FOREWORD
This manual contains information, such as technical parameters, safety information,
operation, lubrication, maintenance, adjustment and Accidents check guidelines which is
primarily for the operator and the maintenance crew.
The operator should read this manual carefully before operating or working on the
excavator. Only after you are familiar to the information of this manual that you are allowed
to operate the Excavator.
Be careful adherence to these safety guidelines during operation, check and maintenance.
Important safety notes such as DANGER, CAUTION or NOTE are used throughout this
manual to emphasize important or critical instructions. Please pay more attention to them.
The Excavator XN75-9 can be widely used to dig, to clean the ditch, to break the stone,
to load and to lift in the construction of water conservancy works, farming & forestry
construction, municipal engineering projects, road building, architecture, water supply, gas
supply, docks and goods yards.
Please take notice that we can not honor any claims which could arise due to careless
handling, improper operation, inadequate maintenance, use of unauthorized oils or lubricants,
non-observance of the safety instructions, etc.
We reserves the rights to cancel any warranty claims, service contracts etc. without prior
notice if any other than Original parts or parts sold by us are being used for maintenance and
repair.
Shandong Rhinoceros Engineering Machinery Co., Ltd reserves the rights to revise the
specifications and charts in this manual according to the necessary technical improvement.
Publication or issue this manual is prohibited without the permission of Shandong
Rhinoceros Engineering Machinery Co., Ltd.
This Operation and maintenance manual contains all necessary information to operate
and maintain Hydraulic Excavator XN75-9. However, should you need additional information
or explanations, please contact Marketing Department or Customer Service Department of
Shandong Rhinoceros Engineering Machinery Co., Ltd.
https://tractormanualz.com

2
INDEX
I.MACHINE DESCRIPTION AND TECHNICAL DATA
Machine description, technical data…………………………………………………….1
Ⅱ.SAFETY INFORMATION
General safety information……………………………………………………………….5
Crushing and burn prevention……………………………………………………………6
Fire and explosion prevention……………………………………………………………7
Machine start up safety……………………………………………………………..……8
Machine operating safety………………………………………………………….….….8
Machine parking safety……………………………………………………………….….10
Machine transportation safety……………………………………………………………10
Machine towing safety…………………………………………………………….….….11
Machine maintenance safety……………………………………………………………..11
Hydraulic pipeline…………………………………………… …………………………12
Additional safety guideline for cabin……………………… …………………………...13
Signs on the hydraulic excavator…………………………… …………………………..13
Ⅲ.OPERATION AND CONTROL
Parts position……………………………………………………………………………...15
Cab………………………………………………………………………………………...16
Instrument panel …………………………… …………………………………… ……...21
Keyset ………………………………………………………………… ………… ….…..24
AC system …………………………………………………………………………………26
Sound system ………………………………………………………………………….…..28
Seat adjustment …………………………………………………………………………….29
Front window ………………………………………………………………………….…..30
Grinding-in new machine …………………………………………………………………..32
Starting and stopping …………………………………………………… …………….…..33
Walking …………………………………………………………………… ……………...44
Operating instructions ……………………………………………………………………...50
Ⅳ.LUBRICATION
General safety information………………………………………………………………….59
Lubricant and fuel specifications……………………………………………………………60
Checking coolant level………………………………………………………………………61
Changing oil in travel gear…………………………………………………………………...62
Lubrication of the swing ring teeth……………………………………………………….…63
Lubrication of attachment bearing points……………………………………………………63
To drain and add oil to the hydraulic tank……………………… …………………………..64
Ⅴ.MAINTENANCE
https://tractormanualz.com

3
Maintenance principles of the excavator………………………………………………..66
Fuel system………………………………………………………………………………66
Air filter………………………………………………………………………………….67
Undercarriage……………………………………………………………………………68
Checking mounting screws for tightness………………………………………………...69
Hydraulic system………………………………………………………………………...69
The electrical system…………………………………………………………………….70
The swing and travel brake……………………………………………………………...71
Adjusting the clearance of the bucket…………………………………………………...72
Replacing wear and tear items…………………………………………………………..72
Maintenance schedule…………………………………………………………………...72
Ⅵ.TROUBLE ANALYSIS GUIDELINE
Engine trouble…………………………………………………………………………...76
Trouble of electrical system……………………………………………………………..76
Others……………………………………………………………………………….…...77
https://tractormanualz.com

