AHRI 5450 Series Manual

I STALLATIO & OPERATI G
I STRUCTIO S
Catalog No. 6000.56A Effective: 03-10-17 Replaces: 12-01-16 92-105917-01-02
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids or other combustible materials in the vicinity of this or any other appliance. To
do so may result in an explosion or fire.
Model Series
5450, 6450,
6450HC, 8450 &
8450HC
Heat Pump
Pool & Spa
Heater
OTE: The instructions in this manual are for the use of qualified individuals specially trained and experienced
in the installation and maintenance of this type of equipment and related system components. Installation and
service personnel are required by some states to be licensed. Persons not qualified shall not attempt to install,
service, or maintain this equipment.
This manual should be maintained in legible condition and kept adjacent to the heat pump pool heater or in a
safe place for future use.

2
Rev. 2 reflects the following:
Changes to: Wiring diagram on page 44.
Additions: None.
Deletions: None.
ATTE TIO : Please Take This Opportunity to Quickly Register Your Unit!!
While your unit is being installed by your professional and licensed installer of choice, Please Take This
Opportunity to Quickly Register Your Unit!! With the necessary information in hand, Registering your new Heat
Pump Pool Heater only takes a few moments and is the only way to assure any verifiable warranty procedures
during the span of your unit's period of protection.
Using the diagram at the bottom of the page (Fig. i) please locate and record your model and serial number.
Once you have done this, please make sure you also have the following information on hand:
NAMEPLATE
• Name, phone number, and email address of homeowner
• physical address of where the unit is installed; please include any
'subdivision' or similar information
• any service challenges present at the house/neighborhood: gated
community, locked access at house, guard dog, etc.
• date of installation of the new unit
• name and phone number of the professional and licensed entity that
performed the installation for you
Fig. i: Model and Serial Number Location
With all of the above information in hand, please feel
free to call us at 800.260.2758 and ask to register your
brand new heat pump or Online:
http://warranty.raypak.com
You will be given a Warranty Registration Confirmation
number which you should notate and keep in one loca-
tion along with your Installation & Owner's Manual, a
copy of your warranty (provided with your manual) and
the above information.
This would also be a good time to review both the
manual and the warranty so that you are aware of how
to correctly operate your new equipment as well as
how to keep from voiding any aspects of your warran-
ty.
During the life of your unit, please feel free to use the
above phone number, or the one conveniently located
right on the unit, to contact us with any questions you
may have about operation, warranty, and/or service.
Thank You Very Much Choosing us to Satisfy Your
Pool Heating needs!!
Warranty Registrati n C nfirmati n #:

3
Water Chemistry
(Corrosive water voids all warranties)
For your health and the protection of your pool equipment, it is essential that your water be chemically
balanced. The following levels must be used as a guide for balanced water.
• Occasional chemical shock dosing of the pool or spa water should not damage the heater providing
the water is balanced. However, it is highly recommended that the heat pump pool heater is isolated
via shut off valves before any aggressive chemical treatment.
• Automatic chemical dosing devices and salt chlorinators are usually more efficient in heated water.
Unless controlled, they can lead to excessive chlorine level which can damage your heater.
• Further advice should be obtained from your pool or spa builder, accredited pool shop, or chemical
supplier for the correct levels for your water.
Recommended Level(s) Fiberglass Pools Fiberglass Spas Other Pool & Spa Types
Water emp. (Deg. F) 68 to 88 89 to 104 68 to 104
pH 7.3 to 7.4 7.3 to 7.4 7.6 to 7.8
otal Alkalinity (PPM) 120 to 150 120 to 150 80 to 120
Calcium Hardness (PPM) 200 to 300 150 to 200 200 to 400
Salt (PPM) 4500 MAXIMUM 4500 MAXIMUM 4500 MAXIMUM
Free Chlorine (PPM)* 2 to 3 2 to 3 2 to 3
otal Dissolved Solids (PPM) 3000 MAXIMUM** 3000 MAXIMUM** 3000 MAXIMUM**
*Free Chlorine MUST OT EXCEED 5 PPM!
** In salt water chlorinated pools, the total TDS can be as high as 6000ppm.

