ALDI FERREX BCH3200PB4 User manual

Contents
Original instructions
Vers.No. 200227
BRUSH CUTTER 31CC
BCH3200PB4
ALDI guarantees that our exclusive brand products are developed to our
stringent quality specifications. If you are not entirely satisfied with this
product, please return it to the nearest ALDI store within 60 days from the
date of purchase, for a full refund or replacement, or take advantage of our
after sales support by calling the supplier’s Customer Service Hotline.
Made in China
FERREX® is a registered trademark of ALDI Stores
DISTRIBUTED BY:
ALDI STORES
1 SARGENTS ROAD
MINCHINBURY NSW 2770
www.aldi.com.au
3
MODEL: BCH3200PB4 10/2020
AFTER SALES SUPPORT
10584
 1300 855 831
[e-mail]
Overview 04
Utilisation 05
Pack contents/Parts 06
Handling pictures 07
Explanation of symbols 11
Introduction 13
Layout 14
Scope of delivery 15
Intended use 15
General safety instructions for power tools 16
Before starting the equipment 21
Attachment and operation 21
Working instructions for Brush Cutting and Line Trimming 25
Maintenance and Cleaning 27
Storage 30
Technical data 31
Disposal and recycling 33
Troubleshooting 34
Warranty Details 36
Repair and Refurbished Goods or Parts Notice 38

UtilisationOverview Pack contents/parts
Pack contents/parts
16
17
18
19 20
24
23
22
21 19
77
76
71
72 73
69
26
27
31
29 30 31
46
36
38
39
40
41
42
43
45
44
63
19
48
47
50
51
52
53
54
51
50 55
54 56
57
59
58
21
62
68
19
70
40
74
75
26
67
63
25
28
34
33 32
49
56
60 61
81
78
79
80
79
13
19
35
64
82
83
83
84
66
65
85
85
40
37
86
1
2
3
4
5
6
7
8
9
10
11
12
14 15
4 5 6
Fig. 2 Fig. 3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
6
20
21
23
24
25
26
Fig. 1 Fig. 4 Fig. 5
4
2728
5
Fig. 6 Fig. 7
29
29
6
25
26
2
17
18 19
Fig. 8 Fig. 9
Fig. 10
7
3233
34
Fig. 11
7
31
8
32
33
34
24
22
26
1x Brush cutter 31cc (4 stroke)
1x 3 teeth blade
2x Nylon cutting head
1x Shoulder strap
1x Loop (P-) handle
1x Spark plug wrench
1x Allen key 4mm
1x Allen key 5mm
3x Cable tie
1x Instruction manual
1x Warranty card
31
30

7
Handling pictures
Fig. 12
Fig. 14
35
Fig. 13
31
32
20
26
Fig. 18
Fig. 15
21
22
Fig. 17
22
Fig. 16
Fig. 19
36
30

8
Handling pictures
2
17
18 19
Fig. 20 Fig. 21
Fig. 24 2
17
18 19
Fig. 25
Fig. 26 Fig. 27
Fig. 22
37
Fig. 23
16
14

9
Handling pictures
Fig. 28
Fig. 32
WIND CORD
Fig. 33
Fig. 34 Fig. 35
Fig. 29
20
Fig. 30
38 39
40
Fig. 31
40 3941

10
Handling pictures
Fig. 36
Fig. 38
Fig. 40
Fig. 39
Fig. 37
Motor oil
10W30 / SAE30
~ 100 ml
Fig. 41
Max. Min.
Fig. 42
9
1

11
Explanation of symbols
Explanation of symbols
Read the instruction manual.
Warning! Petrol is very flammable. Avoid smoking or getting any
flame or sparks close to fuel.
Warning! Denotes risk of personal injury, loss of life, or damage
to the tool in case of non-observance.
Warning! Risk of injury!
Do not let your hands or feet come in contact with the blades
when the motor is running.
Warning! Keep all children, bystanders and helpers 15 meters
away from the brush cutter!
Wear robust footwear when using the device!
Wear protective helmet, ear and eye protection.
Wear protective gloves when using the device!
Warning! The exhaust and other parts of the engine will get very
hot during use, do not touch!
Fuel tank capacity
Warning! Beware of thrown objects hit by cutting attachments.
Never use without properly mounted blade guard.

