Air Direct Dr's Cam Air User manual

Wireless Intraoral Camera
User manual
KorEng
Wireless type
Enjoy wireless

Wireless Intraoral Camera
User manual
Eng
Wireless type
Enjoy wireless

03
Contents
3. List of Components 09
4. Parts and functions 10
5. Installation 11
6. How to use 15
7. Maintenance 17
8. Trouble Shooting 18
9. Specification 19
10. Accessories 20
11. Warranty 21
12. Warranty card 22
2. Safety Information 05
- Symbols
- Notes and reference
- Installation and Connection
- Operation
- Maintenance
1. Introduction 04
- Features
- Description
- Overview

04 Enjoy wireless
Introduction1
- High speed digital wireless
- Autofocus
- Gyro mouse built-in
- 280。 twist head
- Adjustable LED brightness
- Software compatibility
- Easy to read OLED screen
- Dental image software included (DrsViewer2)
- 3 color impressions
Features
Thank you for purchasing the device. The instructions described below have been designed to provide the
necessary information for the successful operation, daily maintenance and safety for the use of this unit.
Description
This device is an intraoral camera used to take images of the inside of the mouth or oral cavity.
Overview
1) Camera 2) Receiver part
Lens
OLED screen
Button
Charger
Wireless receiver

05
Safety information2
It is important to understand the following information to use this product safely.
Symbols
Indicates a potentially hazardous situation which, if not avoided, may result in
serious injury or death.
Indicates a potentially hazardous situation which, if not avoided, may result in
minor/moderate injury or in damage of property.
Caution
Warning
Warning and Caution used in this manual are shown below.
Notes and References used in this manual are shown below.
Indicates that potential malfunctions may occur if the description is ignored.
Supplementary information to facilitate better operation.
Reference
Note
Notes and References

Enjoy wireless
06
Safety information2
- The adapter should be disconnected from the charger before connecting the power
cable to prevent an electric shock.
- Keep away from sources of ignition to avoid fire or explosion.
- Protect the device from any liquid to avoid electric shock or functional error.
- Place the charger on a flat and stable surface. Do not drop device and charger to avoid
internal defect that may cause overheating or fire.
- Do not place the electrical cord near a gas burner or sources of heat.
Should the cord catch on fire, replace with the new one to avoid short-circuit.
Warning
- Do not use or leave the unit in areas of high temperature or exposed to direct sunlight,
internal circuit defect may cause overheat or fire.
- Securely connect the dust-free power plug to the outlet.
- Use this device in well ventilated areas. Overheating may cause fire.
- Do not touch the terminal areas of charger of battery with fingers or conductive objects,
such as metal wire or safety-pin. It may electric shock or fire.
- Do not use any charger other then supplied. It may cause fire due to overheating.
- Do not place barrier between camera and receiver. It would make hesitation wireless
data translation.
Caution
Installation and Connection

07
Safety information2
Operation
- Do not plug the power cord with wet hands. This may result in an electric shock.
- In case of fluid leak from battery or partial discoloration/deformation of the device,
immediately discontinue use.
- In case of partial discoloration of the device, immediately disconnect the power plug
and repair it.
- In case battery fluid contacts the eye, immediately flush with copious amount of clean
water and seek medical attention.
- Do not use this product on a person with a pacemaker as it may cause malfunction of
the pacemaker.
- Should use disposable cover to avoid cross-infection.
Warning
- Disconnect the power cord by grasping the power plug to avoid injuries or burns.
- Avoid damage or use of unnecessary force on the power cord and device.
This may cause an electric shock, fire, or malfunction.
- Should battery fluid contact the skin or clothes, immediately wash it off with copious
amount water to avoid skin damage.
- Do not use this product for any purpose other than dental use.
- This device is not water prove. Use disposable cover when use to avoid wet the device.
In case of malfunction due to this case, it is not covered by warranty.
- For safety, disconnect the adapter from charger in case of device is not charging.
Caution

