Sharp R-752M Instruction Manual

900 W (IEC 705)
R-752M
MICROWAVE OVEN WITH GRILL
OPERATION MANUAL WITH COOKBOOK
E
Quartz Dual Grill
R-752
10min. 1min. 10sec.
LESS MORE
g ozKg Lb
POWER LEVEL
STOP/
CLEAR
START
AUTO MINUTE
TIMER Kg/Lb
AUTO START
GRILL DUAL GRILL
MICROWAVE
CLOCK
1 Roast Beef/Lamb
2 Roast Pork
3 Roast Poultry
4
Chilled Ready Meals
5 Frozen Ready Meals
1 Meat Joint
2 Poultry
3
Chicken Ptn,Steak,Chops
4 Minced Meat
5 Bread
KGTURNSTIR GRILL MICRO COOK
OPERATION MANUAL
This operation manual contains important information which you should read carefully before using
your microwave oven.
IMPORTANT: There may be a serious risk to health if this operation manual is not followed or if the oven is
modified so that it operates with the door open.

1
CONTENTS
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Oven and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Basic Operation:
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Maff Heating Category . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Microwave Power Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Microwaving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
How to Operate the Oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Dual Grilling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Auto Operation:
Instant Cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Instant Cook chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11-12
Auto Cook /Auto Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Auto Cook /Auto Defrost charts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-15
Other Convenient Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-18
Cooking Advice:
Suitable Cookware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19-20
Food Handling & Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20-21
Advice For Reheating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Advice For Defrosting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Cookbook: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24-49
Aftercare:
Cleaning & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50-51
To replace the mains plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Calling for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53

2
OVEN AND ACCESSORIES
ACCESSORIES:
Check to make sure the following
accessories are provided:
12 Turntable 13 Turntable support
14 Coupling
Place the turntable support in the centre
of the oven floor so that it can freely
rotate around the coupling. Then place
the turntable on to the turntable support
so that it locates firmly into the coupling.
To avoid turntable damage, ensure dishes
and containers are lifted clear of the turntable rim
when removing them from the oven.
15 High and Low racks (For use of the racks, refer to
the grilling and dual grilling sections on page 19).
NOTE: When you order accessories, please mention
two details: part name and model name to your dealer
or SHARP authorised service facility.
1Control panel
2Oven lamp
3Waveguide cover
4Door opening button
5Turntable support system
6Oven cavity
7Door seals and sealing
surfaces
8Grill heating element
9Air vent openings
10 Outer cabinet
11 Power supply cord
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

3
CONTROL PANEL
1. DIGITAL DISPLAY
2. TIME keys:
Use to enter cooking time.
3. INSTANT COOK keys:
Use to cook foods illustrated.
4. AUTO COOK key:
Use for programming the AUTO COOK
menus 1 - 5.
5. AUTO DEFROST key:
Use for programming the AUTO DEFROST
menus 1 - 5.
6. Kg.Lb/g.oz keys:
Press to enter weight.
7. LESS/MORE keys:
Press to shorten/lengthen cooking time.
8. MICROWAVE POWER LEVEL key:
Press to select microwave power level.
9. GRILL key:
Press to select grill.
10. DUAL GRILL key:
Press to select a combination of microwave and
grill.
11. STOP/CLEAR key:
Press once to stop a programme, and/or twice
to cancel a programme.
12. START/AUTO MINUTE key:
Press to start a programme. Press to cook on
100P (HIGH) for 1 minute or increase time
during cooking in multiples of 1 minute.
13. TIMER key:
Press to use as a minute timer, or to programme
standing time.
14. WEIGHT CONVERSION key:
Use to alter weight unit, e.g. Kg/g to Lb/oz.
15. AUTO START/CLOCK key:
Use to set the clock, display the time or
programme AUTO START.
R-752
10min. 1min. 10sec.
LESS MORE
g ozKg Lb
POWER LEVEL
STOP/
CLEAR
START
AUTO MINUTE
TIMER Kg/Lb
AUTO START
GRILL DUAL GRILL
MICROWAVE
CLOCK
1 Roast Beef/Lamb
2 Roast Pork
3 Roast Poultry
4
Chilled Ready Meals
5 Frozen Ready Meals
1 Meat Joint
2 Poultry
3
Chicken Ptn,Steak,Chops
4 Minced Meat
5 Bread
KGTURNSTIR GRILL MICRO COOK
1
2
3
4
7
5
9
14
12
10
6
8
11
13 15

