ALFAtron PA100V User manual

40W Power Amplifier

40W Power Amplifier
2
Safety Operation Guide
In order to guarantee the reliable operation of the equipment and safety of the staff,
please abide by the following in installation, using and maintenance:
1) The system must be earthed properly. Please do not use two blade plugs and
ensure the alternating power supply ranged from 100v to 240v and from 50Hz to
60Hz.
2) Do not put the switcher in extreme temperatures.
3) As the power generates heat when running, the working environment should be
maintained with good ventilation, in case of damage caused by overheating.
4) Please turn off the general power switch in humid weather or if left unused for long
periods of time.
5) Before following operation, ensure that the alternating current wire is pull out of the
power supply:
Take off or reship any components of the equipment.
Take off or rejoin any pin or other link of the equipment.
6) As to non-professional or without permission, please DO NOT try to open the casing
of the equipment, DO NOT repair it on your own, in case of accident or increasing
the damage of the equipment.
7) DO NOT splash any chemicals or liquid onto the equipment.
8) NOTICE: Please read this user manual carefully before using this product. Pictures
shown in this manual are for reference only, different model and specifications are
subject to real product.
This manual is for operation instruction only, not for any maintenance usage. Any
changes of functions and parameters will be informed separately. Please refer to
the dealers for the latest details.
All rights reserved. No part of this publication may be copied or reproduced
without permission.

40W Power Amplifier
Table of Contents
1. Introduction.................................................................................................................1
1.1 Introduction to PA100V Power Amplifier............................................................1
1.2 Features ............................................................................................................1
1.3 Package Contents .............................................................................................1
2. Panel Description........................................................................................................2
2.1 Front Panel........................................................................................................2
2.2 Introduction of Rear Panel.................................................................................3
3. System Connection.....................................................................................................4
3.1 Usage Precautions ............................................................................................4
3.2 System Diagram................................................................................................4
3.3 Audio Signal Connection....................................................................................4
3.3.1 Audio Output............................................................................................4
3.3.2 Audio Inputs.............................................................................................5
3.4 System Applications...........................................................................................6
4. System Operations .....................................................................................................6
4.1 Operations of Front Panel..................................................................................6
4.1.1 Audio switching........................................................................................6
4.1.2 Volume/EQ controlling.............................................................................7
4.2 Operations of IR Remote...................................................................................7
4.3 Operations of Control Software .........................................................................8
4.3.1 Connection with Computer ......................................................................8
4.3.2 Installation/uninstallation of RS232 Control Software..............................8
4.3.3 Running Environment..............................................................................9
4.3.4 Function Settings.....................................................................................9
4.3.5 RS232 Communication Commands ......................................................10
5. Specifications............................................................................................................12
6. Panel Drawing ..........................................................................................................13
7. Troubleshooting and Maintenance............................................................................14
8. After-sales Service....................................................................................................15

40W Power Amplifier
1
1. Introduction
1.1 Introduction to PA100V Power Amplifier
PA100V Power Amplifier is a 40W Power Amplifier (Class-D) with output alternatively at
70V or 100V. It has 2 stereo inputs (1x3.5mm jack for line in, 2xRCA for L&R), 1 digital
input & 1 balanced MIC. It is integrated with powerful functions, including ducking
function, EQ control, MIC mixer etc, and MIC input supports 3 levels with condenser
MIC, dynamic MIC & line audio input.
As for power amplifier we have normally voltages at 70V and 100V for different
countries, but PA100V is designed to integrate with both voltages to meet different
requirements.
1.2 Features
Mono audio output at 40Watt.
Switchable between 70V and 100V.
Ducking function.
16 ID codes for controlling between different PA100V amplifiers.
3-level MIC input, supports condenser microphone, dynamic microphone and
wireless microphone.
MIC port can support balance/unbalance signal, suppress the external noise
effectively.
Two stereo audio inputs and one digital audio input, switchable by button, IR remote
& RS232.
Volume/Bass/Treble controllable by buttons, IR remote & RS232.
Fast switching speed for good performance.
Convection cooler, fan is not needed.
LED indicator, for power and working status.
Antistatic case design to provide good protection for long-term and stable
performance.
1.3 Package Contents
1 x PA100V Power Amplifier
2 x Mounting ears (separate from PA100V Power Amplifier)
4 x Screws
1 x Pluggable Terminal Block
1 x RS232 cable
1 x Power adapter (DC 24V)