Enjoy wireless
08
- Use only accessories supplied to avoid fluid leak, explosion, or malfunction.
- Do not disassemble or overhaul the device. Unusual performance may cause injuries,
electric shock, fire, or malfunction.
- Ensure that charger and camera are always separated from the device prior to cleaning.
- Be careful from any liquid when clearing.
Warning
Safety information2
Maintenance
- Do not use solvent (containing orange oil, ethanol or acetone) when clean the device.
It may cause malfunction.
- User must be in charge of operation, maintenance and check.
Caution

09
List of components3
Please check the contents described below when removing the contents from the original packaging.
Camera
(Part No. DCAMM1001)
Charger
(Part No. DCAMM2001)
Adapter
(Part No. AC0105)
Disposable plastic cover x 2ea
(35 x 100mm / narrow)
(Approx.100pcs)
(Part No. AC0103)
1. Product
- Disposable Plastic Cover
2. Size
- Approx. 35 x 100mm
100 Sheets by weight
Sheets 100
Disposable
Plastic Cover
OPEN
Quick Guide
(Part No. DCAM080801)
Quick Guide
Data USB
(Part No. AC0201)
Receiver-Air Direct
(Part No. AC0216)
Power cable
(Part No. AC0111)

Enjoy wireless
10
Parts and functions4
① Lens
- Image is reflected on the lens through prism.
② Head
- Twistable 280。 degrees
③ Button
ⓐ Capture button
- Image capture, focus adjusting, select
ⓑ Left button
- Mouse left button
ⓒ Right button
- Mouse right button
ⓓ Mode button
- Mouse moving activate, setup mode, cancel
④ OLED screen
- Show the device states
① Lens
② Head
④ OLED screen
⑤ Wireless antenna
⑥ Charger
⑦ Charging indicator
⑧ Charging port
③ Button
ⓐ Capture button
ⓑ Left button ⓒ Right button
ⓓ Mode button
⑤ Wireless antenna
- Data is sent from this antenna to receiver.
⑥ Charger
- Charging the device
⑦ Charging indicator
- Red: On charging
- Blue: Full charged
⑧ Charging port
- Connect the AC adapter for charging
Wireless connection indicate
Setting Number indicate (Live image )
Semi or Full autofocus (SE, AF)
Black & White mode indicate
Color mode indicate
(Original, Warm, Cool)
LED brightness indicate
Battery condition indicate

11
Installation5
1. Connection between adapter and charger
1) Securely insert the power cable with 100~240V
power outlet.
2) Connect power cable with adapter.
3) Connect adapter with charger
Note
- Use only the original adapter supplied.
- When the adapter is connected with charger, red and blue light will blink.
- If red and blue light is not blinking when adapter is connected, it is a charger
malfunction.
2. Charging
- Insert the handpiece into the vertical slot at
the front of the charger.
- Red light on : Charging in progress
- Blue light on : Charging process is complete
- If the remaining battery is extremely low, red light may flicker while recharging,
which is not a malfunction.
- It will take approximately 1 hours 40 minutes before the battery will be fully charged.
Reference
Note

Enjoy wireless
12
Installation5
3. Receiver installation
1) Connect the receiver to the USB port on your PC
Connect to the USB port
2) After approximately 5 seconds, the receiver will display a logo and the receiver's default
number "001"
3) To change to a number that does not overlap with other receivers, press the ▲ and ▼
buttons on the receiver to change the number.
(Press and hold the ▲ and ▼ buttons to change quickly.)
4. Camera connection
1) To use the camera for the first time or to connect to another receiver, the camera requires
a receiver connection setup.
Capture button
3) Double-click the Capture button to search for a connectable
receiver.
2) Press and hold the capture button to power on the camera.
Select the number of receiver
Select the Receiver
Chage the Receiver Chage the Receiver
4) When number of connectable receiver is displayed, use the left/right buttons on the camera
to navigate to the receiver number to connect and press the capture button to select it.

