Alba 22/207F Manual

22” / 24” LED TV
Installation & Operating Instructions - Please keep for future reference
Important - Please read these instructions fully before installing or operating
These instructions contain important information which will help you get the best from your
television and ensure safe and correct installation and operation.
For any help concerning set up and use of your TV please call the Customer Helpline:
0330 024 0805 (calls are charged at the standard rate of your network provider).
Lines open: 8.30am - 6pm Monday to Friday and 9am - 5pm Saturday
22/207F
22/207FDVD
24/207
24/207DVDB
24/207DVDW
24/207DVDP
24/207DVDS
434/8160D
429/6511D
359/5048D
346/6108D
356/8934D
339/2540D
338/4888D
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd 1User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd 1 22/05/2015 16:53:3422/05/2015 16:53:34

2For any help concerning set up and use of your TV please call the Customer Helpline on page 3
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:2User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:2 22/05/2015 16:53:3822/05/2015 16:53:38

3
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Important Guarantee Information
Example labels for 22” and 24” models
Serial No.
Model Ref
Serial No.
Model Ref
Congratulations on purchasing this television. We hope you have many years of trouble free
enjoyment from your purchase.
Your product is covered under the manufacturers guarantee for 12 months from the date
of purchase.
If you experience any difficulties with your TV, please refer to the ‘Frequently asked questions’ section
in this user guide.
If you are still unable to remedy the issue, try resetting the TV to factory settings. (Details in the
‘Settings menu’ section of this user guide). Alternatively you can contact the helpline on the
number below.
In the event that a fault is diagnosed, the helpline will arrange to collect the TV from your home
or work address, return it to our service centre, repair the item and then return it to you.
If we believe we cannot offer a permanent repair, we will replace the item.
Helpline Information
Telephone UK 0330 024 0805, ROI 01443 3940
Web support: www.umc-uk.co.uk
The telephone opening hours are Monday to Friday 8.30am to 6pm, Saturday 9am – 5pm.
calls are charged at the standard rate of your network provider.
You must retain all packaging materials, in addition to your proof of purchase/receipt, as you will need
these in the event of warranty/service support.
This guarantee is in addition to and does not affect your statutory rights.
If you need to call the helpline, you will need the following information.
1) Model Ref
_____________________________________ (You can find this on the rear of the TV)
2) Date of purchase
______________________________________ (You can find this on your sales receipt)
3) Serial Number
_____________________________________ (You can find this on the rear of the TV)
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:3User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:3 22/05/2015 16:53:3822/05/2015 16:53:38

