UHF FM TRANSCEIVER
AR-440
SERVICE MANUAL
CIRCUIT DESCRIPTION ............................ 2
SEMICONDUCTOR DATA ........................ 8
COMPONENTS DESCRIPTION ................ 9
PARTS LIST ............................................. 10
EXPLODED VIEW.................................... 17
PACKING ................................................. 18
RESETTING THE TRANSCEIVER ........... 19
ADJUSTMENT ........................................ 20
TERMINAL FUNCTION ........................... 27
PC BOARD
DISPLAY UNIT (X54-3450-10) ............ 28
TX-RX UNIT (X57-686X-XX)............... 30
SCHEMATIC DIAGRAM.......................... 34
BLOCK DIAGRAM ................................... 38
LEVEL DIAGRAM .................................... 40
SPECIFICATION ................... BACK COVER
CONTENTS
AJETRAYS LLC 2010
Microphone
(T91-0641-05)
Cabinet
Panel assy
(A62-1102-03)
Knob (Encoder)
(K29-9293-03)
Key top
(K29-9291-01)
Knob (Volume)
(K29-9292-03)
(A01-2193-01)
AR-440
2
Frequency Configuration
The receiver utilizes double conversion. The first IF is
49.95MHz and the second IF is 450kHz. The first local oscil-
lator signal is supplied from the PLL circuit.
The PLL circuit in the transmitter generates the necessary
frequencies. Figure 1 shows the frequencies.
CIRCUIT DESCRIPTION
Receiver System
The receiver is double conversion superheterodyne. The
frequency configuration is shown in Figure 1.
■Front-end RF Amplifier
An incoming signal from the antenna is applied to an RF
amplifier (Q353) after passing through a transmit/receive
switch circuit (D603, D604 and D605 are off) and a BPF
(L359, L358 L360, L361 and varactor diodes : D353, D354,
D355). After the signal is amplified (Q353), the signal is fil-
tered by a BPF (L354, L355 and varactor diodes: D351, D352)
to eliminate unwanted signals before it is passed to the first
mixer.
The voltage of these diodes are controlled by tracking the
CPU (IC101) center frequency of the band pass filter. (See
Fig. 2.)
■First Mixer
The signal from the RF amplifier is heterodyned with the
first local oscillator signal from the PLL frequency synthesizer
circuit at the first mixer (Q352) to create a 49.95MHz first
intermediate frequency (1st IF) signal. The first IF signal is
then fed through one pair of monolithic crystal filter (MCF :
XF351) to further remove spurious signals.
ANT
SW
RF
AMP
1st
MIX
AF
PA
TCXO
MIC
AMP
X3
multiply
RF
AMP
POWER
AMP
CF 450kHz
MCF
49.95MHz
IF SYSTEM
PLL/VCO
16.8MHz
50.4MHz
ANT
RX
TX
SP
MIC
Fig. 1 Frequency configuration
■IF Amplifier
The first IF signal is amplified by Q351, and then goes to
IC301 (FM processing IC). The signal is heterodyned again
with a second local oscillator signal within IC301 to create a
450kHz second IF signal. The second IF signal is then fed
through a 450kHz ceramic filter (Wide : CF301, Narrow :
CF302) to further eliminate unwanted signals before it is am-
plified and FM detected in IC301.
Item Rating
Nominal center frequency 49.95MHz
Pass bandwidth ±5.0kHz or more at 3dB
35dB stop bandwidth ±20.0kHz or less
Ripple 1.0dB or less
Insertion loss 5.0dB or less
Guaranteed attenuation 80dB or more at fo±1MHz
Spurious 40dB or more
Terminal impedance 350Ω/ 5.5pF
Table 1 Crystal filter (L71-0620-05) : XF351
Item Rating
Nominal center frequency 450kHz
6dB bandwidth ±6.0kHz or more
50dB bandwidth ±12.5kHz or less
Ripple 2.0dB or less
Insertion loss 6.0dB or less
Guaranteed attenuation 35.0dB or more within fo±100kHz
Terminal impedance 2.0kΩ
Table 2 Ceramic filter (L72-0993-05) : CF301
Item Rating
Nominal center frequency 450kHz
6dB bandwidth ±4.5kHz or more
50dB bandwidth ±10.0kHz or less
Ripple 2.0dB or less
Insertion loss 6.0dB or less
Guaranteed attenuation 60.0dB or more within fo±100kHz
Terminal impedance 2.0kΩ
Table 3 Ceramic filter (L72-0999-05) : CF302
ANT
L358~361
D353~355
BPF
Q353
RF AMP
Q351
IF AMP
IC161
D/A CONVERTER
Q352
MIX
XF351
MCF
D601~
D604
ANT
SW
IC203
DC AMP
IC161
D/A
Q302
X3 multiply
X401
TCXO
IC301
IF system
1st local
OSC (VCO/PLL)
W/NO
(EVOL2)
CF301 (Wide)
CF302 (Narrow)
TV
CPU
L354,355
D351,352
BPF
Fig. 2 Receiver system
AR-440
3
■Wide/Narrow Switching Circuit
The Wide port (pin 65) and Narrow port (pin 64) of the CPU
is used to switch between ceramic filters. When the Wide
port is high, the ceramic filter SW diodes (D303, D302) cause
CF301 to turn on to receive a Wide signal.
When the Narrow port is high, the ceramic filter SW diodes
(D303, D302) cause CF302 to turn on to receive a Narrow sig-
nal. (See Fig. 3.)
■AF Signal System
The detection signal from IF IC (IC301) goes to D/A con-
verter (IC161) to adjust the gain and is output to AF filter
(IC251) for characterizing the signal. The AF signal output
from IC251 and the DTMF signal, BEEP signal are summed
and the resulting signal goes to the D/A converter (IC161).
The AFO output level is adjusted by the D/A converter. The
signal output from the D/A converter is input to the audio
power amplifier (IC252). The AF signal from IC252 switches
between the internal speaker and speaker jack (J1) output.
(See Fig. 4.)
■Squelch Circuit
The detection output from the FM IF IC (IC301) passes
through a noise amplifier (Q301) to detect noise. A voltage is
applied to the CPU (IC101). The CPU controls squelch ac-
cording to the voltage (SQIN) level. The signal from the RSSI
pin of IC301 is used for S-meter. The electric field strength of
the receive signal can be known before the SQIN voltage is
input to the CPU, and the scan stop speed is improved.
Narrow
IC101 64pin
IF_IN MIX_O
IC301
IF System
CF302
(Narrow)
CF301
(Wide)
R320
R319
R317
R318
D303 D302
Wide
IC101 65pin
AF
Filter
D/A
CONV.
D/A
CONV.
IC161 IC251 IC161
W/NO
(EVOL2) AF PA
IC252 SP
IF IC
IC301
Q301
NOISE AMP D301IC301 IC101
AFO
RSSI
DET
CPU
IF
SYSTEM
SQIN
RSSI
Fig. 3 Wide/Narrow switching circuit
Fig. 4 AF signal system
Fig. 5 Squelch circuit
PLL Frequency Synthesizer
The PLL circuit generates the first local oscillator signal for
reception and the RF signal for transmission.
■PLL
The frequency step of the PLL circuit is 5 or 6.25kHz. A
16.8MHz reference oscillator signal is divided at IC401 by a
fixed counter to produce the 5 or 6.25kHz reference fre-
quency. The voltage controlled oscillator (VCO) output signal
is buffer amplified by Q410, then divided in IC401 by a dual-
module programmable counter. The divided signal is com-
pared in phase with the 5 or 6.25kHz reference signal in the
phase comparator in IC401. The output signal from the
phase comparator is filtered through a low-pass filter and
passed to the VCO to control the oscillator frequency. (See
Fig. 6)
■VCO
The operating frequency is generated by Q406 in trans-
mit mode and Q405 in receive mode. The oscillator fre-
quency is controlled by applying the VCO control voltage,
obtained from the phase comparator, to the varactor diodes
(D405 and D406 in transmit mode and D403 and D404 in
receive mode). The TX/RX pin is set high in receive mode
causing Q408 and Q407 to turn Q406 off, and turn Q405 on.
The TX/RX pin is set low in transmit mode. The outputs
from Q405 and Q406 are amplified by Q410 and sent to the
RF amplifiers. (See Fig. 6.)
D405,406
Q406
TX VCO
Q410
BUFF
AMP
D403,404
Q405
RX VCO
Q407,408
T/R SW
Charge
pump
LPF
Phase
comparator
1/M
1/N 5kHz/6.25kHz
5kHz/6.25kHz
REF
OSC
16.8MHz
PLL
DATA
IC401 : PLL IC
Q404
AMP
RF amplifiers
Q402,403
TX/RX (CPU)
Fig. 6 PLL circuit
CIRCUIT DESCRIPTION
AR-440
4
■Unlock Circuit
During reception, the 8RC signal goes high, the 8TC signal
goes low, and Q34 turns on. Q33 turns on and a voltage is
applied to 8R. During transmission, the 8RC signal goes low,
the 8TC signal goes high and Q36 turns on. Q35 turns on and
a voltage is applied to 8T.
The CPU monitors the PLL (IC401) LD signal directly.
When the PLL is unlocked during transmission, the PLL LD
signal goes low. The CPU detects this signal and makes the
8TC signal low. When the 8TC signal goes low, no voltage is
applied to 8T, and no signal is transmitted. (See Fig. 7.)
IC101
CPU
Q34
SW
Q33
SW
IC401
PLL
Q36
SW
Q35
SW
LD
8RC
8C
8R 8T
8TC
PLL lock
: LD “H”
Fig. 7 Unlock circuit
Transmitter System
■Outline
The transmitter circuit produces and amplifies the desired
frequency directly. It FM-modulates the carrier signal by
means of a varicap diode.
■Power Amplifier Circuit
The transmit output signal from the VCO passes through
the transmission/reception selection diode (D409) and ampli-
fied by Q500, Q501, Q502 and Q503. The amplified signal
goes to the final amplifier (Q504) through a low-pass filter.
The low-pass filter removes unwanted high-frequency har-
monic components, and the resulting signal is transmitted
through the antenna terminal. (See Fig. 8.)