4
Water Chemistry 3
Warnings 5
Pay Attention to These Terms 5
Introduction 6
Installation Considerations 6
Electrical Connections 9
Water Connections 9
Pressure Drop 10
HPPH Control Display 10
User Modes 11
HPPH Control Menus 12
USER ME U — Heat O LY, Power
Defrost and Heat/Cool Models 13
I STALLER/SERVICE ME U — HEAT
O LY Configuration 15
I STALLER/SERVICE ME U —
POWER DEFROST Configuration 19
I STALLER/SERVICE ME U —
HEAT/COOL Configuration 23
Control Settings 27
Set Current Time 27
C/F Display 27
Spa Max Temp 27
Pool Max Temp 27
Pump Periods 27
Temperature Control 27
Additional Features 27
Pump Control 27
Low Ambient (Outside) Lockout 27
Control Lock ox Mode 27
AUX Mode 28
Remote Pool Operation 29
Pool Heat Mode 29
Pool Cool Mode (HEAT/COOL models
ONLY) 29
Pool Auto Mode (HEAT/COOL models
ONLY) 29
TIMED SPA Mode 29
Fault History 29
Run Hours/Cycles 29
Compressor Start Delay 30
Minimum Run Time 30
Defrost Operation 30
3-Way Valve Control 30
attery ack-up 31
High Water Temperature Limit 31
High Pressure Switch Lockout 31
Low Pressure Switch Lockout 31
Water Pressure Switch 31
Sequence of Operation 31
Digital Controls Operating
Instructions 32
To Increase or Decrease the Desired Water
Temperature (Pool or Spa Mode) 32
Select Temperature in °C or °F 32
Heat/Cool Operation 32
System Start-Up 32
Seasonal Start-Up or
Annual Check 33
Summer Shutdown 33
Freeze Protection 33
System Drain-Down 33
Continuous Pump Operation 33
Maintenance 34
Air Coil Cleaning 34
Cabinet Care (optional) 34
Unplug Condensation Drain Holes 34
Troubleshooting 34
Operational Status Messages 36
Error Messages 37
Service Call Verification 38
Power Supply 38
Water Flow 38
Time Clock Adjustment 38
Set Factory Defaults 38
Service Access to Heaters 38
Plumbing Diagrams 40
Wiring Diagram — 208V/230V
Single-Phase — Digital Models 44
Wiring Diagram — 208V/230V
Three-Phase — Digital Models 45
Installing a Remote Control
Device 46
Heater 2-Wire Controllers (Heat Only) 46
3-Wire Controllers 46
2-Wire Controllers For “Chill” Mode -
Heat/Cool Models Only 46
CO TE TS

CAUTIO : Improper chemical content in a swim-
ming pool or spa can damage the heat pump pool
heater. DO NOT add pool/spa chemicals to the
poo/spa via the skimmer or any other apparatus
(feeder, chlorinator, etc.) that is on the influent side
(i.e. before) of the heater. This will damage the heat
pump pool heater and could void the heat pump pool
heater warranty. ALWAYS follow the product manu-
facturer’s directions when adding any chemicals to
your pool.
DA GER: Indicates the presence of immediate hazards which will cause severe personal injury, death
or substantial property damage if ignored.
WAR I G: Indicates the presence of hazards or unsafe practices which could cause severe personal
injury, death or substantial property damage if ignored.
CAUTIO : Indicates the presence of hazards or unsafe practices which could cause minor personal
injury or product or property damage if ignored.
OTE: Indicates special instructions on installation, operation, or maintenance which are important
but not related to personal injury hazards.
Warnings — Pay Attention to These Terms
This manual, as well as the pool/spa heat pump pool heater itself, contains ANSI-approved product safety signs
and labels. Please read these signs and labels, as they convey important safety information about hazards that
may be potentially present in and around the heat pump pool heater.
CAUTIO : Elevated water temperature can be
hazardous. he U.S. Consumer Product Safety
Commission has these guidelines:
1. Spa water temperatures should never exceed
104°F (40°C). A temperature of 100°F (38°C) is
considered safe for a healthy adult. Special cau-
tion is suggested for young children.
2. Drinking of alcoholic beverages before or during
spa or hot tub use can cause drowsiness which
could lead to unconsciousness and subsequently
result in drowning.
3. Pregnant Women Beware! Soaking in water over
102°F (39°C) can cause fetal damage during the
first three months of pregnancy resulting in the
birth of a brain-damaged or deformed child.
Pregnant women should stick to the 100°F (38°C)
maximum rule.
4. Before entering the spa or hot tub, users should
check the water temperature with an accurate
thermometer; spa or hot tub thermostats may err
in regulating water temperatures by as much as
4°F (2.2°C).
5. Persons with a medical history of heart disease,
circulatory problems, diabetes, or blood pressure
problems should obtain a physician's advice
before using pools or hot tubs.
6. Persons taking medications which induce drowsi-
ness, such as tranquilizers, antihistamines, or
anticoagulants, should not use spas or hot tubs.
5
WAR I G: These heat pump pool heaters are
charged with R-410A refrigerant. Ensure that all
service work is done with gauges and equipment
suitable for R-410A.
EFFICIE CY TESTI G OTICE: For purposes
of verifying or testing efficiency ratings, the test pro-
cedure in Title 10 APPENDIX P to Subpart of Part
430 (Uniform Test Method for Measuring the Energy
Consumption of Pool Heaters) and the clarifying pro-
visions provided in the AHRI Operations Manual
1160 that were applicable at the date of manufacture
should be used for test set up and performance.
Contact manufacturer as needed for Charging Chart
information.

