Micro-Mini Compo

Service Manual

Model No.: MC-6320

Version: 1.0

MODEL:

MC-6320

Model No.: MC-6320

Version: 1.0

CONTENTS

SPECIFICATION..................................................................................................................................... 4

ALIGNMENT INSTRUCTION............................................................................................................... 5

ALIGNMENT CHART ............................................................................................................................ 6

CIRCUIT DIAGRAMS............................................................................................................................ 9

BOM LIST ............................................................................................................................................. 10

EXPLODED VIEW................................................................................................................................ 21

PART LIST............................................................................................................................................. 22

Model No.: MC-6320

Version: 1.0

SPECIFICATIONS

Frequency response 100Hz-10kHz

Signal-to-noise ratio 40dB

Output power 4.5W +4.5W

Power consumption 29W

Speaker: 4ohmsTerminal impedance

Headphone: 32Ohms

AC 117V/ 60Hz

AC 220V /50Hz

AC 230V /50Hz

AC 240V /50Hz

AC 110V/ 220V 60Hz /50Hz

AC 110/230V-240V 60Hz/50Hz

Power source

AC 127V /240V 60Hz /50Hz

Dimension 600(L) x 535(D) x 263.5(H)mm

Weight Approx 6.3Kg

Model No.: MC-6320

Version: 1.0

ALIGNMENT INSTRUCTION

TEST EQUIPMENT

1. AM signal generator with test loop.

2. FM signal generator.

3. AM/FM-IF signal generator with 455 KHz and 10.7 MHz marker.

4. Oscilloscope with a wide band amplifier of approximately 100 KHz.

5. V.T.V.M ( Vacuum-tube voltmeter ).

6. Power supply.

AM ALIGNMENT

1. Turn on AM signal generator, IF generator, VTVM, oscilloscope and power supply.

2. Using the test loop across the output of MW signal generator, the radio will receive the generator

signal by induction.

3. Connect the VTVM, oscilloscope and 4 ohm dummy load to the Speaker terminal.

4. Set the Band Switch to AM position in sequence.

5. Set the Volume Control to max. Position.

6. Set signal generator frequency as listed in AM Alignment Chart and maintain a sufficient output

level to provide an obvious indication.

7. Proceed as listed in Alignment Chart.

FM-IF ALIGNMENT

1. Set the Selector Switch to FM position.

2. Connect a capacitor 0.1Uf between the PIN1 of IC 1 and the "+VE" output of FM-IF signal

generator. The "-VE" pole of FM-IF signal generator connect to GND.

3. Connect a capacitor 0.1UF between the PIN17 of IC 1 and the "+VE" input of signal generator.

The "-VE" pole of FM-IF generator connect to GND.

FM-RF ALIGNMENT

1. Turn on FM signal generator, VTVM, oscilloscope and power supply.

2. Input the signal to FM ANT.

3. Connect the VTVM, oscilloscope and 4 ohm dummy load to the Speaker terminal.

4. Set the Volume Control to max. Position.

5. Set the Signal Frequency as listed in FM Alignment Chart and maintain a sufficient output level

to provide an obvious reading.

Model No.: MC-6320

Version: 1.0

ALIGNMENT CHART

Band Step

Signal

Generator

Frequency

Radio Dial

Setting Adjustment Remark

IF 1 455KHz T8

Adjust for best IF

wave

Form(at detector

output)

1 525KHz

Tuning Gang max.

capacity T5 Adjust for max.

Indication

2 1650KHz

Tuning Gang min.

capacity Trimmer of pvc Adjust for max.

Indication

3 " repeat steps 1 and 2 as required "

4 600KHz Tune to signal

(600KHz) AM ANT COIL Adjust for max.

Indication

5 1400KHz Tune to signal

(1400KHz) Trimmer of pvc Adjust for max.

Indication

6 " repeat steps 4 and 5 as required "

FM-I

F 1 10.7MHz T7 Adjust for best IF

wave Form & S curve

2 87.35MHz

Tuning Gang max.

capacity L3 Adjust for max.

Indication

3 108.3MHz

Tuning gang min.

capacity Trimmer of pvc Adjust for max.

Indication

4 " repeat steps 2 and 3 as required "

5 90MHz Tune to signal

(90MHz) L2 Adjust for max.

Indication

6 106MHz Tune to signal

(106MHz) Trimmer of pvc Adjust for max.

Indication

FM-

7 " repeat steps 5 and 6 as required "

Model No.: MC-6320

Version: 1.0

OPTIONAL BAND

Band Step

Signal

Generator

Frequency

Radio Dial

Setting Adjustment Remark

1 150KHz

Tuning Gang max.

capacity T6 Adjust for max.