1
Ⅰ. MODELAND TECHNICAL SPECIFICATIONS
Engine
Model YC4F60Z-T10
No. of cylinders Vertical, Water-cooled,4 Stroke, In line
Bore and stroke 92x100 mm
Displacement 2.66L
Rated power 43Kw/2200rpm
Max. torque 215N.m/r/min
Fuelconsumption <230g/kwh
Oilconsumption <2 g/kwh
Travelsystem
Travel motor Type Variable axial piston motor
Low speed 2.9 km/h
High Speed 3.2km/h
Travel brake hydraulic disc brake
Parking brake Oilrelease
No. of track shoes 2x43
Travel speed 2.9/4.2(Km/h)
Grade ability 30°
nd
clearance 260mm
Hydraulicsystem
Hydraulic pump Imported from Korea
Type Axial Plunger Pump/gear pump
Max. discharge flow 2x79(L/min)
Pilot control pump Gear pump
Main control valves Negative flow control system
Oil cooler Air cooler
Max. work pressure
Boom, arm and bucket 25Mpa
Travel circuit 25Mpa
Swing circuit 20Mpa
https://tractormanualz.com

2
Swingsystem
Swing motor type Swash plate-piston motor
Brake Oilrelease
Parking brake Hydraulic disc
Swing speed 10~13rpm
Tail swing radius 2700mm
Cab controls
Cab New ergonomic cab, which strengthens the structure
of the entire stamping, with the feature: strong
impact resistance, vibration damping pads, absorbing
vibration, comfortable with broad vision, using of
leather dermatoglyphics ABS+PVC plastic
Technology inside it, smooth lines of the outer
surface, sturdy and durable.
Way of control Two hand levers and two foot pedals for travel
Throttle: hand control
Boom, Arm Bucket
Boomcylinder 80/50-750X1060 (mm)
Stick cylinder 100/63-880X1240(mm)
Bucket cylinder 90/50-600X925(mm)
Bulldozing Cylinder 105/60-193X536(mm)
Refilling capacity &
lubrications
Main Pressure P1 P2 P3
28 Mpa 28 Mpa 3.5 Mpa
Displacement 75 L/min 75 L/min 18-20 L/min
Fuel tank 115L
Cooling system 10L
Engine oil 9L
Travel reduction gear box 2x5.4L
Swing reduction gear box 4L
https://tractormanualz.com

3
Volume of Hydraulic tank/ system 120L/420L
Bucket
Mode backhoe bucket
Capacity 0.3m³
No. of teeth 6
Width of bucket 651mm
Digging force
BoomLength 3250 mm
Arm length 2000mm
Bucket digging force 115KN
Arm digging force 92.5KN
Operating weight ,ground pressure
shoe width 420mm
Material Metal
Tensioning control type Grease
Overall width 2090mm
Ground pressure 0.37Kgf/cm2
Operating weight 7500Kg
Dimension and working range
Length 6400 mm
Width 2090 mm
Height 2690 mm
Dozer Blade Wide, Length 2030x390 mm
Height of max. clearing
range
320 mm
Working Range Boom Length 3330 mm
Bucket Arm Length 2000 mm
Max.excavating range 6430 mm
Max.excavating depth 3850 mm
Max.excavating height 5950 mm
Max.loading height 4320 mm
Capacity of bucket 0.24-0.3 CBM
https://tractormanualz.com

