Aim PORTABLE BAZOOKA BASS TUBE BT68 User manual
PORTABLE
BAZOOKA
BASS TUBE
• BLUETOOTH
• FM TUNER
• USB PLAYBACK
• AUX INPUT
• MMC PLAYBACK
USER MANUAL
BLUETOOTH SPEAKER
1
INDEX
• IMPORTANT SAFEGUARDS
• BLUETOOTH
• FEATURES
• AUX-IN
• FM RADIO
• CHARGING
• SPECIFICATIONS
• 1 YEAR LIMITED WARRANTY
• REPAIRS PROCEDURE
3
5
6
6
6
6
7
8
9
USER INSTRUCTIONS
IMPORTANT SAFEGUARDS
When using electronic equipment, basic safety precautions must
be followed, including the following:
WARNING: To reduce the risk of electric shock,
1. Read all instructions before using the unit.
2. Use this unit only for its intended use as described in this manual.
3. Do not operate this unit if it has a damaged cord or plug, is not working
properly or has been damaged or dropped. If the supply cord is
damaged, it must be replaced by the manufacturer or its service agent
4. WARNING: Do not allow children to use the unit without supervision.
5. WARNING: Liquids and food stuffs must not be spilled or dropped into
the unit.
6.
carry out any service or repair operation.
7. This unit is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the product by a person responsible for their safety.
8. Children must be supervised to ensure that they do not play with the
unit.
9. Never leave the product unsupervised. Switch on the product when it is
not in use, even if this is only for a short while.
10. The unit must be free-standing. It must not be placed in a cabinet.
11. The temperature of accessible surfaces may increase when the unit is
operating.
12. This unit is not intended to be operated by means of an external timer or
separate remote control.
13. If smoke is emitted, switch on and unplug the unit immediately.
Please read this instruction manual carefully before using for
14. Cleaning: Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a slightly
dampened cloth for cleaning and immediately wipe dry.
15. Attachments: Use only attachments recommended by the
16. Water and Moisture: Do not use this product near water (e.g., near
a bath tub, washbowl, kitchen sink, laundry tub, in wet basements, or
near a swimming pool and the like).
17. Ventilation: Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the product and to protect it
from overheating. These openings should never be blocked by placing
the product on a bed, sofa, rug, or other similar surface. This product
should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided.
18. This unit must not be exposed to dripping or splashing and objects
apparatus.
19. Replacement parts: When replacement parts are required, be sure
the manufacturer or that have the same characteristics as the original
20. Safety check: Upon completion of any service or repairs to this
product, ask the service technician to perform safety checks to ensure
that the product is in proper operating condition.
21. Overloading: Do not overload wall outlets, extension cords, or
electric shock.
22. When the AC/ DC adapter is used as the disconnect device, the
disconnect device must remain readily operable. To completely
disconnect the power input, the AC/ DC adapter must be completely
disconnected from the mains.
IMPORTANT SAFEGUARDS - CONTINUED
5 |
BLUETOOTH
FEATURES
Turn both the speaker unit and the Bluetooth switch on your mobile (or
other device) ON and search for the speaker name “BT 68 EVO2”.
Pair the device. Once the device is paired, Bluetooth will automatically
connect whenever the unit is turned on.
Turn on the speaker and it will automatically go into Bluetooth mode.
Once the device is paired it can play music.
Short press to play/ pause. Press and to go to prev or next.
Long press and to turn the volume down or up.
1. Display LED shows information on the mode currently being played.
2. On/ off: Power switch. Push the switch to the on position to turn the
speaker on and push it off to turn the speaker off.
3.
4.
5. M: Mode shift button. Press Mode “M” button to enter into Bluetooth
mode, press once for USB/ TF mode, press again to enter AUX/ FM
mode. Long press to turn LED light on/ off.
6. Next/ skip forward: In FM/ USB/ TF/ Bluetooth mode, short press to
move to next channel/ track.
7. Play/ pause: In USB/ TF/ Bluetooth mode, short press for play and
pause. In FM mode, short press for station selection and frequency
modulator alternation and long press for automatic search.
8. Prev/ skip backward: In FM/ USB/ TF/ Bluetooth mode, short press to
move to the previous channel/ track.
9. Mic-vol: Set the microphone volume.
10. Mic: Microphone input
11. Line-in: External sound source input port (plug and play) enables
connection to an external sound source (PC, digital media player,
mobile phones and other audio-visual products).
