Aegis EL-RG-2.4H User manual

Model:
EL-RG-2.4H
EL-RG-4H
EL-R-2.4H
EL-R-4H
Checker:
Read the Operation Manual carefully before using your appliance.
Keep the Operation Manual in a safe place.
Appearance , color and layout of the door may vary.
Translation of the original instruction.
Aegis pharmaceutical refrigerators are applicable for the storage of
pharmaceutical products, medicines, and other laboratory products that need to
be stored at a temperature of 2℃to 8℃.
Certificate of Quality
Pharmaceutical Refrigerator
Operation Manual
AEGIS SCIENTIFIC
1 Ivybrook Blvd, Unit 145R, Ivyland, PA 18974, USA
Tel: [phone] / Fax: [phone]
Website: www.aegisfridge.com

EC Declaration of Conformity
according to the Machinery Directive 2006/42/EC
For the following equipment :
Product : Pharmaceutical Refrigerator
21
Plastic bag
Key
Drain hole cap
Model
Operation Manual
EL-R-2.4H
EL-RG-2.4H EL-RG-4H
1
2
1
1
1
2
1
1
1
2
1
1
EL-R-4H
1
2
1
1
Packing List
Global Warming Potential
Note: Technical information may vary from the appliance that you have just purchased due to
technical improvements. Please take care of the key, if lost, please contact the seller.
Model Rated voltage
（VAC）
Rated frequency
（Hz）
CO2 equivalent
(Tonnes)
EL-RG-2.4H 220~240 50/60 0.072
EL-RG-4H 220~240 50/60 0.129
EL-R-4H 220~240 50/60 0.122
into the atmosphere.
GWP=global warming potential
Refrigerant type GWP
R134a 1430
Manufactures Name :Aegis Scientific Inc.
Address
Tel
: 1 Ivybrook Blvd, Unit 145R, Ivyland, PA 18974, USA
: 1-800-796-2344 / Fax: [phone]
Refer to in this declaration confirms with the following directive(s)/
standards: 2006/42/EC, EN60335-1, EN60335-2-89 EN62233
Type Designation/Trademark: EL-RG-2.4H
EL-RG-4H
EL-R-2.4H
EL-R-4H

Temperature
Control
Refrigeration
System
Safety
System
User-friendly
Design
Microprocessor control, digital display of temperature, temperature
display accuracy as 1℃ and temperature range as 2℃~8℃.
Multi-fault alarm (high and low temperature alarm, power failure
alarm, sensor error alarm and door ajar alarm,low battery alarm)
Two alarm methods (audible buzzer and visual)
All independent components are safely grounded
Optimized refrigeration system, hermetically sealed refrigeration
compressor
User-friendly design, Microprocessor control, smart and carefree,
adjustment not required
High-performance thermal insulation layer, with excellent insulation
effect
Automatic condensate removal, no drain lines required
Note: Technical information might be somewhat different on your refrigerator than
published due to continuous improvement.
The product is applicable to pharmacies, pharmaceutical factories, quarantine stations, health
centers and hospitals, used to store biological products and those need to be stored at a
temperature between 2~8℃.
