Akai AK4919UHDS User manual

INSTRUCTION MANUAL
49” 4K Ultra HD
Smart TV
Model Number: AK4919UHDS

2
Congratulations on choosing to buy an AKAI product.
All products brought to you by AKAI are manufactured to the highest
standards of performance and safety and, as part of our philosophy of
customer service and satisfaction, are backed by our comprehensive 1 Year
Warranty.
We hope you will enjoy using your purchase for many years to come.
Welcome

3
Contents
Welcome 2
Important Safety Instructions 4
Remote Control 10
Installation 16
Controls and Connections 20
Getting Started 28
Basic Operations 31
TV Guide 34
Recording 35
USB Multimedia Playback 39
Smart TV 43
Menu Settings 49
Troubleshooting 57
Specifications 60
Other Useful Information 61

4
Read this manual thoroughly before first use and keep it in a safe place for future reference,
along with purchase receipt and carton. The safety precautions enclosed herein reduce the risk
of fire, electric shock and injury when correctly adhered to. Follow all instructions and take notice
of all the warnings.
This product complies with Australian Safety standard AS/NZS 60065 to ensure the safety
of the product.
The lightning flash with an arrowhead
symbol within an equilateral triangle is
intended to alert you to the presence
of non-insulated dangerous voltage
within the product’s enclosure that
may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended
to alert you to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
To reduce the risk of electric shock, do not remove
the cover (or back).
This unit contains no user-serviceable parts inside.
Refer all servicing to qualified service personnel only.
Important Safety Instructions
IMPORTANT WARNINGS AND CAUTIONS!
• Only connect this TV to a mains socket with a protective earthing connection.
• To prevent damage which may result in fire or an electric shock hazard, do not expose this
appliance to rain or moisture.
• Do not change or modify the appliance in any way.
• Only use the attachments/accessories specified by the manufacturer.
Electrical Safety and Cord Handling
• Voltage: Before installing this TV, make sure your outlet voltage corresponds to the voltage
stated on the TV’s rating label.
• Protect from moisture: To reduce risk of fire or electric shock, do not expose this TV to
rain or moisture; do not use it near water; do not touch the power plug with wet hands.
• Damage: Do not use a damaged power cord, plug or loose outlet. Doing so may cause
electric shock.
• Power outlet: Do not plug several devices into the same outlet. Doing so may cause the
outlet to overheat and start a fire. Make sure the outlet is properly earthed and readily
accessible during operation of the equipment.
• Power plug: Make sure the plug is properly installed before inserting it fully into the outlet.
A loose or improperly inserted power plug may cause a fire. The mains plug is used as the
power disconnect device and shall remain readily accessible and operable.
The RCM is a visible indication of a product’s compliance with all applicable ACMA
regulatory arrangements, including all technical and record-keeping requirements.

5
Important Safety Instructions (Cont.)
• Protect the cord: Do not bend, twist or kink the power cord excessively. Do not allow
anything to rest on or roll over the power cord and antenna cable. Doing so may cause a
fire or an electric shock. Do not run the power cord near heat-producing appliances such
as radiators, stoves or irons. The excessive heat could melt the insulation and expose live
wires, resulting in fire or electric shock.
• Disconnect: Always grasp the plug when disconnecting the power cord. Pulling the cord
can damage the internal wire and may cause a fire.
• Disconnect device: Where the mains plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily operable.
• Lightning storms: Unplug the power cord and antenna cord during lightning storms or
when unused for long periods of time. Not doing so may result in fire or electric shock.
Before lightning storm events arrive, unplug to minimise risk of damage to your TV.
Installation
• Follow instructions: Only install this TV in accordance with these instructions.
• Location: This TV is designed for indoor, fixed location use only. It must not be used in
portable or mobile applications as vibration or excessive forces may damage the unit.
• When deciding on where to put the TV, make sure the place is:
• Well ventilated, and away from damp and cold.
• Protected from overheating and away from direct sunlight. (Total darkness or a
reflection on the picture screen can cause eyestrain. Soft and indirect lighting is
recommended for comfortable viewing.)
• Away from moisture drips or splashes.
• Protected from excessive dust or grease.
• WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in
accordance with the installation instructions.
• This TV is equipped with standard wall-mounting points, and we recommend that a wall
bracket should be installed between the TV and the wall to prevent the TV from falling
from a cabinet. (The bracket is not included.)
• If a television is not positioned in a sufficiently stable location, it can be potentially
hazardous due to falling and causing injury, particularly to children. To prevent injuries from
your television falling, take a few simple precautions:
• Do not place the TV on tall furniture (e.g., on a cupboard or bookcase) without
anchoring both the furniture and the TV to a suitable support.
• Only use furniture that can safely support the television.
• Ensure the TV is not overhanging the edge of the supporting furniture.
• Educate children about the dangers of climbing on furniture to reach TV controls.
• Do not place the TV on cloth or other materials.
• Bookcase: Do not install this equipment in a confined space such as a bookcase or similar
unit.
• Heat: Do not install the TV near heat sources such as radiators, stoves or other audio visual
equipment (including amplifiers) that produce heat.