4
INSTALLATION
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
Inspect the Oven:
Check the oven carefully for damage
before and regularly after installation.
• Make sure the door closes properly,
that it is not misaligned or warped.
• Check the hinges and door safety
latches are not broken or loose.
• Ensure the door seal and sealing
surfaces are not damaged.
• Inspect the oven interior and door for
dents.
Important:
If the door or door seals are damaged,
the oven must not be operated until it
has been repaired by a competent
person.
1.Remove all packing materials. Do not remove the
plastic film from the inside of the oven window as this
protects it from dirt.
2.Place the oven on a secure, level surface, strong
enough to take the oven weight, plus the heaviest
item likely to be cooked in the oven.
3.Ensure there is a minimum of free space above the
oven of 19cm.
4.Do not place the oven where heat, moisture or high
humidity are generated, (for example, near or
above a conventional oven) or near combustible
materials (for example, curtains). Do not block or
obstruct air vent openings, as obstructions may
ignite due to the emission of hot air. Do not place
items on top of the oven.
5.Make sure the power supply cord is undamaged
(See Installation next page) and that it does not run
under the oven or over any hot or sharp surfaces.
6.The socket must be readily accessible so that it can
be easily unplugged in an emergency.
7.Do not use the oven outdoors.
Oven Use:
• The oven is for domestic food preparation only.
Never operate when empty.
• Do not leave or store anything inside the oven
when not in use.
• Never attempt to use the oven with the door open.
It is important not to force or tamper with the door
safety latches. This may result in exposure to
microwave energy.
• Never operate the oven with any object caught in
the door sealing surfaces, this again may cause
microwave leakage.
• Do not insert fingers or objects in the holes of the
door latches or air-vent openings, as this may
damage the oven and cause an electric shock.
• If water or food drops inside the air vent openings
switch off the oven immediately, unplug it and call
a Service Technician appointed by SHARP.
• Never attempt to move the oven while it is
operating.
Pacemaker: If you have a heart pacemaker,
consult your doctor or the pacemaker manufacturer
prior to oven use.
WARNING: Only allow children to use
the oven without supervision when
adequate instructions have been given so
that the child is able to use the oven in a
safe way and understands the hazards
of improper use.
Do not allow anyone to play with the oven, or lean
or swing on the oven door.
Fire: If food overheats, starts to smoke
or burn: Keep oven door closed; Turn
oven off; Switch off the power at the
socket and disconnect the plug from the
socket. Failure to follow this procedure
may result in fire and oven damage.
Liquids: Take care when microwaving
liquids and beverages. To prevent
delayed eruptive boiling of liquid and
possible scalding: Stir liquid prior to and
during heating/reheating, let liquid stand
in the oven at the end of cooking.
IMPORTANT SAFETY INSTRUCTION: READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