4
Normal operating range
https://tractormanualz.com

5
Ⅱ.SAFETY INFORMATION
Working with an Excavator can be dangerous; it could result in injury or death if proper
precautions are not taken! We urgent you to read this manual carefully! This safety
information is provided to operators and maintenance mechanics to ensure the safe operation
and maintenance of the Excavator. It’s essential that you read and familiarize yourself with
this information, which explains safety requirements and precautions and specific hazards of
which you should be aware. This also applies to any personnel which might be working on
the machine only occasionally. Such as during set up or maintenance.
Careful adherence to safety guidelines will permit safe operation and maintenance and
potentially prevent personal injury to yourself and others, and possible damage to the
excavator.
Important safety notes such as DANGER, WARNING or IMPORTANT are used
throughout this manualto emphasize important or critical instructions.
In this manual DANGER, CAUTION or NOTE are defined as follows:
DANGER: denotes an extreme intrinsic hazard which could result in a high probability of
death or serious injury if proper precautions are not taken.
WARNING: denotes a reminder of safety practices or directs attention to unsafe practices if
proper precautions are not taken.
NOTICE describes operation and maintenance procedures which should be followed to keep
your excavator operation and to insure long machine life and /or to facilitate certain
procedures.
DESTINED USE
Destined use is considered part of observing and adhering to all regulations and inspection
and maintenance guidelines given in this Operation and Maintenance Manual.
The excavator with the standard backhoe any only be used to loosen, pick up, move, load and
dump soil, gravel, rock, or other material and to load trucks, barges, conveyor belts, or rock
crushing system.
Special guidelines are applicable for machines used for lifting applications and special safety
devices must be installed.
Any other use above and beyond the applications described above, such breaking out rock or
demolishing building, pounding in posts etc. requires special attachments and safety devices.
If the machine is exposed to the risk of falling down objects during operation, the cab of the
machine must be fitted with a safety device.
Transporting personnel or loads etc. is not considered destined use and is therefore prohibited.
The manufacturer/dealer is not responsible for any resulting damage. Any risk must be
carried by the user himself.
https://tractormanualz.com

6
GENERALSAFETYINFORMATION
Study the Operation and Maintenance Manual before operating or working on the excavator.
Make sure that you have additional information for special attachments of your machine, read
it and understand it!
Allow only authorized personnel informed about the safety rules to operate, service or repair
the excavator.
Allow only properly trained personnel to operate or work on the excavator, make sure to
clearly specify the person who is responsible for set up, maintenance and repairs.
Make sure the operator knows his responsibility regarding the observance of traffic
regulations and permit him to refuse any unsafe instructions given by a third person.
Any persons still in training should only operate or work on the machine under the
supervision and guidance of an experienced person.
Check and observe any person working or operating the excavator periodically and regularly,
if they observe safety instructions and guideline given in the Operation and Maintenance
Manual.
Wear proper work clothing when operating or working on the excavator .Ring , watches,
bracelets and loose clothing such as ties, scarves, unbuttoned or unzipped shirts and jackets
are dangerous and could cause injury! Wear proper safety equipments , such as safety glasses,
safety shoes, hardhats, work gloves, reflector vests and ear protection.
Always tilt up the safety lever before leaving the operator’s seat. Do not carry tools,
replacement parts or other supplies while climbing on or off the excavator. Never use the
steering column, control lever or joysticks as handholds. Never jump off the excavator, climb
on or off the excavator using only the steps, rails and handles provided.
When climbing on or off the excavator, use both hands for support and face the machine. If
needed, use the front window as an escape hatch.
If no other guidelines are given, perform maintenance and repairs utilizing the following
precautions:
Parking excavator on firm and level ground. Rest the working attachment on the ground.
Placing all control in neutral position and raise the safety lever.
Turning the engine off and remove the ignition key.
Before checking the hydraulic circuit, move all joysticks and pedals with the ignition key in
contact position to relieve the servo pressure and the remaining pressure in the different main
circuits. In additions, relieve the pressure in the hydraulic tank as described in the Operation
and Maintenance Manual.
Never operation the excavator without a complete walk around inspection. Check if all
warning decals are on the machine and if they are all legible.
Secure all loose parts on the excavator.
Observe all danger and safety guidelines.
For certain special applications, the excavator must be equipped with specific safety
equipment. Use the excavator only, if they are installed and functioning properly.
Never perform any changes, additions or modifications on the machine, which could
influence the safety, without obtaining the written permission from the manufacturer. This
also applies to the installation and adjustment of safety device and safety valve as well as to
any welding on load carrying parts.
https://tractormanualz.com

