Agilent Technologies
AC Power Solutions
Models 6811B – 6814B,
6834B, and 6843A
Quick Start Guide

2 Quick Start Guide
Safety Notices
The following general safety precautions
must be observed during all phases of
operation of this instrument. Failure to
comply with these precautions or with
specific warnings elsewhere in this
manual violates safety standards of
design, manufacture, and intended use of
the instrument. Agilent Technologies
assumes no liability if the customer fails
to comply with these requirements.
WARNING: LETHAL VOLTAGES
Ac sources can supply 425 V peak at
their output. DEATH on contact may
result if the output terminals or circuits
connected to the output are touched
when power is applied. Hazardous
voltages can remain active inside the
unit even after it has been turned off. If
the internal LED's are on, hazardous
voltages are present.
General
This product is a Safety Class 1
instrument (provided with a protective
earth terminal). The protective features of
this product may be impaired if it is used
in a manner not specified in the operation
instructions. Any LEDs in this product are
Class 1 LEDs as per IEC 825-1. This ISM
device complies with Canadian ICES-001.
Cet appareil ISM est conforme à la norme
NMB-001 du Canada.
Environmental Conditions
This instrument is intended for indoor use
in an installation category II, pollution
degree 2 environment. It is designed to
operate at a maximum relative humidity of
95% and at altitudes of up to 2000
meters. Refer to the specification tables
for the ac mains voltage requirements
and ambient operating temperature range.
Do not operate the instrument in the
presence of flammable gases or fumes.
Before Applying Power
Verify that all safety precautions are
taken. Make all connections to the unit
before applying power. Note the
instrument's external markings described
under "Safety Symbols"
Ground the Instrument
To minimize shock hazard, the instrument
chassis and cover must be connected to
an electrical ground. The instrument
must be connected to the ac power mains
through a grounded power cable, with the
ground wire firmly connected to an
electrical ground (safety ground) at the
power outlet. Any interruption of the
protective (grounding) conductor or
disconnection of the protective earth
terminal will cause a potential shock
hazard that could result in personal injury.
Fuses
Only fuses with the required rated
current, voltage, and specified type
(normal blow, time delay, etc.) should be
used. Do not use repaired fuses or short-
circuited fuseholders.
Do Not Remove the Cover
Operating personnel must not remove
instrument covers. Parts replacement and
internal adjustments must be made only
by qualified service personnel.
In Case of Damage
Instruments that appear damaged or
defective should be made inoperative and
secured against unintended operation
until they can be repaired by qualified
service personnel.
A CAUTION notice denotes a hazard. It
calls attention to an operating procedure,
practice, or the like that, if not correctly
performed or adhered to, could result in
damage to the product or loss of
important data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and met.
A WARNING notice denotes a hazard. It
calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in personal injury or death.
Do not proceed beyond a WARNING
notice until the indicated conditions are
fully understood and met.
Safety Symbols
Direct current
Alternating current
Both direct and alternating
current
Three phase alternating
current
Earth (ground) terminal
Protective earth ground
terminal.
Frame or chassis
terminal
Terminal is at earth
potential.
Neutral conductor on
permanently installed
equipment
Line conductor on
permanently installed
equipment.
On supply
Off supply
Standby supply. Unit is not
completely disconnected
from ac mains when switch
is off
In position of a bi-stable
push switch
Out position of a bi-stable
push switch
Caution, risk of electric
shock
Caution, hot surface
Caution, refer to
accompanying
description
CAUTION
WARNING

Quick Start Guide 3
Contents
Contents.......................................................................................................................................................3
The front panel - at a glance......................................................................................................................3
The rear panel – at a glance.......................................................................................................................5
What the ac source can do..........................................................................................................................6
How to use the front panel .........................................................................................................................8
Some basic operations...............................................................................................................................10
Measuring the output ...............................................................................................................................12
Programming output transients ..............................................................................................................14
Programming trigger synchronization and delays.................................................................................16
The front panel menus - at a glance........................................................................................................18
NOTE: You can contact Agilent Technologies at one of the following telephone numbers for
warranty, service, or technical support information.
In the United States: [phone]
In Europe: 31 20 547 2111
In Japan: 0120-421-345
Or use our Web link for information on contacting Agilent in your country or specific
location: www.agilent.com/find/assist
Or contact your Agilent Technologies Representative.
© Agilent Technologies, Inc. 1995, 1996, 1998, 2000, 2005
This document contains proprietary information protected by copyright. All rights are reserved. No part of
this document may be photocopied, reproduced, or translated to another language without the prior
agreement and written consent of Agilent Technologies, Inc. as governed by United States and
international copyright laws.
Part number: 5962-0883
Print date: March, 2005

