AIRBOW SYSTEMS Airbow ABF-1000 User manual

Operating Instructions
Refer to the Airbow® website for more information. www.airbowsystems.com
AIRBOW SYSTEMS LTD
Assembly # ABF-1000

2 AIRBOW® FRAMER Operating Instructions
Contents
Introduction .……………………………………………………….......................................................3
Technical Description....................................................................................................4
Overview of AIRBOW® FRAMER .................................................................................5
Safety Instructions ................................................................................................ 6-10
Usage Instructions & Accessories..........................................................................11-18
Air Supply & Pressure Information …………….............................................................19
Maintenance/Servicing .............................................................................................20
General Trouble Shooting ..........................................................................................21
Warranty ......................................................................................................................22
AIRBOW PART NO. ABF-1000
DESCRIPTION: High Pressure Untethered Pneumatic
Fastener Driving Tool
AIRBOW SYSTEMS LTD
Suite 1, 283 Ponsonby Rd
Ponsonby 1011
Auckland
NEW ZEALAND
airbowsystems.com

AIRBOW® FRAMER Operating Instructions 3
Introduction
The AIRBOW® FRAMER harnesses a small amount of compressed air to
deliver serious power. And it does this completely untethered. It feels
amazing to fire, it works in the harshest weather conditions and it’s in the
business of saving money. We have completely reimagined how a framing
gun should fire nails.
The future of nail gun technology is here.
When we considered the challenges this nail gun would rise up against,
it was clear that only one fuel source would do.The AIRBOW® FRAMER
is untethered and draws its power from the air like never before.
The revolutionary new system is made possible by HAMMER FORCE
TECHNOLOGY®, which allows the AIRBOW® FRAMER to direct one gram of
compressed air into a single impact point.
The AIRBOW® FRAMER is a nail gun that is a true pneumatic tool that
operates solely on the power of compressed air and does it completely
untethered. The AIRBOW® FRAMER does not require butane fuel cells, has no
electronics, no battery, no combustion system, no cords and no cooling fan
because it does not need them. The AIRBOW® FRAMER is weatherproof and
performs in the rain, allowing projects to progress in all weather conditions. It
does not require any self-servicing or cleaning by the user and because it runs
on just compressed air it can’t overheat. The AIRBOW® FRAMER is designed
to fire any major branded 50mm – 90mm 34° D head collated nails with up
to 60 nails per collation.

4 AIRBOW® FRAMER Operating Instructions
Technical Description
Tool Dimensions: 390 mm (H) x 430 mm (L) x 120 mm (W)
Weight 3.980 kg
Maximum Fill Pressure: 310 Bar / 4,500 psi
Fill Gas: Fill with Dry Filtered Compressed Air ONLY
(DO NOT Fill with Oxygen or any other type of Gas.
Use only appropriately filtered high pressure air compressors on page 19
Fastener Type: 34° D Head Paper Collated Nails
Shank Diameter: Ø2.8 mm to Ø3.3 mm ONLY
Length: 50 mm to 90 mm ONLY
Material: Bright / Galvanised / Stainless Steel
Magazine Capacity: Allows for a collation strip of up to 60 nails (total 66 nails)
Dry Fire lock out: Last 6 nails
Cycle rate 3 nails per second – Intermittent operation
Noise Characteristics: Noise emission values in accordance with EN 12549 and EN ISO 4871
A-Weighted emission sound pressure level:
LpA: 92.5dB; Uncertainty KpA: 2.5dB;
A-Weighted sound power level:
LWA : 105.5dB; Uncertainty KWA: 2.5dB;
A-Weighted emission sound pressure level at workstation:
LpA: 106.5dB, KpA: 2.5dB;
Peak C-Weighted instantaneous sound pressure level at workstation
LpC,peak: 115.0dB; Uncertainty KpC,peak: 2.5dB;
Vibration: Vibration value in accordance with ISO 8662-11 and EN 12096
Vibration value: 3.7m/s2
Uncertainty of measurement: K=1.9m/s2
Lubrication: Factory/Service lubricated only
DO NOT add oil or any other lubricant to any part of the AIRBOW® FRAMER
Operating Temperatures: -10° C to 50°C
Trigger System: Single sequential trigger mechanism