■APC Circuit
The automatic transmission power control (APC) circuit
detects part of a final amplifier (Q504) output with a diode
(D606, D607) and applies a voltage to IC501. IC501 com-
pares the APC control voltage (PC) generated by the D/A con-
verter (IC161) and DC amplifier (IC203) with the detection
output voltage. IC501 generates the voltage to control Q502,
Q503 and Q504 and stabilizes transmission output.
The APC circuit is configured to protect over current of
Q502, Q503 and Q504 due to fluctuations of the load at the
antenna end and to stabilize transmission output at voltage
and temperature variations. (See Fig. 9.)
RF
AMP
Q500
DRIVE
AMP2
Q503
DRIVE
AMP1
Q502
FINAL
AMP
Q504
PRE
DRIVE
AMP
Q501
DC
AMP
IC203
ANT
SW
D601~D605
LPF
ANT
POWER
DET
D606
D607
IC501
APC
CONTROL
D409
IC161
(PC/TVO)
VR601
(PC)
Fig. 9 APC circuit
Fig. 8 Transmitter system
CIRCUIT DESCRIPTION
Q500
RF AMPRF AMP
Q501
PRE
DRIVE AMP
Q503
ANT
DRIVE
AMP 2
Q502
DRIVE
AMP 1
Q504
FINAL
AMP
Q411
IC161 Q406
D/A
CONVERTER
D/A
CONVERTER
D/A
CONVERTER
X401
TCXO
16.8MHz
VCO
IC401
PLL
Q410
BUFFER
Q404
RF AMP
IC203
BUFFER
IC101
IC161
MIC KEY
INPUT CPU
IC161
IC203
SUM
AMP
IC202IC201
MIC
MIC/IDC SPLATTER
FILTER
AR-440
5
Control Circuit
The CPU carries out the following tasks (See Fig. 10.):
1) Controls the WIDE, NARROW, TX/RX outputs.
2) Adjusts the AF signal level of the AF filter (IC251) and
turns the filter select compounder on or off.
3) Controls the display unit.
4) Controls the PLL (IC401).
5) Controls the D/A converter (IC161) and adjusts the vol-
ume, modulation and transmission power.
■Memory Circuit
The transceiver has an 64k-bit EEPROM (IC66). The
EEPROM contains adjustment data. The CPU (IC101) con-
trols the EEPROM through three serial data lines. (See Fig.
11.)
IC161
D/A
converter
IC401
PLL
IC101
CPU
LD
DT
CK
PLLE
EEPCK
IC101
CPU
IC66
EEPROM
EEPSDT
EEPWP
■Display Circuit
The CPU (IC101) controls the display LCD and LEDs.
When power is on, the LCD driver will use the BL line to con-
trol the LCD illumination and key backlight LEDs.
The brightness function is controlled by the switch Q12.
The LCD driver (IC3) and CPU (IC101) communicate through
the CE, CL, DI, DO lines. (See Fig. 12.)
■Key Matrix Circuit
The AR-440 front panel has function keys. Each of them
is connected to a cross point of a matrix of the KI1 to KI3 and
KS1 to KS2 ports of the LCD driver.
The LCD driver monitors the status of the KI1 to KI3 and
KS1 to KS2 ports. If the state of one of the ports changes,
the LCD driver assumes that the key at the matrix point corre-
sponding to that port has been pressed.
■Encode
The DCS and CTCSS signals are output from QT/DQT of
the CPU (IC101) and summed with the external pin DI line by
the summing amplifier (IC203) and the resulting signal goes
to the D/A converter (IC161). The DTMF signal is output from
DTMF pin of the CPU and summed with a MIC signal by the
summing amplifier (IC203), and the resulting signal goes to
the D/A converter (IC161).
The D/A converter (IC161) adjusts the MOD level and the
balance between the MOD and CTCSS/DCS levels. Part of a
CTCSS/DCS signal is summed with MOD and the resulting
signal goes to the VCOMOD pin of the VCO. This signal is
applied to a varicap diode in the VCO for direct FM modula-
tion.
IC3
LCD
driver
KI1
KI2
KI3
KS2
KS1
FUNC
REV
CALL
VFO
MR
MHz
(Encoder)
X401
TCXO
IC161
D/A VCO
IC203
SUM
AMP
IC203
SUM
AMP
IC401
PLL
TCXO
MOD
VCO
MOD
Amp
DI
QT/DQT
(CPU1)
DTMO
(EVOL15)
IC101
CPU
TONE
DTMF
Fig. 10 Control circuit
Fig. 11 Memory circuit
Q10
SW
Q6
SW
IC101
CPU
D2~D4
Q9
SW D19~D30
Q12
SW
IC3
LCD
driver
CE
CL
DI
DO
BL
COM0~
COM3
SEG0~
SEG30
LCD
BRI
Fig. 12 Display circuit
Fig. 13 Key matrix circuit
Fig. 14 Encoder
CIRCUIT DESCRIPTION
AR-440
6
■Decode
• CTCSS/DCS
The signal (W/NO (EVOL2)) goes to DTMF IN (pin 95) of
CPU (IC101). The CTCSS/DCS signal will pass through the
low-pass filters in the CPU (IC101) and be decoded within the
CPU (IC101). The DTMF signal will be decoded within the
CPU (IC101).
■D/A Converter
The D/A converter (IC161) is used to adjust MO modula-
tion, AF volume, TV voltage, FC reference voltage, and PC
POWER CONTROL voltage level.
Adjustment values are sent from the CPU as serial data.
The D/A converter has a resolution of 256 and the following
relationship is valid:
D/A output = (Vin – VDAref) / 256 x n + VDAref
Vin: Analog input
VDAref: D/A reference voltage
n: Serial data value from the microprocessor (CPU)
Power Supply Circuit
When the power switch on the display unit is pressed, the
power port on the display unit which is connected port 17
(POWER), goes low, then port 82 (SBC) goes high, Q32 turns
on, SB SW (Q31) turns on and power (SB) is supplied to the
radio.
When the DC power supplied to the radio, the voltage
regulator IC (IC33) supply into the CPU VDD and reset voltage
detect IC (IC34). IC34 will generate signal (RESET) in to the
reset terminal on the CPU (IC101) to carry out a power ON
reset. If DC power is less than about 9.5V, the radio is unable
to power on.
When the DC power voltage deceases from normal volt-
age, the INT voltage detector IC (IC35) will set to high on CPU
port 18 (INT) if B line will became less than about 9.5V. Then
CPU send to EEPROM (IC66) the backup data and go into
STOP mode.
This circuit has an overvoltage protection circuit. If a DC
voltage of 18V or higher is applied to the base of Q61, this
voltage turns Q61 on and will set to high on CPU port 18
(INT). Then CPU send to EEPROM (IC66) the backup data
and go into stop mode. (See Fig. 16.)
IC101
CPU
DTMF IN W/NO (EVOL2)
95
Q71
SW
Q31
SW
Q32
SW
Q61
SW
IC33
AVR
D61D62
B
IC34
RST
SBC
IGN
R77R76
R39R40
INT
5M
BATT
IC101
CPU
POWER
SW
POWER
RESET
5M
IC35
INT
SB
IGN
Fig. 15 Decode
Fig. 16 Power supply circuit
CIRCUIT DESCRIPTION
Data Terminal and Peripheral Circuits
CN2 (data terminal) is the data communications terminal
on the TX/RX PCB. It handles transmission control, data in-
put/output, and squelch signals.
There are two data communications modes : 9600bps
mode and 1200bps mode. Unlike with 1200bps AFSK, with
this type of high-speed modulation, frequency modulation is
carried out after the digital base band signals (rectangular
wave) are passed through a band limiting filter. For 9600bps
GMSK for example, compared to 4800Hz signals (nearly sine
wave signals passed through a filter), these signals have a
hissing sound like digital modulation when listened to by ear.
Different types of modulation, such as GMSK is distin-
guished by the type of band limiting filter.
Pin Pin Specification
No. Name
1PKD bps switching 1200bps 9600bps
Modulation input 400mVp-p 4Vp-p
Frequency shift 3±0.5kHz 2.2±0.5kHz
4PR9 Output level 500mVp-p/10kΩ
Always output during reception
5PR1 Output level 500mVp-p/10kΩ
Not output when squelch off
Table 4 Data terminal input/output level
AR-440
7
■Transmission Signals
Transmission modulation signals enter from PKD of the
data terminal (CN2). The path to the modulation depends on
whether communications are 1200bps or 9600bps mode.
For 1200bps mode, the transmission modulation signals
from single analog switch (IC204) pass through MIC amplifier
(IC201,202) and summing amplifier (IC203), and go to VCO
(X401) through D/A converter (IC161).
For 9600bps mode, the transmission modulation signals
from single analog switch (IC205) pass through summing
amplifier (IC303), go to TCXO (X401) and VCO through D/A
converter (IC161). (See Fig. 17.)
■Reception Signals
PR9 is the 9600bps data communications reception out-
put. It outputs the FM detection circuit output through an AF
filter (IC251). These signals are always output whether the
squelch is open or closed.
PR1 is the 1200bps data communications reception out-
put. It outputs the FM detection circuit output through an AF
filter (IC251). Output is controlled with the mute switch
(Q252) according to whether squelch is open or closed. (See
Fig. 17.)
■Squelch Signal Output Circuit
The squelch circuits is input to the TNC to prevents con-
flicts from occurring between simultaneous receive mode
and transmit mode traffic during packet communications
(only during 1200bps). The signal is output from pin 29 of
IC101 to the data terminal. The logic is as shown in the table
below.