6
Important Safety Instructions (Cont.)
• Environments: This TV is not warranted for use in unreasonably hot, cold or humid
environments.
• Antenna: Install the antenna away from high-voltage power lines and communication cables.
Make sure it is installed securely. If the antenna touches a power line, contact with the antenna
could result in fire, electric shock or serious injury.
• Vibration: Do not expose the TV to vibration or shock.
• Ventilation: Install the unit at an adequate distance from the wall to ensure sufficient
ventilation. Leave at least 10cm clear space around the TV, and 30cm from the top of the
TV. If the temperature inside the unit rises, it may result in fire. Do not cover the ventilation
openings.
Usage Conditions and Restrictions
• Adjustments: Follow the instructions in this manual when installing and adjusting the TV.
Only adjust those controls that are covered in this manual, as improper adjustment of other
controls may result in damage.
• Do not modify: Do not change or modify the appliance in any way.
• Attachments: Only use the attachments/accessories specified in this manual.
• Cabinet slots: Do not insert objects of any kind into this unit through the cabinet slots, as
they could touch the current-carrying parts or short-circuit parts, resulting in fire, electric
shock or damage to the unit.
• Smoke or odour: If you notice any unusual odours or smoke around the unit, immediately
disconnect the unit from the outlet and contact the service centre. Failure to do so may
result in fire or electric shock.
• Water: Do not place containers with liquids (such as vases) or with small metallic objects on
top of the unit. If liquid enters the unit or any metal object falls into the unit, it may result in
short-circuit, fire or electric shock.
• Fire or explosion: Do not use or store flammable or combustible materials near the TV.
Doing so may result in fire or explosion. Do not place any naked flame sources, such as lit
candles, cigarettes or incense sticks on top of the TV.
• When not in use: When not using the TV for long periods of time, disconnect the power
cord from the wall outlet.
• Batteries: When removing batteries from the remote control, make sure to keep them out
of reach of infants, children and pets. Seek medical attention immediately if a child has
swallowed a battery. Never throw used batteries in a fire.
• Usage restriction: This product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instructions concerning use of the product by a person
responsible for their safety.
• Children: Supervise children to ensure they do not play with the TV.
• Turning: When you are turning the TV, do not hold and push on the top section of the TV,
always turn at the bottom corner of the TV.