AIRBOW® FRAMER Operating Instructions 5
Overview of the AIRBOW® FRAMER
Intended use
The tool is intended to drive a nail into wood or other suitable building materials.
The tool is to be used only for its prescribed purpose. Any other use is deemed to
be a case of misuse.
Onboard Canister
Pressure Gauge
Trigger
Onboard Canister covered by
Removable Protection Sleeve
Nail
Reload
Lever
Reload
Release
Safety Nail Catch
Nose Safety
Contact
Nail Depth
Adjustment Lever re-cock Lever
Safety Pressure
Release Button
Onboard Canister Pressure
Release Valve
Fill Valve
Reversible Belt Hook
SIDE B
SIDE A

6 AIRBOW® FRAMER Operating Instructions
• The AIRBOW® FRAMER should only be used in
surface contact with timber or other suitable
building materials.
• NEVER assume that the tool safety pressure
release valve is engaged.
• NEVER point the tool at yourself or others.
• DO NOT USE if work safety contact is damaged or
jammed in a depressed position.
• DO NOT USE if any parts are loose or missing.
• DO NOT USE if tool damaged or malfunctioning.
• KEEP YOUR HANDS CLEAR of the work surface to
prevent personal injury.
• Always KEEP OUT OF REACH of children.
• Fill with COMPRESSED AIR ONLY (Max
4500psi/310bar). Air from your high pressure air
compressor must be filtered as detailed on page
19 of this manual. Failure to do so will introduce
particulate to the AIRBOW® FRAMER and will
result in damage and could cause explosion.
• NEVER USE OXYGEN OR OTHER BOTTLED GASES
as explosion may occur.
• USE NO OIL on any part of this tool.
• OPEN Onboard Canister Pressure Release Valve
prior to COURIERING, AIR TRAVEL, SERVICING or
otherwise where there is a suspected issue with
the Onboard Canister.
• AVOID leaving in direct sunlight for a prolonged
period as an increase in temperature will increase
the internal pressure of the Onboard Canister
and potentially cause the maximum working
pressure rating of the Onboard Canister to be
exceeded.
• Avoid dropping from any height.
• For added safety and comfort, the belt hook is
reversible for either left hand or right hand use.
• In New Zealand it is necessary to complete
an Approved Filler Course to meet regulatory
requirements. Course information is available
and the theory component completed at
www.airbowsystems.com
DO NOT ATTEMPT TO FILL OR USE
THIS TOOL UNTIL THE FRAMER QUICK
GUIDE AND COMPRESSOR OPERATING
INSTRUCTIONS HAVE BEEN FULLY READ
AND UNDERSTOOD.Failure to follow
warnings could result in serious injury
or death.
Eye and Hearing Protection must be
worn by the operator and other people in
the work area when using this AIRBOW®
FRAMER. Eye protection must meet
the minimum requirements of AS/NZ
1337:1992 including side shields for
additional protection.
Keep fingers AWAY from trigger when
not driving fasteners to avoid accidental
firing
Safety yoke feature ensures no fastener
driving can be performed before the Nose
Safety Contact of the tool is pressed to
the workpiece
These safety instructions are required for the safe operation of the AIRBOW® FRAMER.

