Agilent Technologies E1468A User manual

Agilent Technologies
E1468A/E1469A
Relay Matrix Switch Modules
User’s Manual
*E1468-90005*
Manual Part Number: E1468-90005
Printed in U.S.A. E1200

3
Contents
E1468A/E1469A Relay Matrix Switch User’s Manual
AGILENT TECHNOLOGIES WARRANTY STATEMENT ............................................7
Safety Symbols............................................................................................................8
WARNINGS .................................................................................................................8
Chapter 1
Getting Started ............................................................................................................11
Using This Chapter ....................................................................................................11
Relay Matrix Switches Description.............................................................................11
E1468A Switch Description ................................................................................11
E1469A Switch Description ................................................................................11
E1468A/E1469A Connector Pin-Outs ................................................................11
Configuring the Relay Matrix Switches ......................................................................15
Warnings and Cautions ......................................................................................15
Setting the Logical Address Switch ....................................................................16
Setting the Status Register Switch .....................................................................16
Setting the Interrupt Priority ................................................................................17
Installing Relay Matrix Switches in a Mainframe ................................................18
Configuring the Terminal Modules..............................................................................20
Wiring the Terminal Modules ..............................................................................20
Creating Larger Matrixes ....................................................................................23
Attaching a Terminal Module to the Relay Switch Module ..................................27
Programming the Relay Matrix Switches...................................................................28
Using SCPI Commands ......................................................................................28
Addressing the Modules ....................................................................................28
Initial Operation ..................................................................................................29
Chapter 2
Using the Relay Matrix Switches ...............................................................................31
Using This Chapter ....................................................................................................31
Relay Matrix Switch Commands/States.....................................................................31
Relay Matrix Switch Commands .........................................................................31
Relay Matrix Switch Query Commands ..............................................................32
Power-on and Reset Conditions .........................................................................32
Relay Matrix Switch Functions...................................................................................33
Checking Module Identification ...........................................................................33
Switching Channels ............................................................................................33
Recalling and Saving States ...............................................................................34
Detecting Error Conditions .................................................................................35
Synchronizing Relay Matrix Switches ................................................................36
Chapter 3
Relay Matrix Switch Command Reference ...............................................................37
About This Chapter ...................................................................................................37
Command Types .......................................................................................................37
Common Command Format ...............................................................................37
SCPI Command Format .....................................................................................37
Linking Commands .............................................................................................39

4
SCPI Commands Reference .....................................................................................39
ABORt........................................................................................................................40
ARM...........................................................................................................................41
ARM:COUNt .......................................................................................................41
ARM:COUNt? .....................................................................................................42
INITiate.......................................................................................................................43
INITiate:CONTinuous .........................................................................................43
INITiate:CONTinuous? .......................................................................................44
INITiate[:IMMediate] ...........................................................................................44
OUTPut......................................................................................................................45
OUTPut:ECLTrg[:STATe] ....................................................................................45
OUTPut:ECLTrg[:STATe]? ..................................................................................46
OUTPut[:EXTernal][:STATe] ................................................................................46
OUTPut[:EXTernal][:STATe]? ..............................................................................47
OUTPut:TTLTrg[:STATe] .....................................................................................48
OUTPut:TTLTrg[:STATe]? ...................................................................................49
[ROUTe:] ....................................................................................................................50
[ROUTe:]CLOSe .................................................................................................50
[ROUTe:]CLOSe? ...............................................................................................51
[ROUTe:]OPEN ...................................................................................................52
[ROUTe:]OPEN? .................................................................................................53
[ROUTe:]SCAN ...................................................................................................53
STATus.......................................................................................................................55
STATus:OPERation:CONDition? ........................................................................56
STATus:OPERation:ENABle ...............................................................................57
STATus:OPERation:ENABle? .............................................................................57
STATus:OPERation[:EVENt]? ............................................................................58
STATus:PRESet .................................................................................................58
SYSTem.....................................................................................................................59
SYSTem:CDEScription? .....................................................................................59
SYSTem:CPON ..................................................................................................59
SYSTem:CTYPe? ...............................................................................................60
SYSTem:ERRor? ................................................................................................60
TRIGger .....................................................................................................................62
TRIGger[:IMMediate] ..........................................................................................62
TRIGger:SOURce ...............................................................................................63
TRIGger:SOURce? .............................................................................................64
IEEE 488.2 Common Commands Quick Reference .................................................65
SCPI Commands Quick Reference ...........................................................................66
Appendix A
Relay Matrix Switch Specifications ...........................................................................67
Appendix B
Register-Based Programming ...................................................................................69
About This Appendix..................................................................................................69
Register Addressing...................................................................................................69
Addressing Overview ..........................................................................................69
The Base Address ..............................................................................................70
Register Definitions ............................................................................................72