7
Cleaning and Maintenance
• Unplug: To reduce risk of fire and electric shock, unplug the TV before cleaning.
• Cleaning: Only use a soft, dry cloth when cleaning the TV. Do not use a damp cloth. Never
clean with industrial strength polish, wax, benzene, paint thinner, air freshener, lubricant,
detergent or other chemicals. Wipe off any moisture, dirt or dust on the power plug pins
with a clean, dry cloth.
• Cleaning the screen: When you clean up dust or water drops on the LCD panel or cabinet,
the power cord should be physically removed from the mains outlet. You may then wipe the
TV with a dry soft cloth.
• Repair: If the TV requires repair, contact the after sales support line; never disassemble or
modify the TV or attempt to service it yourself.
• Service: Refer all servicing to qualified service personnel. Servicing is required when the TV
has been damaged in any way, such as when the power supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the TV, when the TV has been exposed to
rain or moisture, does not operate normally, or has been dropped.
Disc Protection
• Storage: Store your discs in a cool area to avoid damage from heat.
• Contact: Do not touch the playback side of the disc.
• Cleaning: Do not attach tape or paper to the disc. To clean off dust, slightly moisten a soft
cloth and finish with a dry cloth.
• Do not use any type of solvent, commercially available benzene or antistatic spray for vinyl
LPs, as these may damage the discs.
• See the DVD Mode section for more disc cleaning and handling tips.
Important Safety Instructions (Cont.)

8
Moving, Installing and Wall-Mounting the TV
When removing the TV from its original packaging, moving the TV to a different location,
cleaning, installing and wall mounting the TV, make sure you take the below precautions:
• Always move the TV by two people holding it with both hands on either side of the TV.
• Do not apply any pressure directly on the front screen of the TV, the LCD screen may be
damaged if not handled carefully.
• Beware of the TV stand if attached to the TV.
• Always place TV on a stable, flat and clean surface.
• Children should never be allowed to move and play with the TV.
• If moving the apparatus from one location to another (for example from a cold environment
to a warm one) allow sufficient time for the apparatus to acclimatise to the new location
before switching it on. In tropical climates, keep the air surrounding the unit sufficiently dry
to avoid condensation forming.
Important Safety Instructions (Cont.)
WARNING!
• Never tamper with any components inside the TV, or any other adjustment controls. All
LED LCD TVs are high voltage instruments.
• All repairs to this TV must only be performed by qualified TV service personnel. There
are no user-serviceable components within this TV. Changes or modifications to this
TV, including changes to parts, components and constructional attributes that are
responsible for safety and regulatory compliance, may result in non-compliant and
unsafe operation.

9
Remote Control

10
Remote Control
Connect the USB RF receiver dongle
(included with Remote Control) to USB
1 or USB 2 port before using the remote
control.
1 (ON/STANDBY): Set the unit in
standby mode; press it again to switch
it on.
2 : Move fast backward.
3 : Start or pause playing.
4 : Play previous file.
FAV: In DTV mode, show the Favourite
Channels list.
5 : Stop playing.
6 (HOME): Enter the HOME page
(Smart TV).
7 (MOUSE)*: Turn on/off Airmouse
function (Smart TV).
8 OK: Confirm your selection; in DTV
mode, show the Channel list.
9 / / / :Press the LEFT/RIGHT UP/
DOWN buttons to navigate the on-
screen menus and adjust the system
settings to your preference.
10 VOL +/-: Turn the volume up/down.
11 MUTE: Mute the sound. Press it again
to restore the sound.
12 NUMBER BUTTONS (0-9): Select a TV
channel directly when watching TV.
13 REC: Record a program (digital TV
only).
14 / / / BUTTONS:
Perform the corresponding functions
shown on the On-Screen Display.
15 : Return to previous channel.
16 SUBTITLE: Select available subtitles.
17 MEDIA: Enter USB (or Media) mode
directly.
18 INFO: Display information of the
current program.
19 GUIDE: Launch the TV Guide (digital
signals only).
2
4
3
1
5
6
7*
8
9
10
11
12
13
14
26
25
24
23
22
21
20
19
18
17
16
15
* The USB RF receiver dongle
needs to be connected for this
button to function.