AIRBOW® FRAMER Operating Instructions 7
1. Only those fasteners listed in the operating
instructions may be used in the fastener
driving tools;
2. Only the main energy and the lubricants listed
in the operating instructions may be used;
3. Fastener driving tools marked with an inverted
equilateral triangle standing on one point may
only be used with an effective safety yoke;
4. For the maintenance of fastener driving tools,
only spare parts specified by the manufacturer
or his authorised representative shall be used;
5. Repairs shall be carried out only by agents
authorised by the manufacturer or by
other specialists, having due regard to the
information given in the operating instructions;
6. Fastener driving tools operated by compressed
air shall only be connected to compressed air
lines where the maximum allowable pressure
cannot be exceeded by a factor of more than
10%, which can for example be achieved by
a pressure reduction valve which includes a
downstream safety valve;
7. When using fastener driving tools operated
by compressed air, particular attention must
be paid to avoid exceeding the maximum
allowable pressure;
8. Hazards caused by fire and explosion when
using oxygen or combustible gases for
operating compressed air operated fastener
driving tools.
9. Do not operate tool in explosive atmospheres,
such as in the presence of flammable liquids,
gases or combustible dust.
10. The tool should not be modified unless
authorized in the tool manual or approved in
writing by the tool manufacturer.
11. Refer to the tool maintenance instructions
for detailed information on the proper
maintenance of a tool.
12. Use only accessories made or recommended
by the tool manufacturer, or accessories that
perform equivalently to those recommended by
the manufacturer.
13. The employer is responsible to enforce the
use of eye protection equipment by the
tool operator and all other personnel in the
work area.
14. Before operating, check for misalignment
or binding of moving parts and any other
condition that may affect tool operation.
15. Do not use a tool with missing or damaged
safety warning label(s.)
16. A tool that is not in proper working order must
not be used. Tags and physical segregation shall
be used for control.
17. Do not remove, tamper with, or
otherwise cause tool operating controls to
become inoperable.
18. Do not operate tool if any portion of the tool
operating controls is inoperable, disconnected,
altered, or not working properly.
19. Only persons who have read and understand
the tool operating/safety instructions should
operate the tool.
20. Always assume that tool contains fasteners.
21. Do not point tool toward yourself or anyone
whether it contains fasteners or not.
22. Keep bystanders and children away while
operating tool.
23. Do not actuate tool unless tool is placed firmly
against the workpiece.
24. Respect tool as a working implement.
25. Do not engage in horseplay.
26. Stay alert, focus on your work and use common
sense when working with tools.
27. Do not use tool while tired, after having
consumed drugs or alcohol, or while under the
influence of medication.
28. Do not overreach. Keep proper footing and
balance at all times.
29. Do not hold or carry tool with a finger on
the trigger.
30. Drive fasteners into proper work surface only.
31. Do not drive fasteners into other fasteners.
32. After driving a fastener, tool may spring back
(“recoil”) causing it to move away from the
work surface. To reduce risk of injury always
manage recoil by:
a. Always maintaining control of tool.
b. Allowing recoil to move tool away from
work surface.
c. Not resisting recoil such that tool will be
forced back into the work surface.
d. Keeping face and body parts away
from tool.
33. When working close to an edge of a
workpiece or at steep angles use care to
minimize chipping, splitting or splintering, or
free flight or ricochet of fasteners, which may
cause injury.
34. Keep hands and body away from fastener
discharge area of tool.
35. Do not load tool with fasteners when any one
of the operating controls is activated.
36. Do not operate tool with any power source
other than that specified in tool operating/
safety instructions.
37. Do not operate tool with any operating pressure
other than that specified in tool operating/
safety instructions.
38. Use extra caution when driving fasteners into
existing walls or other blind areas to prevent
contact with hidden objects or persons on other
side (e.g., wires, pipes.)
39. Do not lift, pull or lower tool by the hose.
40. Depressurise tool by pressing Safety Pressure
Release button when:
a. Not in use;
b. Performing any maintenance or repairs;
c. Clearing a jam;
d. Elevating, lowering or otherwise moving
the tool to a new location;
e. Tool is outside of the operator’s
supervision or control; or
f. Removing fasteners from the magazine.
Information From Applicable Standards

8 AIRBOW® FRAMER Operating Instructions
1. Damage to lungs if an effective dust mask is
not worn.
2. Damage to hearing if effective hearing
protection is not worn.
3. Damages to health resulting from vibration
emission if the tool is being used over longer
period of time or not adequately managed and
properly maintained
The declared vibration total value has been
measured in accordance with a standard test
method and may be used for comparing one tool
with another.
The declared vibration total value may also be used
in a preliminary assessment of exposure.
Warning
The vibration emission during actual use of the tool
can differ from the declared total value depending
on the ways in which the tool is used.
There is the need to identify safety measures to
protect the operator that are based on an estimation
of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).
Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors.
The following hazards may arise in connection with the tool’s construction and design:
Residual Risks

AIRBOW® FRAMER Operating Instructions 9
All pressure from the system and Onboard Canister can be safely and completely
released through use of the Onboard Canister Pressure Release Valve.
Once opened all pressure will bleed from the system and Onboard Canister until
there is no pressure remaining which renders the tool completely safe and unable
to operate. To use the tool again the valve must be closed and the Onboard Canister
refilled with compressed air.
This valve should be opened in the following situations;
• The tool has been dropped from a height such that it has been damaged or
there is any concern over the safety of the tool
• During a refilling inspection, there are
concerns over the Onboard Canister integrity through damage or misuse
• The tool is to be transported via aircraft or other such transport means
requiring the tool to be rendered completely safe and inoperable
Release of entire Onboard Canister Pressure:
End of day/use Safety Pressure release:
DEPRESSURISE
THE FIRING CHAMBER
When you are putting the tool down, or have
finished using, please push and hold Safety
Pressure Release button (listen for air release) to
depressurise the Firing Chamber & isolate the
Compressed Air Onboard Canister.
Pressure Related Safety Functions
Compressed Air
Onboard Canister
Firing Chamber
Firing Chamber
Isolated

