SPECIFICATIONS
RANGE HOODS
AR SERIES
180 CFM/7.0 Sones @ 0.10" WG. Horizontal,
180 CFM/7.5 Sones @ 0.10"WG. Vertical, 120 Volts, 2.1 amps, 60hz
•Dimensions
Overall bottom projection - 183/8"
Overall top projection -12"
Height - 6". Available widths: 30" & 36"
• Hood Body
23 gauge cold rolled steel, auto welded, coated with a baked
enamel finish.
• Motor
2 speed, single coil, thermally protected, permanently lubricated.
Rated 120 volts, 60 hz., 2.1 amps.
• Lighting
Single 60 watt cook light capacity (bulb not included).
• Ducting Options
Vertical ducting: 7" round (duct collar built into hood).
• Fan Blade
One piece polymeric, electronically balanced blade. 65/8"
diameter with 5 paddles.
• Electrical connection
Hood top - 7/8" electrical knockout.
Hood back - 7/8" electrical knockout.
12"
63/8"
511/16"297/8", 357/8"
6
7
/
8
"
AR SERIES
Canada: 110 Glidden Road
Brampton, Ontario L6T 2J3
Tel: [phone]
Fax: [phone]
U.S.: 820 Lincoln Drive
West Chester, Pennsylvania 19380-4466
Tel: [phone] • 877-304-3785
Fax: [phone]
Updated 2-07Specifications subject to change without notice.
• Filters
UL rated, class 2 filter.
Grease Filter: RF35 - 87/8"x103/8" (included).
• Available Finishes
White, Biscuit, Almond, Black & Stainless Steel.
CUS
PROJECT
LOCATION
CONTRACTOR
ARCHITECT
ENGINEER
SUBMITTED BY DATE
FAN MODEL CFM IN RPM WATTS AMPS SONES QTY OPTIONAL EQUIPMENT
NUMBER NUMBER W.G. & REMARKS
PERFORMANCE
HVI Sones Fan Speed Power
Static Pressure (inches of w.g.) @ .1 SP RPM Watts
0 0.05 0.1 0.125 0.15 0.2 0.25 0.3
Air Flow - CFM 203 191 180 167 148 124 101 82 7.5 2973 87