Introduction
This manual contains important information on the
use, maintenance and troubleshooting of your new
heat pump pool heater. This unit must be properly
installed, maintained and operated for optimal per-
formance.
This heat pump pool heater is an extremely efficient,
economical machine designed specifically for swim-
ming pool heating. It is similar in design and operation
to a typical residential air conditioning system. The unit
employs a hermetic motor/compressor operating in a
refrigeration cycle to extract heat from ambient air and
deliver it to the circulating pool water.
As with all heat pump pool heaters, compared to other
types of heaters such as gas or oil-fired, this heat
pump pool heater has lower heating capacity on a
TUH/hr basis. As a result, it will be required to oper-
ate longer to accomplish the desired results. It may, at
certain times, operate as much as 24 hours per day.
However, this should not be of concern to the owner,
because the unit is designed to operate continuously.
Even though it may operate continuously for many
hours, it will still heat the pool with greater economy
than other types of fossil fuel heaters.
Place a cover or blanket over the pool at night and
other non-use periods. This will keep evaporation, the
main cause of main heat loss, to a minimum, and will
greatly reduce pool heating costs. During warmer
weather, the cover may be required only at night.
Installation Considerations
Situate the heat pump pool heater carefully to mini-
mize installation costs while providing maximum
efficiency of operation, and to allow adequate service
access, as follows:
• For unrestricted air intake and service access,
position each side of the unit at least 1 ft (30 cm)
from walls, pipes and other obstructions.
• This unit features an ‘up-flow’ discharge for quiet
operation. Air is pulled up through the evaporator
coil and discharged through the top grille. Allow at
least 5 ft (1.5 m) clearance above the unit for unre-
stricted air discharge. D N T install the unit
under a porch or deck. Refer to Fig. 1.
Recirculation of cold discharge air back into the
evaporator coil will greatly reduce the unit’s heat-
ing capacity and efficiency.
• To minimize water piping, locate the unit as close
as possible to the existing pool pump and filter.
• Irrigation water should be directed away from the
heat pump pool heater - irrigation water spray can
damage the heat pump pool heater.
• Rain water run offs- the unit is designed to operate
outdoors and can be exposed to rain. However,
rain water run off falling directly onto the unit can
cause damage and/or shorten the life of your unit.
This may also void your warranty. Install rain gut-
ters or rain diverters on your roof if the unit is
installed in a position where contact with rain run
off may occur.
WAR I G: This pool/spa heat pump pool heater is
an electromechanical machine that incorporates a
pressurized refrigerant gas in a sealed system.
ONLY trained and qualified service personnel are
authorized to install or service this equipment.
Without proper training and knowledge of such
equipment, any attempt to install or service the unit
could result in serious injury or even death.
WAR I G: D n t install the unit within 3 ft f
fssil fuel burning heaters. Air intake al ng the
sides f this heat pump p l heater c uld disturb
the c mbusti n pr cess f the unit, and c uld
cause damage r pers nal injury.
• M unt the unit n a level, sturdy base, preferably
a concrete slab. The size of the base should be at
least 3 ft by 3 ft - slightly larger if hurricane tie down
straps are installed. See page 8 for more details.
CAUTIO : The unit’s supporting base must be high
enough to keep it completely free of standing water
at all times.
WAR I G: This unit is designed for outdoor instal-
lation; D N T install it in an enclosed area such as
a shed or garage.
OTE: Hurricane tie down brackets, tie down
screws, 2 x union halves, 2 x 45-degree PVC
elbows, the printed warranty and the I&O manual are
located in an accessory box mounted on the pallet
beside the heater inside the packaging. DO NOT
throw away without removing all components.
6

7
GAS
HEATER
3FT
MIN
AIR
FLOW
IN
AIR
FLOW
IN
AIR FLOW OUT
60” MIN
12”
MIN
Fig. 1: Installation Clearances
• It is important to keep the area next to the heat
pump pool heater clear of shrubs, bushes and
chemicals containers. They could prevent air from
circulating fully through the heat pump pool heater,
and will affect the operation of the heat pump pool
heater or damage the heat pump pool heater.
• When installed in areas where freezing tempera-
tures can be encountered, drain the water circuit
to prevent possible freeze-up damage. Refer to
Freeze Protection section on pg. 33 for proper pro-
cedures.
• If the location of the HPPH is below the water line
of the pool, the Water Pressure Switch (WPS) or
Water Flow Switch (WFS) might need to be adjust-
ed or an external WFS might be needed.
• For high wind installation requirements, refer to
the Fig. 3 on page 8.
Fig. 2: Base Design - Handling
OTE: The base is designed with recessed areas to
allow the use of hand trucks or lifting without the pos-
sibility of pinching fingers as shown in Figure 2.