5
Reading the Registers ...............................................................................................72
Manufacturer Identification Register ...................................................................72
Device Identification Register .............................................................................73
Status/Control Register .......................................................................................73
Relay Control Registers ......................................................................................73
Writing to the Registers..............................................................................................73
Status/Control Register .......................................................................................73
Relay Control Registers ......................................................................................74
Appendix C
Relay Matrix Switch Error Messages ........................................................................77
Appendix D
Relay Life .....................................................................................................................79
Replacement Strategy................................................................................................79
Relay Life Factors......................................................................................................79
End-of-Life Determination..........................................................................................79
Index ...............................................................................................................................81

6
Notes:

7
AGILENT TECHNOLOGIES WARRANTY STATEMENT
AGILENT PRODUCT: E1468A/E1469A Relay Matrix Switch Modules DURATION OF WARRANTY: 3years
1. Agilent Technologies warrants Agilent hardware, accessories and supplies against defects in materials and workmanship for the period
specified above. If Agilent receives notice of such defects during the warranty period, Agilent will, at its option, either repair or replace
products which prove to be defective. Replacement products may be either new or like-new.
2. Agilent warrants that Agilent software will not fail to execute its programming instructions, for the period specified above, due to
defects in material and workmanship when properly installed and used. If Agilent receives notice of such defects during the warranty
period, Agilent will replace software media which does not execute its programming instructions due to such defects.
3. Agilent does notwarrant that the operation of Agilent products will be interruptedor error free. If Agilent is unable, within a reasonable
time, to repair or replace any product to a condition as warranted, customer willbe entitled to a refund of the purchase price upon prompt
return of the product.
4. Agilent products may contain remanufactured parts equivalent to new in performance or may have been subject to incidental use.
5. Thewarranty period begins on thedate of delivery or on the date ofinstallation if installedby Agilent. If customer schedules or delays
Agilent installation more than 30 days after delivery, warranty begins on the 31st day from delivery.
6. Warranty doesnotapply to defects resulting from (a)improper or inadequatemaintenance or calibration, (b) software, interfacing, parts
or supplies not supplied by Agilent, (c) unauthorized modification or misuse, (d) operation outside of the published environmental
specifications for the product, or (e) improper site preparation or maintenance.
7. TO THE EXTENT ALLOWED BY LOCAL LAW, THE ABOVE WARRANTIES ARE EXCLUSIVE AND NO OTHER
WARRANTY OR CONDITION, WHETHER WRITTEN OR ORAL, IS EXPRESSED OR IMPLIED AND AGILENT
SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OR CONDITIONS OF MERCHANTABILITY, SATISFACTORY
QUALITY, AND FITNESS FOR A PARTICULAR PURPOSE.
8. Agilent will be liable for damagetotangible property per incident up to the greater of$300,000 or the actual amount paid for the product
that is the subject of the claim, and for damages for bodily injury or death, to the extent that all such damages are determined by a court
of competent jurisdiction to have been directly caused by a defective Agilent product.
9. TO THE EXTENT ALLOWED BY LOCAL LAW, THE REMEDIES IN THIS WARRANTY STATEMENT ARE CUSTOMER’S
SOLE AND EXLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL AGILENT OR ITS SUPPLIERS BE
LIABLE FOR LOSS OF DATA OR FORDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL (INCLUDING LOST PROFIT OR
DATA), OR OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE.
FOR CONSUMER TRANSACTIONS IN AUSTRALIA AND NEW ZEALAND: THE WARRANTY TERMS CONTAINED IN THIS
STATEMENT, EXCEPT TO THE EXTENT LAWFULLY PERMITTED, DO NOT EXCLUDE, RESTRICT OR MODIFY AND ARE
IN ADDITION TO THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU.
U.S. Government Restricted Rights
The Software and Documentation have been developed entirely at private expense. They are delivered and licensed as "commercial
computer software" as defined in DFARS 252.227- 7013 (Oct 1988), DFARS 252.211-7015 (May 1991) or DFARS 252.227-7014 (Jun
1995), as a "commercial item" as defined in FAR 2.101(a), or as "Restricted computer software" as defined in FAR 52.227-19 (Jun
1987)(or any equivalent agency regulation or contract clause), whichever is applicable. You have only those rights provided for such
Software and Documentation by the applicable FAR or DFARS clause or the Agilent standard software agreement for the product
involved.
E1468A/E1469A Relay Matrix Switch Modules User’s Manual
Edition 5
Copyright © 1990, 1993-1994, 1996, 2000 Agilent Technologies, Inc. All rights reserved.