4 Quick Start Guide
The front panel - at a glance
14-character display shows
menu commands and
measured values.
♦Annunciators indicate
operating modes and
status conditions.
Rotary controls set voltage
and frequency when ac source
is in local mode.
♦Turn rapidly for coarse
control
♦Turn slowly for fine
control.
and
scroll through menu
commands.
and
scroll through lists and
harmonic arrays.
and
scroll through
command parameters.
Turns the ac
source on or off System keys:
♦Return to Local mode
♦Set the GPIB address
and other system
parameters
♦Set the RS-232
interface
♦Display SCPI error
codes
♦Save and recall
instrument states
Function keys:
♦Enable/disable the
output
♦Select output phases
♦Select front panel
metering and harmonic
analysis functions
♦Program voltage
frequency, phase,
current limit, pulse
parameters, and
waveform shapes
♦Set and clear protection
functions
♦Select output and input
coupling
♦Monitor status
♦Scroll through front
panel menu commands.
Entry keys:
♦Enter values
♦Increment or
decrement values
♦Scroll through
command
parameters.
♦Calibrate the ac
source.
!
!!
!index "
""
"index
!
!!
!"
""
"#
##
#
$
$$
$

Quick Start Guide 5
The rear panel – at a glance
Rear Panel Connections (see Chapter 3 in the User’s Guide for details)
1INH (Remote Inhibit) TTL input signal for externally disabling the power source.
FLT (Discrete Fault Indicator) TTL output signal when there is a device fault.
2RS-232 connector for remote controller.
3TRIGGER BNC connectors for external trigger inputs and &source; trigger outputs.
4GPIB connector and GPIB cable for remote controller.
5SENSE connections for remote voltage sensing at the load.
6Airflow Vents (do not block).
7OUTPUT power connections to the load. (φ2, φ3 connections available on Agilent 6834B only.)
8AC Input Line Fuses (Agilent 6814B/6834B/6843A only. Other models have internal fuses).
9LINE RATING label specifies power source required by the power source.
10 AC Line Input connections from the power source.

6 Quick Start Guide
What the ac source can do
Generate waveform shapes
♦Sinewave ♦Squarewave ♦Clipped sinewave ♦User-definable waveforms
Program the output
♦Phase Agilent Models 6811B, 6812B, 6813B program
♦Ac rms voltage the following additional output functions:
♦Distortion ♦Dc voltage
♦Frequency ♦Peak Current limit
♦Voltage and frequency slew rates ♦AC coupling
♦Rms current limit ♦Impedance
Make the following measurements
♦Ac rms, ac + dc rms voltage Agilent Models 6811B, 6812B, 6813B make the
following additional measurements:
♦Ac rms, ac + dc rms current; plus repetitive
and non-repetitive peak current ♦Dc voltage
♦Real, reactive, and apparent power ♦Dc current
♦Harmonic analysis of voltage and current
waveforms giving amplitude, phase, and total
harmonic distortion results of up to the 50th
harmonic.
Agilent Model 6834B makes the following
additional measurement:
♦Triggered acquisition of digitized voltage and
current with extensive post-acquisition
calculations
♦Total power and neutral current

Quick Start Guide 7
Synchronize transient events or measurements with external signals
♦Triggers applied to the unit ♦Triggers generated by the unit
Operate in four transient modes
♦Fixed ♦Step ♦Pulse ♦List
Operate under local or remote control
♦From the front panel keys
♦Through the built-in GPIB or RS-232 interfaces
Implement protection features
♦Over-voltage
♦Over-current
♦Over-power
♦Over-temperature
♦User-defined external events (via a FLT shutdown signal)