4For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Important Safety Instructions
IMPORTANT - Please read these instructions. All the safety and operating instructions
should be read before the appliance is operated.
Safety
Packaging
• Television sets which weigh 20kg or more must
be lifted and carried by at least 2 people.
• This television does not contain any parts that
are serviceable by the user. In case of a fault,
contact the manufacturer or authorised service
department. Exposing the internal parts inside the
TV may endanger your life. The manufacturers
guarantee does not extend to faults caused by
repairs carried out by unauthorised third parties.
• To reduce the risk of fire, electric shock or
damage to the TV, do not expose it to dust, rain
or moisture. Never expose the TV to dripping
or splashing and do not place objects filled with
liquids on or near the TV.
• Do not connect any external devices (DVD
player, games console etc) when the TV is
switched on. Disconnect both the TV and device
from the mains before connecting. Only switch
appliances on when the connection process
is complete.
• Do not place the television in a confined space
and do not obstruct the ventilation openings at
the rear of the television.
• When installing on a wall, ensure the TV is at
least 5cm from the wall for ventilation.
• Always ensure that the TV’s ventilation openings
are not covered with items such as newspapers,
table-cloths, curtains, etc.
• Dispose of this television and any components
including batteries in an environmentally friendly
manner. If in doubt, please contact your local
authority for details of recycling.
• For your safety, this appliance is fitted with a
fused 3 pin mains plug. Should the fuse need to
be replaced, ensure that any replacement is of
the same amperage and approved with the
BSI mark.
• Never try and replace the mains plug unless
you have adequate qualifications and are
legally authorised to do so. In the event that a
replacement mains cable is required, contact the
manufacturer for a suitable replacement.
• Never use the television if it is damaged in
any way.
• Always place the television on a flat level surface
avoiding anywhere which may be subject to
strong vibration.
• The ideal distance to watch the television
is approximately five times the length of the
diagonal measurements of the TV screen. Ensure
the television is not placed on top of the power
cable as the weight of the television may damage
the cable and cause a safety hazard.
• Never place mobile phones, speakers or any
other device which may cause magnetic or radio
interference, near the television. If interference
is apparent, move the device causing the
interference away from the television.
• To Isolate the TV from the mains power, please
use the power switch located on the side,
underside or rear of the TV set.
• Ensure that the power switch on the unit and the
mains plug are always easily accessible.
WARNING: Excessive noise when using earphones
and headphones can cause loss of hearing.
• To clean your TV, wipe with a soft, dry cloth. If
the surfaces are extremely dirty, use a soft cloth
dipped in a soap and water solution or a weak
detergent solution.
• Never use alcohol, paint thinner or benzene to
clean this unit.
• Before using a chemically treated cloth, read the
instructions that came with the cloth carefully.
CAUTION: If water or other liquid enters the
television through the display panel surface,
a malfunction may occur.
• The safest way to transport your item is in
the original box/packaging - please save your
packaging for this.
• You will need the original box/packaging in the
event of warranty/service repair or support. We
are unable to carry out warranty/service if you are
unable to package the item correctly.
Warnings
To prevent the spread of fire, keep
candles or other open flames away
from this product at all times
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:4User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:4 22/05/2015 16:53:3822/05/2015 16:53:38

5
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Cd
How do I dispose of this product?
Important Safety Instructions
IMPORTANT - Please read these instructions. All the safety and operating instructions
should be read before the appliance is operated.
Important information regarding use of video
games, computers, captions or other fixed
image displays
The extended use of fixed image program material
can cause a permanent “shadow image” on the LCD/
LED panel, also known as “screen burn”.
This “shadow image” can appear in the background
during normal viewing. This type of irreversible LCD/
LED panel deterioration can be limited by observing
the following steps:
1. Reduce the brightness/contrast setting to a
minimum suitable viewing level.
2. Do not display the fixed image for extended
periods of time.
3. Turn the power off when not in use.
Examples of images that are more likely to
cause “screen burn” are as follows (this is not an
exhaustive list):
• TV channel logos: e.g. shopping channel logos
and pricing displays - especially if they are bright
and stationary. Moving or low-contrast graphics
are less likely to cause ageing of the screen.
• Time displays.
• Teletext: Do not view a stationary page for a long
period of time
• TV/DVD menus: e.g. listings of DVD disc content.
• Pause mode: Do not leave the TV in pause mode
for long periods of time, e.g. when watching
DVDs or videos.
Important - Once ‘shadow image/screen burn’
occurs, it will never disappear and is not
repairable under warranty.
UK: Waste electrical products should not
be disposed of with household waste. Please dispose
of the product at a designated collection point for
recycling of WEEE. For your nearest facilities, please
see www.recycle-more.co.uk or in store
for details.
ROI: Waste electrical products should
not be disposed of with household waste.
Separate disposal facilities exist.
Check with your local authority or retailer for
recycling advice.
Batteries
• Do not expose batteries to high temperatures,
excessive heat, prolonged sunshine
or fire as this may cause leakage,
explosion or ignition.
Observe the correct polarity when
inserting batteries.
• Do not use different types of batteries
together or mix old and new batteries.
• Dispose of batteries in an environmentally
friendly way.
• Certain regions may regulate the disposal of
batteries. Please consult your local authority.
CAUTION:
This unit is a class 1 laser product. This unit uses a visible laser beam which could cause hazardous radiation
exposure if directed. Be sure to operate the player correctly as instructed.
When this unit is plugged into the wall outlet, do not place your eyes close to the openings to look into the inside of
this unit.
Use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
Do not open covers and do not repair yourself. refer servicing to qualified personnel.
CLASS 1
LASER PRODUCT
TV Models with built in DVD players
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:5User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:5 22/05/2015 16:53:3822/05/2015 16:53:38