11
Remote Control (Cont.)
2
4
3
1
5
6
7*
8
9
10
11
12
13
14
26
25
24
23
22
21
20
19
18
17
16
15
Remote Control Keyboard Tips:
• To enter UPPERCASE letters, press the
‘Caps’ button first. After entering, press the
'Caps' button again to return to lowercase.
• To enter numbers and characters shown
on the keys in blue, press the ‘Alt’ button
first, followed by the chosen letter button.
After entering, press the 'Alt' button again to
return to normal mode.
• The ‘Del’ button on the keyboard performs
the backspace function.
• As an alternative to the keyboard, you can
use the on-screen keyboard.
• The USB RF receiver dongle must be
connected for the keyboard to operate.
20 Live TV: Enter Live TV directly.
21 CH +/-: Press to play the next or
previous channel.
22
*
(RETURN): Go back to previous
page (Smart TV).
23 : Play next file.
24 MENU: Display the main menu; press
again to return to the previous menu.
25 : Move fast forward.
26 SOURCE: Select the input source.
NOTE: There is a built-in keyboard on
the back of the remote control for easy
operation (Smart TV only).

12
Airmouse
Airmouse function
• Airmouse enables you to navigate the
web browser and apps by moving the
remote control, which in turn moves the
cursor.
• For Airmouse to work, you need to
connect the supplied USB RF Receiver
dongle to one of the USB ports.
• To activate the Airmouse function, press
the button. The mouse cursor will
appear on the screen.
• To scroll web pages, press and hold the
OK button, move the remote up or down,
then release the button when you reach
your desired spot on the web page.
• To deactivate the Airmouse function,
press the button again. The mouse
cursor will disappear from the screen.
NOTE: If no actions are made for 20 seconds
or longer, the Airmouse function will turn off
automatically.
1. While the TV is ON and the USB dongle is
connected, point the remote control at the IR
receiver sensor at the bottom-right corner of the
TV, and press and hold the OK button and the
MUTE button on the remote control at the same time.
2. When the LED indicator on the remote control starts blinking, let go of the
buttons. The LED will blink three times and then stay lit.
3. Unplug the dongle and plug it back again.
4. The LED indicator will flash three times again. Pairing has been completed.
5. To make sure that the pairing has been successful, press the Airmouse button
and the cursor should appear on-screen. If not successful, repeat steps 1-4.
Pairing the Remote Control and the USB
RF Receiver Dongle
If you get a new/replacement remote control or a USB
dongle, you will need to pair them with each other.
Remote Control (Cont.)

13

Remote Control (Cont.)
Using the Remote Control
Inserting Batteries
Install the batteries as illustrated in Fig. 1 (see right).
• Slide open the cover at the back of the remote control to
remove it.
• Insert two AAA size batteries according to the polarity
markings (+ / -) inside the compartment. Make sure the
batteries are correctly aligned and properly pushed into
place.
• Slide the back cover back into position.
NOTE: When testing the remote control unit after replacing
the batteries, make sure the TV is properly connected
to the mains power supply.
Battery Service Life
• The service life of batteries depends on usage and
environmental conditions. They should normally last for
about one year.
• If the remote control fails to work even when it is
operated near the TV, replace the batteries.
Precautions When Using Batteries
• Do not use old and new batteries together.
• Do not use different types of batteries (for example, Manganese and Alkaline
batteries) together.
• Note that there are chargeable and non-chargeable batteries. Do not attempt to
charge non-chargeable batteries.
• Remove the batteries from the remote control unit if you do not intend to use the
unit for a long time.
• When discarding used batteries, follow any guidelines for recycling and disposal
of batteries that apply in your local area.
• Keep batteries away from children and pets.
• Never throw batteries into a fire or expose them to fire or other sources of extreme
heat such as direct sunshine.
Push
Press

14
Remote Control (Cont.)
Using the Remote Control
To use the remote control, point it towards the remote
sensor at the front of the television.
The remote control has a range of up to
approximately six metres (6m) from the TV at an angle
of up to 30 degrees each to the right and left of the
sensor, as illustrated on the right.
The remote control will not operate if its path is
blocked.
NOTES:
• Do not drop, step on or otherwise impact the
remote control. This may damage the parts or
lead to malfunction.
• The operating distance may vary according to the
brightness of the room.
• Do not point bright lights at the remote control
sensor.
• Do not place objects between the remote control
and the remote control sensor.
• Do not use this remote control while
simultaneously operating a remote control of
other devices.


