Alfa Plam CFA XILA Service manual

1612294
A.D. METALNA INDUSTRIJA VRANJE
Radnička br: 1
PELLET STOVE
CFA XILA
This product meets the requirements of the Ecodesign Directive in terms of efficiency and air pollution level, in order
to contribute to the reduction of energy consumption and negative environmental impact.
INSTALLATION, USE, AND MAINTENANCE MANUAL
ENG_v.2.0

Introduction
First of all, we would like to use the opportunity to express our gratitude to you for buying this ALFA PLAM product.
We have prepared this short manual for you in order to make the use of our product as easy as possible.
Special technical problems mentioned here should be considered by persons included in assembling, installation, and
putting the product into operation, in order to provideoperations to be carried out as proper as possible.
•This booklet about installation, use, and maintenance shouldbe
read carefully before the installation and use of the product.It should be considered an integral part of the product and
must be kept at a safe place.
•Installation, networking, control, maintenance, and repair procedures must be performed by qualified personnel
•We recommend that the first ignition, or to say more precisely, putting into operation, is carried out only by qualified staff.
•Do not use any flammable liquids for the ignition process.
•This product should not be used by persons with reduced physical, sensory, and mental abilities or a lack of experience or
skills (including children), unless
they are supervised and given instructions by someone who can guarantee their safety.
•Children should always be supervised by an adult in order to protect them from an accidental contact with hot surfaces
ofthe stove, and to prevent them from using, or touchingthe stove adjustment buttons.
•Please ask the sales assistant for additional information you need, which is not included in this
Manual.
The following symbols are used in this Manual:
CAUTION: Safety warning,
IT IS FORBIDDEN TO: Forbidden action,
INFORMATION: Important information.
ALFA PLAM a.d. shall not be held responsible or liablefor any direct or indirect personal injury or property damage arising from
non-compliance with theindications given and highlighted in this Manual.

CONTENT:
INTRODUCTION ........................................................................................................................................1
Product serial number .................................................................................................................1
Materials.....................................................................................................................................1
Certification ................................................................................................................................1
Dimension characteristics ...........................................................................................................1
1.4.1. In detail .................................................................................................................................2
Technical characteristics of the product......................................................................................2
Fuel ..........................................................................................................................2
Safety recommendations ............................................................................................................4
General recommendations...........................................................................................................4
INSTALLATION .........................................................................................................................................5
Placing the device .......................................................................................................................5
Characteristics of the flue pipe....................................................................................................6
2.2.1. FLUE CONVEYANCE TOWARDS THE EXTERIOR WALL ...........................................................6
2.2.2. SMOKE EXHAUST TOWARDS THEROOF VIA TRADITIONAL CHIMNEY ..................................7
Disassembling and waste disposal..............................................................................................8
Electrical connections .................................................................................................................8
Room temperature measuringdevice ...........................................................................................8
Electrical scheme of connection..................................................................................................8
USING THE PRODUCT ...............................................................................................................................9
First ignition................................................................................................................................9
Safety devices...........................................................................................................................10
The control panel (display): use and features ............................................................................11
3.3.1 K100 display .......................................................................................................................11
3.3.2 Alarms ................................................................................................................................11
3.3.3 Other messages ..................................................................................................................11
3.3.4 Visualizations .....................................................................................................................12
User menu 1..............................................................................................................................12
3.4.1 Chrono ................................................................................................................................12
User Menu 2..............................................................................................................................14
Turning the furnace on and the state function ...........................................................................14
3.6.1. Check Up.............................................................................................................................14
3.6.2. Ignition ...............................................................................................................................14
3.6.3. Stabilization........................................................................................................................15
3.6.4. Normal –Run Mode ............................................................................................................15
3.6.5. Modulation..........................................................................................................................15
3.6.6. Safety .................................................................................................................................15
3.6.7. Extinguishing ......................................................................................................................15
3.6.8. OFF .....................................................................................................................................15
3.6.9. Block...................................................................................................................................15
3.6.10. Ignition Recovery ................................................................................................................15
Other functions .........................................................................................................................15
3.7.1. Management of the absence of power.................................................................................15
3.7.2. Management of pellet loading calibration ...........................................................................16
3.7.3. Management of flue gas engine correction..........................................................................16
3.7.4. Safety thermostat ...............................................................................................................16
3.7.5. Periodic cleaning of the furnace ..........................................................................................16
3.7.6. Shutting down during the ignition phase .............................................................................16
Possible problems and solutions (Troubleshooting)..................................................................16
MAINTENANCE .......................................................................................................................................18
Special maintenance .................................................................................................................22
QUALITY CONTROL.................................................................................................................................23

1
INTRODUCTION
Product serial number
The product serial number can be found on the nameplate affixed to the back of the device as well as on the cover of this
manual. The product serial number shall be required any time whena customer requests ancillary services.
Materials
Products of ALFA PLAM a.d. commonly use materials thathave the following characteristics:
•Very thick sheets that provide a solid structure of theequipment;
•For certain models very thick majolica and materials from cast iron are used to give the product a unique design and
elegant finish;
•Before they are painted on a high temperature, metalparts are exposed to phosphate treatment to lead the painting
process to the best level and improve the endproduct;
•Gaskets, which enable air-tight sealing of the combustion chamber, must be checked periodically to prevent improper
heating that may result from excessivewearing of the gaskets;
•Glass and ceramic elements for the combustionchamber door. For information related to the cleaning procedures,
please refer to the maintenance section.
Certification
This product is compliant with the EN 14785 Standard on Residential space heatingappliances fired by wood pellets. It
also complies with the Serbian laws that implement the following European directives:
-2014/30 EU Directive (relating to electromagneticcompatibility);
-2014/35 EU Directive (Low Voltage Directive);
-Regulation (EU) 305/2011 (Construction ProductsRegulation)
Dimension characteristics
Dimensions in mm gas pipe ɸ80