8
Safety Symbols
Instruction manual symbol affixed to
product. Indicates that the user must refer to
the manual for specific WARNING or
CAUTION information to avoid personal
injury or damage to the product.
Alternating current (AC)
Instruction manual symbol affixed to
product. Indicates that the user must refer to
the manual for specific WARNING or
CAUTION information to avoid personal
injury or damage to the product.
Indicates the field wiring terminal that must
be connected to earth ground before
operating the equipment — protects against
electrical shock in case of fault.
Direct current (DC).
Warning. Risk of electrical shock.
or Frameorchassisgroundterminal—typically
connects to the equipment's metal frame.
WARNING Calls attention to a procedure, practice, or
condition that could cause bodily injury or
death.
CAUTION Calls attention to a procedure, practice, or
conditionthat couldpossibly causedamageto
equipment or permanent loss of data.
WARNINGS
The following general safety precautions must be observed during all phases of operation, service, and repair of this product. Failure to
comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture, and
intended use of the product. Agilent Technologies assumes no liability for the customer's failure to comply with these requirements.
Ground the equipment: For Safety Class 1 equipment (equipment having a protective earth terminal), an uninterruptible safety earth
ground must be provided from the mains power source to the product input wiring terminals or supplied power cable.
DO NOT operate the product in an explosive atmosphere or in the presence of flammable gases or fumes.
For continued protection against fire, replace the line fuse(s) only with fuse(s) of the same voltage and current rating and type. DO NOT
use repaired fuses or short-circuited fuse holders.
Keep away from live circuits: Operating personnel must not remove equipment covers or shields. Procedures involving the removal of
covers or shields are for use by service-trained personnel only. Under certain conditions, dangerous voltages may exist even with the
equipment switched off. To avoid dangerous electrical shock, DO NOT perform procedures involving cover or shield removal unless you
are qualified to do so.
DO NOT operate damaged equipment: Whenever it is possible that the safety protection features built into this product have been
impaired, either through physical damage, excessive moisture, or any other reason, REMOVE POWER and do not use the product until
safe operation canbe verified by service-trained personnel. If necessary,return the product to Agilentfor service and repair to ensure that
safety features are maintained.
DO NOT service or adjust alone: Do not attempt internal serviceor adjustment unless another person, capable of rendering first aid and
resuscitation, is present.
DO NOT substitute parts or modify equipment: Because of the danger of introducing additional hazards, do not install substitute parts
or perform any unauthorized modification to the product.Return the product to Agilent for service and repair to ensure that safety features
are maintained.
Documentation History
All Editions and Updates of this manual and their creation date are listed below. The first Edition of the manual is Edition 1. The Edition
number increments by 1 whenever the manual is revised. Updates, which are issued between Editions, contain replacement pages to
correct or add additional information to the current Edition of the manual. Whenever a new Edition is created, it will contain all of the
Update information for the previous Edition. Each new Edition or Update also includes a revised copy of this documentation history page.
Edition1 ..........................................November, 1990
Edition2 .............................................. April,1993
Edition3 ..........................................November,1994
Edition4 ........................................... February,1996
Edition5 .......................................... December,2000