20 1
EL-R-4H
597×635×835
515×415×630
118L
3/1
R134a 85g
LED 0.3W
46kg
2℃~8℃
220V-240V~/50/60Hz
165W/1.16A
EL-RG-4H
597×635×835
515×415×630
118L
3/1
Microprocessor controlled
R134a 90g
LED 0.3W
41kg
2℃~8℃
220V-240V~/50/60Hz
135W/1.03A
Solid door
CFC-Free foamed-in-place urethane
High Quality Hermetically sealed compressor
Force-air cooling circulation
Glass door with electric heat
Force-air cooling circulation
Pharmaceutical Refrigerator
Exterior Dimensions
(W×D×H)
(mm)
Interior Dimensions
(W×D×H)
(mm)
Effective Volume
Door
Insulation
Compressor
Shelves/Basket
Refrigerating Method
Exterior / Interior
Condenser/Evaporimeter
Refrigerant
Lamp
Net Weight
Temperature Range
Voltage
Rated Power/Current
Alarm system High & low temperature alarm, sensor error alarm, power failure alarm,
door ajar alarm，low battery alarm
Name
Model
Battery duration for alarm system at least 8h (when the battery is fully charged)
Anti-shock Safety Classification II
Temperature Control
Power connection type YY
Climate Type 44
Foaming Agent CP/IP CP/IP
Noise Level(Lp) 32dB(A) 32dB(A)
Microprocessor controlled
Max:10kg/m²
Load Max:10kg/m²
Note: Climate Type 4 means the temperature is +30℃,the relative humidity is 55%.Technical information may vary from
the appliance that you have just purchased due to technical improvements.
Wire and tube / Plate type Wire and tube / Plate type
sprayed steel plate /PS plate sprayed steel plate /PS plate
Automatic defrost maintains optimum cooling capacity

1
19
Product Feature........................................................
Content.....................................................................
Application guidelines...............................................
Precautions for Use..................................................
Product Installation ...................................................
Component Names Control Panel...........................
Application method ...................................................
Cleaning and Maintenance.......................................
FAQ..........................................................................
Refrigeration Schematic & Wiring Diagram..............
Specification.............................................................
2
3
6
7
11
13
16
17
18
19
Content:
2
EL-RG-2.4H
Pharmaceutical Refrigerator
Effective Volume
Door
Compressor
Refrigerating Method
Condenser/Evaporimeter
Refrigerant
Lamp
Net Weight
Temperature Range
Rated Power/Current
495×580×660
415×385×505
68L
Solid door
2/1
Force-air cooling circulation
sprayed steel plate /PS plate
Wire and tube / Plate type
R134a 50g
LED 0.3W
38kg
2℃~8℃
220V-240V~ /50/60Hz
84W/0.65A
High & low temperature alarm, sensor error alarm, power failure alarm,
door ajar alarm,low battery alarm
Name
Model EL-R-2.4H
495×580×660
415×385×505
68L
R600a 22g
38kg
2℃~8℃
at least 8h (when the battery is fully charged)
II
220V-240V~/50/60Hz
84W/0.65A
Specification
Specification
Glass door
2/1
Force-air cooling circulation
sprayed steel plate /PS plate
Wire and tube / Plate type
LED 0.3W
YY
Climate Type 44
Foaming Agent CP/IP CP/IP
Noise Level(Lp) 35dB(A) 35dB(A)
Max:10kg/m² Max:10kg/m²
Note: Climate Type 4 means the temperature is +30℃,the relative humidity is 55%.Technical information may vary from
the appliance that you have just purchased due to technical improvements.
Exterior Dimensions
(W×D×H)
(mm)
Interior Dimensions
(W×D×H)
(mm)
Insulation
Shelves/Basket
Exterior / Interior
Voltage
Alarm system
Battery duration for alarm system
Anti-shock Safety Classification
Temperature Control
Power connection type
Load
Microprocessor controlled
CFC-Free foamed-in-place urethane
High Quality Hermetically sealed compressor
Microprocessor controlled

If the power line needs to be extended, the extended line shall be no smaller than 2mm² in
sectional area and no longer than 3m in length. Otherwise, fire or electric shock may be
caused.
The power line for this refrigerator is provided with a standard three wire (grounding) plug,
which complies with 16A. Do not remove or dismantle the grounding pin of power line in
any case. Make sure the power plug is securely and reliably plugged into the socket to
prevent fire.
Apply socket with ground wire to prevent electric shock.If the socket fails to be grounded,
ground wires must be installed by professional technical staffs.
The refrigerator shall not conduct outdoor service. Electrical leakage or shock may be
caused if wet by rainwater.
Do not place the refrigerator in humid places or places where the refrigerator may suffer
splashing water, to prevent electric leakage or shock due to deterioration of insulation.