5
INSTALLATION
BUILDING-IN-KIT.
An installation frame is available which enables the
microwave oven to be integrated within a kitchen unit.
The microwave oven is not designed to be built above
or near a conventional oven.
SHARP recommend the use of the build in kit, EBR-
4500, available from your SHARP dealer. Only the
use of this frame will guarantee the quality and safety
of the oven. When building, follow installation
instructions (for B type) supplied carefully.
IMPORTANT! ELECTRICAL CONNECTION.
• Do not allow water to come into contact with the
power supply cord or plug.
• Insert the plug properly into the socket as the plug
may otherwise overheat and catch fire.
• Do not connect other appliances to the same socket
using an adaptor plug as it may cause the house
wiring to overheat and catch fire.
• If the plug or socket is loose or the power supply
cord is damaged, it must be replaced with a
special cord. The exchange must be made by an
authorised SHARP service agent. A defective plug,
power supply cord or socket may overheat and
catch fire during operation or cause an electrical
shock.
• When removing the plug from the socket always
grip the plug, never the mains lead as this may
damage the power supply cord and the
connections inside the plug.
• The product is fitted with a re-wireable plug. Should
it not be suitable for the socket outlet in your home,
remove the plug and fit an appropriate type,
observing the wiring code given in “To replace the
mains plug” on page 41.
If you wish to remove or replace the plug supplied,
ensure the plug is removed properly and not cut off.
When replacing the plug please ensure that you use a
BSI or ASTA approved plug to BS1363, this should be
fitted with a brown coloured 13 amp fuse approved
by BSI or ASTA to BS1362. If you have any doubt
about electrical connection seek the help of a
qualified electrician.
WARNING
THIS APPLIANCE MUST BE EARTHED
To wire an appropriate plug, follow the wiring code
given in “To replace the mains plug” on page 41.
BEFORE OPERATION
Plug in the oven.
1. The oven display will flash:
2. Touch the STOP/CLEAR key the display will
show:
To set the clock, see page 6.
Use of the STOP/CLEAR key.
Use the STOP/CLEAR key to:
1. Erase a mistake during programming.
2. Stop the oven temporarily during cooking.
3. Cancel a programme during cooking, touch twice.
1.
2.
STIR TURN KG GRILL MICRO COOK
STIR TURN KG GRILL MICRO COOK
Heat the oven using GRILL mode without food for
20 minutes. See note on page 9.
STOP/
CLEAR

6
3. If the electrical power supply to your microwave
oven is interrupted, the display will intermittently
show after the power is reinstated. If
this occurs during cooking, the programme will
be erased. The time of day will also be erased.
4. When you want to reset the time of day, follow
the above example again.
NOTE:
1. Whilst in operation, the oven display will show the
cooking mode and number of minutes/seconds of
remaining cooking time. To check the time of day,
press AUTO START/CLOCK key and the time of
day will remain on the display as long as you keep
your finger on the key. This does not affect the
cooking process.
2. If the clock is set, when cooking is complete, the
display will show the correct time of day. If the clock
has not been set, the display will only show
when cooking is complete.
SETTING THE CLOCK
x1
x3 x5
Your oven is fitted with a clock which can be set to the time of day.
There are two setting modes: 12-hour clock and 24 hour-clock.
To set the 12 hour-clock, press the AUTO
START/CLOCK key once, will appear in
the display.
To set the 24 hour-clock, press the AUTO
START/CLOCK key twice, will appear in
the display.
Example:
To set the 12 hour clock to 12:35
x1 x2x1
2. Press the 10 MINUTE
key once and the 1
MINUTE key twice to
enter hours.
1. Press the AUTO START/
CLOCK key once for
the 12 hour clock.
3. Press the AUTO START/
CLOCK key again.
Check the display.
5. Press the AUTO START/
CLOCK key again to start
the clock.
4. Press the 10 MINUTE key 3
times and the 1 MINUTE
key 5 times to enter
minutes.
AUTO START
CLOCK
AUTO START
CLOCK
x1
AUTO START
CLOCK
x2
AUTO START
CLOCK
AUTO START
CLOCK
10min.
1min.
10min.
1min.
x1