40W Power Amplifier
2
1 x Power Cord
4 x Plastic Cushions
1 x User manual
Note: Ensure the product and the accessories are all included, if not, please contact
the dealers.
2. Panel Description
2.1 Front Panel
Figure 1 Front Panel
No.
Name
Function
①
Audio Input
Selection
To select the input audio source, after choosing the audio
source, the corresponding LED indicator will be on. No.1 is
for dual mono audio input (2 RCAconnectors for L&R), No.2
is for stereo audio input (3.5mm mini jack), and No.3 is for
digital fiber audio input.
②
Audio
Control
Adjust the volume of the MIC, Line, or the level of Bass and
Treble with this button
③
Volume
Adjustment
To turn up/down or mute the corresponding audio.
▽: Turn down the volume
△: Turn up the volume
MUTE: Mute the output

40W Power Amplifier
3
2.2 Rear Panel
Figure 2 Rear Panel
No.
Name
Function
①
Power
Indicator
Turns red when power on.
②
Microphon
e input port
3-pole captive screw connector for microphone input, the dial
switch in right side is to select the micro input kind, including
48V (for condenser microphone), MIC (for dynamic
microphone) and LINE (for line audio).
③
Audio
Inputs
3.5mm mini jack for stereo audio input, it can be connected to
audio source device such as DVD player.
④
ID Code
16 codes range from 0 to F (hexadecimal), works together with
the PC control software.
⑤
IR
To connect with the IR receiver, works together with the IR
remote.
⑥
Power Port
To connect with the power adapter (DC24V).
⑦
2 x RCA
Dual-mono audio input, which can be connected with audio
source device such as a PC.
⑧
Digital
Audio Input
Fiber connector for digital audio input (PCM format only), it can
be connected with a device with fiber port, such as blue-ray
player.
⑨
RS232
3-pole captive screw connector for serial control, it can be
connected with PC (Use a 3-pole captive to 9 pin female D
connector and serial control software) to control PA100V
Power Amplifier.
⑩
Audio
Output
To connect with audio output devices, such as speakers (To
select 70V or 100V depends on the input voltage of the
speakers). COM is for grounding (GND).

40W Power Amplifier
4
3. System Connection
3.1 Usage Precautions
1) Do not use this without having load ( speakers) connected.
2) Speakers must be connected before power on.
3.2 System Diagram
Figure 3 System Diagram
3.3 Audio Signal Connection
3.3.1 Audio Output
PA100V Power Amplifier supports mono audio output, and the output voltage is 70V or
100V. The end COM is for grounding. The amplifier to be connected is mono audio
output with a rated power at 40Watt, so PA100V Power Amplifier can be connected with
several speakers in parallel connection(Total power mustn’t be more than 40Watt).
The following figure shows us how to connect the speakers. Here we take the
100V/10W speakers as an example.
MIC
PC 1
Blu-ray
DVD
Speaker
Speaker
Speaker
Speaker
PC
(100V/10W)
(100V/10W)
(100V/10W)
(100V/10W)
IR Remote
IR Receiver

40W Power Amplifier
5
Figure 4 Audio Output Connection
Note: Speakers to be connected should be with constant pressure.
3.3.2 Audio Inputs
PA100V Power Amplifier provides with 2 stereo audio inputs, one microphone input and
one digital fiber audio input. The following figure shows the audio input ports.
Figure 5 Audio Input Ports
48V phantom power input
When the switch turns to “48V” (It has a good frequency characteristic, high input
impedance and high sensitivity in this mode), the MIC input will provide a 48V phantom
power. This is usually used for power supply for condenser microphone, Connection is:
“+” connects to positive, “-” connects to negative and “ ” to ground.
Note: In this mode, only condenser microphone can be connected.
MIC input
When the switch turns to “MIC” (It has a low frequency characteristics, and wide
frequency response in this mode), the microphone input is used for connecting with
dynamic microphone. There are two different connections:
a) Unbalanced connection:
“+” and “ ” connect to ground, and “-” connects to signal.
COM 70V 100V
Speaker Speaker Speaker Speaker
(100V/10W)
(100V/10W)
(100V/10W)
(100V/10W)
Dial Switch, to select the MIC input mode,
includes MIC (dynamic microphone), 48V
(condenser microphone) and LINE
(normal audio or wireless microphone).