8
ANCHOR SCHEDULE:
CONCRETE:
(4" THICK MIN,
3000 PSI MIN.)
SUBSTRATE DESCRIPTION DIM. 1
DIM. 2 DIM. 3
DIM. 4
4.50" MAX OFFSET FROM DATUM FACE
30.00" MIN OFFSET FROM DATUM FACE
31.00" MIN OFFSET FROM DATUM FACE
13.00" MAX OFFSET FROM DATUM FACE
TIE-DOWN CLIP OFFSETS:
UNITWIDTH
35.75"MAX
UNITLENGTH
35.75"MAX
UNITHEIGHT
51"MAX
UNITWIDTH
35.75"MAX
UNITLENGTH
35.75"MAX
UNITHEIGHT
51"MAX
(4)-#10
SMS PER
CLIP, TYP.
APPLICABLE MODELS:
5450, 6450, 6453, 8450,
8453, 10453, 10454, 10455
(1)-1/4"Ø CARBON STEEL POWERS WEDGE BOLT+, 2" EMBED TO CONCRETE, 3"
MIN. EDGE DISTANCE, 3" MIN. SPACING TO ANY ADJACENT ANCHOR.
B
A
CONCRETE SLAB
BY OTHERS, TYP.
CONCRETE SLAB
BY OTHERS, TYP.
C
D
N.T.S. MECHANICAL UNIT
FRONT ISOMETRICN.T.S.
MECHANICAL UNIT
BACK ISOMETRIC
THESE ISOMETRICS ARE INTENDED FOR
DIAGRAMMATICAL PURPOSES ONLY.
18-GA ASTM
A653 PAINTED
CONTROL COVER
N.T.S. ELEVATION TIE-DOWN CLIPS
BD
A & C
3000 PSI MIN.
CONCRETE BY
OTHERS, TYP.
ANCHOR PER
SCHEDULE
LOUVER
PANEL,
TYP.
UNIT BASE
PAN
UNIT BASE
PAN
UNIT BASE
PAN
INTERNAL POST
ADJACENT TO
CONTROL BOX
A & C ARE SIMILAR
AND OCCUR ON
OPPOSITE FACES
DIM. 1
DIM. 2
DIM. 4
DIM. 3
CLIP A
CLIP B
CLIP D
CLIP C
CONTROL
BOX
CLIP OFFSET DIMENSION SHALL
BE TAKEN FROM THIS SIDE ONLY
N.T.S.
TIE-DOWN CLIP LAYOUT
PLAN
DATUM FACE
TIE-DOWN CLIP
MIAMI TECH CLIP: 14GA (0.07") ASTM A653
Fu=90 KSI STEEL (CUTD10) OR 0.080"
5052-H32 ALUMINUM (CUTDA10).
FLORIDA APPROVAL FL#19731.1
OR APPROVED EQUAL
SEE GENERAL NOTE 6
1.000"
10.000"
0.306"
TYP.
1.000"
1.250"
0.750"
0.313"
0.187"
Minimum pad dimensions are 43-1/4" x 43-1/4" x 4" thick.
Screws to attach brackets to
unit are supplied with the unit
- DO NOT use screws not
specified or provided by manu-
facturer. Screws are stainless
steel #10 x 3/4" self drilling. Each bracket requires 4 screws
attached to the unit.
Fig. 3: Hurricane Tie Down Instructions

Electrical Connections
Refer to the unit rating plate below the control panel for
precise power requirements for your unit, and for
ampacity and over-current protection requirements.
All wiring must be in accordance with the National
Electrical Code, NFPA No. 70, latest edition, and all
applicable state and local codes. Wiring diagrams are
located on pages 44 and 45.
• Locate the equipment disconnect means within 3
feet of the heater’s electrical enclosure, or as
close to the heater as possible. Always satisfy
applicable codes and standards.
• In sizing power wiring, be especially aware of up-
sizing requirements necessary due to wiring
distances. Always satisfy applicable codes and
standards.
• Electrical installation should be done by a licensed
electrician only.
Model
o. Power
Min.
Circuit
Ampacity
Breaker Size (A) Recommended Wire Length from
Breaker to Heater*
MI . MAX. 10 AWG 8 AWG 6 AWG 4 AWG
5450 208/230-1-60 30 50 60 94 ft 151 ft 239 ft 383 ft
6450 208/230-1-60 29 50 60 97 ft 156 ft 247 ft 396 ft
6453 208/230-3-60 26 35 40 109 ft 174 ft 276 ft 442 ft
8450 208/230-1-60 41 50 60 NR 110 ft 175 ft 280 ft
8453 208/230-3-60 34 40 50 83 ft 133 ft 211 ft 338 ft
* Reference only - see National Electric Code or local codes for wire gauge length limits.
Table A: Typical System Electrical Power Requirements
9
OTE: Refer to the National Electrical Code, Article
680, for general requirements for swimming pools
and equipment, and to Article 440 for special consid-
erations necessary for circuits supplying hermetic
refrigeration motor/compressors.
WAR I G: This unit MUST be installed using flex-
ible conduit for supply wiring to the unit. This will
allow movement of the conduit whenever the junc-
tion box is removed for service - see instructions on
page 38.
This unit is pre-wired to work with external control sys-
tems, heat-on-demand options and other external time
clock overrides. Refer to the external control system’s
instructions, and page 29 of this manual, for installa-
tion information.
An earth ground lug is located to the right side of the
water connections.
Water Connections
1. Connect the heat pump pool heater in the return
water line between the filter and the pool/spa. See
the Plumbing Diagrams beginning on page 40.
2. Connect the filter outlet to the fitting marked
INLET/ENTREE at the bottom front of the unit.
3. Connect the fitting marked UTLET/S RTIE to
the return piping to the pool/spa. Unit inlet/outlet
connection fittings are 2-inch PVC unions.
CAUTIO : The heat pump pool heater inlet and
outlet connections are N T interchangeable. They
must be connected as instructed below.
OTE: The earth ground lug may be relocated to
the left side of the water connections as needed dur-
ing unit installation.
WAR I G:Improper installation of any type of
automatic chemical feeders can result in serious
damage to, or premature failure of, the heat
pump pool heater and may void the heat pump
pool heater warranty. Install a check valve and/or a
Hartford loop AFTER the heat pump pool heater and
EFORE any chlorinating devices. Install any auto-
matic chemical feeders AFTER the heat pump pool
heater.