Dear users:
Thanks for your choice of Aegis pharmaceutical refrigerator; please make sure you have carefully
read and observed the contents with following signs in the manual, for better understanding of
this manual and better use of this product, so as to prevent personal injuries and refrigerator
damage.
Do not pour water on the refrigerator to prevent electric shock or short circuit.
In case of flammable gas leakage such as coal gas, shut off the valve of leaked gas, open
windows for ventilation and exhaust; do not plug in or pull out the power plug of refrigerator
to prevent explosion and fire.
The refrigerator shall be installed by professional technical staffs or after-sale maintenance
staffs to prevent electric shock or fire.
Place the refrigerator on a solid and flat ground in a stable manner. The refrigerator will be
tipped over or personal injuries will be caused if the refrigerator is placed on improper
ground or place.
Apply the dedicated power supply marked on the nameplate of refrigerator to prevent fire
or electric shock.
If the voltage being used is 10% higher or lower than the rated voltage, an automatic
voltage regulator above 1000 W and appropriate for motor load shall be installed.
18
Safety Precautions
Ignoring this warning may result in
death or serious injury
Ignoring this warning may result in
death or serious injury,and/or damage
to the refrigerator and property
Actions or operations
which are prohibited
Actions or operations
which must be followed
3
Circuit diagram
Refrigeration Schematic & Wiring Diagram
Schematic diagram
Evaporimeter
Muffler
Dry filter
Capillary tube
Condenser
Compressor
Exhaust
pipe

Do not climb on or place articles on the refrigerator as personal injuries or refrigerator
damage may be caused due to turnover of refrigerator
17
Do not plug metal articles such as iron nails or wires into the holes and gaps or vents
for internal air circulation, to prevent electric shock or personal injuries due to contact
of articles above with moving parts.
Do not place containers with water or heavy stuffs on the refrigerator. Personal injuries
may be caused by falling articles and electrical leakage or shock may be caused by out
flowed water due to deterioration of insulation
Do not ground the refrigerator through gas pipes, water supply pipes, telephone lines or
lightning conductors as electric shock or other dangers may be caused.
Do not touch electrical parts such as power plug or switches with wet hands to prevent
electric shock.
Hold the power plug rather than the wire when pulling the plug from the socket as electric
shock or fire due to short circuit may be caused.
Pull out the power plug when the refrigerator is under abnormal performance as electric
shock or fire may be caused.
Users are not allowed to dismantle, repair or retrofit the refrigerator by themselves as fire
or personal injuries may be caused due to improper operation.
Disconnect the refrigerator when repairs or maintenance are performed on the refrigerator
to prevent electric shock or personal injuries.
Do not inhale airborne chemicals inside and / or near the refrigerator during maintenance
as health hazard may be caused.
The refrigerator shall be used in safe regions when toxic, harmful or radioactive articles
are stored inside, as improper use may pose danger to human health or environment.
Pull out the power plug if the refrigerator has been out of service for long time to prevent
electric shock, leakage or fire caused by aging power lines.
If the refrigerator is left unused in areas where supervision is unavailable for a long time,
make sure children will not get close to the refrigerator and the door can not be
completely closed.
End-of-life disposal shall be performed by competent staffs. Remove the door to prevent
accidents such as suffocation.
Do not store explosive substances such as aerosol cans with a flammbale propellant in
this appliance.
Do not store corrosive articles such as acid or alkali in the refrigerator to prevent damage
to internal components or electrical parts.
Do not place packaging plastic bags within the reach of children to prevent suffocation
accidents.
