Congratulations on choosing the Acoustic
Energy AEGIS ONE — a powerful compact two-
way loudspeaker which features metal
diaphragm technology and is capable of out-
standing performance. Please take a few
moments to read this manual. The advice it
contains will enable you to get the very best
performance out of your Acoustic Energy loud-
speakers.
The AEGIS ONE utilises metal cone mid-bass drive unit
technology, proven in the AE Reference series. The rigid
anodised alloy cone ensures pure piston action and
also acts as a heat sink for the bonded voice coil. These
features provide exceptional clarity, transparency
dynamics and power handling.
The tweeter — or treble driver — is a high-quality silk
fabric dome unit integrating smoothly with the rest of
the system. Both drive units are fully magnetically
shielded so that the speakers can be used in close prox-
imity to a TV screen or monitor for AV applications.
AEGIS ONE loudspeaker uses quality OFC internal
wiring which enhances detail and transparency. For
exceptional results use AE UPOCC speaker cable which
is available from AE dealers and distributors.
The AEGIS ONEs are best heard with the tweeters
at, or just below, ear height when the listener is
seated. For serious listening the grilles are best
removed.
Rigid support is essential for the speaker to develop its
full detail and dynamic performance. Rigid stands
with spikes, cones or other methods of secure
mounting are recommended. ‘Free-field’ stand
mounting gives improved stereo separation and
depth. If AEGIS ONEs are shelf mounted the support
must be firm; cones are still recommended beneath
the cabinets.
Closeness to room boundaries has a major impact
on the low frequency performance. The speakers
should be kept away from corners (which will
produce booming). The speakers can be positioned
fairly close to a back or side wall but should not be
the same distance off the ground as from the rear or
side wall.
Experiment with the best position to achieve a full, yet
clean bass response. Trust your judgement and ears.
For best stereo imaging the speakers should be as far
apart as they are from the listening position.
Introduction Positioning
AEGIS one manual 5/7/99 8:57 am Page 2

AMPLIFIER
LEFT SPEAKER
RL
Power Handling 20 – 120 watt
Impedance 8 ohm
Serial Number
DESIGNED AND ENGINEERED BY
ACOUSTIC ENERGY LIMITED, ENGLAND
MADE IN MALAYSIA
MAIN
Check that your amplifier is switched off before
installing your loudspeakers. Failure to do so may
result in speaker or amplifier damage.
The diagram illustrates one loudspeaker only. The
positive (ribbed) cable from the amplifier positive (or
red) terminal should connect with the positive (red)
terminal on the loudspeaker. Similarly the negative
(smooth) cable should connect the amplifier negative
terminal (black) to the negative terminal (black) on the
loudspeaker.
After wiring up: Lower the volume to minimum,
switch on the amplifier, select the signal source and
then raise the volume to the listening level required.
Connection
AEGIS one manual 5/7/99 8:57 am Page 3

Specifications
HF unit 25 mm silk fabric dome, anti-
reflection pole. Ferrofluid cooled
and damped. Magnetically
shielded
MF/LF unit Pure piston 130 mm AE driver
with 32 mm coil, high-power,
long-throw magnet system and
lightweight alloy cone.
Magnetically shielded
Crossover 2nd/3rd order at 2.8 kHz. High-
power inductors and polyester
capacitors. OFC wire to drive units
Power handling 20 – 120 watt max
Overall frequency response 38 Hz – 22 kHz
Frequency response ±3 dB 50 Hz – 20 kHz
Sensitivity 90 dB/1 w/1 m
Impedance 8 ohm
Cabinet 25 mm MDF low diffraction front
baffle. 15mm MDF enclosure. Full
internal bracing. High-power,
gas-flowed, low-turbulence bass
reflex port.
Terminals Gold-plated 2-way binding posts
Weight (excl. packaging) 7 kg each
Dimensions (WxHxD) 192 x 362 x 235 mm
Warranty
Your Acoustic Energy loudspeakers are guaranteed against original
defects in materials, manufacture and workmanship for 3 years from
the date of purchase. Please retain all original packaging materials for
possible future use. We suggest that you complete details of purchase
now and keep this information in a safe place for future reference.
Under this warranty Acoustic Energy agrees to repair any defect or,
at the company’s discretion, replace the faulty component(s) without
charge for parts and labour. This warranty does not imply any
acceptance by Acoustic Energy or its agents for consequential loss or
damage and specifically excludes fair wear and tear, accident,
misuse or unauthorised modification.
This warranty is applicable in the United Kingdom only and does not
in any way limit the customer’s legal rights. Claims and enquiries
under the warranty for AE products purchased outside the UK should
be addressed to the local importers or distributors.
If you have reason to claim under the warranty please contact your
dealer in the first instance.
Dealer’s name:........................................................................................
Address: ..................................................................................................
................................................................................................................
................................................................................................................
Date of purchase: ...................................................................................
Serial numbers: ......................................................................................
Acoustic Energy Limited
16 Bridge Road, Cirencester
Gloucestershire GL7 1NJ