HPPH Control Display
The HPPH display is viewable from outside of the
heater. All operation and settings of the HPPH control
are accomplished through the use of the 3 buttons of
the user interface. These buttons are labeled as fol-
lows (see Fig. 5):
• MENU/SET – Scroll through available menus
and set changed values (MENU)
• UP – Increase values in adjustible menus
• D WN – Decrease values in adjustible menus
The display uses a 2-line, 16-character backlit Liquid
Crystal Display (LCD) as the method for supplying
information. The backlight is normally off. The back-
light is on for 15 minutes after Power-Up and for 15
Water connections from the unit to the main return
line can be PVC pipe or flexible pipe approved for
the purpose and, in either case, should be at least
equal in size to the main pool/spa circulation pip-
ing.
4. Shut Off/Diverter valves, preferably three-way
valves which allows for a bypass route, on the
inlet and outlet lines of the HPPH are required if:
- water flow to the unit will exceed 60gpm
- to protect (completely bypass) the unit from
any harmful chemical treatments (i.e. Acid
wash, back-to-back super chlorinators, stain
treatments, etc.); or
- to be able to isolate the unit for
service/repair or freeze preparation and still
allow pool/spa circulation to continue
Please refer to the plumbing diagrams, starting on
pg. 40, for further instruction.
Please note that some municipalities do not allow
the use of a shut off valve on the effluent/outlet
side of any heating equipment, especially when
there is one on the inlet side. These entities typi-
cally instead allow a PVC tee and spring check
valve on the effluent/outlet side. This is allowed by
Raypak and can also double as your protection
from chemical feeders & chlorinators that our
downstream of the unit.
5. Operate the pump and check the system for leaks.
6. Drain plugs are located on each union fitting as
shown in Fig. 4 for draining the system during win-
terizing.
Pressure Drop
For system pressure drop information, refer to Table
below.
10
Fig. 4: Water Connections/Drain Plugs
WATER IN
WATER UT
Table B: Pressure Drop Across Heat Pump Pool Heater
Note: Multiply the pressure drop in psi by 2.3067 to yield the pres-
sure drop in Ft. H2O Head (TDH).
Flow
(gpm)
Pressure Drop
5450 6450/
6450HC
8450/
8450HC
30 4 6 9
40 7 9 9
50 10 10 10
60 11 11 11
70 12 12 12
80 13 13 13
CAUTIO : When the drain plugs are removed for
draining the system, ensure that they are stored in a
safe place for re-installation when needed to restart
the system.
OTE: While it is possible to mount the upper union
with the drain plug vertically, the manufacturer has
determined that installing both unions with the drain
plugs facing down as shown in Fig. 4 provides for the
best draining of the system.

minutes after any button press. Use the LCD to setup
and monitor the operation of your heater.
If the membrane switch remains inactive for 180 sec-
onds (3 minutes), the screen will revert to the current
view.
On HEAT ONLY and POWER DEFROST models, the
options available by pressing the MENU/SET (MENU)
button are POOL HEAT, SPA, TIMED SPA and OFF.
On HEAT/COOL models, the options available by
pressing the MENU/SET (MENU) button are POOL
HEAT, POOL COOL, POOL AUTO, SPA, TIMED SPA
and OFF. The cooling setpoint can be adjusted in the
range of 50F to the Cooling Deadband value below the
Heating setpoint. This allows use in Plunge Pools.
Adjust the cooling setpoint accordingly.
Upon initial application of power, the HPPH control
briefly sets all segments on the LCD at power-up. On
a normal power-up, the control displays the current
software revision and the model type configuration
(HEAT ONLY, POWER DEFROST or HEAT/COOL) on
the LCD for 2 seconds and then resumes the user
selected mode it was in before power was interrupted.
Setpoints are read from non-volatile memory. If the
self diagnostic check indicates corrupted values,
“EEPROM Fault” is displayed on the LCD and opera-
tion is prohibited until setpoints are manually set.
If unit type has not been set (like during the replace-
ment of the HPPH control), the control prompts the
user to set the model type (HEAT ONLY, POWER
DEFROST, or HEAT/COOL) before any device opera-
tion is enabled.
Fig. 5: HPPH Control Display
11
Upon initial installation, there are several items that
must be defined and programmed depending on the
configuration and accessories intended to be con-
trolled by the HPPH control. These include: (1) Pump
control (Yes or No and then what type of control – 4-
speed control or variable speed control), (2) 3-way
valve control (Yes or No), and (3) Auxiliary control (Yes
or No and then what type – External Heat, Auxiliary
Output or Remote Output).
Once these choices are made, then additional infor-
mation relating to the establishing of pump periods,
pump speeds during each period and Return/Suction
Valve positions during each period must be deter-
mined and set in the control.
The options for the control can be very simple or very
detailed, depending upon the needs of the installation.
Once programming is completed, the control is ready
for operation.
The user may select one of several operating modes.
Each mode is selected by pressing the MENU (button
is labeled MENU/SET, but MENU is used in these
instructions for simplicity) button to cycle between the
modes. Each press of the MENU button selects the
next mode. There is no automatic increment from con-
tinually pressing the MENU button. In fact, continually
pressing the MENU button (for 3+ seconds) will move
the user into the USER Menu.
User Modes
For HEAT ONLY and POWER DEFROST models, the
mode selections are:
OFF – POOL HEAT – SPA – TIMED SPA.
On HEAT ONLY and POWER DEFROST models,
there are additional operational modes available as
noted below:
1. When POOL HEAT mode is selected, each press
of the UP or DOWN buttons will increase /
decrease the pool heating setpoint temperature.
Holding the UP or DOWN buttons down will speed
up the change of the temperature values.
2. When SPA mode is selected, each press of the UP
or DOWN buttons will increase / decrease the spa
setpoint temperature. Holding the UP or DOWN
buttons down will speed up the change of the tem-
perature values.
3. When TIMED SPA mode is selected, the display
will read “Up or Dn to Set”. This tells the user to
press the UP or DOWN buttons to set the desired