6For any help concerning set up and use of your TV please call the Customer Helpline on page 3
• HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.
• The “HD TV” Logo is a trademark of
DIGITALEUROPE.
• The “HD TV 1080p” Logo is a trademark of
DIGITALEUROPE.
• The DVB logo is the registered trademark of the
Digital Video Broadcasting - DVB – project.
• Manufactured under license from Dolby
Laboratories.
• Dolby and the double-D symbol are trademarks
of Dolby Laboratories.
• Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,487,535 & other
U.S. and worldwide patents issued & pending.
DTS, the Symbol, & DTS and the Symbol
together are registered trademarks & DTS
2.0+Digital Out is a trademark of DTS, Inc.
Product includes software. © DTS, Inc. All
Rights Reserved.
Trademarks
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:6User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:6 22/05/2015 16:53:3822/05/2015 16:53:38

7
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Contents
Manufacturers Guarantee Information 3
Important Safety Instructions 4-5
Trademarks 6
What is included in the box 8
Attaching the stand 9
Detaching the stand and securing the TV
to a wall 10
Wall mounting 11
Getting Started - Initial Set Up 12
TV Buttons and Input Source Menu 13
Remote Control 14
Connections 15-17
TV Menu Operation 18-25
Channel Menu 18
Picture Menu 19-20
Sound Menu 21
Time Menu 22
System/Hotel Lock Menu 23
Setup Menu 24
DVD Setup 25
7 Day TV Guide 26
USB Record Digital / Freeview 27
USB Mode / Media Player 28
General Information 29-33
Using your TV with a Sky digital set top box 29
Frequently Asked Questions 30-31
Technical Specifications 32-33
For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the
Symbol, & DTS and the Symbol together are registered trademarks, and DTS TruSurround is a trademark of DTS,
Inc. © DTS, Inc. All Rights Reserved.
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:7User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:7 22/05/2015 16:53:3822/05/2015 16:53:38

8For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Please save your box/packaging as you will need this in the event of warranty/service repair or support. We are
unable to carry out warranty/service if you are unable to package it correctly. The safest way to package your
item in the event of warranty/service repair is in it’s original box/packaging.
1 x User Guide
1 x Quick Start Guide 2 x AAA Batteries
1 x RF Cable
1 x Remote Control
User Guide
QSG
What Is Included In The Box
1 x TV 1 x Stand Installation Pack
4 x ST(4x12)
3 x M(4x12)
Included with this TV are the following accessories:
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:8User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:8 22/05/2015 16:53:3822/05/2015 16:53:38

9
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
To complete the stand installation you will require a cross head screw driver.
The Stand Installation pack comes with 2 sets
of screws.
fig 1) Attach the stand neck to the rear of the TV set.
fig 2) Secure the neck to the TV using the
3 x M (4x12) screws provided.
fig 3) Attach the stand base to the neck.
fig 4) Secure the base to the neck using the
4 x ST (4x12) screws provided.
Attaching The Stand
HELPFUL ADVICE FOR FIRST TIME STAND INSTALLATION
When securing the self-tapping screw/s into the base of the TV (on first installation) the screw/s may be
naturally tight as they create a thread in the plastic.
a) Ensure the cross head screw driver tip fits correctly into the head of the screw and that it is not too big
or small.
b) Screw in all screws individually and partially before tightening all of the screws fully.
c) If the screws become very tight try loosening and re-tightening, this will continue the process of creating
the thread.
4x ST(4x12)
3 x
M (4x12)
1 1/2
4 x ST (4x12)
1
2
3
4
3x M(4x12)
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:9User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:9 22/05/2015 16:53:4022/05/2015 16:53:40

