Akai P90N30AP-S3 User manual

N13275
30L Digital Microwave Oven
P90N30AP-S3
Instruction Manual
AFTER SALES SUPPORT
NZ: 0800 836 761
AU: 1300 886 649

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 1
IMPORTANT SAFETY INSTRUCTIONS 2
SPECIFICATIONS 3
INSTALLATION 3
RADIO INTERFERENCE 3
MICROWAVE COOKING PRINCIPLES 4
GROUNDING INSTRUCTIONS 4
BEFORE YOU CALL FOR SERVICE 4
UTENSILS GUIDE 5
KNOW YOUR PARTS 5
CONTROL PANEL 6
HOW TO SET THE OVEN CONTROLS 7
Setting The Clock 7
Setting Cooking Times And Power Levels 7
Preset 8
Express 8
Setting “jet defrost” 8
Setting “weight defrost” 8
Program Cooking 8
Setting “safety lock” 9
CLEANING AND CARE 9

1
Precautions to Avoid Possible Exposure
to Excessive Microwave Energy
1. Do not attempt to operate this oven with the
door open since open door operation can result
in harmful exposure to microwave energy. It is
important not to defeat or tamper with the
safety interlocks.
2. Do not place any object between the oven front
face and the door or allow soil or cleaner residue
to accumulate on sealing surfaces.
3. Do not operate the oven if it is damaged. It is
particularly important that the oven door close
properly and that there is no damage to the
a. Door (bent),
b. Hinges and latches (broken or loosened),
c. Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by
anyone except properly qualified
service personnel.

2
Important Safety Instructions
When using electrical appliance basic safety precautions should be followed, including
the following:
WARNING: To reduce the risk of burns, electric shock, fire, injury to persons or exposure to
excessive microwave energy:
1. The appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
2. Young children should be supervised to ensure that they do not play with the appliance.
3. Read all instructions before using the appliance.
4. Use this appliance only for its intended use as described in this manual. Do not use
corrosive chemicals or vapours in this appliance. This type of oven is specifically designed
to heat, cook or dry food. It is not designed for industrial or laboratory use.
5. Do not operate the oven when empty.
6. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly
or if it has been damaged or dropped. If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly qualified person in order to avoid
a hazard.
7. WARNING: Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
8. To reduce the risk of fire in the oven cavity:
• Whenheatingfoodinplasticorpapercontainer,checktheovenfrequentlytothe
possibility of ignition.
• Removewiretwist-tiesfrompaperorplasticbagsbeforeplacingbaginoven.
• Ifsmokeisobserved,switchofforunplugtheapplianceandkeepthedoorclosedin
order to stifle any flames.
• Donotusethecavityforstoragepurposes.Donotleavepaperproducts,cookingutensils
or food in the cavity when not in use.
9. WARNING: Liquid or other food must not be heated in sealed containers since they are
liable to explode.
10. Microwave heating of beverage can result in delayed eruptive boiling, therefore care has
to be taken when handle the container.
11. Do not fry food in the oven. Hot oil can damage oven parts and utensils and even result
in skin burns.
12. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens
since they may explode even after microwave heating has ended.
13. Pierce foods with heavy skins such as potatoes, whole squashes, apples and chestnuts
before cooking.
14. The contents of feeding bottles and baby jars should be stirred or shaken and the
temperature should be checked before serving in order to avoid burns.
15. Cooking utensils may become hot because of heat transferred from the heated food.
Potholders may be needed to handle the utensil.

3
16. Utensils should be checked to ensure that they are suitable for use in microwave oven.
17. WARNING: It is hazardous for anyone other than a trained person to carry out any service
or repair operation which involves the removal of any cover which gives protection
against exposure to microwave energy.
18. This product is a Group 2 Class B ISM equipment. The definition of Group 2 which contains
all ISM (Industrial, Scientific and Medical) equipment in which radio-frequency energy
is intentionally generated and/or used in the form of electromagnetic radiation for the
treatment of material, and spark erosion equipment. For Class B equipment is equipment
suitable for use in domestic establishments and in establishments directly connected to a
low voltage power supply network which supplies buildings used for domestic purpose.
19. If the supplier cord was damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person in order to avoid a hazard.
20. The appliance shall be used as a freestanding appliance and is not recommended for
built-ins.
21. The appliance is for household use only. This microwave is not recommended for use in
caravans, vehicles, boats etc.
Power Consumption: 220-240V~ 50Hz, 1400W(Microwave)
Output: 900W
Operation Frequency: 2450MHz
Outside Dimensions: 300mm(H)×539mm(W)×410mm(D)
Oven Cavity Dimensions: 240mm(H)×354mm(W)×358mm(D)
Oven Capacity: 30Litres
Cooking Uniformity: Turntable System
Net Weight: Approx.16kg
SPECIFICATIONS