SQC terminal output L : SQ CLOSE
CN2 H : SQ BUSY
IC204
Analog
switch
IC201,202
MIC amp
IC203
Sum amp
IC205
Analog
switch
IC251
AF filter
76
75
IC101
CPU
1200bps
9600bps VCO, TCXO,
D/A converter
D/A converter
Q252
Mute SW
D6
D5
PKS (CPU) pin 30
SQC (CPU) pin 29
PKD
PR9
PR1
PKS
SQC
CN2
Fog. 17 Data terminal and peripheral circuits
CIRCUIT DESCRIPTION
AR-440
8
SEMICONDUCTOR DATA
■Terminal Function
Pin No. Name I/O Function
1TONE O CTCSS/DCS/Clone output
2DTMF O DTMF/BEEP/1750Hz output
3PLLE O PLL IC chip select
4,5 NC I
6GND - GND
7CNVSS -
8EVLLD O
9BSHIFT O Beat shift
10 RESET - Reset
11 XOUT - X’tal (8MHz)
12 VSS - GND
13 XIN - X’tal (8MHz)
14 VCC - +5V
15 NMI - (Input only)
16 NC I
17 POWER I Power key input
18 INT I µcom stop
19 NC I
20 TX/RX O TX/RX
21 UL I PLL unlock detect
22,23 NC I
24 EEPSDT I/O EEPROM data
25 EEPCK O EEPROM clock
26 EEPWP O EEPROM write protect
27,28 NC I (Nch open drain)
29 SQC O Squelch signal output for TNC
(TxD for flash)
30 PKS I PTT input for TNC (RxD for flash)
31 CLKFLS I (GND)
32 BSYFLS O (Vcc)
33 TXD O To PC
34 RXD I From PC
35 PTT I PTT input
36~38 NC I
39 EMPFLS I/O (GND)
40~43 NC I
44 CEFLS I/O (Vcc)
45~49 NC I
50 AFM O AF mute
51 SPM O Speaker mute
52 AMPSW O AF AMP switch
Pin No. Name I/O Function
53 DT O Common data
54 CK O Common clock
55 NC I
56 DST1 I Destination 1
57~59 DST2~DST4 I Destination 2~4
60 VCC - +5V
61 NC I
62 VSS - GND
63 ADJ I For adjustment mode
64 NARROW O Wide/Narrow 2
65 WIDE O Wide/Narow
66,67 NC I
68 LCDCL O Clock for LCD
69 LCDCE O Chip enable for LCD
70 LCDDO O Output data to LCD
71 LCDDI I Input data from LCD
72 NC I
73 ENCB I Encoder input B
74 ENCA I Encoder input A
75 TNC9600 O TNC speed H : 9600, L : 1200
76 TNC1200 O TNC speed L : 9600, H : 1200
77 MICMT O MIC mute
78 NC I NC
79 8RC O 8R control
80 8TC O 8T control
81 NC I
82 SBC O Battery switch
83~85 NC I
86 CM I/O MIC key check
87 I For AMR DTMF keypad MIC
88 I For AMR DTMF keypad MIC
89 VOL I Volume encoder
90 TEMP2 I Temperature 2
91 TEMP1 I Temperature 1
92 RSSI I RSSI input
93 SQIN I Squelch input
94 AVSS - GND
95 DTMF IN I CTCSS/DCS/Clone/1050Hz input
96 VREF - +5V
97 AVCC - +5V
98~100
NC I
Microprocessor : 30622MAA-B85GP (TX-RX Unit IC101)
AR-440
9
Display Unit (X54-3450-10)
Ref. No. Parts name Description
IC3 IC LCD controller
Q6 Transistor DC switch
Q9 Transistor LCD backlit switch
Q10 Transistor Key backlit switch
Q12 Transistor Brightness function switch
D2~4 LED Key backlit
D19~30 LED LCD backlit
D31 Diode Reverse connection protection
TX-RX Unit (X57-6863-XX)
Ref. No. Parts name Description
IC31 IC Voltage regulator (8C)
IC32 IC Voltage regulator (5C)
IC33 IC Voltage regulator (5M)
IC34 IC Voltage detector (reset)
IC35 IC Voltage detector (int)
IC66 IC EEPROM
IC101 IC CPU
IC161 IC Digital potentiometer
IC201 IC MIC amplifier / IDC
IC202 IC MIC amplifier / Splatter filter
IC203 IC Buffer amplifier / SUM amplifier /
DC amplifier / 1/2 Vcc
IC204,205
IC Single analog switch
IC251 IC Audio filter
IC252 IC Audio amplifier
IC301 IC FM demodulation
IC401 IC PLL synthesizer
IC501 IC APC controller
Q31,32 Transistor
DC switch (SB) / Active when power is on
Q33,34 Transistor DC switch (8R) / Active while RX
Q35,36 Transistor DC switch (8T) / Active while TX
Q61 Transistor Over voltage detection / Active when
PS voltage is more than18V
Q86,87 Transistor Beat shift / Active while beat shift is on
Q201 Transistor AGC / MIC mute
Q251 Transistor Buffer amplifier / RX audio
Q252,253
FET AF mute / Active while AFM is H
Q254
Digital transistor
AF mute / Active while SPM is H
Q255 Transistor AF mute / Active while AMPSW is H
Q301 Transistor SQL amplifier / Noise amplifier
Q302 Transistor Buffer amplifier / 16.8MHz 3rd over tone
Ref. No. Parts name Description
Q351 Transistor IF amplifier
Q352 FET Mixer
Q353 FET RF amplifier / LNA
Q354 FET PC/TV switch
Q402,403
Transistor Charge pump
Q404 Transistor RF amplifier / PLL F in
Q405 FET RX VCO
Q406 FET TX VCO
Q407 FET T/R SW
Q408 Transistor T/R SW
Q410 Transistor Buffer amplifier / Output of VCO
Q411 Transistor RF amplifier / Output of VCO
Q440 Transistor Lipple filter
Q500 Transistor RF switch (TX/RX)
Q501 Transistor RF amplifier / Predrive amplifier
Q502 Transistor RF amplifier / Drive amplifier 1
Q503 FET RF amplifier / Drive amplifier 2
Q504 FET RF amplifier / Final amplifier
D1 Diode Surge absorption / CM
D2 Diode Surge absorption / MIC key
D3 Diode Surge absorption / RXD
D4 Diode Surge absorption / PTT
D5 Diode Surge absorption / SQC
D6 Diode Surge absorption / PKS
D31 Diode Reverse connection protection
D32 Poly switch Current protection
D61,62 Diode Over voltage detection
D201 Diode OR gate / MIC mute, AGC
D202 Diode AGC
D251 Diode Limiter
D301 Diode Detection
D302,303
Diode IF switch (Wide/Narrow)
D351~355
Varicap RF BPF tuning
D401 Diode Ripple filter
D402 Diode Voltage dropped
D403,404
Varicap RX VCO
D405,406
Varicap TX VCO
D407 Varicap Modulation
D408 Diode Lipple filter
D409 Diode RF switch (TX/RX)
D502 Diode Temperature compensation
D503 Diode Voltage protectionV
D601~605
Diode ANT switch
D606,607
Diode APC voltage detectV
D608 Diode Temperature compensation
COMPONENTS DESCRIPTION
AR-440
10
PARTS LIST
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K:USA P:Canada
Y: PX (Far East, Hawaii) T:England E:Europe
Y:AAFES (Europe) X:Australia M:Other Areas
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
AR-440, DISPLAY UNIT (X54-3450-10)
TX-RX UNIT (X57-686X-XX)
11B✽A01-2193-01 CABINET
23BA10-4048-21 CHASSIS
33A✽A62-1102-03 PANEL ASSY
51D✽B62-1745-10 INSTRUCTION MANUAL
63B✽B72-2176-04 MODEL NAME PLATE C
63B✽B72-2177-04 MODEL NAME PLATE C2
83BE04-0167-05 RF COAXIAL PECEPTACLE (M)
10 3C E30-2111-15 DC CORD ACCESSORY
13 3B ✽E30-7512-05 DC CORD (RADIO)
14 3A E37-1082-05 SPEAKER WIRE
15 2A ✽E37-1097-05 FLAT CABLE
18 2B F10-2449-01 SHIELDING COVER
19 2B,3C F51-0017-05 FUSE (6✽30) (15A)
23 2B G02-0894-04 EARTH SPRING (FINAL FET)
24 2A ✽G10-1324-04 FIBROUS SHEET (DISPLAY UNIT)
25 3B G11-4127-14 RUBBER SHEET (CHASSIS)
26 2B G11-4240-04 RUBBER SHEET (DRIVE FET)
27 3B G13-1468-04 CUSHION (CHASSIS)
28 3A G53-1525-03 PACKING (PANEL)
29 2B G53-1542-03 PACKING (PHONE JACK)
30 1B G53-1544-01 PACKING (SHIELDING COVER)
31 1A G53-1548-02 GASKET
33 2C,1D H12-3112-05 PACKING FIXTURE
34 3D H13-1190-02 CARTON BOARD
36 1D H25-2341-04 PROTECTION BAG
37 2D ✽H52-2030-02 ITEM CARTON CASE
39 3C J19-1584-05 MIC HOLDER ACCESSORY
40 3D J29-0662-03 BRACKET ACCESSORY
42 3A ✽K29-9291-01 KEY TOP
43 3A ✽K29-9292-03 KNOB (VOLUME)
44 3A ✽K29-9293-03 KNOB (CNCODER)