10 For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Detaching The Stand And Securing The TV
To A Wall
Detaching the Stand
Securing the TV to a Wall
3 x
M (4x12)
For maximum security in the home, when using a TV with its stand, anti-tip straps should be fitted. These are
available from supermarket websites and other websites and are an easy, inexpensive and effective way of
ensuring your TV stays safely upright. Straps are designed to be attached to the rear of the TV and then tethered to
the wall or the furniture the TV is stood on, these are fitted as follows.
The Royal Society for the Prevention of Accidents is urging people to take care with flat-screen televisions.
RoSPA stated in 2010 that “Toddlers are particularly at risk of pulling flat-screen televisions on to themselves. They
are unsteady on their feet and are attracted by colourful television images.”
The risk is increased as televisions become lighter.
A) Using one or both of the top wall-mounting holes
and screws fasten one end of the fastening cord/s to
the TV. (the screws are already supplied in the wall
mounting holes)
B) Secure the other end of the fastening cord/s
to your wall. (you will need screws/fixings suitable
for your wall type - available separately from most
DIY stores).
Note - Please ensure that children do not climb on the
TV set.
To detach the stand please remove the 3screws
highlighted then remove the stand neck and base
from the rear of the TV set.
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:10User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:10 22/05/2015 16:53:4022/05/2015 16:53:40

11
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
IMPORTANT - Before drilling any holes in the wall ensure you are not drilling where there could be any electric wires, water or
gas pipes.
1) Remove the four screws located at the back of the TV set.
2) The wall mount can now be easily attached to the mounting holes, located on the back of the TV, using the same
four screws removed.
For optimum viewing, if wall mounting the TV higher
than eye level, the TV should be tilted downwards so
that the TV’s screen is ‘face on’.
See fig 1 and 2 below.
For VESA wall mounting information please refer to
the Technical Specification page.
IMPORTANT – If wall mounting this TV, only use the
screws already provided in the wall mounting holes.
Using other screws which are longer could cause
irreparable damage to internal parts.
TV
fig 1
fig 2
Viewing angle
Viewing angle
INCORRECT
CORRECT
TV
Wall Mounting
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:11User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:11 22/05/2015 16:53:4122/05/2015 16:53:41

12 For any help concerning set up and use of your TV please call the Customer Helpline on page 3
2
Power on/off
Getting Started - Intial Set Up
3
1
Fig A
Fig B
4
5
1) Using the RF cable supplied, connect the TV to the
TV Aerial wall socket (Fig A).
Connect the power cable to the Electrical outlet
(Fig B).
2) Switch on the television using the power on/off
switch located on the side, underside or rear of the
TV set.
3) Insert the batteries supplied into the Remote
control and press the standby button to power on
the TV.
4) You will now be welcomed with the initial set-up
screen. If it does not appear, on the remote control,
please press [MENU] then 8-8-8-8 and the menu will
appear. Press OK on the remote control and tuning
will start.*
5) After tuning the following screen will appear.*
If you are missing channels, the reason for this is
likely to be signal strength, you should consider
connecting a signal booster and re-tuning the TV.
Important
As part of our ongoing development to reduce power
consumption, we have added an extra function to
this Television called ‘Home Mode’ (you will see
this during the first time installation set up). Power
consumption using the Home Mode function is
approximately 25% lower than some other modes.
The picture brightness is reduced using the Home
Mode function. If this function is not suitable for your
viewing environment, you can select other modes as
necessary. (Please note, ‘Store mode’ is for optimum
default picture settings, however, power consumption
is approximately 25% higher than ‘Home Mode’).
Please refer to the user guide section ‘Picture
settings’ in order to change the mode to one that
maybe more suitable for your environment. There
is also a shortcut button on the remote control
called ‘P-Mode’ should you wish to change to
another mode. *Screen shots/images are shown for illustration purposes
only and may change dependent on model/region.
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:12User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:12 22/05/2015 16:53:4122/05/2015 16:53:41

