AirMind mindpx User manual

Autopilot System
!
User Guide
!!
MINDPX

Component List
!
1. MindPX
7. USB cable
2. 6-pin cable
8. M2 countersink screw ×6
3. 4-pin cable
9. Light pipe ×2
4. 4 to 6 pin convertor cable
10. 3M tape
5. PPM encoder
11. TF card
6. Voltage/Current detector
12. Buzz
1

Quick self check
Before mounting please perform following quick check for any potential damages to
MindPX during logistic:
1. Check if any pin headers on the rear are bended or contacted
2. Check if the enclosed case is broken or damaged
3. Check if accessories are intact
If any situation above, please contact your local sales representatives for
replacement.
1. Mounting
2. Wiring
3. Calibrating
Quick Start
MindPX can control 2-rotors, 3 rotors, 4
rotors and 6 rotors. Follow the instructions to
quickly start your air journey!
2

1.Mounting
-Adhere on the bottom of MindPX as illustrated
-Attach MindPX to the frame. Please keep the front of MindPX
consistent with frame’s front.
-Attach MindPX to the frame. Please keep the front of MindPX
consistent with frame’s front.
■Airframe Orientation
!
3
Adhere 3M tape here
Heading
M2
M3
M2
M3

2. Wiring
4
PPM
encode
Buzz
ESC
PWM pins should be
connected to the
corresponding
motors as they are
numbered in Figure
Airframe
Orientation .

5
Power module
Data transmission

!
6
MindFlow
TF card
GPS/Compass module

PIN
!
!
1. Power
9. I2C2 (MindFLow)
2. Debug (refresh bootloader)
10. USB2 (Serial 2 to )
3. USB1 (refresh firmware)
11. UART4,5
4. Reset
12. UART1 (Transmission)
5. UART3 (GPS)
13. CAN
6. I2C1(external compass)
14. ADC
7. TF card slot
15. Tricolor Light
8. NRF/SPI(Remote Control)
16. Looper
Looper
7

3. Calibrate
Before you take off you need to calibrate the copter first. QGroundControl
needs to be installed first which can be downloaded from:
http://www.qgroundcontrol.org/downloads
Install QGroundControl
1. Agree License
!
2. Select installation path
!
3. Start installation
8

!
4. Install PX4 driver
!
5. Agree driver software license
9

!
6. Select driver installation path
!
7. Start driver installation
10

!
8. Continue driver installation
!
9. Finish PX4 driver installation
11

!
!
10. finish QGroundcontrol installation
12

!
The calibration process
Connect MindPX USB1 port to your PC with USB cable, and start
QGroundcontrol.
1. Drop down “connect” menu on top right corner, and select pixhawk on
COMx(depending on your computer configuration)
2. Select frame type
- After frame selected, the “airframe” label on the left will turn from red to
green, indicating setting is successful. The corresponding label will turn to
green after each calibration succeeds.
13

!
!!
■Calibration for 250 frames
Because QGroundControl doesn’t originally support 250 frames, at the first
step of calibration, you should choose DJI Flame Wheel 330 as a
replacement. Before taking off, it is necessary to adjust parameter of airframe
330.
Choose PARAMETER Tab, adjust PID parameters in Multicopter Attitude
Control, set MC_PITCHRATE_P, MC_ROLLRATE_P to 0.1，
MC_YAWRATE_P to 0.22.
14

3. Caliberating remote controller
-Mode 1 is set to left throttle, Mode 2 is set to right throttle.
!
15

!
-Move throttle stick according to prompts in software
!
!
-Move all the transmitter switches/dials to their extreme position
16

!
-Skip remaining steps
!
!
17

!
!
4. Configure Channels
-Set main mode to channel 5, set position control to channel 6 (channel
number may vary depending on your remote controller)
18

!!
■Use channel 5 to select between 3 modes: manual mode, assist mode, and auto
mode.
■Under assist mode, use channel 6 to switch between altitude-control mode or
position-control mode
5. Sensor Calibration
Compass
19