10 AIRBOW® FRAMER Operating Instructions
Note: Onboard Canister is permanently attached and is NOT removable (other than
by an authorised Service Agent).
The compressed air Onboard Canister that is integrated into the AIRBOW® FRAMER
is a 1.1 litre composite Onboard Canister. It has an aluminium internal lining that
is wrapped with a carbon fibre outer. In New Zealand a Carbon Fibre Composite
Onboard Canister must be hydrostatically tested every 5 years. For all other
countries please refer to your local regulations on gas cylinders.
The Onboard Canister has a maximum fill/working pressure of 4500psi/310bar
and has been tested to 6750psi/ 465bar. It has a minimum burst pressure of
13500psi/930bar. Pressurised air (max 4500psi/310bar) from the Onboard Canister
flows up thru the regulator which reduces the pressure to operating pressure. This
is the pressure that is then stored in the Firing Chamber and is used to fire the nail.
The built-in regulator reduces the air pressure from the Onboard Canister before
it is stored in the Firing Chamber ready for nail firing. The regulator has built in
Pressure Release Devices (PRD’s) which will activate should there be a pressure
related issue. It is important to note that if the PRD/Burst disc is activated it will
not “burst” away from the regulator, it will simply allow air to escape and empty
the contents of the Onboard Canister while remaining in place. The AIRBOW®
FRAMER will require servicing should a PRD be activated.
PRD 1 is rated for high pressure activation - located before the pressure reducing
valve and is under full pressure from the Onboard Canister.
PRD 2 is rated for low pressure activation - located following the pressure reducing
regulator. If there is a problem with the Regulator and it does not reduce the
pressure from the Onboard Canister this is the Burst disc that will activate
Compressed Air Onboard Canister & regulator information:
Pressure Related Safety Functions

AIRBOW® FRAMER Operating Instructions 11
Usage Instructions
FILLING THE AIRBOW® FRAMER:
Fill with COMPRESSED AIR ONLY. Do not fill
with Oxygen or any other bottled gases as
explosion may occur. Fill to a maximum pressure
of 310bar/4500psi. Do not exceed.
Use only an Airbow® approved high pressure
compressor otherwise explosion may occur.
Refer to www.airbowsystems.com for further information.
Prior to first use ensure Cylinder Pressure
Release Valve is closed (Hand tighten with a
flathead screwdriver or nail head).
1
2Connect high pressure air compressor
to Airbow® Framer Fill Valve.
HOLD
RELEASE
Ensure properly connected.
i
ii
iii
iv

12 AIRBOW® FRAMER Operating Instructions
Usage Instructions
0
1
2
3
4
5
x1000 PSI
0
1
2
3
4
5
x1000 PSI
Onboard
Canister
Firing Chamber
Follow compressor instructions for compressor
set up. Ensuring appropriate cooling in place,
turn compressor on. Close pressure release valve
and check there are no leaks at connection points.
When Airbow® Framer pressure gauge
reaches 4,500 psi (310 Bar), turn compressor
off (if not auto shut off).
Disconnect high pressure air compressor
from Airbow® Framer, being sure to recap the
fill valve after filling.
WARNING: Compressor hose may whip if air
pressure is not released prior to disconnection.
Slowly unscrew pressure release valve. You will hear
a release of air pressure. Keep clear of air release.
Note 1: This Filling diagram is intended as a generic overview of the process
only. Before you undertake this process, please refer to your country’s
local regulations for any specific requirements regarding filling cylinders
with compressed air. Note 2: Be sure to read and understand your high
pressure air compressors operating instructions prior to use. Note 3: Using
a poorly filtered high pressure air compressor could introduce unwanted
particulate into your Airbow® Framer, resulting in damage to the framer
and potentially making it hazardous. It will also void your Framer Warranty.
Refer to www.airbowsystems.com for more information.
3
i ii
iviii
Firing Chamber
Isolated /
Onboard
Canister FULL

AIRBOW® FRAMER Operating Instructions 13
LOADING NAILS
Usage Instructions
i
Load Collated
Nails ONLY
from bottom of
magazine.
Continue moving the collated nails up until
they are above the Nail Safety Catch.
Push Nail Reload Lever
down over the nails...
...to bottom of collated nails. Release Nail Reload Lever
and click into place
1
2
i ii iii
ii
Uses a wide range of 34° D Head collated nail brands
(as listed on the Airbow® Website).
Capacity: 66 / Smooth & Ring.
50 - 90mm length. 2.8mm – 3.3mm gauge.