A2BN67-2608-46 PAN HEAD SEMS SCREW W
B2AN80-2010-45 PAN HEAD TAPTITE SCREW
C2B,3B N87-2606-46 BRAZIER HEAD TAPTITE SCREW
D1B,2B N87-2614-46 BRAZIER HEAD TAPTITE SCREW
46 3D N99-0395-05 SCREW SET ACCESSORY
48 3A T07-0739-05 SPEAKER
50 2C ✽T91-0641-05 MICROPHONE ACCESSORY
101 2A ✽B11-1809-03 ILLUMINATION GUIDE (LCD)
102 2A ✽B38-0885-05 LCD
D2-4 B30-2205-05 LED (YG)
D19-30 B30-2205-05 LED (YG)
C4 CC73GCH1H101J CHIP C 100PF J
C15,16 CC73GCH1H101J CHIP C 100PF J
C19 CK73GB1H681K CHIP C 680PF K
C22 CK73GB1H102K CHIP C 1000PF K
C24 CK73GB1C104K CHIP C 0.10UF K
C25 CK73GB1H102K CHIP C 1000PF K
C27 CK73GB1H102K CHIP C 1000PF K
C30 CK73GB1C104K CHIP C 0.10UF K
C31-33 CK73GB1H102K CHIP C 1000PF K
C34,35 CK73GB1H472K CHIP C 4700PF K
C36 CK73GB0J105K CHIP C 1.0UF K
C38 CK73GB1H471K CHIP C 470PF K
C39,40 CK73GB1C104K CHIP C 0.10UF K
103 2A ✽E29-1201-04 INTER CONNECTOR (LCD)
CN1 E40-6005-05 FLAT CABLE CONNECTOR
J1 E08-0877-05 MODULAR JACK
104 2A ✽J21-8463-03 HARDWARE FIXTURE (LCD)
L1 L92-0138-05 FERRITE CHIP
CP1 R90-0724-05 MULTI-COMP 1K X4
R8 RK73GB1J102J CHIP R 1.0K J 1/16W
R10 RK73GB1J122J CHIP R 1.2K J 1/16W
R21-23 RK73GB1J103J CHIP R 10K J 1/16W
R25 RK73GB1J563J CHIP R 56K J 1/16W
R26 RK73GB1J392J CHIP R 3.9K J 1/16W
R41 RK73FB2A560J CHIP R 56 J 1/10W
R42 RK73GB1J272J CHIP R 2.7K J 1/16W
R43 RK73GB1J821J CHIP R 820 J 1/16W
R44 RK73GB1J183J CHIP R 18K J 1/16W
R45 RK73GB1J333J CHIP R 33K J 1/16W
R46 RK73GB1J101J CHIP R 100 J 1/16W
R47,48 RK73GB1J473J CHIP R 47K J 1/16W
R49,50 RK73FB2A560J CHIP R 56 J 1/10W
R51-53 R92-1252-05 CHIP R 0 OHM J 1/16W
R55 R92-1252-05 CHIP R 0 OHM J 1/16W
R54 RK73FB2A560J CHIP R 56 J 1/10W
VR1 ✽R31-0646-05 VARIABLE RESISTOR
D31 1SS355 DIODE
IC3 ✽LC75854W MOS IC
IC3 ✽PT6554LQ MOS IC
Q6 KRC102S DIGITAL TRANSISTOR
Q9 2SB1132(Q,R) TRANSISTOR
Q10 KRA225S DIGITAL TRANSISTOR
Q12 UMG3N TRANSISTOR
S1 ✽W02-3665-05 ENCODER
C10 CK73GB1H102K CHIP C 1000PF K
C13-20 CK73GB1H471K CHIP C 470PF K
C28 CK73GB1H221K CHIP C 220PF K
C29 CK73GB1H471K CHIP C 470PF K
C30 CK73GB1H102K CHIP C 1000PF K
C32 CK73GB1H102K CHIP C 1000PF K
C33 CK73GB1H471K CHIP C 470PF K
C34 ✽CE04EQ1E331M ELECTRO 330UF 25WV
C35-38 CK73GB1H471K CHIP C 470PF K
C39,40 CK73GB1C104K CHIP C 0.10UF K
AR-440
DISPLAY UNIT (X54-3450-10) TX-RX UNIT (X57-686X-XX) 3-00 : C 3-01 : C2
AR-440
11
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
C41 C92-0795-05 CHIP-TAN 22UF 10WV
C42 CK73GB1H103K CHIP C 0.010UF K
C43-45 C92-0795-05 CHIP-TAN 22UF 10WV
C48-50 CK73GB1H103K CHIP C 0.010UF K
C51 C92-0589-05 CHIP-TAN 47UF 6.3WV
C52,53 CK73GB1H471K CHIP C 470PF K
C54,55 CK73GB1C104K CHIP C 0.10UF K
C56 CK73GB1H471K CHIP C 470PF K
C61 CK73GB1H471K CHIP C 470PF K
C66 CK73GB1H471K CHIP C 470PF K
C82 CK73GB1H471K CHIP C 470PF K
C83 CK73GB1C104K CHIP C 0.10UF K
C87 CC73GCH1H030C CHIP C 3.0PF C
C88,89 CC73GCH1H040C CHIP C 4.0PF C
C90 CC73GCH1H030C CHIP C 3.0PF C
C97,98 CK73GB1H471K CHIP C 470PF K
C101 CK73GB1H471K CHIP C 470PF K
C102 CK73GB1C104K CHIP C 0.10UF K
C104 CK73GB1C104K CHIP C 0.10UF K
C128 CK73GB1H102K CHIP C 1000PF K
C151 CK73GB1H182K CHIP C 1800PF K
C152 CK73GB1H392K CHIP C 3900PF K
C161 CK73GB1H102K CHIP C 1000PF K
C162 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C163 CK73GB1H471K CHIP C 470PF K
C164 C92-0560-05 CHIP-TAN 10UF 6.3WV
C165 CK73GB1A105K CHIP C 1.0UF K
C201 CK73GB1C104K CHIP C 0.10UF K
C202 CK73GB1H471K CHIP C 470PF K
C203 CK73GB1C273K CHIP C 0.027UF K
C204 C92-0514-05 CHIP-TAN 2.2UF 10WV
C205 CK73GB1C104K CHIP C 0.10UF K
C206 CK73GB1H102K CHIP C 1000PF K
C207 CK73GB1C223K CHIP C 0.022UF K
C208 CK73GB1H103K CHIP C 0.010UF K
C209 CC73GCH1H680J CHIP C 68PF J
C210 CK73GB1C104K CHIP C 0.10UF K
C211 CK73GB1H821K CHIP C 820PF K
C212 CK73GB1H122K CHIP C 1200PF K
C213 CK73GB1H332K CHIP C 3300PF K
C214 CC73GCH1H151J CHIP C 150PF J
C215 CK73GB1C104K CHIP C 0.10UF K
C216 CC73GCH1H390J CHIP C 39PF J
C217,218 C92-0560-05 CHIP-TAN 10UF 6.3WV
C220 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C222 CK73GB1C104K CHIP C 0.10UF K
C225 C92-0004-05 CHIP-TAN 1.0UF 16WV
C226 CK73GB1H472K CHIP C 4700PF K
C227 CK73GB1E103K CHIP C 0.010UF K
C228 C92-0560-05 CHIP-TAN 10UF 6.3WV
C230 CK73GB1C104K CHIP C 0.10UF K
C231,232 CK73GB1H471K CHIP C 470PF K
C233 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C235 CK73GB1A105K CHIP C 1.0UF K
C249 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C250 CK73GB1C104K CHIP C 0.10UF K
C251 C92-0714-05 CHIP-TAN 4.7UF 6.3WV
C252 CC73GCH1H390J CHIP C 39PF J
C253,254 CK73GB1A224K CHIP C 0.22UF K
C255 CK73GB1H822K CHIP C 8200PF K
C256 CK73GB1E183K CHIP C 0.018UF K
C257 CK73GB1C393K CHIP C 0.039UF K
C258-261 CK73GB1H103J CHIP C 0.010UF J
C262 CK73GB1H471K CHIP C 470PF K
C263,264 CK73GB1C333K CHIP C 0.033UF K
C265 CK73GB1C104K CHIP C 0.10UF K
C266 CK73GB1A105K CHIP C 1.0UF K
C267 CK73GB1A474K CHIP C 0.47UF K
C268 CK73GB1A105K CHIP C 1.0UF K
C270 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C271 CK73GB1H122K CHIP C 1200PF K
C272 CK73GB1H102K CHIP C 1000PF K
C273 CK73GB1A105K CHIP C 1.0UF K
C274 CK73FB1C224K CHIP C 0.22UF K
C275 CK73GB1A105K CHIP C 1.0UF K
C276,277 CK73GB1H471K CHIP C 470PF K
C278 CK73GB1C104K CHIP C 0.10UF K
C279 C92-0516-05 CHIP-TAN 4.7UF 16WV
C280 C92-0040-05 CHIP-ELE 47UF 16WV
C281 CK73GB1H471K CHIP C 470PF K
C282 ✽CE04EQ1E331M ELECTRO 330UF 25WV
C283 CK73GB1H102K CHIP C 1000PF K
C301 C92-0507-05 CHIP-TAN 4.7UF 6.3WV
C302 CK73GB1H102K CHIP C 1000PF K
C303 CK73GB1H472K CHIP C 4700PF K
C304,305 CC73GCH1H221J CHIP C 220PF J
C306 CK73GB1H102K CHIP C 1000PF K
C307 CK73GB1E223K CHIP C 0.022UF K
C308 CK73GB1H102K CHIP C 1000PF K
C309 CK73GB1E223K CHIP C 0.022UF K
C310 CK73FB1C334K CHIP C 0.33UF K
C311,312 CK73GB1C104K CHIP C 0.10UF K
C313 C92-0662-05 CHIP-TAN 15UF 6.3WV
C314 CK73GB1H103K CHIP C 0.010UF K
C315-318 CK73GB1C104K CHIP C 0.10UF K
C319 CK73GB1H102K CHIP C 1000PF K
C321 CC73GCH1H680J CHIP C 68PF J
C322 CC73GCH1H560J CHIP C 56PF J
C323 CC73GCH1H271J CHIP C 270PF J
C324 CK73GB1H103K CHIP C 0.010UF K
C326 CK73GB1H103K CHIP C 0.010UF K
C350 CK73GB1H471K CHIP C 470PF K C2
C351 CC73GCH1H330J CHIP C 33PF J
C353 CK73GB1H103K CHIP C 0.010UF K
C354 CC73GCH1H060B CHIP C 6.0PF B
C355 CC73GCH1H180J CHIP C 18PF J
C356 CC73GCH1H020B CHIP C 2.0PF B
C357 CK73GB1H103K CHIP C 0.010UF K
C358 CK73GB1H471K CHIP C 470PF K
C359 CC73GCH1H120J CHIP C 12PF J
C360 CC73GCH1H080B CHIP C 8.0PF B
C361,362 CK73GB1H471K CHIP C 470PF K
C363 CK73GB1H103K CHIP C 0.010UF K
C364 CK73GB1H471K CHIP C 470PF K
C366 CK73GB1C104K CHIP C 0.10UF K
C367 CK73GB1H471K CHIP C 470PF K
C368 CC73GCH1H070B CHIP C 7.0PF B C
