AirCycler® g2-k Installation Testing Guide
®
Ventilation Products
Testing the AirCycler® g2-k completed installation is an easy
two step process:
STEP 1 Test the FanConnect(tm) connection & operation
STEP 2 Test thermostat, damper and furnace connection and
operation
STEP 1
a. With the thermostat o, turn on the FanConnect
switch.
b. Conrm the exhaust fan is running.
c. The AirCycler®g2 display should show the
Exhaust fan is on and the OA damper is open.
d. Conrm the OA damper is open.
e. Turn o exhaust fan.
PERCENTAGE OF
VENTILATION COMPLETE
EXH - EXHAUST
FAN IS ON OA - FRESH AIR
DAMPER IS OPEN
LCD DISPLAY
a. Make sure exhaust fan is o.
b. Turn thermostat FAN switch to ON.
c. Conrm AirCycler®g2 display show’s FAN and OA
damper open.
d. Conrm furnace fan is running.
e. Remover AirCycler®g2 from it’s base. Furnace fan
should shut o..
f. DONE! Replace AirCycler®g2 controller on it’s base.
STEP 2
LCD DISPLAY
OA - FRESH AIR
DAMPER IS OPEN
PERCENTAGE OF
VENTILATION COMPLETE
FAN ON FROM
THERMOSTAT
See reverse for troubleshooting tips and frequently asked questions

HINTS & TIPS
• Make sure the FanConnect switch is in the OFF position when the AirCycler g2 controller is rst
powered on.
• Setup is easier to start without the battery installed. The battery is only used for the real time clock.
If you are not using the operating hours options, the battery is not needed.
TROUBLESHOOTING
No power?
Check common wire connection. “C” must be connected to “C” on the furnace.
EXH icon is ashing
If the EXH icon is ashing it is indicating that the FanConnect switch has been on for more than four
hours or has lost connection with the g2 controller.
My furnace fan runs constantly
Make sure the thermostat FAN switch is set to AUTO and not ON.
Fan does not shut o when AirCycler®g2 is removed from its base (when thermostat fan switch
is on) Check wiring - G wire from thermostat should not be wired to Gt on AirCycler. Gf on AirCycler
should be connected to G on furnace.
FAQ
Will the AirCycler controller lose the settings if the power fails?
No, all settings are saved in non-volatile memory. No battery is needed.
The AirCycler g2 has a small lithium battery to keep the clock running if you are not ventilating 24hrs
a day and are using that feature. It will maintain the time without power for at least 14 days.
Can I run multiple FanConnect switches o of one AirCycler® g2 controller?
No. For additional bathrooms use the SmartExhaust bath fan/light switch as an independent controller.
®