13
Installation5
- When the camera is powered off and on, it automatically connects to the receiver
with the set number
- If it doesn't connect automatically after 20 seconds, you can connect manually
by double-clicking the capture button
Reference
More than 3 digits of number will display as "00" and you can check the whole number
with pressing M button
Reference
5. Dr's Viewer2 installation
- Download Dr's viewer if there is no any viewer software program
< Installation Dr’s Viewer2 screen >
If you are using any other
software, please contact
your supplier
Reference
6) when you press and hold on M button while the viewer is turned off, 3 digits number
of connected receiver will display
5) When "Air Direct connected" message shows up and connected well, receiver's number
will display in the main screen which is connected to wireless icon
Successful connection Number with at least 3 digitsNot connected with the receiver

ⓐ Capture button
ⓑ Left button ⓒ Right button
ⓓ Mode button
2) Mouse speed
- Select appropriate gyro mouse speed. (5 levels)
- Default level is 3
3) Turn off time
- Select turn off time of device (5, 10, 15, 20, 30 mins)
- Default time is 5 mins.
Installation5
6. Camera device setup
- Click and hold left button and right button for 3 seconds. Then the device is turn to setup mode.
- ⓐ Capture button: select
- ⓑ Left button: down
- ⓒ Right button: up
- ⓓ Mode button: Cancel
Reference
Capture key can be changed with “HIDDrs Manager” in the CD.
Reference
1) Capture key setting
- Select appropriate capture key
- Default value is “Space”
4) Autofocus & Autocapture
- Select “Disable” or “Enable”
- Default value is “Disable”
To avoid shaking image there is Auto capture function.
* Auto capture:
- Semi autofocus (Disable): Half click and hold the condition, image is captured after
1 seconds after get focus, and image is captured for every
2 seconds.
- Full autofocus (Enable): Half click is image capture and hold the condition,
image is captured for every 2 seconds.
Reference
Enjoy wireless
14

15
1. Turn on the device
- Click the capture button. Then the device turn on with LED blink with beep sound.
How to use6
Brightness change is worked on live image is on.
Reference
5. Brightness change
- Click mode button with mouse left button. Then LED brightness is changed.
Turn off ⇒ Brightness LV1 ⇒ Brightness LV2 ⇒ Brightness LV3 is rotated.
3. Mouse
- To move mouse cursor click mode button and shake the device.
Then mouse cursor is moved as device shacked.
2. Image capture
- Click camera icon on the DrsViewer2. Then live image is shown.
- Half click is focus adjusting, and click is image capture.
If the mode is full autofocus mode, half click is image capture.
Default setup is semi autofocus. And capture key is “Space”
To use other company software, need to check capture key.
Or need to use twain driver.
Reference
4. Color impression changing
- Click mode button and capture button on live image.
Then the color impression is changed.
- Original ⇒ Warm ⇒ Cool color impression is rotated.

Enjoy wireless
16
Black & White mode is worked on live image is on.
Reference
Normal ⇒ Black & White mode is rotated.
How to use6
6. Black & White mode
- Click mode button with mouse right button.
Then LED turn off, and live image changed to black & white mode.
7. Setup mode
- Click mouse left button and mouse right button both for 3 seconds.
Then setup mode is shown.
- About setup mode, please refer,
“5. Installation ⇒ 6. Camera device setup.”
9. Reset
- If the device doesn’t work normally, reset the device. Then the device will be reboot.
8. Turn off
- Click the capture button for 3 seconds, the device is turned off.
- The device is turned off automatically, if there is no signal for
minutes set on setup mode.
- User can adjust the sleep mode time for 5, 10, 15, 20, 25, and 30 minutes on setup mode.
- If wireless connection is not connected, device will be turn off after 2 minute.
Reference

17
Maintenance7
- Clean the camera and charger gently with clean, soft, lint-free cloth.
- Avoid using solvents which contain ethanol or acetone.
- Do not use sharp or pointed tools to clean as they may damage or scratch the plastic.
- Be careful not to spill any liquid into the device.
- Use disposable cover when use the device to avoid cross-infection and spilling any liquid
into the device.
Cleaning and disinfection
- Do not disassemble the device for any purpose.
- To replace the battery, please contact authorized dealer or manufacturer.
- It is recommended for rechargeable battery to be charged immediately before use to
maximize efficiency.
Maintenance and replacement of the battery.