4
Installation
1. Make sure that all the packing materials are removed from the inside of the door.
2. WARNING: Check the oven for any damage, such as misaligned or bent door, damaged
door seals and sealing surface, broken or loose door hinges and latches and dents inside
the cavity or on the door. If there is any damage, do not operate the oven and contact
qualified service personnel.
3. This microwave oven must be placed on a flat, stable surface to hold its weight and the
heaviest food likely to be cooked in the oven.
4. Do not place the oven where heat, moisture, or high humidity are generated, or near
combustible materials.
5. For correct operation, the oven must have sufficient airflow. Allow 20cm of space above
the oven, 10cm at back and 5cm at both sides. Do not cover or block any openings on the
appliance. Do not remove feet.
6. Do not operate the oven without glass tray, roller support, and shaft in their
proper positions.
7. Make sure that the power supply cord is undamaged and does not run under the oven or
over any hot or sharp surface.
8. The socket must be readily accessible so that it can be easily unplugged in an emergency.
9. Do not use the oven outdoors.
Radio Interference
Operation of the microwave oven can cause interference to your radio, TV, or similar
equipment. When there is interference, it may be reduced or eliminated by taking the
following measures:
1. Clean door and sealing surface of the oven.
2. Reorient the receiving antenna of radio or television.
3. Relocate the microwave oven with respect to the receiver.
4. Move the microwave oven away from the receiver.
5. Plug the microwave oven into a different outlet so that microwave oven and receiver
are on different branch circuits.

5
Principles of Microwave Cooking
1. Arrange food carefully. Place thickest areas towards outside of dish.
2. Watch cooking time. Cook for the shortest amount of time indicated and add more as
needed. Food severely overcooked can smoke or ignite.
3. Cover foods while cooking. Covers prevent spattering and help foods to cook evenly.
4. Turn foods over once during microwave cooking to speed cooking of such foods as
chicken and hamburgers. Large items like roasts must be turned over at least once.
5. Rearrange foods such as meatballs halfway through cooking both from top to bottom
and from the center of the dish to the outside.
Grounding Instructions
This appliance must be grounded. This oven is equipped with a cord having a grounding
wire with a grounding plug. It must be plugged into a wall receptacle that is properly
installed and grounded. In the event of an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the electric current. It is recommended that a
separate circuit serving only the oven be provided. Using a high voltage is dangerous and
may result in a fire or other accident causing oven damage.
WARNING: Improper use of the grounding plug can result in a risk of electric shock.
Note:
1. If you have any questions about the grounding or electrical instructions, consult a
qualified electrician or service person.
2. Neither the manufacturer nor the dealer can accept any liability for damage to the oven
or personal injury resulting from failure to observe the electrical connection procedures.
The wires in this cable main are coloured in accordance with the following code:
Green and Yellow = EARTH
Blue = NEUTRAL
Brown = LIVE

6
Before you call for a service
If the oven fails to operate:
1. Check to ensure that the oven is plugged in securely. If it is not, remove the plug from
the outlet, wait 10 seconds, and plug it in again securely.
2. Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be
operating properly, test the outlet with another appliance.
3. Check to ensure that the control panel is programmed correctly and the timer is set.
4. Check to ensure that the door is securely closed engaging the door safety lock system.
Otherwise, the microwave energy will not flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE OVEN YOURSELF.
Utensils Guide
1. The ideal material for a microwave utensil is transparent to microwave, it allows energy
to pass through the container and heat the food.
2. Microwave cannot penetrate metal, so metal utensils or dishes with metallic trim should
not be used.
3. Do not use recycled paper products when microwave cooking, as they may contain
small metal fragments which may cause sparks and/or fires.
4. Round /oval dishes rather than square/oblong ones are recommend, as food in corners
tends to overcook.
5. Narrow strips of aluminium foil may be used to prevent overcooking of exposed areas.
But be careful don’t use too much and keep a distance of 1 inch (2.54 cm) between foil
and cavity.
The list below is a general guide to help you select the correct utensils.
Cookware Microwave
Heat-resistant glass Yes
Non heat-resistant glass No
Heat-resistant ceramics Yes
Microwave-safe plastic dish Yes
Kitchen paper Yes
Metal tray No
Metal rack No
Aluminium foil & foil containers No