2
A: Flue gas pipe diameter ø 80
B: Air intake ø 50
C: Electric connections
1: Manual resetting thermostat
2: Room temperature sensor
3: On/off switch
4: Power supply cable
Technical characteristics of the product
Product: CFA XILA
Unit measures
Max.
Min.
Heating power
kW
6,5
4,25
CO Emission (at 13% of oxygen)
%
0,0071
0,0071
Efficiency
%
92,9
95,22
Rated power
W
420
Rated voltage
V
230
Rated frequency
Hz
50
Fuel
Drveni pelet
Fuel consumption per hour
kg/h
1,450
0,925
Gas mass flow
g/s
4,96
3,08
Gas combustion temperature
°C
100
76
Min. draft in the chimney
Pa
11
9,3
Tank capacity
kg/h
18
Autonomy
h
12,4
19,4
Required power for functioning
W
90
Flue gas outlet diameter
mm
∅80
Combustion air inlet diameter
mm
∅50
Net weight
kg/h
80
Heating volume*
m3
157
*Values are calculated in line with the thermal needs of 35 W/m3and height of 3 m.
Fuel properties
Use of liquid or any other solid fuel other than wood pellets is strictly forbidden.
The main characteristic of this stove is that it burns natural fuel (wood pellets), which is ecologically produced from
waste in the wood-processing industry (chips/sawdust). Having been properlycleaned and dried, the chips and the sawdust
which are produced in the wood-processing processes, are compressed under extremely high pressure to produce small
cylinders of pure wood: pellets. Each tiny cylinder can vary in length and thickness, from 1 to 3 cm in length and 6 to 8 mm
in diameter.
Wood pellets are primarily distinctive by a low moisturecontent (below 12%) and high density (=600 kg/m3), as well
as with their uniformity and compactness, which gives thistype of fuel characteristics of high caloric value (DTV 4100-5000
kcal/kg).
2
1
1
3
4

3
Wood pellets that are used as fuel for this stove must have excellent quality properties such as the ones prescribed by the
standards DIN 51731, ONORM M 7135, and EN plus A1, for which numerous basic items are given below.
CAUTION: To achieve the best possible level ofoperation of the stove, we recommend the use of the wood pellets that
are verified by the accredited body. Use of pellet typesother than those defined by the manufacturer maycause defect of the
stove and annul the warranty.
Storage and handling of the wood pallets are importanttasks that must be performed carefully.
-The fuel must be stored at a dry and warm place.
-The pellets must be handled in such a way as to prevent theirexcessive crushing and becoming fine powder.
Adherence to these two simple rules shall enable better efficiency of the combustion and even preserve the proper
operation of the movable mechanical parts of thedevice.
CAUTION: If the device is not used for a sufficient period of time (more than fifteen days), all remaining pellets should
be removed from the tank in order to prevent their excessive moisture since it may lead to deterioration of the product.
Wood pellet
quality standards
Unit
measure
ONORM M 7135
DIN 51731
DIN plus
EN plus A1
Diameter
mm
from 4 to 10
from 4 to 10
from 4 to 10
6 ±1
Length
mm
5 x P1
< 50
5 x P1
3.75 < D < 40 3
Density
kg/dm3
> 1.12
1.0-1.4
> 1.12
>0.6 (average bulk
density)
Moisture
%
< 10
< 12
< 10
< 10
Ash
%
< 0.50
< 1.50
< 0.50
< 0.50
Thermal power
kWh/kg
> 5
4.86-5.42
> 5
> 4.5
Sulphur
%
< 0.04
< 0.08
< 0.04
< 0.05
Nitrogen
%
< 0.3
< 0.3
< 0.3
< 0.3
Chlorine
%
< 0.02
< 0.03
< 0.02
< 0.02
Dust
% by weight
< 2.3
-
< 2.3
< 1
Bindingagents
% of the
pressedweight
< 2
2
< 2
1 More than 20% of the pellets should not have length 7.5 times greater than diameter D.
2 DIN prohibits the use of any other additional substances. However, this prohibition does not apply for small heating
systems.
3 More than 5% of the pellets should not have length greater than 40 mm, maximum 45 mm.
FUEL LOADING
Open the top door of the product to insert the pellet. Regarding fuel, you must follow the notes found in the relevant part
of this manual.
CAUTION: Do not let the bag with wood pellets come into contact with the hot partsof the product during the fuel
loading.
CAUTION: Do not remove the protection grid insidethe part for the pellets loading.
CAUTION: Do not lean the full weight of the bagcontaining the fuel on the product.
CAUTION: When you finish the pellets loading, closethe upper door.
Periodically check the quantity of wood pellets that iscontained in the tank and load it on time. This will prevent the
stove from entering into alarm mode dueto the lack of fuel, when the sound signal is activated until the user reacts and
resolves the situation.
Fuel loading

4
Safety recommendations
CAUTION: Read carefully the enclosed manual with instructions before installation.
CAUTION: the burner must be emptied before turning on the device in case there are any difficulties when turning on the
device itself.
It is strictly forbidden to use any other type of solid or liquid fuel except wood pellets with a diameter of 6 mm, for which
the stove is designed. Avoid using wet or crushed pellets.
To achieve the best possible level of operation of the stove, the use of wood pellets certified by an accredited body is
recommended. Use of pellettypes other than those defined by the manufacturer may cause defect of the stove and annul the
warranty.
When loading the pellets, take care to avoid dropping of pellets by accident into some other internal part of the product
other thanthe corresponding tank.
CAUTION: If you are unable to light the stove, it will be necessary to empty the burner.. If you do not perform this
procedure, excessively strong burning may occur, which may lead to the occurrence of significant quantities of smoke.
CAUTION: Do not open the door and do not switch offthe electric cable during the phases of ignition or extinguishing,
or while the stove is in operation, even if the combustion chamber is blocked or too loaded; initiate the extinguishing
procedure and wait until the stove completes the operation phases beforeyou solve the problem. Do not try to ignite the
stove again until the problem is solved.
CAUTION: Do not disturb the process of extinguishing the stove (for example, by switchingoff the electric cable)until it
is completed.
CAUTION: If the wood pellets are accumulated in the combustion chamber until the device is operational,
immediately switch off the device and switch it on usingthe program of larger ventilation. If the pellet continues to
accumulate, try using a different type of wood pellet or call an authorized service technician.
CAUTION: Never feed pellets manually into the burner.
CAUTION: To prevent possible accidents, always follow the instructions for proper use found in this manual for the
device and its electrical components.
CAUTION: Installation, networking, control, maintenance and repair procedures can only be performed by qualified
personnel.
CAUTION: The product must be installed with fulladherence to the applicable legal standards.
CAUTION: Always adhere to the safetyrecommendations and safety standards which this manualrefers to.
CAUTION: Anyone who performs intervention onthe productmust read and fully understand the content of this
manual in advance and must be fully acquainted with the control panelof this product.
CAUTION: The product may be used, changed, and programmed only by adults. Incorrect or arbitrary adjustments can
lead to dangerous situations or failures.
CAUTION: ALFA PLAM a.d. shall not bear any civil orcriminal liability fordamages in the event that the product is
subjected to unauthorised repair or replacement of parts.
CAUTION: While the product is in operation, some of its surfaces can reach extremely high temperatures. Therefore,
the user is recommended to undertake all necessary pre CAUTION measures, especially whenchildren or adults or
disabled persons are present.
CAUTION: Do not cover or choke the hot airdischarge in any way. Do not cover the product with cloth or any similar
material.
CAUTION: To avoid accidental overturning of thedevice, never lean or place excessive weight on the open door while the
cleaning procedure is in progress. Avoiding of such a type of pressure and undertaking the necessary measures of pre
CAUTION is recommended, especially when children or adults or disabled persons are present.
General recommendations
CAUTION: Never use the product forpurposes other than those for which it is designed and manufactured.
CAUTION: The product should not be used for cooking.
CAUTION: The product should not be used in caseof occurrence of any defect or failure. In such a case
immediately disconnect the power cord of the product from the wall socket.
NEVER leave the product door openedwhile it is functioning.
Flue pipes should be regularly inspected.
NEVER use steam for the product cleaning.
Always refer to qualified and authorised stafffor any servicing that may be necessary. Use only original spare parts
forreplacement.
Fuel can be loaded into the hearth only through theautomatic loading system, not directly by the user.
CAUTION: In case of “failed ignition”, allpellets settled in the hearth must be removed before Environment for
use
CAUTION: The device must be installed in a ventilatedenvironment, it must be provided with sufficient air for
combustion, in line with applicable regulations.
This is important for securing its proper operation.
CAUTION: The room should be of the volumenot less than 20 m3 and should possess all the necessary
ventilation conditions, as described in the Section 2 of this Manual. These conditions shall provide the necessary air flow to
enable proper combustion (40 m3/h).
It is FORBIDDEN to use the product in bedroomsand bathrooms.
It is FORBIDDEN to use the product in rooms inwhich another heating device, which does not have its own system for
air entry, is installed.
It is FORBIDDEN to install the product nearflammable materials.
It is FORBIDDEN to install the product on a floormade of flammable materials unless a protective sheet made of fire-
proof material is used.
It is FORBIDDEN to use the product in explosiveor potentially explosive atmospheres.
The new ignition of the stove is tried. The pellets removedfrom the hearth should never be returned to the tank.