Indication

2 270KHz

Tuning Gang min.

capacity CT3 Adjust for max.

Indication

3 " repeat steps 1 and 2 as required "

4 170KHz Tune to signal

(170KHz) LW ANT COIL Adjust for max.

Indication

5 250KHz Tune to signal

(250KHz) CT1 Adjust for max.

Indication

6 " repeat steps 4 and 5 as required "

1 3.1MHz

Tuning Gang max.

capacity T6 Adjust for max.

Indication

2 12.25MHz

Tuning gang min.

capacity CT3 Adjust for max.

Indication

3 " repeat steps 2 and 3 as required "

4 3.5MHz Tune to signal

(3.5MHz) T1 Adjust for max.

Indication

Model No.: MC-6320

Version: 1.0

CASSETTE SECTION

MOTOR SPEED

 Insert 3KHz TEST TAPE to deck compartment and adjust VR of motor to obtain the closing

frequency of 3KHz which is displayed on the frequency counter.

R/P HEAD AZIMUTH

 Set the function selection switch to TAPE position.

 Tune the volume control to max. output position.

 Insert 6.3KHz TEST TAPE into deck compartment. ( TECT MTT-113N )

 Adjust the playback head mounting screw to obtain the max. output of frequency 6.3KHz.

Reading at VTVM.

CD SECTION

 Connect the VTVM and oscilloscope to the speaker output of the unit.

 Put the test disk TCD-781 into the CD compartment.

 Set the function selection switch to CD position.

 Playback track 1 and set volume position to obtain 1V ( 0 dB ) output from the speaker terminal.

Playback track 6 and track 18 to read the output level which must within specification – 6dB.

