Multi-Tasker MT107-100 User manual

MULTI-TASKER™
MANUAL PART NUMBER: 400-0351-002
64X64 MATRIX SWITCHER
FOR MULTI-TASKER™
USER’S GUIDE
MT107-100

MULTI-TASKER™
1
TABLE OF CONTENTS
Page
PRECAUTIONS / SAFETY WARNINGS ..............2
GENERAL..........................................................2
INSTALLATION .................................................2
CLEANING.........................................................2
FCC /CE NOTICE..............................................2
ABOUT YOUR MT107-100...................................3
TECHNICAL SPECIFICATIONS...........................3
PRODUCT DESCRIPTION ..................................4
APPLICATION DIAGRAM ....................................5
DIAGRAM 1: TYPICAL CONFIGURATION ........5
DIAGRAM 2: OUTPUT CARD SWITCHES.........6
DIAGRAM 3: ADD ON CARD SWITCHES..........7
DIAGRAM 4: INTERNAL VIEW .........................8
INSTALLING YOUR MULTI-TASKER™...............9
OPERATION ........................................................9
RS-232 CONTROL.............................................9
DESCRIPTION OF COMMANDS .......................9
SUMMARY OF COMMANDS ...........................17
TROUBLESHOOTING GUIDE ...........................18
LED IS NOT LIT ...............................................18
LED IS BLINKING RED ....................................18
NO DISPLAY....................................................18
ALTINEX POLICY ..............................................19
LIMITED WARRANTY/RETURN POLICY ........19
CONTACT INFORMATION ..............................19

MULTI-TASKER™
2
PRECAUTIONS / SAFETY WARNINGS 1
Please read this manual carefully before using your
MT107-100. Keep this manual handy for future
reference. These safety instructions are to ensure
the long life of your MT107-100 and to prevent fire
and shock hazard. Please read them carefully and
heed all warnings.
1.1 GENERAL
•Qualified ALTINEX service personnel, or their
authorized representatives must perform all
service.
1.2 INSTALLATION
•To prevent fire or shock, do not expose this unit
to rain or moisture. Do not place the MT107-100
in direct sunlight, near heaters or heat radiating
appliances, or near any liquid. Exposure to
direct sunlight, smoke, or steam can harm
internal components.
•Handle the MT107-100 carefully. Dropping or
jarring can damage the card.
•Do not pull the cables that are attached to the
MT107-100.
•Insert the card carefully into the slots of the
Multi-Tasker™ without bending any edges.
1.3 CLEANING
•Clean only the connector area with a dry cloth.
Never use strong detergents or solvents, such
as alcohol or thinner. Do not use a wet cloth or
water to clean the card. Do not clean or touch
any component or PCB.
1.4 FCC / CE NOTICE
•This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
•This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial
environment. This equipment generates, uses,
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications. Operation
of this equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the interference
at his own expense.
•Any changes or modifications to the unit not
expressly approved by ALTINEX, Inc. could void
the user’s authority to operate the equipment.

MULTI-TASKER™
3
ABOUT YOUR MT107-100 2
MT107–100
64 X 64 Matrix Engine 300MHz
The MT107-100 is a 64x64 Matrix Engine used for
connecting audio and video signals. The Matrix
Engine has a built-in 8 video inputs and 8 video
outputs. Additional inputs and outputs can be
added using Input and Output video card, which
are mounted to the engine with the specially
provided high bandwidth video cables. Input and
Output connector cards are available for Video
and/or Audio inputs and outputs.
Video Input signals are buffered to the matrix
system through individual Ground Loop Isolation
Amplifiers. The video amplifier can be used for
either video or sync signals.
All control of the Matrix Engine is maintained
through the MultiTasker enclosure.
A video signal detection circuit is present on all
Inputs and Outputs in order to make
troubleshooting easier.
The VIS (Vertical Interval Switching) is a standard
feature on the MT107-100 and can be turned ON
or OFF from RS-232 port.
The Matrix Engine could be easily configured to the
customer requirements by selecting appropriate
number of switching elements. The proper
selection of configuration can be achieved using
MTSetup. The switching elements within the Matrix
Switcher are available in steps of 16. This is
possible through the modular design of the Matrix
Engine with switching elements blocks of 16x16.
The video output option default configuration is for
analog video or sync. A small slide switch is
provided for TTL Sync option.
TECHNICAL SPECIFICATIONS 3
FEATURES/
DESCRIPTION MT107-100
GENERAL
Inputs 8
Input Connectors 8 BNC Female
Outputs
Output Connector 8 BNC Female
Compatibility
Signal types RGBHV,RGBS,RGsB,
Composite Video, Sync
Signal resolution VGA through UXGA
Table 1. MT107-100 General
MECHANICAL MT107-100
Enclosure Slots Required
Base Configuration 2 Slots
Enclosure Slots Required
Add On Cards 1 Slot per Card
Weight 1.1 lb (0.5 kg)
Connector Panel Black Anodized
T° Operating 10°C-50°C
T° Maximum 75°C
Humidity 90% non-condensing
MTBF (calc.) 50,000 hrs
Table 2. MT107-100 Mechanical
ELECTRICAL MT107-100
Video Input Signals R,G,B
Impedance Analog 75 Ohms
Analog Signal Level 1.5V p-p max.
Sync Input Signals H,V
Impedance 10 kOhm
Signal Level 3 - 5 Volts TTL
Output Video Signals
Impedance Analog 75 Ohms
Gain 1.05
Bandwidth 270 MHz @ -3dB
Output Sync Signals
Impedance 75 Ohms
Signal Level 4.5 Volts TTL
Table 3. MT107-100 Electrical

MULTI-TASKER™
4
PRODUCT DESCRIPTION 4

MULTI-TASKER™
5