7
Do not install any equipment or attachments made by other manufacturers or any which are
not specifically authorized by Shandong Kadekor Power Machine Co.,Ltd for installation
without first obtaining the written permission from Shandong Kadekor Power Machine
Co.,Ltd.
Never work underneath the excavator unless it is safely resting on the ground and /or is
properly blocked and supported and /or it is properly blocked and supported.
Never use damaged or insufficient wire ropes, sling or chains. Always wear gloves when
handling wire ropes.
Never reach into bore during attachment installation or removal. Never align bores with your
fingers or hands. Use proper alignment tools when installing, changing or servicing
attachments.
Keep objects away from the radiator fan. Rotating fans will swirl and throw out objects,
which can become very dangerous and cause severe injury to yourself and others.
Avoid contact with any components containing coolant. At or near operating temperature, the
engine coolant is hot and under pressure and could cause severe burns.
Check the coolant level only after the radiator cap is cool enough to touch. Remove the
radiator cap slowly to relieve pressure.
Do not allow your skin to come into contact with hot oil or components containing hot oil. At
or near operating temperature, engine and hydraulic oil is hot and can be under pressure.
Always wear safety glasses and protective gloves when handling batteries. Keep sparks or
open flames away!
Never permit anyone to hand guide the bucket or grapple into position.
When working in the engine area, make sure the top covers and side doors are properly
secured or closed with the appropriate supports.
FIREAND EXPLOSION PREVENTION
Always turn off the engine while refueling the excavator.
Never smoke or allow an open flame in refueling area or where batteries are being charged,
or where batteries or flammable materials are stored.
Always start the engine as described in the Operation and Maintenance Manual. Check the
electrical system regularly and frequently. All defects, such as loose connections, burnt out
fuses and bulbs, burnt or damaged cables must be repaired immediately by an electrician or
especiallytrained personnel.
Never store flammable fluids on the machine except in storage tanks intended for the
Excavator’soperation.
Inspect all components, lines, tubes and hoses for oil and fuel leaks and/ or damage. Replace
or repair any damaged components immediately. Any oil, which escapes from leaks, can
easily cause a fire.
Be certain that all clamps, guards and heat shields are installed. These components prevent
vibration, rubbing, chafing and heat build-up. Install tie wraps to fasten hoses and wires, as
required.
Cold start ether is extremely flammable. Use ether only in ventilated areas and as directed.
Never use it near heat sources or open flames, do not permit anybody to smoke.
https://tractormanualz.com

8
MACHINE STARTUPSAFETY
Before excavator start up, perform a thorough walk around inspection. Visually inspect the
excavator, look for loose bolts, cracks, wear, any leaks and any evidence of vandalism.
Never start or operate an unsafe excavator.
Report all defects to your foreman or supervisor and make sure they are corrected
immediately.
Make sure all covers and doors are closed and locked and all warning decals are on the
machine.
Make sure all windows, as well as inside and outside mirrors are clean, and secure all doors
and windows to prevent any unintentional movement.
Be certain that the area surrounding the excavator is free of other personnel, and that no one
is working on or under the excavator before starting the engine.
After entering the cab, adjust the operator’s seat and controls, the inside and outside mirror,
the armrests and fasten and adjust the seat belt. Be certain that all controls can be reached
comfortably.
All noise protection devices on the machine must be functional during operation.
ENGINE START UPAND OPERATINGSAFETY
Before start up, check if all indicator lights and instruments are functioning properly, place all
controls in neutral position and tilt the safety lever up.
Before starting the engine, alert any nearby personnel that the excavator is being started by
sounding the horn.
Start the machine only when seated in the operator’s seat, and with the seat belt fastened (if
installed).
If you have no other instructions, start the engine as outlined in the Operation and
MaintenanceManual.
Tilt the safety lever down and check all indicators, gauges, warning devices and controls for
their proper indication.
Start and operate the engine only in a well ventilated area. If necessary, opening door and
window. Warm up the engine and hydraulic system to operating temperatures. Low engine
and hydraulic oil temperatures can cause the excavator to be unresponsive.
Check that all attachment functions are operating properly.
Move the excavator slowly into an open area and check all travel functions for their proper
operation, check travel and swing brakes, the steering function as well as the turn signals and
lights.
MACHINEOPERATINGSAFETY
Familiarize yourself with job site rules. Be informed about traffic and hand signals and safety
signs. Ask who is responsible for signaling. Check your surrounding for any obstacles in the
working and movement range, check the load carrying capacity of the terrain, and secure the
job site to shield it from any jam traffic.
Always keep a safe distance from overhangs, walls, dropoffs, and unstable ground.
https://tractormanualz.com