14 AIRBOW® FRAMER Operating Instructions
REMOVING NAILS
Usage Instructions
Hold & Press Nail Reload Lever.
Nails will fall naturally using gravity when
Airbow® Framer is held upright.
Depress Nail Safety Catch... ...and pull nails down over & out
bottom of magazine. (Ensure removed nails
are placed in an appropriate container).
Release Nail Reload Lever, it will rise
to the top and click into place.
1
i ii
iviii

AIRBOW® FRAMER Operating Instructions 15
PRESSURISING/USE OF THE FRAMING NAIL AIRBOW® FRAMER:
Usage Instructions
PRESSURISE THE FIRING CHAMBER
TIME TO
TOP UP
Pull until you feel a
second movement.
0
1
2
3
4
5
x1000 PSI
0
1
2
3
4
5
x1000 PSI
0
1
2
3
4
5
x1000 PSI
0
1
2
3
4
5
x1000 PSI
Required if the Airbow® Framer has been
depressurised using the Safety Pressure
Release process (See AFTER USE: P11).
To pressurise the Firing Chamber, pull
Re-cock Lever back slowly but firmly until
you hear the air transfer.
Note: You should
depressurise Firing Chamber
when you do not intend
firing nails. – See P11
BEFORE USE
Ensure Airbow® Framer is topped up
with Compressed Air.
Ensure Nails are loaded and Nail Reload
Lever is in place.
1
3
2
Onboard
Canister
Firing Chamber
Firing Chamber
Pressurised

16 AIRBOW® FRAMER Operating Instructions
Usage Instructions
AFTER USE
3 2 1 0 -1 -2 -3
DEPRESSURISE
THE FIRING CHAMBER
When you are putting
the tool down, or have
finished using, please push
and hold Safety Pressure
Release button (listen
for air release) to depressurise
the Firing Chamber
& isolate the onboard canister .
When in position to fire depress Nose Safety Contact
firmly against target first before pulling trigger.
As the onboard canister pressure hits its ‘Empty’ level
the Airbow® Framer will fire a ‘soft shot’ that leaves
the nail sticking out approx. 15mm. This indicates low
pressure and time to top up the Airbow® Framer.
NOTE: Magazine nail lock out will engage with approx.
5-6 nails left to prevent dry firing. DO NOT intentionally
dry fire the Airbow® Framer.
15mm
‘SOFT SHOT’
Choose the desired depth of fired nails by setting
the Nail Depth Adjustment Lever.
4 5
Onboard
Canister
Firing Chamber
Firing Chamber
Isolated

AIRBOW® FRAMER Operating Instructions 17
Couriering the Airbow®
Framer anywhere.
AIRBOW® FRAMERis to be
transported via air travel
There is a suspected issue with
the AIRBOW® FRAMER Onboard Canister.
Before any repairs are done to
the AIRBOW® FRAMER.
For long term storage open Onboard Canister
Pressure Release Valve to release all pressure
(listen for air release) from the Compressed Air
Onboard Canister. Leave valve open until next use.
As an accessory Airbow has a No Mar Tip (part # ABF-1042 Pack of 3) which, when
used in conjunction with the AIRBOW® FRAMER, will dramatically reduce the level of
marking on the timber substrate and reduce penetration depth”
Important
Releasing all pressure from the Onboard Canister
must be undertaken when:
General Safety:
• Always store your AIRBOW® FRAMER in the
case provided.
• Avoid leaving your AIRBOW® FRAMER in direct
sunlight for prolonged periods. Refer to page 18
Pressure Variations Relative To Temperature
• If tool is not being immediately used, it should
be depressurised to avoid accidental firing
Onboard
Canister
Firing Chamber
Open Onboard
Canister Pressure
Release Valve
Note: It is safe for the AIRBOW® FRAMER’s Onboard
Canister to remain under pressure during normal
daily transportation by motor vehicle however we
recommend pushing the Safety Pressure Release
button (rear of re-cock Lever) to depressurise & isolate
the Firing Chamber for transportation as a safety
precaution.
LONG TERM STORAGE AND GENERAL SAFETY INSTRUCTIONS
NO MAR TIP
Usage Instructions