12
Explanation of symbols
Conforms to relevant standards for electromagnetic
compatibility.
Caution kickback!
Caution, do not use saw blades
or multi-part metal cutting tools!
Brush cutter
Grass trimmer
2
Guaranteed sound power
m ATTENTION!These operating instruction provide places concerning your
safety which are marked with this indication.
m CAUTION!Failure to follow these instructions may cause light to medium
risk of injury.
m WARNING!Failure to follow these instructions may cause danger to life or
danger of serious injuries.

13
Introduction
I. Introduction
Congratulations on choosing to buy a FERREX®product.
All products brought to you by FERREX®are manufactured to the highest standards of per-
formance and safety, and as part of our philosophy of customer service and satisfaction, are
backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.
Note:
According to the applicable product liability law the manufacturer of this device is not liable
for damages which arise on or in connection with this device in case of:
• improper handling,
• non-compliance with the instructions for use,
• repairs by third party, non-authorised skilled workers,
• installation and replacement of non-original spare parts,
• improper use,
• failures of the electrical system due to the non-compliance with the electrical specifications
and regulations.
Recommendations:
Read the entire text of the operating instructions prior to the assembly and operation of the
device.
These operating instructions are intended to make it easier for you to get familiar with your
device and utilise its intended possibilities of use.
The operating instructions contain important notes on how to work safely, proper-
ly and economically with your machine and how to avoid dangers, save repair costs,
reduce downtime, and increase the reliability and working life of the machine.
In addition to the safety regulations contained herein, you must in any case com-
ply with the applicable regulations of your country with respect to the operation of the
machine.
Put the operating instructions in a clear plastic folder to protect them from dirt and humidity,
and store them near the machine. The instructions must be read and carefully observed by
each operator prior to starting the work. Only persons who have been trained in the use of
the machine and have been informed on the related dangers and risks are allowed to use the
machine. The required minimum age must be met.
In addition to the safety notes contained in the present operating instructions and the special
regulationsofyourcountry,the generally recognisedtechnical rulesforthe operationof iden-
tically constructed machines must be observed.

14
Layout
2. Layout (Fig. 1 - 31)
1. Petrol tank
2. Rear handle
3. Front handle
4. Star knob
5. Long handle with drive shaft
6. Safe guard
7. Cutting blade
8. Cutting blade safe guard
9. Filler cap
10. Air filter housing cover
11. Air filter housing opener
12. Spark plug boot
13. Housing for engine cooler
14. Choke lever
15. Oil filler neck
16. Starter cable
17. Throttle lever
18. Switch On/Off
19. Throttle lock lever
20. Nylon cutting head
21. Shoulder strap
22. Emergency release
23. Cable ties (3x)
24. Spark plug wrench
25. Allen key (size 5)
26. Allen key (size 4)
27. Locking pin
28. Bore for locking pin
29. Screw for safe guard (2x)
30. Inner Shield
31. Inner flange
32. Outer flange
33. Outer Shield
34. Nut
35. Integrated blade
36. Shoulder belt suspension
37. Fuel pump
38. Nylon cutting head cover
39. Nylon cutting head housing
40. Nylon spool
41. Nylon cord

15
Scope of delivery/ Intended use
3. Scope of delivery
• Open the packaging and take out the equipment with care.
• Remove the packaging material and any packaging and/or transportation braces (if available).
• Check to see if all items are present.
• If possible, keep the packaging until the end of the guarantee period.
• Read the operating instructions to make yourself familiar with the device prior to using it.
• Please dispose the packaging after the guarantee period in an environmentally friendly way.
• Only use original parts for accessories as well as for wearing and spare parts. Spare parts
are available from your specialized retailer.
• Specify ourpartnumbersaswell as thetypeandyear of constructionof thedevice in your orders.
mImportant!
The equipment and packaging material are not toys. Do not let children play with plastic bags,
foils or small parts. There is a danger of swallowing or suffocating!
1x Brush cutter 31cc (4 stroke)
1x 3 teeth blade
2x Nylon cutting head
1x Shoulder strap
1x Loop (P-) handle
1x Spark plug wrench
1x Allen key 4mm
1x Allen key 5mm
3x Cable tie
1x Instruction manual
1x Warranty card
4. Intended use
The brush cutter (using the cutting blade) is designed for cutting young trees, strong weeds
and undergrowth. The brush cutter (using the line spool with cutting line) is designed for
cutting lawns, grassed areas and small weeds. The operating instructions as supplied by
the manufacturer must be obeyed to ensure that the equipment is used properly. Any use
which is not expressly permitted in the manual may result in damage to the equipment and
place the user in serious danger. Be sure to observe the restrictions in the safety instructions.
Please note, this product has been designed for outdoor domestic use only and is not in-
tended for commercial, trade or industrial applications. Our warranty will be voided if the
equipment is used in commercial, trade or industrial businesses or for equivalent purposes.