Model No.: MC-6320

Version: 1.0

CIRCUIT DIAGRAM

Model No.: MC-6320

Version: 1.0

BOM LIST

NUMBER DESCRIPTION PC

101-71-3785-6802 PCB BOARD TS-3785RH-AI REV-0 1

110-53-9014-0320 TRANSISTOR 9014C 5MM 8

110-53-9015-0321 TRANSISTOR 9015C 5MM 2

115-03-0204-1480 DIODE 1N4148 P=26MM 7

192-01-3042-0022 RESISTOR 1/8W +/-5% P=26MM 2.2 OHM 2

192-01-3042-0100 RESISTOR 1/8W +/-5% P=26MM 10 OHM 4

192-01-3042-0220 RESISTOR 1/8W +/-5% P=26MM 22 OHM 1

203-01-0050-0000 JUMPER WIRE D=0.5MM 1

192-01-3042-0470 RESISTOR 1/8W +/-5% P=26MM 47 OHM 5

192-01-3042-1100 RESISTOR 1/8W +/-5% P=26MM 100 OHM 2

192-01-3042-1120 RESISTOR 1/8W +/-5% P=26MM 120 OHM 2

192-01-3042-1150 RESISTOR 1/8W +/-5% P=26MM 150 OHM 2

192-01-3042-1220 RESISTOR 1/8W +/-5% P=26MM 220 OHM 1

192-01-3042-1270 RESISTOR 1/8W +/-5% P=26MM 270 OHM 1

192-01-3042-1330 RESISTOR 1/8W +/-5% P=26MM 330 OHM 1

192-01-3042-2100 RESISTOR 1/8W +/-5% P=26MM 1K OHM 1

192-01-3042-2100 RESISTOR 1/8W +/-5% P=26MM 1K OHM 6

192-01-3042-2220 RESISTOR 1/8W +/-5% P=26MM 2.2K OHM 13

192-01-3042-2270 RESISTOR 1/8W +/-5% P=26MM 2.7K OHM 8

192-01-3042-2330 RESISTOR 1/8W +/-5% P=26MM 3.3K OHM 7

192-01-3042-2470 RESISTOR 1/8W +/-5% P=26MM 4.7K OHM 5

192-01-3042-2510 RESISTOR 1/8W +/-5% P=26MM 5.1K OHM 4

192-01-3042-2560 RESISTOR 1/8W +/-5% P=26MM 5.6K OHM 1

192-01-3042-2560 RESISTOR 1/8W +/-5% P=26MM 5.6K OHM 3

192-01-3042-2680 RESISTOR 1/8W +/-5% P=26MM 6.8K OHM 1

192-01-3042-2820 RESISTOR 1/8W +/-5% P=26MM 8.2K OHM 3

192-01-3042-3100 RESISTOR 1/8W +/-5% P=26MM 10K OHM 13

192-01-3042-3120 RESISTOR 1/8W +/-5% P=26MM 12K OHM 2

192-01-3042-3150 RESISTOR 1/8W +/-5% P=26MM 15K OHM 2

192-01-3042-3220 RESISTOR 1/8W +/-5% P=26MM 22K OHM 2

192-01-3042-3330 RESISTOR 1/8W +/-5% P=26MM 33K OHM 2

192-01-3042-3470 RESISTOR 1/8W +/-5% P=26MM 47K OHM 11

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

192-01-3042-3560 RESISTOR 1/8W +/-5% P=26MM 56K OHM 2

192-01-3042-3680 RESISTOR 1/8W +/-5% P=26MM 68K OHM 1

192-01-3042-4100 RESISTOR 1/8W +/-5% P=26MM 100K OHM 7

192-01-3042-4220 RESISTOR 1/8W +/-5% P=26MM 220K OHM 1

192-01-3042-4470 RESISTOR 1/8W +/-5% P=26MM 470K OHM 1

196-00-3035-0080 CER CAP +/-10% 5MM 8PF 1

196-00-3035-0050 CER CAP +/-10% 5MM 5PF 1

196-00-3035-0100 CER CAP +/-10% 5MM 10PF 1

196-00-3035-0150 CER CAP +/-10% 5MM 15PF 3

196-00-3035-0180 CER CAP +/-10% 5MM 18PF 1

196-00-3035-0200 CER CAP +/-10% 5MM 20PF 1

196-00-3035-0220 CER CAP +/-10% 5MM 22PF 1

196-00-3035-0250 CER CAP +/-10% 5MM 25PF 1

196-00-3035-0270 CER CAP +/-10% 5MM 27PF 1

196-00-3035-0470 CER CAP +/-10% 5MM 47PF 1

196-00-3035-0560 CER CAP +/-10% 5MM 56PF 1

196-00-3035-1100 CER CAP +/-10% 5MM 100PF 2

196-00-3035-1270 CER CAP +/-10% 5MM 270PF 1

196-00-3035-1330 CER CAP +/-10% 5MM 330PF 4

196-00-3035-1470 CER CAP +/-10% 5MM 470PF 4

196-00-3038-2100 CER CAP +80/-20% 5MM 0.001UF(102P) 2

196-00-3038-3100 CER CAP +80/-20% 5MM 0.01UF(103P) 7