12
increments. The timer will start and the unit will
begin heating as necessary to maintain the Spa
setpoint temperature for this duration. At the end of
the timed period, the unit will automatically go to
the last operational state (POOL HEAT, POOL
COOL, POOL AUTO, SPA, or OFF). Once the unit
turns on, the display will toggle between the cur-
rent Spa water temperature and the current
operating state (“Heating” for example). Pressing
the MENU button will change the display to show
the time remaining on the timer. Press the MENU
button again to go back to the current status.
The control saves the setpoint changes in non-volatile
memory and begins using them for heat demand
decsions after both the UP and DOWN buttons have
been released for 2+ seconds.
REMOTE Mode is accessed by pressing and holding
the UP and DOWN buttons simultaneously for 3 sec-
onds. When exiting the REMOTE mode, the control
always selects the OFF Mode.
If the UP, DOWN or MENU buttons are pressed while
in REMOTE mode, the display will read “Exit Remote
Mode to Adjust Temp”. Mode and temperature set-
points are not changed. Press and hold the UP and
DOWN buttons for 3 seconds to exit REMOTE Mode.
The INSTALLER/SERVICE menu can be accessed by
pressing and holding the UP and MENU buttons for 3+
seconds. The INSTALLER/SERVICE menu does not
affect operation of the unit which continues to operate
in the background. When in this mode, pressing the
UP or DOWN buttons will toggle through the various
information reported. Some items (Fault History and
Sensor Temperatures) have multiple values (press UP
or DOWN buttons to scroll through the additional infor-
mation. The service display mode may be exited to
return to the previous display be pressing the UP and
MENU buttons or it will automatically be exited if no
button is pressed within 60 seconds.
HPPH Control Menus
The USER menu is accessed by pressing and holding
the MENU button on the HPPH display for 3+ seconds.
This menu is intended for use by the end user to
change temperature settings and pump periods as
desired. There are different features and settings
required for different Model types. The model types
shown are HEAT ONLY, POWER DEFROST and
HEAT/COOL. The following tables outlines the items
noted on the display in HEAT ONLY, POWER
DEFROST and HEAT/COOL configurations, the
default values and range of adjustable values as well
as a brief description of the feature.
length of time for the timed SPA heating operation.
Pressing the UP button will increase the timer in 15
minutes increments (up to a total of 6 hours maxi-
mum). Pressing the DOWN button will decrease
the timer by 15 minute increments. The timer will
start and the unit will begin heating as necessary
to maintain the Spa setpoint temperature for this
timer duration. At the end of the timed period, the
unit will automatically return to the last operational
state (POOL HEAT, POOL COOL, POOL AUTO,
SPA, or OFF) of the control. Once the unit turns
on, the display will toggle between the current Spa
water temperature and the current operating state
(“Heating” for example). Pressing the MENU but-
ton will change the display to show the time
remaining on the timer. Press the MENU button
again to go back to the current status.
For HEAT/COOL models, the mode selections are:
OFF – POOL HEAT – POOL COOL – POOL AUTO
– SPA – TIMED SPA.
On HEAT/COOL models, there are additional opera-
tional modes available as noted below:
1. When POOL HEAT mode is selected, each press
of the UP or DOWN buttons will increase /
decrease the pool heating setpoint temperature.
Holding the UP or DOWN buttons down will speed
up the change of the temperature values.
2. When POOL COOL mode is selected, each press
of the UP or DOWN buttons will increase /
decrease the pool cooling setpoint temperature.
Holding the UP or DOWN buttons down will speed
up the change of the temperature values.
3. When POOL AUTO mode is selected, each press
of the UP or DOWN buttons will increase /
decrease the pool setpoint temperature. Holding
the UP or DOWN buttons down will speed up the
change of the temperature values.
4. When SPA mode is selected, each press of the UP
or DOWN buttons will increase / decrease the spa
setpoint temperature. Holding the UP or DOWN
buttons down will speed up the change of the tem-
perature values.
5. When TIMED SPA mode is selected, the display
will read “Up or Dn to Set”. This tells the user to
press the UP or DOWN buttons to set the desired
timer for timed SPA heating operation. Pressing
the UP button will increase the timer in 15 minute
increments (up to a total of 6 hours). Pressing the
DOWN button will decrease the timer by 15 minute

13
Item Range Default
Value Access Level Description
Set Current
Time
12:00A–11:59P --- User Selects current time – “A” or “P” will
indicate whether the set time is AM or
PM.
C/F Display Celsius/Fahrenheit Fahrenheit User Selects the units of measure for tem-
perature readings.
Spa Max Temp 65F–104F/18C–40C 104F User Selects the maximum Spa tempera-
ture that the control can be adjusted
to in normal operation.
Pool Max Temp 65F–95F/18C–35C 95F User Selects the maximum Pool tempera-
ture that the control can be adjusted
to in normal operation.
Pump Periods 0–4 User nly available if Pump peration in
the Installer’s Menu is set to “4-
Speed Enabled” or “Variable
Enabled”.
Pump On Time 1 12:00A–11:59P --- User Select ON time for Pump Period #1 to
take effect.
Pump Off Time 1 12:00A–11:59P --- User Select OFF time for Pump Period #1
to stop.
Pump Speed 1 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 1 Pool/Spa Pool User Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 1 Pool/Spa Pool User Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 2 12:00A–11:59P --- User Select ON time for Pump Period #2 to
take effect.
Pump Off Time 2 12:00A–11:59P --- User Select OFF time for Pump Period #2
to stop.
Pump Speed 2 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Table C: USER MENU — Heat NLY, Power Defrost and Heat/Cool Models
OTE: The User Menu is exactly the same for Heat
ONLY, Power Defrost and Heat/Cool models.