5
This manual must be considered an integral partof the product and must be used during its full useful time. It
must be kept at a safe place. If the Manual is lost or damaged, ask for a replacement copy from your seller.
Environment for use
CAUTION: The device must be installed in a ventilated environment, it must be provided with sufficient air for combustion,
in line with applicable regulations. This is important for securing its proper operation.
CAUTION: The room should be of the volume not less than 20 m3 and should possess all the necessary ventilation
conditions, as described in the Section 2 of this Manual. These conditions shall provide the necessary air flow to enable
proper combustion (40 m3/h).
It is FORBIDDEN to use the product in bedrooms and bathrooms.
It is FORBIDDEN to use the product in rooms in which another heating device, which does not have its own system for
air entry, is installed.
It is FORBIDDEN to install the product near flammable materials.
It is FORBIDDEN to install the product on a floor made of flammable materials unless a protective sheet made of fire-
proof material is used.
It is FORBIDDEN to use the productin explosive or potentially explosive atmospheres.
INSTALLATION
To install the product successfully and avoid the occurrenceof failures, we give you below a number of simple advice for
assembling, in line with applicable relevant regulations. You must adhere to all local and national laws and the European
standards when installing, using and maintaining the device.
Placing the device
Our product produces heat by entering air necessary for the combustion process directly from the environment that is to
be heated.
For this reason, as well as for the reason of safety of users of the stove, the device has always to be installed within an
adequately ventilated environment to ensure a constant flow of air for combustion. Therefore, it is necessary to install
openings for the air intakethat is connected to the outside air (as shown in the Figure 2.1).
The openings for the air intake must have the following properties:
1. They must have internal cross-section not smaller than 80 cm2;
2. They must be placed at the approximate floor height;
3. They must be appropriately protected with a wire mesh ora grate in order not to decrease the minimal condition of the
radius for the air flow;
4. They must be installed so as not to be blockedin any way
5. Proper flow of fresh air can also be provided by using an opening to the adjacent room, if it is a room equipped with
direct ventilation and if it does not present a risk of fire, such as a warehouse, garage, or storage area.
You are recommended to avoid installation of the heatingdevice in rooms where there are devices that cannot operate in
a closed mode relative to the environment or in rooms where there are devices that can decrease the pressure inthe room
itself relative to the outside environment, since it can lead to problems of poor intake of air for our product.
CAUTION: It is forbidden to place the stove in a common chimney..
During the check of the system compatibility, you are recommended to verify that the supporting area (the floor) has the
adequate weight capacity (kg) to withstand the weight of the product. If this is not so, you are recommended to undertake
adequate safety measures (e,g.use of a panel for the weight distribution).
CAUTION: Place the external parts of the stove at a distance from any fuel or flammable material: 30 cm from the rear,
30from the lateral and 80 cm from the front side. Ifkeeping of theabove distances is not possible, please provide
corresponding thermal protection.
Figure 2.1: Example of required air intake openings
CAUTION: Never allow the flammable materials to get close to each other, or even get intocontact with theexternal surfaces of
the combustion chamber, since they may reach extremely high temperatures while the product is operational.
CAUTION: If the floor is made of flammable material (e.g. hard wood), you are recommended toprotect it by placing a layer
of non-combustible material below and around the stove.
During the installation phase, pay attention that the electrical cable is accessible when the installation is completed.
⚠CAUTION: The electrical cable must be equipped witha corresponding earthing terminal.