The refrigerator does not work
Fault Troubleshooting
Refrigeration effects are not
apparent, temperature
exceeds the standard
Noise is too significant
Alarm light flashes,
the buzzer alarms
Whether the input power meets the requirements
Whether the plug and socket are in loose contact
Whether the input line and control line break down
Whether the voltage is too low
Whether too much or too hot articles are stored
Whether there is certain clearance among stored articles
Whether the refrigerator is exposed to direct sunlight or radiation of other heat sources
Whether the door is opened too often
Whether the ambient temperature is too high
Whether the air duct is blocked
Whether the refrigerator is placed steadily
Whether part of the refrigerator contact external objects or wall
The noise noted in technical data is average data measured in standard laboratory
without noise when the refrigerator with no stored articles is put on a rubber blanket
and operates steadily after the door is closed, and data measured during startup &
shutdown and at 1 m above the surface is not included. It is normal that actual noise
differs from stated value because of loaded articles, environmental noise, no door
closing, startup & shutdown of the compressor during using.
Whether the articles are newly put in the refrigerator and the temperature is not
stabilized at 3~7℃. The fault will be eliminated automatically after refrigeration for a
while.
Whether the door is not closed completely, which triggers alarm of door opening
Whether the power fails, the refrigerator returns to normal condition after starting up
for a while
Whether the temperature exceeds the standard
FAQ
Do you have questions during using? Do you doubt that the refrigerator breaks
down? Please read description here. This chapter is to give answers in respect
of potential fault phenomenon as well as respective solutions.If your question
is still unresolved after operation, please contact Aegis after-sales service.Do
not maintain and dismantle the refrigerator by yourself!
4

Check refrigerator settings when restarting the refrigerator after power failure or the
power is shut off. Changes of settings may damage the articles stored.
The refrigerator shall be reconnected after more than 5 minutes once it is shut off, to
prevent damage to compressor or system.
Wear gloves when performing maintenance to prevent personal injuries due to sharp
edges or corners.
Hold the knob when closing the door to prevent finger pinching.
The angle of inclination shall not be greater than 45°when handling the refrigerator.
Be careful not to be tripped up by the refrigerator during handling, to prevent
refrigerator damage or personal injuries.
Do not lift or handle equipment with door knob to prevent refrigerator damage or
personal injuries.
Do not use any electrical appliances inside the appliance, unless it is approved by the
manufacturer.
Do not damage refrigerating circuit.
16
Lamp replacement
The refrigerator is equipped with a LED lamp. The lamp has low energy consumption and long
service life. Any doubt, please contact the after-sales service personnel for changing it.
Cleaning and Maintenance
Component Cleaning
To avoid electric shock or staff injuries, please switch off power of the
refrigerator before conducting any repairment or maintenance.
Do not inhale any air borne particles when conducting maintenance on your
refrigerator.
Refrigerator cleaning
Clean the refrigerator once a month. Regular cleaning keeps appearance of the refrigerator new.
Wipe off any dirt with a cleaning cloth with mild detergent water.
Do not dump water on enclosure or inner chamber of the refrigerator, otherwise electrical
apparatus insulation may be damaged, causing occurrence of faults.
The compressor and other mechanical parts are completely sealed. No lubrication is required.
The appliance must be positioned so that the plug is accessible.
The appliance must be placed on a solid and flat surface, or excessive vibration and
noise may be produced when the appliance in operation.
The appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capacibilities or lack of experience and knowledge
if they have been given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
If your cabinet is to be discard, you must remove the door and leave the shelves in
place. This will reduce the posibility of danger to children. And the flammable foaming
needs to be disposed by professional persons.
CP/IP foaming materials are flammable, need professional processing.
5

15
Application guidelines
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection
facilities.Contact you local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into
the groundwater and get into the food chain, damaging your health and well-being.When replacing
old appliances with new ones, the retailer is legally obligated to take back your old appliance for
disposals at least free of charge.
Meaning of crossed –out wheeled dustbin:
6
Make sure the temperature inside the refrigerator has reached the set value and put articles in the
refrigerator by batch. Volumes accounted by articles shall not be greater than 1/3 of refrigerator to
prevent rise of temperature.