8 Quick Start Guide
How to use the front panel
Make sure the unit is turned on.
From the System key group
Press Local to activate the front panel keypad if the unit is not already in local mode. (If
the Local Lockout command is in effect, cycle power to return the unit to local mode.)
From the Function key group
Press Voltage to select the voltage function. To select a different function, simply press
the appropriate key.
To select a function appearing above a key (such as Current), first press the blue shift
key, then press the key below the function.
SYSTEM FUNCTION
Meter
Input
Protect
Trigger
Output
Status
Harmonic
Trigger
Control
Current
Voltage
Freq
Phase
Shape
Pulse
List
Index
Index
Recall
Save
Error
Address
Local
Output
on/off
Phase
Select
FUNCTION
Meter
Input
Protect
Trigger
Output
Status
Harmonic
Trigger
Control
Current
Voltage
Freq
Phase
Shape
Pulse
List
Index
Index
Output
on/off
Phase
Select
NOTE: Pressing Output on/off, Phase Select, or (Shift) + Trigger immediately
implements the function. Display annunciators indicate that an immediate action has
occurred. All other function keys have command menus underneath them that are
accessed via the %and &keys after the function key is pressed. Refer to “The front
panel menus- at a glance”.
Use these keys to move through the command menus of the selected function.
FUNCTION
Meter
Input
Protect
Trigger
Output
Status
Harmonic
Trigger
Control
Current
Voltage
Freq
Phase
Shape
Pulse
List
Index
Index
Output
on/off
Phase
Select
Local
Voltage
%&

Quick Start Guide 9
The following chart shows the commands in the Voltage function menu. Some
commands may not appear on all models. Menus are circular, you can return to the
starting position by continuously pressing %or &.
Key Display Command Function
VOLT <value> Set immediate rms output voltage
VOLT:T <value> Set triggered rms output voltage
VOLT:M FIXED Select the voltage mode
OFFSET <value> Set immediate dc offset voltage
OFFSET:T<value> Set triggered dc offset voltage
OFFSET:M FIXED Select the dc offset voltage mode
RANGE 150 Selects the voltage range
SLEW <value> Set immediate voltage slew rate in volts/second
SLEW:T<value> Set triggered voltage slew rate in volts/second
SLEW:M FIXED Select the voltage slew mode
ALC INT Select the voltage sense source
ALC:DET RMS Select the voltage sense detector
From the Entry key group
Use these keys to increment/decrement or select the command parameters to be
executed. If the parameter is a number, use these keys to make minor changes to the
value. Enter enters the selection and returns to the Meter function.
-
321
0.
789
456
ENTRY
E
Calibration
Enter
Clear Entry
Key Display Description
, , VOLT:M FIXED Sets fixed mode
VOLT:M STEP Sets step mode
VOLT:M PULSE Sets pulse mode
VOLT:M LIST Sets list mode
to Use the numeric Entry keys to directly enter a value for the command parameter. For
example, to enter a value for the voltage parameter:
Key Display Description
VOLT 0 0 volts
, VOLT 60 60 volts
60 V 60 Hz enters the value and returns to the Meter
function
Voltage
&
&
&
&
&
&
&
&
&
&
&
'(
&
Voltage &
(
(
(
9
Voltage
6 0
Enter
1

10 Quick Start Guide
Some basic operations
Make sure the unit is turned on. Use either the front panel keys or the corresponding SCPI commands.
The column on the left indicates the front panel keys that program the indicated action. If the SCPI
programming syntax is substantially different from the front panel menu command, it is shown inside
parentheses ( ).
The text to the right describes the result. If appropriate, the resultant output waveshape is shown
underneath the description.
Enable the output
When the output is enabled, the programmed voltage appears at the output
and the Dis annunciator turns off.
Select the output phase (Agilent 6834B only)
(INST:NSEL)
You can specify phases individually, or you can couple the phases. When
phases are coupled, all three phase annunciators (φ1, φ2, φ3) on the front
panel are on, indicating that commands will be sent to all three phases. Note
that front panel metering is only done one phase at a time (except for the
total power and neutral current measurements).
Set the voltage
VOLT 120
When this command is sent, the output voltage is set to 120 V rms.
120 V rms
0 V
Set the frequency
FREQ 50
When this command is sent, the output frequency is set to 50 Hz.
120 V rms
60 Hz 50 Hz
Output On/Off
Phase Select
Ente
r
0
2
1
Voltage
Enter
Freq
0
5