7
MAFF HEATING CATEGORY
The heating category (a letter A to E) developed by
MAFF (Ministry of Agriculture, Fisheries and Food)
with microwave oven and food manufacturers
indicates the ability of the oven to heat small
quantities of food (up to 500g [1lb 2oz]). It does
not represent the general performance of the oven.
Microwave output power in
watts (based on international
(IEC 705) standard.)
600 700 800 900 1000 Watts
OVEN
OUTPUT
POWER
Less heating time required
More heating time required
Letter representing the oven
heating category.
Microwave
Symbol.
A B C D E
OVEN
OUTPUT
CATEGORY
Less heating time required
More heating time required
MICROWAVE POWER LEVELS
Food packs carry cooking instructions for heating
categories A to E. Follow instructions for the letter
corresponding to the oven’s heating category. The
higher the output power and heating category of
the oven the less heating time is required. As
shown opposite.
Enter required time and select the power level:
There are 5 microwave power levels:
x1
x2
x3
x4
x5
100P (HIGH)
70P (MEDIUM HIGH)
50P (MEDIUM)
30P (MEDIUM LOW)
10P (LOW)
IMPORTANT: The microwave power level will default
to 100P (HIGH) unless you press the MICROWAVE
POWER LEVEL key to the desired setting. To help you
decide which power level is suitable, follow the advice
given in the charts; for defrosting see page 25, for
cooking see pages 26-27, for reheating see page 28.
Power level: The microwave power level is varied
by the microwave energy switching on and off.
When using power levels other than 100P (HIGH) you
will be able to hear the microwave energy pulsing on
and off as the food cooks or defrosts.
Stopping the oven: If you wish to stop the oven
during cooking press the STOP/CLEAR key or open
the oven door. To start the oven, close the door and press
the START/AUTO MINUTE key. If you wish to
cancel the cooking programme, press the
STOP/CLEAR key twice.
POWER LEVEL
MICROWAVE
STIR TURN KG GRILL MICRO COOK
E
STIR TURN KG GRILL MICRO COOK
STIR TURN KG GRILL MICRO COOK
STIR TURN KG GRILL MICRO COOK
STIR TURN KG GRILL MICRO COOK
POWER LEVEL
MICROWAVE
POWER LEVEL
MICROWAVE
POWER LEVEL
MICROWAVE
POWER LEVEL
MICROWAVE
E
900W

8
HOW TO OPERATE THE OVEN
MICROWAVING
Opening and closing the door:
To open the oven door, press the door opening button.
The oven lamp will come on while the door is open.
Close the door firmly and the oven lamp will go out.
Stopping the oven:
If you wish to stop the oven during cooking press
STOP/CLEAR or open the oven door. To start the oven,
close the door and press START/AUTO MINUTE. If
you wish to cancel the cooking programme, press
STOP/CLEAR twice.
Prepare and place food in suitable container onto the
turntable or directly onto the turntable. Close the door.
WARNING
Always operate the oven with the turntable
and support fitted correctly, see page 2. This
promotes thorough even cooking.
A badly fitted turntable may rattle, may not
rotate properly and damage the oven.
The turntable rotates clockwise or counter
clockwise. The rotary direction may change
each time you start the oven. This does not
affect cooking performance.
Enter cooking time,
press the 10
SECOND key three
times.
Press the
MICROWAVE
POWER LEVEL key
once for 100P (HIGH).
Press the
START/AUTO
MINUTE once to
start cooking.
The display will count
down through the
cooking time.
Example:
To cook on 100P (HIGH) power for 30 seconds.
x3 x1
Introduction:
Water, sugar and fat in food absorbs microwaves
and causes them to vibrate. This creates heat by
friction, in the same way your hands get warm when
you rub them together.
Outer areas of food are heated by microwave
energy, and remaining portions by conduction. It is,
therefore, important to turn, rearrange or stir food
to ensure even heating. Where recommended, allow
food to stand, this is not optional but necessary to
ensure thorough cooking and is particularly important
for dense food, such as joints of meat.
Microwaves pass through non-metallic dishes and utensils
and heat the food inside the dishes. Microwaves are
reflected by metal. The oven is lined with metal and has a
fine metallic mesh in the door to prevent microwave
leakage. Metallic dishes are not suitable for
microwaving.
(See suitable cookware, page 19-20).
10sec.
STIR TURN KG GRILL MICRO COOK
START
AUTO MINUTE
1. 2. 3. 4.
STOP/
CLEAR
START
AUTO MINUTE
POWER LEVEL
MICROWAVE
x1
