Link electronics 816-OP/D User manual

816-OP/F Unbalanced BNC Panel
800 SERIES
816-OP/E Balanced Connector Panel
AES Audio Switching Matrix
LINK ELECTRONICS, INC.
AES AUDIO SWITCH MATRIX
MODEL 816-OP/D
TheAVS-816haseightoptionstoconfiguretheunittobe Analog, SD/SDI or HD/SDIfor Video and Audio. The
audiocan be configured for AES or Analog. The 816-OP/D is the AES/EBU audio plug-in board. TheAVS-816
chassis and the 816-OP/D board make up an AES/EBU audio only switcher. NOTICE, you must choose the
rearconnectoroptionforBNCorBalanced.Options816-OP/FistheBNCunbalancedinput.Option816-OP/E
is the balanced 3-Pin connector.
You must select the AES audio matrix and video matrix to make up the desired switcher format. You have the
choice of analog or AES audio. In the case of AES audio, you have the option of BNC unbalanced or Plug-in
3-pin Weco balanced connectors. You can choose the 816-OP/D, AES plus the connector board for an audio
switcher only. The AES matrix has one AES output and one analog output for monitoring.
Software is supplied with all AVS series to control up to 32 switchers from a single computer. See data sheets
for the AVS-816/SA analog switcher and AVS-816/SD for SD SDI system switcher. A remote control is
available for the unit, model PSR-816. The plug-in choices are:
AVS-816, Chassis, power supply and motherboard
816-OP/A, Analog video matrix, 16X1, two outputs
816-OP/B, Analog audio matrix, 16X1, two outputs
816-OP/C, SD SDI video matrix, 16X1, one SD SDI and one analog
816-OP/D, AES audio matrix, 16X1, one AES and one analog
816-OP/E, AES rear panel for Weco 3-pin connectors
816-OP/F, AES rear panel for BNC connectors
816-OP/G, GPI option
816-OP/HD, HD/SD SDI video matrix, 16X1, two outputs
Customer selects the above desired options, and the factory configures to your requirement.
LINKELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]
MADE IN THE USA

When configured, the chassis should look like this photo
MODEL 816-OP/D AES AUDIO SWITCHING MATRIX
SPECIFICATIONS
AES AUDIO INPUTS:
Number: ......................................................................... 16
Interface:..................................................................AES3-1992
Connector: .................................................... BNCor3PinTerm.Plug-in
Format..........................................................Bi-PhaseMarkEncoded
Impedance: ................................................................. 110Ω±1%
Coupling:................................................................. Transformer
Level:.................................................................. 4.2VppTypical
Sample Freq. Range: ...................................................30KHzto50KHz
AES OUTPUTS:
Number: ...........................................................One,DigitalonBNC
............................................... One,AnalogforMonitoring,3pinconnector
Interface: ..................................................................AES3-1992
Connectors: ...............................................BNCor3PinPlug-inTermBlock
Format: .........................................................Bi-PhaseMarkEncoded
Impedance: .................................................................110Ω±1%
Coupling:................................................................. Transformer
Level:.................................................................4.2VP-PTypical
MECHANICAL:
Size:
Height:....................................................................... 1.375 "
Width: ........................................................................ 6.25"
Depth: .......................................................................... 7.0"
Weight: ....................................................................... 8.5oz
ENVIRONMENTAL:
Temperature:........................................................ 0°to50°C,ambient
Humidity: ..................................................... 0%to90%non-condensing
POWER:
Input: .......................................................120/240 VAC ±10% 50/60 Hz
Power:........................................................................ 8VAR
Ordering Information
AVS-816 Chassis
816-OP/A, Video Mstrix
816-OP/B, Audio Matrix
816-OP/C, SDI Video Matrix
816-OP/D, AES Audio Marix
816-OP/E, AES Balanced Connector Panel
816-OP/F, Unbalanced BNC Connector Panel
816-OP/G, GPI Option
816-OP/HD, HD/SD SDI Video Matrix
LINKELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]
