 minutes.
• The cooling unit of your refrigerator is hidden in the rear wall. Therefore, water droplets or ice may occur on the
rear surface of your fridge due to the operation of the compressor in specied intervals. This is normal. There
is no need to perform a defrosting operation unless the ice is excessive.
• If you will not use your fridge for a long time (e.g. in summer holidays) unplug it. Clean your fridge according to
Part 4 and leave the door open to prevent humidity and smell.
• The appliance you have purchased is designed for home type use and can be used only at home and for
the stated purposes. It is not suitable for commercial or common use. If the consumer use the appliance in
a way that does not comply with these features, we emphasise that the producer and the dealer shall not be
responsible for any repair and failure within the guarantee period.
• If the problem persists after you have followed all the instructions above, please consult an authorised service
provider.
EN -17-
CHAPTER -7: TIPS FOR SAVING ENERGY
1. Always allow foodstuffs to cool before storing in the appliance.
2. Thaw food in the fridge compartment, this helps save energy.
-17- FA
6
•
! 5 4 .
• .
. .)(
.
• . )(
.
• .
• .
.
.
7
. )... ( .1
.
. .2
. . .3
.
. . .4
. .
. .5
. ) ... (. .6
. . .7
-16- FA
6
.
. .
•
•
• .
•
.)(
./
.
.
.
. .
)(
.
•
• .
.
• ) ) .
•
•
•
•
)(
.
• .
• .
• .
• .
This manual suits for next models
2
Table of contents
Languages:
Other AEG Refrigerator manuals
AEG
AEG S 75358 KG3 User manual
AEG
AEG SKS81040F0 User manual
AEG
AEG SKZ81800C0 User manual
AEG
AEG SANTO User manual
AEG
AEG S63600CMM1 User manual
AEG
AEG SKZ81800F0 User manual
AEG
AEG SCB819E8TS User manual
AEG
AEG RCB83326MX User manual
AEG
AEG SANTO Compact Refrigerator Freezer User manual
AEG
AEG S83800CTW0 User manual
AEG
AEG SANTO C 7 18 40-4I User manual
AEG
AEG RCB732E5MW User manual
AEG
AEG SANTO 70438-6 DT User manual
AEG
AEG SANTO User manual
AEG
AEG SKB612F1AF User manual
AEG
AEG SCS71801F1 User manual
AEG
AEG SCE81824NC User manual
AEG
AEG RKB738E5MW User manual
AEG
AEG SCS51600S0 User manual
AEG
AEG OKO_SANTO 1443TK User manual