1
2
3
4
5
6
7
13
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
To switch between the different input/connections.
A) Using the buttons on the remote control:
1) Press [SOURCE] - The source menu will appear.
2) Press [\/] or [/\] to select the input you require.
3) Press [OK].
B) Using the buttons on the Television:
1) Press [SOURCE].
2) Scroll up / down using CH+/ CH- buttons to the
input/source you require.
3) Press Vol+ to change input/source to the one
selected.
For further information on input/connections
please view ‘Connections’ pages.
1. Volume up and menu right
2. Volume down and menu left
3. Programme/Channel up and menu up
4. Programme/Channel down and menu down
5. Displays Menu/OSD
6. Displays the input source menu
7. Standby Power On/Off
1. Stop/Eject DVD
2. Play/Pause DVD
3. Volume up and menu right
4. Volume down and menu left
5. Programme/Channel up and menu up
6. Programme/Channel down and menu down
7. Displays Menu/OSD
8. Displays the input source menu
9. Standby Power On/Off
1
2
3
4
5
6
8
7
9
TV Buttons & Source Menu
Choosing Mode Input/Source
For TV models with
built in DVD player
Component / YPbPr
An example of the ‘Input Source’ menu
(will vary by model)
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:13User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:13 22/05/2015 16:53:4122/05/2015 16:53:41

Remote Control
Viewing remote control - TV
1
35
4
7
8
10
11 12
13
15
17
18
20 22
24 26
28
29
21 23
25 27
30
31
32
33
19
16
14
9
6
2
1. STANDBY
2. MUTE
3. DTV
4. RADIO
5. DVD
6. USB
7. NUMBER BUTTONS
8. TV GUIDE
9. - To return to the previous channel viewed
10. P.MODE - Scrolls through picture mode options
11. VOL
12. CH
13. S.MODE - Scrolls through sound mode options
14. FAV - To display favourites menu
15. MENU
16. EXIT
17. - Allows you to navigate the
on-screen menus and adjust the system settings
to your preference
18. SOURCE/AV
19. INFO - Press once for now/next channel
information. Press twice for programme
information about current programme
20. ASPECT
21. SLEEP
22. SUBTITLE
23. AUDIO
24. TEXT
25. TEXT HOLD
26. DISPLAY
27. TEXTZOOM/DVD ZOOM
28. DVD Menu/Record
- To restart the current chapter
- To advance forward to the next chapter
- To stop/eject Disc
(hold for 4 seconds to eject disc)
- To play in fast rewind mode
- To play in fast forward mode
- To play/pause
29. REC LIST
30. GOTO
31. A-B
32. REPEAT
33. ANGLE/ 3D - Change to 3D mode
For Models with Integrated DVD players
For Models with PVR Function
For Models with USB Playback
For Models with 3D Feature
14 For any help concerning set up and use of your TV please call the Customer Helpline on page 3
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:14User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:14 22/05/2015 16:53:4722/05/2015 16:53:47

Connections
SCART SCART input
HDMI 1 HDMI input
Video Video input
R/L Audio in Component Audio input
COMPONENT (HD) Component input (YPbPr)
RF IN RF / TV Aerial input
USB USB input
HDMI 2 HDMI input
CI CARD IN Common Interface module
EARPHONE Earphone socket
1
2
3
4
5
6
7
8
9
10
US B CI CARD IN EARPHONE
VIDEO R LYPb Pr
15
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
12345
78 9 10
6
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:15User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:15 22/05/2015 16:53:4722/05/2015 16:53:47

16 For any help concerning set up and use of your TV please call the Customer Helpline on page 3
L (white)
R (red)
Video
(yellow)
L (white)
R (red)
Video
(yellow)
HDMI HDMI
Connections
Source should be set to Composite/AV
A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio
with minimal loss of quality.
TVs Source should be set to the corresponding HDMI Port (HDMI 1, HDMI 2, etc)
Connecting a Camcorder, Camera or Games Console
Connecting a High Definition (HD) Device
Option 1 - via HDMI to HDMI cable
Note: This model TV can not be used as a PC/laptop monitor via HDMI input. The HDMI Input is provided to view
digital content with compatible external devices.
Scart
Scart
TVs Source should be set to SCART
Connecting a DVD Player/Recorder, Video Recorder or Cable/Satellite Box
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:16User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:16 22/05/2015 16:53:4722/05/2015 16:53:47