9
Manufacturer’s Name: Agilent Technologies, Inc.
Manufacturer’s Address: Measurement Products Unit
815 14th Street S.W.
Loveland, CO 80537 USA
Declares, that the product
Product Name: Relay Matrix Switch Modules
Model Number: E1468A/E1469A
Product Options: This declaration includes all options of the above product(s).
Conforms with the following European Directives:
The product herewith complies with the requirements of the Low Voltage Directive 73/23/EEC and the EMC Directive 89/336/EEC
and carries the CE Marking accordingly.
Conforms with the following product standards:
EMC Standard Limit
IEC 61326-1:1997 + A1:1998 / EN 61326-1:1997 + A1:1998
CISPR 11:1997 + A1:1997 / EN 55011-1991 Group 1, Class A [1]
IEC 61000-4-2:1995+A1998 / EN 61000-4-2:1995 4 kV CD, 8 kV AD
IEC 61000-4-3:1995 / EN 61000-4-3:1995 3 V/m, 80-1000 MHz
IEC 61000-4-4:1995 / EN 61000-4-4:1995 0.5 kV signal lines, 1 kV power lines
IEC 61000-4-5:1995 / EN 61000-4-5:1995 0.5 kV line-line, 1 kV line-ground
IEC 61000-4-6:1996 / EN 61000-4-6:1996 3 V, 0.15-80 MHz
IEC 61000-4-11:1994 / EN 61000-4-11:1994 1 cycle, 100%
Canada: ICES-001:1998
Australia/New Zealand: AS/NZS 2064.1
Safety IEC 61010-1:1990+A1:1992+A2:1995 / EN 61010-1:1993+A2:1995
Canada: CSA C22.2 No. 1010.1:1992
UL 3111-1
Supplemental Information:
[1] The product was tested in a typical configuration with Agilent Technologies test systems.
For further information, please contact your local Agilent Technologies sales office, agent or distributor.
Authorized EU-representative: Agilent Technologies Deutschland GmbH, Herrenberger Straβe 130, D 71034 Böblingen, Germany
Revision: A.03 Issue Date: 09/05/00
September 5, 2000
Date Name
Quality Manager
Title
DECLARATION OF CONFORMITY
According to ISO/IEC Guide 22 and CEN/CENELEC EN 45014