Quick Start Guide 11
Set the rms current limit (and peak current on Agilent 6811B/6812B/6813B units)
CURR:LEV 10
When this command is sent, the rms current limit is set to 10 A. If more
current than the programmed limit is drawn, the output voltage amplitude is
reduced to keep the rms current within the specified limit. Press Shift
Current and &to access CURR:PEAK, which lets you set the peak
current limit on Agilent 6811B/6812B/6813B units. Note that the peak
current limit circuit on these units acts instantly and clips the output voltage
to maintain the programmed peak limit.
120 V rms
current limit active
NOTE: The rms current limit circuit is slower than the peak current limit circuit and, depending
on the setting of the peak current limit and the load on the output, your unit may generate
momentary peak currents that can well exceed the rms current limit.
Select a waveshape
SHAPE SQUARE
When this command is sent, the output generates a squarewave. Note that
the peak-to-peak amplitude of the squarewave is less that that of a
sinewave when it is programmed to the same rms voltage amplitude.
120 V rms
Program a protection function
CURR:LEV 10
CURR:PROT ON
These commands clear all previously set protection functions and then set
the current protection, which disables the output when an overcurrent
condition is detected. The OCP annunciator will light when this command
is programmed.
0 V
overcurrent detected
Shift
Current
Ente
r
0
1
Ente
r
(
Shape
(
Ente
r
&
Protect
Protect
Ente
r

12 Quick Start Guide
Measuring the output
All measurements are based on acquiring and subsequently processing output waveform information.
When the ac source is on, it takes measurements and updates the front panel meter continuously. The
Meter key accesses the measurement functions from the front panel.
The SCPI MEASure command acquires new waveform information each time it is executed. The SCPI
FETCh command does not acquire new waveform information but extracts the desired information from
previously acquired waveform data. SCPI commands let you measure phases individually or
simultaneously measure all phases using the FETCh command.
Measurement functions
The following example illustrates the measurements that can be returned by the front panel of the ac
source when sourcing power to a typical non-resistive load such as a power supply. The ac source output
voltage and current waveforms are shown on the next page.
NOTE: On Agilent 6811B, 6812B, and 6813B units, the Input key selects the meter coupling
and hence, what the meter will measure. The choices are: AC only, DC only, or AC +
DC.
120V 60HZ rms voltage and frequency
(FETC/MEAS)
120V 1.925A rms voltage and current
1.93A 60HZ rms current and frequency
120V 150.5W rms voltage and power
2.82 CREST F current crest factor
5.379A PK REP peak current, repetitive
36.83A PK NR peak current, non repetitive
230.6VA apparent power
175.2 VAR reactive power
0.65 PFACTOR power factor
Note that in addition to the measurement functions listed above, the Agilent 6834B unit can also measure
total power of all phases and neutral rms current.
Mete
r
&
&
&
&
&
&
&
&
&

Quick Start Guide 13
Harmonic measurements
Use the harmonic menu to make harmonic measurements of the output current. The following example
illustrates the current magnitude measurements returned at harmonics 0 to 5. Note that harmonic 1 is the
fundamental. Harmonic 0 is the dc component.
0.01A I:MAG:0 current amplitude at harmonic 0
(FETC/MEAS)
1.43A I:MAG:1 current amplitude at harmonic 1
0.01A I:MAG:2 current amplitude at harmonic 2
0.91A I:MAG:3 current amplitude at harmonic 3
0.01A I:MAG:4 current amplitude at harmonic 4
0.74A I:MAG:5 current amplitude at harmonic 5
Output voltage and current waveforms
Peak Current
(nonrepetitive)
Peak Current
RMSCurrent
RMS Voltage
0
0
(repetitive)
HarmonicShift
%IndexShift
%IndexShift
%IndexShift
%IndexShift
%IndexShift