Before attempting to remove jammed nails you MUST ISOLATE THE FIRING
CHAMBER by pressing the Safety Pressure Release button at back of AIRBOW®
FRAMER.
(Press and hold until all air released from Firing Chamber).
1. Remove the remaining nails from the magazine.
2. Loosen the 2 screws located near the Nose Depth Adjustment lever. This will
also loosen the nail jammed in the nose channel.
3. Clear the jam by pulling nails jammed out the front of the nose using
plyers etc.
4. Retighten the 2 screws you loosened. Do not over tighten.
5. Load with nails and then re-cock the AIRBOW® FRAMER so that the Firing
Chamber
is primed.
6. Fire into target substrate. First shot will likely be a dry fire as the
AIRBOW® FRAMER re-cocks itself.
Loosen only the 2 outside screws with an Allen
key. It is not necessary to remove the magazine
CLEARING A NAIL JAM
Usage Instructions
18 AIRBOW® FRAMER Operating Instructions

Air Supply & Pressure Information
Your AIRBOW® FRAMER requires a high pressure, clean, dry air source to
operate.
High pressure air compressors use multistage compression chambers to produce
air at very high pressure.
A normal site air compressor can’t generate the pressure required to drive the
AIRBOW® FRAMER’s specialised & highly efficient firing mechanism.
Attempting to connect a different pressure source will not work and could void
the warranty.
The Airbow Framer can be used with any high pressure compressor as long
as certain requirements regarding maximum fill pressure, oil and moisture
content are met. Please contact Airbow with details of the compressor you are
considering using.
Using a poorly filtered high pressure air compressor could introduce unwanted
particulates or contaminants into your AIRBOW® FRAMER, resulting in damage
to the FRAMER and potentially causing explosion and will void warranty.
Not all high pressure (HP) compressors operate in the same way.
It is therefore important for you to familiarise yourself with the correct
operating procedure for your HP Compressor.
Appropriate and timely maintenance of your compressor ensures good air
quality for your AIRBOW® FRAMER.
High pressure compressors which integrate an automated shut off pressure
switch are highly recommended to make filling easy and avoid over pressurising
the AIRBOW® FRAMER.
If the maximum fill pressure is exceeded the high pressure burst disk will
activate, and the AIRBOW® FRAMER will need to be serviced to allow it to be
filled again.”
The pressure in the canister on your tool can be effected by the ambient
temperature. It is safest to not leave your AIRBOW® FRAMER in direct sunlight for
prolonged periods as the resultant pressure increase could activate the Pressure
Release Device (requiring a tool service)
HIGH PRESSURE AIR COMPRESSORS: PRESSURE VARIATIONS RELATIVE TO TEMPERATURE:
AIRBOW® FRAMER Operating Instructions 19

20 AIRBOW® FRAMER Operating Instructions
Maintenance/Servicing
The AIRBOW® FRAMER has been designed to minimise servicing requirements
for the end user through use of high grade seals and long-life high specification
lubricants. As the AIRBOW® FRAMER has a closed pressure system it has no air
intake, thus it has no special dust or filters to clean or replace.
Always transport the AIRBOW® FRAMER within its tool case, first depressing the
Safety Pressure release. If transporting the AIRBOW® FRAMER via aircraft then the
Onboard Canister Pressure Release valve should be left open so that there is no
pressure in the Onboard Canister/system (Also check for any specific local aviation
rules prior to transport).
It is recommended that the AIRBOW® FRAMER be checked regularly to ensure that
no screws have come loose which could result in tool damage and possible user
injury.
Wipe down your AIRBOW® FRAMER with a clean cloth particularly when used
in dusty/damp conditions, do not use solvent based cleaners as this may cause
damage to the plastics and soft grip materials.
DO NOT attempt to remove the Onboard Canister from the AIRBOW® FRAMER,
however the onboard canister cover can be removed as required to inspect the
certification details and test dates on the Onboard Canister label.
DO NOT add oil or other lubricant to the air filling system as this could result in tool
damage and possible user injury.
It is recommended that the AIRBOW® FRAMER is fully serviced at 12mth intervals,
or every 6mths for applications of high volume/factory use.
Repairs and servicing shall only be carried out by Airbow Systems or its authorised
agents to ensure that the correct long-life parts/lubricants are used to ensure the
safe working condition of this tool can be verified.