C368 CC73GCH1H100C CHIP C 10PF C C2
C369 CC73GCH1HR75B CHIP C 0.75PF B C2
C370 CK73GB1H471K CHIP C 470PF K
AR-440
12
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
C371 CC73GCH1HR75B CHIP C 0.75PF B C2
C371 CC73GCH1H0R5B CHIP C 0.5PF B C
C372 CC73GCH1H150J CHIP C 15PF J C
C372 CC73GCH1H200J CHIP C 20PF J C2
C373 CC73GCH1H080B CHIP C 8.0PF B C
C373 CC73GCH1H100C CHIP C 10PF C C2
C374 CC73GCH1H070B CHIP C 7.0PF B
C375-380 CK73GB1H471K CHIP C 470PF K
C381 CC73GCH1H050B CHIP C 5.0PF B C2
C381 CC73GCH1H070B CHIP C 7.0PF B C
C382 CK73GB1H471K CHIP C 470PF K
C383 CC73GCH1H0R5B CHIP C 0.5PF B
C384 CC73GCH1H070B CHIP C 7.0PF B C
C384 CC73GCH1H080B CHIP C 8.0PF B C2
C385 CK73GB1H471K CHIP C 470PF K
C386 CC73GCH1HR75B CHIP C 0.75PF B
C387 CC73GCH1H010B CHIP C 1.0PF B C2
C388 CC73GCH1H060B CHIP C 6.0PF B
C389 CK73GB1H103K CHIP C 0.010UF K
C390 CC73GCH1H080B CHIP C 8.0PF B C
C390 CC73GCH1H100C CHIP C 10PF C C2
C391 CK73GB1H471K CHIP C 470PF K
C392 CC73GCH1H030B CHIP C 3.0PF B C
C392 CC73GCH1H060B CHIP C 6.0PF B C2
C393 CC73GCH1HR75B CHIP C 0.75PF B C2
C393 CC73GCH1H2R5B CHIP C 2.5PF B C
C400 CK73GB1C104K CHIP C 0.10UF K
C401-403 CC73GCH1H101J CHIP C 100PF J
C404 C92-0662-05 CHIP-TAN 15UF 6.3WV
C406 CK73GB1H102K CHIP C 1000PF K
C408 CC73GCH1H220J CHIP C 22PF J
C409 CK73GB1C104K CHIP C 0.10UF K
C410 C92-0560-05 CHIP-TAN 10UF 6.3WV
C411 CK73GB1C104K CHIP C 0.10UF K
C412 C92-0560-05 CHIP-TAN 10UF 6.3WV
C413 CK73GB1H103K CHIP C 0.010UF K
C414 CK73GB1C104K CHIP C 0.10UF K
C416,417 CK73GB1H471K CHIP C 470PF K
C418 CK73GB1H102K CHIP C 1000PF K
C421,422 CK73GB1H471K CHIP C 470PF K
C423 C92-0555-05 CHIP-TAN 0.047UF 35WV
C424 C92-0543-05 CHIP-TAN 3.3UF 10WV
C425 C92-0001-05 CHIP C 0.1UF 35WV
C426 CC73GCH1H080B CHIP C 8.0PF B C
C426 CC73GCH1H180J CHIP C 18PF J C2
C427 CC73GCH1H070B CHIP C 7.0PF B C
C427 CC73GCH1H120G CHIP C 12PF G C2
C428 CK73GB1H471K CHIP C 470PF K
C429 CC73GCH1H1R5B CHIP C 1.5PF B C2
C429,430 CC73GCH1H020B CHIP C 2.0PF B C
C430 CC73GCH1H060B CHIP C 6.0PF B C2
C431 CC73GCH1H030B CHIP C 3.0PF B C
C431 CC73GCH1H050B CHIP C 5.0PF B C2
C432 CC73GCH1H0R5B CHIP C 0.5PF B
C433 CK73GB1H471K CHIP C 470PF K
C434 CC73GCH1H050B CHIP C 5.0PF B C
C434 CC73GCH1H090B CHIP C 9.0PF B C2
C435 CC73GCH1H060B CHIP C 6.0PF B
C436 CC73GCH1H0R5B CHIP C 0.5PF B
C437 CK73GB1H471K CHIP C 470PF K
C438 CC73GCH1H010B CHIP C 1.0PF B C2
C438,439 CC73GCH1H020B CHIP C 2.0PF B C
C439 CC73GCH1H030B CHIP C 3.0PF B C2
C440 CC73GCH1H030B CHIP C 3.0PF B C
C440 CC73GCH1H040B CHIP C 4.0PF B C2
C441 CC73GCH1H0R3B CHIP C 0.3PF B
C442 C92-0560-05 CHIP-TAN 10UF 6.3WV
C444 CK73GB1H471K CHIP C 470PF K
C448,449 CK73GB1H471K CHIP C 470PF K
C450 C92-0795-05 CHIP-TAN 22UF 10WV
C451,452 CK73GB1H471K CHIP C 470PF K
C454 CC73GCH1H040B CHIP C 4.0PF B C
C454 CC73GCH1H060B CHIP C 6.0PF B C2
C455 CC73GCH1H020B CHIP C 2.0PF B
C456 CC73GCH1H030B CHIP C 3.0PF B C2
C456 CC73GCH1H040B CHIP C 4.0PF B C
C461 CK73GB1H471K CHIP C 470PF K
C463,464 CK73GB1H471K CHIP C 470PF K
C466 CC73GCH1H050B CHIP C 5.0PF B
C467 CK73GB1H471K CHIP C 470PF K
C472 CC73GCH1H030B CHIP C 3.0PF B C
C472 CC73GCH1H2R5B CHIP C 2.5PF B C2
C473 CK73GB1H102K CHIP C 1000PF K
C475,476 CK73GB1H102K CHIP C 1000PF K
C501 CK73GB1H471K CHIP C 470PF K
C502 CC73GCH1H030B CHIP C 3.0PF B C2
C502 CC73GCH1H050B CHIP C 5.0PF B C
C504,505 CK73GB1H471K CHIP C 470PF K
C507 CK73GB1H471K CHIP C 470PF K
C509 CC73GCH1H040B CHIP C 4.0PF B
C510-515 CK73GB1H471K CHIP C 470PF K
C516 CC73GCH1H030B CHIP C 3.0PF B
C517 CK73GB1H471K CHIP C 470PF K
C518 C92-0040-05 CHIP-ELE 47UF 16WV
C520,521 CK73GB1H471K CHIP C 470PF K
C522 CK73GB1C104K CHIP C 0.10UF K
C523 CC73FCH1H270J CHIP C 27PF J C
C523 CC73FCH1H470J CHIP C 47PF J C2
C524 CC73FCH1H080D CHIP C 8.0PF D C2
C524 CC73FCH1H100D CHIP C 10PF D C
C526 CC73FCH1H090D CHIP C 9.0PF D
C527 CC73FCH1H120J CHIP C 12PF J C2
C527 CC73FCH1H150J CHIP C 15PF J C
C528 CC73FCH1H470J CHIP C 47PF J
C532 CK73GB1H471K CHIP C 470PF K
C534 CK73FB1H471K CHIP C 470PF K
C535 CK73GB1H221K CHIP C 220PF K
C536 CK73GB1H471K CHIP C 470PF K
C537 C92-0719-05 CHIP-TAN 47UF 25WV
C538 CK73FB1C474K CHIP C 0.47UF K
C539 CK73FB1H471K CHIP C 470PF K
C540 C93-0558-05 CHIP C 8.0PF D C
C540 C93-0568-05 CHIP C 47PF J C2
C541 C93-0563-05 CHIP C 18PF J C
C541 C93-0566-05 CHIP C 33PF J C2
C543 C93-0599-05 CHIP C 470PF K
C545 C93-0560-05 CHIP C 10PF D C2
C548,549 C93-0566-05 CHIP C 33PF J C2
C548,549 C93-0567-05 CHIP C 39PF J C
C550,551 CM73F2H300J CHIP C 30PF J
AR-440
13
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
C555 CK73FB1C474K CHIP C 0.47UF K
C556 C93-0599-05 CHIP C 470PF K
C559 CK73GB1H103K CHIP C 0.010UF K
C560 CK73GB1H471K CHIP C 470PF K
C564 CM73F2H150J CHIP C 15PF J C2
C564 CM73F2H200J CHIP C 20PF J C
C567 CM73F2H100D CHIP C 10PF D C
C570 C93-0599-05 CHIP C 470PF K
C571 CK73GB1H471K CHIP C 470PF K
C572,573 CK73GB1H103K CHIP C 0.010UF K
C574 CK73GB1H102K CHIP C 1000PF K
C575 CK73GB1H471K CHIP C 470PF K
C576 CK73GB1H221K CHIP C 220PF K
C579 CM73F2H090D CHIP C 9.0PF D C2
C580 C93-0554-05 CHIP C 4.0PF C C2
C601 CC73GCH1H050B CHIP C 5.0PF B C
C602 C93-0560-05 CHIP C 10PF D C
C602 C93-0599-05 CHIP C 470PF K C2
C603 CC73GCH1H0R5B CHIP C 0.5PF B
C604 CC73GCH1H010B CHIP C 1.0PF B C2
C604 CC73GCH1H020B CHIP C 2.0PF B C
C605 C93-0554-05 CHIP C 4.0PF C C2
C605 C93-0556-05 CHIP C 6.0PF D C
C607 CC73GCH1H0R5B CHIP C 0.5PF B
C608 CC73GCH1H020B CHIP C 2.0PF B C
C608 CC73GCH1H030B CHIP C 3.0PF B C2
C610 C93-0556-05 CHIP C 6.0PF D C2
C610 C93-0560-05 CHIP C 10PF D C
C611 C93-0553-05 CHIP C 3.0PF C C
C611 C93-0554-05 CHIP C 4.0PF C C2
C613,614 CK73GB1H471K CHIP C 470PF K
C620 C93-0550-05 CHIP C 1.0PF C C2
TC401 C05-0245-05 CERAMIC TRIMMER CAP (10PF) C
TC401,402 C05-0245-05 CERAMIC TRIMMER CAP (10PF) C2
TC402 C05-0399-05 CERAMIC TRIMMER CAP (6PF) C
-E11-0425-05 3.5D PHONE JACK (3P)
-E37-1127-05 PROCESSED LEAD WIRE
CN1 E40-6268-05 FLAT CABLE CONNECTOR
CN2 E40-5705-05 PIN ASSY
CN5 E40-3246-05 PIN ASSY
F1 F53-0246-05 FUSE(4.0A/32V)
F501 F53-0108-05 FUSE(1.8A/50V)
CF301 L72-0993-05 CERAMIC FILTER
CF302 L72-0999-05 CERAMIC FILTER
L101 L92-0443-05 FERRITE CHIP
L201 L92-0443-05 FERRITE CHIP
L301 L34-4554-05 COIL
L302 L41-3385-08 SMALL FIXED INDUCTOR
L303,304 L40-3381-86 SMALL FIXED INDUCTOR (0.33UH)
L351,352 L40-4785-85 SMALL FIXED INDUCTOR (0.47UH)
L354,355 L34-4604-05 AIR-CORE COIL C2
L354,355 L34-4605-05 AIR-CORE COIL C
L356 L40-1875-92 SMALL FIXED INDUCTOR (18NH) C2
L356 L40-2275-92 SMALL FIXED INDUCTOR (22NH) C
L357 L40-3375-92 SMALL FIXED INDUCTOR (33NH) C2
L357 L40-3975-92 SMALL FIXED INDUCTOR (39NH) C