196-00-3038-3200 CER CAP +80/-20% 5MM 0.02UF(203P) 3

196-00-3038-3470 CER CAP +80/-20% 5MM 0.047UF(473P) 3

196-00-3038-4100 CER CAP +80/-20% 5MM 0.1UF(104P) 11

196-00-3038-4100 CER CAP +80/-20% 5MM 0.1UF(104P) 8

197-00-3024-2100 MYLAR CAP +/-10% 5MM 0.001UF(102M) 2

197-00-3024-2150 MYLAR CAP +/-10% 5MM 0.0015UF(152M) 2

197-00-3024-2220 MYLAR CAP +/-10% 5MM 0.0022UF(222M) 2

197-00-3024-2270 MYLAR CAP +/-10% 5MM 0.0027UF(272M) 3

197-00-3024-2470 MYLAR CAP +/-10% 5MM 0.0047UF(472M) 3

197-00-3024-3100 MYLAR CAP +/-10% 5MM 0.01UF(103M) 1

197-00-3024-3150 MYLAR CAP +/-10% 5MM 0.015UF(153M) 3

197-00-3024-3330 MYLAR CAP +/-10% 5MM 0.033UF(333M) 2

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

197-00-3024-3470 MYLAR CAP +/-10% 5MM 0.047UF(473M) 1

200-03-1005-6470 ELECT CAP +/-20% 5MM 47UF/10V 9

200-03-1005-7100 ELECT CAP +/-20% 5MM 100UF/10V 9

200-03-1005-7100 ELECT CAP +/-20% 5MM 100UF/10V 5

200-03-1005-7220 ELECT CAP +/-20% 5MM 220UF/10V 3

200-03-1605-6330 ELECT CAP +/-20% 5MM 33UF/16V 1

200-03-1605-6470 ELECT CAP +/-20% 5MM 47UF/16V 5

200-03-1605-7100 ELECT CAP +/-20% 5MM 100UF/16V 2

200-03-2505-7100 ELECT CAP +/-20% 5MM 100UF/25V 1

200-03-2505-7220 ELECT CAP +/-20% 5MM 220UF/25V 1

200-03-5005-4220 ELECT CAP +/-20% 5MM 0.22UF/50V 4

200-03-5005-4470 ELECT CAP +/-20% 5MM 0.47UF/50V 1

200-03-5005-5100 ELECT CAP +/-20% 5MM 1UF/50V 9

200-03-5005-5100 ELECT CAP +/-20% 5MM 1UF/50V 6

200-03-5005-5470 ELECT CAP +/-20% 5MM 4.7UF/50V 1

200-03-5005-6100 ELECT CAP +/-20% 5MM 10UF/50V 3

200-03-5005-6220 ELECT CAP +/-20% 5MM 22UF/50V 2

203-01-0050-0000 JUMPER WIRE D=0.5MM 130

101-71-3785-3702 PCB BOARD TS-3785G-AI REV.3 1

110-53-9014-0320 TRANSISTOR 9014C 5MM 2

192-01-3042-1330 RESISTOR 1/8W +/-5% P=26MM 330 OHM 2

192-01-3042-2100 RESISTOR 1/8W +/-5% P=26MM 1K OHM 1

192-01-3042-3100 RESISTOR 1/8W +/-5% P=26MM 10K OHM 1

192-01-3042-3180 RESISTOR 1/8W +/-5% P=26MM 18K OHM 1

196-00-3038-3200 CER CAP +80/-20% 5MM 0.02UF(203P) 4

200-03-1005-7100 ELECT CAP +/-20% 5MM 100UF/10V 2

200-03-1605-6330 ELECT CAP +/-20% 5MM 33UF/16V 1

192-01-3042-2220 RESISTOR 1/8W +/-5% P=26MM 2.2K OHM 6

192-01-3042-2270 RESISTOR 1/8W +/-5% P=26MM 2.7K OHM 2

101-71-3785-3603 PCB BOARD TS-3785F-AI (C/D) REV.0 1

192-01-3042-1150 RESISTOR 1/8W +/-5% P=26MM 150 OHM 1

192-01-3042-1330 RESISTOR 1/8W +/-5% P=26MM 330 OHM 1

192-01-3042-1560 RESISTOR 1/8W +/-5% P=26MM 560 OHM 2

192-01-3042-2100 RESISTOR 1/8W +/-5% P=26MM 1K OHM 1

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

192-01-3042-2220 RESISTOR 1/8W +/-5% P=26MM 2.2K OHM 1

192-01-3042-2470 RESISTOR 1/8W +/-5% P=26MM 4.7K OHM 1

192-01-3042-3100 RESISTOR 1/8W +/-5% P=26MM 10K OHM 1

101-71-RC09-0002 PCB BOARD TS-RC09-AI REV.2 "REMOTE CONTROL BOARD" 1

110-53-9014-0320 TRANSISTOR 9014C 5MM 1

192-01-3042-0022 RESISTOR 1/8W +/-5% P=26MM 2.2 OHM 1

192-01-3042-2680 RESISTOR 1/8W +/-5% P=26MM 6.8K OHM 1