14 Quick Start Guide
Programming output transients
Up to now the ac source has been programmed with the transient system in Fixed mode. The following
examples briefly describe the transient system's Step, Pulse, and List modes, which require the application
of a trigger to implement the transient mode.
NOTE: For the examples that follow, press Shift Output, scroll to *RST and press Enter to
reset the unit prior to each example. Also press Enter to enter or activate each selection.
Program an output step
VOLT:M STEP
VOLT 120
VOLT:T 150
INIT IMMED
Step transients transition to a new output level upon receipt of a trigger. When these
commands are sent, the voltage amplitude is stepped from its previous setting to
150 V rms upon receipt of a trigger.
VOLT level
TRIG level
Trigger
Program an output pulse
VOLT:M PULSE
VOLT 120
VOLT:T 90
WIDTH .01
PER .03
COUNT 2
INIT IMMED
Pulse transients transition to a new output level upon receipt of a trigger and return
to the original level after a specified time, repeating this action by the number of
times specified by the count. When these commands are sent, two output pulses
step the voltage amplitude from its previous setting to 90 V rms upon receipt of a
trigger. At the end of the specified period (multiplied by the count), the voltage
returns to its original level.
VOLT level
TRIG level
Width
Period
Trigger Pulse Count
Program an output list
VOLT: M LIST
VOLT 120
DWELL [0] .5
DWELL [1] .5
DWELL [2] .5
VOLT [0] 130
VOLT [1] 140
VOLT [2] 150
STEP AUTO
INIT IMMED
List transients generate complex output sequences. When these commands are sent,
the voltage amplitude is sequentially stepped to three levels upon receipt of a
trigger, and then returns to the original voltage level. The output remains at each list
step for .5 seconds. The values inside the brackets ([ ]) are the list index references.
Use Clear Entry to clear a list.
Trigger
VOLT level Step 0
Step 1
List
Step 2
complete
Trigge
r
Trigger Control
Shift
Voltage
TriggerShift
Trigger Control
Pulse
Voltage
Trigge
r
Shift
Trigger Control
ListShift
Voltage

Quick Start Guide 15
More transient examples
The previous examples showed how the transient system can be used to control the output voltage
amplitude. The transient system can also control output frequency, phase, waveform shape, voltage and
frequency slew rates, offset voltage, and peak current limit. The following examples illustrate how the
transient system's Pulse mode can generate frequency, shape, phase, and voltage slew pulses.
FREQ:M PULSE
FREQ 60
FREQ:T 50
WIDTH .1
INIT IMMED
SHAPE:M PULSE
SHAPE SINE
SHAPE:T SQUARE
WIDTH .05
INIT IMMED
PHASE:M PULSE
PHASE 0
PHASE:T 180
WIDTH .05
INIT IMMED
VOLT:M PULSE
VOLT 120
VOLT:T 150
SLEW:M PULSE
SLEW 10000
SLEW:T 1000
WIDTH .1
INIT IMMED
SHAPE
SHAPE TRIG
width
Trigger
FREQ
FREQ TRIG
width
Trigger
SLEW
SLEW TRIG
width
Trigger
PHASE
PHASE TRIG
width
Trigger
Trigge
r
Shift
Trigger Control
Pulse
Voltage
TriggerShift
Trigger Control
Pulse
PhaseShift
Trigge
r
Shift
Trigger Control
Trigger Control
Pulse
Pulse
Shape
TriggerShift
Freq

16 Quick Start Guide
Programming trigger synchronization and delays
The previous transient examples were programmed to respond to immediate triggers. However, delayed
and phase synchronized triggers can also be programmed as shown in the following examples.
No delay; no phase synchronization
VOLT:M STEP
VOLT 120
VOLT:T 150
DELAY 0
SYNC:SOUR IMM
INIT:IMMED
When these commands are sent, the voltage amplitude changes immediately
upon the receipt of a trigger.
VOLT level
TRIG level
Trigger
No delay; 90 degrees phase synchronization
VOLT:M STEP
VOLT 120
VOLT:T 150
DELAY 0
SYNC:SOUR PHAS
SYNC:PHAS 90
INIT:IMMED
When these commands are sent, the voltage amplitude changes at the next
90 degree phase angle that occurs following the receipt of a trigger.
90 0
VOLT level
TRIG level
Trigger
Trigger delay; no phase synchronization
VOLT:M STEP
VOLT 120
VOLT:T 150
DELAY .0167
SYNC:SOUR IMM
INIT:IMMED
When these commands are sent, the voltage amplitude changes .0167
seconds after the receipt of a trigger.
VOLT level
TRIG level
Delay
Trigger
Trigger Control
Voltage
Shift Trigge
r
Trigge
r
Shift
Trigger Control
Voltage
Trigger Control
Voltage
Shift Trigge
r