The temperature display value of refrigerator refers to the temperature value at the temperature
sensing probe inside the refrigerator. Though the temperature displayed is different from the actual
one at the center of refrigerator, it will approach to the real temperature gradually.
Clean the refrigerator with mild detergent water. Brushes, acids, gasoline, soap powders,
polishing powders or hot water are prohibited to clean refrigerator as these materials may damage
the painting surface and plastic & rubber components and parts. Never wipe the plastic & rubber
components and parts with volatile solvent such as gasoline.
Shut off the power if the refrigerator will be out-of-service for a long time.
Reduce the time of keeping door open when storing or taking articles each time, to prevent great
fluctuation to the temperature and humidity inside the refrigerator.
The refrigerator will see a sharp temperature increase in a short time when the door is opened,
which is normal, and the temperature will resume 1h after the door is closed.
The refrigerator shall operate with ambient temperature as 16~32℃ ; if the humidity is higher than
70%,condensation will occur on the glass door(EL-R-2.4H) in high temperature and high humidity
condition, which is normal and will not affect the storage temperature inside the refrigerator; in the
event of condensation, please improve ventilation conditions as soon as possible and reduce
ambient temperature simultaneously.
Please keep the article inside at least 20mm away from the cabinet back wall！
The maintenance should be supplied by professional after-sales service people once the
equipment is faulty.
EL-RG-4H/EL-R-4H EL-RG-2.4H/EL-R-2.4H
Remote alarm terminal is installed on the
refrigerator and the alarm signal behind the
compartment is output by the terminals. The
bearing capacity of the terminals is DC 30V, 2A.
Battery switch is installed on the back of the
products，with“Charge Battery Switch”label；
Battery switch “ON” indicates that battery is on ；
“OFF” indicates that battery is off。
Terminal output:
Remote alarm terminals include NO, NC and COM.
The user can choose “NO” or “NC” if needed.
Remote Alarm Terminal
COM
NO
NC
Battery Switch
Charge Battery Switch
充电电池开关
Charge Battery Switch
充电电池开关

14
Product Installation
Normal operation will be impossible for refrigerator if it is installed in
environments other than those described above as it is sensitive to ambient
temperature. Start operation after the environment is improved.
It is prohibited to install the refrigerator outdoor. Electric leakage or shock may
be caused if the refrigerator gets wet by rainwater.
The installation site shall meet following requirements for normal operation and best performance of
refrigerator:
Do not install the refrigerator in a narrow and confined space and the door of the installation space
may not be smaller or lower than the refrigerator, to ensure smooth entry and exit of the refrigerator
as well as to prevent damage to the stored articles due to not timely repair of refrigerator as the
installation site is not easy to be accessed.
The ground at the installation site shall be solid and flat.
It is well ventilated and free from direct sunshine.
Do not share the same power outlet with other equipment. The power plug must be plugged into
the outlet securely.
Do not twist or compress the power line.
If the power line needs to be extended, the extended line shall be no smaller than 3mm² in
sectional area and no longer than 3m.
Check the operating voltage before operation and voltage regulator appropriate for motor load may
be applied in regions with unstable voltage.Ensure the normal input voltage stands at rated
voltage ± 10% and the power of voltage regulator is greater than 400W.
The refrigerator shall be grounded in a reliable manner.
If the socket is provided with grounding wire, check if it is well grounded before operation.
If the socket is not provided with grounding wire, a new one shall be installed by professional
engineers.
Installation environment
Ambient temperature: 16℃ to 32℃, 18℃ to 25℃ are optimal and air conditioning system is
required as necessary.
Ambient humidity: EL-R-2.4H: below 70%Rh;EL-RG-2.4H:below 75%Rh;EL-RG-4H/EL-R-4H
below 85%Rh. Avoid excessive dust.
Avoid mechanical swing or vibration.
The refrigerator shall operate at an altitude lower than 2000m.
Input voltage: no greater than ±10% of rated voltage.