9
Be alert of changing weather conditions, bad or insufficient visibility and of changing ground
conditions.
Be alert for utility line, check the location of underground cables, gas and water lines, and
work especially careful in that vicinity. If necessary and/or if required, call local authorities to
mark the location.
Keep sufficient distance to electrical lines. When working in the vicinity of high voltage
electrical lines, keep proper distance to assure that the attachment does not come close to the
lines.
DANGER! You must inform yourself about safe distance.
In case you do touch a high voltage line by accident, proceed as follows:
Do not leave the machine,
Move the machine, if possible, from the danger zone until you obtain sufficient distance,
Warn any personnel in the vicinity not to come close to the excavator and not to touch it,
Instruct or initiate that someone turns off the voltage.
Do not leave the machine until you are absolutely sure that voltage in the line, which had
been touched or damaged, has been turned off!
Before moving the machine, make sure that the attachments and equipment are secured
properly to avoid accidents.
When traveling on public roads or highways, make sure to observe traffic regulations, and
make sure that the machine meets federal and local public highway standards.
Always turn on the lights if visibility is bad or if you are still working during dusk.
Never allow other personnel on the excavator.
Report any problems or needs repairs to your foreman or supervisor and make sure they are
correctedimmediately.
Do not move the excavator until you are certain that surrounding area is safe.
On machines without negative brakes check the brake system before starting to work, as
outlined in the Operation Maintenance Manual.
Never leave the operator’s seat while the machines are still moving.
Never leave the machine unattended, with the engine running.
When moving the excavator, keep the upper-carriage in lengthwise direction and keep the
load as close as possible to the ground.
Prevent any working movements, which could tip the machine over. If the excavator begins
to tip or slip on a grade, immediately lower the attachment and load to the ground and turn
the Excavator facing downhill. If possible, always operate the excavator with the attachment
positioned uphill or downhill, never sideways.
Always travel slowly on rough or slippery ground and on slopes.
Always travel downhill at permissible speed, so you don’t loose control over the machine.
The engine must run at nominal speed, use only the foot pedals to brake and slow down the
machine.
Never shift during down hill travel, always shift to a lower gear before traveling downhill.
Never load over an occupied truck. Request that the driver leave the cab, even if a rock
protection is installed.
If operating in visually obstructed terrain or whenever necessary, have another person guide
you. Always have only one person signal you.
For demolition work, clearing, crane operation, etc. always use the appropriate protection
https://tractormanualz.com

10
device designed for this specific application.
Allow only experienced persons to attach loads or to guide operators. The guide must be
visible by the operator and/or must be in voice contact with him.
Depending on the attachment combination, it is possible for the bucket teeth to hit the cab,
the cab protection or the boom cylinders. Be very careful when the bucket teeth get in this
range to prevent any damage.
MACHINEPARKINGSAFTY
Park the excavator only firm and level ground.
If it is becomes necessary to park the machine on a grade, properly block and secure it with
wedges.
Lock the upper-carriage with the lock pin.
Lower the attachments to the ground and anchor the bucket lightly in the ground.
Bring all operating levers in neutral position and engage the travel and swing brakes.
Turn the engine off as outlined in the Operation and Maintenance Manual and raise the
safety lever before you leave the operator’s seat.
Lock the machine, remove all keys and secure the excavator against vandalism and
unauthorized use.
MACHINE TRANSPORTATIONSAFETY
Use only suitable transporting and lifting devices with sufficient capacity.
Park the machine on the firmand level ground and block the chains.
If necessary, remove the working device during transport.
When loading the machine on a flatbed trailer or railroad car, be sure that the loading ramp
incline is less than 30º and covered with wooden planks to prevent skidding.
Remove all mud, snow or ice from track components before moving up the ramp.
Before loading, secure the upper-carriage with the under- carriage with the lock pin.
Align the machine with the loading ramp.
Attach the manual control levers to the foot pedals for sensitive control.
Have another person guide and signal the operator.
Have blocks or wedges ready to block the machine, if necessary, to prevent the machine from
rolling backwards.
Retract the working device as far as possible and lower the working device as close as
possible to the loading surface and carefully drive up the ramp and onto the flat bed trailer.
When the Excavator is on the trailer, release the upper-carriage lock pin, turn the upper-
carriage back and lower the working device. If the backhoe working device is attached, tilt the
stick and bucket in and relock the upper-carriage.
Carefully secure the upper-carriage and other parts with chains, wedges and blocks to prevent
slipping.
Release the hydraulic pressure, remove the ignition key, raise the safety lever, close and lock
the cab and close and secure all other doors and leave the machine.
Carefully check out the transport route. Make sure that width, height and weight allowances
are within the permitted limits. Check that there is enough clearance underneath all bridges,
https://tractormanualz.com