196-00-3035-1100 CER CAP +/-10% 5MM 100PF 2

200-03-1005-6470 ELECT CAP +/-20% 5MM 47UF/10V 1

103-06-7241-0000 ICs-AN7241 1

103-18-2092-0010 ICs-TA2092N 1

110-03-9015-0321 TRANSISTOR 9015C 1

110-04-8050-0320 TRANSISTOR KTC8050C 1

115-00-0204-1480 DIODE 1N4148 2

118-00-4005-0560 DIODE 5.6V 0.5W 1

145-24-1100-1000 CHOKE COIL 10UH(EC24-100K)+/-10% 2

132-02-3169-3430 CRYSTAL 16.9344MHZ/2PINS 1

131-02-4107-0030 CERAMIC FIL TERS 10.7MA3B+/-3KHz (FFE1070M1)/(LT10.7MA5) 1

131-01-2455-0070 CERAMIC FIL TERS 455KHz (3 PINS) BW=7KHz 1

139-00-7045-0250 COIL: 4583T L0.7X4.5X2.5T 1

139-00-7045-0350 COIL: 4584T L0.7X4.5X3.5T 1

139-00-7045-0450 COIL: 4585T L0.7X4.5X4.5T 1

143-10-0220-1770 IFT: MO-177 RED 1

143-10-0300-1760 IFT: MO-176 1

143-10-0001-1600 IFT: 1160R YELLOW 1

143-07-0117-7320 IFT: AN-FD (7732R) PINK / 7CF-N01 7MM 1

192-01-0042-4100 RESISTOR 1/8W +/-5% 100K OHM 1

197-00-0024-4100 MYLAR CAP +/-10% 0.1UF(104M) 2

197-00-0024-4220 MYLAR CAP +/-10% 0.22UF(224M) 2

200-00-1605-6470 ELECT CAP +/-20% 47UF/16V 1

200-00-1605-7100 ELECT CAP +/-20% 100UF/16V 2

200-00-1005-7470 ELECT CAP +/-20% 470UF/10V 2

200-00-2505-7470 ELECT CAP +/-20% 470UF/25V 1

204-02-6300-8000 CONDUCTOR AWG 26# 80MM BLACK 1

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

203-01-0050-0000 JUMPER WIRE D=0.5MM 2

209-06-2510-0200 2P EH-D WAFER CONNECTOR SOCKET 1

209-06-2510-0300 3P EH-D WAFER CONNECTOR SOCKET 2

209-06-2510-0500 5P EH-D WAFER CONNECTOR SOCKET 2

209-06-2510-0600 6P EH-D WAFER CONNECTOR SOCKET 1

209-07-2010-0600 6P PH-D WAFER CONNECTOR SOCKET 1

209-07-2010-1100 11P PH-D WAFER CONNECTOR SOCKET 1

209-07-2010-0400 4P PH-D WAFER CONNECTOR SOCKET 1

564-02-0020-0368 TS-368 CD MOTOR IC HEAT SINK 1

110-04-8820-1650 TRANSISTOR 2SD882P/D882 1

115-00-0204-1480 DIODE 1N4148 2

117-00-2015-3910 DIODE 1N5391 4

118-00-4005-0820 DIODE 8.2V 0.5W 2

192-01-0102-0056 RESISTOR 1W +/-5% 5.6 OHM 1

200-00-2505-8220 ELECT CAP +/-20% 2200UF/25V 1

203-01-0050-0000 JUMPER WIRE D=0.5MM 1

209-06-2510-0200 2P EH-D WAFER CONNECTOR SOCKET 1

197-00-0024-4100 MYLAR CAP +/-10% 0.1UF(104M) 2

203-01-0050-0000 JUMPER WIRE D=0.5MM 1

118-00-4005-0510 DIODE 5.1V 0.5W 1

196-00-0035-1100 CER CAP +/-10% 100PF 1

200-00-1605-6470 ELECT CAP +/-20% 47UF/16V 2

192-01-0042-1330 RESISTOR 1/8W +/-5% 330 OHM 1

192-01-0042-2820 RESISTOR 1/8W +/-5% .2K OHM 1

203-01-0050-0000 JUMPER WIRE D=0.5MM 1

TS-310 BAR HOLDER 1

103-08-2111-0020 ICs-TA2111F 1

103-18-9423-0030 ICs-TC94A23F-503 1

103-18-2153-0020 ICs-TA127A5 2153FN 1

103-07-8223-0010 ICs TA8223K（5WATT）1

136-20-3088-0000 3B P.V.C /88-108MHZ 1

140-07-0416-0800 IFT: 80: 16T (D=10MM) 1

142-10-1300-0020 IFT: SA-02 NATURE 1

137-01-0102-2010 TRIMMER 20PF 1

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

147-00-0010-0800 FERRITE BAR: 10X80MM 1

148-59-6401-2301 SWITCH：SK-64D01 (6P4T)M13 /SK-64D01-M13-S 1

148-59-6401-2900 SWITCH：SK-64D01-M9 / SK-64D01-M9-S 1