Quick Start Guide 17
Trigger delay; 90 degree phase synchronization
VOLT:M STEP
VOLT 120
VOLT:T 150
DELAY .0167
SYNC:SOUR PHAS
SYNC:PHAS 90
INIT:IMMED
When these commands are sent, the voltage amplitude changes at the next
90 degree phase angle that occurs after the .0167 second delay has expired,
following the receipt of a trigger.
VOLT level
TRIG level 90 0
Delay
Trigger
More about the trigger system
In the previous examples, a front panel trigger is used to generate the output transients. The trigger is
shown occurring at 270 degrees but actual triggers may occur at any phase. Delay and phase
synchronization however, will occur as programmed.
Note that trigger system used in the ac source provides great flexibility in generating triggers. The
following figure is a simplified model of the trigger system. A complete discussion of the capabilities of
the trigger system is found in the ac source Programming Guide.
DELAYING STATE
INITIATED STATE
IDLE STATE
TRIGGER RECEIVED
DELAY COMPLETED
INIT:IMMED
WAIT FOR SYNC STATE
OUTPUT CHANGES
PHASE ANGLE OCCURS
Trigge
r
Shift
Trigger Control
Voltage

18 Quick Start Guide
The front panel menus - at a glance
Pressto change the acsource'sselected interface
from remoteoperation to local (front panel)
operation. Pressing the key will have no effect if
the interface state is already Local,Local-with-
Lockout, or Remote-with-Lockout.
Error
Error Functions
ERROR <value> Displays system error codes stored in the SCPI
error queue. If no errors exist, a 0 is displayed.
The Err annunciator is lit when there areerrors.
Address Functions
ADDRESS <value> setsthe GPIB address
INTF GPIB |RS232 selects an interface
BAUDRATE 300 | 600 | 1200
2400 | 4800 | 9600 selects the baud rate
PARITY NONE | EVEN | ODD selects message parity
LANG SCPI |E9012 selectsthe language
NOUTPUTS 1 |3 selects the number ofoutputs1
Save
Save Functions
Pressto save an existing acsource state in nonvolatile memory.
Up to 16 states can be saved (0-15).
Recall Functions
Pressto place the ac source into a previouslysaved state.
Up to 16 states can be recalled (0-15).
First press and release thisblue shiftkey to select
a shifted function. The Shift annunciator lights
when this key is pressed.
Harmonic
Harmonic Functions
<reading>A I:MAG: <index> current harmonic magnitude
<
reading>°I:PHASE: <index> current harmonic phase
<reading>V V:MAG: <index> voltage harmonicmagnitude
<reading>°V:PHASE: <index> voltage harmonic phase
<reading> N:MAG: <index> neutral current harmonic magnitude
<reading>°N:PHASE: <index> neutral current harmonic phase
<reading> CURR:THD current total % harmonic distortion
<reading> VOLT:THD voltage total % harmonic distortion
Meter functions continued on next column
Meter Functions
<reading>V <reading>Hz rms voltage and frequency
<reading>V <reading>A rms voltage and rms current
<reading>A <reading>Hz rms current and frequency
<reading>V <reading>W rms voltage and power
<reading> CREST F current crest factor
<reading>A PK REP peak current, repetitive
<reading>A PK NR peak current, nonrepetitive
<reading>VA apparent power
<reading> VAR reactive power
<reading>W TOTAL total power all phases1
<reading> PFACTOR power factor
<reading>A NEUTRAL neutral rms current1
Output
Output Functions
OUTP:COUP AC | DC select output coupling3
*RST executes the *RST command
TTLT:SOUR BOT| EOT| LIST select Trigger Out source coupling
TTLT:STATE ON | OFF set Trigger Out state
IMP:STATE ON | OFF set output impedance programming3
IMP:REAL <value> set real part of output impedance3
IMP:REAC <value> set reactive part of output impedance3
PON:STATE RST | RCL0 select power-on state command
RI LATCHING | LIVE | OFF sets remote inhibit mode
DFI ON | OFF sets discrete fault indicator state
DFI:SOUR QUES | OPER
ESB | RQS | OFF select the DFI source
Input Functions
INP:COUP AC | DC | ACDC choose meter coupling
CURR:RANGE HIGH | LOW current measurement range3
WINDOW KBESSEL | RECT select harmonic measurement
window meter
Status
Status Functions
*CLS executes the *CLS command
STATUS:PRESET executes STATus:PRESet command
*ESR? <value> returnEvent Status register value
*STB <value> returnStatus Byte register value
OPER:EVEN? <value> returnSTAT:OPER:EVENT? value
OPER:COND <value> return STAT:OPER:COND? value
QUES:EVEN? <value> returnSTAT:QUES:EVENT? value
QUES:COND <value> return STAT:QUES:COND? value
Protect Functions
PROT:CLEAR clears latched protection signal
CURR:PROT ON | OFF set overcurrentprotection function
VOLT:PROT ON | OFF set overvoltageprotection function3
VOLT:PROT <value> set overvoltage protection level
DELAY <value> set a time delayfor activating a
protection fault
Local
Address
Recall
Mete
r
Input
Prot
SYSTEM Keys
FUNCTION Keys
FUNCTION Keys