6
CAUTION: Avoid touching the electrical cableswith wet hands.
Figure 2.2: Maximum safety distance of the combustionmaterial [cm]
CAUTION: After determining the place where you will place the stove, it is possible to adjust the legs on the side of the
stove to achieve the desired height.. Twopersons are needed for the lateral movement of the stove. After you adjust the legs,
place down the stove very carefully.
Characteristics of the flue pipe
Main properties of the flue pipe are listed below:
-Inspection opening (I);
-Maximum height of the pipe directly connected to the opening of the flue exit on the stove must be 2 to 3 m;
-If you need a horizontal segment, please do not exceed 1.5 m in length and a slope of 3 to 5% in order to facilitate the
exit of smoke;
-Use a wind and water resistant end piece on the flue to minimize the change in draft value.
Use the end part that is resistant to wind and waterto prevent change of the state of somewhat larger pressure
of the flue pipe itself (do not place a horizontal part at theend of the flue pipe);
The state of somewhat larger pressure of the flue pipeis needed to make easier flow of the smoke from the combustion
chamber towardsthe outside environment.
Have in mind that any removal of excessive heat ismade by the electrical controlpart (modulation, extinguishing, etc.).
-The exhaust channel must be made of materials that are resistant to the products of combustion and to moisture (the
check shall enable removal of any kind of moisture);
-The channels should be manufactured in such a way as toprevent any smoke leakage;
-The channel should be insulated, especiallythe external part that is exposed to weatherconditions.
Avoid using completely horizontal segments.
Figure 2.3: Exhaust channel
The room where the heating system is to be installedshould not have hoods since they may reduce the pressureof the
environment.
Closing of air openings is strictly forbidden.
The exhaust channel must be cleaned at least once ayear; we recommend thorough cleaning of both the exhaust
channel and its connections.
After a period of inactivity and before the start,check that there is no congestion.
CAUTION: The exhaust channel must be constructed in line with the provisions of applicableregulations.
CAUTION: Check with the appropriate tool whether the chimney has a minimum (draft) of 10 Pa.
One of the solutions that may be applied includes installation of the wood pellet stove near the external wall ofthe house
tolet the exhaust gases escape directly to the outside environment. (Figure 2.4). Some notes highlighted by the standard for
30
30
30
80

7
this type of system configuration are given below:
-Always ensure that there is an inspection opening (I) to allow for regular cleaning procedures as well as the removal of
moisture that may form.
-The chimney pot (T) must be made so as to be resistant towind and water;
-Pay attention that the chimney is properly insulated in the part that passes through the wall.
If the flue is located entirely outside, it must be made of double wall stainless steel to ensure greater resistance to
atmospheric conditions, as well as the correct temperature of the exhaust gases themselves.
Figure 2.4: Smoke exhaust toward the external wall
Flue gases of a stove may be removed via a traditional, already constructed chimney (Figure 2.5), if it meets the applicable
standards. The main properties of a good chimney (Т) are concisely listed below:
-Proper insulation, first of the external part that is exposed to atmospheric conditions;
-Constant internal diameter (there must be no segments with a smaller diameter);
-It must be made of material that is resistant to high temperatures, to the effects of the combustion product and to
corrosion effect of the moisture that may be formed;
-Mainly vertical position, with no deviations ofvertical angles exceeding 45°.
We recommend that the base of the chimney is equippedwith a chamber for collecting of solid particles or moisture(R).
The chamber must be accessible via hermetical door (I).
Figure 2.5: Smoke exhaust towards the roof viatraditional chimney
It is recommended to follow the guidelines established by the standards UNI 9615 and UNI 9731 in relation to the size
and diameter of the chimney (T). However, never use an exhaust duct with an internal diameter of less than 100 mm.
In the case of exhaust ducts with a larger diameter, a steel pipe (A) must be placed inside the brick or mortar of the
chimney (C), as shown in Figure 2.6.

8
Figure 2.6: Example of the connection with the chimney
In case of fire in the chimney or the flue pipe, immediately extinguish the stove and disconnect it from the power system.
Disassembling and waste disposal
The packaging consists of materials that are not toxic or harmful. There is no need for special conditions for its
disposal. Disposal of other components of the packaging is the responsibility of the user. He/she must perform
corresponding disposal procedures in line with applicable standards in the country where the product is installed.
CAUTION: Packaging elements must be kept out of the reach of children not supervised or persons withdisabilities.
Electrical connections
Connect the product to your household power supply.
Just press the main switch on the back of the device if you want to turn on the device. After you do this, the stove is
ready for ignition. For processes ofignition and programming, refer to Section 3.1.
Room temperature measuringdevice
The room temperature meter allows the temperature in the room where the stove is installed to be continuously
monitored. This device enables permanent monitoring of thetemperature in the room where the stove is installed.
Installation of the room temperature measuringdevice at an appropriate place shall enable proper workof the product.
Electrical scheme of connection
For completeness, the electrical scheme of connection is provided. The sheme is specifically intended for technical
personnel responsible for installation and maintenance.
CAUTION: The main switch does not guarantee that the stove will be disconnected from the power supply. Therefore,
the cable of the stovemust be disconnected fromthe socket before the coverings or screws that hold the section of the
integrated circuit in place are removed.
In order to test the electronic card, it is necessary to remove the coverings on the left side.

9
* Optional terminals
USING THE PRODUCT
Before we describe in detail the operation of the product, we would like to remind you that, while using it, you must
observe the relevant national and local provisions, rules and applicable laws. For a better understanding of how the
product works, diagrams of the display control panel are shown, followed by a detailed description, as well as what needs to
be done to start the stove for the first time. The product is easily ignited whenthe electrical cable is connected and the
button IGNITION is pressed.
To ignite the stove, connect the electrical cable to thepower socket and press the ignition button on the rear
During the several first ignitions of the stove, vapours and unpleasant odours may spread from painted parts.
Theseinconveniences are a necessary result ofthe process of chemical stabilisation of special dyes that are used; therefore,
good venting of the room is necessary in this phase.
CAUTION: Pay attention for the door of the stove to be closed while the product is operational.
CAUTION: Although surface temperatures reached by our product are not excessively high, you are recommendedto be
careful when touching them. Especially the external surfaces of the combustion chamber can reach high temperatures during
long-term use.
CAUTION: Place the external part of the stove at a distance from any fuel or flammable material: 30 cm from the rear, 30
cm from the lateral and 80 cm from the front side. If keeping of theabove distances is not possible, please provide
corresponding thermal protection.
To avoid failures that may lead toinjuries and damages to persons or property, you are recommended to avoidsudden
and constant ignition and extinguishing of the product, but to follow the schedule provided by the manufacturer for these
procedures.
CAUTION: The house wiring must be equipped with grounding (in good condition), otherwise the electronic card may
malfunction.
We recommend not to use the stove in an instable supply mode: continuous power cutsmay lead to failures.
You are recommended to clean the chimney and theconnections with the flue pipe thoroughly (at least once during the
whole heating season)in order to prevent the risk of fire.
Pay attention that the door of the stove isclosed while the product is operational.
Any unauthorised change on the deviceis forbidden.
Use only replacement parts recommended by themanufacturer.
First ignition
Pay particular attention to cleaning the burner before starting the ignition process and check whether the braid under the
burner is tight, i.e. whether it rests with its entire surface on the burner support.