40W Power Amplifier
6
“-”and “ ” connect to ground, and “+” connects to signal.
b) Balanced connection: “+” connects to positive, “-” connects to negative and “ ”
connects to ground.
LINE input
When the switch turns to “LINE” (It has a low frequency characteristics, and wide
frequency response in this mode), the microphone input is used for connecting with
normal audio or wireless microphone output. There are two different connections:
a) Unbalanced connection:
“+” and “ ” connect to ground, and “-” connects to signal.
“-”and “ ” connect to ground, and “+” connects to signal.
b) Balanced connection: “+” connects to positive, “-” connects to negative and “ ”
connects to ground.
Digital Audio Input
PA100V Power Amplifier has a fiber optical port to connect with digital audio source
device. With the SPF optical fiber, the audio signal can be transmitted faster, more
stable, reliable, and can be transmitted over a long distance without distortion.
Notice: This digital audio input can support/decode PCM format signal only. If the
CD/DVD is DTS or AC3 format, please set the player to PCM format output before
connecting to PA100V Power Amplifier.
3.4 System Applications
PA100V Power Amplifier can be applied in different occasions, such as classroom,
small meeting room, lecture hall, bar and hotel etc.
4. System Operations
4.1 Operations of Front Panel
The buttons provides the control of volume/EQ control and switching. The LED
indicator will show the connecting status. The following content introduces audio
switching and EQ control in detail.
Operations: Press the corresponding button again for cyclic switching.
4.1.1 Audio switching
There are three switchable audio inputs, one 2xRCA input, one 3.5mm jack input, and
one digital fiber audio input, switchable through the buttons as below:
Figure 6 Audio Source Selection Button
Audio Source Selection:
1: Dual mono audio
2: Stereo audio
3: Digital fiber audio.

40W Power Amplifier
7
4.1.2 Volume/EQ controlling
The line volume and MIC volume can be controlled by the buttons.
The MIC Volume/LINE volume/LINE bass/LINE treble will be selected by the buttons,
and controlled up/down/mute by the function buttons. Please check the picture below:
Figure 7 Audio Mode and Volume Adjustment buttons
For example, to turn up the line volume, you should select the “LINE” first, and then
press the button “ ”.
4.2 Operations of IR Remote
PA100V Power Amplifier provides with an IR eye, with the IR Receiver and the IR
remote, user can control PA100V Power Amplifier remotely.
Notice: The IR Receiver and the IR remote are all offered for charge.
Figure 8 IR Remote
Audio Mode Switching
Volume Adjustment:
▽: Turn down the volume
△: Turn up the volume
MUTE: Mute the output
Mute Mode:
MIC: Mute the
microphone volume.
LINE: Mute the line
volume.
SPEAKER: Unmute
Use to transmit the
infrared signal send by
the remote controller.
Audio Controlling Modes
MIC: turn up/down the
microphone volume.
LINE: turn up/down the line
volume.
BASS: bass tuning
TREBLE: treble of line
volume.
Audio Source Selection:
1:2 RCA dual-mono audio
input
2:1 3.5mm jack
3: 1 Digital fiber audio input

40W Power Amplifier
8
Figure 9 IR Receiver
4.3 Operations of Control Software
4.3.1 Connection with Computer
When the amplifier connects to the COM1 or COM2 of the computer with control
software, users can control it by that computer.
To control the amplifier, users should use a 3-pole male captive screw to 9-pin HD
female connector and use the public COM software.
Figure 10 Connection of RS232 Port
4.3.2 Installation/uninstallation of RS232 Control Software
Installation
Connect the input source devices and the output device according to the system
diagram.
Copy the RS232 control software to one computer, and then connect the RS232
port of this computer and PA100V Power Amplifier.
Double-click the EXE program to execute the software.
Here we take the software CommWatch.exe as example. The icon is showed as
below:
Figure 11 Control Software
IR receiver, works together
with the IR remote. Please
point the IR remote at the IR
receiver when use, to avoid
getting out of control as there
is no signal detected.
3.5mm jack
Insert it into the
specialized PA3
socket (3.5mm), to
connect the IR
receiver with PA3.