7
1. Door Safety Lock System
2. Oven Window
3. Turntable Roller
4. Shaft
5. Door Release Button
6. Control Panel
7. Wave Guide
8. Glass Tray
Know your Parts
4
3
1
6
5
7
8
2
Cancel

8
Control Panel
DISPLAY
Cooking time, power, indicators and present
time are displayed.
POWER LEVEL
Use to set power level and to check power
level during cooking.
TIME
Use to set cooking time.
WEI. DEF.
Use to defrost frozen meat, poultry and
seafood by weight.
MEMORY
Use to set multi-stage cooking program.
EXPRESS
Use this feature to program the oven for 4
popular microwave timing at HIGH power.
JET DEF.
Use to defrost food based on the time.
NUMBER PADS (0-9)
Touch to set times or weights.
CLOCK
Use to set the time of day or recall the time
of day.
PRESET
Use to set the oven to start at a preset time.
CANCEL
Touch to clear the selected power level, cook
or defrost times that previously programmed.
START
Touch to start the cooking or defrosting
programs. The cooking indicator light and the
oven light will turn on and the cooling fan
will operate.
Cancel

9
How to Set the Oven Controls
Each time a button is touched, a beep will sound to acknowledge the touch.
SETTING DIGITAL CLOCK
With the oven ready for input, touch the CLOCK button to set the digital clock in
12 hours cycle.
FOR EXAMPLE: Suppose you want to set the oven clock time to 8:30.
1. Touch CLOCK pad.
2. Touch CANCEL pad.
3. Use the number pads to enter the correct time. You must touch at least three numbers
to set the clock (one for hour and two for minutes).
4. Touch CLOCK pad again.
NOTE:
This is a 12-hour clock. When the oven was plugged in, “1:01” should have appeared in the
display. To reset the time of day, repeat the steps given above. You can check the clock time
while cooking is in progress by touching the CLOCK pad.
SETTING COOKING TIMES AND POWER LEVELS
A. One-stage Cooking
1. Touch TIME pad. Use the number pads to set a cooking time. You can set a cooking time
from one second to 99 minutes and 99 seconds.
2. If you want to set a power level other than 100% power, touch POWER LEVEL, and then
use the number pads to enter the power level.
3. Touch START to start cooking.
MICROWAVE COOKING
USE THESE SINGLE DIGITS TO REPRESENT POWER LEVELS:
For example, suppose you want to cook
for 1 minute at 60% of microwave power.
A.One-stage Cooking
1. Touch TIME pad.
Use the number pads to set a cooking time.
You can set a cooking time from one second
to 99 minutes and 99 seconds.
2. If you want to set a power level other than
100% power, touch POWER LEVEL, and then
use the number pads to enter the power level.
3. Touch START to start cooking.
Number pad % of Power
1, 0 100%
9 90%
8 80%
7 70%
6 60%
5 50%
4 40%
3 30%
2 20%
1 10%
0 0%

10
B - Two-stage Cooking
Some recipes require different stages of cooking at different temperatures.
1. SET STAGE 1:
Follow steps 1 and 2 in “One-stage Cooking”.
DO NOT TOUCH START PAD.
2. SET STAGE 2:
Touch MEMORY pad then enter proper cooking time and (lower) power level.
(Most 2-stage recipes use lower power for second stage.)
3. Touch START pad.
NOTE:
The respective lights will on to indicate which stage the oven is operating.
PRESET
Suppose you want to set the oven to start at 2 o’clock.
Steps:
1. Touch PRESET pad.
2. Touch number pads to enter preset time.
3. Set the cooking programs.
4. Touch START pad.
NOTE:
Be sure the time of day clock is set at the correct time before programming PRESET.
EXPRESS
Use this feature to program the oven for 4 popular microwave timings.
With each touch of the EXPRESS pad you can program the oven for:
15 seconds ………TOUCH ONCE
30 seconds……….TOUCH TWICE
1 minute……….TOUCH 3 TIMES
2 minutes………TOUCH 4 TIMES
The oven will operate at HIGH power (100% power output) for EXPRESS cooking program.
Suppose you want to set the oven to cook for 1 minute at 100% by using the feature:
Steps:
1. Touch the EXPRESS pad 3 times then “1:00” will appear in the display.
2. Touch START pad.