Enjoy wireless
18
Trouble shooting8
If the device does not work normally, please refer to the following points.
Problem Cause and solution
If the button is pressed with excessive force, it will not work, try
pressing the button gently. And check the button condition.
If the device is not recognized well, the button could not work well.
Refer “5. Installation”, “6. How to use”
If connection between camera and receiver is not connected, the
button doesn’t work. Please avoid any barrier between camera and receiver.
If the battery voltage is extremely low, the device is not turned on.
Please charge the battery.
If the battery voltage is extremely low, the device could be turned off.
Please charge the battery.
Capture key-value would not match with other company dental viewer
software. Please check keyboard short-cut. If you don’t know it please
ask the dental viewer software vendor.
And check the key-value of device. Or use twain driver included.
If the device is not recognized well, live image is not shown.
Please check camera and receiver connection, and check imaging device
of device manager.
If there is TV tuner in the PC. The image could be not shown.
Check “Disable” the TV tuner device on the device manager.
If you use other company dental viewer software, it would be related with
its setting. Please ask to the dental viewer software vendor.
If you use other company dental viewer software, other imaging device
(ex. Web-cam, etc.) should be checked for “Disable”.
This device support only MJPG (MPEG) format. If you use other company
dental viewer software, please check the viewer support MJPG or MPEG.
Please ask to the dental viewer software vendor.
Some codec makes block or delay the live image shown.
Uninstall the codec file. (ex. klite codec and etc.)
* If the trouble is not fixed after following solution, please contact your local dealer or manufacturer.
Button doesn’t work
Display screen does
not work
Power off while in
operation
Not able to capture
Live image is not shown

Specification9
■Equipment Class
Model:
Trademark:
Power supply:
Receiver:
Protection from ingress of liquids:
IC-DCAM70
Dr’s Cam Air
3.7V Lithium Ion
5V USB power
IPX0 (ordinary equipment)
■Additional Information
Camera Operation voltage
Measurement
Weight
Resolution
Sensor/Lens type
3.7V
Approx. 255 x 30 x 28 mm
Approx. 89g
5M pixels
CMOS / Liquid lens
Charger Measurement
Weight
Operation voltage
Approx. 110 x 105 x 68 mm
Approx. 100 g
5V
Disposable cover Quantity
Raw material
Approx. 100 pcs by weight x 2ea
Polyethylene
Adapter Input voltage
Output voltage
UL number
AC 100 ~ 240 V
DC 5V 2A
E333054
■Minimum system requirement
PC system:
OS:
USB port:
(Internet access would need for some kinds of PC environments)
* Upper specification is changeable without prior notice.
3.3 Ghz CPU, 4GB RAM
Windows 7
USB 2.0
19
■Operation, transport, and storage condition for the main unit
Storage
10~40C
20~80%
Transport
-10~50C
20~80%
Temperature
Humidity
Atmospheric pressure
Operation
10~30C
10~80%
800 ~ 1360 hPa
■Symbol
This device conforms with the European Directive, 93 / 42 / EEC which
includes the requirements for electromagnetic compatibility
This symbol is appixed to fulfill the requirements of EU Directive 2012/19/EU
Article 11. This equipment cannot be disposed of as unsorted municipal
waste within the European Union. Follow local regulations for disposal.
SN Serial number oo oo oo oooo
Model / Month / Year / Serial Warning, Caution

Enjoy wireless
20
Specification9
Do not device on place where
get direct sunshine.
Transport temperature.
Reuse is not allowed
Accessories10
Power cable
(Part No. AC0111)
Adapter
(Part No. AC0105)
Prevent by wet.
Type B applied part
Authorized representative in the
European Community
Fragile item
No hooks
This box is paper recyclable.
Manufacturer
Check user manual.
Disposable plastic cover
(35 x 100mm / narrow)
(Approx.100pcs)
(Part No. AC0103)
1. Product
- Disposable Plastic Cover
2. Size
- Approx. 35 x 100mm
100 Sheets by weight
Sheets 100
Disposable
Plastic Cover
OPEN
Data USB
(Part No. AC0201)
Receiver-Air Direct
(Part No. AC0216)
EIOS
(Part No. AC0213)