14
Item Range Default
Value Access Level Description
Return Valve 2 Pool/Spa Pool User Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 2 Pool/Spa Pool User Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 3 12:00A–11:59P --- User Select ON time for Pump Period #3 to
take effect.
Pump Off ime 3 12:00A–11:59P --- User Select OFF time for Pump Period #3
to stop.
Pump Speed 3 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 3 Pool/Spa Pool User Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 3 PoolSpa Pool User Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 4 12:00A–11:59P --- User Select ON time for Pump Period #4 to
take effect.
Pump Off Time 4 12:00A–11:59P --- User Select OFF time for Pump Period #4
to stop.
Pump Speed 4 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
User On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 4 Pool/Spa Pool User Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 4 Pool/Spa Pool User Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
OTE: Make sure that the values for each setting are recorded for future reference or if the control ever needs
to be reset to Factory Defaults. All these values will need to be re-entered.

15
The Installer/Service menu is used by Installers and Service personnel to set up and troubleshoot the HPPH.
This menu is accessed by pressing and holding the UP and MENU buttons for 3+ seconds. WARNING: This
menu should never be used by the end user as changes can affect proper operation of the unit.
Table D: INSTALLER/SERVICE MENU — HEAT NLY Configuration
Item Range Default
Value Access Level Description
Set Current
Time
12:00A–11:59P --- Installer Selects current time – “A” or “P” will
indicate whether the set time is AM or
PM.
Pump Periods 0–4 Installer nly available if Pump peration in
the Installer’s Menu is set to “4-
Speed Enabled” or “Variable
Enabled”.
Pump On ime 1 12:00A–11:59P --- Installer Select ON time for Pump Period #1 to
take effect.
Pump Off Time 1 12:00A–11:59P --- Installer Select OFF time for Pump Period #1
to stop.
Pump Speed 1 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 1 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 1 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 2 12:00A–11:59P --- Installer Select ON time for Pump Period #2 to
take effect.
Pump Off Time 2 12:00A–11:59P --- Installer Select OFF time for Pump Period #2
to stop.
Pump Speed 2 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation
Return Valve 2 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 2 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 3 12:00A–11:59P --- Installer Select ON time for Pump Period #3 to
take effect.

16
Item Range Default
Value Access Level Description
Pump Off Time 3 12:00A–11:59P --- Installer Select OFF time for Pump Period #3
to stop.
Pump Speed 3 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 3 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 3 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On ime 4 12:00A–11:59P --- Installer Select ON time for Pump Period #4 to
take effect.
Pump Off Time 4 12:00A–11:59P --- Installer Select OFF time for Pump Period #4
to stop.
Pump Speed 4 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 4 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 4 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Faults Last Installer/
Service
Fault history starting with the most
recent and going back to 10 last
faults. Using the UP/DOWN buttons
scrolls through the fault history. If
there are no faults present, the dis-
play will read “All Faults Clear”.
Clear Faults Installer/
Service
Holding down the UP and DOWN but-
tons for 3+ seconds clears the
recorded fault history and “Faults
Cleared” appears on the display.
Run Hours
XXXX
Cycles
XXXX
Installer/
Service
Displays the number of run hours that
the compressor has been running as
well as the number of cycles that the
unit has operated.

17
Item Range Default
Value Access Level Description
Voltage
Up/ Down for
More
Installer/
Service
Press UP or DOWN buttons to access
additional temperature measure-
ments.
Voltage View Only – VAC --- Installer/
Service
Displays the 24VAC voltage as meas-
ured by the control board.
Coil Temp View Only –
degrees F or C
Installer/
Service
Displays the coil temperature sensor
value – used for defrost operation.
Amb Temp View Only –
degrees F or C
Installer/
Service
Displays the ambient temperature
sensor value – used for Outside
Lockout operation and defrost.
Suct Temp View Only –
degrees F or C
Installer/
Service
Displays the suction line temperature
sensor value – used for EXV opera-
tion ONLY. Will not be shown if EXV
Disabled is selected.
EXV Temp View Only –
degrees F or C
Installer/
Service
Displays the EXV temperature sensor
value – ONLY available with EXV
Enabled AND EXV Temp Sensor uti-
lized. NOTE: This is ONLY utilized
when the pressure transducer is NOT
used.
Sat Temp View Only –
degrees F or C
Installer/
Service
Displays the pressure transducer con-
verted to a temperature. It is
displayed whenever EXV is enabled.
Water emp View Only –
degrees F or C
Installer/
Service
Displays the water temperature sen-
sor value – used for temperature
operation
Installer Menu Yes or No No Select YES and press the MENU but-
ton to gain access to additional
programming selections in this
Installer/Service Sub-menu. Select
No and the next MENU button press
returns to the Set Current Time
screen.
Pump Operation 4-Speed Enabled,
Variable Enabled,
Disabled
Disabled Installer/
Service Sub-
menu
If pump control through the HPPH is
desired, select the appropriate pump
mode – 4-Speed Enabled for discrete
speed control or Variable Enabled for
PWM control of pump.
Pump Heat Installer/
Service Sub-
menu
This feature selects the Digital input
(pump speed) for the pump to operate
during HPPH operation.
Valve Operation Enabled, Disabled Disabled Installer/
Service Sub-
menu
This feature allows control of 3-way
valves. Disabled is the default.
When Enabled, the control will seek
information as to whether the Return
and Suction valves should be posi-
tions for Pool or Spa positions for
each pump period.
AUX Mode AUX OFF, AUX
OUTPUT, REMOTE
OUT, EXT HEAT
AUX OFF Installer/
Service Sub-
menu
See description of auxiliary mode
operation on page 32.