10
Proper operation of the device is performed when there isno uncontrolled air inlet; therefore, the door SHOULD be firmly
closed and, in the same way, it is necessary to check whether all other ways are closed except the intended one. Therefore, it
is a good habit to check that the door seal adheres well to the chamber, over its entire circumference (whether it seals well).
Regulation related to the installation of pellet products EN14785 provides that it is necessary to have a vacuum of10 Pa on
the basis of the chimney, so special attention must be paid to the smoke removal system. If the chimney is lower, if there are
too many flue pipes, the air intake required for combustion (which can change and affect the combustion itself) is also lower.
The lower and more bended the flue pipe is, the lower the air intake required for combustion (which may change and affect the
combustion itself). Slow smoke flow incertain cases may cause the increase of temperature that creates a change ofthe
operating power.
Since there are different types of pellets in the market, the operation of the product must be adjusted for the specific type
of fuel that will be used.
To allow the user to adjust the stove for different pellet typesand different installation types, the user’s menuoffers four
types that are indicated in the ascending order from 1 to 4. The ascending order of the type indicates the higher ventilation of
the system. In the extreme case, if neither of the factory types provides efficient combustion, it should be remembered that
the operating parameters can be changedONLY with the support of specialized technicians of ALFA PLAM a.d. who will
specifically analyses the situation and provide the best solution for any case.
In order for the stove to heat up properly, it is recommended that you set the power of the product to value "4" or to value
"5" during the ignition phase and a few minutes after.
To provide more assistance to the user, please find below a sequence of steps that should be undertaken in order to switch
on the product.
1) Fill the tank with pellets to the optimal level. We recommend that you do not completely fill the part for fuel intake,
the optimal level is achieved by adding fuel until it touches the grid with openings in the tank..
2) Connect the product onto the power socket.
3) Press the switch at the rear of the stove.
4) Follow the instructions described in section 3.3.
CAUTION: Do not place your hand for whatever reason inside the auger for loading of pellets while the stove is
operational.
CAUTION: Do not open the door or disconnect the stove from the power socket, even if there is a blockage or
accumulation of fuel in the burner.. Initiate the extinguishing process and solve the problem before you initiate again the
ignition process.
EXTINGUISHING OF THE PRODUCT
Press and hold the Ignition button for a few seconds. The stove shall initiate the extinguishing process as set in the
planning phase (the extinguishing interval is variable andmay take a few minutes).
CAUTION: You are recommended not to interrupt theextinguishing process before it is fully completed by, for
example, disconnecting the product from the power socket.
If the flame goes out due to the lack of pellets, switch off the stove. You need to put more fuel in the tank and restart
the ignition process only when it is off.
It is forbidden to insert pellets into the burner by hand.
CAUTION: The door of the stove must always be closed when you are using it; its opening is allowed only for the
purpose of maintenance, when the productis cold.
Change of the stove is not possible.
Unsolicited repairs, as well as the useof spare parts that are not genuine or unauthorized replacement of parts of
the product, as well as thecancellation of the warranty may lead to failures andserious risks for users who are in
direct contact withthe product.
CAUTION: During the use, please avoid to cover thevents that enable uninterrupted flow of the combustion air and the air
slot on the rear side of the product.
Safety devices
The product is equipped with the following safety devices:
•Thermostat for determination of the tank temperature: this device switches off the operation of the product any
time the set safety limit is exceeded;
•Device for measuring the smoke temperature: this element determines the smoke temperature and constantly
monitors the proper operation of the product;
•Pressure switch: this element determines whether there is a clogging of drains, i.e. flue pipes;
•Ambient thermometer: this element constantlymonitors the temperature in the room where the stove is located;
•Operation modulation mode: if the smoke temperature exceeds the set safety threshold, the device automatically
decreases the quantity of pellets for combustion until thetemperature drops below the set limit.
Incorrect parameter settings can lead to exceeding the safety limits and can lead to excessive consumption of pellets.
Exceeding of the safety limits may also occur due to the poor ventilation of the environment where the stove islocated, which
do not provide sufficient cool air for the device.
Safety devices MUST NOT be switched off. When the cause for activation of the safety system is eliminated,the device
can be started again in order to restore its proper functioning.
CAUTION: The device must be installed so as toprovide easy access to its electrical cable.
Note: The section on safety is composed taking into accountnormal conditions for the use of the product, which are
described and detailed in Section 3. ALFA PLAM a.d. shall not be held responsible for any personal injuries or damage of
property that can result from the use of the stove contrary to the conditions given in this User’s Manual. In addition, ALFA
PLAM a.d. shall not be held responsible for any personal injuries or damage of property if the user fails tocomply with the
following instructions:
A) All necessary measures and pre CAUTIONs must be takento secure that no party starts the equipment during repair,
setting, replacement of parts, or maintenance works;
B) Do not remove or replace any safety device on thestove;
C) The device must be connected to a properly functionalsystem for smoke removal;

11
D) Check whether the environment in which the device isinstalled is ventilated sufficiently, as prescribed in this
Manual.
The control panel (display): use and features
The main frame shows:
time and date, chrono
activation, combustion
energy, heat energy,
functional state, current
room temperature, set
room temperature, LEDs
Display
Meaning
Main Temp.
The current value of the room temperature
State
Functional state of the furnace
Main Therm.
Set room temperature
Comb. Power
Combustion power
Heat Power
Heating power
Time
Time
Chrono
Scheduled operation
Push button
Feature
P1
Exit menu/submenu
P2
Turning on and off (hold down for 3 seconds), reset errors (hold down for 3 seconds), chrono
activation and deactivation
P3
Enter the user menu 1/submenu, enter the user menu 2 (hold down for 3 seconds), saving data
P4
Enter the visualization menu, maximizing
P5
Enter the visualization menu, minimizing
Led
Feature
Led
Feature
Lack of pellets
Preset room temperature reached
The direction of air flow
Remote thermostat temperature
reached (if connected to the remote
thermostat)
Description
System state
Code
Safety error - safety thermostat: signals when the system is off
Block
Er01
Safety error - pressure switch: signals only if the combustion fan is turned on
Block
Er02
Shutdown in case of flue gas temperatures lower than permissible
Block
Er03
Shutdown in case of flue gas temperatures exceeding the permissible
temperatures
Block
Er05
The pellet thermostat is activated
Block
Er06
Encoder fan error: no encoder signal
Block
Er07
Encoder fan error: failed combustion fan regulation
Block
Er08
Date and time are not correct due to a prolonged power outage
Block
Er011
Ignition failed
Block
Er012
Power outage
Block
Er15
Communication error - display disconnected
Block
Er16
Air flux regulator error
Block
Er17
No more pellets
Block
Er18
Faulty air flux sensor
Block
Er39
The minimum air flux is not reached during the testing phase
Block
Er41
Maximum airflow reached (F40)
Block
Er42
Error: door open
Block
Er44
Auger encoder error: no encoder signal
Block
Er47
Auger encoder error: auger speed control failed
Block
Er48
Module error I/O 12C
Block
Er52
Service error. This informs that the planned period of operation has been
reached (after preload): the system will stop when it goes into operation
mode.
Block
Service
Description
Code