186-02-0100-0000 RCA SOCKET（WHITE）1

186-02-0100-0001 RCA SOCKET/AV-8.4-1 (RED) 1

186-01-0430-4010 SOCKET：MSP-304V-01 1

187-01-5435-1120 STEREO EARPHONE JACK：EJ-3511-202G (ST-202-SWD-G) 1

209-21-1010-1600 SOCKET 2X8 (FFC-16) (CONNECTOR SOCKET) 1

550-04-2226-0400 SCREWS MFS (KM) 2.6X4 2

550-24-5130-1000 SCREWS TPS (PA) 3X10 1

550-04-5430-0600 SCREWS STP (TAP TITE) 3X6 1

721-01-2020-0150 PVC CUSHION 20X20X1.5MM 1

564-01-0040-8718 TS-8718 IC HEAT SINK (HEAT SINK) ADD ONE HOLE 1

207-63-0306-1240 6P EH HOUSNG CONNECTOR 240MM 1

564-01-0020-0182 TS-182X HEAT SINK 1

574-02-0200-0010 FUSE HOLDER MFS-015 2

550-04-5430-0600 SCREWS STP (TAP TITE) 3X6 1

110-04-7720-1651 TRANSISTOR 2SB772P/2SB772Q/B772 1

186-02-0100-8432 SOCKET: AV-8.4-3 BLACK）1

115-00-0204-1480 DIODE 1N4148 1

131-01-2455-0020 CERARNIC FILTER Y.S 455E REPLACE :455KHZ (2 PIN)E/ZTB455E/CRB455E 1

119-01-0111-2200 IR AMITTER EL-1L2 / KY-IR100 / IR333C H0-A / IED350 1

152-01-6060-0451 KFC TACT SWITCH：JTP-1230A (4.5MM)/(KFC-A06-01-H4.5)/TS-1145-250 6

119-08-0112-0430 IR RECEIER PIC-12043T/RIM-A38/KSM-603LM/PIC-2092LM/IRM499H-S 1

122-01-0322-2700 LED D=3MM RED 1

710-04-0000-0000 OIL-CLOTH TUBE 15

126-01-2203-0241 LCD DISPLAY CD LED E3-2030APR3 PIN=24MM 10P 1

207-63-0303-1120 3P EH HOUSING CONNECTOR 120MM 1

207-72-0304-1220 4P PH HOUSING CONNECTOR 220MM 1

207-72-0311-1180 11P PH HOUSING CONNECTOR 180MM 1

150-16-2281-0010 LED：TS-7 2P2T JPS-2281 8.5*8.5 1

159-30-4202-0200 ROTARY VOL. 20KB16.4MM R1615G12A1B20/R1611GOX-V1B203FE00-00 1

207-63-0305-1220 5P EH HOUSING CONNECTOR 220MM 1

TS-3831 POINTER BRACKET (WITHOUT VFD) 1

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

TS-378 TUNING BRACKET 1

TS-378 TUNING SHAFT 1

FIBRE 5

122-01-0322-2700 LED D=3MM RED 1

150-54-0062-0100 LEAF SWITCH：LSA-62 1

151-01-0013-3020 SWITCH：PB1K00A2L 18T 1

205-11-2802-2000 SINGLE SHIELD WIRE S.S.W 2PX220MM 1

207-63-0602-1340 EH 26#HOUSIGN CONNECTOR WIRE P2.5-2PX340 1

217-01-1032-0800 CONDENEER MIC：EM-80 1

721-04-0915-0800 MIC COUSION 15X9X8MM 1

206-22-5020-1000 RAIWBOW CNECTOR WIRE RAINBOW 30# 2PX100MM 1

207-63-0602-1280 EH 26#HOUSING CONNECTOR WIRE P2.5-2PX280MM 1

556-10-0090-0768 TS-768 D0.5X8T DIAL SPRING 1

575-01-3060-0800 M6X0.8MM 1

578-12-4420-4000 EYELET 2X4MM 1

714-12-0300-0000 DIAL CORD D=0.3MM 620

TS-203 CD DUST COVER 1

TS-3831 CD DOOR P03 1

TS-182 VCD HOLDER 1

TS-203 DISK COVER 1

TS-899 LOCK RING 1

TS-8718 DAMPER GEAR 1

TS-8718 DAMPER GEAR HOLDER 1

206-32-0160-2000 CD FLAT CABLEUL20624/2896 E118147 16PX200MM 1

170-01-2130-0000 CD DECK MECHANISM (SONY) KSM-213CDM / 02S 1

207-72-2706-1220 PH/PH 28#HOUSING CONNECTOR WIREP2.0-6PX220MM-P2.0 1

550-04-5220-0400 SCREW MPS (PM) 2X4 1

550-24-5120-0800 SCREW TPS (PA) 2X8 1

550-23-5326-1600 CD DECK MECHANISM SCREW PWB 2.6X16 4

550-34-5130-1000 SCREW TWS (WA) 3X10 H=8MM 2

556-10-0060-1162 TS-1162 (M06) CD DOOR SPRING (CD DOOR SPRING) D1.4X3T 1