10
Notes:

Getting Started 11
Chapter 1
Chapter 1
Getting Started
Using This Chapter
This chapter gives guidelines to get started using the E1468A and E1469A
Relay Matrix Switch modules (Relay Matrix Switches), including:
•RelayMatrixSwitchesDescription......................11
•ConfiguringtheRelayMatrixSwitches...................15
•ConfiguringtheTerminalModules......................20
•ProgrammingtheRelayMatrixSwitches.................28
Relay Matrix Switches Description
The E1468A and E1469A Relay Matrix Switch modules are VXIbus C-Size
register-based modules and operate with an E1406 Command Module.
EachRelayMatrixSwitchconsistsofacomponent module with 64 two-wire
relays and a terminal module for connecting user inputs. The component
module (E1468-66202) is the same for the E1468A and E1469A. The
terminal module for the E1468A (E1468-90011) and the terminal module
for the E1469A (E1469-80011) are different for the two Relay Matrix Switch
modules.
E1468A Switch
Description The E1468A Relay Matrix Switch module provides an 8 x 8 two-wire
crosspoint matrix. Multiple modules can be wired together creating 8 x 16
(two modules), 16 x 16 (four modules), 8 x 24 (three modules), or larger
matrices. Figure 1-1 shows a simplified schematic of the E1468A
component module and terminal module.
E1469A Switch
Description The E1469A Relay Matrix Switch module provides a 4 x 16 two-wire
crosspoint matrix. Multiple modules can be wired together creating 4 x 32
(two modules), 8 x 16 (two modules), 4 x 48 (three modules), or larger
matrices. Figure 1-2 shows a simplified schematic of the E1469A
component module and terminal module.
E1468A/E1469A
Connector Pin-Outs Each Relay Matrix Switch module consists of a component module and a
terminal module. Figure 1-3 illustrates the front panel of an E1468A/E1469A
component module and the connector pin-out. The terminal module makes
the row and column connection to form the matrix configuration (see Figures
1-1 and 1-2).

12 Getting Started Chapter 1
Figure 1-1. E1468A Simplified Diagram
COMPONENT MODULE
E1468A TERMINAL MODULE
E1468A
Matrix 8 x 8
(E1468-66202) (E1468-80011)

Getting Started 13
Chapter 1
Figure 1-2. E1469A Simplified Schematic
E1469A
COMPONENT MODULE TERMINAL MODULE
E1469A
Matrix 4 x 16
(E1468-66202) (E1469-80011)

14 Getting Started Chapter 1
Figure 1-3. E1468A/E1469A Connector Pin-Out

Getting Started 15
Chapter 1
Configuring the Relay Matrix Switches
This section gives guidelines to configure the Relay Matrix Switch modules,
including:
•Warnings and Cautions
•Setting the Logical Address Switch
•Setting the Status Register Switch
•Setting the Interrupt Priority
•Installing Relay Matrix Switches in a Mainframe
Warnings and
Cautions
WARNING SHOCK HAZARD. Only service-trained personnel who are
aware of the hazards involved should install, remove, or
configure the Relay Matrix Switch modules. Before removing
any installed module, disconnect AC power from the VXI
mainframe and from any devices connected to the Relay
Matrix Wwitch modules.
WARNING CHANNEL WIRING INSULATION. All channels that have a
common connection must be insulated so that the user is
protected from electrical shock in the event that two or more
channels are connected together.
CAUTION Maximum Inputs. The maximum voltage that can be applied to any terminal is 220
Vdc/250 Vrms. The maximum current that can be applied to any terminal is 1A at 30
Vdc/Vrms, or 0.3A at 220 Vdc/250 Vrms. The maximum power that can be applied
to any terminal is 40 VA.
CAUTION Static Electricity. Static electricity is a major cause of component failure.
To prevent damage to the electrical components in a Relay Matrix Switch module,
observe anti-static techniques when removing or installing the module or when
workingonthemodule.

16 Getting Started Chapter 1
Setting the Logical
Address Switch The logical address switch (LADDR) factory setting is 112. Valid addresses
are from 1 to 255. See Figure 1-4 for switch information. The address switch
value must be a multiple of8 ifthe module is the firstmodulein a "switchbox"
used with a VXIbus command module using SCPI commands.
Setting the Status
Register Switch Four bits of the status register switch (bits 10-13) define whether the relay
matrix switch module is an E1468A or E1469A. These bits are set
automatically when the terminal module is installed.
To ensure proper operation, even without the terminal module, set the
status register switch as shown in Figure 1-5. However, if the status register
switch is set for the E1468A, but the terminal module is an E1469A (or
vice-versa), the interface will not be able to correctly identify and an error
will occur.
Figure 1-4. Setting the Logical Address Switch
OPEN=SwitchSetTo0(OFF)
CLOSED=SwitchSetTo1(ON)
128
64
32
16
8
4
2
1
Logical Address
Switch Location
1=CLOSED
0=OPEN
Logical Address = 112
16+32+64=112