12
Probe error when controlling during the testing phase
Prob
This informs that the planned period of operation has been reached. It is necessary to clean the
furnace or boiler.
Clean
Door open
Door
The message appears if the system is turned off during ignition (after preload) by the external device:
the system will stop when it goes into operation mode.
Block ignition
No communication between the motherboard and the display (keypad).
Link Error
Periodic cleaning is in progress.
Cleaning On
Pressing P4 and P5 opens the visualization menu.
Here you can see the value of the ambient temperature, flue gases, engine speed of flue gases, ON auger time*, etc, at all
times. The following indicators of the furnace operation can be checked in the visualization menu:
Display
Description
Exhaust T. [ºC]
103
Flue gas temperature
Room T. [ºC] 25
Local room temperature
Rem. Room T. [ºC] 25
Remote room temperature; visible only if the remote thermostat is active
Air Flux 750
Air flux; visible if the primary air flux gauge is active
Fan Speed [rpm]
1250
The exhaust gas fan speed;
Auger [ºC] 1.2
ON auger time;
Cleaning [h] 450
Work time left before cleaning the furnace; visible only if the timer is active
Work time [h] 2985
Total furnace work time in the work mode, modulations and security
Ignitions [h] 106
Number of ignition attempts
Product Code: 494- 0000
Product code
User menu 1
Short press P3 to activate user menu 1.
Keys P4 and P5 list different submenus (combustion management, heating management ...); pressing the P3 key opens
any selected submenu.
Combustion Management
Power
In this submenu it is possible to modify the power of the combustion system. Keys P4
and P5 select between the 5 powers (Power 1, Power 2, Power 3, Power 4 and Power 5).
When you select the desired power press the P3 key to confirm. Exit the submenu by
pressing P1.
Auger Calibration
Allows modification of the set value for the duration of the ON auger time. The values
range from -7 to 7. The default value is 0 (see Section 4.6.2)
Fan Calibration
Allows modification of the set value for the speed of the flue gas engine. The values
range from -7 to 7. The default value is 0 (see Section 4.6.3)
Heating Management
Room Thermostat
This menu allows modification of the set temperature value in the local room (the
room where the furnace is assembled). The temperature value set up in this menu is a
requirement for furnace operation. Namely, the furnace will work in the selected mode
until it reaches the preset value of the room temperature. When the preset value is
reached then the furnace goes into a modulation state or it works using minimum power.
The furnace exits the modulation state and returns to the mode of normal operation as
soon as the room temperature falls below the preset value. The temperature value is set
up using the P4 and P5 keys and then the set value is confirmed by pressing P3. Exit the
submenu by pressing P1.
Remote Room Thermostat
This menu allows you to modify the value of the thermostat in a distant room. It is
visible only if the external thermostat is installed, while a heating plant that uses it is set
up to use an external thermostat.
Remote Control
This menu allows turning the remote control options on and off.
Chrono
Chrono program
It is used for scheduling operation of the furnace and for turning the furnace on and off
in certain time periods.
Manual Load
This procedure activates the manual loading of pellets with the activation of the preset
modality of the auger engine. Loading stops automatically after 600 seconds. The system
must be turned off in order for the function to be activated.
Cleaning Reset
Menu for resetting the "System Maintenance 2” function. Visible only if the option
“System Maintenance 2” is active.
In order to adjust the programmed operation of the furnace it is necessary to access the Chrono menu.
The Chrono menu is accessed in the following manner:
-Short press P3 to activate user menu 1.

13
-Press P4 and P5 to list the submenus until you reach the Crono submenu.
-Press P3 once again and enter the Chrono submenu
-The following is shown on the display:
Chrono
Modality
Chrono program Program
Modality
Chrono program
Press P4 and P5 to select the Modality or Chrono program and then press P3 to enter one of the two submenus.
3.4.1.1 Modality
Allows selection of desired modality or disables all set programs.
Programming is enabled or disabled by pressing P2
Use P4 and P5 to select the desired way of programming the Daily, Weekly
and Weekend furnace operation.
Pressing P3 confirms the selected way of programming furnace
operation.
Save your settings by pressing P1.
Disabled
Daily Weekly
Week End
3.4.1.2 Chrono Program
Chrono program provides three types of programming: daily, weekly and weekend programming.
The following is shown on the display in the Chrono Program:
Chrono
Modalit
y
Chrono
program
Pprogram
Daily
Weekly
Week-end
The system provides three types of programming: daily, weekly and weekend programming. Selection is made by
pressing P4 and P5 after which the user enters the selected program by pressing P3.
1. Daily Programming
The following is shown on the display once the Daily submenu or the daily program is entered:
Days of the week are selected by pressing P4 and P5. When you select the date press P3.
Setting the activation and deactivation time of the program for the selected day is done as follows:
Enter the change of time (the preset time is blinking) by pressing P3.
Change the time by pressing P4 or P5.
Save by pressing P3.
Activate ("●”appears) or deactivate the time period ("○”remains) by pressing P2.
Example: For example, select Monday and press P3. Then press P3 and ON time (time of turning on of the furnace)
starts blinking. By pressing P4 and P5 you can set up the desired ON time and confirm it by pressing P3. In this way ON
time can be set up to, for example, 9:30 AM. When ON time is set up press P5 and then the OFF time (time of turning off of
the furnace) starts blinking. By pressing P4 and P5 you can set up the desired OFF time and confirm it by pressing P3. In
this way OFF time can be set up to, for example, 11:15 AM. In the end press P2 in order to activate the program. The
following is shown on the display:
Daily
Monday
ON
OFF
●09:30 -
11:1
5
○00:00 -
00:0
0
○00:00 -
00:0
0
This program schedules the furnace to turn on on Monday at 9:30 AM and turn off at 11:15 AM.
Save your settings by pressing P1.
For daily programming it is possible to switch the program from the previous day to the next day.
The procedure is as follows:
Select the day of the week for programming and setting up the turn on and turn off time.
Set the clock to ON on the previous day at the desired time: e.g., 8:30 PM.
Set the clock to OFF on the previous day at 11:59 PM.
Set the clock to ON on the next day at 12:00 AM.
Set the clock to OFF on the next day at the desired time: e.g., 6:30 AM.
The system will turn on at 8:30 AM on Tuesday and will turn off at 6:30 AM on Wednesday.
2. Weekly Programming
In terms of weekly programming, programs are the same for all days of the
week.
Weekly
Mon-Sun