Quick Start Guide 19
Trigger
Trigger Function
Pressing the Shift Trigger key generates an immediate trigger
Trigger Control Functions
INIT:IMMED Initiate trigger immediately
INIT:CONT ON | OFF Initiate trigger continuously
TRIG:SOUR BUS | EXT
TTLT | IMM Select transient trigger source
DELAY <value> Set trigger delay in seconds
ABORT Abort all trigger sequences
SYNC:SOUR PHASE | IMM Select synchronous trigger source
SYNC:PHASE <value> Set synchronousphase reference
Current
Current Functions
CURR:LEV <value> set immediate rms current limit4
CURR:PEAK <value> set immediate peak current limit3
CURR:PEAK:T <value> set triggered peak current limit3
CURR:PEAK:M FIXED | STEP
PULSE | LIST select the peak current limit mode3
Voltage Functions
VOLT <value> set immediate ac output voltage4
VOLT:T<value> set triggered output voltage4
VOLT:M FIXED | STEP
PULSE | LIST select the voltage mode4
RANGE 150 | 300 set the voltage range2, 4
OFFSET <value> set immediate dc offset voltage3
OFFSET:T<value> set triggered dc offset voltage3
OFFSET:M FIXED | STEP
PULSE | LIST select the dc offset voltage mode3
SLEW <value> set voltage slew inV/sec4
SLEW:T<value> set triggered voltage slew inV/sec4
SLEW:M FIXED | STEP
PULSE | LIST select the voltage slew mode4
OFF:SLW <value> set dc offset slew in V/sec3
OFF:SLW:T<value> set triggered dcoffset slew in V/sec3
OFF:SLW:M FIXED | STEP
PULSE | LIST select the dc offset voltage slew mode3
ALC INT |EXT select the voltage sense source
ALC:DET RTIME | RMS select the voltage sense detector3
Phase
Phase Functions
PHASE <value> set immediate output phase4
PHASE:T <value> set triggered output phase4
PHASE:M FIXED | STEP
PULSE | LIST select the phase mode4
Freq Functions
FREQ <value> set immediate output frequency
FREQ:T<value> set triggered output frequency
FREQ:M FIXED | STEP
PULSE | LIST select the frequency mode
SLEW <value> set frequency slew in Hz/sec
SLEW:T<value> set triggered frequency slew Hz/sec
SLEW:M FIXED | STEP
PULSE | LIST select the frequency slew mode
Shape Functions
SHAPE SINE |SQUARE
CSIN | <user> set immediate shape
SHAPE:T SINE |SQUARE
CSIN | <user> set triggered shape
SHAPE:M FIXED | STEP
PULSE | LIST set shape mode
CLIP <value> set clipping level
List
List Functions
COUNT <value> numberof times a list repeats
DWEL:<index> <value> list of output dwell times
FREQ:<index> <value> list of output frequencies
FSLW:<index> <value> list of output frequency slew rates
IPK:<index> <value> list of output peak current limits3
OFFS:<index> <value> list of dc output voltages3
OSLW:<index> <value> dcoffset voltage slew rate list3
PHASE:<index> <value> list of output voltage phase angles4
SHAP:<index> SINE | SQUARE
CSIN | <user> list of output waveform shapes
STEP ONCE | AUTO set response of list to triggers
TTLT:<index> ON | OFF set trigger out pulse list
VOLT:<index> <value> list of ac output voltages4
VSLW:<index> <value> list of output voltage slew rates4
Pulse Functions
WIDTH <value> set the pulse width
COUNT <value> set the number of output pulses
DCYCLE <value> set the pulse duty cycle
PER <value> set the pulse period count
HOLD WIDTH | DCYCLE set parameter that is held constant
&Index %
%%
%Index
&%Index Functions
These are ShiftIndex keys which areused to scroll through indexed
functions.Press these keys to step through integers 0 through 50 for a
harmonic list, or 0 through 99 forlist points. Hold down these keys to
rapidlyaccess any harmonicor list point.
&%Functions
These keys let you move through the choices in a command list.
Command lists are circular; you can return to the starting position by
continuously pressing either key.
This key applies to 3-phase ac sources only.
Pressing this keysuccessively selects phase 1
first, followed by phase 2, phase 3, and then all
threephases.
This key toggles the output on and off. When off,
the ac source output is disabled and the Dis
annunciator is on.
Trigge
r
Control
Voltage
Freq
Shape
Pulse
!
!!
!"
""
"
Phase
Select
Output
On/Off