18
Item Range Default
Value Access Level Description
Defrost Temp 20F–35F / -6.5C–1.5C 24F Installer/
Service Sub-
menu
This is the temperature measured on
the coil when the control goes into
Defrost mode.
Defrost
Deadband
5F–20F / 3C–11C 10F Installer/
Service Sub-
menu
Defrost terminates when the coil tem-
perature is greater than the Defrost
Temperature + Defrost Deadband.
Outside Lockout Off,
30F–50F / -1C–10C
Off Installer/
Service Sub-
menu
The installer can program the control
to Lock out operation of the unit if a
specific outside temperature is meas-
ured. Off allows operation at any
ambient temperature.
Set Model Type HEAT ONLY, POWER
DEFROST,
HEAT/COOL
HEAT
ONLY
Installer/
Service Sub-
menu
Set at the factory. Will need to be set
by Installer during any replacement of
the control board.
EXV Disabled, Type 1,
Type 2
Installer/
Service Sub-
menu
Set at the factory on new units.
Select “Disabled” if unit equipped with
TXV for board replacement. EXV
Type 1 is 500 step EXV. EXV Type 2
is 1600 step EXV.
Change EXV to Yes/No Installer/
Service Sub-
menu
This screen asks if you really want to
change the EXV setting – the UP or
DOWN button must be pressed to
show YES before the EXV type will be
changed.
rownout
Detection On
On/Off On Installer/
Service Sub-
menu
This function will shut down operation
of the unit if the 24VAC signal drops
below 18VAC to protect the unit from
Low Voltage. This feature can be
turned off as desired.
Set Factory
Defaults
Installer/
Service Sub-
menu
Press and hold both the UP and
DOWN buttons for 3+ seconds to
reset the factory defaults in the con-
trol. When reset, the screen will
display “Defaults Set”.
OTE: Make sure that the values for each setting are recorded for future reference or if the control ever needs
to be reset to Factory Defaults. All these values will need to be re-entered.

19
Table E: INSTALLER/SERVICE MENU — P WER DEFR ST Configuration
Item Range Default
Value Access Level Description
Set Current
Time
12:00A–11:59P --- Installer Selects current time – “A” or “P” will
indicate whether the set time is AM or
PM.
Pump Periods 0–4 Installer nly available if Pump peration in
the Installer’s Menu is set to “4-
Speed Enabled” or “Variable
Enabled”.
Pump On ime 1 12:00A–11:59P --- Installer Select ON time for Pump Period #1 to
take effect.
Pump Off Time 1 12:00A–11:59P --- Installer Select OFF time for Pump Period #1
to stop.
Pump Speed 1 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 1 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 1 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 2 12:00A–11:59P --- Installer Select ON time for Pump Period #2 to
take effect.
Pump Off Time 2 12:00A–11:59P --- Installer Select OFF time for Pump Period #2
to stop.
Pump Speed 2 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation
Return Valve 2 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 2 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On Time 3 12:00A–11:59P --- Installer Select ON time for Pump Period #3 to
take effect.

20
Item Range Default
Value Access Level Description
Pump Off Time 3 12:00A–11:59P --- Installer Select OFF time for Pump Period #3
to stop.
Pump Speed 3 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 3 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 3 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Pump On ime 4 12:00A–11:59P --- Installer Select ON time for Pump Period #4 to
take effect.
Pump Off Time 4 12:00A–11:59P --- Installer Select OFF time for Pump Period #4
to stop.
Pump Speed 4 1–4 if 4-Speed Enabled
0%–100% if Variable
Enabled
Installer On 4-speed pumps, this denotes the
selected pump output (which con-
nects to the pump for the selected
speed) for this pump period. On
Variable speed pumps, this denotes
the PWM signal to be provided to the
pump for pump operation.
Return Valve 4 Pool/Spa Pool Installer Select the position of a 3-way valve
located between the HPPH and the
Pool/Spa for this scheduled pump
period.
Suction Valve 4 Pool/Spa Pool Installer Select the position of the 3-way valve
located between the Pool/Spa and the
Pump for this scheduled pump period.
Faults Last Installer/
Service
Fault history starting with the most
recent and going back to 10 last
faults. Using the UP/DOWN buttons
scrolls through the fault history. If
there are no faults present, the dis-
play will read “All Faults Clear”.
Clear Faults Installer/
Service
Holding down the UP and DOWN but-
tons for 3+ seconds clears the
recorded fault history and “Faults
Cleared” appears on the display.
Run Hours
XXXX
Cycles
XXXX
Installer/
Service
Displays the number of run hours that
the compressor has been running as
well as the number of cycles that the
unit has operated.