Getting Started 17
Chapter 1
Setting the Interrupt
Priority The E1468A/E1469A Relay Matrix Switch modules generate an interrupt
after a channel has been closed. These interrupts are sent to, and
acknowledgments are received from, the command module (such as an
E1406) through the VXIbus backplane interrupt lines.
For most applications where the relay matrix switch module is installed
in a C-Size VXI mainframe, the interrupt priority jumper does not have to be
moved. This is because the VXIbus interrupt lines have the same priority
and interrupt priority is established by installing the modules in slots
numerically closest to the E1406 Command Module. Thus, slot 1 has a
higher priority than slot 2, slot 2 has a higher priority than slot 3, etc..
See Figure 1-6 to change the interrupt priority. You can select eight different
interrupt priority levels. Level 1 is the lowest priorityand level 7 is the highest
priority. Level X disables the interrupt.
The module's factory setting is level 1. To change the priority level, remove
the four-pin jumper from the old priority location and reinstall the jumper in
the new priority location. If the four-pin jumper is not used, the two jumper
locations must have the same interrupt priority level selected.
NOTE The interrupt priority jumper must be installed in position 1 when using the
E1406 Command Module. Level X interrupt priority should not be used
under normal operating conditions. Changing the interrupt priority level
jumper is not recommended.
Figure 1-5. Setting the Status Register Switch
13 10
E1469A
E1468A0
1
10 10 1
0
Example shows
switch set
to "E1468A"
Switch Location
Status Register

18 Getting Started Chapter 1
Installing Relay
Matrix Switches in a
Mainframe
The E1468A/E1469A modules may be installed in any slot (except slot 0)
in a C-Size VXI mainframe. See Figure 1-7 to install a module in a
mainframe.
Figure 1-6. Interrupt Priority Selection
X
X
IRQ
3
6
7
4
5
2
1
IRQ
Using 2-Pin
Jumper
4
Jumper
Using 4-Pin
6
7
5
2
3
1
Priority
Location
Interrupt

Getting Started 19
Chapter 1
Figure 1-7. Installing Relay Matrix Switches in a Mainframe
Slide the E1468/69A into any slot
(except slot 0) until the backplane
connectors touch.
To remove the module from the mainframe,
Tighten the top and bottom screws
to secure the module to
reverse the procedure.
the mainframe.
Levers
Extraction
Set the extraction levers out.
4
1
2
into the mainframe by
Seat the E1468/69A
pushing in the extraction
levers.
3
NOTE: The extraction levers will not
seat the backplane connectors on older
VXIbus mainframes. You must manually
seat the connectors by pushing in the
module until the module's front panel is
flush with the front of the mainframe. The
extraction levers may be used to guide or
remove the module.

20 Getting Started Chapter 1
Configuring the Terminal Modules
This section gives guidelines to configure the E1468A and E1469A terminal
modules, including:
•Wiring the Terminal Module
•Creating Larger Matrixes
•Attaching a Terminal Module to the Relay Switch Module
Wiring the Terminal
Modules Guidelines to wire the E1468A and E1469A terminal modules follow.
E1468A Terminal Module
Connectors Figure 1-8 shows the E1468A terminal module connectors and associated
row/column designators. Shielding jumpers JM1 - JM10 are shown. See
"Creating Larger Matrices" for information on using the expansion
connectors J1 - J4 and for shield wiring details.
NOTE Jumpers JM1 - JM10 on the E1468A terminal module connect row/column
shields to earth ground through the VXIbus backplane. You may want to
remove one or more of these jumpers to reduce common mode noise.
Figure 1-8. E1468A 8 x 8 Matrix Switch Terminal Module
Column
Connector Connector
Row
Column Expansion
Connector
*
Column Input
Connector Row Input Connector Row Expansion Connector Shield Connector
TB5
***
In parallel with the screw terminals.
*