20 Quick Start Guide
These keyslet you scroll through choices in a parameter list that apply
to a specific command. Parameter listsare circular; you can return to
the starting position by continuously pressing either key. If the
command has a numeric range, these keys increment or decrement
the existing value.
−The numeric keys 0 through9 are used for
entering numericvalues.
−
Press shift and this key to enter a minus.
Press this key alone to enter a decimal point.
Until you press the Enter key, the values or
parameters you enter with the other Entry
keysare displayed but notentered into the ac
source.
E
Press Shift and this key to enter an exponent.
Clear Entry
PressShift and this key to abort a keypad
entryand clearthe value.When editing a
list, pressing Clear Entry truncates or clears
the list at the presently displayed list point.
Pressthis keyalone to backspace and delete
the last digit entered
Calibration
Press Shift and this key to access the
calibration menu. Refer to appendix B In the
user's for more information.
Notes:
1 Valid for Model Agilent 6834B only
2 Valid for Models Agilent 6814B, 6834B,and 6843A only
3 Valid for Models Agilent 6811B, 6812B,and 6813B only
4 Phase selectable on Agilent 6834B
Documentation Map
Quick Start Guide
(this document) Condensed overview of ac source operation. Read this to quickly get started.
Quick Reference Card Memory jogger for front panel and remote
programming commands. Use this if you are
already familiar with programming ac sources.
User's Guide
(pdf file included on Customer
Care CD-ROM)
Includes description, installation, checkout,
operation, specifications, and calibration.
Programming Guide
(pdf file included on Customer
Care CD-ROM)
Includes introduction to SCPI, command
reference dictionary, and application
examples.
Service Guide
(pdf file included on Customer
Care CD-ROM)
Includes assembly level repair procedures and
detailed schematics.
Localized Quick Start Guides
(pdf files included on
Customer Care CD-ROM)
Available in French, German, Spanish, Italian,
Japanese, Korean, Simplified and Traditional
Chinese.
The web has the most up to date version of the manuals. Go to http://www.agilent.com. Type your model
number (e.g. 6811B) into the Search field on the top of the page and click GO. Scroll down to “Manuals
and Guides”.
To order a printed copy of any of the above manuals, go to http://www.parts.agilent.com. Enter either the
product number (e.g. 6811B) or the part number (e.g. 5962-0883) in the Search Value field on the top of
the page and click Start Search.
'(
90
.
Ente
r
0
)
7
ENTRY Keys