11
underpasses, utility lines, and in tunnels.
During the unloading procedure, proceed with the same care and caution as during the
loading procedure. Remove all chains and wedges. Start the engine as outlined in the
Operation and Maintenance Manual. Carefully drive off the loading platform. Keep the
working device as close as possible to the ground level. Have another person guide and signal
you.
MACHINETOWINGSAFETY
Only tow the Excavator if absolutely necessary and the towing should be done by the driver.
Be sure all towing and pulling device such as cables, hooks and couplers are safe and
adequate.
Make sure that the cable or the towing rod are strong enough and are routed to the towing
hook. Be aware that any damage to the machine caused by towing is never covered by
Shandong Kadekor Power Machine Co.,Ltd.
Never allow anyone to stand near the cable when pulling or towing the Excavator.
Keep the cable tight and free of kinks.
Engage travel slowly, and do not jerk. With a slack cable, the sudden impact of the load being
towed could snap and break.
During the towing procedure, keep within the required transport position, permissible speed
and distance.
After the towing procedure is completed, return the machine to its previous state.
MACHINEMAINTENANCESAFETY
The machine may not be made unsafe when performing maintenance work. Never attempt
maintenance procedures or repairs you do not understand.
Check the Operation & Maintenance Manual for service and maintenance intervals. Make
sure you use only appropriate tools for all maintenance work.
During maintenance, do not allow unauthorized personnel to enter the maintenance are.
Before any maintenance work and especially when working under the machine, make sure a
“Do not operate” tag is attached to the starter switch and remove the ignition key.
Use only nonflammable cleaning fluids to clean the machine.
Any welding, torch or grinding work on the machine must be explicitly authorized. Written
authorization is necessary for welding on carrying structures. Before any using a welder,
torch or grinder, clean off any dust and dirt and remove any flammable materials from the
surrounding area. Make sure the area is sufficiently ventilated.
Observe all product safety guidelines when handling oils, grease, and other chemical
substances.
When using hot service fluids, be very careful. They can cause severe burns and injury!
Never try to lift heavy parts. Use appropriate lifting devices with sufficient load carrying
capacity. When replacing or repairing parts or components, make sure they are mounted very
carefully on lifting devices, to prevent any possible danger. Use only suitable and technically
sound lifting devices make sure that lifting tackle, wire cables, etc. has adequate load carrying
https://tractormanualz.com

12
capacity.
Never position yourself, walk or work underneath suspended loads.
Never use damaged lifting devices or devices which are not sufficient to carry the load.
Always wear gloves when handling wire cables.
Ask only experienced personnel to attach loads and guide and signal the crane operator. The
guide must be within the visibility range of the operator and /or must be in direct voice
contact with the operator.
When working overhead, use appropriate and safe ladders, scaffolding or other working
platforms designated for this purpose.
When working high above ground, make sure you are fitted with ropes and appropriate safety
devices which will prevent a possible fall.
Always keep handles, steps, railings, platforms and ladders free of dirt, snow and ice.
When working on the attachments, makes sure the attachment is supported properly. Never
use metal on metal support.
Never work underneath the machine if it is raised or propped up with the attachment. The
undercarriage must be supported with wooden blocks and supports.
If it is necessary to repair the track, block the chain with wedges and lock the upper-carriage.
Fluid escaping from a small hole can have enough force to penetrate the skin. So never check
for leaks with your bare hands, always wear gloves or make indirect check by other
instruments.
If it is necessary that the machine must be repaired on a grade, block the chains with wedges
and secure the upper-carriage to the undercarriage with the lock pin.
Never loosen or remove lines or fitting before the working device has been lowered to the
ground and the engine has been turned off. Then turn the ignition key to contact position,
move all servo controls (hand-control lever and foot pedals) in both direction to release
pressures. Then release the tank pressure as outlined in this Operation and Maintenance
Manual.
Always disconnect the battery cable before working on the electrical system or before any arc
welding on the machine. Always disconnect the negative cable first and reconnect it last.
HYDRAULIC LINESAND HOSES
All the hoses, lines and fittings must be checked regularly. It is better to check before start, to
check monthly, to check annually for leaks and any externally visible damage! Any damaged
sections must be replaced immediately! Escaping oil can cause injuries and fires!
Even if hoses and lines are stored and used properly, they undergo a natural aging process.
For that reason, their service life is limited.
Improper storage, mechanical damage and improper use are the most frequent causes of hose
failures.
The service life of a hose may not exceed six years, including a storage period of not more
than two years (always check the manufacturer’s date on the hoses).
Using hoses and lines close to the limit ranges of permitted use can shorten the service life
(for example at high temperatures, frequent working cycles, etc).
Hoses and lines must be replaced if any of the following points are found during an
https://tractormanualz.com

