Aircalo PB 172 Manual

1
INSTALLATION AND
MAINTENANCE MANUAL
ROOM THERMOSTAT
« PB 172 »

2
DESCRIPTION
This is an easy-to-use MECHANICAL THERMOSTAT. It allows an
accurate room temperature a justment in the hosting room,
thus meeting any users’ nee s as far as room comfort.
CONFORMITY TO THE STANDARDS
This pro uct complies with:
- EN 60730-1 an subsequen revisions
- EN 60730-2-9
CONFORMITY TO THE GUIDELINES
This pro uct complies with:
-LVD 2014/35/EU
-Class ErP I (+1%) - EU 811/2013
TECHNICAL DATA
TEMPERATURE RANGE = 5°÷30°C
TEMPERATURE DIFFERENTIAL = 0,4K÷0,8K
DEGREE OF PROTECTION = IP 20
INSULATION CLASS =
TEMPERATURE RATE OF CHANGE = 1K/15min.
OUTPUT = switching contacts
CONTACTS RATING = 16(2,5)A/250V~ (example : up to 7 ELIS max. I
abs
ELIS = 0,33A)
SWITCH ACTION = 1B
POLLUTION DEGREE = (2)
MAXIMUM STANDING TEMPERATURE = 50°C
STORAGE TEMPERATURE = 0°÷50°C
MOUNTING = to the wall
RATED IMPULSE VOLTAGE = 4kV
THERMOSTAT CONTROL KEYS
1 = Temperature setting knob
2 = Warning lamp
3 = ON/OFF switch

3
INSTALLATION AND CONNECTIONS
SAFETY INSTRUCTIONS
Before connecting the thermostat, make sure
that the supply voltage of the
UNIT TO BE CONTROLLED (boiler, pump, air-
con itioning system, etc.) is NOT
CONNECTED an that it matches the in ication
given insi e the appliance
(250V~ max).
PLACEMENT OF THE THERMOSTAT
Install the thermostat away from heat sources
(ra iators, sunrays, an kitchens) an away from
oors/win ows, at approx. 1,5 m height from
the floor.
INSTALLATION AND WIRING CONNECTIONS
Remove the front cover from the thermostat
base by releasing the provi e clip
Threa the power supply wires through the slot
in the base an connect them to the terminals as
per the wiring iagram sketche insi e the
appliance.
Snap the front cover back.
WARNING:
It is recommen e to install the
appliance strictly in compliance with all
safety an law provisions in force.

4
TURNING THE THERMOSTAT ON AND OFF
Put the switch onto the “ON” position to start
the equipment or onto the “OFF” to turn it off.
TEMPERATURE SETTING
When the appliance is connecte an the
electric power is switche on, set the esire
room temperature simply by turning the
temperature-a justing knob to the
correspon ing value on the gra uate scale.
PROBLEM SOLVING
PROBLEM POSSIBLE CAUSE SOLUTION
The system oes not start Wrong wiring Check if the wiring connections
to the thermostat terminals were
carrie out as per wiring iagram
The set room temperature has
been alrea y reache
Increase or re uce the set
temperature value accor ing to
the system application
(heating/air-con itioning system)
Switch on OFF position Put switch onto ON position
The ambient temperature oes
not correspon to the
temperature set on the
thermostat
Incorrect positioning of the
thermostat within the room
Follow the instructions of
paragraph “Placement of the
thermostat”
Air raughts coming from the
electrical wires con uit
Seal the con uit to prevent
warm or col air raughts
NOTE:in cas of r p at d malfunctioning, pl as call our T chnical S rvic . Do not tamp r for any r ason
with any part of th th rmostat.
Tel : [phone] - Fax [phone]
www.aircalo.fr
14 Avenue Cassiopée
33160 Saint-Médard-en-Jalles
M PB172-05-17_UK