L358 L34-4605-05 AIR-CORE COIL C2
L358,359 L34-4605-05 AIR-CORE COIL C
L359 L34-4604-05 AIR-CORE COIL C2
L360 L34-4603-05 AIR-CORE COIL C2
L360,361 L34-4604-05 AIR-CORE COIL C
L361 L34-4604-05 AIR-CORE COIL C2
L401 L92-0443-05 FERRITE CHIP
L403 L41-1005-08 SMALL FIXED INDUCTOR
L404 L92-0442-05 FERRITE CHIP
L405 L92-0443-05 FERRITE CHIP
L406,407 L40-2785-92 SMALL FIXED INDUCTOR (270NH) C
L406,407 L40-4791-86 SMALL FIXED INDUCTOR (4.7UH) C2
L408 L40-2778-67 SMALL FIXED INDUCTOR (27NH) C2
L408 L40-5678-67 SMALL FIXED INDUCTOR (56NH) C
L409-412 L40-2785-92 SMALL FIXED INDUCTOR (270NH) C
L409,410 L40-4791-86 SMALL FIXED INDUCTOR (4.7UH) C2
L411,412 L40-2702-86 SMALL FIXED INDUCTOR (27UH) C2
L413 L40-2778-67 SMALL FIXED INDUCTOR (27NH) C2
L413 L40-4778-67 SMALL FIXED INDUCTOR (47NH/8) C
L414 L40-1885-92 SMALL FIXED INDUCTOR (180NH) C
L414,415 L40-2702-86 SMALL FIXED INDUCTOR (27UH) C2
L415 L40-2785-92 SMALL FIXED INDUCTOR (270NH) C
L416,417 L92-0443-05 FERRITE CHIP
L418 L41-2775-06 SMALL FIXED INDUCTOR
L420 L41-2775-06 SMALL FIXED INDUCTOR
L470 L40-2275-92 SMALL FIXED INDUCTOR (22NH) C2
L470 L40-2775-92 SMALL FIXED INDUCTOR (27NH) C
L501 L41-1575-06 SMALL FIXED INDUCTOR
L502 L41-2275-08 SMALL FIXED INDUCTOR
L503 L41-3363-08 SMALL FIXED INDUCTOR
L504 L41-1075-08 SMALL FIXED INDUCTOR
L505 L34-4603-05 AIR-CORE COIL
L506 L34-4607-05 AIR-CORE COIL
L507 L34-4602-05 AIR-CORE COIL C2
L507 L34-4603-05 AIR-CORE COIL C
L508 L34-4694-05 AIR-CORE COIL
L509 L34-4667-05 AIR-CORE COIL
L601 L34-4669-05 AIR-CORE COIL
L602,603 L34-4694-05 AIR-CORE COIL
L604 L34-4667-05 AIR-CORE COIL
X86 ✽L78-1409-05 RESONATOR (8.00MHZ)
X401 ✽L77-1944-05 TCXO (16.8MHZ)
XF351 ✽L71-0620-05 MCF (49.95MHZ)
R1 R92-1252-05 CHIP R 0 OHM J 1/16W
R2,3 RK73GB1J101J CHIP R 100 J 1/16W
R4-8 RK73GB1J102J CHIP R 1.0K J 1/16W
R31 RK73GB1J472J CHIP R 4.7K J 1/16W
R32 R92-1215-05 CHIP R 470 J 1/2W
R33 RK73GB1J473J CHIP R 47K J 1/16W
R34 RK73GB1J472J CHIP R 4.7K J 1/16W
R35 RK73GB1J473J CHIP R 47K J 1/16W
R36 RK73GB1J152J CHIP R 1.5K J 1/16W
R37 RK73GB1J103J CHIP R 10K J 1/16W
R38 RK73GB1J334J CHIP R 330K J 1/16W
R39 RK73GB1J474J CHIP R 470K J 1/16W
R40 RK73GB1J394J CHIP R 390K J 1/16W
R41 RK73GB1J334J CHIP R 330K J 1/16W
R61 RK73GB1J471J CHIP R 470 J 1/16W
R62,63 R92-1252-05 CHIP R 0 OHM J 1/16W
R70 RK73GB1J473J CHIP R 47K J 1/16W
R81 RK73GB1J473J CHIP R 47K J 1/16W
R82 R92-1252-05 CHIP R 0 OHM J 1/16W
R86 R92-1252-05 CHIP R 0 OHM J 1/16W
AR-440
14
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
R87 RK73GB1J102J CHIP R 1.0K J 1/16W
R91,92 RK73GB1J102J CHIP R 1.0K J 1/16W
R93 RK73GB1J682J CHIP R 6.8K J 1/16W C
R93,94 RK73GB1J822J CHIP R 8.2K J 1/16W C2
R94 RK73GB1J822J CHIP R 8.2K J 1/16W C
R101,102 RK73GB1J473J CHIP R 47K J 1/16W
R103-106 RK73GB1J102J CHIP R 1.0K J 1/16W
R109 RK73GB1J152J CHIP R 1.5K J 1/16W
R110 RK73GB1J473J CHIP R 47K J 1/16W
R111 RK73GB1J102J CHIP R 1.0K J 1/16W
R114 RK73GB1J473J CHIP R 47K J 1/16W
R118 R92-1252-05 CHIP R 0 OHM J 1/16W
R119 R92-0670-05 CHIP R 0 OHM C
R123 R92-1252-05 CHIP R 0 OHM J 1/16W
R124-127 RK73GB1J473J CHIP R 47K J 1/16W
R151 RK73GB1J103J CHIP R 10K J 1/16W
R152 RK73GB1J472J CHIP R 4.7K J 1/16W
R161 RK73GB1J122J CHIP R 1.2K J 1/16W
R162 RK73GB1J152J CHIP R 1.5K J 1/16W
R164-166 RK73GB1J102J CHIP R 1.0K J 1/16W
R200 RK73GB1J681J CHIP R 680 J 1/16W
R203 RK73GB1J104J CHIP R 100K J 1/16W
R204 RK73GB1J183J CHIP R 18K J 1/16W
R205 RK73GB1J821J CHIP R 820 J 1/16W
R206 RK73GB1J101J CHIP R 100 J 1/16W
R207 RK73GB1J754J CHIP R 750K J 1/16W
R208 RK73GB1J152J CHIP R 1.5K J 1/16W
R209 RK73GB1J244J CHIP R 240K J 1/16W
R210 RK73GB1J183J CHIP R 18K J 1/16W
R211,212 RK73GB1J823J CHIP R 82K J 1/16W
R213 RK73GB1J334J CHIP R 330K J 1/16W
R214,215 RK73GB1J683J CHIP R 68K J 1/16W
R216 RK73GB1J274J CHIP R 270K J 1/16W
R217 RK73GB1J224J CHIP R 220K J 1/16W
R218 RK73GB1J823J CHIP R 82K J 1/16W
R219 RK73GB1J393J CHIP R 39K J 1/16W
R220,221 RK73GH1J153D CHIP R 15K D 1/16W
R222 RK73GB1J103J CHIP R 10K J 1/16W
R224 RK73GB1J561J CHIP R 560 J 1/16W
R225 RK73GB1J154J CHIP R 150K J 1/16W
R226 RK73GB1J104J CHIP R 100K J 1/16W
R227 RK73GB1J223J CHIP R 22K J 1/16W
R228 RK73GB1J103J CHIP R 10K J 1/16W
R229 RK73GB1J684J CHIP R 680K J 1/16W
R230 RK73GB1J224J CHIP R 220K J 1/16W
R231 RK73GB1J124J CHIP R 120K J 1/16W
R232 RK73GB1J912J CHIP R 9.1K J 1/16W
R233 RK73GB1J682J CHIP R 6.8K J 1/16W
R234 R92-1252-05 CHIP R 0 OHM J 1/16W
R236 RK73GB1J103J CHIP R 10K J 1/16W
R237 R92-1252-05 CHIP R 0 OHM J 1/16W
R246 RK73GB1J154J CHIP R 150K J 1/16W
R247 RK73GB1J124J CHIP R 120K J 1/16W
R248 RK73GB1J562J CHIP R 5.6K J 1/16W
R249 RK73GB1J153J CHIP R 15K J 1/16W
R250 RK73GB1J123J CHIP R 12K J 1/16W
R251 RK73GB1J473J CHIP R 47K J 1/16W
R252 RK73GB1J474J CHIP R 470K J 1/16W
R253 R92-1252-05 CHIP R 0 OHM J 1/16W
R254 RK73GB1J272J CHIP R 2.7K J 1/16W
R255,256 RK73GB1J562J CHIP R 5.6K J 1/16W
R257 RK73GB1J105J CHIP R 1.0M J 1/16W
R258 RK73GB1J272J CHIP R 2.7K J 1/16W
R259 RK73GB1J123J CHIP R 12K J 1/16W
R260 RK73GB1J224J CHIP R 220K J 1/16W
R261 RK73GB1J124J CHIP R 120K J 1/16W
R262 RK73GB1J183J CHIP R 18K J 1/16W
R263 RK73GH1J913D CHIP R 91K D 1/16W
R264 RK73GH1J124D CHIP R 120K D 1/16W
R265 RK73GH1J562D CHIP R 5.6K D 1/16W
R266 RK73GB1J562J CHIP R 5.6K J 1/16W
R268 RK73GB1J102J CHIP R 1.0K J 1/16W
R269 RK73GB1J393J CHIP R 39K J 1/16W
R271 RK73GB1J332J CHIP R 3.3K J 1/16W
R272 RK73GB1J392J CHIP R 3.9K J 1/16W
R273 RK73GB1J123J CHIP R 12K J 1/16W
R274,275 RK73GB1J153J CHIP R 15K J 1/16W
R276 RK73GB1J473J CHIP R 47K J 1/16W
R277 RK73GB1J683J CHIP R 68K J 1/16W
R278 RK73GB1J123J CHIP R 12K J 1/16W
R279 RK73GB1J472J CHIP R 4.7K J 1/16W
R280 RK73GB1J391J CHIP R 390 J 1/16W
R281 R92-0670-05 CHIP R 0 OHM
R301,302 RK73GB1J472J CHIP R 4.7K J 1/16W
R303 RK73GB1J223J CHIP R 22K J 1/16W
R304 RK73GB1J472J CHIP R 4.7K J 1/16W
R305 RK73GB1J182J CHIP R 1.8K J 1/16W
R306 RK73GB1J274J CHIP R 270K J 1/16W
R308 RK73GB1J334J CHIP R 330K J 1/16W
R309 RK73GB1J332J CHIP R 3.3K J 1/16W
R310 RK73GB1J102J CHIP R 1.0K J 1/16W
R311 RK73GB1J333J CHIP R 33K J 1/16W
R312 RK73GB1J473J CHIP R 47K J 1/16W
R313 RK73GB1J104J CHIP R 100K J 1/16W
R314 RK73GB1J222J CHIP R 2.2K J 1/16W
R315 RK73GB1J183J CHIP R 18K J 1/16W
R316 RK73GB1J223J CHIP R 22K J 1/16W
R317-320 RK73GB1J103J CHIP R 10K J 1/16W
R321 RK73GB1J223J CHIP R 22K J 1/16W
R322 RK73GB1J101J CHIP R 100 J 1/16W
R323 RK73GB1J124J CHIP R 120K J 1/16W
R324 R92-1252-05 CHIP R 0 OHM J 1/16W
R325 RK73GB1J333J CHIP R 33K J 1/16W
R349 RK73GB1J473J CHIP R 47K J 1/16W C2
R350 RK73GB1J273J CHIP R 27K J 1/16W C1
R351 RK73GB1J471J CHIP R 470 J 1/16W