40W Power Amplifier
9
Uninstallation Delete all the control software files in corresponding file path.
4.3.3 Running Environment
While the control software is installed, we can activate the software through the RS232
port and set the parameters, to make it able to send RS232 commands to control
PA100V Power Amplifier.
4.3.4 Function Settings
With the control software, we can easily switch the input channel, mute the output,
check the working status, and adjust the volume etc. Please refer the details in RS232
Communication Commands.
The interface of the control software is showed as below:
Figure 12 Main Interface of Control Software
Parameter Configuration area
Monitoring area, indicates if
the command sent works.
Command Sending area

40W Power Amplifier
10
4.3.5 RS232 Communication Commands
Communication Protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
Command
Function Description
Feedback Code
1A1.
Switching the audio to input 1
A: 1 -> 1
2A1.
Switching the audio to input 2
A: 2 -> 1
3A1.
Switching the audio to input 3
A: 3 -> 1
0A0.
Mute Audio of MIC and Line out
Mute
1A0.
Mute audio of MIC
Mute MIC
2A0.
Mute audio of line out
Mute LIN
3A0.
Enable noise gate.
Gate On
4A0.
Disable noise gate.
Gate Off
0A1.
Unmute Audio
Unmute Audio
600%
Checking the working status
A: 1 -> 1
Volume of MIC : 50
Volume of LINE : 50
Bass of LINE : 4
Treble of LINE : 4
Ducking Off
601%
MIC volume up
Volume of MIC: 51
602%
MIC volume down
Volume of MIC: 51
603%
Line volume up
Volume of LINE: 51
604%
Line volume down
Volume of LINE: 51
605%
Bass level up
Bass of LINE: 4
606%
Bass level down
Bass of LINE: 4
607%
Treble level up
Treble of LINE: 4
608%
Treble level down
Treble of LINE: 4
609%
Initialization, back to the default setting
Init OK
610%
Enable/disable the ducking function.
Ducking off/Ducking on
4[x][x]%
Preset the volume level of ducking
function. [xx] Arranges from [00] to [60].
61 degrees in total.
Ducking of LINE: 50
5[x][x]%
Preset MIC volume, [xx] arranges from
[00] to [60]. 61 degrees in total.
Volume of MIC: 50
7[x][x]%
Preset line volume, [xx] arranges from
[00] to [60]. 61 degrees in total.
Volume of LINE: 50
8[x][x]%
Preset the bass level, [xx] arranges from
[00] to [08]. 9 degrees in total.
Bass of LINE: 4
9[x][x]%
Preset the treble level, [xx] arranges from
[00] to [08]. 9 degrees in total.
Treble of LINE: 4

40W Power Amplifier
11
Notice:
1. The letter inside bracket [ ] is the variable code, which is changeable.
2. The bracket [ ] is not included to the RS232 commands.
3. Any dot “.” after the letters is part of the commands.
4. Ducking function:
When input with MIC, the volume of the line audio will be automatically turned down
to the preset volume level, if there is no input MIC audio signal after 5 seconds,
then the volume will be automatically turned up to the original one. If you need to
disable/enable the ducking function, just send the command “610%”again.
5. ID coding
The ID codes of PA100V Power Amplifier ranges from 0 to F (hexadecimal), when
sending RS232 commands, please take notice of the address of the ID code.
If the address of the ID code is 0, any RS232 command is available.
If the address is in 1~F, it has one unique ID code (If the ID code is not the same
with the address, no RS232 command will work).
While the ID code is in 1~F, please add “ID/” before sending the command.
For example, if the ID code is 5, the RS232 command needed is “604%”, the
correct command is in this format: 5/604%.
There is no need to add “ID/” before the command when the ID code is 0.
Examples:
1) Switching the input 2 to the line out, the command is: 2A1.
2) Turning up the volume of line audio, the command is: 603%
3) Preset the MIC volume to “21” degree, the command is: 521%
4) Checking the working status of PA100V Power Amplifier, the command is: 600%
5) If the ID code is 0, sending command 601% is able to turn up the MIC volume.
If the ID code is 2, sending command 601% will not work, and the MIC volume
remains unchanged. The right command is 2/601%.