11
SETTING “JET DEFROST”
1. Touch JET DEF. pad.
2. Enter desired defrosting time by touching correct number pads.
3. Touch START pad.
NOTE:
The maximum time you can set is 99 minutes and 99 seconds.
SETTING “WEIGHT DEFROST”
Suppose you want to defrost 600g shrimp.
1. Touch WEI. DEF. pad 3 times. “d3” will appear in the display.
2. Use number pads to enter food weight.
3. Touch START pad.
NOTE: The maximum allowable weight for each category is shown below.
FOOD CATEGORY MAXIMUM WEIGHT DISPLAY
Meat 2300g d1
Poultry 4000g d2
Seafood 900g d3
For foods exceeding these maximum weights, use the JET DEFROST program. If you program
weight in excess of the maximum recommended, the oven will not operate properly.
PROGRAM COOKING

12
The oven has the ability to be programmed to do several consecutive functions.
Suppose you want to set the following cooking program:
(1) JET DEFROST;
(2) 1st stage: Cook for 5 minutes at 100%;
(3) 2nd stage: Cook for 10 minutes at 50%.
Steps:
1. Touch CANCEL pad.
2. Input jet defrost program.
3. Touch MEMORY pad.
4. Input time (5 minutes) and power level (100%) cooking program.
5. Touch MEMORY pad.
6. Input time (10 minutes) and power level (50%) cooking program.
7. Touch START pad.
NOTE:
JET DEFROST and WEI. DEFROST can only be set as the first stage. EXPRESS COOKING can be
set in a multi-stage cooking program.
SETTING “SAFETY LOCK”
Use to prevent unsupervised operation of the oven by little children. The CHILD LOCK
indicator will show up on display screen, and the oven can not be operated while the CHILD
LOCK is set.
1. To set the CHILD LOCK: Press and hold the CANCEL button for 3 seconds, a beep sounds
and lock indicator lights.
2. To cancel the CHILD LOCK: Press and hold the CANCEL button for 3 seconds until
LOCK indicator on display goes off.
NOTE:
SPEED DEFROST, AUTO DEFROST, QUICK START COOKING, AUTO COOK can not be set in
multi- stage cooking program.
AUTO REMINDER
After cooking, beeps sound and END appears in display. Touch any pad or open oven door to
clear END before starting another cooking function

13
Clean & Care Instructions
1. Turn off the oven and remove the power plug from the wall socket before cleaning.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven
walls, wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty.
Avoid the use of spray and other harsh cleaners as they may stain, streak or dull the
door surface.
3. The outside surfaces should be cleaned with a damp cloth. To prevent damage to
the operating parts inside the oven, water should not be allowed to seep into the
ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently
with a damp cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When
cleaning the control panel, leave oven door open to prevent oven from accidentally
turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft
cloth. This may occur when the microwave oven is operated under high humidity
condition. And it is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm
sudsy water or in a dishwasher.
8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise.
Simply wipe the bottom surface of the oven with mild detergent. The roller ring may be
washed in mild sudsy water or dishwasher. When removing the roller ring from cavity
floor for cleaning, be sure to replace in the proper position.
9. Remove odours from your oven by combining a cup of water with the juice and skin of
one lemon in a deep microwaveable bowl, microwave for 5 minutes. Wipe thoroughly
and dry with a soft cloth.
10. When it becomes necessary to replace the oven light, please consult a dealer to have
it replaced.
11. The oven should be cleaned regularly and any food deposits removed. Failure to
maintain the oven in a clean condition could lead to deterioration of the surface that
could adversely affect the life of the appliance and possibly result in a hazardous.
12. Please do not dispose this appliance into the domestic rubbish bin; it should be
disposed to the particular disposal centre provided by the municipalities.
Recycling
At the end of its working life, do not throw this appliance out with your household rubbish.
Observe any local regulations regarding the disposal of electrical consumer goods and
dispose of it appropriately for recycling. Contact your local authorities for advice on recycling
facilities in your area.

14
Troubleshooting
If the oven fails to operate:
1. Check to ensure that the oven is plugged in securely. If it is not, remove the plug from
the outlet, wait 10 seconds, and plug it in again securely.
2. Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be
operating properly, test the outlet with another appliance.
3. Check to ensure that the control panel is programmed correctly and the timer is set.
4. Check to ensure that the door is securely closed engaging the door safety lock system.
Otherwise, the microwave energy will not flow into the oven.
If none of the above rectifies the situation, then please call the After Sales Support Number.
WARRANTY
We pride ourselves on producing a range
of quality home appliances that are both packed with features
and are completely reliable. We are so condent in our products
that we back them up with a full 2 year replacement warranty.
Now you can relax knowing that you are covered.
After Sales Support NZ: 0800 836 761
AU: 1300 886 649
This Product is covered by 2 year replacement warranty
when accompanied by proof of purchase.