R352 RK73GB1J101J CHIP R 100 J 1/16W
R353 RK73GB1J104J CHIP R 100K J 1/16W
R354 RK73GB1J561J CHIP R 560 J 1/16W
R355 RK73GB1J681J CHIP R 680 J 1/16W
R358 RK73GB1J390J CHIP R 39 J 1/16W C2
R358 RK73GB1J470J CHIP R 47 J 1/16W C
R359 RK73GB1J823J CHIP R 82K J 1/16W
R360 RK73GB1J474J CHIP R 470K J 1/16W
R361 RK73GB1J270J CHIP R 27 J 1/16W
R362 RK73GB1J474J CHIP R 470K J 1/16W
R363 RK73GB1J224J CHIP R 220K J 1/16W
R364 R92-1252-05 CHIP R 0 OHM J 1/16W
R365,366 RK73GB1J104J CHIP R 100K J 1/16W
R367 RK73GB1J101J CHIP R 100 J 1/16W
AR-440
15
PARTS LIST
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
R369 RK73GB1J151J CHIP R 150 J 1/16W
R370 RK73GB1J473J CHIP R 47K J 1/16W
R371 RK73GB1J393J CHIP R 39K J 1/16W
R372 RK73GB1J683J CHIP R 68K J 1/16W
R373 RK73GB1J153J CHIP R 15K J 1/16W C2
R373 RK73GB1J183J CHIP R 18K J 1/16W C
R374 RK73GB1J104J CHIP R 100K J 1/16W
R375 R92-1252-05 CHIP R 0 OHM J 1/16W
R376 RK73GB1J104J CHIP R 100K J 1/16W
R377 R92-1252-05 CHIP R 0 OHM J 1/16W
R378 RK73GB1J104J CHIP R 100K J 1/16W
R380 RK73GB1J104J CHIP R 100K J 1/16W
R381 R92-1252-05 CHIP R 0 OHM J 1/16W
R401-403 RK73GB1J102J CHIP R 1.0K J 1/16W
R404 RK73GB1J103J CHIP R 10K J 1/16W
R406 RK73GB1J103J CHIP R 10K J 1/16W
R407 RK73GB1J152J CHIP R 1.5K J 1/16W
R408 RK73GB1J100J CHIP R 10 J 1/16W
R409 RK73GB1J104J CHIP R 100K J 1/16W
R410,411 RK73GB1J103J CHIP R 10K J 1/16W
R412 RK73GB1J123J CHIP R 12K J 1/16W
R413 RK73GB1J103J CHIP R 10K J 1/16W
R414,415 R92-1252-05 CHIP R 0 OHM J 1/16W
R416 RK73GB1J471J CHIP R 470 J 1/16W
R417 RK73GB1J224J CHIP R 220K J 1/16W
R418,419 RK73GB1J102J CHIP R 1.0K J 1/16W
R420 RK73GB1J222J CHIP R 2.2K J 1/16W
R421 RK73GB1J152J CHIP R 1.5K J 1/16W
R422 RK73GB1J103J CHIP R 10K J 1/16W
R423 RK73GB1J221J CHIP R 220 J 1/16W C2
R423 RK73GB1J331J CHIP R 330 J 1/16W C
R424 RK73GB1J151J CHIP R 150 J 1/16W C2
R424 RK73GB1J271J CHIP R 270 J 1/16W C
R425,426 RK73GB1J473J CHIP R 47K J 1/16W
R427 RK73GB1J104J CHIP R 100K J 1/16W
R428 RK73GB1J473J CHIP R 47K J 1/16W
R429,430 RK73GB1J221J CHIP R 220 J 1/16W
R431 RK73GB1J104J CHIP R 100K J 1/16W
R432 RK73GB1J102J CHIP R 1.0K J 1/16W
R433 RK73GB1J472J CHIP R 4.7K J 1/16W
R434 R92-1252-05 CHIP R 0 OHM J 1/16W
R435 RK73GB1J101J CHIP R 100 J 1/16W
R436 RK73GB1J124J CHIP R 120K J 1/16W C
R436 RK73GB1J823J CHIP R 82K J 1/16W C2
R439 RK73GB1J124J CHIP R 120K J 1/16W C
R439 RK73GB1J823J CHIP R 82K J 1/16W C2
R440 RK73GB1J101J CHIP R 100 J 1/16W
R441 RK73GB1J102J CHIP R 1.0K J 1/16W
R442 RK73GB1J101J CHIP R 100 J 1/16W
R443 RK73GB1J222J CHIP R 2.2K J 1/16W
R444 RK73GB1J102J CHIP R 1.0K J 1/16W
R445 R92-1252-05 CHIP R 0 OHM J 1/16W
R501 RK73GB1J102J CHIP R 1.0K J 1/16W
R502 RK73GB1J472J CHIP R 4.7K J 1/16W
R506 RK73GB1J103J CHIP R 10K J 1/16W
R507 RK73GB1J470J CHIP R 47 J 1/16W
R509 RK73GB1J100J CHIP R 10 J 1/16W
R511 RK73GB1J471J CHIP R 470 J 1/16W
R512 RK73GB1J332J CHIP R 3.3K J 1/16W
R513 RK73GB1J682J CHIP R 6.8K J 1/16W
R514 RK73FB2A470J CHIP R 47 J 1/10W C2
R514 RK73FB2A560J CHIP R 56 J 1/10W C
R515 RK73GB1J100J CHIP R 10 J 1/16W C2
R515 RK73GB1J330J CHIP R 33 J 1/16W C
R516 RK73GB1J332J CHIP R 3.3K J 1/16W
R517 RK73GB1J100J CHIP R 10 J 1/16W
R518 RK73GB1J153J CHIP R 15K J 1/16W
R519 RK73FB2A220J CHIP R 22 J 1/10W
R520 RK73GB1J333J CHIP R 33K J 1/16W
R521 RK73GB1J101J CHIP R 100 J 1/16W
R522 R92-1217-05 CHIP R 0 OHM
R524 RK73FB2A821J CHIP R 820 J 1/10W C2
R525 RK73EB2B5R6J CHIP R 5.6 J 1/8W C2
R525 R92-0679-05 CHIP R 0 OHM C
R526 RK73FB2A821J CHIP R 820 J 1/10W C2
R527 RK73GB1J474J CHIP R 470K J 1/16W
R528,529 RK73GB1J471J CHIP R 470 J 1/16W
R530 RK73GB1J821J CHIP R 820 J 1/16W
R531 RK73GB1J473J CHIP R 47K J 1/16W
R532,533 R92-1252-05 CHIP R 0 OHM J 1/16W
R534 RK73GB1J473J CHIP R 47K J 1/16W
R535 RK73GB1J563J CHIP R 56K J 1/16W
R536 RK73EB2B100J CHIP R 10 J 1/8W
R537 RK73GB1J823J CHIP R 82K J 1/16W
R538 RK73GB1J473J CHIP R 47K J 1/16W C
R538 RK73GB1J563J CHIP R 56K J 1/16W C2
R539 R92-1213-05 CHIP R 100 J 1/2W
R601,602 RK73GB1J223J CHIP R 22K J 1/16W
R605 RK73GB1J153J CHIP R 15K J 1/16W
R606 RK73GB1J221J CHIP R 220 J 1/16W
R607 RK73GB1J331J CHIP R 330 J 1/16W
R800 R92-1061-05 JUMPER
R822 R92-1215-05 CHIP R 470 J 1/2W
VR601 R12-6427-05 TRIMMING POT. (47K/12)
D1-6 DA221 DIODE
D31 ZSH5MA27 SURGE ABSORBER
D32 1812L110PR VARISTOR
D61 02DZ18(X,Y) ZENER DIODE
D62 MA2S077 DIODE
D201 DAN222 DIODE
D202 1SS372 DIODE
D251 MA742 DIODE
D301 MA742 DIODE
D302,303 DAN222 DIODE
D351-355 HVC350B VARIABLE CAPACITANCE DIODE C2
D351,352 HVC350B VARIABLE CAPACITANCE DIODE C
D353 HVC355B VARIABLE CAPACITANCE DIODE C
D354,355 HVC350B VARIABLE CAPACITANCE DIODE C
D401 MA2S111 DIODE
D402 HZU5ALL DIODE
D403-406 MA2S304 VARIABLE CAPACITANCE DIODE
D407 1SV278 VARIABLE CAPACITANCE DIODE
D408 MA2S111 DIODE
D409 DAN235E DIODE
D502 DA221 DIODE
D503 02DZ5.1(Y) ZENER DIODE
D601,602 MA4PH633 DIODE
D603,604 XB15A709 DIODE C2
D604,605 XB15A709 DIODE C
AR-440
16
PARTS LIST
D606,607 MA742 DIODE
D608 1SS355 DIODE
IC31 KIA7808AF ANALOG IC
IC32,33 NJM78L05UA BI-POLAR IC
IC34 ✽BD4732G MOS IC
IC35 BD4740G MOS IC
IC66 AT24C64A10SI18 ROM IC
IC66 ✽CAT24WC64JI ROM IC
IC101 ✽30622MAA-B85GP MPU
IC161 M62363FP MOS IC
IC201 NJM2100V MOS IC
IC202 ✽BA10358FV MOS IC
IC203 ✽BA10324AFV MOS IC
IC204,205 BU4S66 MOS IC
IC251 ✽BA10324AFV MOS IC
IC252 2B LA4600 BI-POLAR IC
IC301 TK14489V BI-POLAR IC
IC401 MB15A02 MOS IC
IC501 TA75W01FU MOS IC
Q31 2SA1641(S,T) TRANSISTOR
Q32 KRC102S DIGITAL TRANSISTOR
Q33 2SA1745(6,7) TRANSISTOR
Q34 KRC102S DIGITAL TRANSISTOR
Q35 KTA1664(Y) TRANSISTOR
Q36 KRC102S DIGITAL TRANSISTOR
Q61 KRC404RTK DIGITAL TRANSISTOR
Q86,87 2SK1830 FET
Q201 2SC4919 TRANSISTOR
Q251 2SC2412K TRANSISTOR
Q252,253 2SK3019 FET
Q254 DTC363EU DIGITAL TRANSISTOR
Q255 KRC102S DIGITAL TRANSISTOR
Q301,302 2SC2412K TRANSISTOR
Q351 2SC5108(Y) TRANSISTOR
Q352,353 3SK255 FET
Q354 2SK1830 FET C2
Q402 2SA1832(GR) TRANSISTOR
Q403 2SC4738(GR) TRANSISTOR
Q404 2SC4649(N,P) TRANSISTOR
Q405,406 2SK508NV(K52) FET
Q407 2SJ347 FET
Q408 KRX102U TRANSISTOR
Q410,411 2SC5108(Y) TRANSISTOR
Q440 2SC2412K TRANSISTOR
Q500 2SC5110(O) TRANSISTOR
Q501 2SC3356(R24) TRANSISTOR
Q502 2SK2596 FET
Q503 PD55008TR DRIVE FET
Q504 2B RD60HUF1-01 FINAL FET
TH97,98 ✽NCP18WF104J03 THERMISTOR
TH301 ✽NCP18WF104J03 THERMISTOR
TH351 NCP18XW332J03 THERMISTOR
TH352 ✽NCP18XQ102J03 THERMISTOR
TH401 NCP18XH103K03 THERMISTOR C2
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
TX-RX UNIT (X57-686X-XX)
AR-440
17
EXPLODED VIEW
Parts with the exploded numbers larger than 700 are not supplied.
3
2
1
BA
1
30
31
18
2
3
Dx8
13
19
29 Ax2
ACx12 26 23
IC252
Q504
25 27
8Cx2
6
701
S/No. label
