AGOSTANI Tuttocialde SMALL CUP User manual
User manual
SMALL CUP
8. Drip tray
7. Cup support grid
6. Used capsule
drawers (max. 8)
5. Coee dispenser
1. Agostani Small Capsules
loading lever
11. Power
button
2. Restart button after Stand by
3. Espresso coee button
4. Long coee button
9. Water tank
cover
10. 0.85 liters
water tank
2
Index:
Safety precautions 4
General information 4
First use 5
Coffee preparation 6
Regulation of the coffee level 6
Coffee temperature adjustment 7
Restore factory settings 8
Machine descaling 8
Water softener 8
Troubleshooting 9
Specs 10
Disposal 10
Warranty 10
Service center 11
Figure A Figure B Figure C
3
Height-adjustable cup supporting grid
Safety precautions
• Connect the appliance only to mains grounded suitable con-
nections. Using incorrect connections voids the warranty.
• Remember not to position the power cable near sharp edges.
• Keep the appliance away from heat sources.
•
Please do not use the appliance in the case of bump damages.
• Do not open the appliance: danger of electric discharge.
• Do not insert any object into the openings of the appliance,
danger of fire or electric discharge.
• Do not insert your fingers into the openings of the appliance:
danger of burns.
• Use the appliance only with a full water tank.
• This appliance uses ONLY Agostani Small capsules. The cap-
sules can only be used once.
• Please keep these instructions.
General Indications
1. Agostani Small Capsules loading lever.
2. Restart button after Stand by.
3. Espresso coffee button.
4. Long coffee button.
5. Coffee dispenser.
6. Recovery tray 8 used capsules.
7. Cup supporting grid.
8. Drop collection tray.
9. Water tank cover.
10. 0.85 liters water tank.
11. Power button. General Indications.
4
First use
1. Place the machine on a at and stable surface, away from
water and heat sources.
2.
Remove the protective plastic lm from the drop collection tray.
3. The water tank must be removed from the machine, rinsed
and lled with drinking water.
4. Turn on the machine with the power button 11.
5. When all 3 buttons feature a steady blue light,
the machine has reached the right temperature and is ready
for use.
6. Do not insert the capsule and press the dispensing button
for long coffee 4: the spout 5 will deliver hot water.
7. In case of no water supply, please repeat point 6.
8. Open capsules loading lever (see gure A).
9. Please insert Agostani Small capsules only (see Figure B).
10. Close the lever (see gure C).
11. Press the coffee dispensing button 3 or 4
12. Once the coffee has been delivered, please open and close
lever 1 to place the capsule into the appropriate capsule
holder 6.
13. After 25 minutes of inactivity, the machine switches automat-
ically to energy-saving mode (standby mode). Please press
button 11 and when not in use for a longer period.
5
Coffee preparation
1. Press the Standby button 2 and see the lights ashing.
2. When all 3 buttons feature a steady blue light,
the machine has reached the right temperature and is ready
for us.
3. Open capsules loading lever 1 (gure A).
4. Please insert Agostani Small capsules only (see Figure B).
5. Close lever 1 (gure C).
6. Press the coffee dispensing button 3 or 4
7. Once the coffee has been delivered, please open and close
lever 1 to place the capsule into the appropriate capsule
holder 6.
Note: The machine will automatically switch to power save mode,
after 25 minutes.
Coffee level adjustment
1. Exit stand-by by pressing button 2
2. When all 3 buttons feature a steady blue light,
the machine has reached the right temperature and is ready
for adjustment
.
3. Open the capsules loading lever 1 (gure A).
4. Please insert only Agostani Small capsules (gure B).
5. Close the lever (see gure C).
6. Press and hold the button you want to adjust 3
or 4
7. The machine pump starts up after about 5 seconds: please
keep holding the button down.
8. Release the button when the desired coffee level has been
reached.
6
Coffee temperature adjustment
1. Exit stand-by mode by pressing button 2
2. When all 3 buttons feature a steady BLUE light,
press and hold button 2 (stand by) for 5 seconds until it
becomes RED.
3. The factory-set temperature is 88 ° C
4. Raise the temperature to 90 ° C by holding down button 4
(long coffee) for 5 seconds until the light ashes RED
once.
5. To increase the temperature to 2° C, please hold button 4
(long coffee) for 5 seconds until the RED light ashes
twice.
6.