Installation site
Do not ground the refrigerator through gas pipes, water supply pipes, telephone
lines or lightning conductors as electric shock may be caused.
The power plug should be accessed after installation to ensure the power line
can be pulled immediately in case of an emergency. The air vents should be
free from any obstruction.
7
Display
6.Check recent highest and lowest cabinet temperature: See fig #1
Press both “Set” and “+” buttons to check the most recent cabinet temperature. Release the
buttons to return to the cabinet temperature display.
Press both “Set” and “-“ buttons to check the most recent cabinet temperature. Release the
buttons to return to the cabinet temperature display.
7.Adjust alarm temperature range: See fig #1
The method sets high temperature alarm “HA” and low temperature alarm “LA”.
Press “Alarm” button for 10 seconds. LED display code “HA” , press “Set” button again (quickly),
code ”HA” flash, adjust the set-temperature by both pressing “+” and “-” buttons and increment 1 ℃,
adjustment range should’t be 6℃ higher than pre-set cabinet temperature, press “Alarm”button to
return the former menu(each press of “Alarm” button will return one step back to former menu until
display cabinet temperature) and LED display “HA” . Press both “+” and “-” to choose another
parameter “LA” , “LA” setting method like “HA”, and its adjustment range shouldn’t be 6 ℃ lower
than pre-set cabinet temperature.
8.Defects display
The control panel only can display one sensor error, when the sensor error happens . LED display
“EE”, and alarm at the same time. The refrigerator will keep working according to the defect safety
model , and you should put the stored goods to other refrigerator as soon as possible, and contact
the after-sales department quikly.
9.Inner light
In order to see the stored goods clearly, a LED light has been installed in the cabinet. You can
control light “on” or “off” by “light” button to save energe, please turn off the light after observing the
stored goods in the refrigerator.
The light is on when the door is open; The light is off when the door is closed.
10.Power failure alarm function
5.Check alarm temperature: See Fig #1
Press both “Set” and “+” buttons to check the most recent cabinet temperature. Release the buttons
to return to the cabinet temperature display.
Press both “Set” and “-“ buttons to check the most recent cabinet temperature. Release the buttons
to return to the cabinet temperature display.
When the power is down, power-off alarm function is activated, buzzer with 1 Hz frequency
continuously beeps,at the same time alarm indicator light of the board flashes, if alarm equipment
is connected to the remote alarm port, it will alarm synchronously and last at least 8 hours. Press
the "Alarm" button to cancel the power off alarm, while the remote alarm function is cancelled.

1. Remove the packaging materials and strings
Remove all packaging materials and strings for transport.
2. Count refrigerator accessories accompanied
Check the articles inside the refrigerator against
the packing list; if any difference, contact the
after-sale service.
3. Placing conditions
Choose the appropriate distance according
to the space requirement.
4. Adjust the leveling leg
Rotate the leveling legs with a wrench in
clockwise to extend them out and secure them
onto the ground. This is to make sure the
refrigerator does not move during operation.
5. Standing
Do not switch on the power after the refrigerator is placed, leveled and cleaned. Switch on the
power after it is put on standing for more than 24h, to ensure normal performance of refrigerator.
13
Preparation before use
Leveling leg
Downward upward
8
1.Microprocessor temperature controller
Adjust the cabinet temperature easily by the micropressor temperature controller in control panel
installed on the top of the refrigerator. Don’t do any adjustment in the first 30 mins when you first
power the refrigerator.
LED displays the cabinet temperature.
Application method
Factory pre-set to 5℃. Set cabinet temperature： Press “Set” button and loosen quikly, LED
dispaly the pre-set temperature and flash.
Adjust the cabinet temperature with the buttons “+” or “-” and increment 1℃ when the temperature
flash. Automatically quit the system after 10 seconds no operation and display the cabinet
temperature again(no flash). The cabinet temperature will reach pre-set temperature after a while.