16
Intended use/ General safety instructions for power tools
mIMPORTANT! Due to the high risk of bodily injury to the user, the petrol brush cutter must
not be used to carry out the following work: to clean dirt and debris off walkways, or to chop
up tree or hedge clippings. Similarly, the petrol brush cutter must not be used to level out
high areas. For safety reasons, the petrol brush cutter must not be used as a drive unit for
other work tools or toolkits of any kind.
The equipment is allowed to be used only for its prescribed purpose. Any other use is deemed
to be a case of misuse. The user/operator and not the manufacturer will be liable for any dam-
age or injuries of any kind resulting from such misuse.
Non-permitted users:
Persons who are not familiar with the operating manual, children, young people under the
age of 16 as well as persons under the influence of alcohol, drugs or medication must not
operate the unit.
5. General safety instructions for power tools
mWARNING! Read all safety warnings, instructions, illustrations and spec-
ifications provided with this power tool. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded)
power tool, petrol driven power tool or battery-operated (cordless) power tool.
1) Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Dis-
tractions can cause you to lose control.
2) Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric
shock.
b. Avoidbodycontactwith earthedorgrounded surfaces,such as pipes,radia-
tors, ranges and refrigerators. There is an increased risk of electric shock if your
body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.

17
General safety instructions for power tools
d. Do not abuse the cord. Never use the cord for carrying, pulling or un-
plugging the power tool. Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords increase the risk of electric
shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual
current device (RCD) protected supply. Useof anRCDreduces theriskofelectric
shock.
3) Personal safety
a. Stay alert, watch what you are doing and use common sense when op-
erating a power tool. Do not use a power tool while you are tired or un-
der the influence of drugs, alcohol or medication. A moment of inattention
while operating power tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye protection. Pro-
tective equipment such as a dust mask, non-skid safety shoes, hard hat or
hearing protection used for appropriate conditions will reduce personal in-
juries.
c. Prevent unintentional starting. Ensure the switch is in the off-position
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may re-
sult in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair and
clothing away from moving parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g. If devices are provided for the connection of dust extraction and col-
lection facilities, ensure these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to
become complacent and ignore tool safety principles. A careless action
can cause severe injury within a fraction of a second.
4) Power tool use and care
a. Do not force the power tool. Use the correct power tool for your appli-
cation. The correct power tool will do the job better and safer at the rate for

18
General safety instructions for power tools
which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c. Disconnect the plug from the power source and/or remove the battery
pack, if detachable, from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive safety meas-
ures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool.Power tools are dangerous in the hands of untrained users.
e. Maintain power tools and accessories. Check for misalignment or bind-
ing of moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly maintained
power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and
grease. Slippery handles and grasping surfaces do not allow for safe han-
dling and control of the tool in unexpected situations.
5) Service
a. Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
mWARNING! This electric tool generates an electromagnetic field during op-
eration. This field can impair active or passive medical implants under certain
conditions. In order to prevent the risk of serious or deadly injuries, we recom-
mend that persons with medical implants consult with their physician and the
manufacturer of the medical implant prior to operating the electric tool.