15
Installation

16
Unpacking and Preparing the TV
Remove the TV carefully from its packaging, be careful not to apply any pressure to
the front of the LCD screen. Some accessory items may be located in cut-out sections
of the internal packaging, so make sure you check the entire packaging to not miss
any items. Once all items are removed from the packaging, use the list below to check
there are no items missing.
1 x 49" 4K Ultra HD Smart TV
2 x Base Stands
1 x Remote Control
1 x USB RF receiver dongle for the Remote Control
2 x “AAA” Batteries
4 x Screws (for assembling the base stands to the TV)
1 x Instruction Manual
1 x Quick Start Guide
1 x Warranty Card
Once all the accessory items have been accounted for, prepare your TV for installation
– you can either use it standing up on the supplied base stands on suitable furniture,
or mounted to a wall. You will find installation instructions for both options on the
following pages.
After having installed the base stands (or wall-mounted the TV), follow the instructions
in the “Controls and Connections” section to ensure that you TV is correctly
connected to your TV antenna and related AV equipment (e.g., Blu-ray player,
amplifier, sound bar, etc.).
Installation
IMPORTANT!
The TV panel may be awkward to install on your own. We recommend you ask
someone to help with installation and/or removal of the stands, or with wall-
mounting the TV.
IMPORTANT! It is highly recommended that you install Safety Straps to
prevent your TV from falling over. This is particularly important if young children
have access to the TV. Safety Straps can be purchased separately from most
electronic or hardware retailers. Please follow the instructions provided with
the Safety Straps for correct installation.

17
Step 1
Place a soft cushioned material on top
of a flat surface to prevent damaging the
screen panel. Then place the TV monitor
flat on top, with the screen side facing
down, as illustrated (1).
Step 2
Align the screw holes on the stands and
the bottom of the TV, as illustrated with
arrows (2).
Step 3
Tighten the screws (supplied) with a
screwdriver to affix the stands to the
panel.
CAUTION! Do not apply excessive force
as this may damage the screw holes.
Installation (Cont.)
Assembling the Base Stands
If you want to stand the TV on furniture, first find a suitable location where you can
attach the base stands to the body of the TV. You will need to arrange a soft cloth that
is large enough to cover the entire front panel of the TV (for protection of the screen),
as well as a screwdriver to attach the base stands.
Before using the TV, install the stands as described below. If you want to mount it to a
wall, see the next page for mounting advice (wall mount/bracket is not supplied).
IMPORTANT!
Make sure the TV is unplugged from the power supply before installing or removing
the base stands.

18
Installation (Cont.)
Wall-Mounting the TV
• The TV is equipped with holes on the back panel for use with wall-mounting
brackets (not included). Please use the illustration below as a reference when
buying wall-mounting brackets.
• Use four (4) standard M6*10mm screws (or longer, depending on the mounting
bracket) to mount this TV.
NOTE: The screws in the package are for securing the TV stands only. If you are wall-
mounting the TV, please consult a qualified installer for further instructions on bracket
support and wall support.
IMPORTANT!
• Make sure the TV is unplugged from the power supply before mounting it to a
wall or taking it off the wall mount.
• We recommend you contact a professional for assistance when wall-mounting
the TV. We assume no liability for any eventual damage to the product or injury
to yourself if you mount the TV on your own.
Back of the TV
200mm
200mm

19
Controls and Connections

20
Front and Side Button Controls
Controls and Connections
Front View
Side View
1
2
1. Display Screen
2. Remote control sensor/Power indicator: In standby mode the indicator
light is red; when switching on the unit the indicator light is blue.
3. SOURCE button : Select the input source.
4. MENU button: Enter the menu settings page.
5. CH +/- : Select the next/previous channel, or navigate up/down.
6. VOL +/- : Increase/decrease the volume level, or navigate left/right.
7. STANDY/ON button: Switch the TV to ON or Standby mode.
3
4
5
6
7