5. Specifications
Audio Input
Audio Output
Input
2stereo audio
1MIC
1Digital fiber audio
Output
1mono amplifier
Input
Connector
2RCA
13.5mm jack
13-pole 3.81mm
captive screw
connector
1SPF fiber connector
Output
Connector
13-pole 3.81mm
captive screw
connector
Input
Impedance
>10KΩ
Output Type
Constant voltage 70V
or 100V.
Audio General
Frequency
Response
120Hz ~ 20KHz
CMRR
>70dB@20Hz~20KHz
SNR
80dB (Max)
Bandwidth
120Hz ~ 20KHz
Rated Power
Output
40Watt
THD + Noise
1%@1KHz,
0.3%@20KHz at
nominal level
Voltage Gain
26dB
Control Function
RS232 Control
13-pole 3.81mm
captive screw
connector
Front Panel
Control
buttons
ID Code
Control
16 ID codes for control.
Optional
IR remote & TCP/IP controlled by PTNET(PTN's programmable
interface)
General
Temperature
-10 ~ +40℃
Humidity
10% ~ 90%
Power
Supply
DC 24V power
adapter
Standby
Power
Consumption
5W
Case
Dimension
W130 x H44 x
D144mm (1U high)
Product
Weight
0.86Kg

6. Panel Drawing
Figure 13 Panel Drawing

7. Troubleshooting and Maintenance
Problems
Causes
Solutions
No output audio
No signal at input/ output
end
Check input/ output signal
by an oscilloscope or a
multi-meter.
Failed cable connection
Change for another cable.
Broken unit
Send it to the dealer for
repair.
POWER indicator doesn’t
work or no response from
unit.
Failed power connection
Make sure the power cord
connection is good
Static becomes stronger
when connecting the
video connectors
Bad grounding
Check the grounding and
make sure it is connected
well.
Interference on audio
output
Cannot control the device
by front panel buttons,
RS232 port or IR remote
Broken unit
Send it to the dealer for
repair
If your problem persists after following the above troubleshooting steps, seek further
help from authorized dealer or our technical support.

8. After-sales Service
1) If there are some problems when running PA100V Power Amplifier, please check
and deal with the problems reference to this user manual.Any transport costs are
borne by the users during the warranty.
2) You can email to our after-sales department or make a call, please tell us the
following information about your cases.
Product Limited Warranty: We warrant that our products will be free from defects
in materials and workmanship for Five years, which starts from the first day the
product leaves warehouse (check the SN mark on the product).
Proof of purchase in the form of a bill of sale or receipted invoice must be presented
to obtain warranty service.
What the warranty does not cover:
Warranty expiration.
Factory applied serial number has been altered or removed from the product.
Damage, deterioration or malfunction caused by:
Normal wear and tear
Use of supplies or parts not meeting our specifications
No certificate or invoice as the proof of warranty.
The product model showed on the warranty card does not match with the
model of the product for repairing or had been altered.
Damage caused by force majeure.
Servicing not authorized
Other causes which does not relate to a product defect
Delivery, installation or labor charges for installation or setup of the product
Technical Support: Email to our after-sales department or make a call, please
inform us the following information about your cases.
Product version and name.
Detailed failure situations.
The formation of the cases.
Remarks: For any questions or problems, please try to get help from your local
distributor.
1. Limited warranty in respect of Alfatron Products Only
1.1 This limited warranty covers defects in materials and workmanship in this product.
1.2 Should warranty service be required, proof of purchase must be presented to the
Company. The serial number on the product must be clearly visible and not have been
tampered with in any way whatsoever.