19
General safety instructions for power tools
Additional Safety Rules for Petrol products
• Do not operate in a hazardous location. Such areas include where there is a
risk of explosion of petrol fumes, leaking gas or explosive dust.
• Do not operate in a confined area. Exhaust gases, smoke or fumes could reach
dangerous concentrations.
• Protect your product. This brush cutter / grass trimmer is NOT WEATHERPROOF
and should not be exposed to direct sunlight, high ambient temperature and
damp, wet or high humidity conditions.
• Do not smoke while refuelling. This is potentially dangerous as it may ignite
the fuel and cause an explosion.
• Take care not to spill fuel or oil. When refuelling the brush cutter / grass trim-
mer ensure that the motor has been switched off. Prevent the spilling of fu-
el as this may also ignite with the hot motor. Never refuel whilst the engine
running.
• Check for fuel leaks. Do not operate if a fuel leak is detected. Where a fuel leak
is detected, drain the tank of fuel and have the leak repaired.
• Be careful where you store the brush cutter / grass trimmer. Store the brush
cutter / grass trimmer in a dry area away from flammable liquids.
• Keep your distance. The brush cutter / grass trimmer emits exhaust fumes.
Ensure bystanders keep a safe distance.
• Never fill fuel tank indoors. Never fill fuel tank when engine is running or hot.
Do not smoke when filling fuel tank.
Additional Safety Rules for Petrol Grass Trimmers
• Follow all sections of the Additional Safety Rules for Petrol Products.
• Always wear goggles, earmuffs and a dusk mask when using the Grass Trim-
mer.
• Only use the length and diameter of nylon cutting line as detailed in this man-
ual. Never use any other cutting material.
• Never use the Grass Trimmer without the supplied and correctly fitted guard.
• Ensure the line trimming blade is in good order to ensure the correct length
of cutting line is maintained.
• Keep bystanders at least 15 metres away from the operating the Grass Trim-
mer.
• During operation, always hold the Grass Trimmer with both hands, and make
use of the Double Shoulder Strap Harness.
• Maintain a firm footing. Wear suitable fully enclosed footwear.
• Always turn off the petrol motor when making adjustments to the cutting
head or line, when cleaning, or performing any maintenance tasks.
• When operating the Grass Trimmer, be aware of the ground where the Grass
Trimmer is being operated. The cutting head and line is designed to trim grass
and similar undergrowth, and stones and foreign matter should be avoided.

20
General safety instructions for power tools/Before starting the equipment
• Prior to operation, ensure the assembled line Grass Trimmer is checked for
loose components and the operating controls of the trimmer. Do not use the
Grass Trimmer if the controls are not in perfect working order. Ensure all nuts,
bolts and clamps are all tight.
Additional Safety rules for Petrol Brush cutters
mWARNING! Extreme care must be taken when using blades to ensure safe
operation. Read the safety information for safe operation using the blade.
• Follow all sections of the Additional Safety Rules for Petrol Products.
• Always hold brush cutter with both hands when operating. Use a firm grip
on both handles.
• Maintain your grip and balance on both feet. Position yourself so that you
will not be drawn off balance by the kick-back reaction of the cutting blade.
• Inspect and clear the area of any hidden objects such as glass, stones, con-
crete, fencing, wire, wood, metal, etc.
• Never use blades near footpaths, fencing, posts, buildings or other immov-
able objects.
• Never use a blade after hitting a hard object without first inspecting it for
damage. Do not use if any damage is detected.
• The unit is used as a scythe, cutting from the right to the left in a broad sweep-
ing action from side to side.
• Always wear goggles, earmuffs and a dusk mask when using the brush cutter.
• Only use blades with a cutting diameter of 255mm and a bore size of 25.4 mm.
• Only use the brush cutter with the correctly supplied and fitted brush cutter
guard.
• Keep bystanders a minimum of 15 metres from the operation of the brush
cutter.
• Prior to operation, ensure the assembled brush cutter is checked for loose
components and the operating controls of the brush cutter. Do not use the
brush cutter if the controls are not in perfect working order. Ensure all nuts,
bolts and clamps are all tight.
• Check the blade is correctly seated and the blade nut is tight.
• DO NOT substitute the blade with any other types of blade other than that is
detailed in this manual. DO NOT fit a saw blade to this product.
• This brush cutter is fitted with a centrifugal clutch. At idle, the blade must not
be rotating. Make a practice to always check the clutch is correctly operating
and at idle the blade does not rotate, and rotation of the blade only occurs as
the speed of the motor is increase from manually operating the speed trigger.
Do NOT use the brush cutter if the blade at idle speed is rotating and take it
to an authorised service centre.
• Exercise extreme caution when using the 3T brush cutter blade with this unit.
Blade thrust is the reaction which may occur when the spinning 3T brush cut-