12. DC-5V: Connect USB cable and plug into PC or other charging sources
to recharge the unit. The red LED light turns on when charging.
| 6
To play your favourite music from an external audio source, connect BT 68
EVO2 with an audio cable. Press M (mode) button to select Line-in mode.
Long press and button to turn the volume down or up.
NOTE: In Line-in mode prev and next selection is not available. This function
may only be controlled by an external device.
Press to play/ pause. Short press and to go to prev or next.
Long press and button to turn the volume down or up.
Press to automatically search for FM channels. This operation will scan
all FM stations and record them to memory. The scan procedure will take
several minutes to complete and should not be interrupted. Once complete,
short press or to move backward or forward. Long press or
to turn the volume down or up.
NOTE: Connect the cable into the Line-in port to receive FM radio clearly
as the cable functions as an antenna.
Plug the DC side of the cable to the DC port of the speaker and insert the
USB side of the cable to any USB Power Source. The red LED below the DC
Port will be light up when charging.
NOTE:
AUX-IN
FM RADIO
CHARGING
7 |
Bluetooth version: 2.1 + EDR
Output power: 15W
Speaker impedance: 4Ohm
Signal to noise ratio: >=85dB
Bluetooth wireless range: 10 meters
Max memory USB/ SD: 32GB
USB charging: DC 5V
Battery capacity: 1500mAh
Backup time via Bluetooth mode: Approx 1.5 hours at max volume
Backup time via USB mode: Approx 1.5 hours at max volume
Charging via USB port (PC): 1-2 hours
SPECIFICATIONS
| 8
1
The Manufacturer hereby provides a warranty to the original purchaser of this product (the
consumer) that this product will be free of manufacturing defects in materials and workmanship
which under normal, personal, family or household use (commercial use expressly excluded)
manifest themselves within the 1 year from the date of purchase.
EXCLUSIONS
• The warranty does not include and will not be construed to cover products damaged as a
result of disaster, misuse, commercial use, not in accordance within the written instructions
incorrect installation of the product or normal wear and tear.
• Insect infestation of the electrical or motor makes the claim invalid.
• Customer abuse do not fall under warranty.
WAIVER
The warranty and the obligations of the Manufacturer provided herein are in lieu of, and the
consumer, waives all other warranties, guarantees, conditions or liabilities, express or implied,
arising by law or otherwise, including without limitation, any obligation of the manufacturer in
respect of any injury, loss or damage (direct, indirect or consequential) arising out of the use of,
or any act or omission on its part.
PROOF OF PURCHASE
Any claim in terms of the warranty must be supported by a proof of purchase. If such proof
prevailing charges for services/repairs and/or spares will be payable by the Consumer upon
collection of the repaired product. The Consumer should call the Pick n Pay CUSTOMER
CARE number on 0860 30 30 30 (only in South Africa). Customers residing outside South
Africa may return the product back to a Pick n Pay store. During the warranty period the
1 YEAR LIMITED WARRANTY
If this product proves to
be faulty during normal
use due to defective
materials or workmanship.
Refer to our website for
terms and conditions.
9 |
REPAIRS PROCEDURE
Should you experience any faults on your Aim product, please adhere to the following
You can return the product to the store.
Call the Pick n Pay CUSTOMER CARE number on 0860 30 30 30 (only in South Africa) to
report the fault and make arrangements for the next steps.
Note: Should you live in an outlying area or outside South Africa, it may be necessary to
return the product to the store nearest to you.
COST OF REPAIRS
UNDER WARRANTY
Any items still under warranty will be repaired free of charge, as long as it complies with the
terms and conditions of the warranty (refer to “warranties” section in this manual). Any items
expense. A quote for the repair/replacement of these items will be provided to the consumer
for approval prior to repairs being conducted.
OUT OF WARRANTY
expense including call out fees. A quote for the repair/replacement of these items will be
provided to the consumer for approval prior to repairs being conducted.
Raymond Ackerman
Founder of Pick nPay
Product of China
CUSTOMER CARE
Sharecall: 0860 30 30 30
ONLY IN SOUTH AFRICA
customercare@pnp.co.za
MODEL NUMBER:
BT68 EV02
Specially packed for
Pick n Pay Retailers (Pty) Ltd.
Pick n Pay Oce Park,
101 Rosmead Avenue,
Kenilworth, Cape Town, 7708
www.picknpay.co.za