562-00-1010-0600 TS-600 FIXED PLATE 6

567-00-0000-1128 TS-1128 CD DOOR LOCK / DL-1902 1

567-02-0010-0899 TS-899 (M27) DISK STEEL COVER PLATE 1

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

567-03-0000-2388 CD MAGNET "SONY" 30X16X5MM 1

712-00-2130-0121 CD CUSHION D13X12 (RED) 30 / CTL002-01430-05S 2

712-00-6130-0121 CD CUSHION D13X12 (GREEN) 40 / CTL002-01440-09S 2

816-01-2388-0000 TEAMSING WARRANTY STICKER 1

TS-RC09 REMOTE CONTROL FRONT CABINET P01 1

TS-RC09 REMOTE CONTROL BACK CABINET P02 1

TS-RC09 REMOTE CONTROL BATTERIES DOOR P03 1

TS-RC09 REMOTE UPPER KEY P04 1

TS-RC09 REMOTE LOWER KEY P05 1

TS-RC09 REMOTE CONTROL LENS P06 1

213-12-0090-RC09 RULTER KEY-PAD TS-RC09（9KEY) 1

555-07-1000-RC09 TS-RC-09 BATTERY CONTACT"+" 1

555-07-2000-RC09 TS-RC-09 BATTERY CONTACT"-" 1

555-07-3000-RC09 TS-RC-09 BATTERY CONTACT"+/-" 1

550-24-2120-0800 SCREW TFS (KA) 2X8 1

550-24-2126-0800 SCREW TFS (KA) 2.6X8 1

718-30-2100-0000 RIBBON W=10MM 120

837-51-0072-0720 BUBBLE BAG 7-1/4X(7-1/4X2)+1-1/4 1

150-54-0062-0100 LEAF SWITCH：LSA-62 1

167-13-1055-0000 MACHANISM TN21SC-102M 12V/TN21SC-102M 1

174-04-1102-3020 FUSE 2A/250V(VDE) 1

181-00-5731-1910 EI-57A-17E(K5712BF)115℃VDE APP 120/230V WITHOUT AC CORD 1

185-15-0201-0090 CE STANDARD AC SOCKET (AC-009) 1

204-02-6301-6020 JUMPER WIRE AWG 26# 160MM RED 1

207-63-0203-1220 3P EH DOUBLE SHIELD WIRE D.S.W 220MM 1

207-63-0605-1200 EH 26#DOUBLE SHIELD WIRE P2.5-5PX200MM 1

550-04-5420-0300 SCREW STP (TAP TITE) 2X3 1

550-04-5420-0500 SCREW STP (TAP TITE) 2X5 1

559-30-0010-1162 TS-1162 RECORDER PLATE 1

712-11-0030-0500 EXTRUDED TUBE D3X50MM 1

154-00-2120-1000 SWITCH 1P2T SS12J01M (1P2T) /SS-12J01-G0-N 110/220V 1

204-02-2301-0020 JUMPER WIRE AWG 22# 100MM RED 1

TS-7322 BATTERIE DOOR 1

TS-3831 BACK CABINET P22 1

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

TS-182X HEADPHONER MANTING BRACKET 1

TS-3831 VOLUME KNOB P13 1

TS-3831 BASS KNOBP15 1

TS-899 DAMPER GEAR HOLDER 1

TS-410 DAMPER GEAR 1

TS-3831 POWER KNOB P12 1

TS-3831 FRONT CABINET P01 1

TS-3831 TUNING KNOB P14 1

TS-3831 FUNCTION KNOB JP09 1

TS-3831 CASS. DOOR P02 1

TS-3831 CASS. DOOR LENS P07 1

TS-3831 CONTROL LENS P05 1

TS-MH01CASS. DOOR 1

TS-3831 CASS. DOOR LENS P08 1

TS-3831 CD DOOR LENS P06 1

TS-3831 TUNING LENS P04 1

TS-8718 DIAL DRUM 1

TS-8718 EQ BRACKET 2

TS-3831 FUNCTION SWITCH LEFT P10 1

TS-3831 FUNCTION SWITCH RIGHT P11 1

TS-368 DIAL DRUND32MM 1

204-02-6311-5000 JUMPER WIRE AWG 26# 1500MM BLACK 1

207-63-0604-0800 EH 26#SOCKET WIREP2.5-4PX80MM 1

184-32-0330-7200 1.83M VDE CORDSF-103+SF-106 REPLACE 6 FT VDE APPROVAL 1

TS-3831 BACK PLATE 46X26MM 1

498-03-0000-0020 TS-206 VCD VOLTAGE PLATE 73X17.8X0.3MM 1

498-03-8718-0020 TS-8718 VOLTAGE PLATE 16X22X0.3MM 1

498-03-0203-0010 TS-203 (M11) DC JACK PLATE (A) 29.8X15.3X0.3 1

550-04-0226-0400 SCREW MBS (BM) 2.6X4 1

550-24-5126-1000 SCREW TPS (PA) 2.6X10 2