21
General safety instructions for power tools/Before starting the equipment/Attachment and operation
ter blade contacts anything it cannot cut. This contact may cause the 3T brush
cutter blade to stop for an instant, and suddenly “thrust” the unit away from
the object that was hit. This reaction can be violent enough to cause the oper-
ator to lose control of the unit. Blade thrust may occur without warning if the
blade snags, stalls or binds. This is more then likely to occur in areas where it
is difficult to see the material being cut.
6. Before starting the equipment
Each time before use, check the following:
• That there are no leaks in the fuel system.
• That the equipment is in perfect condition and that the safety devices and cutting devices
are complete.
• That all screws are securely fastened.
• That all moving parts move smoothly.
• That there are no damaged parts, such as cracks in the cutting attachment.
•
mCAUTION! The engine does not come with oil in it. Therefore, ensure that you add 0.08
litres (80mL) of oil before starting it up. Use normal, multigrade oil (SAE30 / 10W30). The
oil level in the engine must be checked each time before mowing. (Fig. 41+42)
You will also need to fill with petrol, as this is also not supplied upon delivery.
Fuel:
Recommended fuels.
Normal petrol / Lead free max. 5% bioethanol
mImportant!Only use containers designed and approved for the purpose to transport and
store fuel.
mWARNING! Take care of the emission of exhaust gases. Always shut off engine before
fueling. Never add fuel to a machine with a running or hot engine. Take care of fire!
7. Attachment and operation
7.1 ASSEMBLY
When assembling this machine, please follow the instructions for assembly printed.
7.1.1 Assemble the handle on the machine (Fig. 4-5)
• Install the front handles as show in Fig. 5.
• Make sure that you align the pin with the hole in the aluminum shaft. Tighten the screws
after you have set the risers to the most comfortable working position.
• The front handles should be aligned as in Fig. 4 and 5 shown, then tighten the four screws
with the allen key (26).

22
Attachment and operation
7.1.2 Mounting the shaft (Fig. 6)
• Push the lower part of the long handle with drive shaft (5) right down until the locking pin
(27) slots into the bore for locking pin (28) in the shaft. This is easier to do if you rotate the
bottom of the long handle with drive shaft (5) slightly in both directions. The locking pin
(27) is in place when it is completely lodged in the bore for locking pin (28).
• Lastly, tighten the star knob (4) securely.
7.1.3 Assemble the safe guard (Fig. 7-9)
• Fix the safe guard (6) with the two screws for safe guard (29) and the allen key (25).
mWARNING! Use only original manufacturer‘s replacement parts, accessories and attach-
ments. Failure to do so can cause poor performance, possible injury and may void your war-
ranty. Never use the machine without the guard assembled.
7.1.4 Assembling and disassembling the two cutting devices
7.1.4.1 Assemble the cutting blade (7) (Fig. 10-11)
• Fit the blade: Take the outer flange (32), outer shield (33) off after releasing the nut (34) with
the spark plug wrench (24), then put the nut (34), outer shield (33), outer flange (32), cut-
ting blade (7) and inner flange (31) together. Use an allen key (26) to line up the two holes
of inner flange (31) and inner shield (30) and tighten nut anti-clockwise with the spark plug
wrench (24), ensuring the nut is tightened enough. (See Fig. 10)
• Release blade. Use a allen key to hold inner shield (30) and inner flange (31) and release
nut, the blade can be took off.
mWARNING! Please make sure the cutting head has been assembled correctly before use!
7.1.4.2 Assemble and disassemble the nylon cutting head (20) (Fig. 12-13)
• Release the nut (34) if mounted with cutting blade. (Fig. 10)
• Line up the two holes of inner flange (31) and inner shield (30), use the allen key (26) to
hold the inner flange (31) and turn the spark plug wrench (24) clockwise, the nut (34) will
be released. Remove the outer shield (33) after releasing the nut (34).
• Fit the Nylon cutting head (20). (See Fig. 13)
• Still holding the inner flange (31), take the Nylon cutting head on the shaft and rotate an-
ti-clockwise, the Nylon cutting head is fitted.
• To remove the Nylon cutting head: Use an allen key to hold inner flange (31) and then rotate
the Nylon cutting head (20) clockwise, it can be removed.