14
The following is shown on the display once the Weekly submenu or the weekly
program is entered.
The programs are activated and deactivated in the same way as with the daily
programming.
3. Weekend Programming
In terms of weekend programming it is possible to choose between programs:
-Mon-Fri
-Sat-Sun
Selected programs will be active from Monday to Friday or Saturday and
Sunday.
The programs are activated and deactivated in the same way as with the daily
programming.
ON
OFF
○00:00
00:00
○00:00
-
00:00
○00:00
-
00:00
Week-end
Mon-Fri
ON
OFF
○00:00
00:00
○00:00
-
00:00
○00:00
-
00:00
User Menu 2
Long press P3 (3 seconds) to activate user menu 2.
Keys P4 and P5 list different submenus ((Keyboard Settings, Keyboard Menu ...); pressing P3 opens any selected
submenu.
Keyboard Settings
Time and Date
Used for setting up the day, month, year and current time.
Language
Menu for changing the language
Keyboard Menu
Learn Menu
Allows manual updating of the menu; access is protected by a four-digit password
and the procedure cannot be stopped once it is started. In the event of a failed save or
change of the menu, this procedure starts automatically.
Set Contrast
Menu used to regulate the contrast of the LCD screen.
Set Minimum Light
Menu used to regulate the brightness of the LCD screen when controls are not used.
Keyboard Address
This menu is password protected and is not available to the user.
Node List
This menu displays the following: table communication address, table typology,
firmware code and firmware version. Data cannot be changed. Table typology that can
be displayed are as follows:
MSTR Master INP KEYB OUT
CMPS composite SENS Sensor COM Communication
Acoustic Alarm
Allows enabling or disabling of the keyboard alarm.
System menu
Menu for entering the technical menu. This menu is password protected and is not
available to the user.
Turning the furnace on and the state function
The furnace is turned on by long pressing P2 for 3 seconds. After that come the next function states of the furnace:
During the check up phase the initial checks of the input signals or the probity of safety probes and pressure switches of
the furnace are done. In this phase the flue gas engine runs at maximum speed while the auger and igniter are turned off.
The check up phase lasts for a few seconds, and a successful check up is followed by the ignition phase.
The ignition phase consists of four sub phases which alternate, and those are:
- Preheating phase
- Pellet preload phase
- Fixed ignition phase
- Variable ignition phase
The message IGNITION is displayed during the entire ignition phase. There are no special markings on the display for
sub phases.
3.6.2.1 Ignition Preheating
At this stage there is warming of the igniter before dispensing of the pellets starts. In order for pellet burning to be as
efficient as possible, it is desirable that the igniter is already preheated at the time when dispensing the pellets starts. At
this stage the igniter is active and the auger is inactive. Flue gas engine runs on lower rpm in order to promote heating of

15
the igniter.
3.6.2.2 Ignition Preload
In this phase there is the initial dispensing of pellets or the auger loads a certain amount of pellets necessary for
ignition. In this phase the igniter, auger and flue gas engine are active.
3.6.2.3 Ignition –Fixed Phase
This phase is a fixed time period that lasts for 180 seconds and in case that the furnace ignition requirement is reached
before the expiry of this phase it will always last until the end and only after the expiration of the fixed time period will the
furnace move into stabilization phase. In this phase the igniter, auger and flue gas engine are active.
3.6.2.4 Ignition –Variable Phase
This phase occurs after the fixed ignition phase. The duration of this phase is a variable period that lasts until the
moment of fulfillment of the ignition requirements or until the moment when the flue gas temperature of 50 °C is reached. In
case the furnace ignition requirement is met before the expiry of the duration of this phase, it is stopped and the next phase
follows, which is the stabilization phase. In this phase the igniter, auger and flue gas engine are active.
The stabilization phase is a transitional phase between the ignition phase and the run mode phase. This phase occurs
when the ignition requirement is met, that is, when flue gas temperature reaches 50 °C. It lasts for three minutes and during
that time the auger, flue gas engine and the igniter are active.
The normal run mode begins following the stabilization phase. In this phase there are five levels of power that can be set
up as explained in the user menu 1. In this phase the igniter is turned off while the auger, flue gas engine and area engine
are active and run with different intensity depending on the level of power of the furnace. The furnace runs on the given
power until the modulation requirements are met.
The furnace goes into the modulation phase when one of the two conditions are met:
1. When the furnace reaches the preset ambient temperature
2. When the flue gas temperature reaches a value greater than 250 °C
In the modulation phase the furnace runs on minimal power - power 1, until the moment when the temperature
decreases below the threshold value.
The Safety status occurs when flue gas temperature exceeds 275 °C. In this phase dispensing the pellets stops until the
temperature of flue gases decreases. If there is no decrease in temperature in the next 60 seconds the furnace goes into an
alarm stage and displays the Er05 message.
The furnace is turned off by long pressing P2 for more than 3 seconds. The extinguishing phase occurs next during
which dispensing of pellets stops and the flue gas engine and the ambient fan operate at maximum capacity in order for the
furnace to cool down as soon as possible. Minimum duration of the extinguishing phase is 30 seconds and the requirement
for the furnace to completely turn off is for the flue gas temperature to be less than 68 °C.
During this phase the furnace is turned off, that is, no furnace output (flue gas engine, ambient fan, igniter and auger) is
active.
The block state occurs in the event of a fault or alarm. In the block state the exhaust gas fan, auger and igniter are
turned off. To exit press P2 for 3 seconds: if there is no more block and no cause for alarm the system will turn off.
The furnace goes into this phase in two cases:
1. If there is a power failure in the operating mode and the flue gas temperature is greater than 50 °C.
2. By pressing the main switch at a time while the furnace is in the extinguishing phase.
Other functions
In the absence of power, the system keeps the most important functional data. When the power is restored the system
evaluates the saved data and:
If the furnace is turned on and the temperature of exhaust. gases is greater than 50°C, the system enters
the recovery point. Pressing P1 can lead to a sudden new system ignition.