550-05-2230-0800 SCREW MFS (KM) 3X8 BLACK 6

550-24-5130-0800 SCREW TPS (PA) 3X8 5

550-24-5130-1000 SCREW TPS (PA) 3X10 8

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

550-24-5130-1200 SCREW TPS (PA) 3X12 4

550-24-5130-3500 SCREW TPS (PA) 3X35 4

550-25-2130-1000 SCREW TFS (KA) 3X10 BLACK 2

550-34-5126-0600 SCREW TWS (WA) 2.6X6 H=8MM 1

550-34-5130-1003 SCREW TWS (WA) 3X10 H=10MM 1

550-34-5130-2200 SCREW TWS (WA) 3X22 H=8MM 2

550-04-3226-0500 SCREW M2.6X5 HEAD=7.0 12

556-20-0010-8718 TS-8718 CASSETTE DOOR SPRING D0.8mm 1

562-00-0320-0568 TS-568 CSAAETTE KEY CLIP 1

576-01-7302-1800 BANDER 3X18 1

715-01-0000-1000 CABLE TIE 100MM 2

836-01-0120-0240 POLYBAG 2-1/2"X12" 1

TS-3831 GIFT BOX 1

TS-3831 INSTRUCTION MANUAL FOR ENGLISH 1

835-21-0378-0000 CARTON TS-378 1

833-02-0403-0000 TS-403 CD HEAD COVER 1

812-01-0000-0000 SERAL NO. STICKET 4

805-00-0000-0000 P.M.P.O. LABEL 1

823-03-2501-2000 FUSE LABEL 2A/250V 1

826-01-0000-0110 WARNING LABEL 1

826-01-0000-0010 CLASS LABEL 1

827-06-0000-0120 FUSE LABEL 1

836-01-0030-0200 POLYBAG 2X3 (P.E.) 2

836-02-0190-1800 POLYBAG 18"X19" 3

838-01-3831-0000 POLYFOAM TS-3831/188X 1

TS-3831 SPEAKER FRONT CABINET P18 2

TS-MH02 SPEAKER BACK CABINET 2

TS-3831 SPEAKER COVER P19 2

TS-3831 SPEAKER CLOTH GRILL BRACKET P21 2

TS-3831 SPEAKER BOX BADGE P20 2

177-45-8116-1400 4OHM 4" 8W 2

177-45-3124-0201 4OHM 2" 10W 2

200-00-5005-5470 ELECT CAP +/-20% 4.7UF/50V 2

451-03-8718-0010 4ΩSPEAKER PLATE TS-10/8718 20X30 2

Model No.: MC-6320

Version: 1.0

NUMBER DESCRIPTION PC

204-02-6301-4020 JUMPER WIRE AWG 26# 140MM RED 2

204-02-6301-4000 JUMPER WIRE AWG 26# 140MM BLACK 2

SPEAKER GRILL CLOTH JY-29A-2 2

206-20-1021-1501 SPEAKER WIRE 1.5M (22# 1500MM) 2

550-34-5130-0800 SCREW TWS (WA) 3X8 H=8MM 4

550-34-5130-1000 SCREW TWS (WA) 3X10 H=8MM 8

550-24-5130-2500 SCREW TPS (PA) 3X25 12

Table of contents

Other akira Stereo System manuals

akira

akira MC-6320V User manual

akira

akira MC-4200DVD User manual

Popular Stereo System manuals by other brands

Sony

Sony MHC-GZR999DA operating instructions

Philips

Philips FWM997X/78 Service manual

Aiwa

Aiwa JAX-N5 operating instructions

Sony

Sony DHC-AZ7DM operating instructions

Panasonic

Panasonic SC-NC6 operating instructions

Sven

Sven SPS-678 Operation manual

Aurender

Aurender N20 installation guide

SEM

SEM Evolution Z-7787 quick start guide

Sonoro

Sonoro SO-310 operating manual

Sony

Sony MHC-EC68PI Specifications

Philips

Philips FW-C38/21M Specifications

JVC

JVC UXG28 - UX G28 Micro System instructions

Loewe

Loewe ARS Audio AC3 operating instructions

Sony

Sony SRS-XB31 reference guide

Panasonic

Panasonic SC-AK17 operating instructions

Sony

Sony MHC-GRX50 operating instructions

Eton

Eton Rukus XL user manual

JVC

JVC CA-UXP30 PŘiruČka k obsluze

akira MC-6320 User manual

Popular Stereo System manuals by other brands