13
inspection:
-- Damage on the external layer into the inner layer (such as chaffing, cuts and rips)
-- Brittleness of the outer layer and
-- Changes in shape.
-- Corrosion on fittings, Crack, wear and squeeze.
-- Storage or service life has been exceeded.
When replacing hoses or lines, always use the original parts of Shandong Kadekor Power
Machine Co.,Ltd.
ADDITIONALSAFETY GUIDELINEFOR CABIN
When entering into the cabin and before operating the Excavator, please read the following
safety instruction carefully.
Keep ladders, footsteps, handles and handrail in clean condition and always free them from
mud, oil, grease, ice, snow or any other obstacles.
To guarantee an easy opening of the cab door in all weather conditions, coat the rubber seals
around the door with silicon oil or talcum every two months and more often if necessary.
Regularly grease the hinges and lock of the cab door as well the fixing device of the door in
opened position.
During maintenance works, always wear safety glasses and proper protective clothes.
To climb up or down the cab, the Excavator must be parked on firm, flat and level ground.
Face the Excavator when climbing up the cabin and always hold on to the machine at three
points.
As soon as you can reach the handle of the door with your free hand unlock and open the
door before climbing up any more.
Keep and guide the doors all the way with your hand and lock it in its opened position,
making sure it is securely fixed in this position, so it can not be slammed by the wind.
Some external influences, and especially the wind, may make the opening of the door uneasy.
Sit down on the seat, fast your seat belt and start the machine.
It is essential to have your seat belt fastened if you want to operate the machine with the cab
door open. Should the belt be missing on your machine, so you must get one installed before
you start working with opened cab door.
Be aware of difficult weather conditions and their possible consequences. For example, the
wind could slam the cab door.
Before sitting down on the seat, you must make sure the machine is parked on a flat, firm and
level ground.
SIGNS ON THE HYDRAULIC EXCAVATOR
Your hydraulic excavator has several kinds of signs.
Warning Signs: Warn accident risks with potentially serious or fatal injuries.
Notice: Indicate specific points of control, maintenance and properties of the excavator.
Identification Tags: Indicates the original and other details.
Keep these signs clean. If it is missing or damaged, paste or replace a new one.
https://tractormanualz.com

14
Other signs should be treated as the same as the above mentioned.
1. Warning Sign on hydraulic oil tank: To avoid being scalded.
2. Warning Sign on fuel tank: Warn to use the designated fuel.
3. Warning Sign: To keep space fromthe stick.
4. Identification Tags: Indicates the Model, Manufacturer, Operating Weight, Date of EXW,
and the Series No.
5. Reminding Tags: Remind the driver to read Operation & Maintenance Manual and
other Cautions before operating the Excavator.
6. Warning Sign on Water tank: To avoid being scalded.
7. Safety Warning: Cautions when the Engine turning on.
8. No Entering Warning: Entering into the swing area is strictly prohibited.
Caution
1. Turn off the Engine before open the cover.
2. Don’t open the cover when the oil temperature is high.
3. Open the cover slowly to release the inner pressure.
4. Don’t loose the displacement plug when the oil temperature is high.
Fuel
1. Release the water in the fuel tank after 50 working hours and use the
designated fuel according to the Operation & Maintenance Manual.
https://tractormanualz.com

15
ⅢOPERATION AND CONTROL
“OPERATION AND CONTROL” contains the following items.
1. Position of each parts
2. Cab
3. Instrument panel
4. Appliance board
5. Air conditioner system
6. Sound system
7. Adjustment of seat
8．Safe belt
9. Front glass
10. Control bar of door
11. Inside lights of the cab
▲WARNING 
Warning light, buzzer or each lights on the appliance board go on or sound worn,please cut
off the power, clear the faults
https://tractormanualz.com

16
1. boom 2. boom cylinder 3. bucket arm cylinder 4. bucket arm 5. bucket cylinder
6. connecting rod 7. connecting rod 8. bucket 9. swing platform 10. engine hook
11. fuel tank 12. hydraulic oil tank 13. cab 14. balance weight 15. dozer blade
16. dozer blade cylinder 17. guide pulley 18. idler strain spring 19. thrust wheel
20. traveling motor 21. radiator 22. engine 23. crawler belt
https://tractormanualz.com