High and low temperature alarms:
The alarms are activated when the cabinet temperature is warmer than the high alarm temperature
or lower than the low temperature. Press the “Alarm” button to end the buzzer, the flashing light
continues until the cabinet temperature recovers to the normal operating range.
4.Temperature adjustment: See fig #1
The maximum tilt angle of the refrigerator shall
be no more than 45° during the course of
movement.
Transportation and relocation requirement:
clamp truck or forklift truck. 2. Unlock operation instructions
3. Password setting
If there is no operation in 20s,the keys for temperature setting &parameter setting & high/low
temperature setting will be locked,the keys for alarm & light & highest/lowest temperature
checking & high/low temperature alarm checking will still be available.Unlock:press “+”, the
display screen blinking displays "01",then press “+”or “-” to choose the password,then press "Set"
to unlock.Once unlock successfully,the buzzer beeps once and the display screen displays the
temperature normally.If the password is wrong,the display screen will flicker and it will quit the
system automatically if there is no operation in 5s.
The default unlock password is “06”.After unlock,press “Set” and “Alarm” at the same time for
5s,the display screen displays "06",then press “+” and “-”to set the password.Press“Set” to save
the setting.If there is no operation in 5s,password setting will be saved automatically. The pass-
word could be selected from 05、06、07……29、30.
When setting the parameters and high/low temperature alarm value,it will quit the system auto-
matically if there is no operation in 10s and display the inner temperature again.

12 9
Observe the rules below for initial start-up and continuous operation:
When the refrigerator is empty, connect the power line to the appropriate dedicated socket and
make sure the power is rated voltage and frequency.
After the power is on, the audible alarm will alarming and this is normal .
Press the “Alarm”in the control panel to stop alarming. The audible alarm continues to operate
until the temperature of sensor reaches 5℃±3℃.
The temperature of refrigerator will stay at the preset temperature in a stable manner after hours
of operation.
After operation status of refrigerator is checked thoroughly, put articles into the refrigerator.
Initial Power-on
The refrigerator has been preset to operate at 2~8℃ in the factory and it is not required to set
temperature.
Before products go out of the factory , the battery switch is off, the users must open it before
using at the first time. Once the power failure occurs, the product can realize the function of
power failure alarm.
Basket
Inner light
EL-R-2.4H
Door lock Control panel
Handle Leveling legShelf
Inner lightDoor lock Control panel
BasketHandle Leveling leg Shelf
EL-R-4H

11
This unit should be managed by a dedicated person. Inspection should be performed
daily to keep appropriate records. When the temperature is out pf specification, action
should be taken to move the products to a safe place.
This product is pharmaceutical refrigerator with temperature ranging from 2~8℃ inside.
Please make sure articles to be stored conform to environment inside to avoid damages
of articles and economic loss.
Because of refrigeration inertia, display temperature of the product may differ from actual
temperature and humidity inside, which is normal.
Pull out the power plug if the refrigerator has been out of service for long time
to prevent electric shock, leakage or fire caused by aging power lines.
All refrigerators are refrigerator equipments. Relatively too hot articles must not be put in
the refrigerator by one time. Otherwise the compressor will not stop for a long time, no
temperature fall may be apt to burn the compressor. Therefore, articles shall be put in
batches and cooling shall be conducted in batch until required temperature is reached!
Do not damage refrigerating circuit.
Do not use electrical apparatus without production permit in the refrigerator.
The refrigerator is capable of memorizing set value. When power restores after outage, the
refrigerator will continue operating according to set parameter before last outage.
The refrigerator shall be reconnected after more than 5 minutes once it is shut
off, to prevent damage to compressor or system.
If the refrigerator is left unused in areas where supervision is unavailable for a
long time, make sure children will not get close to the refrigerator and the door
can not be completely closed.
Operation after outage
10
Component Names Control Panel
Component Names
Door lock
Handle Leveling leg
Control Panel
Solid door Handle Leveling legSolid door
Door lock Control Panel
EL-RG-2.4H EL-RG-4H