17
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Note: Connecting cables are shown for example only and may not be included. Please check ‘What Is Included In
The Box’ page.
3.5mm
audio
in
3.5mm
earphone
Y (green)
PB (blue)
PR (red)
R (red)
L (white)
Y (green)
PB (blue)
PR (red)
R (red)
L (white)
Connections
When connecting via the TV’s 3.5mm Earphone output, this will disable the TV speakers.
If you are supplied with a cable from the device which has RED, GREEN, BLUE, RED & WHITE connectors you
must connect via Component (for picture) and by phono cable (for sound).
TV Source should be set to Component.
Connecting a High Definition (HD) Device
Option 2 - via Component cable
Connecting to an external audio device (Amplifiers, Surround Sound,
Sound Bars etc)
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:17User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:17 22/05/2015 16:53:4822/05/2015 16:53:48

18 For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Tip: If you do not press any buttons for 30 seconds,
the menu will automatically exit. You can change the
length of time before the menu exits automatically -
see ‘Menu Duration’ section.
Auto Tuning
Allows you to retune the television for all digital
channels, digital radio stations and analogue
channels.
Analogue Manual Tuning
Allows you to manually tune your analogue signal
Freeview Manual Tuning
Allows you to manually tune your digital signal
Channel Edit
Allows you to delete, move, skip and add
favourite channels.
Schedule List
Lists your programme reminders
Signal Information
Displays signal strength information
CI Information
Pay per view services require a “smartcard” to be
inserted into the TV. If you subscribe to a pay per
view service the provider will issue you with a ‘CAM’
and a “smartcard”. The CAM can then be inserted
into the COMMON INTERFACE PORT (CI Card In).
To access this menu, press [MENU] button on the
remote control. To enter a menu press [OK]
If you wish to make changes to any of the default
settings, use the scroll buttons. To confirm
any settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
Channel Menu
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:18User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:18 22/05/2015 16:53:4822/05/2015 16:53:48

19
For any help concerning set up and use of your TV please call the Customer Helpline on page 3
Picture Mode
• Dynamic - Recommended settings for fast
moving pictures
• Standard - Default settings
• Mild - Set to be lighter in colour and less
bright
• Personal - Lets you manually alter all the
settings
• Economy - Power saving mode which reduces
the energy used by up to 25% (by reducing the
power to the LED/LCD panel). In Economy mode,
the TV will switch itself to Standby mode after 3-5
hours in the event that the TV buttons or remote
control buttons are not pressed (change the
picture mode to another setting to de-activate
this function)
Contrast
Switch the balance between black and white
Brightness
Increase or decrease the brightness of the picture
Colour
Increases the colour from black and white
Tint
Lets you increase or decrease the level of tint within
the picture
Sharpness
Increase or decrease the sharpness of the picture
Colour Temperature
• Normal - Default settings
• Warm - Increases red within the picture
• Cool - Increases blue within the picture
Noise Reduction
• Off - Turns noise reduction off
• Low - Minor system adjustment
• Middle - Medium system adjustments
• High - Maximum system adjustments
• Default - Default settings
Picture Menu
To access this menu, press [MENU] button on the
remote control and scroll right.
To enter a menu press [OK]
If you wish to make changes to any of the default
settings, use the scroll buttons. To confirm
any settings press [OK] button.
To exit this menu at anytime, press [EXIT] button.
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:19User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:19 22/05/2015 16:53:4822/05/2015 16:53:48

20 For any help concerning set up and use of your TV please call the Customer Helpline on page 3
• 16:9 - Fills the screen with a regular 16:9 signal
and 4:3 will stretch to fill the screen
• 4:3 - Displays the 4:3 picture in its original size.
Side bars are shown to fill the 16:9 screen
• 14:9 - Displays the 14:9 picture in the correct
proportion. As a result bars are shown on
the screen
• Zoom - The picture is the correct proportion but
zoomed in to fill the screen
Picture Menu
Aspect Ratio
Within the UK the picture format varies depending
on the channel/broadcast. There are a number of
different options to best meet your needs
• Auto - Automatically displays the best picture
format. So the picture is in the correct position.
May have black lines at the top/bottom and/or
sides.
• Original - Will display the picture from the
broadcaster without any change
User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:20User Guide - ALB-MAN-0003 - 22-207F, 22-207FDVD, 24-207F, 24-207FDVD,W,P,S.indd Sec1:20 22/05/2015 16:53:4822/05/2015 16:53:48