1.3 This limited warranty does not cover any damage, deterioration or malfunction
resulting from any alteration, modification, improper or unreasonable use or
maintenance, misuse, abuse, accident, neglect, exposure to excess moisture, fire,
improper packing and shipping (such claims must be presented to the carrier),
lightning, power surges, or other acts of nature. This limited warranty does not cover
any damage, deterioration or malfunction resulting from the installation or removal of
this product from any installation, any unauthorized tampering with this product, any
repairs attempted by anyone unauthorized by the Company to make such repairs, or
any other cause which does not relate directly to a defect in materials and/or
workmanship of this product. This limited warranty does not cover equipment
enclosures, cables or accessories used in conjunction with this product.
This limited warranty does not cover the cost of normal maintenance. Failure of the
product due to insufficient or improper maintenance is not covered.
1.4 The Company does not warrant that the product covered hereby, including, without
limitation, the technology and/or integrated circuit(s) included in the product, will not
become obsolete or that such items are or will remain compatible with any other
product or technology with which the product may be used.
1.5 Only the original purchaser of this product is covered under this limited warranty.
This limited warranty is not transferable to subsequent purchasers or owners of this
product.
1.6 Unless otherwise specified, the goods are warranted in accordance with the
manufacturer’s product specific warranties against any defect attributable to faulty
workmanship or materials, fair wear and tear being excluded.
1.7 This limited warranty only covers the cost of faulty goods and does not include the
cost of labor and travel to return the goods to the Company’s premises.
1.8 In the event of any improper maintenance, repair or service being carried out by
any third persons during the warranty period without the Company’s written
authorization, the limited warranty shall be void.
1.9 A5 (five) year limited warranty is given on the aforesaid product where used
correctly according to the Company’s instructions, and only with the use of the
Company’s components.
1.10 The Company will, at its sole option, provide one of the following three remedies to
whatever extent it shall deem necessary to satisfy a proper claim under this limited
warranty:
1.10.1 Elect to repair or facilitate the repair of any defective parts within a reasonable
period of time, free of any charge for the necessary parts and labor to complete the
repair and restore this product to its proper operating condition.; or
1.10.2 Replace this product with a direct replacement or with a similar product deemed
by the Company to perform substantially the same function as the original product; or

1.10.3 Issue a refund of the original purchase price less depreciation to be determined
based on the age of the product at the time remedy is sought under this limited
warranty.
1.11 The Company is not obligated to provide the Customer with a substitute unit
during the limited warranty period or at any time thereafter.
1.12 If this product is returned to the Company this product must be insured during
shipment, with the insurance and shipping charges prepaid by the Customer. If this
product is returned uninsured, the Customer assumes all risks of loss or damage
during shipment. The Company will not be responsible for any costs related to the
removal or re-installation of this product from or into any installation. The Company will
not be responsible for any costs related to any setting up this product, any adjustment
of user controls or any programming required for a specific installation of this product.
1.13 Please be aware that the Company’s products and components have not been
tested with competitor’s products and therefore the Company cannot warrant products
and/or components used in conjunction with competitor’s products.
1.14 The appropriateness of the goods for the purpose intended is only warranted to
the extent that the goods are used in accordance with the Company’s installation,
classification and usage instructions.
1.15 Any claim by the Customer which is based on any defect in the quality or condition
of the goods or their failure to correspond with specification shall be notified in writing to
the Company within 7 days of deliver or (where the defect or failure was not apparent
on reasonable inspection by the Customer) within a reasonable time after discovery of
the defect or failure, but, in any event, within 6 months of delivery.
1.16 If delivery is not refused, and the Customer does not notify the Company
accordingly, the Customer may not reject the goods and the Company shall have no
liability and the Customer shall pay the price as if the goods had been delivered in
accordance with the Agreement.
1.17 THE MAXIMUM LIABILITY OF THE COMPANY UNDER THIS LIMITED
WARRANTY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID FOR THE
PRODUCT.