700
Caution label
28
44
43
48
14
42
24
24
Bx2
15
103
101
104
102
TX-RX unit
Display unit
A M2.6 x 8 : N67-2608-46
B M2 x 10 BLK: N80-2010-45
C M2.6 x 6 (Br-Tap) : N87-2606-46
D M2.6 x 14 (Br-Tap) : N87-2614-46
702
Sticker
AR-440
18
PACKING
Parts with the exploded numbers larger than 700 are not supplied.
3
2
1
DC
5 Instruction manual
(B62-1745-10)
10 AJUA38 DC cord
(E30-2111-15)
46 Screw set
(N99-0395-05)
703
Pamphlet
36 Protection bag
(H25-2341-04)
36 Protection bag
(H25-2341-04)
33 Packing xture
(H12-3112-05)
33 Packing xture
(H12-3112-05)
34 Carton board
(H13-1190-02)
40 Bracket
(J29-0662-03)
39 MIC holder
(J19-1584-05)
37 Item carton case
(H52-2030-02)
50 AJMC-32 Microphone
(T91-0641-05)
19 Fuse (6x30, 15A)
(F51-0017-05)
AR-440
19
Resetting the Tansceiver
If your transceiver seems to be malfunctioning, resetting
the microprocessor may solve the problem. The following 2
reset modes are available. When performing the reset, you
may lose memory data and stored information. Back up or
write down important data before performing the reset.
■Initial Settings
The factory defaults for the operating frequencies are as
follows.
Transceiver : 410.000MHz (C), 450.000MHz (C2)
The Memory Channels have no data stored. The Call
Channel and frequency step size default values.
Note : When in Channel Display Mode or while Key Lock is
activated, you cannot perform VFO reset or Full reset.
■Full Reset
This resets all transceiver parameters to the factory de-
fault values. There are two methods available for resetting
the transceiver.
• Full Reset Method 1:
1. With the transceiver power OFF, press [F]+[ ] (Power).
• All indicators light momentarily, followed by the full reset
confirmation message.
■VFO Reset
This resets the transceiver parameters excluding the
DTMF Memory, the Memory channel contents, and the Call
channel contents. There are two methods available for reset-
ting the transceiver.
Note : Menu No. 7 (P.VFO) and Menu No. 10 (OFFSET) re-
turn to the factory default values.
• VFO Reset Method 1:
1. With the transceiver power OFF, press [VFO]+[ ]
(Power).
• The VFO reset confirmation message appears.
2. Press [F].
• “SURE ?” appears.
• Press any key other than [F] to cancel.
3. Press [F] again to reset the transceiver.
• “WAIT” appears momentarily.
• Full Reset Method 2:
1. Press [F], [MENU] and turn the Tuning control to select
Menu No. 99 (RESET).
2. Press [MENU] and turn the Tuning control to select
“FULL”.
3. Press [MENU].
• “SURE ?” appears.
• Press any key other than [MENU] to cancel.
4. Press [MENU] to reset the transceiver.
• “WAIT” appears momentarily.
2. Press [VFO].
• “SURE ?” appears.
• Press any key other than [VFO] to cancel.
3. Press [VFO] again to reset the transceiver.
• “WAIT” appears momentarily.
• VFO Reset Method 2:
1. Press [F], [MENU] and turn the Tuning control to select
Menu No. 99 (RESET).
2. Press [MENU] and turn the Tuning control to select
“VFO”.
3. Press [MENU].
• “SURE ?” appears.
• Press any key other than [MENU] to cancel.
4. Press [MENU] to reset the transceiver.
RESETTING THE TRANSCEIVER
AR-440
20
ADJUSTMENT
Adjustment Mode
In Adjustment Mode, the transceiver can adjusted using
its panel keys.
■
Items that can be adjusted in Adjustment Mode
*1
1. Frequency Tune
2. Transmit High Power *2
3. Transmit Low Power *2
4. DCS Balance *3
5. Max Deviation *3
6. CTCSS Fine Deviation *3
qBlinks in Adjustment Mode.
wAdjustment item display
eAdjustment value display. Can be adjusted while it is
“blinking”.
Displayed as a hexadecimal number from 00 to FF.
rAdjustment value stored in memory.
When an adjustment value is determined, it is equal to the
value in “3”.
■
Panel Key Operation Method in Adjustment Mode
qPower switch/Volume control
wWhen the knob is pressed once, the adjustment value dis-
play blinks. (Select an adjustment item with “4” or “5”
key before performing the operation. It cannot be per-
formed while transmitting.)
When the knob is rotated while the adjustment display is
blinking, the adjustment value changes. (Adjust transmis-
sion items while transmitting.)
When the knob is pressed again, the adjustment value
stops blinking and lights, and the adjustment value is
saved in the memory of the transceiver. (For transmission
item adjustment, enter receive mode before performing
the operation.)
eChanging between adjustment value display and fre-
quency display
The display changes as follows : Adjustment value display
→Transmit frequency display →Receive frequency dis-
play →Adjustment value display.
The frequency for adjustment can be confirmed.
rMoves the adjustment item backward. (If it is operated
when a frequency is displayed, the adjustment item dis-
play returns.)
tMoves the adjustment item forward. (If it is operated
when a frequency is displayed, the adjustment item dis-
play returns.)
yIf it is pressed before determining the adjustment value,
the adjustment value of the Adjustment item returns to its
original value.
uNot used in Adjustment Mode.
Note :
If Max Power for transmission is low, check the DC cable.
If the DC cable connector has poor contact due to rust or
stain, voltage may drop occur frequently and correct trans-
mission power may not be supplied.
In this case, polish the DC cable connector. If the problem
still persists, replace the DC cable with a new one.
r
we
q
AR-440 MENU
qw
erty u
TX-RX unit
Component side
7. DCS Fine Deviation *3
8. DTMF Fine Deviation
9. Band Pass Tuning *4
10. Squelch Tight *5
11. Squelch Open *5
12. S-Meter S1 Level
13. S-Meter Full Level
Note :
*1 : The PLL lock voltage and Max Power Alignment for
transmission cannot be adjusted in Adjustment Mode.
*2 : Adjusted in 5 points in the transmission operating fre-
quency range.
*3 : Adjusted in 3 points for the Wide Band Width in the
transmission operating frequency range.
Adjusted in 1 point for the Narrow Band Width
*4 : Adjusted in 3 points in the reception operating frequency
range.
*5 : Adjusted in 3 points for the Wide Band Width in the re-
ception operating frequency range.
Adjusted in 1 point for the Narrow Band Width
■How to Enter Adjustment Mode
To perform adjustments with transceiver panel keys, the
transceiver must be set to “Adjustment Mode”.
While shorting the following figure terminals on the PCB
with tweezers, etc., turn the power switch ON to enter Ad-
justment Mode. (See Fig. 1.)
■LCD Display When Adjustment Mode is Enabled
Example of Frequency Tune. See “Table 1” for an LCD
display list.
Fig. 1
Fig. 2
Fig. 3
Table of contents
Other Ajetrays Transceiver manuals
