Alfresco AXESB-2C User manual

AXESB-2C INSTALLATION GUIDE:
MAIN BODY INSTALLATION:
STEP 1:
Remove the Left or Right Side
Table from the ALXE cart.
(for the purpose of this guide the
AXESB-2C will be installed on
right side of the cart.)
The side table is supported by 4
Philips screws (10-32) accessible
from the bottom side.
STEP 2:
Install 4 new 10-32 x 1/2” socket
head screws as well as the
11/16ӯ grommet provided.
(see picture 1)
STEP 3:
Remove the AXESB-2C burner
knobs.
Remove AXESB-2C front panel
by loosening the 2 Philips screws
on the inside top and 2 hex-head
bolts at the bottom.
(see picture 2)
STEP 4:
Install the AXESB-2C side burner
body on the cart by hooking and
latching the body of the burner
onto the cart’s screws installed in
STEP 2. (see picture 3)
Picture 1
Picture 2

STEP 5:
Fasten the screws that the
AXESB-2C has been latched on
with the 5/32” Allen Wrench
provided.
Screws are accessible on the
back at locations A and B
(picture 3) , and locations C and
D on the front. (picture 4)
STEP 6:
Reinstall the AXESB-2C Front
Panel and knobs to complete
the mounting of the body onto
the ALXE Cart by reattaching
the 2 upper screws and 2 lower
bolts shown on step 3.
PIPING CONNECTIONS:
STEP 7:
Prepare the ALXE BBQ gas
connection by removing the
existing 1/2” NPT elbow and
1/2” NPT x 3/8” ODF reducing
nipple (on LP system only) from
the BBQ’s manifold pressure
regulator. (see picture 5).
Picture 3
A
B
Picture 4
C
D
Picture 5
Pressure
Regulator
1/2” NPT
Elbow
1/2” NPT x 3/8” ODF
Reducer Nipple

STEP 8:
Install the new piping assembly
on the ALXE BBQ side
consisting of :
 (1) 1/2” NPT Close Nipple
 (1) 1/2” NPT Tee
 (1) 1/2” NPT x 3/8” OD
Compression Fitting
 3/8” Ø x 42” Flex hose.
For LP systems only, reinstall
the existing:
 1/2” NPT x 3/8” ODF
Reducer
That was removed on STEP 7.
(see picture 6)
STEP 9:
Route the 3/8” Ø x 42”
Flex Hose over the ALXE BBQ’s
Rotisserie Motor Housing and
insert through the 11/16”
grommet installed in STEP 2.
(see picture 7)
STEP 10:
Connect the 3/8” Flex Hose to
the 1/2” NPT x 3/8” OD
Compression Fitting already
installed in the AXESB-2C side
burner unit.
(see picture 8)
FINISHING:
Pressure test all fittings with
soapy water to ensure that no
LP or NG gas leaks are present.
Finish by closing off and re-
installing all panels on the back
sides of the AXESB-2C and the
ALXE BBQ unit.
Your AXESB-2C is ready for
use.
Picture 6
Pressure
Regulator
1/2” NPT
Nipple
1/2” NPT
Tee
1/2” NPT x 3/8”
OD Compression
1/2” NPT x 3/8”
ODF Reducer (LP)
3/8”Ø x 42”
Flex Hose
Picture 7
Rotisserie
Motor
3/8”Ø x 42”
Flex Hose
11/16ӯ
Grommet
Picture 8
Pressure
Regulator
1/2”NPT x 3/8”OD
Compression
3/8”Ø x 42”
Flex Hose