To lower the temperature to 86° C, please hold the button 3
(Espresso coffee) for 5 seconds until the RED light ashes
twice.
7.
To lower the temperature to 2° C, please hold the button 3
(Espresso coffee) for 5 seconds until the RED light ashes
twice.
8. Drip tray
7. Cup support grid
6. Used capsule
drawers (max. 8)
5. Coee dispenser
1. Agostani Small Capsules
loading lever
11. Power
button
2. Restart button after Stand by
3. Espresso coee button
4. Long coee button
9. Water tank
cover
10. 0.85 liters
water tank
5"
TO LOWER THE TEMPERATURE
HOLD THE
BOTTOM FOR
8. Drip tray
7. Cup support grid
6. Used capsule
drawers (max. 8)
5. Coee dispenser
1. Agostani Small Capsules
loading lever
11. Power
button
2. Restart button after Stand by
3. Espresso coee button
4. Long coee button
9. Water tank
cover
10. 0.85 liters
water tank
5"
TO INCREASE THE TEMPERATURE
HOLD THE
BOTTOM FOR
7
Factory reset
(temperatures and doses)
1. Exit stand-by mode by pressing button 2
2. When all 3 buttons feature a steady blue light,
simultaneously press button 3 (espresso coffee) and 4
(long coffee) for 10 seconds.
3. The blue lights of buttons 3 and 4 will ash 3 times
to signal the factory reset has been performed.
Descaling
1. Please use only specic descaling products for coffee ma-
chines.
2. We recommend descaling once a month to prevent the
formation of limescale.
3. Dissolve the contents of the descaling sachet inside the wa-
ter tank.
4. Dispense the entire water tank without inserting any coffee
capsule.
5. Rinse the water tank well and ll it with water drinking.
6. Dispense the entire water tank without inserting any coffee
capsule.
Water softener
We recommend using a universal softener lter in the water tank
to protect the machine and improve the taste of coffee.
8
Troubleshooting
The machine does not turn on Check the power cable, the correct
insertion of the plug, and the electricity
in the electrical outlet.
Check the main power switch
(bottom 11)
The machine does not dispense
Check that the tank is full of water
and correctly positioned (remove and
reposition).
Coffee does not get hot enough
Preheat the cups with hot water.
Change the coffee temperature as indi-
cated in the manual on page 7.
Descaling as indicated in the manual on
page 8.
The door does not open Please turn off the machine and wait
for a few minutes: as it cools down, the
pressure decreases, then try to open
again.
The machine is noisy Check that the tank is full of water
and correctly positioned (remove and
reposition).
The machine switches off The machine switches off after 25 min-
utes of inactivity, thus reducing energy
consumption.
All the lights ash Turn off the machine, wait for 1 minute
and turn it on again.
Stuck capsule Switch off the machine, empty the used
capsule drawer, open and close the
door.
If the problem could not be solved,
please contact Agostani srl assistance
to the number +39 0341/530409 or on
WhatsApp at + 39 3456210066
Presence of coffee grounds Please use exclusively Agostani Small
capsules: this machine is not compati-
ble with other caps.
9
Specs
Model Small Cup
Size width 140 mm
depth 370mm
height 288mm
Weight 3.3 kg
Capacity of the water tank 0,85 liters
Pump pressure 19 Bar
Power supply 220-240V/50Hz
Power 1100 Watt
Authomatic shutdown after 25 minutes
Disposal
The machine is made with top-quality materials that can be re-
used or recycled. Please deposit the device in a specic collec-
tion center. Local authorities provide information on disposal.
Warranty
Agostani srl warrants this product against any defects of manu-
facture or materials for two years from the date of purchase.
During this period (*legal guarantee), Agostani SRL will repair or
replace the appliance free of charge if a defect is found, at its
sole discretion.
Replaced products or xed components will be warranted only
for the part of the original warranty which has not expired or for
the following six months, depending on which one is longer.
Within the limits and terms of the law in force, this guarantee is
not valid for defects caused by damage, incorrect use, inade-
quate maintenance, or natural wear and tear.
10
The conditions of this warranty do not exclude, reduce or modify
the provisions of current law applied to the sale of the product.
If you believe that the product is defective, please contact
the Agostani srl assistance center at the telephone number
Service center
Please contact Agostani srl at the telephone number
11
Distributed by AGOSTANI SRL
Viale Lombardia, 4/1 - 23847 Molteno (Lecco)
Tel. 0341 530409
