SHUTTIE
Installation Manual

Part No. HDW-000081-001
Product description The wireless, battery operated water Actuator
is mounted on an ISO5211 ball valve installed
on the main water line. The water supply
automatically shuts o whenever a leak
is detected. Shuto can also be manually
controlled by the user.
Dimensions 142x73x92mm (5.6x2.87x3.62’’)
Weight 640g (22.5 oz)
Power supply 4 x 3V batteries (CR123A)
Operation voltage 6V
Battery life span Up to four years based on one operation per
day/5 days a week.
Operating RF 915 MHz
Transmission range Open space - up to 230 m (750 ft.)
In enclosed space - up to 120 m (390 ft.)
Avoid installing in a metal cabinet.
Certication FCC: 2AFOILORA
IC: 20798-LORA
IP Rating IEC60529 IP67
Working temperature -20C to +50C (-40F to +1220F)
SHUTTIE SPECIFICATION
Warning! This product includes moving parts. Keep your ngers or any other objects away.
Warning! This product was designed to prevent water leakage damages and should be used for this purpose only.

FCC STATEMENTS
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate this equipment.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment o and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician
for help.
WARNING – RF EXPOSURE COMPLIANCE: This equipment should be
installed and operated with a minimum distance 20cm between the
radiator and your body.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numerique de la classe B est conforme a la norme
NMB-003 du Canada.
IC STATEMENTS
This device contains licence-exempt transmitter(s)/receiver(s) that
comply with Innovation, Science and Economic Development
Canada’s licence-exempt RSS(s). Operation is subject to the following
two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le
présent appareil est conforme aux CNR d’Innovation, Sciences et
Développement économique Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :
1) L’appareil ne doit pas produire de brouillage;
2) L’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le
fonctionnement.
AVERTISSEMENT – CONFORMITÉ AUX NORMES D’EXPOSITION
AUX RF : Cet équipement doit être installé et utilisé à une distance
minimale de 20 cm entre le radiateur et votre corps.

Shuttie
Actuator Valve
Perpendicular Actuator
Mount
Perpendicular Valve
Adapter Insert
In-line Actuator Mount
In-line Valve Adapter
Insert
T-Shaped Key
Screws
Lock washers
Nuts
Batteries
Shuttie Installation
Manual
What’s Included
Installation
manual
Guide
d'installation
Installation
manual
Guide
d'installation
Installation
manual
Guide
d'installation
Installation
manual
Guide
d'installation
Installation
manual
Guide
d'installation
1
1
2
3
4
5
6
7
8
9
10
11
12
2
3
5
4
6
7

What You Need
Installation
manual
Guide
d'installation
Installation
manual
Guide
d'installation
Installation
manual
Guide
d'installation
Installation
manual
Guide
d'installation
1
811
910
12
Phillips Head Screwdriver

What To Do First
Call a plumber
Ask the plumber to install the valve because
the water pipe will need to be cut.
A plumber installed
this valve
1
2

Installation Options
Shuttie can be installed either in-line or perpendicular to the water line.
In-line
Installation:
Perpendicular
Installation:

Installing Shuttie
Before you begin installing Shuttie, watch the video at alertlabs.com/ShuttieInstall.
Remove Shuttie from the box and remove the plastic wrap from the batteries.
NOTE: When the batteries are rst installed and the compartment is closed, Shuttie will automatically
start a cleaning process where it will close and then open again.

Inserting The Batteries
Loosen the screw on the bottom of the battery compartment to remove the cap using a Phillips-head #1
screwdriver. Place all 4 x CR123 batteries into the compartment with ‘
- ’ end facing out. Place the cap back onto
the compartment. Align the edges of the cap and compartment before tightening the screw to make sure it closes
properly. Press the orange button briey to check the Shuttie LED status color. It should blink green.
1
RED - Error
BLUE - Communication fault
GREEN - Operating
OFF - No power

Installing The Adapter
Open a water tap briey to conrm that the valve is open and water is running. If the valve is closed, turn it 90
degrees using a wrench. Select the actuator mount according to installation type. Remove the one you need from
the box.
LONG ACTUATOR MOUNT - In-line installation SHORT ACTUATOR MOUNT - Perpendicular installation
Remove the grey star-shaped valve adapter insert from inside the actuator mount.
2
LONG ACTUATOR MOUNT
In-line installation
SHORT ACTUATOR MOUNT
Perpendicular installation

Place the valve adapter insert onto the valve. The direction of the rectangular slot will depend on the type of
installation (see images above).
PARALLEL to the pipe - In-line installation
PERPENDICULAR to the pipe - Perpendicular installation.
3
PERPENDICULAR
INSTALLATION
IN-LINE
INSTALLATION

Slide the gray actuator mount over the valve adapter insert, aligning the screw holes on the water valve.
NOTE: There are 2 holes for screws on opposite corners of the actuator mount that align to the holes on
the water valve.
4

Next you will need the bag of screws, lock washers, and nuts. Insert the screws through the mount and valve.
Tighten the nuts with lock washers onto the screws.
NOTE: Fully tighten the screws with the hexagon heads inside the cut-outs in the adapter mount.
5

Mounting Shuttie
Make sure Shuttie is set to the open position. When the line of the brass actuator shaft is horizontal, Shuttie is in the
open position . The metal locking pin must also be pulled out so that Shuttie can slide onto the actuator mount.
6
Brass actuator shaft in
open position

Slide Shuttie onto the actuator mount by inserting the brass actuator shaft into the rectangular slot.
7

Make sure that you have access to the metal locking pin once Shuttie is attached. Push the metal locking pin into its
slots to lock the valve adapter in place.
8

Now you can test that valve will close. Press and hold the orange button for 5 seconds then release. The line of
the brass actuator shaft will move to a vertical position to match . Turn on a water tap to conrm that water ow
through the pipe stops. Test that the valve will open. Press and hold the orange button again for 5 seconds then
release. The line of the actuator shaft will move to the horizontal position to match .
NOTE: When testing is complete, remember to turn the water tap o again.
9
Brass actuator shaft in
closed position

How do I know if the water valve is open?
Open a water tap briey to conrm that the valve is open and water is running.
How do I open the water valve if it’s closed?
If the valve is closed at the beginning of the installation process, turn the valve 90 degrees with a wrench.
After the adapter is installed you can use the T-shaped key that comes in the Shuttie box.
What if the valve is stuck?!
If the valve gets stuck (not fully open or closed), try again by holding the orange button for 5 seconds. If this is not
successful, remove Shuttie from the actuator mount and turn the valve using the T-shaped key.
Troubleshooting
Need help?
For additional help, or in case of issue, visit alertlabs.com/support or contact
us at [email protected]