23
Attachment and operation
7.1.5 Fit the shoulder strap (21) (Fig. 16-19)
• As shown in Fig. 16, fit the shoulder strap well. When closing the shoulder strap you will
hear a noticeable click.
• The shoulder straps can be adjusted according to your size.
• Hang the unit by the shoulder belt suspension (36) on the shoulder strap (21).
• The shoulder strap (21) is fitted with a emergency release (22) which allows rapid removal
of the appliance from the harness. (See Fig. 19) To activate the emergency release and re-
lease the appliance, “Pull the red tab thus with drawing the metal tab”. The attaching clip
will release from the harness.
7.2 OPERATION
When working with the equipment, the appropriate safe guard (6) hood for cutting blade mode
or cutting line mode must be fitted to prevent objects being thrown out by the equipment. (Fig.
7-9) The integrated blade (35) in the safe guard automatically cuts the line to the optimum
length. (Fig. 14)
7.2.1 Filling with fuel (Fig. 40)
mDanger of injury! Fuel is explosive! Turn off and cool the motor down before filling the
tank with fuel. You must observe all safety instructions relating to handling fuel.
mRisk of device damage! The device is supplied without motor or gearbox oil.
mATTENTION! Before operating, you must fill it with fuel.
• Unscrew the filler cap (9) from the petrol tank (1) and remove it. (Fig. 40)
• Pour in the fuel carefully. Avoid spilling!
• Screw the filler cap (9) on the petrol tank (1) firmly by hand.
mWarning! Before starting the unit, move away from the fueling site.
7.2.2 Draining fuel. (Fig. 40)
• Hold a collection container beneath the filler cap (9).
• Unscrew the filler cap (9) and remove it.
• Allow the fuel to run out completely.
• Screw the filler cap (9) on firmly by hand.
7.2.3 Start and stopping the Unit
Do not start the unit until it has been completely assembled.
mDanger of injury! Do not operate the device unless you did not find any faults. If a
part has become defective, make sure to replace it before you use the device again.

24
Attachment and operation
Check before use!
• Check the safe condition of the device.
• Check the device for leaks.
• Check the device for visual defects.
• Check that all parts of the device have been securely fitted.
• Check that all safety devices are in proper condition.
mDanger of injury!
Before starting work, always check the ground and remove all objects which could be thrown
by the device.
7.3 Start (Fig. 20 - 25)
Once the machine has been set up properly, start the engine as follow:
• Set the equipment down on a hard, level surface.
• Turn the switch On/Off (18) to the ON "I"position. (Fig. 20)
• Put the choke lever (14) on the position. (Fig. 21)
• Press the fuel pump (37) about 10 times. (Fig. 22)
• Pull the starter cable (16) 3-5 times to start the engine. (Fig. 23)
• Adjust the choke lever (14) to position. (Fig. 24)
• Pull the starter cable (16) until engine starts. (Fig. 23)
7.4 Adjusting the speed on the brush cutter/Grass Trimmer
• NOTE: The cutting head (nylon cutting head or cutting blade) will not rotate at the idle
speed. The cutting head (nylon cutting head or cutting blade) will engage and rotate when
the speed of the motor is increased.
• To increase speed and engage the cutting head, squeeze the throttle lock lever (19) and
then the throttle lever (17). The throttle lock lever (19) can be released during operation.
• To decrease the speed, slowly release the throttle lever (17) to the desired speed.
• To disengage the cutter head (nylon cutting head or cutting blade), release all pressure on
the throttle lever (17) and allow the motor to return to idle. The cutter head (nylon cutting
head or cutting blade) will disengage at idle.
• NOTE: Be aware that when using the cutting blade (7), it will take a few seconds to run down.
•
mIMPORTANT! If the cutting head (nylon cutting head or cutting blade) does not disengage
and stop when the throttle is in the idle position, turn off the petrol motor and have the unit
checked at a service centre. This should be checked every time the motor is started.
7.5 Stopping the brush cutter/ Grass Trimmer
• Release the throttle lever (17) and allow the engine to idle for a few moments.
• Slide the switch on/off (18) to the ‘OFF’ position (also indicated on the side of the handle
housing by an “O”).
• The engine will stop.