16
If the furnace is turned on but the temperature of exhaust. gases is lower than 50°C, the system enters the
shutdown point with error Er15.
If the furnace is turned off or in extinguish or block phase, the system returns to its previous state.
In the absence of power for more than a week the system goes into block with an error message Er11
indicating that the DATE/TIME values are incorrect. When P1 is enabled the TIME value starts to blink signaling the
need for updating the TIME and DATE with the CLOCK function.
The user has the option to calibrate the dispensing of pellets in the user menu 1. Calibration ranges between -7 ÷ 7.
1=5%. Each calibration of dispensing the pellets is applied to all workforce in percentages. For example, if -1 is set up then
the dispensing of pellets will be reduced by 5% in all operating modes (Power 1 - 5).
Example
Before calibration
Power 1 = 2.0
Power 2 = 3.0
Power 3 = 4.0
Power 4 = 5.0
Power 5 = 6.0
Step = -1
Power 1 = 1.9
Power 2 =
2.85
Power 3 = 3.8
Power 4 = 4.75
Power 5 = 5.7
Never calibrate dispensing of pellets without consulting with the service center first.
The user has the option to calibrate the rpm of the flue gas engine in the user menu 1. Calibration ranges between -7 ÷
7. 1=5%. Each calibration is applied to all workforce in percentages. For example, if it is set up to 3 then the rpm of the flue
gas engine will be increased by 15% (3x5%) in all operating modes (Power 1 - 5).
Example
Before
calibration
Power 1 = 1000
Power 2 = 1200
Power 3 = 1400
Power 4 = 1600
Power 5 = 1800
Step = +3
Power 1 = 1150
Power 2 = 1380
Power 3 = 1610
Power 4 = 1840
Power 4 = 2070
Never calibrate the rpm of the flue gas engine without consulting with the service center first.
In the event that the temperature in the pellet tank reaches the value higher than 90 °C, the safety thermostat activates
in order to prevent the ignition of pellets in the tank. The system goes into block mode and there is an alarm message Er01.
When the system is stable after a specified time interval (every 45 minutes), the system automatically performs periodic
cleaning which lasts for 30 seconds.
During the periodic cleaning, the flue gas engine works with increased intensity while dispensing of pellets stops.
When the system shuts down during the ignition phase (after the preheating phase) through an external device or an
internal chrono device, the system goes into shutdown mode when it enters running mode at the end of ignition phase.
Message Block ignition is shown on the display.
If an error occurs, the system immediately goes into shutdown; if P2 is pressed, it is possible to immediately introduce
the system into the turning on or off.
Possible problems and solutions (Troubleshooting)
Message on
the display
Description
Possible causes
Resetting errors
Possible solution of alarm
causes
Er01
Activation of the safety
thermostat
High temperature inside
the furnace
Wait until the
furnace has cooled
and then unscrew
the plastic cap on
the thermostat and
press the reset
button
Check the heat sink and
check that there is no
obstacle for the hot air to get
out
Too high a temperature in
the room where the
furnace is assembled
Contact the service center
Faulty thermostat
Er02
Activation of the safety
pressure switch
Obstruction of flue gas
drain
Press and the P2
key for more than 3
seconds
Check contamination of flue
pipes and funnel
Incorrect funnel
installation
Contact the service center
Faulty pressure switch
Er03
Shutting down due to
very low flue gas
temperatures
Poor combustion (too few
or too many pellets
remain in the combustion
chamber)
Wait for the furnace
to shut down and
then press P2 for
more than 3
seconds
Check the size of the pellet
granules
Check for contamination of
the furnace chamber
Empty pellet tank
Check the status of flue pipes
Faulty flue gas probe
Contact the service center
Er05
Shutting down due to
very high flue gas
temperatures
The temperature of flue
gases exceeds the limit
Wait for the furnace
to shut down and
then press P2 for
more than 3
seconds
Insufficient heat transfer -
contact the service center
Obstruction of flue gas
drain
Check contamination of the
flue drain and funnel
Faulty flue gas probe

17
Er07
Encoder error
Missing encoder signal
Wait for the furnace
to shut down and
then press P2 for
more than 3
seconds
Contact the service center
Er08
Encoder error
Flue gas engine is not
responding
Wait for the furnace
to shut down and
then press P2 for
more than 3
seconds
Contact the service center
Flue gas engine operates
at a speed that is different
from the set speed
Er011
Clock error
Problems with the internal
clock
Press and hold P2
for more than 3
seconds
Check the accuracy of the
preset time
Insufficient capacity of
the internal battery
Check the correctness of
programming in the Chrono
mode
Contact the service center
Er012
Ignition failed
Ignition error
Wait for the furnace
to shut down and
then press P2 for
more than 3
seconds
Check the state and quality of
the used pellets
During the ignition phase
adequate temp. of flue
gases is not reached
Check contamination and
draft of the flue drain
Faulty flue gas probe
Contact the service center
Er15
Interruption of power
supply
Loss of power supply
during furnace operation
Press and hold P2
for more than 3
seconds
Check to see if the system
and installation are in order
Contact the service center
Er16
Communication error
between the
electronics and the
display
Interruption of the display
cable
Press and hold P2
for more than 3
seconds
Check the cable and display
cable connectors
Damage to the display
cable connector
Contact the service center
Er17
Primary air flux meter
error
Primary air flux meter
does not adjust the
operation of the furnace
The furnace
continues to run
without adjustment
of primary air.
Turn the furnace off
to reactivate the air
flux meter. Wait for
the furnace to shut
down and then
press P2 for more
than 3 seconds
Check pipe contamination for
primary air inlet
Check contamination and
draft of the flue drain and
funnel
Contact the service center
Er39
Primary air flux meter
sensor is damaged
Faulty sensor
The furnace
continues to run
without adjustment
of primary air
Contact the service center
Er41
The minimum primary
air flux is not reached
during the testing
stage
There is an obstacle or
large contamination in the
pipe for primary air inlet
Wait for the furnace
to shut down and
then press P2 for
more than 3
seconds
Check and clean the pipe for
primary air inlet
Check contamination and
draft of the flue drain and
funnel
Obstruction of flue gas
drain
Doors not properly closed
during the ignition phase
Check if the doors close well
Contact the service center
Er42
Primary air flux is
greater than the
maximum permissible
value
Too much air intake
Wait for the furnace
to shut down and
then press P2 for
more than 3
seconds
Check the pipe for primary air
inlet
Check contamination and
draft of the flue drain and
funnel
Contact the service center
Description
Possible solution of causes
The stove is not receiving electrical power (led
indicator not lit)
The power cable could be damaged or else could be disconnected frok
the electrical outlet
The fuse inside the circuit board may have burnt out (in this case,
request technical assistance)
Repeated failed ignitions take place
The combustion chamber may not have been subjected to regular
maintenance (see section 5.1.3.4)
The ignition heating element or smoke temperature sensor may have
malfuncioned (in this case, request technical assistance)
